Properties of rosin-based waterborne polyurethanes/cellulose nanocrystals composites

Article abstract of DOI:10.1016/j.carbpol.2013.04.010

Polymers from renewable biomass are viable supplements for synthetic polymers. In this study, cellulose nanocrystals (CNs) were used as nanofillers to improve properties of rosin-based waterborne polyurethanes (RWPU). The morphology, structure, thermal, and mechanical properties of the RWPU/CNs nanocomposites were investigated. It demonstrated that CNs were compatible with RWPU and dispersed homogeneously in the polymer matrix. CNs as nanofillers improved tensile strength of RWPU significantly. Tensile strength of RWPU/CNs composite films increased from 28.2 to 52.3 MPa with increasing CNs amount from 0 to 20 wt%. Moreover, the thermal stability of RWPU was also improved by CNs and the glass transition temperature of RWPU/CNs decreased comparing with RWPU. This work provided a novel pathway for preparation of biomass-based WPU with excellent properties from cellulose and rosin.

Full text of DOI:10.1016/j.carbpol.2013.04.010

Accepted Manuscript
Title: Properties of Rosin-Based Waterborne
Polyurethanes/Cellulose Nanocrystals Composites
Author: He Liu Shuqin Cui Shibin Shang Dan Wang Jie Song
PII:
S0144-8617(13)00363-9
DOI:
Reference:
http://dx.doi.org/doi:10.1016/j.carbpol.2013.04.010
CARP 7626
To appear in:
Received date:
Revised date:
Accepted date:
25-2-2013
18-3-2013
9-4-2013
Please cite this article as: Liu, H., Cui, S., Shang, S., Wang, D., & Song, J., Properties
of Rosin-Based Waterborne Polyurethanes/Cellulose Nanocrystals Composites,
Carbohydrate Polymers (2013), http://dx.doi.org/10.1016/j.carbpol.2013.04.010
This is a PDF file of an unedited manuscript that has been accepted for publication.
As a service to our customers we are providing this early version of the manuscript.
The manuscript will undergo copyediting, typesetting, and review of the resulting proof
before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that
apply to the journal pertain.

1
2
Properties of Rosin-Based Waterborne Polyurethanes/Cellulose Nanocrystals Composites
He Liu, a Shuqin Cui, a Shibin Shang,*, a,b Dan Wang a,b, and Jie Song c
3
a Institute of Chemical Industry of Forestry Products, Chinese Academy of Forestry; Key Lab. of
Biomass Energy and Material, Jiangsu Province; National Engineering Lab. for Biomass
Chemical Utilization; Key and Lab. on Forest Chemical Engineering, SFA, Nanjing 210042,
China.
4
5
6
7
b Institute of New Technology of Forestry, Chinese Academy of Forestry, Beijing 100091, China.
c
8
Department of Chemistry and Biochemistry, University of Michigan-Flint, Flint MI 48502,
9
United States.
10
11
12
Corresponding author footnote: 16 Suojin Wucun, Nanjing 210042, China. Tel: +86 25 85482499;
Fax: +86 25 85482499; E-mail:shangsb@hotmail.com
13
14
15
16
17
18
19
20
Highlights:
►Novel rosin-based waterborne polyurethanes and cellulose nanocrystals composites were
prepared.
►Cellulose nanocrystals were compatible with rosin-based waterborne polyurethanes.
►Thermal stability of rosin-based waterborne polyurethanes was improved by cellulose
nanocrystals.
►Tensile strength of waterborne polyurethanes was improved significantly by rosin and cellulose
nanocrystals.
21
1
Page 1 of 16

