Synthesis, structure, linear and nonlinear properties of tricyanofuran–terminated merocyanine dyes

Article abstract of DOI:10.1016/j.molstruc.2019.04.001

Structural and spectroscopic characteristics of merocyanine dyes are important because of their potential applications in optoelectronics and sensors. Herein we report synthesis, X-ray diffraction characterization of crystal structure, spectroscopic and NMR studies of four merocyanine dyes which, according to their strong donor-acceptor structure, exhibit a second order polarizability (β). Crystallographic studies demonstrated an almost planar structure of all molecules and indicated the occurrence of conformational changes in π-conjugated bridge between donor and acceptor. For three homologues similar packing modes, defined mostly by week C[sbnd]H?N interactions, were found in crystals. Bond length alternation (BLA) values have been evaluated using crystallographic and NMR data and have shown a correlation to their nonlinear optical activity. Second order polarizabilities for all compounds were measured using hyper Rayleigh scattering (HRS) in solution. It was found that the merocyanines studied exhibit very large second order polarizabilities (up to 4.1 10^?27 esu), making them potentially useful for materials for second harmonic generation (SHG). Unfortunately, they do not demonstrate acentric packing of chromophores, which is required for SHG in the crystalline state, but may show promise for other applications such as poled polymer blends or for SHG sensing in biological environments.

Full text of DOI:10.1016/j.molstruc.2019.04.001

Accepted Manuscript
Synthesis, structure, linear and nonlinear properties of Tricyanofuran–Terminated
merocyanine dyes
John P. Tillotson, Georgii Bogdanov, Evgheni V. Jucov, Victor N. Khrustalev, Sergei
Rigin, Joel M. Hales, Joseph W. Perry, Tatiana V. Timofeeva
PII:
S0022-2860(19)30390-4
DOI:
https://doi.org/10.1016/j.molstruc.2019.04.001
MOLSTR 26373
Reference:
To appear in: Journal of Molecular Structure
Received Date: 19 January 2019
Revised Date: 30 March 2019
Accepted Date: 1 April 2019
Please cite this article as: J.P. Tillotson, G. Bogdanov, E.V. Jucov, V.N. Khrustalev, S. Rigin, J.M. Hales,
J.W. Perry, T.V. Timofeeva, Synthesis, structure, linear and nonlinear properties of Tricyanofuran–
Terminated merocyanine dyes, Journal of Molecular Structure (2019), doi: https://doi.org/10.1016/
j.molstruc.2019.04.001.
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to
our customers we are providing this early version of the manuscript. The manuscript will undergo
copyediting, typesetting, and review of the resulting proof before it is published in its final form. Please
note that during the production process errors may be discovered which could affect the content, and all
legal disclaimers that apply to the journal pertain.

ACCEPTED MANUSCRIPT
Synthesis, Structure, Linear and Nonlinear Properties of Tricyanofuran–Terminated
Merocyanine Dyes
John P. Tillotson1*, Georgii Bogdanov2, Evgheni V. Jucov2, Victor N. Khrustalev2,3, Sergei
Rigin2, Joel M. Hales1, Joseph W. Perry1, Tatiana V. Timofeeva2*
1School of Chemistry and Biochemistry, Georgia Institute of Technology, Atlanta, Georgia, 30332 USA
2Department of Chemistry, New Mexico Highlands University, Las Vegas, New Mexico, 87701 USA
3Peoples’ Friendship University of Russia (RUDN University), 117198 Moscow, Russia
ABSTRACT
Structural and spectroscopic characteristics of merocyanine dyes are important because of their
potential applications in optoelectronics and sensors. Herein we report synthesis, X-ray
diffraction characterization of crystal structure, spectroscopic and NMR studies of four
merocyanine dyes which, according to their strong donor-acceptor structure, exhibit a second
order polarizability (β). Crystallographic studies demonstrated an almost planar structure of all
molecules and indicated the occurrence of conformational changes in π-conjugated bridge
between donor and acceptor. For three homologues similar packing modes, defined mostly by
week C-H…N interactions, were found in crystals. Bond length alternation (BLA) values have
been evaluated using crystallographic and NMR data and have shown a correlation to their
nonlinear optical activity. Second order polarizabilities for all compounds were measured using
hyper Rayleigh scattering (HRS) in solution. It was found that the merocyanines studied exhibit
very large second order polarizabilities (up to 4.1 10-27 esu), making them potentially useful for
materials for second harmonic generation (SHG). Unfortunately, they do not demonstrate
acentric packing of chromophores, which is required for SHG in the crystalline state, but may
show promise for other applications such as poled polymer blends or for SHG sensing in
biological environments.
Keywords: Nonlinear optical materials, Bond length alternation, Second harmonic generation,
Crystal structure
1

