Differential proliferation effect of the newly synthesized valine, tyrosine and tryptophan–naphthoquinones in immortal and tumorigenic cervical cell lines

Article abstract of DOI:10.3390/molecules25092058

We previously showed that microwave assisted synthesis is the best method for the synthesis of naphthoquinone amino acid and chloride-naphthoquinone amino acid derivatives by a complete evaluation of reaction conditions such as stoichiometry, bases, and pH influence. Following the same strategy, we synthesized chloride and non-chloride tyrosine, valine, and tryptophan-naphthoquinones achieving 85–95%, 80–92%, and 91–95% yields, respectively. The cyclic voltammetry profiles showed that both series of naphthoquinone amino acid derivatives mainly display one redox reaction process. Overall, chloride naphthoquinone amino acid derivatives exhibited redox potential values (E₁/₂) more positive than non-chloride compounds. The six newly synthesized compounds were tested in HPV positive and negative as well as in immortal and tumorigenic cell lines to observe the effects in different cellular context simulating precancerous and cancerous status. A dose-response was achieved to determine the IC50 of six newly synthesized compounds in SiHa (Tumorigenic and HPV16 positive), CaLo (Tumorigenic and HPV18 positive), C33-A (Tumorigenic and HPV negative) and HaCaT (Keratinocytes immortal HPV negative) cell lines. Non-chloride tryptophan-naphthoquinone (3c) and chloride tyrosine-naphthoquine (4a) effects were more potent in tumorigenic SiHa, CaLo, and C33-A cells with respect to non-tumorigenic HaCaT cells. Interestingly, there seems to be a differential effect in non-chloride and chloride naphthoquinone amino acid derivatives in tumorigenic versus non tumorigenic cells. Considering all naphthoquinone amino acid derivatives that our group synthesized, it seems that hydrophobic and aromatic amino acids have the greatest effect on cell proliferation inhibition. These results show promising compounds for cervical cancer treatment.

Full text of DOI:10.3390/molecules25092058

molecules
Article
Differential Proliferation Effect of the Newly
Synthesized Valine, Tyrosine and
Tryptophan–Naphthoquinones in Immortal and
Tumorigenic Cervical Cell Lines
1
1
2
Sergio Córdova-Rivas , Jorge Gustavo Araujo-Huitrado , Ernesto Rivera-Avalos ,
3
3
4
Ismailia L. Escalante-García
Hiram Hernández-López 3 , Lluvia López 5 , Denisse de Loera * and Jesús Adrián López *
, Sergio M. Durón-Torres , Yamilé López-Hernández
,
2,
1,
1
Laboratorio de microRNAs y Cáncer, Unidad Académica de Ciencias Biológicas,
Universidad Autónoma de Zacatecas, Zacatecas 98068, Mexico; cordova092@hotmail.com (S.C.-R.);
aahj011871@uaz.edu.mx (J.G.A.-H.)
School of Chemistry, Universidad Autónoma de San Luis Potosí, San Luis Potosí 78210, Mexico;
2
neto_riava@hotmail.com
3
Unidad Académica de Ciencias Químicas, Universidad Autónoma de Zacatecas, Zacatecas 98160, Mexico;
ileg@uaz.edu.mx (I.L.E.-G.); duronm@uaz.edu.mx (S.M.D.-T.);
hiram.hernandez.lopez@uaz.edu.mx (H.H.-L.)
CONACYT, Laboratorio de Metabolómica y Proteómica, Unidad Académica de Ciencias Biológicas,
4
Universidad Autónoma de Zacatecas, Zacatecas 98068, Mexico; ylopezher@conacyt.mx
Instituto de Investigación de Zonas Desérticas, Universidad Autónoma de San Luis Potosí,
5
San Luis Potosí 78377, Mexico; lluvia.lopez@uaslp.mx
*
Correspondence: atenea.deloera@uaslp.mx (D.d.L.); jalopez@uaz.edu.mx (J.A.L.);
Tel.: +52-444-826-2300 x6415 (D.d.L.); +52-492-149-2648 (J.A.L.)
ꢀ
ꢁꢂꢀꢃꢄꢅꢆꢇ
Academic Editor: Simona Collina
Received: 21 March 2020; Accepted: 21 April 2020; Published: 28 April 2020
ꢀ
ꢁꢂꢃꢄꢅꢆ
Abstract: We previously showed that microwave assisted synthesis is the best method for the synthesis
of naphthoquinone amino acid and chloride-naphthoquinone amino acid derivatives by a complete
evaluation of reaction conditions such as stoichiometry, bases, and pH influence. Following the same
strategy, we synthesized chloride and non-chloride tyrosine, valine, and tryptophan-naphthoquinones
achieving 85–95%, 80–92%, and 91–95% yields, respectively. The cyclic voltammetry profiles showed
that both series of naphthoquinone amino acid derivatives mainly display one redox reaction process.
Overall, chloride naphthoquinone amino acid derivatives exhibited redox potential values (E1/2
)
more positive than non-chloride compounds. The six newly synthesized compounds were tested in
HPV positive and negative as well as in immortal and tumorigenic cell lines to observe the effects
in different cellular context simulating precancerous and cancerous status. A dose-response was
achieved to determine the IC50 of six newly synthesized compounds in SiHa (Tumorigenic and HPV16
positive), CaLo (Tumorigenic and HPV18 positive), C33-A (Tumorigenic and HPV negative) and
HaCaT (Keratinocytes immortal HPV negative) cell lines. Non-chloride tryptophan-naphthoquinone
(3c) and chloride tyrosine-naphthoquine (4a) effects were more potent in tumorigenic SiHa, CaLo,
and C33-A cells with respect to non-tumorigenic HaCaT cells. Interestingly, there seems to be a
differential effect in non-chloride and chloride naphthoquinone amino acid derivatives in tumorigenic
versus non tumorigenic cells. Considering all naphthoquinone amino acid derivatives that our group
synthesized, it seems that hydrophobic and aromatic amino acids have the greatest effect on cell
proliferation inhibition. These results show promising compounds for cervical cancer treatment.
Keywords: naphthoquinone; amino acids; alternative methods; microwave; ultrasound; anticancer
Molecules 2020, 25, 2058; doi:10.3390/molecules25092058
www.mdpi.com/journal/molecules

Molecules 2020, 25, 2058
2 of 18
1
. Introduction
Naphthoquinones (NQ) are a group of natural and synthetic compounds known for their
antibacterial, antifungal, anticancer, antimalarial, and antiviral effects, among others [ ]. Several
1,2
studies have reported that naphthoquinones with different substituents like paclitaxel, esters, metals,
furans, carbazoles, or inclusive with carbohydrates in their structure, among others, inhibit cell
proliferation [3–5]. These properties are principally attributed to the oxidant-reductive characteristics
of naphthoquinones, which allow the generation of dianions or semiquinone radicals. In the last
decades, some publications have been dedicated to the finding of an explanation for the formation
of these intermediates in the synthetic mechanism, and their properties that have produced different
compounds with a plethora of applications of biological importance and effects that involve intra-
or intermolecular interactions. One of the principal effects of these compounds is the generation of
reactive oxygen species (ROS), producing cytotoxicity in different cell lines [6–11]. ROS generation
with naphthoquinones represents a challenge in the design of new active compounds, principally with
anticancer effects. In this context, the addition/substitution on naphthoquinone moiety by atoms or
groups such as flour, oxygen, or amine can be modulated by redox properties, decreasing the toxicity
levels and maintaining or potentiating the biological effect [12–14].
Cell proliferation inhibition could be achieved by the induction of apoptosis, topoisomerase II-
inhibition, and ROS generation, among others [ ]. Furthermore, it has been shown that -lapachone
inhibits epidermal growth factor (pEGFR), protein kinase B (pAKT/PKB), glycogen synthase kinase
pGsk-3 ), cyclin D1, and cyclooxygenase-2 (COX-2) protein expression in a dose-dependent
α
3
β
(
β
manner [15]. Naphthoquinone regulation depends on the composition of its substituents, as well as
targets and cellular components that could be inhibited and/or activated in cancer.
Cervical cancer is the second most common cancer in women worldwide, with an estimated global
incidence of 470000 new cases and over 200000 deaths per year [16]. High-risk human papillomavirus
(HPV) infection has been associated with the development of cervical, penile, and anal cancers.
Although high-risk HPV expression appears necessary to immortalize and stimulate proliferation in
human keratinocytes [17], it is not sufficient to produce a fully transformed phenotype suggesting that
other genetic changes participate in the development of cervical cancer [18]. Several naphthoquinones
have been produced; however, they usually have non-desirable effects in cancer therapy use. Therefore,
the production of new compounds by alternative methods is imperative for cancer treatment.
In this regard, the synthesis and biological activities of some naphthoquinone–amino acids have
been reported in several publications. Nonetheless, all of these methodologies present different
drawbacks, like low yields and/or long reaction times [19–23]. To our knowledge, the synthesis of
naphthoquinone–amino acid derivatives has not been reported using microwave and ultrasound
irradiation until our previous work [24], which offer diverse advantages to conventional synthesis.
Our research group synthesized naphthoquinone amino acid derivatives to study their potential
antitumorigenic activity against cervix and breast cancer cell lines. The compounds studied showed
an inhibition grade ranked from 85% to 40% in SiHa cells, and 90% to 30% in MCF-7 cells. Surprisingly,
chloride naphthoquinone amino acid derivatives possess a selective activity against breast cancer
cell lines, on the other hand, without chlorine atom in their structure the naphtoquinone amino
acid derivatives presented selectivity against cervix cancer cell lines [24]. To complete the study of
naphthoquinone amino acid derivatives against cancer cell lines, in this paper, we present the synthesis
of valine, tyrosine and tryptophan 1,4-naphthoquinone (3a–c), and chloro-naphthoquinone (4a–c)
derivatives by microwave (MAS) and irradiation, and their effect in the cervical cancer cell lines
HPV-positive SiHa and CaLo, HPV-negative C33-A and the keratinocytes non-cancerous HPV negative
cell line, HaCaT. The incorporation of amino acids to naphthoquinones could enhance their cytotoxicity
capacity as well as their specificity achieving its potential use as antitumorigenic compounds.

