Direct Base-Assisted C-H Cyclonickelation of
6-Phenyl-2,20-bipyridine
Nicolas Vogt 1 , Vasily Sivchik 2,3,
*
, Aaron Sandleben 1 , Gerald Hörner 4,5
and Axel Klein 1,
*
1
Department für Chemie, Institut für Anorganische Chemie, Universität zu Köln, Greinstraße 6,
D-50939 Köln, Germany; nicolasvogt89@gmail.com (N.V.); aaronsandleben@googlemail.com (A.S.)
Department of Chemistry, University of Eastern Finland, 80101 Joensuu, Finland
School of Chemistry, University of East Anglia, Earlham Road, Norwich NR4 7TJ, UK
Institut für Chemie, Anorganische Chemie IV, Universität Bayreuth, Universitätsstraße 30,
D-95440 Bayreuth, Germany; gerald.hoerner@uni-bayreuth.de
2
3
4
5
Theoretische Chemie, Technische Universität Berlin, Straße des 17. Juni 135, D-10623 Berlin, Germany
Correspondence: v.sivchik@uea.ac.uk (V.S.); axel.klein@uni-koeln.de (A.K.); Tel.: +49-221-470-4006 (A.K.)
*
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
Academic Editor: Burgert Blom
Received: 4 February 2020; Accepted: 20 February 2020; Published: 24 February 2020
ꢀꢁꢂꢃꢄꢅꢆ
Abstract: The organonickel complexes [Ni(Phbpy)X] (X = Br, OAc, CN) were obtained for the first
time in a direct base-assisted arene C(sp2)–H cyclometalation reaction from the rather unreactive
precursor materials NiX2 and HPhbpy (6-phenyl-2,20-bipyridine) or from the versatile precursor
[Ni(HPhbpy)Br2]2. Different from previously necessary C-Br oxidative addition at Ni(0), an extended
scan of reaction conditions allowed quantitative access to the title compound from Ni(II) on
synthetically useful timescales through base-assisted C-H activation in nonpolar media at elevated
temperature. Optimisation of the reaction conditions (various bases, solvents, methods) identified 1:2
mixtures of acetate and carbonate as unrivalled synergetic base pairs in the optimum protocol that
holds promise as a readily usable and easily tuneable access to a wide range of direct nickelation
products. While for the base-assisted C-H metalation of the noble metals Ru, Ir, Rh, or Pd, this
acetate/carbonate method has been established for a few years, our study represents the leap into the
world of the base metals of the 3d series.
Keywords: cyclometalation; cyclonickelation; C–H activation; organonickel; base-assisted
1. Introduction
Metal-driven C(sp2)-H activation and turnover of the resulting metalated species in catalytic
processes has for a long time been the domain of heavy elements from the 4d and 5d rows,
such as ruthenium, iridium and, especially, palladium. Platinum-promoted C-H activation of
hydrocarbons was one of the first milestones in this endeavour [
as cyclometalation initiated a period of rapid knowledge growth, owing to favourable metalation
kinetics and thermodynamics [ ]. Von Zelewsky et al. prepared the first biscycloplatinated derivatives
of 2-phenylpyridine by transmetalation of the carbolithiated precursor back in the 1980s as well as
discovered the intriguing luminescence of the obtained cyclometalated compounds [ ]. Later, Constable
et al. introduced cycloruthenation, cycloplatination, and cyclopalladation through C-H activation (direct
cyclometalation) of aryl/N-donor moieties [ ]. This straightforward synthetic approach coupled with
the potential diversity of -conjugated derivatives of CˆN ligands to tailor photophysical properties led
to intensive development in the field with more than 1000 congeners published today [ 19]. For Pd(II)
salts (e.g., chloride or acetate) the direct cyclometalation of 2-phenylpyridine proceeds already at
1]. The intramolecular variant coined
2,3
4
5,6
π
7–
room temperature [
6
,
14
,
20]. Not surprisingly, a considerable number of
π-conjugated CˆN-derivatives
Molecules 2020, 25, 997; doi:10.3390/molecules25040997
www.mdpi.com/journal/molecules

Molecules 2020, 25, 997
2 of 13
are reported with interesting photophysical and biomedical properties [20
,21]. Moreover, the ease
of cyclopalladation resulted in the development of ground-breaking catalytic technologies based on
Pd-catalysed directed C−H functionalisation [22–25].
In sharp contrast to the literally thousands of examples available for Pd(II) and Pt(II),
cyclometalated Ni(II) derivatives of nitrogen-donating π-conjugated moieties have remained rare
species, although the first example of a cyclometalated Ni(II) complex, [Ni(Cp)(o-phenylazo)-phenyl)],
was prepared from [Ni(Cp)2] (Cp− = cyclopentadienide) in 1963 [26]. Van Koten et al. introduced
two approaches for the synthesis of Ni(NˆCˆN)-pincer complexes: (a) transmetalation of a Au(I)
precursor; or (b) oxidative addition of zero-valent nickel to the bromoaryl precursor [27]. Much later,
Wolczanski et al. directly metalated 2-phenylpyridine under harsh heating conditions (Scheme 1) [28],
whereas Klein et al. performed a two-step cyclometalation via Pd-directed ortho-bromination of
6-phenyl-2,20-bipyridine followed by the oxidative addition of zero-valent nickel, akin to van Koten’s
approach [29,30]. Direct, base-assisted metalation with NiCl2 was demonstrated by Gong and Song
in a pincer topology [31] and, in a similar approach by Zargarian et al. [32], it was found to be also
feasible in macrocyclic NˆCˆNˆC or NˆCˆNˆN setups [33]. These reactions were considered to be
electrophilic substitutions (H+ versus Ni(II)) that are archetypal for Pt(II) and Pd(II) complexes [
1,25]
but quite unique for Ni(II). Mechanistic insights were provided by van der Vlugt et al. for the formation
of a [Ni(CNP)Br] pincer complex from the tetrahedral [Ni(HCˆNˆP)Br2] precursor using NEt3 as a
base (Scheme 2) [34]. The isolation of a tri-coordinated T-shaped Ni complex with weak (an)agostic
Ni . . . (H-C) interaction invokes C-H bond coordination to Ni(II), forming a sigma-complex as a key
step of the process with base neutralising the proton outside of the coordination sphere.
Scheme 1. Cyclonickelation of C(sp2)-H bonds with monodentate and bidentate N-heterocyclic
directing groups.
