An excellently stable heterovalent copper–organic
framework based on Cu4I4 and Cu(COO)2N2 SBUs: The
catalytic performance for CO2 cycloaddition reaction and
Knoevenagel condensation reaction
Feng Jin,a*
a Experiment Management Center, Dezhou University, Dezhou 253023, Shandong.
Corresponding Author: Feng Jin
E-mail address: dzjfeng@163.com

2
Abstract
A novel 3D heterovalent Cu-based MOF, [Cu2Cu4I4(ANA)4(DMF)4]n (denoted as
complex 1), was successfully designed and synthesized by the self-assembly of CuI and
5-aminonicotinic acid (HANA) under the solvothermal synthesis. The prepared sample
has the fascinating structure and was analysed in detail by lots of testing methods. Due
to the excellent stability and various catalytic sites, this material can catalyse CO2
cycloaddition reaction and Knoevenagel condensation reaction; meanwhile, complex 1
has outstanding recyclability and keep catalytic performance at least four cycles.
Keywords: heterovalent copper-organic framework; heterogeneous catalyst; stability;
CO2 cycloaddition reaction; Knoevenagel condensation reaction.
Metal–organic frameworks (MOFs) are a rapidly developing inorganic-organic hybrid
crystals,[1-3] which have been attracted a lot of interest due to their plentiful structures
and potentially actual applications, such as gas sorption/separation,[4-6] immobilizing
enzyme,[7,8] luminescence sensor,[9-11], optical device,[12-14] and heterogeneous
catalysis[15,16]. Contrast to traditional materials, MOFs have various unique properties
and merits, especially structural diversity, designability, and modification.[17-19] From
the previous researches, MOFs can be well designed and synthesized by the
coordination assembly of various metal ions/clusters and organic ligands.[20-23]
Meanwhile, diverse factors from internal and external environments all can affect the
crystal textures, such as pH value, temperature, pressure, template, solvent, and
countervailing anion.[24-27] Also, organic linkers play a vital role in the preparation of
MOFs, especially linkers with multifarious coordination sites of N and O donors,
because they are able to provide a variety of self-assembly configurations with metal
nodes to generate fascinating structures with unique properties.[28-30] Recently, MOFs
based on metal halides (especially copper(I) halides) as secondary building unit (SBU)
have been attracted lots of considerable attentions due to their attractive structures and
functional properties.[31-33] CuI-based SBUs offer a series of geometrically diverse

3
structural motifs, including the dimeric rhomboid [Cu2I2], the tetrameric cubane-like
[Cu4I4], the hexagonal-prism-shaped [Cu6I6], the zigzag [CuxIy]n chain, etc.[34-37] CuI
can be implemented as the metal source to construct MOFs, which is not only attributed
to the formation of various CuxIy clusters but also the easy conversation of Cu2+ ions
from Cu+ ions in air by the oxidation process in suit.[38] Cu2+ ions are easy to coordinate
with −COO− to form Cu(CO2)n SBUs;[39] meanwhile, Cu+ and I− ions can be linked with
N donors to generate much more stable [CuxIy]n SBUs.[40-44] It is significantly important
to implement suitable building linkers to synthesize heterovalent copper–organic
frameworks with fascinating textures and excellent properties. Hence, organic linkers
containing pyridine and –COOH are good candidates to assemble with CuI to construct
such MOFs.
According to the above discussions, we chose a 5-aminonicotinic acid (HANA) as
the organic linker, which has pyridine, carboxylic acid, and amino functional group.
CuI is the metal source to coordinate with HANA to prepare MOFs. Herein, a novel
three-dimensional (3D) heterovalent Cu–organic framework based on Cu4I4 and
Cu(COO)2N2 SBUs, formula as [Cu2Cu4I4(ANA)4(DMF)4]n (complex 1), was
successfully prepared under the solvothermal approach. The as-synthesized 1 possesses
a fascinating structure, which was analysed in detail by various testing methods. By
virtue of the excellent stability and lots of catalytic sites, complex 1 is a heterogeneous
catalyst for the CO2 cycloaddition reaction and Knoevenagel condensation reaction. In
addition, complex 1 owns the remarkable recyclability and retains the catalytic
performance at least four cycles.
From the single crystal X-ray diffraction analysis, it evidently shows that complex 1
belongs to the I41/a space group of the tetragonal system. As shown in Fig. 1a, the
asymmetrical unit of complex 1 has a half Cu atom, another Cu atom, one I atom, one
ANA– bridging organic linker, and a terminated DMF molecular. The ANA– bridging
linker has only one coordination fashion as 3-1: 1: 1 to connect with three Cu atoms
by pyridine, carboxylic acid, and amino functional groups (Fig. 1b). Notably,
Cu(COO)2N2 SBU can be found in complex 1 and the Cu2+ ion exists in this SBU,