Molecules 2020, 25, 2058
3 of 18
2
. Results
2
.1. Chemistry
Figure 1 shows the general method to prepare 3a–c and 4a–c derivatives, and in Table 1 are present
the reaction conditions used based on the optimized conditions previously reported [24].
Figure 1. Preparation of 3a–c and 4a–c derivatives.
Table 1. Reaction conditions to prepare 3a–c and 4a–c derivatives.
Compound
Nq-aa
MAS a (%)
TEA
KOH
3
a
1:1.8
1:1.5
1:1.2
1:1.7
1:2.5
1:1.5
◦
85
80
80
95
92
91
90
92
88
90
87
89
3
b
3
c
4a
4
b
4
c
a
Microwave Assisted Synthesis: 110 C, 250 W, 25 min, in dioxane-water (4:1), TEA (1mmol)/KOH (3N) 5 mL.
Nq-aa: Naphthoquinone amino acid proportion.
2
.2. Electrochemical Studies by Cyclic Voltammetry
Cyclic voltammetry (CV) curves of naphthoquinone–amino acid (3a–c) and chloride–naphthoquinone
−
amino acids (4a–c) derivatives in 0.1M TBABF /DMSO at 100 mV s are reported in Figure 2A,B,
4
1
–
respectively. Tyrosine, valine, and tryptophan naphthoquinone derivatives, without and with the
chloride moiety, exhibit a similar electrochemical response to that for naphthoquinone derivatives
modified with alanine, phenylalanine, methionine, glycine and asparagine as previously reported by
our group [24]. One redox reaction is identified in the cathodic potential region at half-wave potentials
values (E1/2) near to
−
1.2 V and 1.1 V for the naphthoquinone (3a–c) and chloride–naphthoquinone
−
(
4a–c) derivatives, respectively. Additionally, several irreversible oxidation processes are also observed
+
at more positive potential values, >
The cathodic waves at potentials near to the redox reaction are related to the electrochemical reduction
−
0.75 V vs. Ag/Ag for 3a–c and 4a–c compounds (Figure 2).
of these oxidation reactions since voltammetry measurements in a shorter potential range, from
−
0.5 V
+
to
−
2.0 V vs. Ag/Ag , did not display those cathodic waves. The redox reaction at E1 is associated
/2
with the reduction of the quinone moiety (Q) of compounds 3a–c or 4a–c by a single step two-electron
2
−
transference process to yield the quinone dianion (Q ) (Figure 3, reaction (i)) [25
–27]. To recall, the
electrochemical reduction of typical quinone moiety (Q) in nonaqueous media exhibits two successive
•
−
2−
one electron-transfer steps forming the semiquinone radical (Q ) and quinone dianion (Q ) (Figure 3,

Molecules 2020, 25, 2058
4 of 18
reaction (ii). Thus, two redox processes at different half-wave potentials are expected [24
–27]. In this
study, it is then suggested that the reduction mechanism of the quinone moiety (Q) in 3a–c and 4a–c is
influenced by electronic and steric effects due to the amino acid substituent groups (tyrosine, valine
and tryptophan); as consequence, only one well-defined redox process is observed (Figure 2). Possibly,
electronic interference of the amine group between the quinone ring and the amino acid substituent,
as well as strong intramolecular hydrogen bonding help to stabilize the quinone moiety (Q) or the
•−
2−
radicals intermediates (Q and Q ) [25,27–30].
A)
B)
Figure 2. Cyclic voltammetry curves of (
A
) naphthoquinone (3a–c) and (
B) chloride-naphthoquinone
(
4a–c) derivatives with a: tyrosine, b: valine and c: tryptophan at 5 mM in 0.1 M TBABF //DMSO at
4
−1
room temperature. Scan rate: 100 mV s
.
The electrochemical parameters of the redox reaction were evaluated by cyclic voltammetry at
different scan rates and are summarized in Table 2. First of all, the redox reaction of 3a–c and 4a–c is a
diffusion-controlled process according to a linear relationship of the cathodic peak current density (ipc
)
with the square root of the scan rate (ipc vs. v1 ), thus indicating fast chemical kinetics. The potential
/2
peak separation values (
p
∆E ) are quite similar among compounds 3a–c or 4a–c. Here, it is worth noting
that the redox reaction for the naphthoquinone with tryptophan (3c) and chloride-naphthoquinone
+
p
with valine (4b) exhibit the lowest ∆E , 0.11 V vs. Ag/Ag , therefore, faster kinetics are occurring.
Additionally, compounds 3a–c exhibit good reversibility according to the ratio of the anodic peak
current to cathodic peak current (ipa/ipc) which is close to one in value as described for reversible
systems [31]. Chloride-naphthoquinone amino acid derivatives, 4a–c, behave quite irreversible as
compared to 3a–c compounds according to ipa/ipc values reported in Table 2. The E1/2 for the redox
reaction was in the potential range of
respectively, as reported in Table 2. Note that E1 for 4a–c compounds shifts toward anodic potentials
−
1.21 V to
−
1.24 V and
−
1.10 V to 1.12 V for 3a–c and 4a–c,
−
/2
by at least 110 mV as compared to the E1/2 registered for non-chloride naphthoquinone amino acid
derivatives, 3a–c. The potential shift is related to the electron-attracting capacity of the chloride
substituent in ortho-position that facilitate the electron transfer and the electrochemical reduction of
the quinone moiety [28,32]. Here, the potential shift is related to inductive and resonance effects of the

Molecules 2020, 25, 2058
5 of 18
halogen substituent at this position [28]. These results are consistent with those previously reported
by our group for naphthoquinone amino acid derivatives modified with alanine, phenylalanine,
methionine, glycine and asparagine [24]. Nonetheless, the naphthoquinone amino acid derivatives
reported before demonstrated higher reversibility and slightly lower kinetics.
Figure 3. Schematic representation of the quinone moiety (Q) reduction in the naphthoquinone amino
acid derivatives: (i) single step two-electron reduction reaction and (ii) two successive one-electron
reduction reactions. X = H for 3a–c and X = Cl for 4a–c.
Table 2. Electrochemical parameters of non-chloride and chloride naphthoquinone with tyrosine,
valine and tryptophan substituents a.
∆Ep b
E1/2 c
(V)
Epa
Epc
(V)
ipa
ipc
|ipa/ipc|
Compound
(mA cm 2)
−
(V)
(V)
3
a
−1.15
−1.16
−1.19
−1.04
−1.05
−1.05
−1.27
−1.27
−1.30
−1.15
−1.19
−1.17
0.13
0.12
0.11
0.11
0.14
0.12
−1.21
−1.21
−1.24
−1.10
−1.12
−1.11
0.28
0.28
0.26
0.22
0.21
0.23
−0.30
−0.30
−0.27
−0.24
−0.25
−0.27
0.95
0.95
0.95
0.92
0.83
0.85
3
b
3
c
4
a
4
b
4
c
a
Determined by cyclic voltammetry in TBABF
4
0.1 M/DMSO at 100 mV/s. The potentials are given with respect to
the Ag/Ag+ pseudo-reference electrode; ∆Ep = Epc − Epa; E1/2 = (Epa + Epc)/2.
b
c
Besides the redox process of the quinone moiety, naphthoquinone amino acid derivatives show
+
two or more irreversible oxidation waves at anodic potentials between 0.75 V and 0.75 V vs. Ag/Ag
−
as mentioned above (Figure 2). Particularly, a well-defined oxidation potential peak is identified at
.60 V and 0.45 V for naphthoquinones modified with valine (3b) and tryptophan (3c) as shown in
0
Figure 2A, respectively; as well as for the corresponding amino-chloride-naphthoquinones derivatives,
valine (4b) and tryptophan (4c), at 0.57 V and 0.46 V, respectively (Figure 2B). Compounds 3a and
4
a exhibit an ill-defined oxidation wave at potential values higher than 0.5 V as shown in Figure 2.
Additionally, chloride naphthoquinone amino acid derivatives display a noticeable anodic peak at
0.33V or 0.36 V as shown in Figure 2B for 4a or 4b,c, respectively. Naphthoquinone derivative with
valine (3b) also exhibits an anodic peak at 0.2 V meanwhile 3a and 3c compounds display several
overlapping oxidation processes in the potential range of 0.75 V to 0.25 V (Figure 2A). All of these
irreversible anodic processes are related to oxidation reactions by electron dislocation of the amino acid
−
−
−
−

