Nucleus targeting anthraquinone-based copper (II) complexes as the potent PDT agents: Synthesis, photo-physical and theoretical evaluation

Article abstract of DOI:10.1016/j.ica.2019.119208

Present work explored the structural aspects of four new anthraquinone-based copper(II)complexes of the general formula [Cu(L¹)B] (1, 2) and [Cu(L²)B] (3, 4) where L¹ = 2-((2-mercaptophenylimino)methyl)phenol, L² = 2-((2-mercaptophenylimino)methyl)-4,6-di-tert-butylphenol and B are 1,10-phenanthroline,dipyrido[3,2-d:2′,3′-f]quinoxaline-8,9-napthaquinone, in modulating in vitro photo-dynamic activities. Nucleus targeting complexes have shown remarkable cytotoxicity in visible-light to cancer cells (IC₅₀ ～ 2–11 μM) with reduced dark toxicity (IC₅₀ > 50 μM) unlike other copper (II) complexes. Singlet oxygen generated on photo-sensitization of the complexes was the key cytotoxic species responsible for apoptotic damage of cancer cells. Degree of photo-cytotoxicity of the photo-activated complexes was related to the extent of ¹O₂ generation which was probed by several photo-physical studies along with TD-DFT calculations. Presence of low-lying, long-lived triplet excited state and hence increased ability to generate ¹O₂ from ³O₂ through type-II photo-process was proposed to explain the degree of photo-cytotoxicity of the complexes. We observed dual photo-sensitization of S-coordination and anthraquinone moiety for the complex 4 leading to remarkable PDT effect to cancer cells with minimal dark toxicity. Overall, our investigations on exploring the structural aspects of copper (II) complexes for PDT were a phenomenal break-through in developing copper-based photo-chemotherapeutics in the clinical arena of cancer therapy.

Full text of DOI:10.1016/j.ica.2019.119208

Journal Pre-proofs
Nucleus targeting anthraquinone-based copper (II) complexes as the potent PDT
agents: Synthesis, photo-physical and theoretical evaluation
Longjam Reena Devi, Md Kausar Raza, Dulal Musib, Vanitha Ramu, Joshila
Devi, Mithun Roy
PII:
S0020-1693(19)30969-7
https://doi.org/10.1016/j.ica.2019.119208
ICA 119208
DOI:
Reference:
Inorganica Chimica Acta
To appear in:
Received Date:
Revised Date:
Accepted Date:
3 July 2019
4 September 2019
14 October 2019
Please cite this article as: L.R. Devi, M.K. Raza, D. Musib, V. Ramu, J. Devi, M. Roy, Nucleus targeting
anthraquinone-based copper (II) complexes as the potent PDT agents: Synthesis, photo-physical and theoretical
evaluation, Inorganica Chimica Acta (2019), doi: https://doi.org/10.1016/j.ica.2019.119208
This is a PDF file of an article that has undergone enhancements after acceptance, such as the addition of a cover
page and metadata, and formatting for readability, but it is not yet the definitive version of record. This version will
undergo additional copyediting, typesetting and review before it is published in its final form, but we are providing
this version to give early visibility of the article. Please note that, during the production process, errors may be
discovered which could affect the content, and all legal disclaimers that apply to the journal pertain.
© 2019 Published by Elsevier B.V.

Nucleus targeting anthraquinone-based copper (II)
complexes as the potent PDT agents: Synthesis, photo-
physical and theoretical evaluation
Longjam Reena Devi,† Md Kausar Raza‡, Dulal Musib,† Vanitha Ramu‡, Joshila Devi† and
Mithun Roy*,†
†Department of Chemistry, National Institute of Technology, Manipur, Langol 795004, Imphal
(Manipur), India
‡Department of Inorganic and Physical Chemistry, Indian Institute of Science, Bangalore 560012
(India)
Keywords:Copper(II) complexes, nuclear localization, photodynamic therapy, ROS generation,
apoptosis.
Highlights:
 In vitro photodynamic activity of anthraquinone-based copper(II) complexes is reported here.
 Increased concentration of singlet oxygen (1O2) generated from type-II photo-process was
responsible for the photocytotoxicity through apoptosis.
 Generation of 1O2 by the photo-activated copper(II) complexes was evaluated photo-physically
and theoretically.
-------------------------------------------------------
*Author to whom correspondence should be addressed. E-mail: mithunroy@nitmanipur.ac.in,
mithunroy.iisc@gmail.com
1