ACCEPTED MANUSCRIPT
1 INTRODUCTION
Interest in organic merocyanine dyes, or “push-pull” polymethines, has arisen largely a
result of their applications in optoelectronics, for instance, in organic light emitting diodes [1],
luminescent sensors [2,3], solid-state lasers [4] and in bioimaging [5], where two-photon
excitation offers additional advantages [6]. Optimizing the electrooptic activity of push-pull
chromophores requires rational molecular design, analogous to that of other nonlinear optical
(NLO) molecules. The photophysical properties of this class of chromophores are largely
dependent on three main structural aspects: strength of terminal donor and acceptor groups and
length of conjugated chain between them. Recently, organic chromophores with (3-cyano-5,5-
dimethyl-2(5H)-furanylidene)malononitrile (so called tricyanofuran, TCF) as an acceptor group
have been investigated for their high electrooptic activity and structural characteristics in solid
state [6-10]. Different applications in technics, biology and medicine were identified for this
group of materials, such as their use for data storage [11], for sensors for gaseous and aqueous
alkaline analytes [12,13], antibacterial activity [14] and many others.
Computational estimates of the first hyperpolarizability of a large series of TCF-terminated
push-pull chromophores have been carried out using DFT calculations [15]. Authors considered
different conformations of polyene chains and different orientations of TCF groups relative to
these chains. Absorbance and fluorescence spectra of this group of materials have also been
studied before [16,17], and we enriched published data by investigation of these spectra in
different solvents. However, to the best of our knowledge, no structural studies of TCF
merocyanines with N,N-dimethylaminophenyl (DMAP) donor groups, such as those of this
series (see Scheme 1 for a generic DMAP-TCF structure) in crystal, have been published. We
are presenting here four DMAP-TCF structures with the polyene bridges containing 1, 2, 3 or 4 -
C=C- bonds (TCF[1], TCF[2], TCF[3], and TCF[4], respectively) along with discussion of their
conformational peculiarities and interrelations of the molecular and packing characteristics to
their properties.
Chemical structure of TCF[n], where n = 1-4
2

ACCEPTED MANUSCRIPT
Scheme 1
3

ACCEPTED MANUSCRIPT
2 MATERIALS AND METHODS
2.1 Synthesis
Synthetic scheme of described materials is presented below.
Figure 1. Stepwise extension of dimethylaminophenyl-terminated polyenals.
Figure 2. Synthesis of TCF[n] by Knoevenagel condensation.
All materials and reagents were commercially available, purchased from Sigma Aldrich and used
as received except where noted. Tetrahydrofuran was dried using a sodium-benzophenone ketyl
pot and freshly distilled for each use. ((1,3-Dioxolan-2-yl)methyl)triphenyl phosphonium
bromide, while commercially available, was synthesized as described below because it resulted
in higher yields. Synthesis details are presented in Supporting Information.
2.2 Instrumentation
X-Ray: The single-crystal X-ray diffraction data for TCF[1]-TCF[4] were collected on a Bruker
SMART APEX II CCD diffractometer (λ(MoKα)-radiation, graphite monochromator, ω and φ
scan mode) and corrected for absorption using the SADABS program [18]. For details, see Table
1. The structures were solved by the intrinsic phasing modification of direct methods [19] and
refined by a full-matrix least square technique on F2 in anisotropic approximation for non-
hydrogen atoms. The hydrogen atoms were placed in calculated positions and refined within the
4

ACCEPTED MANUSCRIPT
riding model with fixed isotropic displacement parameters [Uiso(H) = 1.5Ueq(C) for the methyl
groups and 1.2Ueq(C) for the other groups]. All calculations were carried out using the
SHELXTL program suite [19].
1
NMR: H, 13C, and 31P NMR spectra were acquired on one of the following NMR
spectrometers: Bruker Avance IIIHD-500 MHz (with Prodigy cryoprobe), a Bruker Avance
IIIHD-700 MHz spectrometer, or a Bruker Avance IIIHD-800 MHz spectrometer. Each NMR
will list the field strength used. All chemical shifts are indirectly referenced TMS through the
residual solvent peaks as reported in the literature [20].
Spectroscopic characterization: Linear absorption measurements were performed using either
a UV-Vis-NIR scanning spectrophotometer (UV-3101PC, Shimadzu). Steady state fluorescence
measurements were conducted using a scanning spectrofluorometer (Flurolog-2, SPEX). All
spectra were measured in 1 cm special optical glass cuvettes (SOG, Starna cells).
Hyper-Rayleigh scattering (HRS): measurements were conducted on a home-built Hyper-
Rayleigh scattering / two-photon induced fluorescence setup. The light source for the HRS
measurements consisted of a Ti:Sapphire regenerative amplifier (Solstice, Spectra-Physics, 800
nm, 3.7 W average power, 100-fs pulse width, 1 kHz repetition rate). The amplified laser is used
to pump a computer controlled optical parametric amplifier (OPA, TOPAS-C, Light
Conversion). The OPA can be continuously tuned from 1100 – 2600 nm (FWHM 10 – 30 nm)
and the second harmonic of the OPA can be used in the range of 550 – 1100 nm (~30 mW
average power). The range of excitation energy, at the sample, varies between 2 – 12.5 µJ and is
limited below the onset of higher order nonlinear optical effects such as white-light generation.
Before entering the sample enclosure, the beam is filtered using appropriate long pass filters
(typically 850nm long pass) to remove stray 800 nm light. The beam then passes through two
orthogonally oriented cylindrical lenses and into the sample cell (1 cm path length, Special
Optical Glass, Starna Cells). The cell holder is attached to a movable stage allowing the cuvette
to be positioned such that the focus of the beam is just next to the wall of the cell, in order to
minimize reabsorption. The generated light is collected at a right angle by means of a collection
lens (focal length = 8.0 mm, KPA016-C, Newport Corporation) and is passed through
appropriate short pass filters needed to remove scattered light from excitation beam as well as
two-photon fluorescence from the sample. The filtered light is collected by fiber collimators
(F810SMA-543, Thorlabs) and sent through a two-leg fiber bundle (13 fibers per bundle oriented
in a line, Leoni) to an imaging fiber adapter (FC-446-030, Princeton Instruments) that is coupled
5