Molecules 2020, 25, 2058
6 of 18
substituent group which could allow interaction with DNA, RNA and proteins in the cells affecting
their proliferation.
2
.3. Effect of Naphthoquinone Amino Acid Derivatives in Cell Proliferation of Tumorigenic Cervical Cancer Cell
Lines and Immortal Cell Line
A desired feature of a new potential therapeutic agent is its differential effect between pre-cancerous
and cancerous status, therefore, we tested two principal characteristics: 1) status of cells regarding the
development toward cancer (immortal versus tumorigenic) and 2) HPV content (negative or positive).
Immortal and HPV negative cell line HaCaT cells was selected as control for both immortality status
and HPV content. SiHa (HPV16 positive), CaLo (HPV positive), and C33-A (HPV negative) cells were
evaluated considering their tumorigenic status and HPV content. In order to evaluate the effect of
the naphthoquine amino acid derivatives in immortal and tumorigenic cells with HPV positive and
negative status we performed a dose-response analysis. The forth cells were treated with 6.25, 12.5,
25, 5, 100, and 200 µM of naphthoquinone amino acid derivatives 3a–c and 4a–c. Compounds with
tyrosine (3a), valine (3b), and tryptophan (3c) substituents showed a dose-dependent proliferation
inhibition in all the cells tested, Figure 4A–D. IC50 of compound 3a was 40.98, 55.67, 61.60, and 81.08
for SiHa, HaCaT, CaLo and C33-A cells, respectively. A different proliferation inhibition was exerted by
3
b compound, being SiHa the most affected, followed by HaCaT, C33-A, and CaLo. While proliferation
inhibition was stronger in C33-A cells followed by CaLo, SiHa and HaCaT after 3c compound treatment,
Table 3. The results analysis suggests that HPV status in cell lines doesn’t seem to be important in the
compounds exerted effects. By contrast the immortal/tumorigenic status appears to be an important
cell feature for non-chloride-tryptophan-naphthoquinone (3c) compound exerted effect. Interestingly,
a similar behavior in proliferation inhibition was observed by chloride-tyrosine-naphthoquinone (4a),
Figure 4 and Table 3. It is worth highlighting the strong difference observed between non-chloride
(3a–c) and chloride compounds (4a–c), remarkably a difference of more than one order of magnitude
with respect to the proliferation inhibition exerted by chloride compounds, as shown in Figure 4.
It is of relevance to mention that almost all the compounds exerted lower proliferation inhibition
over HaCaT cells in comparison to SiHa and C33-A cells, however, CaLo and HaCaT cells showed no
important proliferation inhibition difference or even CaLo cells were less affected (3a,b), as shown in
Figure 4 and Table 3. Finally, based on the low effect exerted on proliferation inhibition in HaCaT cells,
which represent a closer resemblance to normal cells, we suggest 3c and 4a compounds are interesting
candidates for further studies regarding cervical cancer therapeutic potential.

Molecules 2020, 25, 2058
7 of 18
Figure 4. Cont.

Molecules 2020, 25, 2058
8 of 18
Figure 4. Proliferation effect of Naphthoquinone amino acid derivatives was evaluated in HPV positive
cancer cell lines derived from cervix and a non-tumorigenic HPV negative cell line. ( ) HaCaT HPV
negative cell line cells were treated with 6.25, 12.5, 25, 50, 100 and 200 M of naphthoquinone amino
acid derivatives to assay proliferation rate at 72 h post-treatment. ( ) SiHa HPV 16 positive cancer cells
were treated with 6.25, 12.5, 25, 50, 100 and 200 M of naphthoquinone amino acid derivatives to assay
proliferation rate at 72 h post-treatment. ( ) CaLo HPV 18 positive cancer cells were treated with 6.25,
2.5, 25, 50, 100 and 200 M of naphthoquinone amino acid derivatives to assay proliferation rate at 72 h
post-treatment. ( ) C33-A HPV negative cancer cells were treated with 6.25, 12.5, 25, 50, 100 and 200
A
µ
B
µ
C
1
µ
D
µM
of naphthoquinone amino acid derivatives to assay proliferation rate at 72 h post-treatment. Cells
treated with 0.1% of DMSO were used as Control. * represents statistically significant p < 0.05 value.

Molecules 2020, 25, 2058
9 of 18
Table 3. IC50 of naphthoquinone amino acid derivatives in immortal and tumorigenic cell lines after
2 h exposure. Results obtained from three independent experiments.
7
Cell line
Naphthoquine Amino acid Derivatives
IC50
3
a
40.98 µM
47.22 µM
28.8 µM
3
b
3
c
SiIHa
4
a
6.830 µM
11.34 µM
3.209 µM
4
b
4
c
3
a
81.08 µM
56.96 µM
25.20 µM
7.028 µM
2.878 µM
2.697 µM
3
b
3
c
CaLo
C33-A
HaCaT
4a
4
b
4
c
3
a
55.64 µM
55.56 µM
21.36 µM
3
b
3
c
4a
~0.001577 µM
~0.0003566 µM
~0.003454 µM
4
b
4
c
3a
61.6 µM
55.29 µM
40.82 µM
9.882 µM
7.970 µM
~0.3311 µM
3
b
3
c
4a
4
b
4
c
3
. Discussion
The naphthoquinone–amino acid derivatives have been previously reported [3,5] and our group
performed an extensive analysis about the reactivity of the equivalents of each amino acid used in the
reactions, the dependence of the pH and the optimized reactions under ultrasonic and microwave
irradiation reducing the reaction times from days or hours to only a few minutes to improve their
production [24]. In this work tyrosine, valine and tryptophan naphthoquinone derivatives were
synthesized obtaining excellent yields, 80–95%. The results show that chloride naphthoquinone
derivatives yield increased using a weak base (TEA). On the other hand, to improve the yields in
naphthoquinone derivatives, a strong base was needed (KOH), and this can be explained by the
presence of a good releasing group in 2,3-dichloronaphthoquinone favoring the amino acid addition.
The overall electrochemical pathway of naphthoquinone amino acid derivatives is anticipated
to be complicated since both the reduction of naphthoquinone moiety and oxidation of amino acid
substituents are contributing to electron-transfer reactions as reported above. Although a thorough
understanding of the electron-transfer pathway is not considered in this work, the electrochemical
studies of naphthoquinone amino acid derivatives give an insight of possible biological reactions
concerning electron transfer processes that could occur at cellular level. Furthermore, electrochemical
parameters (Table 2) calculated by cyclic voltammetry are considered to predict the biological effect of
newly synthesized compounds as reported elsewhere [33,34]. However, it is worth mentioning that a
direct correlation of the electrochemical parameters with biological activity can be compromised due
to the complexity of biomedical chemistry or, in such a case, to the complexity of the physiological
environment in living systems as compared to the media used for the electrochemical studies.
In this context, the redox potential or half-wave potential (E1/2) is an electrochemical parameter that
has been generally used to assess the biological activity of naphthoquinone compounds [33
–35].
Naphthoquinones with more positive E1/2 values are associated with higher biological effects. This is

Molecules 2020, 25, 2058
10 of 18
because a spontaneous reduction of the compounds occurs, and thus the generation of reactive oxygen
species (ROS) is presumably facilitated. Recall that the main mechanism of action for naphthoquinones
is the generation of ROS. According to this, chloride-naphthoquinone amino acid derivatives (4a–c)
in this work are expected to present higher biological activity than the naphthoquinone derivatives
without the chloride moiety (3a–c) as the E1/2 values reported in Table 2. The E1/2 values for the redox
reaction of chloride-naphthoquinone amino acid derivatives (4a–c) were found in the potential range
of
values in the potential range of
derivatives is at least 110 mV more positive than non-chloride naphthoquinone amino acid derivatives
3a–c). Similar results were reported by our group for chloride naphthoquinone amino acids derivatives
−
1.10 V to
−
1.12 V meanwhile non-chloride naphthoquinone amino acid derivatives (3a–c) exhibited
−
1.21 V to 1.24 V. E1/2 for chloride-naphthoquinone amino acid
−
(
modified with alanine, phenylalanine, methionine, glycine, and asparagine, suggesting that the redox
reaction, and as a consequence, ROS production could occur in a similar manner to the naphthoquinone
compounds reported in the present study [24].
For amino acid substituent groups, the relationship between the electrochemical behavior and
biological activity is unknown. Thus, further studies are needed for better understanding of the
action mechanism. However, the electrochemical behavior related to the oxidation of tyrosine,
valine, and tryptophan in the naphthoquinone compounds may contribute in some extent to
antiproliferative activity. For instance, some authors indicate that the intensity of the current density
due to electrochemical oxidation depends on how the amino acids adsorb or lay at the electrode surface,
that is, if the electro-active amino acid substituents are externally exposed or hidden by the molecule
structure (i.e., proteins, DNA, RNA molecules) to ease the electron-transfer process [36,37]. However,
Dourado et al. [38] mentioned that the oxidation of amino acids is observed in the same potential
region and presents similar electrochemical behavior either tested free or linked to other compounds
or molecules. In this study, note that all naphthoquinone derivatives, 3a–c and 4a–c, exhibit oxidation
processes at similar potential range but chloride-naphthoquinone amino acid derivatives display
well-defined oxidation peaks with high-current density response. This behavior is also attributed to
the influence of the chloride with the amino acid substituent as described previously for the reduction
of the quinone moiety. In fact, it is suggested that chloride-naphthoquinone amino acid derivatives
(4a–c) are easily-adsorbed on the electrode surface enhancing the electrochemical oxidation reaction of
amino acid substituents. Thus, it is clear that chloride substituent group improves the electrochemical
activity of the naphthoquinone amino acid derivatives, and consequently, they could have an important
antiproliferative effect in combination with the amino acid substituent group, possibly facilitating the
drug delivery into the cell. However, further studies are needed to get insights into the mechanism of
drug metabolism or detoxification when amino acid substituents are involved.
Recently it has been shown a proliferation inhibition effect of naphthoquinone amino
acid derivatives in different cell lines. Alanine, methionine, phenylalanine, glycine, and
asparagine-naphthoquinones were synthesized showing inhibition ranked from ~40% to 85% and
30% to 90% in SiHa and MCF-7 cells, respectively. Interestingly, cervix cell line, SiHa, responded
better to non-chloride while breast cell line MCF-7 did to chloride compounds [24]. Nevertheless,
this observation was weak since it was only seen in one cell type from each type of cancer. However,
in this study we included HPV18, HPV16 positive and HPV negative cervical cancer cell lines to
further clarify our previous observation and assure whether cervical cancer cell lines better respond to
non-chloride than to chloride amino acid-naphthoquinones. Additionally, cell lines with different levels
of cancer development were considered to investigated the response to the compounds. Interestingly,
in the present study it was appreciated a difference in HPV18, HPV16, and HPV negative cell
types preferentially responding to chloride than to non-chloride compounds. Among non-chloride
compounds, tryptophan-naphthoquinone (3c) exerted the lesser effect in proliferation inhibition in
HaCaT cells (40.82
µM) and an ascendant effect in C33-A (IC50 = 21.36
µM), CaLo (IC50 = 25.20 µM) and
SiHa (IC50 = 28.8
µM) cell lines. The difference in proliferation inhibition with 3c treatment between
immortal and tumorigenic cells was near double, being an important feature regarding its potential use

