Q. Li, et al.
LifeSciences261(2020)118433
pH 7.4). The electron donor was NADPH (1 mM), NADH (2 mM) or FAD
(0.1 mM). The anaerobic incubations were performed by pre-gassing of
nitrogen for 2 min. The reaction was initiated by the addition of SNO
with a subsequent 120-min incubation at 37 °C. The role of ferrous ion
in the metabolism of SNO, with an identical concentration of the ferrous
ion in hemoglobin, was also evaluated.
diacetate (DCFH-DA) assay [26]. Raw264.7 cells were seeded in 6-well
plates (1 × 106 cells/well). Cells were incubated for 12 h. Subse-
quently, H2O2 (100 μM) and SNO (10 μM) were incubated with
Raw264.7 cells for 120 min, respectively. Thereafter, the cells were
rinsed three times, followed by the incubation with LPS (0.1 μg/mL) for
24 h. DCFH-DA (10 μM) was then added to each well after the rinse of
the cells, followed by the incubation for 0.5 h. Then, the cells were
collected to determine the fluorescence intensity using a flow cytometer
(Attune NXT, Thermo, USA).
Sample preparation: All the samples were prepared immediately by
the addition of 600 μL of ice-cold I.S.-containing methanol after in-
cubations for 120 min, followed by 3-min vortex mixing and cen-
trifugation at 16,000 ×g for 15 min. The supernatant (300 μL) was
collected and evaporated under nitrogen. The residue was reconstituted
by 100 μL of 30% methanol. After 15-min centrifugation of the mixture
at 16,000 × g, the resulting supernatant was analyzed by UPLC-MS/MS
to quantify the content of SIN formation.
2.6. LC-MS/MS analyses
2.6.1. Scan mode for preliminary identification of the metabolites of SIN
An Agilent 6470 triple quadruple mass spectrometer (Agilent
Technologies, USA) coupled with electrospray ionization (ESI) source
was employed for preliminary identification of the metabolites of SIN.
Chromatographic separations were achieved by a Waters ACQUITY
UPLC BEH C18 column (100 × 2.1 mm, 1.7 μm particles). Mobile
phases consisted of eluents A (0.1% formic acid in water) and B (me-
thanol). A 1-μL aliquot of the sample was injected into and eluted off
the column at a flow rate of 0.3 mL/min. The gradient elution program
was described as follows: 0–1.0 min (3% B), 1.0–10.0 min (3–30% B),
10.0–12.0 min (30–60% B), 12.0–13.0 min (60–3% B), and 13.0–15.0
(3% B). The temperatures of the auto-sampler and column were set at
8 °C and 30 °C, respectively. The optimized MS parameters were shown
as follows: positive-ion mode, gas temperature at 300 °C, gas flow at
5 L/min, nebulizer gas with 45 psi, sheath gas temperature at 250 °C,
sheath gas flow at 11 L/min, nozzle voltage at 500 V, source voltage at
3500 V, and nozzle voltage at 500 V.
2.5. Exploration of the anti-inflammation effects of SIN, DS and SNO and
oxidation property of SNO
2.5.1. Cell culture
Raw 264.7 cells were incubated in DMEM supplemented with 10%
FBS, 50 U/mL penicillin, and 50 μg/mL streptomycin in a humidified
incubator with 5% CO2 and 95% air at 37 °C.
2.5.2. Measurement of IL-6 and TNF-α protein levels by ELISA
RAW 264.7 cells were seeded in 6-well plates (about 1 × 106 cells/
well) and cultured for 12 h, followed by pretreatment with SIN (10, 100
and 200 μM), SNO (10, 100 and 200 μM), DS (10, 100 and 200 μM) and
DEX (25 μM) for 120 min, respectively. Thereafter, LPS (0.1 μg/mL)
was added to the medium with a subsequent incubation for 24 h. The
medium was collected and centrifuged, followed by the determination
of the cytokines using IL-6 and TNF-α ELISA kits based on the manu-
facturer's protocols.
