Chloro({2-[mesityl(quinolin-8-yl-κN)boryl]-3,5-dimethylphenyl}methyl-κC)palladium(II) as a catalyst for heck reactions

Article abstract of DOI:10.3390/molecules200712979

We recently reported an air and moisture stable 16-electron borapalladacycle formed upon combination of 8-quinolyldimesitylborane with bis(benzonitrile)dichloropalladium(II). The complex features a tucked mesityl group formed upon metalation of an ortho-m

Full text of DOI:10.3390/molecules200712979

Molecules 2015, 20, 12979-12991; doi:10.3390/molecules200712979
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Chloro({2-[mesityl(quinolin-8-yl-κN)boryl]-3,5-dimethyl-
phenyl}methyl-κC)palladium(II) as a Catalyst for
Heck Reactions
Sem Raj Tamang and James D. Hoefelmeyer *
Department of Chemistry, University of South Dakota, 414 E. Clark St., Vermillion, SD 57069, USA;
E-Mail: sem.tamang@coyotes.usd.edu
* Author to whom correspondence should be addressed; E-Mail: jhoefelm@usd.edu;
Tel: +1-605-677-6186; Fax: +1-605-677-6397.
Academic Editor: Derek J. McPhee
Received: 1 May 2015 / Accepted: 15 July 2015 / Published: 17 July 2015
Abstract: We recently reported an air and moisture stable 16-electron borapalladacycle formed
upon combination of 8-quinolyldimesitylborane with bis(benzonitrile)dichloropalladium(II).
The complex features a tucked mesityl group formed upon metalation of an ortho-methyl
group on a mesityl; however it is unusually stable due to contribution of the boron pz orbital
in delocalizing the carbanion that gives rise to an η4-boratabutadiene fragment coordinated to
Pd(II), as evidenced from crystallographic data. This complex was observed to be a highly
active catalyst for the Heck reaction. Data of the catalyst activity are presented alongside data
found in the literature, and initial comparison reveals that the borapalladacycle is quite active.
The observed catalysis suggests the borapalladacycle readily undergoes reductive elimination;
however the Pd(0) complex has not yet been isolated. Nevertheless, the ambiphilic ligand
8-quinolyldimesitylborane may be able to support palladium in different redox states.
Keywords: Heck reaction; catalysis; organometallic; palladium; frustrated Lewis pair;
non-classical ligand
1. Introduction
Palladium catalyzed Heck reactions have become an indispensable tool for the synthesis of organic
molecules [1–3]. The Heck reaction is a C-C coupling, most commonly with an aryl halide and an alkene

Molecules 2015, 20
12980
as reactants (Scheme 1). In the palladium catalyzed reaction, the aryl halide undergoes oxidative addition
to a coordinatively unsaturated Pd(0) fragment, followed by 1,2-insertion of the alkene into the Pd-C
bond and β-hydride elimination to form the coupled η2-alkene, and finally reductive elimination of H-X
to regenerate the active Pd(0) fragment. A stoichiometric amount of base is required to neutralize the
H-X product. The first palladium catalysts were simple Pd(II) salts, PdCl2 or Pd(OAc)2. In the course
of the reaction, Pd(II) must be reduced to Pd(0) in order to achieve facile oxidative addition of the aryl
halide. Ligands could be introduced to stabilize Pd(0) as molecular species and avoid precipitation
of the bulk metal. Phosphines are known to stabilize Pd(0), and complexes can be isolated such as
Pd(PPh3)4 [4], Pd(P(tBu)3)3 [5], and Pd(PCy3)3 [6]. As a result, phosphines have been a popular choice
as a ligand; though, numerous examples of Pd-catalyzed Heck coupling with non-phosphine ligands are
known [7–14]. In an effort to arrive at nucleophilic, coordinatively unsaturated Pd(0) centers, the
preparation of pre-formed L2Pd catalysts with bulky, basic ligands such as phosphines and N-heterocyclic
carbenes have been an active area of work [1–3]. The steric and electronic properties of these ligands can
be varied upon changing the substituents, and the shape of the ligands can impart stereoselectivity or
regioselectivity in the catalysis. Also of interest, bent, low-coordinate, nucleophilic metals are more
active towards oxidative addition [15], and this may become a new design strategy for future catalysts.
Scheme 1. Mechanism of the palladium-catalyzed Heck reaction.
There has been a recent surge of interest in frustrated Lewis pairs (FLPs) that feature Lewis
acid-Lewis base combinations that are unable to approach closely to form a strong dative bond to one
another [16–18]. The frustrated state can be relieved in the presence of appropriate small molecules
that undergo heterolytic bond dissociation or ambiphilic molecular fragments (Scheme 2). For example,
classic papers from the Stephan lab show that molecular hydrogen undergoes heterolytic cleavage
with frustrated phosphine-borane combinations [19,20], and contributed a dramatic increase in interest in
the FLP field. Since those findings, it has been shown that several small molecules undergo heterolytic
bond dissociation (or severe polarization) in the presence of an FLP, such as CO2 [21–26], HX [27],
X2 [28,29], M-X [30], RS-SR [31]. The stabilization of ambiphilic molecules or fragments with a FLP
is less explored. The most widely studied examples utilize a unimolecular preorganized FLP as an L-Z
ligand to stabilize a transition metal in low oxidation state [32,33]. In this configuration, the Lewis base