21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Abstract
Polymers from renewable biomass are viable supplements for synthetic polymers. In this study,
cellulose nanocrystals (CNs) were used as nanofillers to improve properties of rosin-based
waterborne polyurethanes (RWPU). The morphology, structure, thermal, and mechanical
properties of the RWPU/CNs nanocomposites were investigated. It demonstrated that CNs were
compatible with RWPU and dispersed homogeneously in the polymer matrix. CNs as nanofillers
improved tensile strength of RWPU significantly. Tensile strength of RWPU/CNs composite films
increased from 28.2 to 52.3 MPa with increasing CNs amount from 0 to 20 wt%. Moreover, the
thermal stability of RWPU was also improved by CNs and the glass transition temperature of
RWPU/CNs decreased comparing with RWPU. This work provided a novel pathway for
preparation of biomass-based WPU with excellent properties from cellulose and rosin.
Key words: Cellulose Naocrystals, Rosin, Waterborne Polyurethanes, Nanocomposite
1. Introduction
Polyurethanes (PU) are polymeric materials that are widely used in coatings and adhesives
industries, and finding their way into other high performance niche applications (Chattopadhyay
& Raju, 2007). The use of PU is mainly in solvent borne systems. As more people are becoming
more environmentally conscious, research on the development of new coating systems to
minimize volatile organic compounds have been motivated (Noble, 1997). Waterborne
Polyurethanes (WPU) are fully reacted urethane polymers dispersed in water, which shows many
excellent features compared to conventional organic solvent-based polyurethane. However, some
defects, such as low mechanical strength and thermal stability, restrict the application of WPU. In
the past decades, research on high performance WPU focuses on two aspects, molecular design of
WPU and hybridizing with other materials (Ma & Zhang, 2009; Naghash & Abili, 2010; Cao et al.,
2008; Lee & Kim, 2012).
The effective ways to improve the properties of WPU are through chemical modification of
their structures and hybridizing with nanomaterials (Chattopadhyay & Raju, 2007; Althues et al,
2007). Molecular chemical modification is aimed at two aspects, either changing the hard and soft
segments of WPU or introduction of chemical crosslink. In the first aspect, WPU can be described
as block copolymer composed of hard and soft segments. The intrinsic incompatibility or
2
Page 2 of 16

51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
thermodynamic immiscibility between hard and soft segments causes phase separation. Degree of
the hard and soft phase separation plays a vital role in determining the solid-state properties of
WPU. In the second aspect, chemical crosslink produces a three-dimensional network structure of
WPU which restricts the movement of soft segments and reduces macromolecular degradation to a
negligible amount (Cooper & Tobolsky, 1966; Chang et al., 1998). So an appropriate chemical
crosslink is beneficial to improve the mechanic strength and thermal stability of WPU.
Furthermore, the hybridization of WPU and fillers not only improves, but also provides WPU with
some new properties (Althues et al., 2007). A low volume fraction of fillers, especial nanofillers,
can significantly induce change in properties of WPU. Commonly, the fillers can be divided into
two descriptions: inorganic materials like clay (Rahman et al., 2008), silica (Lee et al., 2011),
grapheme (Wang et al., 2012), and zinc oxide (Ma & Zhang, 2009) etc. in nanosize, and organic
polymers like polyacrylate (Song et al., 2004), polyaniline (Chen et al., in press), vinyl
acetate-acrylic (Naghash & Abili, 2010), cellulose (Cao et al., 2009; Wang et al., 2010; Gao et al,
2012), starch (Zou et al, 2011; Lee & Kim, 2012) and chitosan (Nikjea & Tehrania, 2010) etc.
Some of these polymers exist in natural resources, which show numerous benefits to human
beings.
Biomass is an abundant carbon-neutral renewable resource. As a viable supplement to fossil
fuel resources, biomass is available for the production of energy and materials. In the past decade,
numerous research interests are greatly focusing on the hybrid materials consisted of WPU and
natural polymers. Cellulose nanocrystals (CNs), with a high bending strength, a high Young’s
modulus and low density, employed as nanofillers to reinforce WPU was first discussed by Cao
and coworkers (Cao et al., 2007). The WPU/CNs showed a significant increase in tensile strength
from 4.27 to 14.86 MPa with increasing filler content from 0 to 30 wt %. Subsequently, Cao et al.
adopted another method to synthesize a series of new WPU/CNs composites via in situ
polymerization, which induced the grafting part of the pre-synthesized WPU chains on the surface
of CNs. Tensile strength of WPU increased from 4.4 to 9.7 MPa in the condition of the CNs
content range from 0 to 10 wt% (Cao et al., 2009). In addition, some works about CNs, starch, and
chitosan hybridizing with WPU to improve the mechanic strength or thermal stability were carried
out (Gao et al, 2012; Lee & Kim, 2012; Nikjea & Tehrania, 2010). These novel materials are
eco-friendly and biodegradable, which have a broad potential application in various fields.
3
Page 3 of 16