Evidence for an inner-sphere attack of coordinated base was provided by Punji et al., who proposed
the anion exchange of chloride or acetate by bis(trimethylsilyl)amide as a step precluding N-directed
C-H bond activation under solvent-free conditions [35] (Scheme 2). In keeping with this, Musaev
et al. suggested a cesium/carboxylate cluster as the active basic principle based on computational
studies [36]. The latter treatment appears to be the most comprehensive one to explain the “carboxylate
effect”, which is a recurrent motif in metalation at d8 metal centres, as reviewed a while ago by
Ackermann [37] and recently discussed in deep mechanistic detail by Macgregor et al. for Ru, Ir, Rh,
or Pd systems [38
–40]. Schafer, Love et al. elegantly adopted this motif for the C-H activation of
H3C-N(Cy)C(O)N(H)(quinolin-8-yl), forming [Ni(-CH2-N(Cy)(O)N(quinolinyl)(PEt3)] [41].

Molecules 2020, 25, 997
3 of 13
Herein, we describe the development of a user-friendly protocol for a quantitative direct,
base-assisted C(sp2)-H cyclonickelation procedure, relying on a simple ortho-phenyl pyridine system
and NiBr2 as the starting material. As a generic prototype of (di)nitrogen-directing moieties, we
have selected 6-phenyl-2,20-bipyridine (HPhbpy), rendering the protocol suitable for a wide range of
bidentate and tridentate ligands. Bidentate directional group assisted C–H activations have recently
gained high interest in organometallic catalysis [36,37,42–45]. In a thorough and comprehensive
scan of the reaction conditions (solvent; counter ion; temperature; external base(s); Schemes 2
and 3) we identified the combination of high-boiling nonpolar solvents and acetate/carbonate as a
homogeneous/heterogeneous base couple to enable rather rapid and very efficient nickelation.
Scheme 2. Examples of base-assisted cyclonickelations and scope of this work.
Scheme 3. Cyclonickelation methods A–C and prepared compounds.
2. Results
We worked out different procedures for the direct C-H cyclonickelation of 6-phenyl-2,20-bipyridine
(HPhbpy) to yield the previously reported red complex [Ni(Phbpy)Br] (Scheme 3) [29,30].

Molecules 2020, 25, 997
4 of 13
The first synthesis attempts using NiBr2 and HPhbpy in boiling ethanol or methanol were
unsuccessful. After the initial dissolution of the precursor materials, the typical red colour was
observed. However, further reaction and isolation yielded grey-green materials. This is in line
with earlier reports on the title complex [29,30] and related work on the complex [Ni(Mes)(bpy)Br]
(Mes = 2,4,6-trimethylphenyl; bpy = 2,20-bipyridine), which decomposes in protic solvents yielding
greenish octahedral Ni(II) species [46]. Avoiding protic solvents and working in vigorously dried
solvents, we heated HPhbpy with NiBr2 in toluene, but no yield was observed after 60 h at 130 ◦C
(Table 1, entry 1). In keeping with the few literature reports, we ascribe the lack of reactivity to the
lower basicity of the coordinated bromide ligand; similar observations have been reported by Campeau
et al. [47] for a Pd catalysed bimolecular arylation and by Maseras and Echavarren et al. [48] for an
intramolecular Pd-dependent arylation. In the following, we added external bases [49] such as NEt3,
NaHCO3, Na2CO3, or Cs2CO3 to the reaction mixture (Entries 2–6). While for most reaction conditions
the yields of [Ni(Phbpy)Br] were very poor (up to 2%), for Na2CO3/90 h/reflux, a crude yield of 19%
was obtained (Table 1, Entry 6). In one of these experiments, MeOH was added to dissolve the starting
materials, and the reaction time could be tremendously shortened (Entry 3). However, yield was poor
due to decomposition, which was in line with the initial experiments. A further experiment in the melt
(Entry 4) showed no yield.
Table 1. Essential parameters for the optimisation of the cyclonickelation of 6-phenyl-2,20-bipyridine
(HPhbpy).
a
NiX2
Base (eq.)
Solvent
Time (h)
T (◦C)
Yield (%)
Analysis
1
2
3
4
5
6
7
A
A
A
A
B
NiBr2
NiBr2
NiBr2
NiBr2
NiBr2
no base
NEt3 (11.5)
NaHCO3 (2)
Na2CO3 (4)
Cs2CO3 (2)
Na2CO3 (3)
NaOtBu (2)
KOAc/K2CO3
(2/4)
toluene
toluene
toluene/MeOH
solid
toluene
toluene
diethyl ether
60
48
3
111 g
111 g
111 g
170
0
1.5
2.5
0
trace
19
visual b
1H NMR c
1H NMR
visual b
1
111 g
111 g
23
1H NMR
1H NMR
1H NMR
66
90
16
B
C
NiBr2
[Ni(HPhbpy)Br2]
0
8
9
C
C
[Ni(HPhbpy)Br2]
toluene
toluene
16
62
111 g
6
1H NMR
KOAc/K2CO3
(2/4)
[Ni(HPhbpy)Br2]
111 g
28
1H NMR
Ni(OAc)2.4H2O
Ni(OAc)2
-
-
-
toluene/EtOH//DME 15
111
250
180
XRD
visual b
XRD
5 d
0 e
4 f
10
11
12
A
A
A
solid
solid
1
1
Ni(OAc)2
a
Method A: Strictly direct cyclonickelation using NiBr2 or Ni(OAc)2. Method B: Cyclonickelation via in situ
b
formation of [Ni(HPhbpy)Br2]2. Method C: Starting from isolated [Ni(HPhbpy)Br2]2. The target complex has a
characteristic red colour and can be easily traced visually in the reaction solution by the naked eye. see Figures
S1–S4 in the Supplementary Materials. [Ni(Phbpy)(OAc)] was obtained. Red material recrystallised from HOAc
c
d
e
f
gave green-grey decomposed material. Solid mixture heated while evaporated, trapped by NaCN in THF, and
recrystallised from CH2Cl2, yielding [Ni(Phbpy)(CN)]. g The boiling temperature (reflux) is reported. Further details
in Table S1 in the Supplementary Materials.
During this series of experiments, we noticed the quantitative formation of the non-cyclometalated
1:1 adduct [Ni(HPhbpy)Br2]2 upon heating NiBr2 and HPhbpy in THF [50]. We were able to grow single
crystals of this compound. Single-crystal XRD revealed a binuclear structure with an almost isotropic
Ni2(µ-Br)2 diamond core with two triplet Ni(II) centres. Two other bromides are terminal ligands
completing a five-coordinated trigonal bipyramidal geometry around nickel. (Figure 1; pertinent
metrical data in Table S2 in the Supplementary Materials). In the following work, [Ni(HPhbpy)Br2]2
proved to be beneficial as a convenient, well-defined, and long-term storable form and was used as
precursor (Table 1, Entries 7–9).