4
which is attributed to the oxidation of Cu+ in air (Fig. 1c). On the other hand, the Cu+
in Cu4I4 SBU can coordinate with four N donors of pyridines from four ANA– bridging
linkers (Fig. 1d). The structure clearly illustrates that the heterovalent Cu–organic
framework is successfully prepared as expected. Finally, Cu(COO)2N2 and Cu4I4 SBUs
can be further connected with each other by these ANA– linkers to construct a novel
3D framework (Fig. 1e).
Fig. 1 (a) The asymmetrical unit; (b) the coordination mode of organic linker; (c, d) the coordination
environments of CuO3N2 and Cu4I4; and (e) viewing of the 3D structure in complex 1 (all H atoms
are removed for clarity).
As displayed in Fig. 2a, the thermogravimetric (TG) data of experimental complex
1 obviously can keep a platform and no any weight loss before ~250 °C, but a
significant weight loss can be found after increasing the heating temperature due to
losing the coordinated DMF molecules. Finally, the main skeleton collapses after the
temperature increases to ~520 °C. From the powder X-ray diffraction (PXRD) patterns
of fresh as-synthesized sample, these characteristic peaks are consistent well with those
of simulated patterns to prove the pure phase and uniformity (Fig. 2b). To further
estimate the stability, the as-synthesized samples were immersed in air for one month,
in water for one week at room temperature, after heating at 250 °C for one week, and
in pH aqueous solutions of pH = 3 and 13 at room temperature for one day, respectively.
Also, the corresponding PXRD patterns clearly show that the skeleton can be kept very

5
well after treating with these conditions. The result illustrates complex 1 has the
excellent physicochemical stability.
Fig. 2 (a) The TG data of as-synthesized complex 1; and (b) the PXRD profile of simulated and
experiment complex 1 after treating with various conditions.
Benefit from the excellent stability and various metal sites as Lewis acid sites,
complex 1 may be used as a potential heterogeneous catalyst for chemical fixation of
CO2 and epoxides to cyclic carbonates.[45-50] The prepared crystals were dried in air for
1 day before processing catalytic reactions. Epoxides (20 mmol), n-Bu4NBr (0.3 mmol),
and complex 1 (100 mg) were putted in a high-pressure reaction with 1 MPa CO2, which
was heated at 80 °C for 8 hours. The product of cyclic carbonate can be calculated by
the GC measurement with n-dodecane as the additive internal standard. Catalytic results
are all listed in Table 1. As seen in entries 1 and 2, the individual component for
epoxypropane and CO2 only show the low yields of complex 1 (~11%) or n-Bu4NBr
(~19%), respectively. However, a higher catalytic yield of >99% can be detected by
using complex 1 and n-Bu4NBr in the reaction system (entry 3). The results show that
this CO2 cycloaddition reaction almost can’t be efficiently catalysed by itself and can
fully react in the presence of complex 1 and n-Bu4NBr because of their synergistically
catalytic effect of metal centres as catalytic sites in complex 1 and n-Bu4NBr as co-
catalysis. To investigate the catalytic performance for different epoxides, complex 1
and n-Bu4NBr were both used to catalyse these reactions at the same reaction condition.

6
The yield of epichlorohydrin and CO2 can react completely (entry 4), but the other
catalytic yields obviously decrease to ~93%, ~87%, and ~72% for 1,2-epoxy-3-
allyloxypropane, benzyl phenylglycidyl ether, and tert-butyl glycidyl ether,
respectively (entries 5, 6 and 7), which may be attributed to the increasing molecule
sizes and different electronic effects of functional groups.[51-53] To estimate the
recyclability of complex 1, the cyclic sample can well keep the catalytic ability for
chemical transformation of epoxypropane and CO2 at least four cycles (entry 8 and Fig.
3a). The PXRD pattern of complex 1 after reusing four times is consistent well with
that of pristine complex 1 to prove the excellent stability of complex 1 in the successive
catalytic experiments (Fig. 3b).
Table 1. The catalytic yields of CO2 and various epoxides.
O
O
CO2
O
O
1 MPa
R
R
Entry
1
Catalyst
Epoxide
Product
Yield
%
O
O
O
O
O
O
complex 1
11
O
O
O
O
O
O
2
3
n-Bu4NBr
19
complex 1 + n-
>99
Bu4NBr