Molecules 2020, 25, 2058
11 of 18
as cancer therapy drug. On the other hand, it could be observed that chloride naphthoquinone amino
acid derivatives exerted a proliferation inhibition with more than one magnitude order with respect
to non-chloride compounds. These observations are also consistent with the electrochemical results
obtained in this work since chloride naphthoquinone amino acid derivatives (4a–c) were expected to
present higher cytotoxicity effects than non-chloride naphthoquinone amino acids derivatives (3a–c).
Therefore, a direct correlation of the electrochemical parameters for each chloride compound with
the antiproliferative effect is suggested, however, it must be noted that further studies are needed.
Remarkably, comparing chloride compounds between them, tryptophan-naphthoquinone (4c) has
almost the most potent effect in all cell lines, except for C33-A. Interestingly, Tyrosine-naphthoquinone
(4a) presented the lesser effect in immortal cell line HaCaT (IC50 = 9.882
µM) compared with CaLo
(
IC50 = 7.028 M), SiHa (IC50 = 6.830 M) and C33-A(IC50 = 0.001577 M) suggesting it is a potential
µ
µ
µ
therapy candidate. However, based on the severe effect exerted on cellular proliferation inhibition they
should be proved in animal models to assay risk-benefit. It should be noted that the differential effect
on each cell type may obey to the different cell lines origin and genetic background, which is going to be
reflected in cell proliferation inhibition exerted by naphthoquinone amino acid derivatives. For example,
HPV18 positive CaLo cell line showed resistance (IC50 = 81.08
positive SiHa cells (IC50 = 40.98 M), albeit a medium effect is recorded in immortal HPV negative
HaCaT (IC50 = 61.6 M) and C33-A (IC50 = 55.64 M) HPV negative cells. Despite structural
µM) to 3a treatment opposite to HPV16
µ
µ
µ
differences between (3a), (3b), and (3c) compounds, all naphthoquinone amino acid derivatives present
considerable levels of proliferation inhibition in all cells tested. The percentage inhibition obtained in
our work was similar to other compounds. For example, in a study with the ileocecal adenocarcinoma
cell line HCT-8, 86%, 84% and 59% of proliferation inhibition was shown with phenylalanine, alanine,
and proline naphthoquinone derivatives. In the breast cancer cell line MDAMB-435 proliferation
inhibition was of 100%, 100%, and 36%, while in human multiforme cell line SF-295, 86%, 83%,
and 59% of inhibition was observed, respectively [20]. Interestingly, de Moraes et al. [20] added three
complete amino acids to naphthoquinone structure showing similar cytotoxicity to doxorubicin with
an IC50 of 0.48 in MDAMB-435 cell line. The effect of glycine, alanine, and phenylalanine derivatives
synthesized by de Moraes et al. [20] was similar to our results, highlighting their potential as cytotoxicity
compounds in cancer. Marastoni et al. [39], incorporated leucine, asparagine, phenylalanine and serine
into naphthoquinone with diamine alkyl spacers inhibiting three subunits of proteasome linked to
proliferation inhibition of the breast cancer cell line MDA and ovarian cancer cell line A2780 in the range
of 100 µM similar to the non-chloride compounds concentration used in this study. Remarkably, it
should be noted that the chloride naphthoquine amino acids derivatives reached the nM concentration.
3
Additionally, in Marastoni et al.’s work, the compounds effect was evaluated in 15
×
10 cells, while
3
in our study the number of cells used was of 40
×
10 . The molecules per cell that we used in our
0
study were fewer than Marastoni et al. s study, suggesting that our compounds are more potent than
the ones they tested. Interestingly, in this work, it was shown that chloride naphthoquinone amino
acid derivatives have similar effect to Taxol, a common drug used in cervical cancer treatment [40].
Remarkably, the chloride naphthoquinone amino acid derivatives have almost double the effect of
Taxol in SiHa and C33-A cells.
Amino acid naphthoquinone derivatives performed different effects on cell proliferation of cell
lines, therefore, it could be theorized that each particular effect observed may be dependent on
hydropathy index and protein occurrence of the amino acids. The tyrosine, valine, and tryptophan
amino acids have
−
1.3, 4.2, and 0.9 hydropathy index, respectively. However, the non-chloride (3c)
−
and chloride tryptophan-naphthoquinone (4c) recorded the most potent effect in tested cells, except
in C33-A cells which was severely inhibited by valine-naphthoquinone (4b). However, comparing
tyrosine and tryptophan synthesized in this work versus glycine and asparagine-naphthoquinone
derivatives in previous work [24] it seems probable that hydropathy index could participate in the
compounds effect recorder. Glycine and asparagine possess the negative hydropathy index
−
0.4
and 3.5, respectively. Nevertheless, it should be noted that asparagine hydropathy index is more
−

Molecules 2020, 25, 2058
12 of 18
negative that glycine’s hydropathy index, even though it is more abundant in proteins than Asparagine,
existing 7.2 and 5.1 molecules per protein, respectively [24]. In contrast, it should be noted that valine
hydropathy index is out of range versus glycine, asparagine, tryptophan, and tyrosine without taking
into account the changes that the amino acid could have when it is part of a complex. The amino
acids occurrence in proteins for tyrosine, valine and tryptophan is 3.2, 6.6, and 1.4, respectively.
Since valine and tyrosine-naphthoquinones present similar effects, their occurrence in proteins is not
determinant. In contrast, compound size seems not to be an important feature since it was shown
valine-naphtoquinone only exerted a potent effect in C33-A cells. Even though, it has been demonstrated
that amino acid size is important in the β-turn folding of some proteins therefore the substitution and/or
interaction with amino acid-naphthoquinones could destabilize the proteins structure affecting their
function. Additionally, it must be considered that tyrosine is involved in several cell signaling pathways
and a possible competition with endogenous tyrosine could occur. The occurrence of tryptophan in
proteins is the lowest among the essential amino acids, however it is present in a family of proteins called
GW-182 that participate in miRNA-mediated repression [41], therefore, the interruption or competition
with GW-182 protein synthesis could affect several cellular processes like proliferation, apoptosis,
migration and invasion among others. Nevertheless, this hypothesis needs several experimental
studies to be addressed. In contrast, chloride tyrosine, valine and triptophane-naphthoquinones (4a,b,c)
selectively show antitumorigenic properties versus non-chloride compounds in cervix cancer cell lines,
positioning them as promising compounds for specific cancer treatment.
4
. Materials and Methods
4
.1. General
Commercially supplied 1,4-naphthoquinone, 2,3-dichloronaphthoquinone, tyrosine, valine and
1
13
tryptophan were used for the synthesis without further purification. H and C Nucleus Magnetic
1
Resonance (NMR) spectra were recorded on a Bruker Avance III 400 MHz spectrometer ( H at 400,
13
C at 101 MHz, Silbestreifen, Rheinbstetten, Germany). The spectra were acquired from solution in
methanol-d at room temperature, TMS as internal reference, the chemical shifts ( ) are expressed in
δ
4
part per million (ppm) and the coupling constants (J) in Hz. High-resolution mass spectra (HRMS)
were measured with a Jeol JMS-AccuTOF through DART (Direct Analysis in Real Time, Peabody,
MA, USA) and by ESI (Electrospray Ionization) in an Agilent 6200 Series TOF (Santa Clara, CA, USA)
and 6500 Series Q-TOF LC/MS System (Santa Clara, CA, USA). Infrared spectra were recorded on a
Thermo Scientific NICOLET iS10 with ATR dispositive (SMART iTR, Madison, WI. USA). Melting
points were determined using a Bicote-Stuart SMO 10 apparatus (Stone, Staffordshire, UK) and were
uncorrected. Microwave Assisted Synthesis (MAS) was performed on a CEM Mars 6 oven with a
carrousel device (Matthews, NC, USA). Ultrasound Assisted Synthesis (UAS) was carried out in an
Autoscience Ultrasonic cleaner-AS2060B with 60 Watts of power (Lewisville, TX, USA). TLC was
performed using silica gel 60 PF254 containing gypsum (Merck, Darmstadt, Germany). The isolated
reaction products were found to be >95% purity by NMR analysis.
4
.2. General Procedure for the Synthesis of Compounds 3a–c and 4a–c
The obtention and purification of the compounds were carried out under the methodology
described by [24]. Briefly, the solution of respective amino acid (1.5–2.5 mmol) in dioxane/water (4:1,
1
5 mL for 3a–c derivatives or 20 mL for 4a–c derivatives), was basified with TEA or KOH (Sigma-Aldrich,
◦
St. Louis, MO, USA) aq. (pH 9–10) and activated under microwave irradiation under 110 C, 250 W
for a time of 10 min (Mars 6, CEM, ISASA Latam, S.A. Alajuela, Costa Rica). Then a solution of
naphthoquinone (Sigma-Aldrich, St. Louis, MO, USA) 5 mL (1a) or 2,3-dichloro-1,4-naphthoquinone
(
1b), 10 mL of dioxane:water mixture was added. The reaction mixture was irradiated with the
same parameters by 15–20 min. The progress reaction was monitored by TLC, using MeOH:CHCl3
Sigma-Aldrich, St. Louis, MO, USA) (9:1) as eluent mixture. Finally, 20 mL of HCl (Sigma-Aldrich,
(