Molecules 2015, 20
12981
is formally a neutral two-electron donor (L) to the metal and the Lewis acid is a two-electron acceptor
(Z). There is only appreciable contribution of electron density from the metal to the Lewis acid if the
metal is in low oxidation state.
Scheme 2. Selected examples of reactions that relieve frustration in FLP molecules via
heterolytic bond dissociation or complexation with an ambiphilic guest.
The use of L-Z ligands to stabilize palladium may be an interesting avenue of investigation, especially
considering the potential utility of such complexes for catalysis of C-C coupling reactions. A handful of
L-Pd-Z examples exist that will be briefly introduced here with structures represented in Figure 1. The
molecule [Me2P(CH2)2]3B was combined with Pd(PPh3)4 and led to formation of a complex (1) with
tridentate coordination of the ambiphilic ligand to Pd(0) via phosphorus donor atoms; however the role
of boron in stabilizing the Pd(0) center was difficult to establish without structural information [34].
Combination of Pd(OAc)2 with tris(2-mercapto-1-R-imidazolyl)hydroborate gave {[μ-κ1,κ3-B(mimtBu)3]Pd}2
(2) [35]. Treatment with PMe3 gave a monomeric [κ4-B(mimtBu)3]Pd(PMe3) complex (3). The dimeric
complex 2 features Pd-B bond length of 2.073(4) Å and the monomeric complex 3 has Pd-B bond
length of 2.050(8) Å. The triphosphine-borane ligand [o-iPr2P-(C6H4)]3B (tpb) on combination with
[Pd(P-tBu3)2] led to formation of (tpb)Pd (4) that features a Pd-B bond length of 2.2535(17) Å [36].
The diphosphine-borane ligand [o-(iPr2P)C6H4]2BPh (dpb) was combined with [PdCl2(COD)] to give
[PdCl2(dpb)] (5) with Pd-B distance of 2.650(3) Å [37]. DFT calculations suggest very little donation of
electron density from Pd(II)→B and significantly weaker bonding than found for the Pt(II)→B and
Rh(I)→B interactions with the same ligand. It is noteworthy that the Pd-B distances in 3 and 4 are
substantially shorter than in 5, which is due primarily to the nucleophilicity of the metal. It can be agreed
that in the absence of the Pd→B interaction, compounds 3 and 4 are d10 Pd(0) complexes whereas 5 is a
d8 Pd(II) complex. However, it has been debated whether the Pd→B interaction should be considered as
oxidative addition of the borane to Pdn+ to give Pdn+2 or if the oxidation state is unchanged on formation
of the M-Z bond. This discrepancy is not real, and its origins have been described by Hill [38]. Both
electron counting methods assume neat, whole numbers of electrons assigned to individual elements,
which is an artificial abstraction to help understand chemical bonding. In actuality, as is most easily
seen in molecular orbital theory, electron wavefunctions tend to be distributed over multiple atoms.
The ambiguity of assigning formal charges and oxidation states as result of wavefunctions that span
several atoms can be easily seen. To further illustrate, combination of 2,7-di-tert-butyl-5-diphenylboryl-4-
diphenylphosphino-9,9-dimethylthioxanthene (TXPB) with [PdCl2(COD)] followed by reduction led to
[Pd(TXPB)] (6). Rather than a direct Pd→B bond, complex 6 features an η3-BCC bonding mode
with Pd-B distance of 2.320(5) Å [39]. In order to truly assess the degree of oxidation of the metal,
one should use spectroscopic analyses such as near-edge energies of X-ray absorption spectra, X-ray
photoelectron spectroscopy, or Mössbauer spectroscopy [40].

Molecules 2015, 20
12982
Figure 1. Known L-Pd-Z complexes as reported in the literature.
Recently, Bourissou and coworkers demonstrated Suzuki–Miyaura couplings were catalyzed
by mixtures of Pd(OAc)2, [PdCl2(COD)], Pd2(dba)3, or [Pd(ma)(nbd)] (nbd = norborna-1,4-diene,
ma = maleic anhydride) with Ph2P(o-C6H4)BMes2 [41,42]. Interestingly, the product formed from the
reaction of [Pd(ma)(nbd)] with the monophosphine-borane was isolated and well characterized as
[Ph2P(o-C6H4)BMes2]Pd(ma) (7) (Scheme 3). Single crystal X-ray data show Pd(0) within the cavity of
Ph2P(o-C6H4)BMes2. However, instead of the FLP stabilizing Pd(0) via L-Pd-Z coordination, the structure
of 7 consists of the monophosphine-borane participating as a bidentate chelating ligand to palladium via
donation from the phosphine and η2-C-C coordination from the ipso and ortho carbons of a mesityl group.
The preformed complex was shown to be a highly active Suzuki-Miyaura catalyst [41]. Interestingly,
7 was shown to oxidize in the presence of iodobenzene (Scheme 3) to form an η4-boratabutadiene
iodophosphinopalladium(II) complex (8) [42]. The structure of 8 is very similar to that of 9 (Figure 2)
reported by our group, which formed upon reaction of 8-(BMes2)quinoline with [PdCl2(PhCN)2] [43].
Cyclometalation occurs concomitantly with elimination of HCl to form a borapalladacycle in which the
Pd(II) coordination sphere contains a quinolinyl nitrogen donor, chloride donor, and η4-boratabutadiene.
Scheme 3. The [Ph2P(o-C6H4)BMes2]Pd(ma) complex 7 and the product 8 formed upon
reaction with iodobenzene.

