Structure-Based Discovery and Synthesis of Potential
Transketolase Inhibitors
Jingqian Huo 1 , Bin Zhao
,†
2,† ID
, Zhe Zhang , Jihong Xing , Jinlin Zhang *, Jingao Dong 1,3,*
1
3
1,
and Zhijin Fan 2
,4,
*
ID
1
College of Plant Protection, Agricultural University of Hebei, Baoding 071001, China;
huojingqian@163.com (J.H.); zhang_z2013@163.com (Z.Z.)
2
State Key Laboratory of Elemento-Organic Chemistry, College of Chemistry, Nankai University, No. 94,
Weijin Road, Nankai District, Tianjin 300071, China; bdzhaobin@126.com
College of Life Science, Agricultural University of Hebei, Baoding 071000, China; xingjihong2000@126.com
Collaborative Innovation Center of Chemical Science and Engineering (Tianjin), Nankai University,
Tianjin 300071, China
3
4
*
†
Correspondence: zhangjinlin@hebau.edu.cn (J.Z.); dongjingao@126.com (J.D.); fanzj@nankai.edu.cn (Z.F.)
These authors contributed equally to this work.
ꢀ
ꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀ
ꢁꢂꢃꢄꢅꢆ
Received: 9 August 2018; Accepted: 21 August 2018; Published: 23 August 2018
Abstract: Transketolase (TKL) plays a key role in plant photosynthesis and has been predicted to be
a potent herbicide target. Homology modeling and molecular dynamics simulation were used to
construct a target protein model. A target-based virtual screening was developed to discover novel
potential transketolase inhibitors. Based on the receptor transketolase 1 and a target-based virtual
screening combined with structural similarity, six new compounds were selected from the ZINC
database. Among the structural leads, a new compound ZINC12007063 was identified as a novel
inhibitor of weeds. Two novel series of carboxylic amide derivatives were synthesized, and their
structures were rationally identified by NMR and HRMS. Biological evaluation of the herbicidal and
antifungal activities indicated that the compounds 4u and 8h were the most potent herbicidal agents,
and they also showed potent fungicidal activity with a relatively broad-spectrum. ZINC12007063
was identified as a lead compound of potential transketolase inhibitors, 4u and 8h which has the
herbicidal and antifungal activities were synthesized based on ZINC12007063. This study lays a
foundation for the discovery of new pesticides.
Keywords: transketolase; virtual screening; amides derivatives; synthesis; biological activity
1
. Introduction
Weed control in agricultural crops is a global problem. Chemical control has become the best
choice for weed control since the emergence of 2,4-dichlorophenoxyacetic acid (2,4-D) in the 1940s.
However, with the large number and long-term use of chemical herbicides, the negative effects of
weed resistance and ecological pollution have gradually been revealed [1,2]. Traditional pesticide
development not only requires a long period of time but also more financial resources. Accordingly,
it is urgently necessary to develop green highly efficient and environmentally friendly green herbicides.
With the advances in molecular biology and the widespread application of computer technology,
the combination of computer simulation, chemical synthesis and biological testing represents has been
became a new strategy for drug development. Currently, computer simulation is widely used in the
field of medicine, but it is rarely used in the field of herbicide development.
The enzyme transketolase is a limiting factor of photosynthesis, and small changes in its
activity can lead to the inhibition of plant growth as well as phenylalanine and aromatic amino acid
Molecules 2018, 23, 2116; doi:10.3390/molecules23092116
www.mdpi.com/journal/molecules

Molecules 2018, 23, 2116
2 of 12
metabolism [3–6]. Since transketolase plays a key role in plant photosynthesis, and is highly conserved
in plants, it represents an important candidate target for the development of new herbicides. Henkes [
3]
found that transketolase can be used as a target for new herbicide development, but inhibitors for this
enzyme have not been reported up until now.
Virtual screening is a cost-effective and efficient strategy in drug discovery. It involves searching
small molecule libraries to identify those structures that are most likely to bind to a biological target,
which is typically a proteinreceptor or enzyme [7]. Molecular docking is a drug screening method
based on the target protein three-dimensional (3D) structure. Through the molecular docking of
small molecules to the target, the spatial conformation can be analyzed, including the nature of the
electrostatic interactions, hydrogen bond, hydrophobic interactions and van der Waals forces [8].
Accordingly, virtual screening is a good tool for new compound discovery. In molecular docking,
to perform pharmacophore screening or shape similarity screening, a database with a larger diversity
of small molecules should be selected. For this purpose, we chose ZINC free database which contains
fragment libraries, drug pools, drug libraries, natural product libraries, etc. fragment libraries, drug
pools, drug libraries, natural product libraries, etc. [9].
In this study, the ZINC free database was screened by virtual screening using transketolase as the
target to obtain the potential transketolase inhibitors, and two novel series of amide derivatives were
designed and synthesized based on the structural leads, which could increase the structural diversity
and discover more potent inhibitors of transketolase.
2
. Results and Discussion
2
.1. Homology Modeling of AtTKL1
The structure of Arabidopsis thaliana transketolase (AtTKL1) was established by Modeller.
The sequence of AtTKL1 (ID: AT3G60750) was obtained from the TAIR database, and Zea mays
corn) transketolase ZmTKL1 (PDB, 1ITZ_A) [10] was chosen as the homologous model. The homology
(
was 85%, and the sequence coverage was 90%. The sequence alignment for modeling and the structural
elements are shown in Figure 1A, the structures of ZmTKL1 and AtTKL1 have similar tertiary structure.
The features of an
α helix, β sheet and r coil are conserved in both protein structures. The model of
AtTKL1 was optimized by dynamic simulation with Amber12 after 500 ps, and the stability of the
architecture was verified again. The final model was obtained by MD simulations to achieve the stable
3
D structure of AtTKL1 (Figure 1C). The stability of the architecture was verified again. The residues
in most of the favored regions [A, B, L] were 80.7%; the residues in the additional allowed regions
a, b, l, p] were 18.2%; the residues in the generously allowed regions [~a, ~b, ~l, ~p] were 1.1%;
[
and the residues in the disallowed regions were 0% (Figure 1B). All of the parameters were suitable for
virtual screening.