7
O
4
5
6
complex 1 + n-
>99
93
O
Cl
Bu4NBr
O
O
Cl
O
complex 1 + n-
O
O
Bu4NBr
O
O
O
O
O
complex 1 + n-
87
O
Bu4NBr
O
O
O
O
7
8
complex 1 + n-
72
O
Bu4NBr
O
O
O
O
O
O
Reused complex
>99
1 + n-Bu4NBr
O
O
Fig. 3 Reusability (a) and PXRD pattern (b) of complex 1.
According to the previous reported MOFs for catalyzing this reaction,[54-58] the

8
assumptive reaction can be deduced as follows: Firstly, this reaction is caused by the
interaction between the O atom in epoxide ring and the metal site in complex 1.
Subsequently, the epoxide ring will be attacked by Br– anion from n-Bu4NBr to open
the ring. At the same time, the O anion can quickly react with CO2 as C1 source to
synthesize an ionic alkycarbonate intermediate. Finally, the targeted cyclic carbonates
will be obtained from alkycarbonate anions by the cyclization process. Nevertheless,
the accurate mechanism is still far beyond our understanding nowadays.
Due to various N atoms in complex 1, the resultant sample may be used as a Lewis
basic catalysis for Knoevenagel condensation reaction. [59-70] After the as-synthesized
samples were dried in air before the reaction, complex 1 (100 mg) was added in a
toluene solution (5 mL) containing substrates with different functional groups (1.0
mmol) and malononitrile (1.05 mol). The above reaction was heated at 100 °C in an oil
bath for 10 hours under slowly stirring. The catalytic result was tested and calculated
by the GC approach. The catalytic yield of 2-benzylidenemalononitrile can reach up as
high as >99% after 10 hours (entry 1 of Table 2); however, this reaction has very low
catalytic performance (~9%) without complex 1. The catalytic result obviously
illustrates that complex 1 can efficiently catalyze this catalytic reaction (entry 2).
Different substrates with various functional groups were explored and investigated to
further evaluate the relationship between the structures of substrates and the
corresponding catalytic performances. The –F and –NO2 groups have the electron-
withdrawing effect, which both have high catalytic yields as high as >99% (entries 3
and 4 of Table 2). When the functional groups are substituted by other functional groups,
the catalytic performance has totally different catalytic yield. As seen in entries 5 and
6, the yields obviously reduce to 90% of only one electron donor –OMe group (entry
5) and 83% (entry 6) of two –OMe groups, respectively. Based on the catalytic yields,
it shows that the electron effect of functional groups on substrates will directly affect
the catalytic performance. Meanwhile, the reusability of complex 1 is also an important
factor to estimate this heterogeneous catalyst. As seen in entry 7 and Fig. 4b, complex
1 can catalyze the Knoevenagel condensation by using benzaldehyde as the substrate
model, which can keep the catalytic yield at least four times. The result shows that

9
complex 1 has the greatly potential application for the Knoevenagel condensation with
excellent reusability.
Table 2. Catalytic yields of Knoevenagel condensations by using complex 1.
CN
O
+
NC
CN
R
R
H
CN
Entry
1 [a]
Substrate
Product
Yield %
>99
CN
CN
O
O
CN
CN
2 [b]
3 [a]
4 [a]
5 [a]
6 [a]
9
>99
>99
90
CN
O
CN
F
F
CN
O
CN
O N
2
O N
2
CN
O
CN
O
O
83
CN
O
CN
O
O
O
O
7 [c]
>99
CN
O
CN
[a] Reaction conditions: substrates with various functional groups (1.0 mmol), malononitrile (1.05 mol), and catalyst (100 mg)
were added in toluene (5 mL) at 100 °C for 10 hours. [b] The same reaction conditions as in [a], but without the catalyst. [c] The
recyclability test after four cycles.