Abstract: Present work explored the structural aspects of four new anthraquinone-based
copper(II)complexes of the general formula [Cu(L1)B] (1, 2) and [Cu(L2)B] (3, 4) where L1 = 2-((2-
mercaptophenylimino)methyl)phenol, L2 = 2-((2-mercaptophenylimino)methyl)-4,6-di-tert-butylphenol
and B are 1,10-phenanthroline,dipyrido[3,2-d:2’,3’-f]quinoxaline-8,9-napthaquinone, in modulating in
vitro photo-dynamic activities. Nucleus targeting complexes have shown remarkable cytotoxicity in
visible-light to cancer cells (IC50 ~ 2-11 µM) with reduced dark toxicity (IC50>50 µM) unlike other
copper (II) complexes. Singlet oxygen generated on photo-sensitization of the complexes was the key
cytotoxic species responsible for apoptotic damage of cancer cells. Degree of photo-cytotoxicity of the
1
photo-activated complexes was related to the extent of O2 generation which was probed by several
photo-physical studies along with TD-DFT calculations. Presence of low-lying, long-lived triplet
1
3
excited state and hence increased ability to generate O2 from O2 through type-II photo-process was
proposed to explain the degree of photo-cytotoxicity of the complexes. We observed dual photo-
sensitization of S-coordination and anthraquinone moiety for the complex 4 leading to remarkable PDT
effect to cancer cells with minimal dark toxicity. Overall, our investigations on exploring the structural
aspects of copper (II) complexes for PDT were a phenomenal break-through in developing copper-based
photo-chemotherapeutics in the clinical arena of cancer therapy.
2

1. Introduction
Photodynamic therapy (PDT) has emerged as tumor specific and non-invasive treatment modality for
cancer[1-3]. It requires simultaneous presence of photosensitizer (PS), non-toxic red light and molecular
oxygen (3O2) to show anticancer activity. The excited triplet state of the PS transfers its energy to triplet
molecular oxygen (3O2) and converts it into toxic singlet molecular oxygen (1O2) which oxidizes key
cellular macromolecules like proteins, DNA [4]. Photofrin® is FDA approved first generation PDT drug
which is the oligomeric mixture of porphyrin derivative and clinically tested against primarily
esophageal cancer [5-6]. Although other porphyrins, phthalocyanines or their metal analogues absorbing
red light have emerged as second and third generation PDT agents [7-10]. PDT is limited by severe
hepatotoxicity, prolonged skin photo-sensitivity and other side effects related to the tumor non-
specificity of the present drugs [6]. Photo-activated transition metal complexes absorbing longer
wavelength light and exhibiting ligand exchange, intramolecular redox reaction, facile ligand release,
generation of radical species including ROS (reactive oxygen species) on photo-activation, may be of
particular interest in developing metal-based photochemotherapeutic agents [11-14]. However, high
energy requirement (<500 nm) for activation as well as heavy metal toxicity related to the complexes of
later transition metals are the major challenges for their application in clinical arena of photo-
chemotherapy. On contrary, bio-essential and kinetically labile first-row transition metal complexes
absorbing light in PDT window (600-800 nm) are however preferable for photo-chemotherapeutic
applications in considering deeper tissue penetration of longer wavelength light[15-17]. Photo-labile
complexes of vanadium, manganese, iron or cobalt are explored extensively for photo-activated
chemotherapy in PDT window to various cancer cell lines [18-23]. Biologically benign copper (II)
complexes absorbing lights (>600 nm) were also previously studied for photo-cytotoxicity to various
cancer cells with significantly low IC50values [24-29]. Significantly high dark-toxicity of the copper(II)
complexes is the major hindrance in designing copper(II)-based PDT agents (Scheme S1, Table S1).
3