Molecules 2020, 25, 997
5 of 13
Figure 1. Ellipsoid view (two asymmetric units resulting in a binuclear structure) of [Ni(HPhbpy)Br2]2
left) and crystal structure of [Ni(HPhbpy)Br2]2 viewed along the a axis (right). Ellipsoids are drawn at
the 50% probability level.
(
.
Starting from Ni(OAc)2 4H2O, the acetato complex [Ni(Phbpy)(OAc)] was obtained in traces
(Entry 10), and the crystal and molecular structure could be solved (Figure 2, crystal and molecular
data in Table S3 in the Supplementary Materials). The coordination geometry around Ni(II) is
distorted square-planar.
Figure 2. Ellipsoid view of [Ni(Phbpy)(OAc)] (left) and crystal structure viewed along the c axis (right).
Ellipsoids are drawn at the 50% probability level.
In a further experiment, anhydrous nickel acetate was used in a solid-state reaction to produce
the acetato complex, but the product could not be isolated due to the degradation by acetic acid (Entry
11). Quenching the same reaction mixture with cyanide yielded some crystals of [Ni(Phbpy)(CN)]
(Entry 12, Figure S6, Table S4 and further details in the Supplementary Materials). Unfortunately, the
crystal quality was too low for a satisfying crystal structure solution and refinement. However, the
atom connectivity is unequivocal. Thus, in contrast to Br−, acetate can obviously act as base.
Based on the encouraging 19% yield obtained from the reaction starting from the in situ formation
of [Ni(HPhbpy)Br2]2 (Table 1, Entry 6) we started a series of reactions using isolated [Ni(HPhbpy)Br2]2.
The reaction progress was monitored using UV-vis absorption spectroscopy with the spectrum of
the previously reported [Ni(Phbpy)Br] [29] as reference. Using a 1:2 ratio and equimolar amounts
(regarding the precursor) of KOAc and K2CO3, we achieved a yield of 43% within three days
of heating in toluene (Table 2). The yields further increased to 91% upon prolonged heating in
chlorobenzene, reaching 98% in 1,2-dichlorobenzene and quantitative yield in p-xylene within 25 h
(Figure 3). The use of the high-boiling benzonitrile did not yield the product. After 20 h, no yield

Molecules 2020, 25, 997
6 of 13
was observed and further heating at 200 ◦C for more than 60 h yielded a brown precipitated material
that does not contain the targeted complex. We assume that the coordinating abilities of benzonitrile
hamper the reaction by forming nitrile complexes [46], thus interfering with the formation of the
intermediate [Ni(HPhbpy)Br2]2. This is in line with low yields for Ni-catalysed C(sp2)
functionalisation of aminoquinoline in polar solvents such as DMSO, dioxane, and MeCN [51].
−
H and C(sp3)
H
−
Table 2. Solvent influence on the optimised cyclonickelation reaction of HPhbpy a.
Tb.p. (◦C)
ETN
Tbat (◦C)
Yield (%)
b
Entry
Solvent
Time (h)
13
14
15
16
17
18
19
toluene
chlorobenzene
1,2-dichlorobenzene
72
64
25
25
20
64
64
120
160
190
160
200
160
190
111
131
180
138
190
138
180
0.099
0.188
0.225
0.074
0.333
0.074
0.225
43
91
98
100
0
93
15
p-xylene
benzonitrile
p-xylene c (from NiBr2)
1,2-dichlorobenzene d (no base)
a Using [Ni(HPhbpy)Br2]2 (65 mg, 0.14 mmol), KOAc (28 mg, 0.28 mmol), and K2CO3 (39 mg, 0.54 mmol), Dean–Stark
apparatus, or activated molecular sieve. Yields as observed from UV-vis absorption measurements of the reaction
solutions were based on the reported molar extinction coefficients of the long-wavelength maximum around 510
b
c
nm of the target complex [Ni(Phbpy)Br] [29
,
30]. ENT = normalised empirical parameter of solvent polarity [52].
d
Reaction starting from anhydrous NiBr2. Reaction without added base.
100
80
60
1,2-dichlorobenzene
p-xylene
40
20
0
p-xylene, from NiBr
2
chlorobenzene
1,2-dichlorobenzene, no base
time / h
0
10
20
30
40
50
60
Figure 3. Yields of the cyclometalation reaction in various solvents, as monitored using UV-vis
absorption spectroscopy. The traces represent the reaction entries 14, 15, 16, 18 and 19 in Table 2.
A detailed look on the time-dependence of the reaction for selected examples (Figure 3) shows
that p-xylene and 1,2-dichlorobenzene reach high yields already after about 20 h, while chlorobenzene
requires at least 40 h. Using NiBr2 instead of [Ni(HPhbpy)Br2]2 for the reaction in p-xylene under
the same conditions afforded only 18% yield after 20 h but could be brought to 93% yield when
heating for 64 h. This observation is in line with the assumed pre-formation of the p-xylene-soluble
[Ni(HPhbpy)Br2]2 from insoluble NiBr2. Finally, a blank experiment in 1,2-dichlorobenzene (no external
base) delivered a mediocre 15% yield after 64 h.
3. Discussion
Summarising the experimental results shows that (i) protic solvents and water-containing Ni
salts must be avoided. Although they speed up reaction times due to perfect dissolution of the
precursor compounds especially simple Ni(II) salts, the final product is quenched, presumably forming
non-cyclometalated hexacoordinate Ni(II) species. (ii) The acetate/carbonate mixture is capable of
−
driving the C-H metalation to completion, whereas single-component bases such as CO32−, HCO3
,

Molecules 2020, 25, 997
7 of 13
−OtBu, and NEt3 promote the reaction on a trace level. (iii) The reaction proceeds preferably via the
formation of the NˆN-coordinated intermediate [Ni(HPhbpy)Br2]2. (iv) This precursor allows the use
of high boiling nonpolar solvents, while protic solvents and water-containing polar solvents, which are
necessary to dissolve the NiBr2 precursor, can be avoided.