10
Fig. 4 (a) The reusability and (b) the PXRD pattern of complex 1 for this catalytic reaction.
In conclusion, a 3D excellently stable heterovalent copper–organic framework based
on Cu4I4 and Cu(COO)2N2 SBUs is successfully designed and synthesized by the
solvothermal synthesis. The prepared sample can be used as a bifunctional
heterogeneous catalyst for chemical fixation of CO2 and epoxide, and Knoevenagel
condensation reaction. Especially, the excellent stability of complex 1 can be used to
continuously catalyse both reactions at least four cycles.
Appendix A. Supplementary data
The experiments are listed in the supporting information. The CCDC reference number
is 1992434.
Acknowledgements
This research did not receive any specific funding.
References
[1] M. Pan, W.-M. Liao, S.-Y. Yin, S.-S. Sun, C.-Y. Su, Single-phase white-light-
emitting and photoluminescent color-tuning coordination assemblies, Chem. Rev.
118 (2018) 8889-8935.
[2] B. He, M. M. Sadiq, M. P. Batten, K. Suzuki, M. Rubio-Martinez, J. Gardiner, M.
R. Hill, Continuous flow synthesis of a Zr magnetic framework composite for post-

11
combustion CO2 capture, Chem. Eur. J. 25 (2019) 13184-13188.
[3] L. Feng, K.-Y. Wang, G. S. Day, H.-C. Zhou, The chemistry of multi-component
and hierarchical framework compounds, Chem. Soc. Rev. 48 (2019) 4823-4853.
[4] H. He, D.-Y. Zhang, F. Guo, F. Sun, A versatile microporous Zinc(II)
metal−organic framework for selective gas adsorption, cooperative catalysis, and
luminescent sensing, Inorg. Chem. 57 (2018) 7314-7320.
[5] H. Cui, Y. Ye, H. Arman, Z. Li, A. Alsalme, R.-B. Lin, B. Chen, Microporous
copper isophthalate framework of mot topology for C2H2/CO2 separation, Cryst.
Growth Des. 19 (2019) 5829-5835.
[6] Q. Li, N. Wu, J. Li, D. Wu, Y. Li, Amino-functionalized water-stable metal–
organic framework for enhanced C2H2/CH4 separation performance, Inorg. Chem.
59 (2020) 2631-2635.
[7] H. He, H. Han, H. Shi, Y. Tian, F. Sun, Y. Song, Q. Li, G. Zhu, Construction of
thermophilic lipase-embedded metal–organic frameworks via biomimetic
mineralization: a biocatalyst for ester hydrolysis and kinetic resolution, ACS Appl.
Mater. Interfaces 8 (2016) 24517-24524.
[8] X. Lian, Y. Huang, Y. Zhu, Y. Fang, R. Zhao, E. Joseph, J. Li, J.-P. Pellois, H.-C.
Zhou, Enzyme-MOF nanoreactor activates nontoxic paracetamol for cancer
therapy, Angew. Chem., Int. Ed. 57 (2018) 5725-5730.
[9] H. Jia, Y. Qi, X. Wang, J. Xie, W. Yu, Water-stable CdII-based metal–organic
framework as a reversible luminescent sensor for NFT with excellent recyclability
and selectivity, Inorg. Chem. Commun. 111 (2020) 107668.
[10]J. Li, T.-J. Chen, S. Han, L.-F. Song, Four Zn(II)–organic frameworks as
luminescent probe for highly selectivity detection of CrVI ions and antibiotics, J.
Solid State Chem. 277 (2019) 107-114.
[11]H. He, Y. Song, F. Sun, Z. Bian, L. Gao, G. Zhu, A porous metal–organic
framework formed by a V-shaped ligand and Zn(ii) ion with highly selective
sensing for nitroaromatic explosives, J. Mater. Chem. A 3 (2015) 16598-16603.
[12]Y. Sun, N. Zhang, Q. L. Guan, C. H. Liu, B. Li, K. Y. Zhang, G. H. Li, Y. H. Xing,
F. Y. Bai, L. X. Sun, Sensing of Fe3+ and Cr2O72– in water and white light: synthesis,