Molecules 2015, 20
12983
Figure 2. Chloro({2-[mesityl(quinolin-8-yl-κN)boryl]-3,5-dimethylphenyl}methyl-κC)-palladium(II) (9).
It was observed that 8 showed less activity in Suzuki-Miyaura coupling compared to 7. Nevertheless,
we were inspired to test the hypothesis that 9 is capable of catalyzing typical Pd-catalyzed C-C couplings.
In this report, we present new findings that 9 does indeed show high activity in the Heck reaction.
2. Results and Discussion
Coupling of aryl halides with n-butylacrylate was studied (Scheme 4). The conditions of the reactions
were empirically optimized upon comparison of activity in the presence of various bases and solvent
systems. Very poor activity was observed with inorganic bases Cs2CO3, K2CO3, or NaOAc. The bulky
organic base, Cy2NMe, also gave poor results. However, the reaction proceeded very well with n-Bu3N.
The reactions were studied in the DMF/H2O solvent system. The best results (results using other
bases/solvents are shown in the Supporting Information) were obtained in DMF without any addition of
water; though, no steps were taken to remove water from the DMF reagent. The reactions were generally
carried out at 140 °C. In these reaction conditions, the color of the solution was yellow and Pd black was
not observed. The results of the coupling of various arylhalides with n-butylacrylate are summarized in
Table 1.
X
O
O
Pd Catalyst
Solvent
O
+
O

Base,
R
R
Scheme 4. Coupling of arylhalides with n-butylacrylate.
The first entry in Table 1 shows that the coupling of iodobenzene with n-butylacrylate in the presence
of 0.05 mol % 9 proceeded quite rapidly, as we isolated the coupled product in 88% yield after only
5 h reaction time. The second through fourth entries show that the catalyst loading could be reduced
substantially in order to demonstrate the catalyst turnover number (TON). At 0.001 mol % loading of 9,
after 20 h of reaction time a 90% isolated yield of the coupled product was found that corresponds to a
TON ~ 90,000. Potentially this figure could be improved with further optimization; though we already
show that the catalyst is capable of TON comparable with active Pd-catalysts reported in the literature.
For example, a highly active Pd-PCP pincer complex achieved a TON of 143,000 for the coupling
of iodobenzene with n-butylacrylate [44]. A heterogeneous catalyst consisting of Pd encapusalated
within cross-linked poly(1,3-diethynylbenzene) gave TON ~ 100,000 [45]. For additional comparison,

Molecules 2015, 20
12984
combination of Pd(OAc)2 with a trifunctional N,N,O-terdentate amido/pyridyl/carboxylate ligand
produced a catalyst that achieved TON ~ 10,000 for coupling of iodobenzene with n-butylacrylate [46].
We found that combination of PdCl2 with two equivalents of quinoline at 0.01 mol % Pd catalyzed the
coupling of iodobenzene with n-butylacrylate with TON ~ 9300, and this result is similar to the initial
screening of Pd(quinoline-8-carboxylate)2 at 0.01 mol % loading that gave a TON ~ 8700 [47]. However,
with respect to achieving high TON [48] combinations of Pd(OAc)2 with phosphines has been shown
to give TON ~ 106 for the coupling of p-bromoacetophenone with n-butylacrylate [49]. Ferrocenylimine
palladacycles were shown to achieve TON ~ 3.6 × 106 [50]. Imine-palladacycle catalysts were shown to
reach TON ~ 1.4 × 106 for the coupling of iodobenzene with methylacrylate [51]. Oxime-palladacycle
catalysts were shown to reach TON ~ 1010 for the coupling of iodobenzene with alkylacrylate [52,53]
Catalyst 9 was completely ineffective for the coupling of bromobenzene with n-butylacrylate; however,
p-cyanobromobenzene could be utilized as a substrate. At 0.01 mol % loading of 9, the yield was already
limited to 58%, corresponding to TON ~ 5800. For comparison, it was shown that mixture of Pd(OAc)2
with phosphines could catalyze coupling of arylbromides with n-butylacrylate with TON ~ 106 [49].
A comparison of the coupling of p-R-C6H4I (R = OCH3, H, NO2) with 9 as catalyst shows the tolerance
for the functional groups; however, there was not a clear indication of an electronic effect of the substrate
on the rate of the reaction.
Table 1. Heck coupling reaction of aryl halides with n-butylacrylate using 9 as catalyst and
comparison with other data from the literature. a Isolated yield (our work).
Catalyst
X
I
R
mol % Catalyst T (°C) Time/h Yield (%) a
TON
1800
9400
18,000
90,000
8300
7900
5800
0
9
H
H
0.05
0.01
140
140
140
140
140
140
140
140
140
80
5
5
88
94
89
90
83
79
58
0
9
I
9
I
H
0.005
0.001
0.01
10
20
10
10
10
5
9
I
H
9
I
p-NO2
p-OCH3
p-CN
H
9
I
0.01
9
9
Br
Br
I
0.01
0.01
Quinoline:PdCl2 = 2:1
Pd(OAc)2 [54]
H
0.01
5
93
96
100
87
95
93
100
100
99
98
9300
I
H
0.5
2
192
106
PR3:Pd(OAc)2 = 2:1 [49] Br p-C(O)CH3
0.0001
0.01
130
130
145
145
160
100
100
160
24
30
20
20
14
48
145
72
Ref. [47]
Ref. [46]
I
I
H
8700
9500
9300
1.4 × 105
105
3.6 × 106
1010
H
0.01
Ref. [46]
Br
I
p-OCH3
0.01
Ref. [44]
H
H
H
H
0.0007
0.001
2.73 × 10−5
10−8
Pd@PDEB [45]
Ref. [50]
I
I
Ref. [52]
I
Coupling of aryl halides with styrene was studied as well (Scheme 5). Again, the reaction proceeded
poorly in the presence of inorganic bases Cs2CO3, K2CO3, NaOAc, or with the bulky organic base Cy2NMe;
whereas, the n-Bu3N gave good activity. The reactions proceeded smoothly in DMF, and addition of
water led to substantially lower activity. Again, the solutions remained yellow and homogeneous