Molecules 2020, 25, 2058
13 of 18
St. Louis, MO, USA) (1 N) was added and the precipitated product was filtered and purified by flash
column chromatography staring with dichloromethane (DCM) (Sigma-Aldrich, St. Louis, MO, USA)
and changing the polarity to finish with methanol (Sigma-Aldrich, St. Louis, MO, USA).
4
.3. Spectroscopic Characterization of Amino Acid-1,4-Naphthoquinone Derivatives
IR, NMR, MS and EPR data are available in Supplementary Materials (Figures S1–S19). With
respect to NMR characterization, some compounds reported here and in a previous work [5] presented
complications due to low intensity of peaks as well as absence or presence of some protons or carbons in
the spectra. This phenomenon could be explained considering that it has been reported the formation
of organic radicals in some amino acid-naphthoquinone derivatives with sodium borohydride [20,21].
In this regard, we performed the EPR (electron paramagnetic Resonance) analysis of a previously
reported amino acid-naphthoquinone derivative (2-((1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-4
-(methylthio)butanoic acid) [5], showing the presence of organic radicals even in the solid state (see SI).
A hyperfine coupling could be observed using a basic solution (KOH 1N). Nonetheless, most analyses
are required and studies on EPR and cyclic voltammetry are now in progress to explain this behavior.
2
-((1,4-dioxo-1,4-dihydronphthalen-2-yl)amino)-3-(4-hydroxyphenyl) propanoic acid (3a). Orange
◦
powder. Yield: 90%. m. p.: 214–216 C; IR (ATR): 3334.28, 2922.97, 1680.57, 1595.76, 1557.60, 1510.95,
−
1
1
(
1
(
341.34, 1252.30, 1031.80, 777.39cm ; 1H NMR (400 MHz, Methanol-d4)
d, J = 8.10 Hz, 1H), 7.70 (td, J = 7.60/1.20 Hz, 1H), 7.61 (td, J = 7.60/1.10 Hz, 1H), 7.03 (d, J = 8.40 Hz,
H), 6.65 (d, J = 8.40 Hz, 1H), 5.55 (s, 1H), 4.09 (t, J = 5.40 Hz, 1H), 3.21 (dd, J = 13.90/4.60 Hz, 1H), 3.03
dd, J = 13.90/6.80 Hz, 1H).; 13C NMR (75 MHz, MeOD)
184.69, 182.32, 177.03, 157.26, 149.17, 135.76,
34.82, 133.28, 131.87, 131.50, 129.30, 127.30, 126.76, 116.22, 100.79, 59.96, 37.88, 30.71 ppm. HRMS
δ 7.95 (d, J = 8.00 Hz, 1H), 7.93
δ
1
(
ESI/Q-TOF) m/z: [M + H]+ for C H NO : 338.0984; found: 338.1008.
19 15 5
2
9
-((1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-methylbutanoic acid (3b). Orange powder. Yield
◦
◦
2%. m. p.: 170–172 C; (Lit: 171.1–173.1 C). IR (ATR): 3330.04, 2922.97, 2867.84, 1680.57, 1595.76,
−1
1
566.08, 1502.47, 1341.34, 1303.18, 1053.00, 1031.80, 730.74 cm ; (Lit; No rep); 1H NMR (400 MHz,
Methanol-d4) = 8.09 (dd, J = 7.60/1.00 Hz, 1H), 8.03 (dd, J = 7.70/1.00 Hz, 1H), 7.79 (td, J = 7.60/1.40 Hz,
H), 7.71 (td, J = 7.50/1.30 Hz, 1H), 5.74 (s, 1H), 5.49 (s, 1H), 3.99 (d, J = 5.60 Hz, 1H), 2.39–2.30 (m, 1H),
.10 (d, J = 6.90 Hz, 3H), 1.05 (d, J = 6.80 Hz, 3H); (Lit: 1H NMR (500.13 MHz, DMSO-d6): = 13.22 (bs,
δ
1
1
1
1
δ
H, OH) ppm; 8.01 (dd, J = 7.57, 0.95 Hz, 1H, CH); 7.94 (dd, J = 7.57, 0.95 Hz, 1H, CH); 7.85 (dt, J = 7.57,
.26 Hz, 1H, CH); 7.76 (dt, J = 7.57, 1.26 Hz, 1H, CH); 6.85 (d, J = 8.51 Hz, 1H, CH); 5.72 (s, 1H, CH);
3
.93–3.96 (m, 1H, CH); 2.23–2.27 (m, 1H, CH); 0.96 (d, J = 6.62 Hz, 3H, CH3); 0.91 (d, J = 6.94 Hz, 3H,
13
CH3) ).; C NMR (101 MHz, MeOD)
δ 185.11, 182.31, 170.32, 135.95, 133.67, 131.98, 127.47, 126.92,
3
13
1
01.82, 100.34, 61.83, 31.94, 19.19, 18.85 ppm; (Lit: C NMR (125.75 MHz, DMSO-d6):
δ = 135.49 (CH),
1
32.98 (CH), 126.52 (CH), 125.88 (CH), 101.44 (CH), 60.67 (CH), 30.33 (CH), 19.15 (CH ), 19.03 (CH ),
3
3
ppm). HRMS (ESI/Q-TOF) m/z: [M + H]+ for C H NO : 274.1035, found: 274.1063. Characterization
15
15
4
according to Janeczko M et al., [21].
2
-((1,4-dioxo-1,4-dihidronaphthalen-2-yl)amino)-3-(1H-indol-3-yl)propanoic acid (3c). Orange powder.
◦
Yield 88%. m. p.: 157–159 C (Lit: 159.1-161), IR (ATR): 3338.52, 2922.97, 1672.08, 1600, 1561.84, 1506.71,
1
1
332.86, 1307.42, 1265.02, 828.27, 722.26; H NMR (400 MHz, Methanol-d )
δ
7.89 (dd, J = 7.70/1.30 Hz,
4
2
7
2
7
H), 7.66 (td, J = 7.50/1.40 Hz, 1H), 7.56 (td, J = 4.90/2.50 Hz, 3H), 7.26 (d, J = 8.10 Hz, 1H), 7.10 (s, 1H),
.00 (t, J = 7.30 Hz, 1H), 6.90 (t, J = 7.30 Hz, 1H), 5.54 (s, 1H), 4.23–4.18 (m, 1H), 3.49 (dd, J = 14.60/4.30 Hz,
1
H), 3.12 (q, J = 7.30 Hz, 1H); (Lit: H NMR (300 MHz, DMSOd ):
δ = 10.90 (s,1H), 7.92-8.00 (m,2H),
6
.83 (t, J = 7.5 Hz, 1H), 7.74 (t, J = 7.5 Hz, 1H), 7.52 (d, J = 8.10 Hz, 1H), 7.32 (dd, J = 0.6, 8.1 Hz, 1H), 7.18
(
(
1
d, J = 2.4 Hz, 1H), 7.05 (t, J = 7.8 Hz, 1H), 6.91–6.97 (m. 2H), 5.74 (s, 1H), 4.45–4.52 (m, 1H), 3.36–3.38
m, 2H)).; 13C NMR (101 MHz, MeOD)
184.66, 182.27, 178.44, 149.39, 137.94, 135.70, 134.79, 133.22,
31.81, 129.05, 127.24, 126.69, 124.61, 122.32, 119.75, 119.34, 112.21, 111.20, 100.67, 59.35, 28.77 ppm;
HRMS (ESI/Q-TOF) m/z: [M + H]+ for C H N O ]: 361.1144, found: 361.1173. Characterization
δ
21
16
2
4
according to Janeczko et al. [21].