81
82
Therefore, biomass becomes a competitive supplement to high performance WPU materials.
In our previous work, derivatives of pimaric acid which is the most content of rosin reacted
with diols as main chains of WPU (Xu et al, 2011a,b). The hydrophenanthrene moiety, consisting
of fused cycloaliphatic and aromatic structures, provides rosin acids with substantial
hydrophobicity and rigidity. These properties can potentially provide beneficial applications with
improved mechanical properties, thermal stability, and water resistance of rosin-based WPU. We
also prepared CNs/Ag nanoparticles (AgNPs) composites as bifunctional nanofillers within WPU
(Liu et al, 2012). The CNs/AgNPs not only improve the mechanical strength, but it also provides
antimicrobial activity to WPU composites. However, overfilled filling of CNs will reduce the
tensile strength of WPU due to the aggregation of nanofillers. It is proved that the extent of the
reinforcement depends on such factors such as the dispersion of the nanofillers in the polymer
matrix and the interfacial adhesion between nanofillers and polymer matrix (Habibi & Dufresne,
2008; Habibi et al, 2008). Therefore, the compatibility of CNs in rosin-base WPU and properties
of rosin-based WPU/CNs composites are our research interests. In our current work, CNs isolated
from microcrystalline cellulose (MCC) by sulphuric acid hydrolysis incorporated into rosin-based
WPU to be novel composites. Rosin-based WPU (RWPU) was prepared according to our previous
work. RWPU/CNs composites were prepared by casting the mixture of CNs aqueous suspensions
and emulsion of RWPU with various contents. The morphology and performance of RWPU/CNs
composites were investigated and characterized.
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
2. Experimental
2.1. Materials
Rosin was supplied by Wuzhou Pine Chemicals Ltd (Guangxi, China). Polyether glycol N-210
(average molecular weight 1000 g/mol) was obtained from Sinopharm Chemical Reagent Co. Ltd
(Shanghai, China). 2,4-Toluene diisocyanate (TDI) was purchased from Jiangbei Chemical
Reagents Factory (Wuhan, China) and redistilled before use. Dimethylol propionic acid and
dibutyl tin dilaurate of synthetic grade were purchased from First Chemicals of Tianjin (Tianjin,
China). Triethylamine and diethylene glycol (DEG) were from Lingfeng Chemicals of Shanghai
o
(Shanghai, China). The polyol, dimethylol propionic acid and DEG were dehydrated at 100 C in
vacuum for 24 h before use. Sulfuric acid (H2SO4, 98 wt %) and microcrystalline cellulose (MCC)
were purchased from Sinopharm Chemical Reagent Co., Ltd. and used without further
4
Page 4 of 16