2
.2. Virtual Screening and Biological Activity
Transketolase is a target for herbicide design [3,11], and it has a highly conserved homologous
domain in higher plants and fungi. A total of 25 candidate molecules with binding affinities lower
than 8.5 kcal/mol (Table S1) were obtained from 1 million ZINC compounds after virtual screening.
−
Some compounds had similar structures, and thus we selected six small molecules that had a lower
affinity and different structures (Table 1). The combination of a small molecule model and transketolase
was simulated using PyMOL [12,13], and the details of the docking study of AtTKL1 with ligand
molecules are shown in Table 1. These small molecules could be bound by hydrogen bonding.
These compounds had similar molecular weights (350–500), XlogP (1.5–4.0), hydrogen donor (1–3),
hydrogen acceptor (6–10) and H-bond binding sites (Table 1, Figure S1). All of the selected compounds
were purchased from the ZINC database vendor. The biological activities of those compounds were
tested against rape and barnyard grass with a dosage of 500 mg/L. The bioassay indicated that

Molecules 2018, 23, 2116
3 of 12
ZINC12007063 displayed moderate to good herbicidal activity, and it had a similar herbicidal activity
to the commercial herbicide atrazine (Table 2).
With the development of computer technology and the emergence of the post genome era, there is
a new way to discover new drugs by computer-based virtual screening technology, which can provide
an opportunity for the re-identification of active compounds. In recent years, researchers have used
molecular docking technology to find an increasing number of lead compounds. Docking calculations
have been applied in pharmaceutical research for nearly two decades. To date, the researchers have
identified two million active compounds from approximately 500 targets. Admittedly, this technology
is still mainly used in the field of medicine, and it has not been widely used in the development
of pesticides.
In agriculture, Yuan et al. [14] has screened antifungal drugs from the ZINC database with CYP51,
which is an essential enzyme in sterol biosynthesis. A novel herbicide of urease inhibitors has also
been identified by virtual screening and in vitro assays [15]. However, with the advances of science
and technology, more of these new technologies will be applied to the field of pesticide development.
Figure 1. The bioinformatics analysis of transketolase. (
A. thaliana and ZmTKL1 in Zea mays; ( ) Ramachandran Plot of the protein after structural refinement;
) Refined structure of the AtTKL1 protein, where helix is shown in red, yellow indicates beta sheets,
and coil is shown in green color.
A) Structure alignment between AtTKL1 in
B
(
C

Molecules 2018, 23, 2116
4 of 12
Table 1. The structure of inhibitors which obtained by virtual screening.
Affinity
kcal/mol)
Molecular Weight
(g/mol)
H-Bond
Donors/Acceptors
H-Bond Binding
Site/Bond Distance
Structural
Formula
No.
ZINC ID and Chemical Name
xlogP
(
Ser266/3.3Å
Ser140/3.0Å
Gly232/3.4Å
His340/3.3Å
Leu194/2.9Å
Ser266/2.9Å
ZINC12007063
a
−9.1
−9.0
3.81
474.497
462.53
1/10
1/9
2
-[(2,2-dimethyl-3H-benzofuran-7-yl)oxy]-N-[2-(4-ethyl-6-oxo-1H-pyrimidin-2-yl)-5-(2-furyl)pyrazol-3
Ser266/3.3Å
Ser140/3.0Å
Gly232/3.4Å
His340/3.3Å
Leu194/2.9Å
ZINC12126699
b
4.07
N-[5-cyclopropyl-2-(4-isopropyl-6-oxo-1H-pyrimidin-2-yl)pyrazol-3-yl]-2-[(2,2-dimethyl-3H-benzofuran
His143/3.2Å
Gly/234/3.5Å
Gly232/3.1Å
ZINC19961402
c
−9.0
−8.7
1.61
4.33
391.818
392.405
3/7
1/6
(
5R,6S)-5(3-chlorophenyl)-4,7-dioxo-2-(phenylamino)-3,4,5,6.7,8-hexahydroquinazoline-6-carbonitrile
ZINC16283531
NE)-N-[[(4,6-dimethylpyrimidin-2-yl)amino]-[[3-(trifluoromethyl)phenyl]amino]methylene]-2,2-dimethyl
d
Gly234/3.2Å
(
His103/3.2Å
His340/3.5Å
Cys235/3.1Å
ZINC58191888
4Z)-4-[[4-[(1-methylimidazol-2-yl)methoxy]phenyl]-methyslene]isoquinoline-1,3-dione
e
f
−8.6
−8.6
2.5
359.385
377.404
1/6
1/8
(
Gly232/3.4Å
His340/3.1Å
Gly192/3.5Å
ZINC12929396
-isopropyl-N-methyl-N-[(4-oxo-3H-quinazolin-2-yl)methyl]isoxazolo[4,5-e]pyridine-5-carboxamide
3.46
3

Molecules 2018, 23, 2116
5 of 12
Table 2. Bioactivity of compounds (4a–4x and 8a–8n) through growth inhibition method (inhibition rate %, herbicide activity at 500 mg/L and fungicide activity at 50
mg/L).