Molecules 2020, 25, 2058
14 of 18
4
.4. Spectroscopic Characterization of Amino Acid-2,3-Dichloronaphthoquinone Derivatives
-((3-chloro-1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-(4-hydroxyphenyl)propanoic acid (4a).
2
◦
◦
Dark-red powder. Yield 95%. m. p.: 78–80 C (Lit: 74–76 C). IR (ATR): 3300.35, 2918.73, 2863.60,
1
1
735.69, 1591.52, 1553.36, 1506.71, 1226.86, 1031.80, 828.27, 718.02; (Lit: IR (KBr): 3305, 1739, 1684,
1
641); H NMR (400 MHz, Methanol-d )
δ 7.99 (d, J = 7.3 Hz, 1H), 7.93 (d, J = 7.8 Hz, 1H), 7.73 (td,
4
J = 7.50/1.40 Hz, 1H), 7.65 (td, J = 7.50/1.30 Hz, 1H), 7.05–6.95 (m, 2H), 6.64 (dd, J = 23.70/8.50 Hz, 2H),
1
5
.59 (s, 1H), 5.32 (t, J = 5.70 Hz, 1H), 3.14 (ddd, J = 38.30, 14.10, 5.80 Hz, 1H); (Lit; H NMR (300 MHz,
DMSO-d6)
.91 (d, 2H, 8.4), 6.55 (d, 2H, 8.4). 5.05 (m, 1H, 5.4), 2.97–3.11 (m, 2H).; C NMR (101 MHz, MeOD)
84.72, 183.42, 179.78, 156.12, 134.65, 132.48, 130.46, 130.10, 125.81, 114.85, 99.79, 92.10, 58.46, 39.09 ppm.
HRMS (ESI/Q-TOF) m/z: [M + H]+ for C H ClNO : 372.0594, found: 372.0672. Characterization
δ 9.25 (br s, 1H), 7.90–7.98 (td, 2H, 7.5, 1.3), 7.82 (td, 1H, 7.4, 1.5), 7.72 (td, 1H, 7.4, 1.6),
13
6
δ
1
19
14
5
according to Gorohovsky et al. [23].
2
-((3-chloro-1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-methylbutanoic acid (4b). Red powder.
◦
◦
Yield 92%. m. p.: 54–56 C (Lit: 50–52 C); IR (ATR): 3308.83, 2961.13, 2867.84, 1731.45, 1676.38, 1595.76,
1
1
570.32, 1290.46, 1137.81, 819.79, 722.26, (Lit: IR (KBr): 3456, 3309, 1749, 1688, 1651); H NMR (400 MHz,
Methanol-d4)
δ 8.00 (dd, J = 7.60/1.50 Hz, 1H), 7.75 (td, J = 7.60/1.40 Hz, 1H), 7.67 (td, J = 7.50/1.40 Hz,
1
H), 5.05 (d, J = 4.10 Hz, 1H), 2.28 (dq, J = 6.80/4.30 Hz, 1H), 1.26 (s, 1H), 1.12 (d, J = 7.00 Hz, 3H), 1.00
1
(d, J = 6.9 Hz, 3H); (Lit; H NMR (300 MHz, DMSO-d )
δ
8.02 (d, 1H, 75), 7.91 (d, 1H, 7.1), 7.66 (td,
6
1
H, 7.4, 1.3), 7.53 (td, 1H, 7.5, 1.5), 6.37 (br, s, 1H), 5.01–5.12 (m, 1H), 1.03 (d, 3H, 6.9), 0.97 (d, 3H, 6.8);
1
3
C NMR (75 MHz, MeOD)
δ 180.22, 177.21, 174.80, 143.93, 135.07, 132.95, 130.33, 126.96, 126.41, 62.23,
3
3
2.89, 29.79, 17.70, 17.45 ppm. HRMS (ESI/Q-TOF) m/z: [M + H]+ for C H ClNO : 308.0645, found:
08.0668. Characterization according to Gorohovsky et al. [23].
15
14
4
2
-((3-chloro-1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-(1H-indol-3-yl)propanoic acid (4c). Red
◦
◦
powder. Yield 91%. m. p.: 148–150 C (Lit: 153–155 C); IR (ATR): 3423.32, 3296.11, 2927.21, 1676.33,
1
1
595.76, 1561.84, 1404.95, 1298.94, 1260.78, 1226.86, 1031.80, 845.23, 739.22, (Lit: IR (KBr): 3437, 3318,
1
728, 1680, 1602, 1567, 1511, 1342, 1300, 1272); H NMR (400 MHz, Methanol-d )
δ 10.28 (s, 1H),
4
8.01–7.84 (m, 2H), 7.62 (td, J = 21.20, 20.6, 10.0 Hz, 2H), 7.50 (dd, J = 19.00/7.60 Hz, 2H), 7.12 (d,
J = 9.40 Hz, 1H, NH), 7.05 (d, J = 6.60 Hz, 1H, NH), 6.94 (t, J = 7.30 Hz, 1H), 6.87 (t, J = 7.10 Hz, 1H),
1
5
5
7
.42 (t, J = 5.90 Hz, 1H), 3.48 (dd, J = 14.60/4.50 Hz, 2H); (Lit: H RMN (DMSO-d ):
δ
= 3.39 (m, CH2),
6
.36 (m, CH), 6.58 (br, 1H), 6.93 (t, J = 5.60 Hz, 1H), 7.03 (t, J = 5.60 Hz, 1H), 7.28 (d, J = 6.32 Hz, 1H),
.31 (d, J = 6.38 Hz, 1H), 7.49 (d, J = 6.32 Hz, 1H), 7.85–8.05 (m, 4H), 10.95 (NH), 12.95 (br, CO2H)); 13
179.54, 179.49, 173.75, 146.19, 136.57, 134.39, 134.17, 132.17, 127.43, 126.23,
25.59, 124.07, 123.97, 121.05, 118.56, 118.06, 110.80, 108.80, 58.01, 29.29 ppm; (Lit: 13C RMN (DMSO-d6):
= 28.60 (CH2), 56.40 (CH), 107.9, 111.0, 111.3, 118.1, 118.5, 121.0, 124.4, 125.7, 126.4, 127.1, 129.6, 131.5,
32.8, 134.8, 136.1, 144.4, 172.6 (CO2H), 175.4 (C=O), 179.6 (C=O)); HRMS (ESI/Q-TOF) m/z: [M + H]+
C H ClN O for 395.0754, found: 395.0770. Characterization according to Shrestha et al., [42].
C
NMR (101 MHz, MeOD)
1
δ
δ
1
21
15
2
4
4
.5. Cyclic Voltammetry
Electrochemical studies of naphthoquinone–amino acids (3a–c) and chloride–naphthoquinone
–
amino acids (4a–c) derivatives were studied by cyclic voltammetry (CV) as previously reported [24].
Briefly, non-aqueous solutions of compounds 3a–c or 4a–c at a concentration of 5 mM were dissolved in
dimethyl sulfoxide (DMSO, Sigma–Aldrich, St. Louis, MO, USA) containing 0.1 M tetrabutylammonium
tetrafluoroborate (TBABF , Sigma–Aldrich, St. Louis, MO, USA) as supporting electrolyte. Then, the
4
non-aqueous solutions containing 3a–c or 4a–c were studied by CV in a three-electrode cell using
2
a freshly polished glassy carbon disk electrode (GC) (0.07 cm , BASi, West Lafayette, IN, USA) as
+
working electrode and a Pt wire (Alfa-Aesar, Tewksbury, MA, USA) as counter electrode. An Ag/Ag
electrode in 0.1 M TBABF DMSO was used as pseudo-reference electrode. A potential scan was
4
/
+
−1
performed from
−
2.0 V to 0.75 V vs. Ag/Ag at 100 mV s in the cathodic direction in order to identify
any electron transfer reaction associated to compounds 3a–c or 4a–c using a potentiostat/galvanostat