111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
purification.
2.2. Synthesis of rosin-based waterborne polyurethane
The preparation of rosin-based waterborne polyurethane (RWPU) was described by our
previous works (Xu et al, 2011a,b). Fumaropimaric acid (FPA) was first synthesized from rosin.
o
Mixture of rosin and fumaric acid was maintained at 220 C for 3 h under a dry nitrogen
atmosphere and weight ratio of rosin and fumaric was 5:1 as well. After cooled to room
temperature, FPA was obtained. Second, fumaropimaric acid polyester polyol (FAPP) was
o
synthesized from FPA (200.0 g) reacting with DEG (76.2 g) at 220 C for 3 h under reduced
pressure. The reaction was terminated when the acid value was reduced to less than 10 mg/g.
Finally, FAPP and polyether glycol N-210 that total weight was 25.0 g and weight ratio was 3:7
reacted with TDI (13.5 g) and dimethylol propionic acid (2.2 g) at 85 oC. Then acetone was slowly
o
added to obtain a homogeneous mixture and maintained at 85 C for 3 h. The prepolymer was
extended by addition of DEG (2.5 g), and allowed to react at 60 oC for 3 h. The mixture was then
neutralised by addition of triethylamine (2.0 g) under stirring at 30 oC for 30 min. Dispersion was
accomplished by slowly adding water (100.8 g) to the neutralized polyurethane solution with
vigorous stirring. After removing the acetone (by evaporation at 35 oC in a rotary evaporator under
reduced pressure), RWPU with about 30 wt% solids content was obtained. WPU with about 30
wt% solids content without rosin was also prepared in the same condition.
2.3. Preparation of Cellulose Nanocrystals
Microcrystalline cellulose (6 g) was mixed with sulfuric acid solution (90 mL, 64 wt %) and the
mixture was stirred vigorously at 40 °C for 2 h. The suspension was then diluted ten times to stop
the reaction. The suspension of pH 2 was obtained by centrifuging and washing the CNs
suspension with water repeatedly. Dialysis was performed to remove free acid in the suspension,
and the result was monitored by checking the neutrality of the dialysis effluent. CNs powder was
finally freezing dried.
2.4. Preparation of RWPU/CNs Nanocomposites Films
The RWPU emulsions (30 wt%) were mixed with aqueous CNs dispersion under sonication for
20 min to obtain suspensions of different compositions. Resulting mixtures were stirred in a rotary
evaporator under vacuum for 15 min to remove residual air and avoid the formation of irreversible
bubbles during evaporation. Resulting mixtures were subsequently cast in Teflon molds and water
5
Page 5 of 16

141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
was evaporated at room temperature. The dry composites films were roasted at 80 °C for 4 h. A
series of nanocomposites films with a thickness of ~0.3 mm were prepared by altering the CNs
content over the range of 0, 5, 10, 15, and 20 wt %, and were denoted as RWPU, RWPU/CNs5%,
RWPU/CNs10%, RWPU/CNs15%, and RWPU/CNs20%, respectively. Prior to characterization,
the resulting films were conditioned at room temperature in a desiccator containing P2O5 with 0%
relative humidity (RH).
2.5. Characterizations
The morphology of CNs was observed by atomic force microscopy (AFM), using a Multimode
SPM (Bruker). AFM samples were typically prepared by dropping the sample suspension on a
mica slice, and AFM images of CNs were obtained by tapping mode. Fourier transform infrared
(FT-IR) spectra were recorded on an iS10 FT-IR Spectrometer (Nicolet). Scanning electron
microscope (SEM) was carried out using a Hitachi S4800, and used to investigate the surface of
RWPU-based films. Thermal gravimetric analysis (TGA) was carried out with a TAQ50 system
from 100 to 600 oC at heating rate of 10 oC/min in air. Differential scanning calorimetry (DSC) of
the films was carried out with a DSC200 PC apparatus (Netzsch, Selb, Germany) under a nitrogen
o
atmosphere. Each sample was subjected to heating/cooling cycles between -50 and 100 C to
obtain reproducible glass transition temperature (Tg) values. The heating rate was 10 oC/min. The
mechanical properties of the RWPU-based films were measured on a universal testing machine
(CMT 6503, Shenzhen SANS Test Machine Co. Ltd., China) and an average value of at least five
replicates for each sample was taken according to the ASTM D412 standard.
3. Result and Discussion
3.1. Morphologies of CNs and RWPU/CNs
An AFM image of CNs deposited from a dilute suspension is shown in Figure 1, from which it
is apparent the suspension contains cellulose fragments. Fragments appear as slender rods of
~10-20 nm in width and ~100-200 nm in length. The surface characterization of RWPU,
RWPU/CNs10%, and RWPU/CNs20% films was carried out by SEM. The SEM images in Figure
2a show that no morphology of CNs is observed in the matrix of the neat RWPU film. In contrast,
the rod-like morphology of CNs is easily identified in Figure 2b and Figure 2c, which are the
surface of RWPU/CNs10% and RWPU/CNs20%, respectively. In our previous work, overfilled
filling of CNs will reduce the tensile strength of WPU due to the aggregation of nanofillers (Liu et
6
Page 6 of 16