Substituent Group
Herbicidal Activity
Brassica campestris Echinochloca crus-galli
Root Stem
Fungicide Activity
Compound
R
X
C. arachidicola
B. cinerea
G. zeae
S. sclerotiorum
R. cerealis
P. sasakii
Root
Stem
4
a
7-ethoxybenzofuran
pyridin-2-yl
pyridin-3-yl
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
H
H
H
H
H
H
CF3
CF3
CF3
CF3
CF3
CF3
CF3
CF3
/
0
0
0
0
0
0
0
46.24 ± 1.63
31.24 ± 1.63
8.57 ± 1.41
31.36 ± 2.16
27.97 ± 1.63
46.52 ± 1.41
42.30 ± 2.16
31.61 ± 0.82
15.23 ± 2.83
23.06 ± 0.82
8.41 ± 0.82
46.52 ± 2.94
0
31.61 ± 0.82
36.99 ± 2.16
27.16 ± 1.63
27.12 ± 3.56
36.35 ± 1.41
18.81 ± 0.82
55.49 ± 2.94
27.61 ± 0.82
36.35 ± 1.63
45.19 ± 1.63
64.56 ± 2.94
47.89 ± 4.97
40.39 ± 0.82
53.19 ± 2.16
27.18 ± 1.63
18.49 ± 2.83
36.48 ± 3.74
27.18 ± 1.63
27.19 ± 1.41
27.49 ± 3.27
36.52 ± 1.63
9.87 ± 1.41
27.91 ± 3.27
45.49 ± 1.63
9.35 ± 2.16
17.29 ± 3.56
/
30.24 ± 2.94
50.95 ± 0.82
0
19.18 ± 1.63
26.34 ± 3.56
19.57 ± 1.63
26.02 ± 0.82
43.86 ± 2.16
37.56 ± 1.41
65.26 ± 5.89
30.15 ± 0.82
22.50 ± 8.29
15.35 ± 1.63
26.64 ± 1.41
41.53 ± 2.16
4.29 ± 3.56
59.58 ± 2.45
57.30 ± 5.35
43.91 ± 0.82
48.64 ± 1.41
24.28 ± 0.82
29.17 ± 1.63
48.61 ± 1.41
62.28 ± 1.63
43.09 ± 1.41
30 ± 2.45
97.18 ± 2.16
85.35 ± 2.94
96.09 ± 2.94
98.12 ± 1.63
81.39 ± 1.63
73.92 ± 3.56
100
0
39.65 ± 4.32
43.96 ± 2.16
30.28 ± 1.41
0
28.66 ± 3.56
63.17 ± 1.63
52.28 ± 2.94
0
4b
4.15 ± 1.63
14.24 ± 2.45
26.32 ± 2.94
73.85 ± 9.27
0
25.24 ± 1.41
23.32 ± 4.32
0
9.46 ± 1.41
9.94 ± 3.74
9.42 ± 7.12
14.97 ± 2.16
39.38 ± 7.12
17.49 ± 2.83
9.28 ± 4.32
0
4
c
31.30 ± 2.16
43.12 ± 5.35
0
6.12 ± 1.63
25.59 ± 2.45
4d
pyridin-4-yl
0
0
0
0
0
0
0
0
10.37 ± 1.41
21.28 ± 0.82
60.43 ± 0.82
35.28 ± 1.63
33.37 ± 0.82
70.29 ± 0.82
50.49 ± 0.82
30.58 ± 2.94
50.09 ± 1.63
55.98 ± 1.63
30.94 ± 2.94
50.37 ± 0.82
40.29 ± 0.82
45.38 ± 2.16
50.49 ± 4.08
60.38 ± 0.82
65.94 ± 1.63
50.28 ± 2.16
65.37 ± 0.82
55.28 ± 1.63
75.68 ± 2.94
70.64 ± 1.63
25.28 ± 4.32
58.46 ± 0.82
67.35 ± 1.41
55.88 ± 1.63
50.92 ± 0.82
55.38 ± 0.82
54.19 ± 0.82
25.28 ± 2.16
50.94 ± 2.16
20.35 ± 1.41
50.97 ± 2.16
65.97 ± 0.82
60.68 ± 1.63
50.94 ± 2.16
24.35 ± 0.82
/
4
4
e
f
6-CF
3
-pyridin-2-yl
36.22 ± 1.41
thiophene-2-yl
furan-2-yl
Ph
2-CF3-Ph
3-CF3-Ph
4-CF3-Ph
3-F-Ph
4-F-Ph
2-F-Ph
2-Cl-Ph
3-Cl-Ph
0
0
4
g
27.21 ± 3.74
10.26 ± 2.16
4h
0
0
0
7.15 ± 2.94
100
4
4
i
j
0
96.01 ± 2.83
0
22.18 ± 3.74
5.18 ± 2.16
100
4.55 ± 1.41
9.37 ± 8.52
0
43.09 ± 6.98
33.17 ± 2.45
33.92 ± 10.2
22.40 ± 3.27
52.38 ± 5.89
24.19 ± 2.94
20.28 ± 0.82
8.07 ± 2.16
20.59 ± 2.94
24.94 ± 1.63
32.97 ± 0.82
12.08 ± 2.94
28.33 ± 3.74
12.28 ± 2.16
32.17 ± 0.82
39.16 ± 4.08
43.24 ± 3.56
35.49 ± 1.63
24.28 ± 1.41
16.57 ± 2.16
36.39 ± 3.56
35.02 ± 0.82
26.89 ± 3.56
24.34 ± 2.83
20.28 ± 9.42
24.19 ± 2.45
20.28 ± 1.41
16.47 ± 2.16
36.35 ± 2.16
13.02 ± 1.63
/
4k
17.02 ± 1.63
19.65 ± 2.94
71.14 ± 1.63
69.30 ± 2.94
19.08 ± 3.27
0
32.25 ± 3.60
59.66 ± 3.27
60.29 ± 1.63
54.48 ± 2.94
66.70 ± 0.82
25 ± 2.45
0
0
0
0
0
100
4
l
23.11 ± 1.41
45.20 ± 3.56
22.45 ± 2.94
8.18 ± 3.74
0
57.14 ± 3.56
40.02 ± 2.16
25.30 ± 2.16