ACCEPTED MANUSCRIPT
to a monochrometer (SpectrPro-150, Acton). The HRS signal is detected on a liquid nitrogen
cooled CCD camera (LN/CCD-1100PB, Roper Scientific, controller: ST-133, Roper Scientific).
For HRS measurements, samples were dissolved in spectroscopy grade solvents at
concentrations ranging from 1 µM to 10 mM. HRS spectra were acquired over long exposure
times (50 – 500 s) due to the weak nature of the HRS signal. All samples were stirred with a
micro stirbar that was carefully placed below the beam. All hyperpolarizability values were
referenced internally to and corrected for the HRS signal and hyperpolarizability of the
corresponding solvent as reported by Campo et al1. The raw data was processed in MATLAB by
first smoothing the data using the built-in smoothing protocol and the robust loess function
which is a local regression using a weighted linear least square fit with second degree
polynomial model and assigns a lower weight to outliers. The smoothing function was adjusted
to exclude cosmic rays, typically spanning 0.5 to 1% of the data. To remove the contribution
from multiphoton fluorescence the baseline of the smoothed data was fit by a fifth-order
polynomial using manually selected regions of baseline and subtracted from the raw data.
6

ACCEPTED MANUSCRIPT
3. RESULTS AND DISCUSSION
3.1 X-Ray structure determination
Crystal data and structure refinement results of TCF[1]-TCF[4] are summarized in Table 1.
Table 1. Crystallographic data and summary of data collection and structure refinement for
TCF[1]-TCF[4].
Identification code
Empirical formula
Formula weight, g/mol
Temperature, K
Crystal system
Space group
a, Å
b, Å
c, Å
α, °
β, °
TCF[1]
C20H18N4O
330.38
150
Orthorhombic
Pnma
18.618(3)
6.9885(13)
13.737(3)
90
90
90
1787.3(6)
4
1.228
TCF[2]
C22H20N4O
356.42
100
Orthorhombic
Pnma
17.553(3)
6.8670(13)
15.561(3)
90
90
90
1875.7(6)
4
1.262
TCF[3]
C24H22N4O
382.45
150
Monoclinic
P21/c
7.0919(10)
17.289(2)
17.417(3)
90
98.082(2)
90
TCF[4]
C26H24N4O
408.49
100
Triclinic
P-1
7.6501(17)
17.261(4)
18.469(4)
66.112(3)
87.328(3)
85.196(3)
2221.9(8)
4
γ, °
V, Å3
2114.3(5)
4
1.201
Z
dcalcd, g/cm3
µ, mm-1
1.221
0.076
0.079
0.080
0.076
F(000)
696
752
808
864
Theta range for data
collection, °
Index ranges
1.842 to 31.759 4.097 to 30.603 1.668 to 31.868 4.261 to 30.650
-27
-10
-20
≤
≤
≤
h
k
l
≤
≤
≤
26,
9,
19
-25
≤
k
≤
h
≤
l
≤
25,
9,
22
-9
-24
-24
≤
≤ k ≤
≤
h
≤
10,
25,
25
-10
-24
-26
≤
≤
≤
h
k
l
≤
≤
≤
10,
24,
26
-9
≤
-22
≤
l
≤
Reflections collected
Independent reflections
20316
3125
15371
3089
24461
6785
26728
13529
[Rint = 0.0446]
[Rint = 0.0363]
[Rint = 0.0574]
[Rint = 0.0308]
Data / restraints /
parameters
3125 / 0 / 151
1999 / 0 / 170
6785 / 0 / 266
13529 / 0 / 567
Goodness-of-fit on F2
Final R indices [I>2σ(I)]
R1, wR2
1.129
0.0680, 0.1819
1.045
0.0441, 0.1211
1.011
0.0542, 0.1469
1.007
0.0511, 0.1219
R indices (all data), R1,
wR2
0.0899, 0.1976
0.0526, 0.1294
0.0809, 0.1653
0.0839, 0.1372
3.2 Structural properties
All molecules studied (Scheme 1, Figures 3, 4) have nearly planar structures. A
consideration of the three planar fragments in these molecules – donor (D), acceptor (A) and π-
conjugated bridge (π) demonstrated that TCF[1] and TCF[2] are perfectly planar (in the crystal,
7