Molecules 2015, 20
12985
throughout the reaction and Pd black was not observed. The results of the coupling of various aryl
halides with styrene are summarized in Table 2.
X
Pd Catalyst
+
Solvent

Base,
R
R
Scheme 5. Coupling of arylhalide with styrene.
Table 2. Heck coupling reaction of aryl halides with styrene using 9 as catalyst and
comparison with other data from the literature. a Isolated yield (our work).
Catalyst
X
I
R
H
mol % Catalyst T (°C) Time/h Yield (%) a
TON
2000
9
9
9
9
9
0.01
0.01
140
140
140
140
140
130
145
145
140
160
140
80
5
20
37
42
30
0
I
H
10
10
10
5
3700
I
p-OCH3
p-CN
H
0.01
4200
Br
Br
0.01
3000
0.01
0
PPh3:Pd(OAc)2 = 2:1 [49] Br p-C(O)CH3
0.0001
0.01
72
20
20
60
16
80
15
8
94
96
95
93
97
74
95
94
57.5
83
940,000
9600
Ref. [46]
Ref. [46]
Ref. [44]
Ref. [52]
Ref. [51]
Ref. [55]
Ref. [56]
Ref. [57]
Ref. [58]
I
Br
I
H
p-OCH3
H
0.01
9500
0.0007
0.001
0.0007
1
133,000
97,000
106,000
95
Br
I
p-OCH3
H
Br
I
p-CHO
p-OCH3
2
120
180
140
47
Br p-C(O)CH3
Br
0.00001
0.005
69
1
5,750,000
16,600
H
The reactions with styrene were substantially slower than comparable reactions with n-butylacrylate.
Interestingly, we again observe no reaction with bromobenzene yet an appreciable reaction with
p-cyanobromobenzene. The activity of 9 for coupling of styrene to aryl halides appears to be markedly
lower than other catalysts reported in the literature. Even a 2:1 mixture of PPh3 and Pd(OAc)2 has
been shown to catalyze coupling of styrene to p-bromoacetophenone with TON ~ 9.4 × 105 [49].
Oxime-palladacycle catalysts were shown to reach TON ~ 105 for the coupling of p-bromoanisole
with styrene [52]. Imine-palladacycle catalysts were shown to reach TON ~ 105 for the coupling of
iodobenzene with styrene [51]. A Pd-PCP pincer complex achieved a TON of 133,000 for the coupling of
iodobenzene with styrene [44]. An orthopalladated triarylphosphite catalyst achieved TON ~ 5.75 × 106
for the coupling of p-bromoacetophenone with styrene [57].
Palladacycles have received much attention as catalysts for C-C coupling reactions [48,49,59,60].
The palladacycle must undergo a chemical change in order to generate the catalytically active Pd(0)
species. Hartwig postulated a mechanism that involved a reductive elimination step to form a classical
phosphine stabilized Pd(0) species [61]. Conceivably, the palladacycle 9 could undergo reductive
elimination of the tucked mesityl and chloride ligands to form a postulated catalyst 10 (Scheme 6). The
observation of Heck reactions catalyzed by compound 9 suggests this possibility; however so far we