41.01 ± 2.45
73.15 ± 2.83
0
96.94 ± 1.63
96.37 ± 2.83
94.38 ± 3.74
93.28 ± 2.45
71.30 ± 0.82
69.07 ± 4.97
64.32 ± 1.41
79.59 ± 4.32
62.27 ± 5.72
50.38 ± 2.94
69.29 ± 2.45
79.21 ± 1.41
79.28 ± 3.27
85.59 ± 3.56
98.03 ± 1.63
93.49 ± 2.16
76.58 ± 2.16
76.19 ± 2.16
71.49 ± 0.82
93.38 ± 2.16
95.06 ± 3.74
74.15 ± 1.41
74.27 ± 1.41
83.59 ± 4.55
57.14 ± 2.94
52.79 ± 7.35
67.29 ± 8.04
63.94 ± 3.56
/
4
4
m
n
61.25 ± 2.45
12.14 ± 2.94
21.15 ± 1.63
0
35.38 ± 4.32
9.25 ± 1.63
9.34 ± 2.94
23.36 ± 2.16
14.63 ± 2.94
18.28 ± 2.45
18.91 ± 11.43
14.28 ± 5.72
36.97 ± 3.56
36.29 ± 2.94
14.52 ± 1.41
23.88 ± 2.16
23.34 ± 3.74
24.09 ± 2.16
10.29 ± 2.94
19.87 ± 4.32
5.24 ± 1.63
9.91 ± 1.41
27.28 ± 3.74
0
0
4
4
4
o
p
q
5.15 ± 2.94
0
0
0
0
4-Cl-Ph
6.18 ± 2.16
4
4
4
r
s
t
2,6-F2-Ph
2,4-Cl2-Ph
PhOCH2CH2
0
2.92 ± 2.16
33.45 ± 4.32
83.52 ± 2.16
0
10.18 ± 4.32
55.26 ± 2.45
0
4
4
u
v
2,4-Cl
2
-PhOCH
2
CH
CH
2
4-NO2-Ph
4-MeO-Ph
cyclopropyl
3-CF3-Ph
3-Cl-Ph
PhOCH2CH2
4w
0
58.24 ± 2.45
26.40 ± 4.24
9.20 ± 3.27
47.48 ± 1.63
38.17 ± 3.56
21.18 ± 4.08
43.54 ± 5.89
21.40 ± 1.41
15 ± 2.94
41.15 ± 1.63
8.18 ± 2.16
20.18 ± 2.16
3.24 ± 1.41
3.20 ± 2.16
44.18 ± 2.16
0
33.23 ± 2.16
10.12 ± 2.16
20.02 ± 6.48
16.65 ± 3.74
10.15 ± 1.63
5.47 ± 4.32
31.24 ± 4.55
5.18 ± 1.63
0
4
8
x
a
0
11.04 ± 1.63
17.10 ± 2.16
41.24 ± 2.16
60.55 ± 1.41
29.58 ± 2.16
13.22 ± 2.83
0
19.44 ± 4.24
72.25 ± 4.55
26.15 ± 2.16
40.25 ± 2.16
29.02 ± 2.45
0
33 ± 0.82
53.15 ± 3.56
56.22 ± 1.63
73.27 ± 2.94
76.25 ± 0.82
27.49 ± 2.16
31.54 ± 3.74
52.22 ± 6.48
82.48 ± 7.26
48.47 ± 2.94
35.26 ± 4.32
18.30 ± 2.94
2.19 ± 1.41
12.18 ± 2.94
4.24 ± 2.94
78.48 ± 2.16
96.54 ± 1.63
/
37.17 ± 0.82
40.76 ± 1.41
43.16 ± 0.82
40.25 ± 0.82
57.28 ± 6.53
38.66 ± 3.74
69.19 ± 1.63
37.17 ± 2.94
62.91 ± 8.83
37.09 ± 2.45
24.28 ± 0.82
38.17 ± 3.56
62.29 ± 0.82
38.89 ± 4.55
16.21 ± 1.41
/
8b
8
c
8d
2,4-Cl
4-MeO-Ph
6-CF -pyridin-2-yl
2
-PhOCH
2
2
8
8
e
f
3
8
g
3-CF3-Ph
PhOCH2CH2
3-Cl-Ph
2-Cl-Ph
4-Cl-Ph
4-NO2-Ph
4-MeO-Ph
3
6-CF -pyridin-2-yl
8h
11.08 ± 4.08
19.21 ± 2.83
8
8
i
j
0
0
1.08 ± 0.82
0
9.20 ± 3.56
13.30 ± 2.45
0
61.18 ± 3.27
90.23 ± 2.83
/
14.19 ± 1.63
23.28 ± 1.41
27.09 ± 4.55
14.68 ± 1.41
9.53 ± 2.94
36.27 ± 2.16
/
8k
8
l
8
8
m
n
11.15 ± 3.27
2.99 ± 2.16
63.22 ± 2.83
92.45 ± 4.32
/
ZINC12007063
Atrazine
Azoxystrobin
/
/
/
66.18 ± 2.16
92.62 ± 4.32
/
/
/
56.49 ± 1.41
71.29 ± 1.63
75.19 ± 2.16
100
88.10 ± 1.41
84.34 ± 2.45
Note: Representative fungi used in this study included B. cinereal, C. arachidicola, G. zeae, P. sasakii, S. sclerotiorum, and R. cerealis; “/” means that which is not detected or non-existent.

Molecules 2018, 23, 2116
6 of 12
2
.3. The Syntheses and Biological Activities of the New Compounds
Virtual screening and biological activity analysis showed that ZINC12007063 had a good
herbicidal activity. Basing on compound ZINC12007063, two novel series of carboxylic amides
were designed (Scheme 1) and synthesized. The two-novel series of carboxylic amides (4a 4x
and (8a 8n) were synthesized as described in Scheme 2, and the structures are shown in Table 2.