12
characterization, and fluorescence properties of a crystalline bismuth-1,3,5-
benzenetricarboxylic acid framework, Cryst. Growth Des. 19 (2019) 7217-7229.
[13]Y. Wang, N. Zhang, E. Zhang, Y. Han, Z. Qi, M. B. Ansorge-Schumacher, Y. Ge,
C. Wu, Heterogeneous metal–organic–framework–based biohybrid catalysts for
cascade reactions in organic solvent, Chem. Eur. J. 25 (2019) 1716-1721.
[14]H. He, F. Sun, T. Borjigin, N. Zhao, G. Zhu, Tunable colors and white-light
emission based on a microporous luminescent Zn(II)-MOF, Dalton Trans. 43 (2014)
3716-3721.
[15]Y. Wang, N. Zhang, E. Zhang, Y. Han, Z. Qi, M. B. Ansorge-Schumacher, Y. Ge,
C. Wu, Heterogeneous metal-organic-framework-based biohybrid catalysts for
cascade reactions in organic solvent, Chem. Eur. J. 25 (2019) 1716-1721.
[16]S. Mistry, A. Sarkar, S. Natarajan, New bifunctional metal–organic frameworks
and their utilization in one-pot tandem catalytic reactions, Cryst. Growth Des. 19
(2019) 747-755.
[17]J. Zhou, Z. Zhang, L.-F. Xu, R.-J. Li, R.-D. Bao, L. Du, M.-J. Xie, Y.-F. Qiao,
Q.-H. Zhao, Mixed-ligand strategy affording two 6-connected 3-fold
interpenetrated metal-organic frameworks with binuclear CoII /NiII subunits:
2
2
synthesis, crystal structures and magnetic properties, Inorg. Chem. Commun. 111
(2020) 107624.
[18]F. Zarekarizi, A. Morsali, Dimension control in mixed linker metal–organic
frameworks via adjusting the linker shapes, Inorg. Chem. 59 (2020) 2988-2996.
[19]H. He, Y. Song, F. Sun, N. Zhao, G. Zhu, Sorption properties and nitroaromatic
explosives sensing based on two isostructural metal-organic frameworks, Cryst.
Growth Des. 15 (2015) 2033-2038.
[20]X. Wang, J.-Y. Luo, J.-W. Tian, D.-D. Huang, Y.-P. Wu, S. Li, D.-S. Li, Two new
3D isostructural Co/Ni-MOFs showing four-fold polyrotaxane-like networks:
Synthesis, crystal structures and hydrogen evolution reaction, Inorg. Chem.
Commun. 98 (2018) 141-144.
[21]H.-Y. Liu, J. Liu, G.-M. Gao, H.-Y. Wang, Assembly of two metal–organic
frameworks based on distinct cobalt dimericbuilding blocks induced by ligand

13
modification: gas adsorption and magnetic properties, Inorg. Chem. 57 (2018)
10401-10409.
[22]R. Rajak, M. Saraf, S. M. Mobin, Mixed-ligand architected unique topological
heterometallic sodium/cobalt-based metal–organic framework for high-
performance supercapacitors, Inorg. Chem. 59 (2020) 1642-1652.
[23]H.-H. Liu, J. Pan, Z.-Z. Xue, S.-D. Han, J.-H. Li, G.-M. Wang, Multiple detection
characteristics of two zinc phosphonates: syntheses, crystal structures, and
luminescent properties, Inorg. Chem. 19 (2019) 5326-5333.
[24]W. Chen, L. Li, X.-X. Li, L.-D. Lin, G. Wang, Z. Zhang, L. Li, Y. Yu, Layered
rare earth–organic framework as highly efficient luminescent matrix: the crystal
structure, optical spectroscopy, electronic transition, and luminescent sensing
properties, Cryst. Growth Des.19 (2019) 4754-4764.
[25]W. Wang, N. Gong, H. Yin, B. Zhang, P. Guo, B. Liu, Y.-Y. Wang, Two stable
terbium–organic frameworks based on predesigned functionalized ligands:
selective sensing of Fe3+ ions and C2H2/CH4 separation, Inorg. Chem. 58 (2019)
10295-10303.
[26]Q. Sun, X. Zhu, N. Zhang, B. Zhang, J. Lu, H. Liu, Auxiliary ligand-assisted
structural variation of two Co(II) metal-organic frameworks: Syntheses, crystal
structure and magnetic properties, Inorg. Chem. Commun. 99 (2019) 172-175.
[27]H. He, Q.-Q. Zhu, C.-P. Li, M. Du, Design of a highly-stable pillar-layer Zinc(II)
porous framework for rapid, reversible, and multi-responsive luminescent sensor
in water, Cryst. Growth Des. 19 (2019) 694-703.
[28]J. Gu, M. Wen, Y. Cai, Z. Shi, D. S. Nesterov, M. V. Kirillova, A. K. Kirillov,
Cobalt(II) coordination polymers assembled from unexplored pyridine-carboxylic
acids: structural diversity and catalytic oxidation of alcohols, Inorg. Chem. 58
(2019) 5875-5885.
[29]X. Lin, J. Lin, H. Deng, R. C. K. Reddy, J. Liu, Structural diversity of zinc(II),
manganese(II), and gadolinium(III) coordination polymers based on two isomeric
N-heteroaromatic polycarboxylate ligands: Structures and their derived Mn2O3 for
lithium storage applications, Inorg. Chem. 59 (2020) 460-471.