Molecules 2015, 20
12986
were unable to obtain structural or spectroscopic evidence for this hypothesized intermediate. Such
information would be helpful in understanding the catalyst reactivity, for example, whether the Pd(0)
stabilization in 10 resembles complex 7 or an example of a bent L-Pd(0)-Z complex. In either case the
Pd(0) would be coordinatively unsaturated and have a bent geometry, both of which would enhance
the reactivity for oxidative addition reactions. It is important to point out that 8 was reported to be less
active than 7 for Suzuki couplings. So far, we could not compare the reactivity of 9 and 10, since we
have not found a way to isolate 10.
Scheme 6. Postulated molecular catalyst 10 involved in the oxidative addition step.
Remarkably, the catalyst 9 was stable in the reaction conditions of elevated temperature for extended
time periods without formation of any palladium black precipitate. The reaction solution is a yellow
color throughout the entire course of the reaction. Additionally, we note that the onset of catalytic
activity is immediate without any induction period. These observations suggest that the catalyst species
is molecular rather than a colloidal nanoparticle catalyst.
3. Experimental Section
3.1. General Information
Compound 9 was prepared according to the literature [43]. All organic reagents and solvents were
obtained from commercial sources and used without further purification. A GCMS-QP2010SE gas
chromatograph-mass spectrometer (Shimadzu Corp., Kyoto, Japan) was used for GCMS analyses.
NMR spectra were recorded on an Avance 400 MHz spectrometer (Bruker, Billerica, MA, USA).
3.2. Heck Cross Coupling Reaction
A 50 mL flask was charged with 1 mmol aryl halide, 1.2 mmol olefin, 2 mmol n-Bu3N, 9, and DMF
(5 mL). The reaction mixture was then stirred at 140 °C h under N2. The reaction was worked up by
extraction with ether and washing with DI H2O. The organic phase was collected and dried over
anhydrous sodium sulfate. The residue was purified by flash column chromatography to afford the desired
product. NMR spectra of isolated products matched well with the literature [62].

Molecules 2015, 20
12987
4. Conclusions
To summarize, the molecule chloro({2-[mesityl(quinolin-8-yl-κN)boryl]-3,5-dimethylphenyl}-
methyl-κC)palladium(II) was demonstrated to catalyze Heck reactions of n-butylacrylate or styrene
with aryl halides. Turnover numbers in the coupling of aryliodides with n-butylacrylate were quite high;
however, this was not the case with styrene. We speculate, based on discussion in the chemical literature,
that the palladacycle 9 undergoes reductive elimination to form active Pd(0) species. The postulated
active catalyst species could potentially be a bent L-Pd(0)-Z species; however, structural or spectroscopic
evidence has not been obtained so far. Further work is needed to elucidate the reactive catalyst species,
and to determine whether this motif offers advantages in catalysis. The results so far suggest that the
preparation of pre-formed bent L-Pd(0)-Z catalysts may be a fruitful avenue for development of active
catalyst materials.
Supplementary Materials
Supplementary materials can be accessed at: http://www.mdpi.com/1420-3049/20/07/12979/s1.
Acknowledgments
We acknowledge the support of the National Science Foundation for purchase of the glove box
(EPS-0554609), NMR (CHE-1229035), and student support (EPS-0903804 and DGE-0903685).
Author Contributions
S.R.T. performed the synthesis and reactivity studies. S.R.T. and J.D.H. contributed to the design of
the experiments and wrote the manuscript.
Conflicts of Interest
The authors declare no conflict of interest.
References and Notes
1. Li, H.; Johansson Seechurn, C.C.C.; Colacot, T.J. Development of Preformed Pd Catalysts for
Cross-Coupling Reactions, Beyond the 2010 Nobel Prize. ACS Catal. 2012, 2, 1147–1164.
2. Beletskaya, I.P.; Cheprakov, A.V. The Heck Reaction as a Sharpening Stone of Palladium Catalysis.
Chem. Rev. 2000, 100, 3009–3066.
3. Cabri, W.; Candiani, I. Recent Developments and New Perspectives in the Heck Reaction.
Acc. Chem. Res. 1995, 28, 2–7.
4. Ozawa, F.; Kubo, A.; Hayashi, T. Generation of tertiary phosphine-coordinated Pd(0) species
from Pd(OAc)2 in the catalytic Heck reaction. Chem. Lett. 1992, 11, 2177–2180.
5. Littke, A.F.; Fu, G.C. Heck Reactions in the Presence of P(t-Bu)3: Expanded Scope and Milder
Reaction Conditions for the Coupling of Aryl Chlorides. J. Org. Chem. 1999, 64, 10–11.