-Furoylacetonitrile, which is required in the synthesis of both series of compounds 4a 4x and 8a 8n
–
)
–
2
–
–
,
was prepared from methyl-2-furoate. The reaction of methyl-2-furoate with CH CN in the presence of
3
NaH in toluene at the refluxing temperature for 24 h gave 2-furoylacetonitrile. 2-Furoylacetonitrile
was then reacted with 2-hydrazinepyrimidine or 2,3-dichloro-5-substituted pyridine in absolute
ethanol at the refluxing temperature to afford 3-(furan-2-yl)-1-pyrimidin-1H-pyrazol-5-amine (
-(furan-2-yl)-1-(3-dichloro-5-substituted pyridine-2-yl)-1H-pyrazol-5-amines ( ). The substituted
acyl chlorides were obtained by the reaction of the corresponding carboxylic acids with SOCl and a
3) or
3
7
2
catalytic amount of DMF at the refluxing temperature. Compounds 4a
by the condensation reaction of the substituted acyl chlorides with intermediates
the base and CH Cl as the solvent.
–
4x and 8a
–
8n were synthesized
or using Et N as
3
7
3
2
2
Scheme 1. The design strategy for new compounds.
(
A)
(
B)
Scheme 2. Synthetic route for compounds 4a
a) absolute ethanol, hydrazine hydrate, refluxing for 90 min; (b) absolute ethanol, 2-furoylacetonitrile,
refluxing for 120 min; (c) anhydrous DCM, substituted acyl chloride, Et N, room temperature,
–4x and 8a–8n. (A) Reagents and conditions for 4a–4x:
(
3
overnight. (
for 180 min; (b) absolute ethanol, 2-furoylacetonitrile, refluxing for 180 min; (c) anhydrous DCM,
substituted acyl chloride, Et N, room temperature, overnight.
B) Reagents and conditions for 8a–8n: (a) absolute ethanol, hydrazine hydrate, refluxing
3

Molecules 2018, 23, 2116
7 of 12
The reaction temperature was very important for the cyclization reaction of 2-furoylacetonitrile
with 3-(furan-2-yl)-1-pyrimidin-H-pyrazol-5-amine ( ) or 3-(furan-2-yl)-1-(3-dichloro-5-substituted
pyridine-2-yl)-H-pyrazol-5-amines ( ) and a by-product was detected unless the reaction was
3
7
performed at reflux temperature. The crude products were purified by column chromatography
over silica gel (200–300 mesh) using ethyl acetate-petroleum ether or dichloromethane-methanol as the
eluent to afford pure products 4a–4x and 8a–8n.
The chemical structures of the newly synthesized compounds were established on the basis of
1
analytical and spectroscopic data. In the H-NMR spectra, the chemical shifts for the amide NH were
found at δ = 13.74–10.48 ppm as singlets. The aromatic proton signals appeared at δ = 9.24–6.43 ppm.
The signals for OCH and CH were observed at
δ = 3.91–3.89 and 4.82–3.09 ppm, respectively.
3
2
Furthermore, all compounds were confirmed by ESI-MS and were in agreement with their molecular
weight. The molecular structure of compound 4b is shown in Figure S2. X-ray single-crystal diffraction
analysis further confirmed the structure of compound 4b. The appearance, yields, melting points and
spectral data of the synthesized compounds are described in the Supporting Information.
2
.4. The Biological Activities of the New Compounds 4a–4x and 8a–8n
A. thaliana is a widely used model plant which could be used to develop a homology model,
and Brassica campestris L. (rape) and Echinochloca crus-galli L. (barnyard grass) were the two
representative plants used to measure the herbicidal activity. All of the synthesized compounds
4
a– , 8a–8n were evaluated for herbicidal activity against rape and barnyard grass at dosages of
4x
5
00 mg/L. Some compounds displayed moderate to good herbicidal activity against rape and barnyard
grass in the bioassays (Table 2). For example, 4u exhibited inhibitory rates of >80% towards the root
growth of barnyard grass, and 8h showed inhibitory rates of >80% towards the root growth of rape.
However, some compounds showed poor or no herbicidal activity against rape and/or barnyard grass.
In general, the herbicidal activities of compounds 8a–8n were higher than those of compounds 4a–4x,
which indicated that the introduction of a chloro or trifluoromethyl substituent could improve the
herbicidal activity. For example, compound 8h displayed higher herbicidal activities than compound
4t, which had no chloro or trifluoromethyl substituent. In addition, 4n, 4q, 4r, 4s and 8d showed
stronger inhibition against the growth of the dicotyledon rape than that of the monocotyledon barnyard
grass, and 4e as well as 4w showed stronger inhibition against the growth of the barnyard grass than
that of the rape. Furthermore, these compounds exhibited a relative selectivity.
Transketolase is widely distributed in microorganisms, such as fungi, bacteria, yeast and so
on. Therefore, the inhibitory effects of all of the synthesized compounds 4a–4x, 8a–8n against six
typical fungi were evaluated at dosages of 50 mg/L in vitro. Azoxystrobin was used as a positive
control. Some compounds showed good fungicide activity against the selected fungi (Table 2). All of
the compounds showed moderate to good antifungal activity against the strain of S. sclerotioru.
Compound 4x presented the best activity against the strain of C. arachidicola, with an inhibition rate of
6
4.56%, which was higher than that of azoxystrobin. The inhibition rates of compounds 4f
,
4g and 4n
against P. sasakii were above 50%. Compounds 4f, 4g, 4n, 8a, 8c and 8e had relatively broad-spectrum
fungicidal activity.