171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
al, 2012). However, in the current work, surface of the RWPU/CNs films are smooth and have no
cracks. Our investigation indicates that no CNs sedimentation or flocculation occurred during the
evaporation process. Homogeneous distribution of CNs in the RWPU matrix is observed, which
implies there is good compatibility between the fillers and polymeric matrix.
FT-IR spectra of dried RWPU and RWPU/CNs composites are presented in Figure 3. For
RWPU film, the stretching vibration of N-H bonds formed by interaction of the -NCO group of
TDI with the -OH group on FAPP and polyether glycol N-210 surfaces exhibits a strong
absorption peak centered at around 3298 cm-1 arising from the hydrogen bonding between NH and
carbonyl groups; otherwise the free NH stretching vibration should appear at around 3420 cm-1.
With an increase of the content of CNs in the RWPU matrix, a shoulder peak appears at 3335 cm-1.
This is attributed to the OH stretching vibration of the CNs.
3.2. Thermal Properties of RWPU/CNs composites
The thermal decomposition behavior of RWPU and RWPU/CNs composites are shown in
Figure 4. The RWPU and the CNs composites display a weight loss at temperatures from 100 to
600 oC. Three obvious stages of decomposition appear at the TGA curves. The first stage is from
o
100 to 300 C and weight loss is from 0 to 20 %. The curves of RWPU and RWPU/CNs
composites are similar in this stage, which means that thermal stabilities of RWPU/CNs
composites are as same as RWPU. However, in the second stage, the decomposition temperature
o
alters remarkably from 300 to 375 C, which implies there is a change in the thermal stability of
o
the composites. The 30 % weight loss temperature of RWPU is 307 C, and the temperatures of
o
RWPU/CNs with varying CNs loading level with 10 wt% and 20 wt% are 316 and 334 C,
respectively. This significant enhancement of thermal resistance caused by CNs can be attributed
to the formation of a confined structure in the RWPU/CNs nanocomposites. In the last stage, the
residues’ mass of RWPU/CNs composites are more than RWPU, which is because of the
aromatization of cellulose residue to be graphite.
To further understand the structure and interactions between the two components, DSC studies
of the RWPU and RWPU/CNs nanocomposites were conducted. Figure 5 shows the DSC
thermograms of RWPU matrix and nanocomposites reinforced with varying amounts of CNs. The
values of Tg and the heat capacity change (∆Cp) are shown in Table 1. According to the results, the
o
Tg decreased as the amount of CNs increased and it varied from 22.54 C for neat RWPU to
7
Page 7 of 16