ACCEPTED MANUSCRIPT
molecules occupy a special position on the mirror plane m). In molecule TCF[3], deviations of
atoms from the mean plane passed through these three fragments are relatively small – 0.048 .
In two symmetrically independent TCF[4] molecules (A and B), deviations from the total
planarity are slightly larger (for A – 0.187
and B – 0.242 ). The dihedral angles between
acceptor and bridge groups (A/π) and donor and bridge groups (D/π) are presented in Table 2.
All the above-mentioned data demonstrate that an increase of length of conjugated bridge makes
a molecule slightly less planar, however, these changes are insignificant. Thus, in all molecules
TCF[1]-TCF[4], the X-ray studies revealed the presence of extensive conjugated system. It
should be noted that, in all molecules, the π-bridge adopts the all-trans (all-E-isomeric)
configuration of the double bonds.
Table 2. Dihedral angles ( ) between planar fragments and selected bond lengths (Å) in
°
molecules TCF[1]-TCF[4].
TCF[1]
TCF[2]
0.0
TCF[3]
TCF[4] (A B )
10.698(74)/11.933(57)
/
Dihedral angle Acceptor/
0.0
3.671(55)
π- Bridge
Dihedral angle Donor/ π -
Bridge
0.0
0.0
3.920(57)
10.022(84)/8.268(83)
C6-C2
1.3792(17)
1.4344(17)
1.3771(17)
1.4166(17)
1.3689(17)
1.4200(18)
1.3676(17)
1.4354(18)
-
-
1.3736(15)
1.4323(15)
1.3728(15)
1.4202(15)
1.3575(17)
1.4219(15)
1.3555(17)
1.4217(16)
1.3507(17)
1.4449(15)
-
1.3774(18)/1.3722(18)
1.4301(18)/1.4329(18)
1.3732(17)/1.3727(17)
1.4140(18)/1.4148(18)
1.377(3)
1.432(3)
1.383(3)
1.416(3)
1.364(3)
1.432(3)
-
-
-
C2-C3
C3-C4
C4-C18
C18-C19
C19-C20 (C19-C13)
C20-C21
C21-C22 (C21-C13)
C22-C23
C23-C24 (C23-C13)
C24-C25
C25-C26 (C25-C13)
C13-C14
1.3641(18)/1.3692(18)
1.4162(18)/1.4177(18)
1.3588(18)/1.3588(18)
1.4213(18)/1.4253(18)
1.3552(19)/1.3507(18)
1.4249(18)/1.4357(19)
1.3502(18)/1.3470(18)
1.4470(18)/1.4510(19)
1.4044(18)/1.3960(19)
1.3785(19)/1.3775(19)
1.4064(20)/1.4019(19)
-
-
-
-
-
-
1.4086(17)
1.3798(18)
1.4204(18)
1.4040(17)
1.3775(16)
1.4105(18)
1.414(3)
1.375(3)
1.415(3)
C14-C15
C15-C10
C10-N10
1.3647(17)
1.3707(16)
1.3730(18)/1.3673(17)
1.366(3)
(a)
8

ACCEPTED MANUSCRIPT
(b)
(c)
Figure 3. Molecular structures of TCF[1] (a), TCF[2] (b) and TCF[3] (c) with atomic numbering
scheme.
Figure 4. Molecular structures of two symmetrically independent TCF[4] molecules with atomic
numbering scheme (A – bottom, B – top).
9

ACCEPTED MANUSCRIPT
It is important to point out that, in all molecules TCF[1]–TCF[4], the TCF acceptor group
contains the internal –C=C-C=C- conjugated chain, which is bound to the conjugated bridge in
different ways. In the molecules TCF[1], TCF[2], TCF[3] and TCF[4]-A, the TCF group is
oriented in such a way as to continue the all-trans bridge configuration of the double bonds,
when talking about polyenes, this is known as s-trans configuration, as the double bonds are
opposite to one another across the single bond. Conversely, TCF[4]-B exhibits the s-cis type
configuration. The differences between the s-cis and s-trans conformers is highlighted in Figure
5. While single bonds generally allow free rotation, in conjugated π-systems, delocalization of
electrons across the conjugated chain leads to a configuration less able to freely rotate.
Consequently, the two independent molecules A and B of TCF[4] represent different conformers
(atropoisomers) relative to the A/π fragment. It should be mentioned that, according to quantum
DFT computations of TCF[4] carried out by Chafin and Lindsay [21], the s-cis conformer was
found to be 1.3 kcal/mol more favorable than the s-trans conformer. However, our previous DFT
calculations of the s-cis and s-trans conformers performed for dye FTC [7] give a smaller
difference of only 0.3 kcal/mol. Analysis of literature data shows that in solid state the both
binding types have been found [7-10]. This mixture of the TCF[4]-A and B states can also be
seen by NMR using a nuclear Overhouser effect spectroscopy (NOESY), showing the
interactions of protons through space. As is shown in the Figure 5 below, the interaction of the
polyene chain protons and the methyl protons of the TCF group can be examined due to their
through-space interactions. Integration of the NOESY signals estimates TCF[4]-A makes up
about 62% of the sample in CD2Cl2.
Figure 5. Schematic representation of the through space interactions yielding NOESY
correlations by NMR.
Molecular packing in crystals of TCF[1]–TCF[4] is influenced by two dominant factors:
strong dipole moments and electrostatic interactions. First, due to high dipole moments and
10