Molecules 2020, 25, 2058
15 of 18
PAR VersaStat 3 (Ametek, Inc. Berwyn, PA, USA). Furthermore, any redox reaction processes of 3a–c
−1
or 4a–c were further studied at a scan rate of 10, 25, 50, 100, 200, and 300 mV s . As received TBABF4
and DMSO were used without further purification or drying processes. All the non-aqueous testing
solutions were degassed for 30 min with high-purity N gas before cyclic voltammetry experiments.
2
4
.6. Cell Lines
HPV-16 positive, cervical tumor line SiHa; HPV-18 positive, cervical tumor line CaLo; HPV
negative, cervical tumor line C33-A, and HPV negative non-tumorigenic cell line HaCaT were grown in
Dulbecco’s Modified Eagle’s Medium (DMEM) (Invitrogen Corporation, Carlsbad, CA, USA) enriched
with 5% fetal bovine serum (FBS). Medium change and passage were performed every 3 and 4 days,
respectively. SiHa, CaLo, C33-A and HaCaT cell lines were kindly provided by Ph.D. Gariglio’s Lab
from CINVESTAV-IPN.
4
.7. Cell Proliferation Analysis
Cell proliferation was quantified by violet crystal dye in 1X phosphate-buffered saline (PBS)
(
2.7 mM KCl, 1.8 mM KH PO , 136 mM NaCl, 10 mM Na HPO pH 7.4). The treated cells were
2 4 2 4
incubated in methanol for 15 min and washed two times with distilled water. Cells were dyed with
.1% crystal violet and washed three times with water and finally violet crystal was recovered with 10%
0
acid acetic to be analyzed in microplate reader Multiskan GO Spectrophotometer (Thermo Scientific
Ratastie, Finland).
™,
5
. Conclusions
As in our previous report, the synthesis of tyrosine, valine, and tryptophan naphthoquinone
derivatives were obtained by microwave assisted synthesis with excellent yields and in a shorter
time. Chloride naphthoquinone derivatives could be successfully prepared using a weak base TEA.
The obtained results on the analysis of the synthetic methodology showed a direct dependence of the
stoichiometry of the reactants and pH by deprotonation of the amino acids increasing yield with the
microwave system. Electrochemical studies showed that naphthoquinones amino acid derivatives
recorded a well-defined redox process and calculated redox potential E1/2 values give an overall
insight towards their biological activity. The biological evaluation showed a potent proliferation
inhibition with chloride naphthoquinone versus non-chloride amino acids derivatives. Non-chloride
tryptophan (3c) and chloride Tyrosine-naphtoquinone (4a) compounds showed preferential effect in
cervical tumorigenic cell lines versus immortal cell line.
Supplementary Materials: The following are available online, Figure S1. IR spectrum of 2-((1,4-dioxo-1,4-
dihydronphthalen-2-yl)amino)-3-(4-hydroxyphenyl) propanoic acid (3a), Figure S2.
IR spectrum of
2
2
2
-((1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-methylbutanoic acid (3b), Figure S3. IR spectrum of
-((1,4-dioxo-1,4-dihidronaphthalen-2-yl)amino)-3-(1H-indol-3-yl)propanoic acid (3c), Figure S4. IR spectrum of
-((3-chloro-1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-(4-hydroxyphenyl)propanoic acid (4a), Figure S5.
IR spectrum of 2-((3-chloro-1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-methylbutanoic acid (4b), Figure S6.
IR spectrum of 2-((3-chloro-1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-(1H-indol-3-yl)propanoic acid (4c),
Figure S7. NMR spectrum of 2-((1,4-dioxo-1,4-dihydronphthalen-2-yl)amino)-3-(4-hydroxyphenyl) propanoic
acid (3a), 1H (A) and 13C (B), Figure S8. NMR spectrum of 2-((1,4-dioxo-1,4-dihydronaphthalen-2-yl)
amino)-3-methylbutanoic acid (3b), 1H (A) and 13C (B), Figure S9. NMR spectrum of 2-((1,4-dioxo-1,4-
dihidronaphthalen-2-yl)amino)-3-(1H-indol-3-yl)propanoic acid (3c), 1H (A) and 13C (B), Figure S10. NMR
spectrum of 2-((3-chloro-1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-(4-hydroxyphenyl)propanoic acid (4a),
1
H (A) and 13C (B), Figure S11. NMR spectrum of 2-((3-chloro-1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-
3
-methylbutanoic acid (4b), 1H (A) and 13C (B), Figure S12. NMR spectrum of 2-((3-chloro-1,4-dioxo-1,4-
dihydronaphthalen-2-yl)amino)-3-(1H-indol-3-yl)propanoic acid (4c), 1H (A) and 13C (B), Figure S13. MS
spectrum of 2-((1,4-dioxo- 1,4-dihydronphthalen-2-yl)amino)-3-(4-hydroxyphenyl) propanoic acid (3a), Figure S14.
MS spectrum of 2-((1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-methylbutanoic acid (3b), Figure S15. MS
spectrum of 2-((1,4-dioxo-1,4-dihidronaphthalen-2-yl)amino)-3-(1H-indol-3-yl)propanoic acid (3c), Figure S16. MS
spectrum of 2-((3-chloro-1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-(4-hydroxyphenyl)propanoic acid (4a),
Figure S17. MS spectrum of 2-((3-chloro-1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-methylbutanoic acid (4b),
Figure S18. MS spectrum of 2-((3-chloro-1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-3-(1H-indol-3-yl)propanoic

Molecules 2020, 25, 2058
16 of 18
acid (4c), Figure S19. EPR spectrum of 2-((1,4-dioxo-1,4-dihydronaphthalen-2-yl)amino)-4-(methylthio)butanoic
acid, in solid state (A) and KOH 1N solution (B).
Author Contributions: Conceptualization, D.d.L. and J.A.L.; Data curation, S.C.-R., J.G.A.-H., E.R.-A., I.L.E.-G.,
S.M.D.-T., Y.L.-H., H.H.-L., L.L., D.d.L. and J.A.L.; Formal analysis, S.C.-R., J.G.A.-H., E.R.-A., I.L.E.-G., S.M.D.-T.,
Y.L.-H., H.H.-L., L.L., D.d.L. and J.A.L.; Funding acquisition, D.d.L. and J.A.L.; Investigation, S.C.-R., J.G.A.-H.;
Methodology, S.C.-R., J.G.A.-H. All authors have read and agreed to the published version of the manuscript.
Funding: This research was funded by National Council for Science and Technology, Grant number
CB-2013-01-220844, PhD Scholarship number 304251 and PhD Scholarship number 589994.
Acknowledgments: E.R.-A.: D.d.L. and L.L. acknowledge to the group of Instituto de Qu
especially to Braulio Rodr guez Molina, the technical support to (Ma. de los ngeles Peña Gonz
Huerta Salazar, Mar a del Carmen Garc lez and Everardo Tapia Mendoza.), to all the facilities to perform
í
mica of the UNAM,
í
Á
ález, Elizabeth
í
ía Gonzá
the characterization of the compounds and material used for the experiments.
Conflicts of Interest: The authors declare no conflict of interest.
References
1
.
Sikka, H.C.; Shimabukuro, R.H.; Zweig, G. Studies on Effect of Certain Quinones. Plant Physiol. 1972, 49,
81–384. [CrossRef] [PubMed]
3
2
.
Kosiha, A.; Parthiban, C.; Elango, K.P.; Koshika, A. Synthesis, characterization and DNA binding/cleavage,
protein binding and cytotoxicity studies of Co(II), Ni(II), Cu(II) and Zn(II) complexes of aminonaphthoquinone.
J. Photochem. Photobiol. B: Boil. 2017, 168, 165–174. [CrossRef] [PubMed]
3.
4.
5.
6.
Chen, J.; Huang, Y.-W.; Liu, G.; Afrasiabi, Z.; Sinn, E.; Padhye, S.; Ma, Y. The cytotoxicity and mechanisms of
1,2-naphthoquinone thiosemicarbazone and its metal derivatives against MCF-7 human breast cancer cells.
Toxicol. Appl. Pharmacol. 2004, 197, 40–48. [CrossRef]
Kongkathip, N.; Kongkathip, B.; Siripong, P.; Sangma, C.; Luangkamin, S.; Niyomdecha, M.; Pattanapa, S.;
Piyaviriyagul, S.; Kongsaeree, P. Potent antitumor activity of synthetic 1,2-Naphthoquinones and
1
,4-Naphthoquinones. Bioorganic Med. Chem. 2003, 11, 3179–3191. [CrossRef]
Li, C.J.; Li, Y.-Z.; Pinto, A.V.; Pardee, A.B. Potent inhibition of tumor survival in vivo by beta -lapachone
plus taxol: Combining drugs imposes different artificial checkpoints. Proc. Natl. Acad. Sci. USA 1999, 96,
1
3369–13374. [CrossRef]
Kongkathip, N.; Luangkamin, S.; Kongkathip, B.; Sangma, C.; Grigg, R.; Kongsaeree, P.; Prabpai, S.;
Pradidphol, N.; Piyaviriyagul, S.; Siripong, P. Synthesis of Novel Rhinacanthins and Related Anticancer
Naphthoquinone Esters. J. Med. Chem. 2004, 47, 4427–4438. [CrossRef] [PubMed]
7
8
.
.
A Pedersen, J. On the application of electron paramagnetic resonance in the study of naturally occurring
quinones and quinols. Spectrochim. Acta Part A: Mol. Biomol. Spectrosc. 2002, 58, 1257–1270. [CrossRef]
Coates, C.S.; Ziegler, J.; Manz, K.; Good, J.; Kang, B.; Milikisiyants, S.; Chatterjee, R.; Hao, S.; Golbeck, J.H.;
Lakshmi, K.V. The Structure and Function of Quinones in Biological Solar Energy Transduction: A Cyclic
Voltammetry, EPR, and Hyperfine Sub-Level Correlation (HYSCORE) Spectroscopy Study of Model
Naphthoquinones. J. Phys. Chem. B 2013, 117, 7210–7220. [CrossRef]
9
.
Smithson, C.S.; Macdonald, D.J.; Letvenuk, T.M.; Carello, C.E.; Jennings, M.; Lough, A.J.; Britten, J.; Decken, A.;
Preuss, K.E. A 1,2,3-dithiazolyl-o-naphthoquinone: A neutral radical with isolable cation and anion oxidation
states. Dalton Trans. 2016, 45, 9608–9620. [CrossRef]
1
1
1
0. Tar
ábek, J.; Wen, J.; Dron, P.I.; Pospíšil, L.; Michl, J. EPR Spectroscopy of Radical Ions of a
2
,3-Diamino-1,4-naphthoquinone Derivative. J. Org. Chem. 2018, 83, 5474–5479. [CrossRef]
1. Wardman, P. Electron transfer and oxidative stress as key factors in the design of drugs selectively active in
hypoxia. Curr. Med. Chem. 2001, 8, 739–761. [CrossRef]
2. Ham, S.W.; Choe, J.-I.; Wang, M.-F.; Peyregne, V.; Carr, B. Fluorinated quinoid inhibitor: Possible ‘pure’
arylator predicted by the simple theoretical calculation. Bioorganic Med. Chem. Lett. 2004, 14, 4103–4105.
[CrossRef]
1
1
3. Kar, S.; Wang, M.; Ham, S.W.; Carr, B. Fluorinated Cpd 5, a pure arylating K-vitamin derivative, inhibits
human hepatoma cell growth by inhibiting Cdc25 and activating MAPK. Biochem. Pharmacol. 2006, 72,
1
217–1227. [CrossRef]
4. Park, H.; Carr, B.; Li, M.; Ham, S.W. Fluorinated NSC as a Cdc25 inhibitor. Bioorganic Med. Chem. Lett. 2007
7, 2351–2354. [CrossRef] [PubMed]
,
1