The observation of high reaction temperatures suggests a high activation barrier for the direct
cyclonickelation of N-donor/aryl systems. Similarly, cyclonickelation to form CˆN or NˆCˆN chelates
required harsh heating [28,31,32]. High reaction temperatures seem to be the price for starting
from rather unreactive Ni(II) precursors and a not very reactive C(sp2)–H bond. In addition, the
base-assisted N–H2C(sp3)–H nickelation yielding [Ni(-CH2-N(Cy)(O)N(quinolinyl)(PEt3)] required
temperatures above 70◦ [41]. In contrast to this, the CˆNˆP nickelation in the recently reported
complex [Ni(HPh-Py-O-PR2)Br2] (R = tBu) proceeds at 50 ◦C in an hour [34]. The significantly lower
activation barrier can be tentatively explained by the following factors: (i) the P-donor brings the
Ni(II) centre closer to the C–H activation site to enable (an)agnostic interactions, since phosphorus
has a bigger covalent radius versus nitrogen (107 pm versus 71 pm), resulting in a Ni–P bond length
of approximately 2.29 Å compared with the Ni–N bond of approximately 2.04 Å; (ii) this P-donor
(decorated by two tBu groups) is a much stronger σ-donor and perhaps a better π-acceptor than the
N-site in our study. The Ni . . . C distance in our precursor is 2.97(1) Å, which is quite short compared
to the 3.039(3) Å of the phosphine complex. However, this distance is largely depending on the
angle of the freely rotating phenyl group toward the binding plane, and the values represent only
the solid state and not the molecules in solution. Moreover, the Ni–C bond in the cyclonickelated
species [Ni(Ph-Py-O-PR2)Br] [34], [Ni(Phbpy)Br] [29], and [Ni(Phbpy)OAc] (Table S3) is of the same
magnitude (approximately 1.9 Å). Therefore, the crystallographic data suggest that the difference in
the electronic properties of the P- and N-donors rather than steric effects are responsible for the much
lower activation barrier.
It is tempting to correlate the enhanced reaction efficiency with the high boiling points of
these solvents, indicating simple Arrhenius behaviour. However, the complete lack of reactivity in
benzonitrile as a solvent with a similarly high boiling point indicates that aspects of solvent polarity
and coordination ability also affect the reaction progress. This generally agrees with the recent work of
Sandford et al., who reported low cyclonickelation yields in polar-coordinating solvents [51]. In our
study, alongside the series of solvents, an increase in polarity (ENT values)
[52] leads to a decrease
in activity. This inverse relationship points to a nonpolar transition state of the cyclometalation
reaction, in stark contrast to the findings of Davies and Macgregor et al. [39], who inferred from
substituent Hammett plots a substantial accumulation of positive charge in the transition state of a
cycloruthenation reaction. Thus, in future work, we will model this reaction using density functional
theory (DFT) methods.
4. Materials and Methods
4.1. Materials
Commercially available chemicals were purchased from Sigma-Aldrich, Acros, ABCR, or
Fisher-Scientific and were used without further purification. Dry THF was obtained from distillation
over sodium/potassium alloy. The preparation of N-(1-(2-pyridyl)-1-oxo-2-ethyl)pyridinium-iodide
(Kroehnke salt) and 6-Phenyl-2,20-bipyridine (HPhbpy) is described in the Supplementary Materials.
Preparation of [Ni(HPhbpy)Br2]2 (adopted from Yang et al.) [50]: NiBr2 (328 mg, 1.50 mmol),
HPhbpy (348 mg, 1.50 mmol) in THF (125 mL) were heated under reflux for 15 h. After cooling to
room temperature, a yellow solid was collected by filtration on a glass frit, washed using diethyl
ether (3
×
10 mL), and dried in vacuo for 15 h. Yield: 72% (487 mg). Elemental analysis found (calc.
for C16H12Br2N2Ni) C 42.62 (42.63); H 2.86 (2.68); N 6.23 (6.21)%.

Molecules 2020, 25, 997
8 of 13
4.2. Cyclonickelation Experiments
General considerations: In comparison with Pt or Pd congeners, cyclometalated Ni(II) complexes
are less stable due to weaker Ni-C and Ni-N bonds [38 53]. The Ni–N bond, being also weaker than
,
Ni–P bonds, is susceptible to facile ligand substitution by oxygen donors (e.g., alcohols) even in the
case of chelating NˆN-donors. [46]. The Ni–C bond is also chemically unstable. In addition to facile
hydrolysis [46], oxygen insertion can occur in the presence of dioxygen with the formation of C-O-Ni
bonds [54,55]. Thus, the cyclonickelation in this study was conducted under N2 atmosphere in solvents
purified by distillation over Na-benzophenone ketyl (toluene or THF) or rigorously dried molecular
sieves (chlorobenzene, 1,2-dichlorobenzene, and benzonitrile).
Preparation of [Ni(Phbpy)Br] via C-H-activation: After a number of optimisation experiments
(Tables 1 and 2), the reaction was carried out as follows. Under inert atmosphere [Ni(HPhbpy)Br2]2
(112.7 mg, 0.25 mmol, 1 eq.) was suspended in p-xylene (140 mL). After adding KOAc (25.5 mg,
0.25 mmol, 1 eq.) and K2CO3 (34.6 mg, 0.25 mmol, 1 eq.), the mixture was heated to reflux. For the
separation of forming water, the reaction flask was interconnected by a glass frit filled with activated
molecular sieve to the reflux condenser. After 25 h, the mixture was allowed to cool to room temperature,
and the solvent was evaporated under reduced pressure. The deep red residue was dissolved in dry
CH2Cl2 (100 mL) and filtered through a plug of Na2SO4/Celite. After evaporating the solvent, the
product was received as a red powder. The yield was determined from the UV-vis absorption band of
the product [Ni(Phbpy)Br] in THF (see Figure S5). The isolated material (183 mg, 0.495 mmol, 99%)
was identified through its 1H NMR spectrum [29,30].
From previous work, it was known that the [Ni(Phbpy)Br] is somewhat stable and soluble in
CH2Cl2 (1H NMR) and THF (reaction medium, crystallisation solvent). The complex has a characteristic
red colour [29,30]. In the course of our investigation, we found that [Ni(Phbpy)Br] is insoluble in
diethyl ether. Profiting from its moderate solubility and stability in acetone, 1H and 1H-1H COSY NMR
spectra was measured in acetone-d6. Additionally, the compound can be recrystallised by the vapour
diffusion of diethyl ether to CH2Cl2 or acetone at room temperature without special precautions. At the
final stage, the red crystals can be quickly washed using methanol to eliminate the contaminant (yellow
powder, presumably NiBr2). Yet, [Ni(Phbpy)Br] degrades in methanol solution, as can be seen from the
colour change from red to yellow and green, and 1H NMR (CD3OD) gave very broad signals indicating
the formation of paramagnetic species. Details on the cyclometalation reactions yielding [Ni(Phbpy)X]
(X = Br, OAc, CN) through base-assisted C-H activation (direct cyclometalation) are available in the
Supplementary Materials.
Instrumentation: 1H, 13C and 19F NMR spectra were recorded on a Bruker Avance II 300 MHz
(1H: 300 MHz, 13C: 75 MHz, 19F: 282 MHz, Ettlingen, Germany) equipped with a double resonance
(BBFO) 5 mm observe probehead with z-gradient coil or on Bruker Avance 400 spectrometer (1H:
400 MHz, 13C: 100 MHz, Ettlingen, Germany). Chemical shifts were relative to TMS. UV–vis absorption
spectra were recorded on a Varian Cary 05E spectrophotometer (Troisdorf, Germany). Elemental
analyses were obtained using a HEKAtech CHNS EuroEA 3000 analyzer (Wegberg, Germany).