ACCEPTED MANUSCRIPT
elongated conformations, which are common for NLO chromophores, molecules have
antiparallel packing. Second factor is intramolecular and intermolecular interactions between the
negatively charged N-atoms of the cyano groups and nearby protons of the polyene chains,
phenyl ring and methyl groups. These interactions help to form planar layers (Figure 6) and
superposition of the layers brings to formation of stacks with antiparallel molecular arrangement.
Homologues TCF[1] and TCF[2] are packed in the same space groups with close unit cell
parameters and have very similar packing modes. In Figure 6, only packing of TCF[2] is shown.
Molecular packing mode of TCF[3], which has a monoclinic space group, is also similar to
molecular packing in TCF[1] and TCF[2]. In crystal structure of TCF[1]–TCF[4] short C-H…N
contacts within the layers are in range 2.48-2.67 (Figures 6-8, Table 3) . These data are in good
agreement with the average values for C-H…N(sp2) contacts presented by Gavezzotti and Presti
[22] based on approximately 12,000 of such contacts. Molecular layers are packed in TCF[1]
along b axis with distance between them equal to 3.494, and in TCF[2] with distance 3.434 .
(a)
(b)
Figure 6. Molecular packing in crystal TCF[2]: (a) molecular layer along b direction; (b) parquet
packing of stacks.
11

ACCEPTED MANUSCRIPT
In crystal TCF[3] (Figure 7) molecular layers are packed parallel to (-101) with the
alternating distances between these layers equal to 3.112 and 3.524 . Stacks in structures
TCF[1]–TCF[3] present parquet motif (Figures 6b, 7b).
(a)
(b)
Figure 7. Molecular packing in crystal TCF[3]: (a) molecular layer parallel to (-101); (b) parquet
packing of stacks.
In the crystal TCF[4] molecular packing is more complicated since this crystal is built of
two symmetrically independent molecules A and B. Molecules A and B form ribbons with
alternating positions of these molecules (Figure 8). As in molecular layers of TCF[1]–TCF[3],
molecules in TCF[4] ribbons are connected by the weak C-H…N hydrogen bonds (Table 3).
Superposition of this ribbons brings to formation of molecular stacks with antiparallel positions
of molecules in such way that stacks are formed of just A or just B molecules (Figure 8). These
stacks are packed in almost parallel way (Figure 8b).
12

ACCEPTED MANUSCRIPT
(a)
(b)
Figure 8. Molecular packing in crystal TCF[4]: (a) molecular ribbons connected with C-H…N
bonds and (b) parquet packing of molecular stacks.
Table 3. Hydrogen bonds parameters in TCF[1]–TCF[4].
C-H, Å
H…N, Å
C…A, Å
Angle C-H…N,°
TCF[1]: #1 x,-y+3/2,z #2 x-1/2,y,-z+3/2 #3 x-1/2,y,-z+1/2
C(51)-H(51B)...N(8)#2
0.98
2.67
2.63
3.526(3)
3.489(4)
145.5
145.7
C(16)-H(16B^a)...N(9)#3 0.98
TCF[2]: #1 x,-y+1/2,z #2 x,y,z-1 #3 x-1/2,y,-z+1/2
C(15)-H(15)...N(7)#2
C(16)-H(16A)...N(9)#3
0.95
0.98
2.55
2.51
3.491(2)
3.489(2)
169.2
176.8
TCF[3]: #1 -x,y+1/2,-z+1/2 #2 -x+1,-y+1,-z+1
C(16)-H(16B)...N(9)#1
C(17)-H(17A)...N(7)#2
0.98
0.98
2.60
2.67
3.572(2)
3.629(2)
172.0
165.0
TCF[4]: #1 -x+1,-y+1,-z #2 -x+2,-y-1,-z+1
C52B-H52E-N8A
C16A-H16A-N7B
0.98
0.98
2.61
2.48
3.274(2)
3.381(2)
169.4
153.1
13

ACCEPTED MANUSCRIPT
It should be mentioned that none of crystals studied demonstrate acentric packing that excludes
their direct use for NLO devices.
3.3 Bond length alternation
Furthermore, the structures of TFC[1]–TFC[4] suggest delocalization of electron density
inside a polyene chain with the bond length alternation (BLA) presented in Table 2 and Figure
9. The BLA distribution in the dimethylaminophenyl donor fragments found in all molecules
demonstrates their pronounced quinoid character (Table 2). This phenomenon can be presented
by combination of two different resonance forms in the molecules TFC[1]–TFC[4] with
distribution of single and double bonds in crystals.
Figure 9. Bond length alternation, in Å, for the TCF[n] series as measured by X-ray
crystallography.
3.4 Absorption spectrum
As it is typical with merocyanines, the studied TCF series exhibit an electronic spectrum,
which is dominated by a large broad charge transfer band (Figure 10). This series also shows a
14