Molecules 2020, 25, 2058
17 of 18
1
5. Subramaniya, B.R.; Srinivasan, G.; Sadullah, S.S.M.; Davis, N.; Subhadara, L.B.R.; Halagowder, D.;
Devaraj, S.N. Apoptosis Inducing Effect of Plumbagin on Colonic Cancer Cells Depends on Expression of
COX-2. PLoS ONE 2011. [CrossRef] [PubMed]
1
6. Parkin, D.M.; Bray, F.; Ferlay, J.; Pisani, P. Estimating the world cancer burden: Globocan 2000. Int. J. Cancer
2
001, 94, 153–156. [CrossRef] [PubMed]
1
7. Woodworth, C.D.; Cheng, S.; Simpson, S.; Hamacher, L.; Chow, L.T.; Broker, T.R.; A Dipaolo, J. Recombinant
retroviruses encoding human papillomavirus type 18 E6 and E7 genes stimulate proliferation and delay
differentiation of human keratinocytes early after infection. Oncogene 1992, 7, 619–626.
1
1
2
8. Hausen, H.Z. Immortalization of human cells and their malignant conversion by high risk human
papillomavirus genotypes. Semin. Cancer Boil. 1999, 9, 405–411. [CrossRef] [PubMed]
9. Bittner, S.; Gorohovsky, S.; Levi, O.P.-T.; Becker, J.Y. Synthesis, electrochemical and spectral properties of
some ω-N-quinonyl amino acids. Amino Acids 2002, 22, 71–93. [CrossRef] [PubMed]
0. De Moraes, T.A.P.; Filha, M.J.S.; Camara, C.A.; Da Silva, T.M.S.; Soares, B.M.; Bomfim, I.S.;
Pessoa, C.; Ximenes, G.C.; Silva, V.; Junior, V.A.S. Synthesis and Cytotoxic Evaluation of a Series of
2
-Amino-Naphthoquinones against Human Cancer Cells. Molecules 2014, 19, 13188–13199. [CrossRef]
2
2
2
2
1. Janeczko, M.; Demchuk, O.M.; Strzelecka, D.; Kubi n´ ski, K.; Maslyk, M. New family of antimicrobial agents
derived from 1,4-naphthoquinone. Eur. J. Med. Chem. 2016, 124, 1019–1025. [CrossRef] [PubMed]
2. Bittner, S.; Gorohovsky, S.; Lozinsky, E.; Shames, A.I. EPR study of anion radicals of various N-quinonyl
amino acids. Amino Acids 2000, 19, 439–449. [CrossRef] [PubMed]
3. Gorohovsky, S.; Bittner, S. Novel N-quinonyl amino acids and their transformation to 3-substituted
p-isoxazinones. Amino Acids 2001, 20, 135–144. [CrossRef] [PubMed]
4. Rivera-
Á
valos, E.; De Loera, D.; Araujo-Huitrado, J.G.; Escalante-Garc
ía, I.L.; Muñoz-Sánchez, M.A.;
Hern ndez, H.; L
á
ó
pez, J.A.; L pez, L. Synthesis of Amino Acid-Naphthoquinones and In Vitro Studies on
ó
Cervical and Breast Cell Lines. Mol. 2019. [CrossRef]
2
5. Roy, S.; Guin, P.S. Solvation of 1-Amino-4-Hydroxy-9,10-Anthraquinone Governs Its Electrochemical Behavior
in Non-Aqueous and Aqueous Media: A Cyclic Voltammetry Study. J. Electrochem. Soc. 2014, 162, 124–131.
[CrossRef]
2
2
2
6. Guin, P.S.; Das, S.; Mandal, P.C. Electrochemical Reduction of Quinones in Different Media: A Review.
Int. J. Electrochem. 2011, 2011, 1–22. [CrossRef]
7. Eggins, B.R.; Chambers, J.Q. Proton Effects in the Electrochemistry of the Quinone Hydroquinone System in
Aprotic Solvents. J. Electrochem. Soc. 1970. [CrossRef]
8. Aguilar-Mart
Mac as-Ruvalcaba, N. An Experimental and Theoretical Study of the Substituent Effects on the Redox
Properties of 2-[(R-phenyl)amine]-1,4-naphthalenediones in Acetonitrile. J. Org. Chem. 1999, 64, 3684–3694.
CrossRef]
ínez, M.; Cuevas, G.; Jiménez-Estrada, M.; González, I.; Lotina-Hennsen, B.;
í
[
2
9. Cauquis, G.; Marbach, G. The Redox Behavior of Biological Quinones and its Relation With the Mitochondrial
Respiratory Chain BT–Biological Aspects of Electrochemistry. In Proceedings of the 1st International
Symposium, Istituto Superiore di Sanità, Rome, Italy, 31 May–4 June 1971; Birkhäuser Basel: Basel,
Switzerland, 1971; pp. 205–214. [CrossRef]
3
3
3
3
0. Staley, P.A.; Lopez, E.M.; Clare, L.A.; Smith, D.K. Kinetic Stabilization of Quinone Dianions via Hydrogen
Bonding by Water in Aprotic Solvents. J. Phys. Chem. C 2015, 119, 20319–20327. [CrossRef]
1. Bard, A.J.; Faulkner, L.R. Electrochemical Methods: Fundamentals and Applications, 2nd ed.; John Wiley & Sons:
Hoboken, NJ, USA, 2007.
2. Song, Y.; Buettner, G.R. Thermodynamic and kinetic considerations for the reaction of semiquinone radicals
to form superoxide and hydrogen peroxide. Free. Radic. Boil. Med. 2010, 49, 919–962. [CrossRef]
3. De Abreu, F.C.; Ferraz, P.A.D.L.; Goulart, M.O.F. Some Applications of Electrochemistry in Biomedical
Chemistry. Emphasis on the Correlation of Electrochemical and Bioactive Properties. J. Braz. Chem. Soc.
2
002, 13, 19–35. [CrossRef]
3
4. Hillard, E.A.; De Abreu, F.C.; Ferreira, D.C.M.; Jaouen, G.; Goulart, M.O.F.; Amatore, C. ChemInform
Abstract: Electrochemical Parameters and Techniques in Drug Development, with an Emphasis on Quinones
and Related Compounds. ChemInform 2008, 39, 2612–2628. [CrossRef]
3
5. Pereyra, C.E.; Dantas, R.F.; Ferreira, S.B.; Gomes, L.P.; Silva-Junior, F.P. The diverse mechanisms and
anticancer potential of naphthoquinones. Cancer Cell Int. 2019, 19, 207–220. [CrossRef] [PubMed]

Molecules 2020, 25, 2058
18 of 18
3
6. Enache, T.A.; Paquim, A.M.C.; Oliveira-Brett, A.M. Amyloid–
β
peptides time-dependent structural
modifications: AFM and voltammetric characterization. Anal. Chim. Acta 2016, 926, 36–47. [CrossRef]
PubMed]
[
3
3
7. Enache, T.A.; Brett, C. Alzheimer’s disease amyloid beta peptides in vitro electrochemical oxidation.
Bioelectrochemistry 2017, 114, 13–23. [CrossRef] [PubMed]
8. Dourado, A.H.B.; Pastrian, F.; De Torresi, S.I.C. The long and successful journey of electrochemically active
amino acids. From fundamental adsorption studies to potential surface engineering tools. Anais da Academia
Brasileira de Ciências 2018, 90, 607–630. [CrossRef]
3
4
9. Marastoni, M.; Trapella, C.; Scotti, A.; Fantinati, A.; Ferretti, V.; Marzola, E.; Eleonora, G.; Gavioli, R.; Preti, D.
Naphthoquinone amino acid derivatives, synthesis and biological activity as proteasome inhibitors. J. Enzym.
Inhib. Med. Chem. 2017, 32, 865–877. [CrossRef]
0. Wang, J. Combination Treatment of Cervical Cancer Using Folate-Decorated, pH-Sensitive, Carboplatin
and Paclitaxel Co-Loaded Lipid-Polymer Hybrid Nanoparticles. Drug Des. Dev. Ther. 2020, 14, 823–832.
[CrossRef]
4
4
1. Chekulaeva, M.; Parker, R.; Filipowicz, W. The GW/WG repeats of Drosophila GW182 function as effector
motifs for miRNA-mediated repression. Nucleic Acids Res. 2010, 38, 6673–6683. [CrossRef]
2. Shrestha-Dawadi, P.B.; Bittner, S.; Fridkin, M.; Rahimipour, S. On the Synthesis of Naphthoquinonyl
Heterocyclic Amino Acids. Synthesis 1996, 1996, 1468–1472. [CrossRef]
Sample Availability: Samples of the compounds 3a–c and 4a–c are available from the authors.
©
2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
CC BY) license (http://creativecommons.org/licenses/by/4.0/).
(