Facile redox activity of the copper(II) complexes by intracellular thiols could be responsible for
increased dark-toxicity.
The anthracycline antibiotics like daunorubicin, doxorubicin and others are used as anticancer agents for
past few decades. Such anthracycline drugs having planar anthraquinone moiety target telomeres to
exhibit anti-proliferative activity [30-32]. Ability of photo-sensitized anthraquinone moiety in
•-
1
generating reactive oxygen species (ROS: O2 , O2) [33] has prompted us to synthesize anthraquinone-
based copper(II) complexes to modulate in vitro photo-cytotoxicity(Scheme 1). Here in, we report the
synthesis, analytical characterization, photo-physical studies and theoretical evaluation of singlet
oxygen generation (1O2) on photo-activation, nuclear localization, cytotoxicity studies in MCF-7 and
HaCaT cells in dark and visible light (400-700 nm, 10 Jcm-2) of four new ternary copper(II)complexes
of following formulas [Cu(L1)B] (1-2) and [Cu(L2)B] (3-4), where L1
=
2-(2-
mercaptophenylimino)methyl)phenol, L2 = 2-(2-mercaptophenylimino)methyl)-4,6-di-tert-butylphenol
and B= 1,10-phenanthroline (L3) and anthraquinyl-dipyridoquinoxaline (L4)(Scheme 1).
.
2. Experimental Section
2.1. Materials and Reagents
The reagents and all chemicals were obtained from Sigma-Aldrich (USA), SD-Fine chemicals (India),
HI-MEDIA and used as received without any further purification. The solvents used were purified by
standard methods [34]. DCFH-DA, Propidium iodide (PI), diphenylisobenzofuran (DBPF), Annexin V-
FITC/PI was purchased from Sigma-Aldrich (USA). 1, 10-phenanthroline monohydrate (A.R.),
Potassium bromide (KBr), 3,5-ditertbutyl-2-hydroxybenzaldehyde, 2-Aminothiophenol, 1,2-
diaminoanthraquinone. A previously reported synthetic procedure was used to synthesize 1,10-
phenanthroline-5,6-dione,Salicylideneimine-2-thiophenol(satpH2),
2((2mercaptophenylimino)methyl)4,6-ditertbutylphenol and 10,11[1,4naphthalendione]dipyrido[3,2-
a;2”,3”-c]phenazine(Aqphen) with minor modification[35-38].
4

FT-IR spectra were recorded in solid phase using Perkin-Elmer UATR TWO FT-IR Spectrometer
operating from 400 to 4000 cm–1, UV-vis and emission spectra were recorded on Perkin-Elmer UV/VIS
spectrometer and HITACHI F-7000 Fluorescence spectrophotometer respectively. Time-correlated
single-photon-counting (TCSPC) spectrometer (Horiba Jobin Yovon) was used to accomplish
fluorescence lifetime measurement. Nanosecond laser of 375 nm was used as excitation source in the
following decay kinetics. The data were analysed by a bi-exponential fitting program using IBH DAS-6
decay analysis software. Molar conductivity measurements were done by using a EUTECH
INSTRUMENT CON 510 (India) conductivity meter. Cyclic voltammetry of the complex (1-4) in DMF
was studied at 25⁰C using a EG & G PAR 253 Versa Stat potentiostat/galvanostat with a three electrode
configuration consisting of a glassy carbon working, a platinum wire auxiliary and a saturated calomel
reference (SCE) electrode. Ferrocene (E1/2 =0.42 V) was used as a standard in MeCN 0.1 M
[nBu4N](ClO4) (TBAP) .
2.2. Synthesis
All the ligands (L1, L2 and L4) were synthesized according to the literature [35-38] and further verified
by Q-TOF ESI mass spectroscopy.
General synthesis procedure for L1–L4:
Salicylideneimine-2-thiophenol (L1): A mixture of salicylaldehyde (5 mL, 47.8 mmol), o-
aminothiophenol (4.696ml, 47.8 mmol) were heated to 80⁰C and refluxed in 30 mL ethanol for 4 h. The
reaction mixture was cooled to room temperature and the solvent was evaporated in vacuum and the
resulting solid was recrystalized in ethanol. The yellow crystals were filtered and dried in air (Yield:
~80%, M.P: -1300C)[35].
2-((2-mercaptophenylimino)methyl)4,6-ditertbutylphenol (L2): A solution of 3,5-di-tert-butyl-2-
hydroxybenzaldehyde (0.586g, 2.5 mmol) in benzene (30 mL) was added to a solution of 2-
aminothiophenol (0.26ml, 2.5 mmol) in benzene (20 mL) and were heated at 100 °C in closed container
under N2 atmosphere for 3 days. The solvent was removed in vacuum. The product was obtained as
yellow oil in a good yield (~80%) [36].
5