201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
approximately 16.95 oC for RWPU with a 10% CNs loading. The addition of CNs might interrupt
the original interactions between soft segments and hard segments, and improve the microphase
separation in RWPU. This effect can indirectly result in a decrease of Tg of soft segments.
However, comparing with RWPU/CNs10%, the Tg of RWPU/CNs15% and RWPU/CNs20%
o
increased to 17.07 C and 20.80 oC, respectively. This is the opposite effect of CNs in RWPU
matrix. The restricted mobility of RWPU chains neighboring CNs that is due to the
co-crystallization event with those grafted on the surface might be the origin of the shift of Tg
towards higher temperature. Also, it is hypothesized that this co-crystallization could also enhance
the interactions between soft and hard segments; and therefore limits the microphase separation in
RWPU, which could also indirectly result in an increase of Tg of the soft segments of RWPU.
3.3. Tensile strength and elongation at break study
The mechanical behaviors of WPU, RWPU, and composites films reinforced with various
compositions of CNs were investigated by tensile testing at room temperature. Data showing
tensile strength, elongation at break, and Young’s modulus are presented in Table 2. Figure 6
shows the evolution of tensile strength and elongation at break, as a function of CNs content for
the WPU and RWPU matrix composites films, respectively. Pure WPU showed a low tensile
strength of 12.0 MPa, a low Young’s modulus of 27.0 MPa, and a high elongation at break of
about 971%. CNs content has a significant effect on the mechanical properties of WPU. Tensile
strength increased from 12.0 to 29.1 MPa, which represented a ~142% increased, and elongation
at break decreased from 971 to 99%, upon increasing CNs content from 0 to 20 wt% of WPU. So
the Young’s modulus of WPU/CNs composites significantly increased from 27.0 to 457.4 MPa as
compared with pure WPU. This indicated that incorporating CNs into the RWPU matrix resulted
in strong interactions between the filler and matrix, which restricted the matrix motion. RWPU
shows higher tensile strength and lower elongation at break than neat WPU because of the rigid
structure of rosin acid. With increasing CNs content from 0 to 20 wt%, tensile strength of
RWPU/CNs composite films increased from 28.2 to 52.3 MPa and elongation at break decreased
from 267 to 22%. The Young’s modulus of RWPU/CNs composites also increased from 316.2 to
1045.4 MPa as compared with RWPU. Elongation at break of RWPU/CNs decreased greatly with
increasing CNs content because of restriction between CNs and polymer segments. In addition,
tensile strength of RWPU was much higher than most WPU/CNs composites except
8
Page 8 of 16

231
WPU/CNs20%. These results indicated that mechanic properties of WPU composites can be
232
233
234
improved significantly by incorporating CNs and rosin within the WPU matrix.
4. Conclusion
CNs was prepared and used as nanofiller with varying amount to improve the properties of
235
236
237
238
239
240
241
RWPU. SEM and FT-IR results indicated that CNs was dispersed homogeneously within the
RWPU matrix. The filling of CNs into RWPU could lead to a decrease of Tg for RWPU-based
composites and improve the thermal decomposition resistance. Tensile strength of RWPU films
increased significantly with filling CNs. Elongation at break decreased greatly with increasing
CNs content. Comparing with WPU, mechanic properties of RWPU and RWPU/CNs composites
were both improved significantly. The results indicated that incorporation with bio-resource, like
rosin and CNs, are valuable for the WPU applications.
242
Acknowledgements
243
244
We gratefully acknowledge the financial support from the National Natural Science Foundation
of China (Grant No. 31070519).
245
246
Reference
Althues, H., Henle, J., & Kaskel, S., (2007). Functional inorganic nanofillers for transparent
247
248
249
250
251
252
253
254
255
256
257
258
polymers. Chemical Society Reviews, 36, 1454-1465.
Cao, X. D., Chang, P. R., & Huneault, M. A., (2008). Preparation and properties of plasticized
starch modified with poly(ε-caprolactone) based waterborne polyurethane. Carbohydrate
Polymers, 71, 119-125.
Cao, X. D., Dong, H., & Li, C. M., (2007). New nanocomposite materials reinforced with flax
cellulose nanocrystals in waterborne polyurethane. Biomacromolecules, 8, 899-904.
Cao, X. D., Habibi, Y., & Lucia, L. A., (2009). One-pot polymerization, surface grafting, and
processing of waterborne polyurethane-cellulose nanocrystal nanocomposites. Journal of
Materials Chemistry, 19, 7137-7145.
Chang, S. L., Yu, T. L., Huang, C. C., Chen, W.C., Linliu, K., & Lin, T. L., (1998). Effect of
polyester side-chains on the phase segregation of polyurethanes using small-angle X-ray
scattering. Polymer, 39, 3479-3489.
9
Page 9 of 16