EI-MS spectra were measured using a Finnigan MAT 95 mass spectrometer (Bremen, Germany).
Simulations were performed using ISOPRO 3.0 (Sunnyvale, CA, USA). Single crystal structure analysis
(XRD): Measurement of [Ni(HPhbpy)Br2]2 was performed at 170(2) K using an IPDS IIT (STOE
and Cie., Darmstadt, Germany) diffractometer, with Mo-K
α radiation (λ = 0.71073 Å) employing
ω-ϕ θ
-2 scan technique. The structure was solved by direct methods using SIR 2014 [56], and
2
refinement was carried out with SHELXL 2018 employing full-matrix least-squares methods on F0
2
≥
2
σ
(F0 ) [57]. The numerical absorption corrections (X-RED V1.22; Stoe & Cie, 2001, Darmstadt,
Germany) were performed after optimising the crystal shapes using X-SHAPE V1.06 (Stoe & Cie, 1999,
Darmstadt, Germany) [58]. The non-hydrogen atoms were refined with anisotropic displacement
parameters without any constraints. The hydrogen atoms were included by using appropriate riding
models. Measurement of [Ni(Phbpy)(OAc)] was conducted at 150 K. The X-ray diffraction data were
collected with Bruker Kappa Apex-II (Ettlingen, Germany) diffractometer by using Mo-Kα radiation

Molecules 2020, 25, 997
9 of 13
(λ = 0.71073 Å). The APEX2 [59] program package was used for cell refinements and data reduction.
Using OLEX2 [60], the structure was solved with the SHELXS program structure solution program using
direct methods and refined with the SHELXL refinement package using least squares minimisation [61].
A numerical absorption correction (SADABS) [62] was applied to all data. The non-hydrogen atoms
were refined with anisotropic displacement parameters without any constraints. All H atoms were
positioned geometrically and constrained to ride on their parent atoms, with C
−
H = 0.95 0.99 Å and
−
Uiso = 1.2 1.5 Ueq (parent atom). Data of both structure solutions and refinements can be obtained
−
free of charge at https://summary.ccdc.cam.ac.uk/structure-summary-form or from the Cambridge
Crystallographic Data Centre, 12 Union Road, Cambridge, CB2 1EZ, UK (fax: +44-1223-336-033 or
e-mail: deposit@ccdc.cam.ac.uk). CCDC 1956740 ([Ni(HPhbpy)Br2]2) and 1956739 ([Ni(Phbpy)(OAc)]).
5. Conclusions
Herein, we have addressed the central problem of a direct metalation of arene C(sp2)-H functions
using rather unreactive Ni(II) precursors such as NiBr2 or Ni(OAc)2, which lifts the limitation of
user-friendly metalation routines to the 4d and 5d rows. The target organonickel complex [Ni(Phbpy)Br]
(HPhbpy = 6-phenyl-2,20-bipyridine), which previously was accessible only from C-Br activation
through a Ni(0) precursor, has now been obtained for the first time through C-H activation in a direct,
base-assisted cyclonickelation. Optimal reaction conditions were identified to require (i) anhydrous
precursor materials, ii) elevated temperature, (iii) nonpolar media (p-xylene, (di)chlorobenzene),
and (iv) the presence of carbonate and acetate as a synergetic base pair. On the other hand, the
di-nitrogen coordination step of NiX2 (X = Br, OAc) proceeds slowly in nonpolar media. Therefore,
[Ni(HPhbpy)Br2]2 obtained by Ni(II) coordination in THF proved to be a convenient precursor for the
direct, base-assisted metallation. The concerted fulfilment of all four criteria allows quantitative direct
C-H activation on a synthetically reasonable timescale.
Although the reaction requires high temperatures > 100 ◦C, overall, the described quantitative
direct nickelation appears superior to previous protocols with respect to a potential diversification.
Variation of the substitution pattern of the metalated arene including deuteration and DFT modelling
is subject of ongoing work. The high efficiency motivates a future extension to the more challenging
cyclometalation of C(sp3)-H protoligands, which was elegantly demonstrated recently by Schafer, Love
et al. for the formation of [Ni(-CH2-N(Cy)C(O)N(quinoline-8-yl)(PEt3)] [41]. While for the noble metals
Ru, Ir, Rh, or Pd, the base-assisted C(sp2)-H deprotonation and metalation using acetate/carbonate has
been established for a few years [38
base metals of the 3d series.
–40] our study represents an important step into the world of the
Supplementary Materials: Details on the C-H activation reactions and synthesis of the new complexes, NMR
spectra, pictures of the crystal and molecular structure of [Ni(Phbpy)(CN)] and UV-vis absorption spectra with
tables of important structural parameters of [Ni(HPhbpy)Br2]2, [Ni(Phbpy)(OAc)], and [Ni(Phbpy)(CN)] are
1
available (see Supplementary Materials). The following are available online: Figure S1. 600 MHz H NMR
1
spectrum of [Ni(Phbpy)Br] in CD2Cl2. Figure S2. 400 MHz H NMR spectrum of [Ni(Phbpy)Br] in CD2Cl2.
1
1
Figure S3. 400 MHz H NMR spectrum of [Ni(Phbpy)Br] in acetone-d6. Figure S4. 400 MHz H-1H COSY
spectrum of [Ni(Phbpy)Br] in acetone-d6. Figure S5. UV-vis absorption spectra recorded during the reaction of
[Ni(HPhbpy)Br2]2 in p-xylene in the presence of KOAc/K2CO3. Figure S6. Molecular structure of [Ni(Phbpy)(CN)]
(left) and crystal structure viewed along the c axis (right). Note that the structure could not be solved satisfactorily.
These plots show only preliminary results. Table S1. Parameters for the optimisation of the cyclonickelation
of HPhbpy. Table S2. Crystal data, refinement parameters, and important bond parameters of the structure of
the binuclear complex [Ni(HPhbpy)Br2]2. Table S3. Crystal data, structure refinement, and important bond
parameters for [Ni(Phbpy)(OAc)]. Table S4. Crystal data for [Ni(Phbpy)(CN)].
Author Contributions: Conceptualisation, A.K. and V.S.; methodology, A.K. and G.H.; syntheses and analysis,
V.S., N.V. and A.S.; crystal structures, A.S.; writing, review, and editing, V.S., A.K., and G.H.; visualisation, N.V.;
funding acquisition, A.K. All authors have read and agreed to the published version of the manuscript.