10,11-[1,4-naphthalendione]dipyrido[3,2-a;2”,3”-c]phenazine (L4): To the mixture of 1,10-
phenanthroline (2.0 g, 0.011 mol) and KBr (2.00 g, 0.084 mol), H2SO4 (40 mL) followed by HNO3 (20
mL) were added drop wise at 0°C. The resulting mixture was heated at 100°C until the bromine vapours
disappeared. The solution was poured carefully into ice and slowly neutralized to pH 7.0 with 1M
NaOH solution. The product was extracted with dichloromethane and dried over Na2SO4. The solvent
was evaporated to get a yellow solid which was dried under vacuum to get yellow powder product1, 10–
0
phenanthroline-5, 6-dione. (Yield: 1.96 g, 85%). M.P: 255-260 C [37]. Mixture of 0.13g (1.24 mmol)
of 1, 10-phenanthroline-5, 6-dione and 0.14g (1.24 mmol) of 1, 2-diaminoanthraquinone was refluxed in
30 ml ethanol at 85°C for 9 hours. After evaporating the ethanol, the suspension was filtered, and the
dark brown residue was dissolved in 500 ml of hot chloroform in the presence of charcoal. Then, the
orange coloured solution was concentrated to approximately 50 ml to obtain yellow solid. Diethyl ether
was added to complete the precipitation. The product was filtered and dried under high vacuum to give
golden yellow solid. (Yield: ~60%)[38].
The product was characterized spectroscopically and used for further complexation.
General synthesis procedure for preparation of the complexes (1-4):
Complexes (1-4) were prepared by a general procedure in which 0.199 g (1 mmol) quantity of
monomeric copper(II) acetate monohydrate in 10 mL of MeOH was added with the respective Schiff
bases [0.252g, 1.0 mmol of salicylideneimine-2-thiophenol (L1) (1 and 2); 0.375 g of 2-((2-
mercaptophenylimino)methyl)4,6-ditertbutylphenol (L2) (3 and 4)] in 10 mL of MeOH while stirring at
25 °C for 1 h followed by addition of heterocyclic bases [0.162g, 1.0 mmol of 1,10-phenanthroline (L3)
(1 and 3); 0.371 g, 1 mmol of 10,11-[1,4-naphthalendione]dipyrido[3,2-a;2”,3”-c]phenazine (L4) (2 and
4)]. The mixture turned from blue to bluish green color. After being stirred for 2 h, the complexes were
isolated as bluish green microcrystalline precipitate and washed with cold methanol, and finally
recrystallization from MeOH into pale green colored microcrystalline solid. Yield: 0.392ꢀg, 59% (1);
0.381ꢀg, 52% (2), 0.429ꢀg, 60% (3) and 0.451g, 56% (4).
6

Anal. Calc. For C25H19N3O2SCu (1): Calculated: C, 63.75; H, 3.64; N, 8.92; Found: C, 63.17; H, 3.55;
N, 8.99; FT-IR (Solid phase; br, broad; vs, very strong; s, strong; m, medium; w, weak)cm-1:
2993m(NH), 1590m(C=N), 1210m, 830m, 721m, 617m, 521m(Cu-N), 495m(Cu-O), 425w(Cu-S).ESI-
MS in CH3CN: m/z 470.0361 [Cu(L1)(L3)H]+. UV-visible in 10% v/v DMSO-H2O [max/nm (/L mol-1
cm-1)]: 265(2851), 394(127), 660(67),(sh, shoulder). M(Sm2mol-1) in 10% v/v DMSO-H2O: 28 at 298
K.
Anal. Calc. for C39H21N5O3SCu (2):Calculated: C, 66.61; H, 3.01; N, 9.96; Found: C, 65.97; H, 2.91; N,
9.92; FT-IR (Solid phase), cm-1: 2995m(NH), 1575m(C=N), 1739s(C=O), 1328m, 1086m, 621m, 797m,
719s, 546w(Cu-N), 487m(Cu-O), 432w(Cu-S); ESI-MS in CH3CN: m/z 702.0914 [Cu(L1)(L4)H]+. UV-
visible in 10% v/v DMSO-H2O [max/ nm ( /L mol-1 cm-1)]: 274(1883), 404(945), 650(350); M(Sm2
mol-1) in 10% v/v DMSO-H2O: 39 at 298 K.
Anal. Calc. For C33H33N3OSCu (3):Calculated: C, 67.96; H, 5.70; N, 7.20; Found: C, 67.51; H, 5.55; N,
7.11; FT-IR (Solid phase), cm-1: 3006m (NH), 1614m (C=N),1210m, 755m, 683m, 537m(Cu-
N),501(Cu-O), 445w(Cu-S).ESI-MS in CH3CN: m/z 582.1640 [Cu(L2)(L3)H]+. UV-visible in 10% v/v
DMSO-H2O [max/ nm (/L mol-1 cm-1)]: 264(2654), 421 (212), 610(174), M(Sm2 mol-1) in 10% v/v
DMSO-H2O: 33 at 298 K.
Anal. Calc. for C47H37N5O3SCu (4): Calculated: C, 69.23; H, 4.57; N, 8.59; Found: C, 69.13; H, 4.37;
N, 8.51; FT-IR (Solid phase), cm-1: 3011m (NH), 1618s (C=N), 1740s (C=O), 1262m,1170m, 859m,
m, 719s, 530m(Cu-N), 492m(Cu-O), 436w(Cu-S). ESI-MS in CH3CN: m/z 814.2688 [Cu(L2)(L4)H]+.
UV-visible in 10% v/v DMSO-H2O [max/ nm (/L mol-1 cm-1)]: 276 (3782), 397(971), 670(189).
M(Sm2 mol-1) in 10% v/v DMSO-H2O: 29 at 298 K.
3. Results and Discussion
3.1. Synthesis, characterization and general aspects
7