Molecules 2015, 20
12988
6. Fu, G.C. The Development of Versatile Methods for Palladium-Catalyzed Coupling Reactions of
Aryl Electrophiles through the Use of P(t-Bu)3 and PCy3 as Ligands. Acc. Chem. Res. 2008, 41,
1555–1564.
7. We note that numerous supported Pd(0) catalysts, such as Pd/C or zeolite supported Pd, exist and
that these are phosphine-free.
8. Selvakumar, K.; Zapf, A.; Beller, M. New Palladium Carbene Catalysts for the Heck Reaction of
Aryl Chlorides in Ionic Liquids. Org. Lett. 2002, 4, 3031–3033.
9. Park, S.B.; Alper, H. Highly Efficient, Recyclable Pd(II) Catalysts with Bisimidazole Ligands for
the Heck Reaction in Ionic Liquids. Org. Lett. 2003, 5, 3209–3212.
10. Consorti, C.S.; Zanini, M.L.; Leal, S.; Ebeling, G.; Dupont, J. Chloropalladated Propargyl Amine:
A Highly Efficient Phosphine-Free Catalyst Precursor for the Heck Reaction. Org. Lett. 2003, 5,
983–986.
11. Beletskaya, I.P.; Kashin, A.N.; Karlstedt, N.B.; Mitin, A.V.; Cheprakov, A.V.; Kazankov, G.M.
NC-palladacycles as highly effective cheap precursors for the phosphine-free Heck reactions.
J. Organomet. Chem. 2001, 622, 89–96.
12. Mino, T.; Shirae, Y.; Sasai, Y.; Sakamoto, M.; Fujita, T. Phosphine-free palladium catalyzed
Mizoroki-Heck reaction using hydrazone as a ligand. J. Org. Chem. 2006, 71, 6834–6839.
13. Gruber, A.S.; Pozebon, D.; Monteiro, A.L.; Dupont, J. On the use of phosphine-free PdCl2(SEt2)2
complex as catalyst precursor for the Heck reaction. Tetrahedron Lett. 2001, 42, 7345–7348.
14. Herrman, W.A.; Reisinger, C.P.; Spiegler, M. Chelating N-heterocyclic carbene ligands in
palladium-catalyzed heck-type reactions. J. Organomet. Chem. 1998, 557, 93–96.
15. Joost, M.; Zeineddine, A.; Estevez, L.; Mallet-Ladeira, S.; Miqueu, K.; Amgoune, A.; Bourissou, D.
Facile Oxidative Addition of Aryl Iodides to Gold(I) by Ligand Design: Bending Turns on Reactivity
J. Am. Chem. Soc. 2014, 136, 14654–14657.
16. Stephan, D.W.; Erker, G. Frustrated Lewis Pairs: Metal-free Hydrogen Activation and More.
Angew. Chem. Int. Ed. 2010, 49, 46–76.
17. Stephan, D.W. Frustrated Lewis pairs: A new strategy to small molecule activation and
hydrogenation catalysis. Dalton Trans. 2009, 3129–3136.
18. Rokob, T.A.; Hamza, A.; Papai, I. Rationalizing the Reactivity of Frustrated Lewis Pairs:
Thermodynamics of H2 Activation and the Role of Acid-Base Properties. J. Am. Chem. Soc. 2009,
131, 10701–10710.
19. Welch, G.C.; San Juan, R.R.; Masuda, J.D.; Stephan, D.W. Reversible, Metal-Free Hydrogen
Activation. Science 2006, 314, 1124–1126.
20. Welch, G.C.; Stephan, D.W. Facile Heterolytic Cleavage of Dihydrogen by Phosphines and Boranes.
J. Am. Chem. Soc. 2007, 129, 1880–1881.
21. Momming, C.M.; Otten, E.; Kehr, G.; Frohlich, R.; Grimme, S.; Stephan, D.W.; Erker, G.
Reversible Metal-Free Carbon Dioxide Binding by Frustrated Lewis Pairs. Angew. Chem. Int. Ed.
2009, 48, 6643–6646.
22. Berkefeld, A.; Piers, W.E.; Parvez, M. Tandem Frustrated Lewis Pair/Tris(pentafluorophenyl)borane-
Catalyzed Deoxygenative Hydrosilylation of Carbon Dioxide. J. Am. Chem. Soc. 2010, 132,
10660–10661.