Funding: The Deutsche Forschungsgemeinschaft DFG KL1194/15-1 is acknowledged for funding of this project.
Acknowledgments: G.H. thanks the DFG for financial support within the cluster of excellence UNICAT and SFB
840 (Von partikulären Nanosystemen zur Mesotechnologie) and Martin Kaupp (TU Berlin) for generous support.

Molecules 2020, 25, 997
10 of 13
We also grateful to Igor Koshevoy, Department of Chemistry, University of Eastern Finland, Joensuu for support
and helpful discussions.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
4.
5.
Labinger, J.A. Platinum-Catalyzed C
[PubMed]
Cope, A.C.; Siekman, R.W. Formation of Covalent Bonds from Platinum or Palladium to Carbon by Direct
Substitution. J. Am. Chem. Soc. 1965, 87, 3272–3273. [CrossRef]
Cope, A.C.; Friedrich, E.C. Electrophilic Aromatic Substitution Reactions by Platinum(II) and Palladium(II)
Chlorides on N,N-Dimethylbenzylamines. J. Am. Chem. Soc. 1968, 90, 909–913. [CrossRef]
Chassot, L.; Mueller, E.; Von Zelewsky, A. cis-Bis(2-phenylpyridine)platinum(II) (CBPPP): A Simple Molecular
Platinum Compound. Inorg. Chem. 1984, 23, 4249–4253. [CrossRef]
Constable, E.C.; Henney, R.P.G.; Leese, T.A.; Tocher, D.A. Cyclometallation Reactions of
6-Phenyl-2,2’-bipyridine; a Potential C,N,N-Donor Analogue of 2,2’:6’,2”-Terpyridine. Crystal and Molecular
Structure of Dichlorobis(6-phenyl-2,2’-bipyridine)ruthenium(II). J. Chem. Soc., Dalton Trans. 1990, 443–449.
[CrossRef]
−
H Functionalization. Chem. Rev. 2017, 117, 8483–8496. [CrossRef]
6.
Constable, E.C.; Henney, R.P.G.; Leese, T.A.; Tocher, D.A. Cyclopalladated and Cycloplatinated Complexes
of 6-Phenyl-2,20-bipyridine: Platinum-Platinum Interactions in the Solid State. J. Chem. Soc. Chem. Commun.
1990, 513–515. [CrossRef]
7.
8.
9.
Berenguer, J.R.; Lalinde, E.; Moreno, M.T. Luminescent cyclometalated-pentafluorophenyl PtII, PtIV and
heteropolynuclear complexes. Coord. Chem. Rev. 2018, 366, 69–90. [CrossRef]
Tang, M.-C.; Chan, A.K.-W.; Chan, M.-Y.; Yam, V.W.-W. Platinum and Gold Complexes for OLEDs. Top. Curr.
Chem. (Z) 2016, 374, 1–43. [CrossRef]
Kalinowski, J.; Fattori, V.; Cocchi, M.; Williams, J.A.G. Light-emitting devices based on organometallic
platinum complexes as emitters. Coord. Chem. Rev. 2011, 255, 2401–2425. [CrossRef]
10. Williams, J.A.G. Metal complexes of pincer ligands: Excited states, photochemistry, and luminescence.
Top. Organomet. Chem. 2011, 40, 89–130.
11. Yang, S.; Meng, F.; Wu, X.; Yin, Z.; Liu, X.; You, C.; Wang, Y.; Su, S.; Zhu, W. Dinuclear platinum(II) complex
dominated by a zig-zag-type cyclometalated ligand: A new approach to realize high-efficiency near infrared
emission. J. Mater. Chem. C 2018, 6, 5769–5777. [CrossRef]
12. Sivchik, V.; Sarker, R.K.; Liu, Z.-Y.; Chung, K.-Y.; Grachova, E.V.; Karttunen, A.J.; Chou, P.-T.; Koshevoy, I.O.
Improvement of the Photophysical Performance of Platinum-Cyclometalated Complexes in Halogen-Bonded
Adducts. Chem. Eur. J. 2018, 24, 11475–11484. [CrossRef]
13. Soellner, J.; Strassner, T. The “Enders Triazole” Revisited: Highly Efficient, Blue Platinum(II) Emitters.
Organometallics 2018, 37, 1821–1824. [CrossRef]
14. Schulze, B.; Friebe, C.; Jäger, M.; Görls, H.; Birckner, E.; Winter, A.; Schubert, U.S. PtII Phosphors with
Click-Derived 1,2,3-Triazole-Containing Tridentate Chelates. Organometallics 2018, 37, 145–155. [CrossRef]
15. Sesolis, H.; Chan, C.K.-M.; Gontard, G.; Fu, H.L.-K.; Yam, V.W.-W.; Amouri, H. Dinuclear (N∧C∧N)
Pincer Pt(II) Complexes with Bridged Organometallic Linkers: Synthesis, Structures, Self-Aggregation, and
Photophysical Properties. Organometallics 2017, 36, 4794–4801. [CrossRef]
16. Schneider, L.; Sivchik, V.; Chung, K.-Y.; Chen, Y.-T.; Karttunen, A.J.; Chou, P.-T.; Koshevoy, I.O. Cyclometalated
Platinum(II) Cyanometallates: Luminescent Blocks for Coordination Self-Assembly. Inorg. Chem. 2017, 56,
4459–4467. [CrossRef] [PubMed]
17. Li, K.; Tong, G.S.M.; Wan, Q.; Cheng, G.; Tong, W.-Y.; Ang, W.-H.; Kwong, W.-L.; Che, C.-M. Highly
phosphorescent platinum(II) emitters: Photophysics, materials and biological applications. Chem. Sci. 2016
,
7, 1653–1673. [CrossRef]
18. Solomatina, A.I.; Chelushkin, P.S.; Abakumova, T.O.; Zhemkov, V.A.; Kim, M.; Bezprozvanny, I.; Gurzhiy, V.V.;
Melnikov, A.S.; Anufrikov, Y.A.; Koshevoy, I.O.; et al. Reactions of Cyclometalated Platinum(II)
[Pt(N∧C)(PR3)Cl] Complexes with Imidazole and Imidazole-Containing Biomolecules: Fine-Tuning of
Reactivity and Photophysical Properties via Ligand Design. Inorg. Chem. 2019, 58, 204–217. [CrossRef]

Molecules 2020, 25, 997
11 of 13
19. Zhang, Y.; Luo, Q.; Zheng, W.; Wang, Z.; Lin, Y.; Zhang, E.; Lü, S.; Xiang, J.; Zhao, Y.; Wang, F. Luminescent
cyclometallated platinum(II) complexes: Highly promising EGFR/DNA probes and dual-targeting anticancer
agents. Inorg. Chem. Front. 2018, 5, 413–424. [CrossRef]
20. Chow, P.-K.; Cheng, G.; Tong, G.S.M.; Ma, C.; Kwok, W.-M.; Ang, W.-H.; Chung, C.Y.-S.; Yang, C.; Wang, F.;
Che, C.-M. Highly luminescent palladium(II) complexes with sub-millisecond blue to green phosphorescent
excited states. Photocatalysis and highly efficient PSF-OLEDs. Chem. Sci. 2016, 7, 6083–6098. [CrossRef]
21. Fleetham, T.; Li, G.; Li, J. Phosphorescent Pt(II) and Pd(II) Complexes for Efficient, High-Color-Quality, and
Stable OLEDs. Adv. Mater. 2017, 29, 1601861. [CrossRef]
22. Hartwell, G.E.; Lawrence, R.V.; Smas, M.J. The Formation of Palladium(II)- and Platinum(II)-Carbon Bonds
by Proton Abstraction from Benzo[h]quinoline and 8-Methylquinoline. J. Chem. Soc., Chem. Commun. 1970
,
912. [CrossRef]
23. Dick, A.R.; Hull, K.L.; Sanford, M.S. A Highly Selective Catalytic Method for the Oxidative Functionalization
of C-H Bonds. J. Am. Chem. Soc. 2004, 126, 2300–2301. [CrossRef] [PubMed]
24. Thu, H.-Y.; Yu, W.-Y.; Che, C.-M. Intermolecular Amidation of Unactivated sp2 and sp3 C-H Bonds via
Palladium-Catalyzed Cascade C-H Activation/Nitrene Insertion. J. Am. Chem. Soc. 2006, 128, 9048–9049.