Bio-rational design of new pesticide molecules based on target genes or proteins plays an
important role in the current new pesticide creation process and is an important way to develop
new pesticides [16–18]. Therefore, the search and verification of new drug targets will become hot in
the development of new drugs [19
–
21]. In addition, design and development of novel eco-friendly
pesticides based on a new target [22] is of great importance to solve the resistance problem. Optimizing
the structure of a lead compound, which is obtained based on the new target, will give a chance to
develop more potent inhibitors. In this study, we identified compound ZINC12007063 with good
herbicidal activity according to the virtual screening based on transketolase. To obtain more potential
transketolase inhibitors, some heterocyclic groups were introduced to modify the lead compound
structure according to the bio-electronic isotype principle and at last two novel series of carboxylic

Molecules 2018, 23, 2116
8 of 12
amide derivatives were synthesized. The bioassay results of the synthesized compounds indicated
that the herbicidal activities and fungicide activities of compounds 4u and 8h were all better than
those of the lead compound ZINC12007063. The design and synthesis of compounds with multiple
activities at the same time seems difficult, and currently, there are few reports in this area. Zhang et al.
have synthesized 5-substituted-1,3,4-oxadiazole Mannich bases and bis-Mannich bases with a target
ketol-acid reductoisomerase, which exhibited obvious herbicidal activity against Echinochloa crus-galli
and fungicidal activities against Rhizoctonia cerealis and Physalospora piricola [23,24]; Zhao et al. have
designed and synthesized a series of novel triazines containing arylmethyl amino moieties, but some
compounds only have good activity on plants or fungi [25].
2
.5. Molecular Docking of Compounds 4u and 8h with Transketolase
In order to better understand the mechanism of newly designed potential transketolase inhibitors,
all the derivatives were docked into the active site of AtTKL1. The detailed interactions of compounds
ZINC12007063, 4u and 8h with AtTKL1 are showed in Figure 2. In the docked complex of compound
ZINC12007063 and AtTKL1 (Figure 2A,D), the benzene ring benzotetrahydrofuran of ZINC12007063
4
interacted with His103 through a
π
-
π
interaction. Moreover, the tetrahydrofuran ring and O of
ZINC12007063 formed a hydrogen bond with catalytic site residues Leu194 and His340 respectively,
20
which were importantly catalytic site in AtTKL1 . Through docking analysis between 4u with AtTKL1
Figure 2B,E) and 8h with AtTKL1 (Figure 2C,F), we found a similar combination pattern. In addition,
(
the compounds 4u and 8h can combined Gly234 of AtTKL1 with hydrophobic interaction. All of these
favorable interactions may result in the potent bioactivity of 4u and 8h.
Thus, the changes in some functional groups did not affect ligand-protein binding, but biological
activity was better than the control. In the future, we will design new compounds based on
the quantitative structure-activity relationship analysis and consider the affinity of the designed
compounds with transketolase based on molecular docking. Therefore, this study will lay the
foundation for the further design and synthesis of new bioactive compounds.
(
A)
(B)
(C)
(
D)
(E)
(F)
Figure 2. Binding mode of ZINC12007063 (A,D), 4u (B,E) and 8h (C,F).

Molecules 2018, 23, 2116
9 of 12
3
. Materials and Methods
3
.1. Homology Modeling of A. thaliana Transketolase 1 (AtTKL1)
The protein sequence of A. thaliana transketolase 1 (AtTKL1) was obtained from the TAIR
database. The Modeller 9.13 software is used for the modeling of protein 3D structures [26 28].
–
Molecular dynamics and energy minimization were carried out using Amber12 according to standard
approaches [29]. The structural evaluation for AtTKL1 was performed by the ERRAT server [30],
Procheck server [31], and Verify3d server [32].
3
.2. Virtual Screening
The almost one million chemical ligand structures used in this study were downloaded from the
ZINC database (http://zinc.docking.org). The PDBQT files of the receptor and ligands were converted
by Open Babel 2.3.2 [33]. Then, the receptor and ligand docking studies were conducted using the
AutoDock Vina program [34].
3
.3. Biological Activities of Compounds
3
.3.1. Herbicidal Bioassay
The effects of the compounds on inhibiting the growth of dicotyledonous rape (B. campestris L.)
and monocotyledonous barnyard grass (E. crus-galli L.) were assessed using the small cup method.
Generally, the compound (2 mg) was dissolved in acetone (80 L). Then, the solution was diluted with
µ
water containing 0.2% Tween 80 to reach a concentration of 500 mg/L. The mixture of the same amount
of water, acetone, and Tween 80 was used as a control. Barnyard grass seeds and rape seeds were
soaked in distilled water for 12 h before being placed on a filter paper in a 5 cm cup, to which 1 mL of
inhibitor solution had been added in advance. Usually, 10 barnyard grass seeds and 10 rape seeds were
used for each cup. Each treatment was repeated three times. The cup was placed in an illumination
◦
2
incubator and kept at 25 C, with light of 10 µmol/m /s for 12 h each day. After incubation for 7 days,
the root and stalk of two test plants were measured in each cup, respectively. The percentage inhibition,
which is based on the measurement of root length (or stalk length) compared to an untreated control,
was used to describe the control efficiency of the compound.
3
.3.2. Fungicide Bioassay
The effects of the compounds on inhibiting the growth of fungi were assessed using the fungi
growth inhibition method with potato dextrose agar (PDA) as the cultivation medium. Generally, 2 mg
of the compound was dissolved in 200 L of N,N-dimethylformamide (DMF), and then, 3.8 mL of
µ
sterilized water was added to obtain a stock solution with a concentration of 500 mg/L. One milliliter
of the stock solution was transferred into a 10 cm diameter Petri dish. Plates were prepared with 9 mL
of PDA. Before the plate solidification, the PDA was thoroughly mixed by turning the Petri dish in the
sterilized hood 5 times to scatter the compound evenly in the PDA. Next, each plate was inoculated
◦
with a 4 mm diameter fungi cake and cultured in the culture tank at 24~26 C. Each treatment was
repeated three times. The diameter of the fungal spread was measured 2 days later. The growth
inhibition was then calculated using the corresponding blank.