Molecules 2015, 20
12989
23. Ashley, A.E.; Thompson, A.L.; O’Hare, D. Non-Metal-Mediated Homogeneous Hydrogenation of
CO2 to CH3OH. Angew. Chem. Int. Ed. 2009, 48, 9839–9843.
24. Appelt, C.; Westenberg, H.; Bertini, F.; Ehlers, A.W.; Slootweg, J.C.; Lammertsma, K.; Uhl, W.
Geminal Phosphorus/Aluminum-Based Frustrated Lewis Pairs: C-H versus C≡C Activation and
CO2 Fixation. Angew. Chem. Int. Ed. 2011, 50, 3925–3928.
25. Lu, Z.; Wang, Y.; Liu, J.; Lin, Y.J.; Li, Z.H.; Wang, H. Synthesis and Reactivity of the CO2
Adducts of Amine/Bis(2,4,6-tris(trifluoromethyl)phenyl)borane Pairs. Organometallics 2013, 32,
6753–6758.
26. Rochette, E; Courtemanche, M.A.; Pulis, A.P.; Bi, W.; Fontaine, F.G. Ambiphilic Frustrated
Lewis Pair Exhibiting High Robustness and Reversible Water Activation: Towards the Metal-Free
Hydrogenation of Carbon Dioxide. Molecules 2015, 20, 11902–11914.
27. Roesler, R.; Piers, W.E.; Parvez, M. Synthesis, structural characterization and reactivity of the
aminoborane 1-(NPh2)-2-[B(C6F5)2]C6H4. J. Organomet. Chem. 2003, 680, 218–222.
28. Fromel, S.; Frohlich, R.; Daniliuc, C.G.; Kehr, G.; Erker, G. Halogen Addition to a Frustrated
Lewis Pair. Eur. J. Inorg. Chem. 2012, 23, 3774–3779.
29. Son, J.H.; Tamang, S.R.; Hoefelmeyer, J.D. Bis(3-bromomesityl)8-quinolyliniumboron(III) tribromide.
Acta Cryst. 2015, in press.
30. Sircoglou, M.; Bouhadir, G.; Saffon, N.; Miqueu, K.; Bourissou, D. A Zwitterionic Gold(I)
Complex from an Ambiphilic Diphosphino–Alane Ligand. Organometallics 2008, 27, 1675–1678.
31. Dureen, M.A.; Welch, G.C.; Gilbert, T.M.; Stephan, D.W. Heterolytic Cleavage of Disulfides by
Frustrated Lewis Pairs. Inorg. Chem. 2009, 48, 9910–9917.
32. Fontaine, F.G.; Boudreau, J.; Thibault, M.H. Coordination Chemistry of Neutral (Ln)-Z Amphoteric
and Ambiphilic Ligands. Eur. J. Inorg. Chem. 2008, 35, 5439–5454.
33. Amgoune, A.; Bourissou, D. σ-Acceptor, Z-type ligands for transition metals. Chem. Commun.
2011, 47, 859–871.
34. Grobe, J.; Lutke-Brochtrup, K.; Krebs, B.; Lage, M.; Niemeyer, H.H.; Wurthwein, E.U.
Alternative Ligands, XXXVII. Phosphane Ligands with Boron as Lewis-acidic Centre: Synthesis and
Coordinating Properties. Z. Naturforsch. B 2006, 61, 882–895.
35. Pang, K.; Quan, S.M.; Parkin, G. Palladium complexes with Pd→B dative bonds: Analysis of
the bonding in the palladaboratrane compound [κ4B(mimBut)3]Pd(PMe3). Chem. Commun. 2006,
42, 5015–5017.
36. Sircoglou, M; Bontemps, S.; Bouhadir, G.; Saffon, N.; Miqueu, K.; Gu, W.; Mercy, M.; Chen,
C.H.; Foxman, B.M.; Maron, L.; et al. Group 10 and 11 Metal Boratranes (Ni, Pd, Pt, CuCl,
AgCl, AuCl, and Au+) Derived from a Triphosphine–Borane. J. Am. Chem. Soc. 2008, 130,
16729–16738.
37. Bontemps, S.; Sircoglou, M.; Bouhadir, G.; Puschmann, H.; Howard, J.A.K.; Dyer, P.W.; Miqueu, K.;
Bourissou, D. Ambiphilic Diphosphine–Borane Ligands: Metal→Borane Interactions within
Isoelectronic Complexes of Rhodium, Platinum and Palladium. Chem. Eur. J. 2008, 14, 731–740.
38. Hill, A.F. An Unambiguous Electron-Counting Notation for Metallaboratranes. Organometallics
2006, 25, 4741–4743.