[CrossRef] [PubMed]
25. Christman, W.E.; Morrow, T.J.; Arulsamy, N.; Hulley, E.B. Absolute Estimates of PdII(
η
2-Arene) C
H Acidity.
−
Organometallics 2018, 37, 2706–2715. [CrossRef]
26. Kleiman, J.P.; Dubeck, M. The preparation of cyclopentadienyl [o-(phenylazo)phenyl]nickel. J. Am. Chem.
Soc. 1963, 85, 1544–1545. [CrossRef]
27. Grove, D.M.; van Koten, G.; Ubbels, H.J.C.; Zoet, R. Organonickel(II) Complexes of the Terdentate
Monoanionic Ligand o,o’-Bis[(dimethylamino)methyl]phenyl (N-C-N). Syntheses and the X-ray Crystal
Structure of the Stable Nickel(II) Formate [Ni(N-C-N)O2CH]. Organometallics 1984, 3, 1003–1009. [CrossRef]
28. Volpe, E.C.; Chadeayne, A.R.; Wolczanski, P.T.; Lobkovsky, E.B. Heterolytic CH-bond activation in the
synthesis of Ni{(2-aryl-
[CrossRef]
κ κN}2 and derivatives. J. Organomet. Chem. 2007, 692, 4774–4783.
C2)pyridine-
29. Klein, A.; Rausch, B.; Kaiser, A.; Vogt, N.; Krest, A. The cyclometalated nickel complex [(Phbpy)NiBr] (Phbpy–
= 2,20-bipyridine-6-phen-2-yl)—Synthesis, spectroscopic and electrochemical studies. J. Organomet. Chem.
2014, 774, 86–93. [CrossRef]
30. Sandleben, A.; Vogt, N.; Hörner, G.; Klein, A. On the Redox Series of Cyclometalated Nickel Complexes
[Ni((R)Ph(R’)bpy)Br]+/0/-/2- (H-(R)Ph(R’)bpy = substituted 6-phenyl-2,20-bipyridine). Organometallics 2018
37, 3332–3341. [CrossRef]
,
31. Shao, D.-D.; Niu, J.-L.; Hao, X.-Q.; Gong, J.-F.; Song, M.-P. Neutral and cationic chiral NCN pincer nickel(II)
complexes with 1,3-bis(20-imidazolinyl)benzenes: Synthesis and characterization. Dalton Trans. 2011, 40,
9012–9019. [CrossRef] [PubMed]
32. Cloutier, J.P.; Vabre, B.; Moungang-Soum
Pincer Complexes of Nickel. Organometallics 2015, 34, 133–145. [CrossRef]
33. Yang, C.; Wu, W.-D.; Zhao, L.; Wang, M.-X. Macrocyclic Aryl Nickel(II) Complexes: Synthesis, Structure,
and Reactivity Studies. Organometallics 2015, 34, 5167–5174. [CrossRef]
é, B.; Zargarian, D. Synthesis and Reactivities of New NCN-Type
−
34. Jongbloed, L.S.; García-López, D.; van Heck, R.; Siegler, M.A.; Carbó
, J.J.; van der Vlugt, J.I. Arene C(sp2)-H
Metalation at NiII Modeled with a Reactive PONCPh Ligand. Inorg. Chem. 2016, 55, 8041–8047. [CrossRef]
[PubMed]
35. Jagtap, R.A.; Soni, V.; Punji, B. Expeditious and Solvent-Free Nickel-Catalyzed C H Arylation of Arenes and
−
Indoles. ChemSusChem 2017, 10, 2242–2248. [CrossRef] [PubMed]
36. Xu, H.; Muto, K.; Yamaguchi, J.; Zhao, C.; Itami, K.; Musaev, D.G. Key Mechanistic Features of Ni-Catalyzed
H/C O Biaryl Coupling of Azoles and Naphthalen-2-yl Pivalates. J. Am. Chem. Soc. 2014, 136, 14834–14844.
C
−
−
[CrossRef]
37. Ackermann, L. Carboxylate-Assisted Transition-Metal-Catalyzed C
−H Bond Functionalizations: Mechanism
and Scope. Chem. Rev. 2011, 111, 1315–1345. [CrossRef]
38. Davies, D.L.; Macgregor, S.A.; McMullin, C.L. Computational Studies of Carboxylate-Assisted C-H Activation
and Functionalization at Group 8-10 Transition Metal Centres. Chem. Rev. 2017, 117, 8649–8709. [CrossRef]

Molecules 2020, 25, 997
12 of 13
39. Alharis, R.A.; McMullin, C.L.; Davies, D.L.; Singh, K.; Macgregor, S.A. Understanding Electronic Effects
on Carboxylate-Assisted C–H Activation at Ruthenium: The Importance of Kinetic and Thermodynamic
Control. Faraday Discuss. 2019, 220, 386–403. [CrossRef]
40. Alharis, R.A.; McMullin, C.L.; Davies, D.L.; Singh, K.; Macgregor, S.A. The Importance of Kinetic and
Thermodynamic Control when Assessing Mechanisms of Carboxylate-Assisted C H Activation. J. Am.