3
.4. Designing and Synthesizing New Compounds as Potent Herbicide Candidates
To increase the structural diversity and discover more potent inhibitors of transketolase, it is
important to design new compounds based on the structures of candidate compounds that have good
activities. All reagents and solvents for the syntheses and analyses were of analytical grade and used
without further treatment unless otherwise stated. Column chromatography purification was carried
out by using silica gel (200~300 mesh). The melting points were measured on an XT-4A apparatus,
and are uncorrected. NMR spectra were obtained on an AV-400 spectrometer (Bruker, Rheinstetten,

Molecules 2018, 23, 2116
10 of 12
1
13
Germany) operating at 400 MHz for H NMR and 100 MHz for C NMR using CDCl or DMSO-d
3
6
as solvents and TMS as the internal standard. The high-resolution mass spectra were recorded on
a 6520-QTOF LC/MS (Agilent, Santa Clara, CA, USA) with an ESI source in the positive ion mode.
The single-crystal structure was determined on a Saturn 724 CCD diffractometer (Rigaku, Woodlands,
TX, USA).
4
. Conclusions
Transketolase is a target for herbicide design, and a highly active lead compound ZINC12007063
was identified by virtual screening. Based on this lead compound, compounds 4u and 8h
,
two carboxylic amide derivatives, were synthesized, and both have herbicidal and antifungal activities.
This study will lay a foundation for discovering new pesticides.
Supplementary Materials: The following are available online, Figure S1: The binding mode between the small
molecules and transketolase, Figure S2: Molecular structure of compound 4b shown as thermal, Table S1:
The Docking affinity of the compounds with transketolase, the other supplementary database: The appearance,
yields, melting points and spectral data of the synthesized compounds.
Author Contributions: The experiments were conceived and planned by J.H., B.Z., J.D. and J.Z., the manuscript
was written by J.H., Z.F. and Z.Z. Experiments were performed by B.Z., J.H. and J.X. The final version of this
manuscript has been read and approved by all authors.
Funding: This research was funded by the National Nature Science Foundation of China (No. 31471786).
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
Fan, Z.J.; Ai, Y.W.; Qian, C.F.; Li, Z.M. Herbicide activity of monosulfuron and its mode of action.
J. Environ. Sci. 2005, 17, 399–403.
Song, Y. Insight into the mode of action of 2,4-dichlorophenoxyacetic acid (2,4-D) as an herbicide. J. Integr.
Plant Biol. 2014, 56, 106–113. [CrossRef] [PubMed]
Henkes, S.; Sonnewald, U.; Badur, R.; Flachmann, R.; Stitt, M. A small decrease of plastid transketolase
activity in antisense tobacco transformants has dramatic effects on photosynthesis and phenylpropanoid
metabolism. Plant. Cell 2001, 13, 535–551. [CrossRef] [PubMed]
4.
5.
6.
7.
Ikeda, M.; Kamada, N.; Takano, Y.; Nakano, T. Molecular analysis of the Corynebacterium glutamicum
transketolase gene. Biosci. Biotechnol. Biochem. 1999, 63, 1806–1810. [CrossRef] [PubMed]
Suzuki, Y.; Kondo, E.; Makino, A. Effects of co-overexpression of the genes of rubisco and transketolase on
photosynthesis in rice. Photosynth. Res. 2017, 131, 281–289. [CrossRef] [PubMed]
Zhang, Q.; Linnemann, T.V.; Schreiber, L.; Bartels, D. The role of transketolase and octulose in the resurrection
plant Craterostigma plantagineum. J. Exp. Bot. 2016, 67, 3551–3559. [CrossRef] [PubMed]
Bagherzadeh, K.; Shirgahi Talari, F.; Sharifi, A.; Ganjali, M.R.; Saboury, A.A.; Amanlou, M. A new insight into
mushroom tyrosinase inhibitors: Docking, pharmacophore-based virtual screening, and molecular modeling
studies. J. Biomol. Struct. Dyn. 2015, 33, 487–501. [CrossRef] [PubMed]
8
9
1
.
.
De Ruyck, J.; Brysbaert, G.; Blossey, R.; Lensink, M.F. Molecular docking as a popular tool in drug design, an
in silico travel. Adv. Appl. Bioinform. Chem. 2016, 9, 1–11. [CrossRef] [PubMed]
Irwin, J.J.; Shoichet, B.K. ZINC—A free database of commercially available compounds for virtual screening.
J. Chem. Inf. Model. 2005, 45, 177–182. [CrossRef] [PubMed]
0. Gerhardt, S.; Echt, S.; Busch, M.; Freigang, J.; Auerbach, G.; Bader, G.; Martin, W.F.; Bacher, A.; Huber, R.;
Fischer, M. Structure and properties of an engineered transketolase from maize. Plant Physiol. 2003, 132,
1
941–1949. [CrossRef] [PubMed]
1
1. Zhao, B.; Huo, J.; Liu, N.; Zhang, J.; Dong, J. Transketolase is identified as a target of herbicidal substance
alpha-terthienyl by proteomics. Toxins 2018, 10, 41. [CrossRef] [PubMed]
1
2. Lill, M.A.; Danielson, M.L. Computer-aided drug design platform using pymol. J. Comput.-Aided Mol. Des.
2
011, 25, 13–19. [CrossRef] [PubMed]

Molecules 2018, 23, 2116
11 of 12
1
1
3. Seeliger, D.; De Groot, B.L. Ligand docking and binding site analysis with pymol and autodock/vina.
J. Comput.-Aided Mol. Des. 2010, 24, 417–422. [CrossRef] [PubMed]
4. Yuan, Y.; Han, R.; Cao, Q.; Yu, J.; Mao, J.; Zhang, T.; Wang, S.; Niu, Y.; Liu, D. Pharmacophore-based virtual
screening of novel inhibitors and docking analysis for CYP51a from Penicillium italicum. Mar. Drugs 2017
5, 107. [CrossRef] [PubMed]
,
1
1
5. Khan, K.M.; Wadood, A.; Ali, M.; Zia, U.; Ul-Haq, Z.; Lodhi, M.A.; Khan, M.; Perveen, S.; Choudhary, M.I.
Identification of potent urease inhibitors via ligand- and structure-based virtual screening and in vitro assays.