14
[30]F. Guo, C. Su, Y. Fan, W. Fu, Two Pb(II) coordination complexes based on 5-
halonicotinate (Cl or Br): Structural diversities and sensing performance, J. Solid
State Chem. 277 (2019) 83-92.
[31]W.-M. Liao, X.-N. Li, Q. Zeng, Y.-H. Zhong, Y.-G. Yin, J. He. Enantiomerism,
diastereomerism and thermochromism in two Cu7I4 cluster-based coordination
polymers, J. Mater. Chem. C 7 (2019) 15136-15140.
[32]A. Kobayashi, Y. Yoshida, M. Yoshida, M. Kato, Mechanochromic switching
between delayed fluorescence and phosphorescence of luminescent coordination
polymers composed of dinuclear copper(I) iodide rhombic cores, Chem. Eur. J. 24
(2018) 14750-14759.
[33]S.-Y. Yin, Z. Wang, Z.-M. Liu, H.-J. Yu, J.-H. Zhang, Y. Wang, R. Mao, M. Pan,
Multiresponsive UV-one-photon absorption, near-infrared-two-photon absorption,
and X/γ-photoelectric absorption luminescence in one [Cu4I4] compound, Inorg.
Chem. 58 (2019) 10736-10742.
[34]E. Lee, H. Ju, J. H. Jung, M. Ikeda, Y. Habata, S. S. Lee, Conventional and
mechanochemical syntheses of copper(I) iodide luminescent MOF with
bis(amidoquinoline) and its application for the detection of amino acid in aqueous
solution, Inorg. Chem. 58 (2019) 1177-1183.
[35]M. S. Deshmukh, A. Yadav, R. Pant, R. Boomishankar, Thermochromic and
mechanochromic luminescence umpolung in isostructural metal–organic
frameworks based on Cu6I6 clusters, Inorg. Chem. 54 (2015) 1337-1345.
[36]H. He, F. Sun, S. Ma, G. Zhu, Reticular synthesis of a series of HKUST-like MOFs
with carbon dioxide capture and separation, Inorg. Chem. 55 (2016) 9071-9076.
[37]C. Miao, T.-E. Su. Construction of a heterometallic organic framework based on
cuprous-halide clusters and lanthanide clusters with CO2 storage and
transformation, Inorg. Chem. Commun. 113 (2020) 107796.
[38]Z.-Z. Xue, D. Zhang, J. Pan, S.-D. Han, J.-H. Li, G.-M. Wang, A porous copper-
organic framework with intersecting channels and gas adsorption properties,
Dalton Trans. 46 (2017) 13952-13956.
[39]J. Yuan, J. Li, L. Kan, L. Zou, J. Zhao, D.-S. Li, L. Zhang, Y. Liu, A microporous