ACCEPTED MANUSCRIPT
hypsochromic shift in absorbance with increasing solvent polarity, also called negative
solvatochromism (Table 4). This is due to differential solvation of the ground and excited states.
It is likely that there is better stabilization of molecule in the ground state relative to that of the
first excited state as solvent polarity increases. Interestingly, the negative solvatochromic shift
becomes larger with increasing chain length.
Figure 10. Normalized absorbance of TCF[n] series in acetonitrile.
Table 4. Wavelengths of the absorbance peaks (nm) of TCF[n] series in chloroform and
acetonitrile.
Polyene Chain Length (number of double bonds)
Chromophore
TCF[n]
Solvent
1
2
3
4
CHCl3
ACN
577
569
612
595
645
605
657
611
15

ACCEPTED MANUSCRIPT
3.5 Bond length alternation by NMR
The measurement of bond lengths by crystallography is widely accepted as a direct
measurement of bond length alternation [23,24]. A lesser utilized measurement of BLA for
molecules in solution comes from the proton coupling constants of adjacent methylene units
[25]. This practice makes the assumption that, in solution, the chromophores maintain a planar
structure, thereby eliminating the dependence of coupling constants on dihedral angle of vicinal
protons as described, famously, by Karplus [26]. Without having to consider an angular
dependence of coupling constants, the major remaining influence is the C-C bond distance
between the two methylene units [22]. The measurements of BLA by NMR are shown below
(Table 5).
Figure 11. Schematic representation of BLA measurement by NMR.
Table 5. Vicinal coupling constants and <∆J> of TCF[n] series as measured in dichloromethane-
d2
J1-2
(Hz)
J2-3
(Hz)
J3-4
(Hz)
J4-5
(Hz)
J5-6
(Hz)
J6-7
(Hz)
J7-8
(Hz)
J8-9
(Hz)
<∆J>
(Hz)
Dye
TCF[1] 15.91
TCF[2] 15.16 11.21 14.93
TCF[3] 15.20 11.36 14.24 11.04 15.12
TCF[4] n.d. n.d. 13.42 11.44 14.12 11.50 15.21
--
3.84
3.65
2.78‡
‡: BLA estimate based on incomplete assignment of coupling constants
n.d.: not determined because of overlapping/higher order spectrum
The estimation of BLA by NMR is more ambiguous than by crystallography, largely owing to
the need to correctly assign each resonance and characterize its relationship to the others.
Complicating this measurement is that second order effects which occur when the separation
between two resonances ∆υ (in Hz) is similar in magnitude to the coupling constant between
16

ACCEPTED MANUSCRIPT
them. The only major advantage of estimating BLA by NMR over that of crystallography is that
the BLA can be estimated in a particular solvent field.
TCF2rxtal_acetone_700MHz
1
1
"/Users/jtillotson3/Documents/NMR/D-A polyenes"
7.8
7.6
7.4
7.2
7.0
6.8
6.6
6.4 [ppm]
Figure 12. 1H NMR spectra of TCF[2] in acetone-d6 (blue trace), DMSO-d6 (red trace),
acetonitrile-d3 (green trace), Chloroform-d (purple trace), and dichloromethane-d2 (black trace)
as an example of measuring ∆J. All spectra were recorded using a Bruker AVIII-HD 700 MHz
NMR spectrometer and are referenced to their residual solvent signals.
3.6 Hyperpolarizability
This series of DMAP-TCF merocyanines exhibit very large first hyperpolarizabilities,
making them potentially useful for second harmonic generation (SHG), electrooptic modulation,
and for voltage sensitivity (Table 6). Unfortunately, a requirement for SHG in solids is a non-
centrosymmetric spatial arrangement of chromophores [27], which none of the TCF[n] materials
17

ACCEPTED MANUSCRIPT
exhibit in their crystalline forms. That said, in applications leading to alignment of these
chromophores and a loss of center of symmetry, such as poled polymer blends and in lipid
membranes, their utility for SHG should be quite strong.
Table 6. Measured first hyperpolarizabilities (β) of TCF[1-4] in acetonitrile (ACN) and N,N-
dimethylformamide (DMF); β values referenced to ACN and DMF respectively according to
Campo et al. [28] Error in HRS measurements estimated at ±8%.
β x 10-27
Dye
Solvent
[esu]
1.33
1.63
1.21
2.54
2.11
3.11
2.31
3.06
1.97
n.d.
CHCl3
ACN
DMF
CHCl3
ACN
DMF
CHCl3
ACN
DMF
CHCl3
ACN
DMF
TCF[1]
TCF[2]
TCF[3]
TCF[4]
4.10
n.d.
n.d.: not determined due to degradation
18

ACCEPTED MANUSCRIPT
Figure 13. First hyperpolarizability of TCF[1]–TCF[4] in chloroform, acetonitrile and
N,N-dimethylformamide as measured by HRS.
The HRS measurements in acetonitrile showed the expected trend in β, as the
hyperpolarizability increases with chain length. In chloroform and in DMF, the measured β for
TCF[2] was a pretty sizable increase over that of both TCF[1] and TCF[3] (Figure 13).
19