Molecules 2015, 20
12990
39. Emslie, D.J.H.; Harrington, L.E.; Jenkins, H.A.; Robertson, C.M.; Britten, J.F. Group 10
Transition-Metal Complexes of an Ambiphilic PSB-Ligand: Investigations into η3(BCC)-Triarylborane
Coordination. Organometallics 2008, 27, 5317–5325.
40. Sircoglou, M; Bontemps, S.; Mercy, M; Saffon, N.; Takahashi, M.; Bouhadir, G.; Maron, L.;
Bourissou, D. Transition-Metal Complexes Featuring Z-Type Ligands: Agreement or Discrepancy
between Geometry and dn Configuration? Angew. Chem. Int. Ed. 2007, 46, 8583–8586.
41. Malacea, R.; Saffon, N.; Gomez, M.; Bourissou, D. A new insight into ortho-(dimesitylboryl)
diphenylphosphines: Applications in Pd-catalyzed Suzuki–Miyaura couplings and evidence for
secondary π-interaction. Chem. Commun. 2011, 47, 8163–8165.
42. Malacea, R.; Chahdoura, F.; Devillard, M.; Saffon, N.; Gomez, M.; Bourissou, D.
ortho-(Dimesitylboryl)phenylphosphines: Positive Boryl Effect in the Palladium-Catalyzed
Suzuki–Miyaura Coupling of 2-Chloropyridines. Adv. Synth. Catal. 2013, 355, 2274–2284.
43. Son, J.H.; Pudenz, M.A.; Hoefelmeyer, J.D. Reactivity of the Bifunctional Ambiphilic Molecule
8-(dimesitylboryl)quinoline: Hydrolysis and Coordination to Cu(I), Ag(I) and Pd(II). Dalton Trans.
2010, 39, 11081–11090.
44. Ohff, M.; Ohff, A.; van der Boom, M.E.; Milstein, D. Highly Active Pd(II) PCP-Type Catalysts
for the Heck Reaction. J. Am. Chem. Soc. 1997, 119, 11687–11688.
45. Dong, Z.; Ye, Z. Reusable, Highly Active Heterogeneous Palladium Catalyst by Convenient
Self-Encapsulation Cross-Linking Polymerization for Multiple Carbon—Carbon Cross-Coupling
Reactions at ppm to ppb Palladium Loadings. Adv. Synth. Catal. 2014, 356, 3401–3414.
46. Kantam, M.L.; Srinivas, P.; Yadav, J.; Likhar, P.R.; Bhargava, S. Trifunctional N,N,O-Terdentate
Amido/Pyridyl Carboxylate Ligated Pd(II) Complexes for Heck and Suzuki Reactions. J. Org. Chem.
2009, 74, 4882–4885.
47. Cui, X.; Li, J.; Zhang, Z.P.; Fu, Y.; Liu, L.; Guo, Q.X. Pd(quinoline-8-carboxylate)2 as a Low-Priced,
Phosphine-Free Catalyst for Heck and Suzuki Reactions. J. Org. Chem. 2007, 72, 9342–9345.
48. Farina, V. High-Turnover Palladium Catalysts in Cross-Coupling and Heck Chemistry: A Critical
Overview. Adv. Synth. Catal. 2004, 346, 1553–1582.
49. Herrman, W.A.; Brossmer, C.; Reisinger, C.P.; Riermeier, T.H.; Ofele, K.; Beller, M. Palladacycles:
Efficient New Catalysts for the Heck Vinylation of Aryl Halides. Chem. Eur. J. 1997, 3, 1357–1364.
50. Wu, Y.; Hou, J.; Yun, H.; Cui, X.; Yuan, R. Cyclopalladated ferrocenylimines: Highly active
catalysts for Heck reactions. J. Organomet. Chem. 2001, 637, 793–795.
51. Ohff, M.; Ohff, A.; Milstein, D. Highly active PdII cyclometallated imine catalysts for the Heck
reaction. Chem. Commun. 1999, 357–358.
52. Alonso, D.A.; Najera, C.; Pacheco, M.C. Oxime-Derived Palladium Complexes as Very Efficient
Catalysts for the Heck-Mizoroki Reaction. Adv. Synth. Catal. 2002, 344, 172–183.
53. Alonso, D.A.; Najera, C.; Pacheco, M.C. Oxime Palladacycles: Stable and Efficient Catalysts for
Carbon–Carbon Coupling Reactions. Org. Lett. 2000, 2, 1823–1826.
54. Amini, M.; Bagherzadeh, M.; Moradi-Shoeili, Z.; Boghaei, D.M. Pd(OAc)2 without added ligand
as an active catalyst for Mizoroki–Heck reaction in aqueous media. RSC Adv. 2012, 2, 12091–12095.
55. Özdemir, I.; Yiğit, M.; Çetinkaya, E.; Çetinkaya, B. Synthesis of novel palladium N-heterocyclic-carbene
complexes as catalysts for Heck and Suzuki cross-coupling reactions. Appl. Organomet. Chem.
2006, 20, 187–192.

Molecules 2015, 20
12991
56. Wang, R.; Twamley, B.; Shreeve, J.M. A Highly Efficient, Recyclable Catalyst for C–C
Coupling Reactions in Ionic Liquids: Pyrazolyl-Functionalized N-Heterocyclic Carbene Complex
of Palladium(II). J. Org. Chem. 2005, 71, 426–429.
57. Albisson, D.A.; Bedford, R.B.; Scully, P.N. Orthopalladated triarylphosphite complexes as highly
efficient catalysts in the Heck reaction. Tetrahedron Lett. 1998, 39, 9793–9796.
58. Heidenreich, R.G.; Köhler, K.; Krauter, J.G.E.; Pietsch, J. Pd/C as a Highly Active Catalyst for
Heck, Suzuki and Sonogashira Reactions. Synlett 2002, 1118–1122.
59. Herrman, W.A.; Bohm, V.P.W.; Reisinger, C.P. Application of palladacycles in Heck type reactions.
J. Organomet. Chem. 1999, 576, 23–41.
60. Dupont, J.; Consorti, C.S.; Spencer, J. The Potential of Palladacycles: More than Just Precatalysts.
Chem. Rev. 2005, 105, 2527–2571.
61. Louie, J.; Hartwig, J.F. A Route to Pd0 from PdII Metallacycles in Amination and Cross-Coupling
Chemistry. Angew. Chem. Int. Ed. 1996, 35, 2359–2360.
62. Huang, S.H.; Chen, J.R.; Tsai, F.Y. Palladium(II)/Cationic 2,2′-Bipyridyl System as Highly
Efficient and Reusable Catalyst for the Mizoroki-Heck Reaction in Water. Molecules 2010, 15,
315–330.
Sample Availability: Samples of the compounds are not available from the authors.
© 2015 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/4.0/).