15
heterovalent copper–organic framework based on [Cu2I]n and Cu2(CO2)4
secondary building units: High performance for CO2 adsorption and separation and
iodine sorption and release, Cryst. Growth Des. 18 (2018) 5449-5455.
[40]C.-X. Liu, W.-H. Zhang, N. Wang, P. Guo, M. Muhler, Y. Wang, S. Lin, Z. Chen,
G. Yang, Highly efficient photocatalytic degradation of dyes by a copper-triazolate
metal–organic framework, Chem. Eur. J. 24 (2018) 16804-16813.
[41]H. Xu, C.-S. Cao, J.-Z. Xue, Y. Xu, B. Zhai, B. Zhao, A cuprous/lanthanide–
organic framework as the luminescent sensor of hypochlorite, Chem. Eur. J. 24
(2018) 10296-10299.
[42]J. Zhong, X.-H. Yi, P. Wang, C.-C. Wang, A stable 1D mixed-valence CuI/CuII
coordination polymer with photocatalytic reduction activity toward Cr(VI), J. Mol.
Struct. 1183 (2019) 256-262.
[43]G.-X. Jin, J. Wang, J.-Y. Liu, J.-P. Ma, Y.-B. Dong, Visual recognition and
removal of C2H2 from C2H4/C2H2 mixtures by a CuI-MOF, Inorg. Chem. 57 (2018)
6218-6221.
[44]Y.-L. Hou, Y.-L. Peng, Y. Diao, J. Liu, L. Chen, D. Li, Side chain induced self-
assembly and selective catalytic oxidation activity of copper(I)-copper(II)-N4
complexes, Cryst. Growth Des. 20 (2020) 1237-1241.
[45]H. He, Q.-Q. Zhu, J.-N. Zhao, H. Sun, J. Chen, C.-P. Li, M. Du, Rational
Construction of an exceptionally stable MOF catalyst with metal-adeninate vertices
toward CO2 cycloaddition under mild and cocatalyst-free conditions, Chem. Eur.
J. 25 (2019) 11474-11480.
[46]Y.-S. Xue, W. Cheng, J.-P. Cao, Y. Xu, 3D enantiomorphic Mg-based metal–
organic frameworks as chemical sensor of nitrobenzene and efficient catalyst for
CO2 cycloaddition, Chem. Asian J. 14 (2019) 1949-1957.
[47]H. He, J. A. Perman, G. Zhu, S. Ma, Metal–organic frameworks for CO2 chemical
transformations, Small 12 (2016) 6309-6324.
[48]Y.-Z. Li, H.-H. Wang, H. Y. Yang, L. Hou, Y.-Y. Wang, Z. Zhu, An uncommon
carboxyl-decorated metal–organic framework with selective gas adsorption and
catalytic conversion of CO2, Chem. Eur. J. 24 (2018) 865-871.

16
[49]C. Yao, S. Zhou, X. Kang, Y. Zhao, R. Yan, Y. Zhang, L. Wen, A cationic Zinc–
organic framework with Lewis acidic and basic bifunctional sites as an efficient
solvent-free catalyst: CO2 fixation and Knoevenagel condensation reaction, Inorg.
Chem. 57 (2018) 11157-11164.
[50]Y. Li, X. Zhang, J. Lan, P. Xu, J. Sun, Porous Zn(Bmic)(AT) MOF with abundant
amino groups and open metal sites for efficient capture and transformation of CO2,
Inorg. Chem. 58 (2019) 13917-13926.
[51]Q.-Q. Zhu, W.-W. Zhang, H.-W. Zhang, Y. Yuan, R. Yuan, F. Sun, H. He, A
double-walled porous metal–organic framework as a highly efficient catalyst for
chemical fixation of CO2 with epoxides, Inorg. Chem. 58 (2019) 15637-15643.
[52]M. Singh, P. Solanki, P. Patel, A. Mondal, S. Neogi, Highly active ultrasmall Ni
nanoparticle embedded inside a robust metal–organic framework: remarkably
improved adsorption, selectivity, and solvent-free efficient fixation of CO2, Inorg.
Chem. 58 (2019) 8100-8110.
[53]H. He, Q. Sun, W. Gao, J. A. Perman, F. Sun, G. Zhu, B. Aguila, K. Forrest, B.
Space, S. Ma, A stable metal–organic framework featuring a local buffer
environment for carbon dioxide fixation, Angew. Chem., Int. Ed. 57 (2018) 4657-
4662.
[54]B. Parmar, P. Patel, R. S. Pillai, R. K. Tak, R. I. Kureshy, N.-U. H. Khan, E. Suresh,
Cycloaddition of CO2 with an epoxide-bearing oxindole scaffold by a metal–
organic framework-based heterogeneous catalyst under ambient conditions, Inorg.
Chem. 58 (2019) 10084-10096.
[55]S. Cheng, Y. Wu, J. Jin, J. Liu, D. Wu, G. Yang, Y.-Y. Wang, New multifunctional
3D porous metal–organic framework with selective gas adsorption, efficient
chemical fixation of CO2 and dye adsorption, Dalton Trans. 48 (2019) 7612-7618.
[56]W. Jiang, J. Yang, G. Yan, S. Zhou, B. Liu, Y. Qiao, T. Zhou, J. Wang, G. Che, A
novel 3-fold interpenetrated dia metal-organic framework as a heterogeneous
catalyst for CO2 cycloaddition, Inorg. Chem. Commun. 113 (2020) 107770.
[57]T. Jing, L. Chen, F. Jiang, Y. Yang, K. Zhou, M. Yu, Z. Cao, S. Li, M. Hong,
Fabrication of a robust lanthanide metal–organic framework as a multifunctional