259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
Chattopadhyay, D. K., & Raju, K. V. S. N., (2007). Structural engineering of polyurethane
coatings for high performance applications. Progress in Polymer Science, 32, 352-418.
Chen, C. H., Kan, Y. T., Mao, C. F., Liao, W. T., & Hsieh, C. D., Fabrication and characterization
of water-based polyurethane/polyaniline conducting blend films. Surface & Coatings
Technology, doi:10.1016/j.surfcoat.2012.03.056.
Cooper, S. L., & Tobolsky, A. V., (1966). Properties of linear elastomeric polyurethanes. Journal
of Applied Polymer Science, 10, 1837-1844.
Gao, Z. Z., Peng, J., Zhong, T. H., Sun, J., Wang, X. B., & Yue, C., (2012). Biocompatible
elastomer of waterborne polyurethane based on castor oil and polyethylene glycol with
cellulose nanocrystals. Carbohydrate Polymers, 87, 2068-2075.
Habibi, Y., & Dufresne, A., (2008). Highly filled bionanocomposites from functionalized
polysaccharide nanocrystals. Biomacromolecules, 9, 1974-1980.
Habibi, Y., Goffin, A. L., Schiltz, N., Duquesne, E., Dubois, P., & Dufresne, A., (2008).
Bionanocomposites
based
on
poly(ε-caprolactone)-grafted
cellulose
nanocrystals by ring-opening polymerizatio. Journal of Materials Chemistry, 18, 5002-5010.
Lee, S. J., & Kim, B. K., (2012). Covalent incorporation of starch derivative into waterborne
polyurethane for biodegradability. Carbohydrate Polymers, 87, 1803-1809.
Lee, S. K., Yoon, S. H., Chung, I., Hartwig, A., & Kim, B. K., (2011). Waterborne polyurethane
nanocomposites having shape memory effects. Journal of Polymer Science Part A: Polymer
Chemistry, 49, 634-641.
Liu, H., Song, J., Shang, S. B., Song, Z. Q., & Wang, D., (2012). Cellulose nanocrystal/silver
nanoparticle composites as bifunctional nanofillers within waterborne polyurethane. ACS
Applied Materials & Interfaces, 4, 2413-2419.
Ma, X. Y., & Zhang, W. D., (2009). Effects of flower-like ZnO nanowhiskers on the mechanical,
thermal and antibacterial properties of waterborne polyurethane. Polymer Degradation and
Stability, 94, 1103-1109.
Naghash, H. J., & Abili, B., (2010). Synthesis of a silicone containing allylic monomer and its
uses in the waterborne polyurethane/vinyl acetate–acrylic hybrid emulsion copolymers.
Progress in Organic Coatings, 69, 486-494.
Nikjea, M. M. A., & Tehrania, Z. M., (2010). Synthesis and characterization of waterborne
10
Page 10 of 16

289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
polyurethane-chitosan nanocomposites. Polymer-Plastics Technology and Engineering, 49,
812-817.
Noble, K. L., (1997). Waterborne polyurethanes. Progress in Organic Coatings. 32, 131-136.
Rahman, M. M., Kim, H. D., & Lee, W. K., (2008). Preparation and characterization of
waterborne polyurethane/clay nanocomposite: Effect on water vapor permeability. Journal of
Applied Polymer Science, 110, 3697-3705.
Song, C. M., Yuan, Q. L., & Wang, D. N., (2004). Effect of the content of urea groups on the
particle size in water-borne polyurethane or polyurethane/polyacrylate dispersions. Colloid
and Polymer Science, 282, 642-645.
Wang, X., Xing, W. Y., Song, L., Yang, H. Y., Hu, Y., & Yeoh, G. H., (2012). Fabrication and
characterization of graphene-reinforced waterborne polyurethane nanocomposite coatings by
the sol-gel method. Surface and Coatings Technology, 206, 4778-4784.
Wang, Y. X., Tian, H. F., & Zhang, L. N., (2010). Role of starch nanocrystals and cellulose
whiskers in synergistic reinforcement of waterborne polyurethane. Carbohydrate Polymers,
80, 665-671.
Xu, X., Shang, S. B., Song, Z. Q., Cui, S. Q., Wang, H. X., & Wang, D., (2011). Preparation and
characterization of rosin-based waterborne polyurethane from maleopimaric acid polyester
polyol. BioResources, 6, 2460-2470.
Xu, X., Song, Z. Q., Shang, S.B., Cui, S. Q., & Rao, X. P., (2011). Synthesis and properties of
novel rosin-based water-borne polyurethane. Polymer International, 60, 1521-1526.
Zou, J. W., Zhang, F., Huang, J., Chang, P. R., Su, Z. M., & Yu, J. H., (2011). Effects of starch
nanocrystals on structure and properties of waterborne polyurethane-based composites.
Carbohydrate Polymers, 85, 824-831.
313
314
11
Page 11 of 16