ACCEPTED MANUSCRIPT
4 CONCLUSIONS
The X-ray diffraction study of four tricyanofuran terminated merocyanine dyes, TCF[n], which
crystal structures were never studied before, demonstrate that in the crystalline state these
chromophores have almost planar molecular structures with very similar molecular packing
modes for members with n=1-3. In TCF[4] coexistence of two conformers in one crystal was
found. The observed bond length alternation in these molecules suggests that they should have
notable second-order NLO properties. Experimental measurements of their first
hyperpolarizabilities (β values) in different solvents revealed that, in acetonitrile, the β values
increase with an increase in length of conjugated chain. In chloroform and DMF solutions,
however, such trend was not observed. This unusual behavior may either be due to
conformational changes in different solvents or large solvent-dependence in the nonlinearities.
The suggested solvent-based conformational change is supported by presence of two conformers
in crystal TCF[4].
20

ACCEPTED MANUSCRIPT
ASSOCIATED CONTENT
Crystallographic data for TCF[1]-TCF[4] have been deposited with the Cambridge
Crystallographic Data Center, CCDC 1884797-1884800. The supplementary crystallographic
data can be obtained free of charge from the Cambridge Crystallographic Data Centre via
www.ccdc.cam.ac.uk/data_request/cif.
AUTHOR INFORMATION
Corresponding Authors
E-mail: tvtimofeeva@nmhu.edu
Address: 1005 Diamond st., Las Vegas, NM 87701 USA
Author Contributions
All authors have given approval to the final version of the manuscript.
Notes
The authors declare no competing financial interest.
ACKNOWLEDGEMENTS
This work was supported by the U.S. National Science Foundation (grants PREM DMR-
0934212 & 1523611) and the RUDN University Program “5-100”. Spectroscopic studies were
supported by the NIH (grant 1R21NS084353-01).
21

ACCEPTED MANUSCRIPT
REFERENCES
[1] C.D. Muller, A. Falcou, N. Reckefuss, M. Rojahn, V. Wiederhirn, P. Rudati, H. Frohne, O.
Nuyken, H. Becker, K. Meerholz, Multi-colour organic light-emitting displays by solution
processing, Nature 421(6925) (2003) 829-833.
[2] A. Duarte, K.-Y. Pu, B. Liu, G.C. Bazan, Recent advances in conjugated polyelectrolytes for
emerging optoelectronic applications, Chem. Mater. 23(3) (2011) 501-515.
[3] W. Qin, J.W. Lam, Z. Yang, S. Chen, G. Liang, W. Zhao, H.S. Kwok, B.Z. Tang, Red
emissive AIE luminogens with high hole-transporting properties for efficient non-doped OLEDs,
ChemComm 51(34) (2015) 7321-7324.
[4] I.D. Samuel, G.A. Turnbull, Organic semiconductor lasers, Chem. Rev. 107(4) (2007) 1272-
1295.
[5] W.-C. Wu, C.-Y. Chen, Y. Tian, S.-H. Jang, Y. Hong, Y. Liu, R. Hu, B.Z. Tang, Y.-T. Lee,
C.-T. Chen, W.-C. Chen, A.K.Y. Jen, Enhancement of aggregation-induced emission in dye-
encapsulating polymeric micelles for bioimaging, Adv. Funct. Mater. 20(9) (2010) 1413-1423.
[6] M. Ipuy, Y.-Y. Liao, E. Jeanneau, P.L. Baldeck, Y. Bretonnière, C. Andraud, Solid state red
biphotonic excited emission from small dipolar fluorophores, J. Mater. Chem. C 4(4) (2016)
766-779.
[7] T.L. Kinnibrugh, T.V. Timofeeva, O. Clot, A. Akelaitis, L.R. Dalton, A non-linear optical
chromophore:
2-[3-cyano-4-((E)-{5-[4-(diethylamino)styryl]thiophen-2-yl}vinyl)-5,5-
dimethylfuran-2-(5H)-ylidene]propanedinitrile, Acta Crystallogr. E 62(11) (2006) o4804-o4806.
[8] G.J. Gainsford, M.D. Bhuiyan, A.J. Kay, Geometry and bond-length alternation in nonlinear
optical materials. III. Structural parameters of two chromophores containing aromatizable
donorsPart II: Gainsford, Bhuiyan & Kay (2008a), Acta Crystallogr. C 64(11) (2008) o616-619.
[9] G.J. Gainsford, M. Ashraf, A.J. Kay, 2-{3-Cyano-4-[2-(4-diethylamino-2-hy-
droxyphenyl)ethenyl]-5,5-dimethyl-2,5-dihydr ofuran-2-ylidene}malononitrile acetone 0.25-
solvate, Acta Crystallogr. E 68(10) (2012) o2991-2992.
[10] J. Wu, S. Bo, J. Liu, T. Zhou, H. Xiao, L. Qiu, Z. Zhen, X. Liu, Synthesis of novel nonlinear
optical chromophore to achieve ultrahigh electro-optic activity, ChemComm 48(77) (2012) 9637-
9639.
[11] A. Saini, C.W. Christenson, T.A. Khattab, R. Wang, R.J. Twieg, K.D. Singer, Threshold
response using modulated continuous wave illumination for multilayer 3D optical data storage, J.
Appl. Phys. 121(4) (2017).
22