J. Mol. Graph. Model. 2010, 28, 792–798. [CrossRef] [PubMed]
1
1
1
1
6. Deng, X.-L.; Zhang, L.; Hu, X.-P.; Yin, B.; Liang, P.; Yang, X.-L. Target-based design, synthesis and biological
activity of new pyrazole amide derivatives. Chin. Chem. Lett. 2016, 27, 251–255. [CrossRef]
7. Lu, J.; Zhang, P.; Bi, Y.; Luo, X. Analysis of a drug target-based classification system using molecular
descriptors. Comb. Chem. High Throughput Screen. 2016, 19, 129–135. [CrossRef] [PubMed]
8. Turnbull, A.P.; Boyd, S.; Walse, B. Fragment-based drug discovery and protein-protein interactions.
Res. Rep. Biochem. 2014, 4, 13–26. [CrossRef]
9. Moreno, M.A.; Alonso, A.; Alcolea, P.J.; Abramov, A.; De Lacoba, M.G.A.; Abendroth, J.; Zhang, S.;
Edwards, T.; Lorimer, D.; Myler, P.J. Tyrosine aminotransferase from leishmania infantum: A new drug
target candidate. Int. J. Parasitol. Drugs Drug Resist. 2014, 4, 347–354. [CrossRef] [PubMed]
0. Morris, G.; Anderson, G.; Dean, O.; Berk, M.; Galecki, P.; Martin-Subero, M.; Maes, M. The glutathione
system: A new drug target in neuroimmune disorders. Mol. Neurobiol. 2014, 50, 1059–1084. [CrossRef]
2
2
[
PubMed]
1. Lu, P.; Hontecillas, R.; Casandra, W.P.; Bassaganya-Riera, J. Lanthionine synthetase component c-like protein
: A new drug target for inflammatory diseases and diabetes. Curr. Drug Targets 2014, 15, 565–572. [CrossRef]
PubMed]
2. Dayan, F.E.; Duke, S.O. Natural compounds as next-generation herbicides. Plant Physiol. 2014, 166, 1090–1105.
CrossRef] [PubMed]
2
[
2
2
[
3. Zhang, Y.; Liu, X.H.; Zhan, Y.Z.; Zhang, L.Y.; Li, Z.M.; Li, Y.H.; Zhang, X.; Wang, B.L. Synthesis and biological
activities of novel 5-substituted-1,3,4-oxadiazole mannich bases and bis-mannich bases as ketol-acid
reductoisomerase inhibitors. Bioorg. Med. Chem. Lett. 2016, 26, 4661–4665. [CrossRef] [PubMed]
2
4. Wang, B.L.; Zhang, L.Y.; Liu, X.H.; Ma, Y.; Zhang, Y.; Li, Z.M.; Zhang, X. Synthesis, biological activities and
sar studies of new 3-substitutedphenyl-4-substitutedbenzylideneamino-1,2,4-triazole mannich bases and
bis-mannich bases as ketol-acid reductoisomerase inhibitors. Bioorg. Med. Chem. Lett. 2017, 27, 5457–5462.
[
CrossRef] [PubMed]
5. Zhao, H.; Liu, Y.; Cui, Z.; Beattie, D.; Gu, Y.; Wang, Q. Design, synthesis, and biological activities of
arylmethylamine substituted chlorotriazine and methylthiotriazine compounds. J. Agric. Food Chem. 2011
9, 11711–11717. [CrossRef] [PubMed]
6. Chen, Y.; Shang, Y.; Xu, D. Multi-dimensional scaling and modeller-based evolutionary algorithms for
protein model refinement. In Proceedings of the 2014 IEEE Congress on Evolutionary computation, Beijing,
China, 6–11 July 2014; pp. 1038–1045.
2
2
,
5
2
2
2
7. Parida, B.K.; Panda, P.K.; Misra, N.; Mishra, B.K. MaxMod: A hidden markov model based novel interface to
modeller for improved prediction of protein 3D models. J. Mol. Model. 2015, 21, 30. [CrossRef] [PubMed]
8. Eswar, N.; Eramian, D.; Webb, B.; Shen, M.Y.; Sali, A. Protein structure modeling with modeller.
Methods Mol. Biol. 2008, 426, 145–159. [PubMed]
9. Kassler, K.; Meier, J.; Eichler, J.; Sticht, H. Structural basis for species selectivity in the HIV-1 gp120-cd4
interaction: Restoring affinity to gp120 in murine cd4 mimetic peptides. Adv. Bioinform. 2011, 2011, 736593.
[CrossRef] [PubMed]
3
3
0. Colovos, C.; Yeates, T.O. Verification of protein structures: Patterns of nonbonded atomic interactions.
Protein Sci. A Publ. Protein Soc. 1993, 2, 1511–1519. [CrossRef] [PubMed]
1. Laskowski, R.A.; Rullmannn, J.A.; MacArthur, M.W.; Kaptein, R.; Thornton, J.M. AQUA and
PROCHECK-NMR: Programs for checking the quality of protein structures solved by NMR. J. Biomol. NMR
1
996, 8, 477–486. [CrossRef] [PubMed]

Molecules 2018, 23, 2116
12 of 12
3
3
3
2. Luthy, R.; Bowie, J.U.; Eisenberg, D. Assessment of protein models with three-dimensional profiles. Nature
992, 356, 83–85. [CrossRef] [PubMed]
3. O’Boyle, N.M.; Banck, M.; James, C.A.; Morley, C.; Vandermeersch, T.; Hutchison, G.R. Open babel: An open
chemical toolbox. J. Cheminform. 2011, 3, 33. [CrossRef] [PubMed]
4. Trott, O.; Olson, A.J. Autodock vina: Improving the speed and accuracy of docking with a new scoring
function, efficient optimization, and multithreading. J. Comput. Chem. 2010, 31, 455–461. [CrossRef]
1
[PubMed]
Sample Availability: Samples of the all target compounds are available from the authors.
©
2018 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
