R. TampØ et al.
scopy (LSM 510, Carl Zeiss, Jena, Germany). Firstly, the chip was placed
in a disposable Petri dish and incubated with either unlabeled or Texas
Red-labeled (TR-labeled) bovine serum albumin (100 mgmLÀ1 protein;
Molecular Probes) for 10 min. After protein adsorption, the chip was
thoroughly rinsed with the buffer, such that the surface remained wet all
the time. Subsequently, the chip was exposed for 10 min to a mixed solu-
tion of unlabeled (2.5 mm) or Oregon Green-labeled (OG-labeled;
125 nm) His6-tagged maltose-binding protein. His6-tagged maltose-bind-
ing protein was purified by the standard IMAC procedure. After rinsing,
the wet chips were immediately mounted into a custom-built flow cham-
ber and were imaged by use of a Plan-Neofluor 40 oil-immersion objec-
tive (NA 1.3) and an inverted microscope setup (Axiovert 200M, Carl
Zeiss, Jena, Germany). Argon (488 nm, 25 mW) and HeNe (543 nm,
1 mW) lasers were used for the excitation of Oregon Green and Texas
Red, respectively. The image size was 20482048 pixels, corresponding
to an area of 326326 mm.
[16] D. L. Pearson, R. D. Reimonenq, K. M. Pollard, Protein Expression
Purif. 1999, 17, 49–56.
[17] J. Schmitt, H. Hess, H. G. Stunnenberg, Mol. Biol. Rep. 1993, 18,
223–230.
[18] J. A. Bornhorst, J. J. Falke, Methods Enzymol. 2000, 326, 245–254.
[19] E. Hochuli, J. Chromatogr. 1988, 444, 293–302.
[20] E. Hochuli, Genet. Eng.1990, 12, 87–98.
[21] M. Kindermann, N. George, N. Johnsson, K. Johnsson, J. Am.
Chem. Soc. 2003, 125, 7810–7811.
[22] Y. Kwon, Z. Han, E. Karatan, M. Mrksich, B. K. Kay, Anal. Chem.
2004, 76, 5713–5720.
[23] C. D. Hodneland, Y. S. Lee, D. H. Min, M. Mrksich, Proc. Natl.
Acad. Sci. USA 2002, 99, 5048–5052.
[24] F. H. Arnold, Metal-affinity protein separations, Academic Press, San
Diego, 1992.
[25] E. Hochuli, W. Bannwarth, H. Dçbeli, R. Gentz, D. Stüber, Bio-
Techniques 1988, 6, 1321–1325.
[26] I. T. Dorn, K. R. Neumaier, R. TampØ, J. Am. Chem. Soc. 1998, 120,
2753–2763.
[27] L. Nieba, S. E. Nieba-Axmann, A. Persson, M. Hamalainen, F. Ede-
bratt, A. Hansson, J. Lidholm, K. Magnusson, A. F. Karlsson, A.
Plückthun, Anal. Biochem. 1997, 252, 217–228.
[28] L. Schmitt, C. Dietrich, R. TampØ, J. Am. Chem. Soc. 1994, 116,
8485–8491.
[29] D. R. Shnek, D. W. Pack, D. Y. Sasaki, F. H. Arnold, Langmuir 1994,
10, 2382–2388.
[30] I. T. Dorn, K. Pawlitschko, S. C. Pettinger, R. TampØ, Biol. Chem.
1998, 379, 1151–1159.
[31] I. T. Dorn, R. Eschrich, E. Seemüller, R. Guckenberger, R. TampØ,
J. Mol. Biol. 1999, 288, 1027–1036.
Atomic force microscopy (AFM): AFM experiments were performed
with a Digital Instruments NanoScope IIIa SPM MultiMode atomic force
microscope (Veeco Instruments, Santa Barbara, CA) in a commercial
quartz fluid cell. NP-S cantilevers with a force constant of 0.06 NmÀ1
(Veeco Instruments) were used for all experiments. Imaging was per-
formed in tapping mode at resonance frequencies of around 9 kHz in
HBS buffer and at drive amplitudes of 100 to 150 mV. All solutions were
prepared or diluted in HBS buffer. The chelating SAMs were activated
with NiSO4 solution (5 mm) for 20 min, rinsed with HBS buffer, and incu-
bated for 30 min at 48C with bC-His6-tagged proteasomes (30 nm).[32,52]
Specifically immobilized proteins were detached in HBS buffer supple-
mented with imidazole (1m) and EDTA (500 mm). Imaging of the surface
was always performed in HBS buffer between these steps.
[32] A. Thess, S. Hutschenreiter, M. Hofmann, R. TampØ, W. Baumeis-
ter, R. Guckenberger, J. Biol. Chem. 2002, 277, 36321–36328.
[33] A. Ulman, Chem. Rev. 1996, 96, 1533–1554.
[34] C. Pale-Grosdemange, E. S. Simon, K. L. Prime, G. M. Whitesides, J.
Am. Chem. Soc. 1991, 113, 12–20.
[35] G. B. Sigal, C. Bamdad, A. Barberis, J. Strominger, G. M. White-
sides, Anal. Chem. 1996, 68, 490–497.
[36] L. Schmitt, M. Ludwig, H. E. Gaub, R. TampØ, Biophys. J. 2000, 78,
3275–3285.