17
material for Fe(III) detection, CO2 capture, and utilization, Cryst. Growth Des. 18
(2018) 2956-2963.
[58]B. Ugale, S. S. Dhankhar, C. M. Nagaraja, Exceptionally stable and 20-connected
lanthanide metal–organic frameworks for selective CO2 capture and conversion at
atmospheric pressure, Cryst. Growth Des. 18 (2018) 2432-2440.
[59]F. Guo, C. Su, Z. Chu, M. Zhao, A highly stable 3D metal–organic framework for
selectively luminescent sensing and knoevenagel condensation reaction, J. Solid
State Chem. 277 (2019) 25-31.
[60]X. Zhang, R. Zhang, Y. Jin, T. Li, Two PbII-based coordination polymers based on
5-aminonicotinic acid and 5-hydroxynicotinic acid for Knoevenagel condensation
reaction and luminescent sensor, J. Solid State Chem. 278 (2019) 120927.
[61]A. Das, N. Anbu, S. K. Mostakim, A. Dhakshinamoorthy, S. Biwas, A
functionalized UiO-66 MOF for turn-on fluorescence sensing of superoxide in
water and efficient catalysis for Knoevenagel condensation, Dalton Trans. 48
(2019) 17371-17380.
[62]J. Wang, X. Wang, H. Xu, X. Zhao, Z. Zheng, Z.-L. Xu, A zinc(II) porous
metal−organic framework and its morphologically controlled catalytic properties
in the Knoevenagel condensation reaction, ChemPlusChem 82 (2017) 1182-1187.
[63]Z. Miao, F. Yang, Y. Luan, X. Shu, D. Ramella, Synthesis of Fe3O4@P4VP@ZIF-
8 core-shell microspheres and their application in a Knoevenagel condensation
reaction, J. Solid State Chem. 256 (2017) 27-32.
[64]H. He, Q-Q. Zhu, F. Sun, G. Zhu, Two 3D metal−organic frameworks based on
CoII and ZnII clusters for Knoevenagel condensation reaction and highly selective
luminescence sensing, Cryst. Growth Des. 18 (2018) 5573-5581.
[65]S. Zhao, A novel 3D MOF with rich Lewis basic sites as a base catalysis toward
Knoevenagel condensation reaction, J. Mol. Struct. 1167 (2018) 11-15.
[66]C. Miao, A bi-functional 3D PbII-organic framework for Knoevenagel
2-
condensation reaction and highly selective luminescent sensing of Cr2O7 , Inorg.
Chem. Commun. 105 (2019) 86-92.
[67]A. Dhakshinamoorthy, Z. Li, H. Garcia, Catalysis and photocatalysis by metal

18
organic frameworks, Chem. Soc. Rev. 47 (2018) 8134-8172.
[68]A. Das, N. Anbu, A. Dhakshinamoorthy, S. Biswas, A highly catalytically active
Hf(IV) metal-organic framework for Knoevenagel condensation, Micropor.
Mesopor. Mat. 284 (2019) 459-467.
[69]A. Dhakshinamoorthy, N. Heidenreich, D. Lenzen, N. Stock, Knoevenagel
condensation reaction catalysed by Al-MOFs with CAU-1 and CAU-10-type
structures, CrystEngComm 19 (2017) 4187-4193.
[70]A. Dhakshinamoorthy, M. Opanasenko, J. Čejka, H. Garcia, Metal organic
frameworks as solid catalysts in condensation reactions of carbonyl groups, Adv.
Synth. Catal. 355 (2013) 247-268.

19
Graphical Abstract-Pictogram
This work exhibits an excellently stable heterovalent copper–organic framework
based on Cu4I4 and Cu(COO)2N2 SBUs, which can catalyse the CO2 cycloaddition
reaction and Knoevenagel condensation reaction with preferable recyclability.

20
Highlights
1. A 3D heterovalent Cu–organic framework based on Cu4I4 and Cu(COO)2N2 SBUs
was successfully designed and synthesized.
2. The resultant sample can catalyse the CO2 cycloaddition reaction and Knoevenagel
condensation reaction.
3. Complex 1 has the remarkable stability and recyclability at least four cycles.

21
Declaration of interests
☒ The authors declare that they have no known competing financial interests or personal
relationships that could have appeared to influence the work reported in this paper.
☐The authors declare the following financial interests/personal relationships which may be
considered as potential competing interests:

22
Feng Jin: Supervision and writing this article.