2.6.2. Multiple reaction monitoring (MRM) Mode for quantification of SIN,
DS and SNO
2.5.3. Analysis of TNF-α mRNA levels by RT-PCR
RAW 264.7 cells were seeded in 6-well plates (about 1 × 106 cells/
well) and cultured for 12 h, followed by pretreatment with SNO
(200 μM), DS (200 μM) and DEX (25 μM) for 120 min, respectively. LPS
at 0.1 μg/mL was added to the medium, followed by incubation for
24 h. Total RNA was extracted with TRIzol Reagent, and M-MLV reverse
transcriptase was used to reversely transcribe RNA using random hex-
amers at 37 °C. The diluted transcribed cDNA was mixed with gene-
specific primer and SYBR Green. Changes in gene expression were
analyzed using an RT-PCR machine (QuantStudio 6 Flex System,
Applied Biosystems, USA). The 2−ΔΔCT method was used to calculate
the fold-change of gene expression with GAPDH as the housekeeping
gene. The sequences of primers used were as follows: GAPDH: AGGT
CGGTGTGAACGGATTTG (F) and GGGGTCGTTGATGGCAACA (R);
TNF-α: CAGGCGGTGCCTATGTCTC (F) and CGATCACCCCGAAGTTCA
GTAG (R).
A series 1290 UPLC system coupled with an Agilent 6470 triple
quadruple mass spectrometer (ESI source) was employed for quantifi-
cation of SIN, SNO and DS. Chromatographic separations were achieved
by a Waters ACQUITY UPLC BEH C18 column (100 × 2.1 mm, 1.7 μm
particles). Mobile phases consisted of eluents A (0.1% formic acid in
water) and B (methanol). A 2-μL aliquot of the sample was injected into
and eluted off the column at a flow rate of 0.3 mL/min. The gradient
elution program was described as follows: 0–1.0 min (10% B),
1.0–1.1 min (10–20% B), 1.1–2.0 min (20% B), 2.0–2.1 min (20–30%
B), 2.1–3.0 (30% B), 3.0–3.5 min (30–80% B), 3.5–4.0 (80% B),
4.0–4.5 min (80–10% B), and 4.5–6.0 min (10% B). The temperatures of
the auto-sampler and column were set to be 8 °C and 30 °C, respec-
tively. The optimized MS parameters were shown as follows: positive-
ion mode, gas temperature at 300 °C, gas flow at 5 L/min, nebulizer gas
with 45 psi, sheath gas temperature at 250 °C, sheath gas flow at 11 L/
min, nozzle voltage at 500 V, source voltage at 3500 V, and nozzle
voltage at 500 V. The MRM mode was adopted for quantification of all
the analytes. In detail, SIN: m/z 330.4 → 207.2, Fragmentor 190 V,
Collision energy 38; SNO: m/z 346.2 → 314.2, Fragmentor 135 V,
Collision energy 30; DS: m/z 316.1 → 239.2, Fragmentor 150 V,
Collision energy 30; Propranolol (I.S.): m/z 260.2 → 116.3, Fragmentor
110 V, Collision energy 14.
2.5.4. Evaluation of the nuclear translocation of NF-kB p65 by western
blotting
The cells mentioned in Section 2.5.2 were washed twice. The total
the protein concentrations. Equal amounts (10 μg/lane) of the protein
samples were separated by SDS-PAGE and then transferred onto PVDF
membranes. Subsequently, the membranes were incubated with pri-
mary antibodies and anti-GAPDH overnight at 4 °C after the incubation
of the membranes with 5% BSA for 120 min. After incubation with
horseradish peroxidase-conjugated goat anti-rabbit IgG secondary an-
tibody for 4 h at room temperature, the blots were visualized using an
enhanced chemiluminescent ECL reagent. The protein bands were
quantified by the ChemiDoc XRS gel imaging system (Bio-Rad, USA).
2.7. Statistical analysis
Data were expressed as mean
SD. Statistical analysis was per-
formed using GraphPad Prism software (USA). One-way analysis of
variance (ANOVA) followed by Dunnett's multiple comparisons test was
used to assess the significance among groups. p < 0.05 was considered
statistically significant.
2.5.5. Exploration of the oxidation property of SNO
Intracellular ROS was measured using the 2,7-dichlorofluorescin
4