ACCEPTED MANUSCRIPT
[12] T.A. Khattab, M. Rehan, S.A. Aly, T. Hamouda, K.M. Haggag, T.M. Klapötke, Fabrication
of PAN-TCF-hydrazone nanofibers by solution blowing spinning technique: Naked-eye
colorimetric sensor, J. Environ. Chem. Eng. 5(3) (2017) 2515-2523.
[13] H. Abou-Yousef, T.A. Khattab, Y.A. Youssef, N. Al-Balakocy, S. Kamel, Novel cellulose-
based halochromic test strips for naked-eye detection of alkaline vapors and analytes, Talanta
170 (2017) 137-145.
[14] T.A. Khattab, H.E. Gaffer, S.A. Aly, T.M. Klapötke, Synthesis, solvatochromism,
antibacterial activity and dyeing performance of tricyanofuran-dydrazone analogues,
ChemistrySelect 1(21) (2016) 6805-6809.
[15] A.P. Chafin, G.A. Lindsay, A pattern for increasing the first hyperpolarizability of a
push−pull polyene dye as indicated from DFT calculations, J. Phys. Chem. C 112(21) (2008)
7829-7835.
[16] L. Han, Y. Jiang, W. Li, Y. Li, P. Hao, Spectroscopic investigations of a novel tricyanofuran
dye for nonlinear optics, Spectrochim. Acta A 71(1) (2008) 86-89.
[17] S.-H. Kim, S.-Y. Lee, S.-Y. Gwon, Y.-A. Son, J.-S. Bae, D–π–A solvatochromic charge
transfer dyes containing a 2-cyanomethylene-3-cyano-4,5,5-trimethyl-2,5-dihydrofuran acceptor,
Dyes Pigm. 84(2) (2010) 169-175.
[18] Sheldrick, G. SHELXT - Integrated space-group and crystal-structure determination. Acta
Crystallogr. A 2015, 71 (1), 3-8.
[19] Sheldrick, G. Crystal structure refinement with SHELXL. Acta Crystallogr. C 2015, 71 (1),
3-8.
[20] G.R. Fulmer, A.J.M. Miller, N.H. Sherden, H.E. Gottlieb, A. Nudelman, B.M. Stoltz, J.E.
Bercaw, K.I. Goldberg, NMR chemical shifts of trace impurities: common laboratory solvents,
organics, and gases in deuterated solvents relevant to the organometallic chemist,
Organometallics 29(9) (2010) 2176-2179.
[21] S.R. Marder, J.W. Perry, B.G. Tiemann, C.B. Gorman, S. Gilmour, S.L. Biddle, G. Bourhill,
Direct observation of reduced bond-length alternation in donor/acceptor polyenes, J. Am. Chem.
Soc. 115(6) (1993) 2524-2526.
[22] Sheldrick, G. SADABS, v. 2.03, Bruker/Siemens area detector absorption correction
program: Bruker AXS, Madison, Wisconsin, 2003.
[23] S.R. Marder, J.W. Perry, C.P. Yakymyshyn, Organic salts with large second-order optical
nonlinearities, Chem. Mater. 6(8) (1994) 1137-1147.
23

ACCEPTED MANUSCRIPT
[24] C.B. Gorman, S.R. Marder, An investigation of the interrelationships between linear and
nonlinear polarizabilities and bond-length alternation in conjugated organic molecules, PNAS
USA 90(23) (1993) 11297-11301.
[25] M. Blanchard-Desce, V. Alain, P.V. Bedworth, S.R. Marder, A. Fort, C. Runser, M.
Barzoukas, S. Lebus, R. Wortmann, Large quadratic hyperpolarizabilities with Donor–Acceptor
polyenes exhibiting optimum bond length alternation: correlation between structure and
hyperpolarizability, Chem. Eur. J. 3(7) (1997) 1091-1104.
[26] M. Karplus, Contact electron spin coupling of nuclear magnetic moments, J. Chem. Phys.
30(1) (1959) 11-15.
[27] M. Karplus, Vicinal proton coupling in nuclear magnetic resonance, J. Am. Chem. Soc.
85(18) (1963) 2870-2871.
[28] J. Campo, F. Desmet, W. Wenseleers, E. Goovaerts, Highly sensitive setup for tunable
wavelength hyper-Rayleigh scattering with parallel detection and calibration data for various
solvents, Opt. Express 17(6) (2009) 4587-4604.
24

ACCEPTED MANUSCRIPT
Synopsis
Structural and spectroscopic studies of nonlinear optical merocyanine dyes are presented
25

ACCEPTED MANUSCRIPT
Highlights:
•
•
•
Series of merocyanine dyes with different length of conjugated chain was synthesized and
characterized with X-ray diffraction, 1H NMR, and several spectroscopic methods.
NLO characteristics of compounds in different solvents have been evaluated using structural,
spectroscopic and 1H NMR data.
NLO characteristics in solutions demonstrated growth with the increase of the length of
conjugated chain between donor and acceptor.