314
315
Figure Captions
316
317
318
319
320
321
322
323
324
325
326
Fig. 1. AFM image of CNs
Fig. 2. Surface morphologies of RWPU films with different content of CNs, 0 wt% (a), 10 wt%
(b), and 20 wt% (c).
Fig. 3. FT-IR spectra of RWPU (a), RWPU/CNs5% (b), RWPU/CNs10% (c), RWPU/CNs15% (d),
and RWPU/CNs 20%(e).
Fig. 4. TGA thermograms of RWPU (a), RWPU/CNs10% (b), and RWPU/CNs20% (c).
Fig. 5. DSC thermograms of RWPU and RWPU/CNs nanocomposites with different CNs loading:
RWPU (a), RWPU/CNs5% (b), RWPU/CNs10% (c), RWPU/CN15% (d), and RWPU/CNs20%
(e).
Fig. 6. Tensile strength and elongation at break of WPU (a) and RWPU (b) film incorporating with
varying amount of CNs.
327
328
12
Page 12 of 16

328
329
Tables
330
331
Table 1. Data showing of RWPU-based films: Glass transition temperature (Tg), Heat Capacity
Change (∆Cp),
Tg
∆Cp (J g-1
K-1)
Sample
(°C)
RWPU
22.54
17.13
16.95
17.07
20.80
0.64
RWPU/CNs5 %
RWPU/CNs10 %
RWPU/CNs15 %
RWPU/CNs20 %
0.64
0.60
0.74
0.63
332
333
Table 2. Data showing of WPU and RWPU composites films: Tensile Strength (σB), Elongation at
Break (ε), and Young’s modulus (E)
334
σB
(MPa)
12.0
16.0
19.4
23.4
29.1
28.2
35.0
38.8
46.0
52.3
E
sample
ε (%)
(MPa)
27.0
WPU
971
429
253
144
99
WPU/CNs5%
WPU/CNs10%
WPU/CNs15%
WPU/CNs20%
RWPU
136.1
246.2
336.9
457.4
316.2
509.3
699.3
814.8
1045.4
267
167
83
RWPU/CNs5%
RWPU/CNs10%
RWPU/CNs15%
RWPU/CNs20%
45
22
335
336
337
338
339
340
341
342
343
13
Page 13 of 16

343
344
Images
345
346
347
Fig. 1. AFM image of CNs
348
349
350
14
Page 14 of 16

351
Fig. 2. Surface morphologies of RWPU films with different content of CNs, 0 wt% (a), 10 wt%
352
353
(b), and 20 wt% (c).
354
355
Fig. 3. FT-IR spectra of RWPU (a), RWPU/CNs5% (b), RWPU/CNs10% (c), RWPU/CNs15% (d),
356
357
and RWPU/CNs 20%(e).
358
359
Fig. 4. TGA thermograms of RWPU (a), RWPU/CNs10% (b), and RWPU/CNs20% (c).
360
361
362
363
Fig. 5. DSC thermograms of RWPU and RWPU/CNs nanocomposites with different CNs loading:
364
RWPU (a), RWPU/CNs5% (b), RWPU/CNs10% (c), RWPU/CN15% (d), and RWPU/CNs20%
15
Page 15 of 16

365
366
(e).
367
368
Fig. 6. Tensile strength and elongation at break of WPU (a) and RWPU (b) film incorporating with
369
varying amount of CNs.
370
371
372
16
Page 16 of 16