[37] M. Mrksich, C. S. Chen, Y. N. Xia, L. E. Dike, D. E. Ingber, G. M.
Whitesides, Proc. Natl. Acad. Sci. USA 1996, 93, 10775–10778.
[38] K. L. Prime, G. M. Whitesides, Science 1991, 252, 1164–1167.
[39] D. K. Schwartz, Annu. Rev. Phys. Chem. 2001, 52, 107–137.
[40] R. Valiokas, S. Svedhem, M. Ostblom, S. C. T. Svensson, B. Lied-
berg, J. Phys. Chem. B 2001, 105, 5459–5469.
Acknowledgements
We acknowledge Gerhard Spatz-Kümbel for excellent technical assis-
tance. We thank Dr. Ye Zhou and Dr. Olle Inganꢂs for providing materi-
als and laboratory, respectively, for the PDMS stamp preparation. We are
grateful to Dr. Silke Hutschenreiter, Dr. Lutz Schmitt, Dr. Alart Mulder,
and Katrin Schulze for stimulating discussions. The work was supported
by the Deutsche Forschungsgemeinschaft (DFG) and the BMBF Nano-
biotechnology Program. Work at Linkçping University was supported by
the Swedish Foundation for Strategic Research (SSF) through the Bio-
mimetic Materials Science Program.
[41] P. Harder, M. Grunze, R. Dahint, G. M. Whitesides, P. E. Laibinis, J.
Phys. Chem. B 1998, 102, 426–436.
[42] R. Valiokas, S. Svedhem, S. C. T. Svensson, B. Liedberg, Langmuir
1999, 15, 3390–3394.
[43] C. D. Bain, E. B. Troughton, Y. T. Tao, J. Evall, G. M. Whitesides,
R. G. Nuzzo, J. Am. Chem. Soc. 1989, 111, 321–335.
[44] R. Valiokas, M. Ostblom, S. Svedhem, S. C. T. Svensson, B. Lied-
berg, J. Phys. Chem. B 2002, 106, 10401–10409.
[45] L. Malysheva, Y. Klymenko, A. Onipko, R. Valiokas, B. Liedberg,
Chem. Phys. Lett. 2003, 370, 451–459.
[46] R. G. Nuzzo, L. H. Dubois, D. L. Allara, J. Am. Chem. Soc. 1990,
112, 558–569.
[47] M. Liley, T. A. Keller, C. Duschl, H. Vogel, Langmuir 1997, 13,
4190–4192.
[48] J. K. Lee, Y. G. Kim, Y. S. Chi, W. S. Yun, I. S. Choi, J. Phys.
Chem. B 2004, 108, 7665–7673.
[1] M. P. Washburn, Nat. Biotechnol. 2003, 21, 1156–1157.
[2] D. S. Wilson, S. Nock, Curr. Opin. Chem. Biol. 2002, 6, 81–85.
[3] G. MacBeath, Nat. Genet. 2002, 32, 526–532.
[4] S. Y. Seong, C. Y. Choi, Proteomics 2003, 3, 2176–2189.
[5] P. F. Predki, Curr. Opin. Chem. Biol. 2004, 8, 8–13.
[6] J. LaBaer, N. Ramachandran, Curr. Opin. Chem. Biol. 2005, 9, 14–
19.
[7] H. Zhu, M. Snyder, Curr. Opin. Chem. Biol. 2003, 7, 55–63.
[8] H. Zhu, M. Bilgin, R. Bangham, D. Hall, A. Casamayor, P. Bertone,
N. Lan, R. Jansen, S. Bidlingmaier, T. Houfek, T. Mitchell, P. Miller,
R. A. Dean, M. Gerstein, M. Snyder, Science 2001, 293, 2101–2105.
[9] P. D. Gershon, S. Khilko, J. Immunol. Methods 1995, 183, 65–76.
[10] S. Quetglas, C. Leveque, R. Miquelis, K. Sato, M. Seagar, Proc. Natl.
Acad. Sci. USA 2000, 97, 9695–9700.
[11] I. Gokce, E. M. Raggett, Q. Hong, R. Virden, A. Cooper, J. H.
Lakey, J. Mol. Biol. 2000, 304, 621–632.
[49] R. Arnold, W. Azzam, A. Terfort, C. Woll, Langmuir 2002, 18,
3980–3992.
[50] J. Piehler, G. Schreiber, Anal. Biochem. 2001, 289, 173–186.
[51] D. H. Waldeck, A. P. Alivisatos, C. B. Harris, Surf. Sci. 1985, 158,
103–125.
[12] M. R. Martzen, S. M. McCraith, S. L. Spinelli, F. M. Torres, S. Fields,
E. J. Grayhack, E. M. Phizicky, Science 1999, 286, 1153–1155.
[13] H. Bach, Y. Mazor, S. Shaky, A. Shoham-Lev, Y. Berdichevsky,
D. L. Gutnick, I. Benhar, J. Mol. Biol. 2001, 312, 79–93.
[14] P. Riggs, Mol. Biotechnol. 2000, 15, 51–63.
[52] E. Seemüller, A. Lupas, D. Stock, J. Lçwe, R. Huber, W. Baumeis-
ter, Science 1995, 268, 579–582.
[15] B. A. Bouchard, B. Furie, B. C. Furie, Biochemistry 1999, 38, 9517–
9523.