−
Chem. Soc. 2019, 141, 8896–8906. [CrossRef]
41. Beattie, D.D.; Grunwald, A.C.; Perse, T.; Schafer, L.L.; Love, J.A. Understanding Ni(II)-Mediated C(sp3)–H
Activation: Tertiary Ureas as Model Substrates. J. Am. Chem. Soc. 2018, 140, 12602–12610. [CrossRef]
42. Rej, S.; Ano, Y.; Chatani, N. Bidentate Directing Groups: An Efficient Tool in C–H Bond Functionalization
Chemistry for the Expedient Construction of C–C Bonds. Chem. Rev. 2020. [CrossRef] [PubMed]
43. Sambiagio, C.; Schönbauer, D.; Blieck, R.; Dao-Huy, T.; Pototschnig, G.; Schaaf, P.; Wiesinger, T.; Zia, M.F.;
Wencel-Delord, J.; Besset, T.; et al. A comprehensive overview of directing groups applied in metal-catalysed
C–H functionalisation chemistry. Chem. Soc. Rev. 2018, 47, 6603–6743. [CrossRef] [PubMed]
44. Kommagalla, Y.; Chatani, N. Cobalt(II)-catalyzed CH functionalization using an N,N0-bidentate directing
group. Coord. Chem. Rev. 2017, 350, 117–135. [CrossRef]
45. Tang, H.; Zhou, B.; Huang, X.-R.; Wang, C.; Yao, J.; Chen, H. Origins of Selective C(sp2)
−
H Activation Using
Experimental
Transition Metal Complexes with N,N-Bidentate Directing Groups: A Combined Theoretical
Study. ACS Catal. 2014, 4, 649–656. [CrossRef]
−
46. Feth, M.P.; Klein, A.; Bertagnolli, H. Investigation of the ligand exchange behaviour of square planar nickel(II)
complexes by X-ray absorption spectroscopy and X-ray diffraction. Eur. J. Inorg. Chem. 2003, 839–852.
[CrossRef]
47. Sun, H.-Y.; Gorelsky, S.E.; Stuart, D.R.; Campeau, L.-C.; Fagnou, K. Mechanistic Analysis of Azine N-Oxide
Direct Arylation: Evidence for a Critical Role of Acetate in the Pd(OAc)2 Precatalyst. J. Org. Chem. 2010, 75,
8180–8189. [CrossRef]
48. Garica-Cuadrado, D.; de Mendoza, P.; Braga, A.A.C.; Maseras, F.; Echavarren, A.M. Proton-Abstraction
Mechanism in the Palladium-Catalyzed Intramolecular Arylation: Substituent Effects. J. Am. Chem. Soc.
2007, 129, 6880–6886. [CrossRef]
49. Raamata, E.; Kaupmeesa, K.; Ovsjannikova, G.; Trummalb, A.; Kütta, A.; Saamea, J.; Koppela, I.; Kaljuranda, I.;
Lippinga, L.; Rodimaa, T.; et al. Acidities of strong neutral Brønsted acids in different media. J. Phys. Org.
Chem. 2013, 26, 162–170. [CrossRef]
50. Yang, P.; Yang, Y.; Zhang, C.; Yang, X.J.; Hu, H.M.; Gao, Y.; Wu, B. Synthesis, structure, and catalytic
ethylene oligomerization of nickel(II) and cobalt(II) complexes with symmetrical and unsymmetrical
2,9-diaryl-1,10-phenanthroline ligands. Inorg. Chim. Acta 2009, 362, 89–96. [CrossRef]
51. Roy, P.; Bour, J.R.; Kampf, J.W.; Sanford, M.S. Catalytically Relevant Intermediates in the Ni-Catalyzed
C(sp2)–H and C(sp3)–H Functionalization of Aminoquinoline Substrates. J. Am. Chem. Soc. 2019, 141,
17382–17387. [CrossRef]
52. Reichardt, C.; Welton, T. Solvents and Solvent Effects in Organic Chemistry, 4th ed.; WILEY-VCH Verlag GmbH
& Co. KGaA: Weinheim, Germany, 2011; p. 455.
53. Hartwig, J.F. Organotransition Metal Chemistry: From Bonding to Catalysis; University Science Books: Millvalley,
CA, USA, 2010; p. 9.
54. Pattanayak, P.; Pratihar, J.L.; Patra, D.; Burrows, A.; Mohan, M.; Chattopadhyay, S.; Lal Pratihar, J.; Patra, D.;
Burrows, A.; Mohan, M.; et al. Regiospecific ortho-aromatic hydroxylation via cyclonickelation using
hydrogen peroxide and other oxygen donors: Synthesis of metalloazosalophens. Eur. J. Inorg. Chem. 2007
2007, 4263–4271. [CrossRef]
,
55. Sripothongnak, S.; Barone, N.; Ziegler, C.J. C–H bond activation and ring oxidation in nickel
carbahemiporphyrazines. Chem. Commun. 2009, 30, 4584–4586. [CrossRef] [PubMed]
56. Burla, M.C.; Caliandro, R.; Carrozzini, B.; Cascarano, G.L.; Cuocci, C.; Giacovazzo, C.; Mallamo, M.;
Mazzone, A.; Polidori, G. Crystal structure determination and refinement via SIR2014. J. Appl. Crystallogr.
2015, 48, 306–309. [CrossRef]
57. Sheldrick. G.M. SHELXL 2016. Acta Crystallogr., Sect. A: Found. Crystallogr. 2008, 64, 112–122.
58. X-RED32 1.31 & X-SHAPE; Version 1.06; STOE & Cie GmbH: Darmstadt, Germany, 2006.
59. APEX2—Software Suite for Crystallographic Programs; Bruker AXS, Inc.: Madison, WI, USA, 2010.

Molecules 2020, 25, 997
13 of 13
60. Dolomanov, O.V.; Bourhis, L.J.; Gildea, R.J.; Howard, J.A.K.; Puschmann, H. OLEX2: A Complete Structure
Solution, Refinement and Analysis Program. J. Appl. Crystallogr. 2009, 42, 339–341. [CrossRef]
61. Sheldrick, G.M. Crystal Structure Refinement with SHELXL. Acta Crystallogr. Sect. C: Struct. Chem. 2015, 71,
3–8. [CrossRef]
62. Sheldrick, G.M. SADABS-2008/1—Bruker AXS Area Detector Scaling and Absorption Correction; Bruker AXS,
Inc.: Madison, WI, USA, 2008.
Sample Availability: Samples of the compounds [Ni(Phbpy)Br], [Ni(HPhbpy)Br2]2, and [Ni(Phbpy)(OAc)] are
available from the authors.
©
2020 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