Complexes (1-4) were synthesized in 50-60% yield by a general synthetic procedure in which
methanolic solution of Cu(OAc)2.H2O was added with the Schiff base ligands (L1 or L2) pre-dissolved in
MeOH followed by the addition of N,N-diimine ligands (L3 and L4) at room temperature with constant
stirring for 2 h. Complexes were isolated as microcrystalline bluish-green precipitate and the pure solid
was obtained after recrystallization from MeOH. Purity of the complexes were determined by elemental
analysis (CHN analysis) and further characterized analytically and spectroscopically (Table S2). Non-
conducting (Molar conductance, M, 20-40 (Sm2 mol-1) in 10% v/v DMSO-H2O) solution indicated as
neutral complexes (Scheme 1)[29]. All the complexes were characterized by typical C=Nstr at ~1590-
1620 cm-1 in addition to NHstr at ~2990-3010 cm-1 in solid-phase IR spectra. Moreover, Cu-Sstr, Cu-Nstr
were observed at ~420, ~550 cm-1 respectively in the solid-phase IR spectra of the complexes (Figure
S1)[39]. Initially formation of the complexes was confirmed by the UV-visible spectral measurements
recorded in 10% v/v DMSO-H2O (Figure S2). Typical molecular ion peak for the complexes
characterized by [Cu(L)B]+ (L= L1, L2; B=L3, L4) was identified along with other fragmented mass in
the Q-TOF ESI mass spectra (MS) of the complexes in acetonitrile (Figure S3-S6). Powder XRD
spectrum of Cu(II) complexes are shown in Figure S7. Based on the data obtained analytically and
spectroscopically we performed DFT calculations to obtain energetically favorable optimized structures
and corresponding HOMO and LUMO stereographs are shown Figure S8.
3.2. Solubility and stability
Complexes (1-4) were soluble in acetonitrile (MeCN), methanol (MeOH), dimethylsulphoxide
(DMSO), dimethylformamide (DMF), 5% v/v DMF-H2O, 10% v/v DMSO-H2O. Stability of the
complexes on exposure to the visible light (400-700 nm, 10 Jcm-2) was studied by UV-visible
spectroscopy in which the complexes (1-4) in 10% v/v DMSO-H2O (pH 6.8) were irradiated with
visible light for 5 min followed by UV-Visible spectral measurements till 72 h (Figure S9). No apparent
changes were observed in UV-Visible spectra of the complexes on visible light (400-700 nm, 10 Jcm-2)
exposure indicating the stability of the complexes on photo-exposure.
8

3.3. Electrochemical properties
Cyclic voltammetry of the complex (1-4) in DMF was studied at 25 ⁰C using a EG & G PAR 253 Versa
Stat potentiostat/galvanostat with a three electrode configuration consisting of a glassy carbon as
working, a platinum wire as auxiliary and a saturated calomel as the reference (SCE) electrode.
Ferrocene (E1/2 = 0.42 V) was used as a standard in DMF containing 0.1 M [nBu4N](ClO4) (TBAP)
(Figure S10). Complex 4 exhibited quasi-reversible cyclic voltammetric response with E1/2 at -0.46 V
and ∆E = 0.12V. The reduction potential for Cu(II)/Cu(I) system of the complex 4 was significantly
higher beyond the biological redox window which is typically in the range +0.2 to -0.3 V. Such a high
value of E1/2 for complex 4 could be due to higher π accepting ability of the anthraquinyl moiety.
3.4. Electronic properties
Electronic spectra of the complexes (1-4) were recorded in 10% v/v DMSO-H2O. Broad and weak
metal-centered d-d band for the complexes were observed in the range 600-800 nm along with intense
LMCT/MLCT bands at ~400 nm (Figure 1, Table S2). We observed red-shift in d-d band of the
complex 3 and 4 clearly indicating the effect of strong electron donating t-butyl group on the electronic
structure of the complexes. The nature of the electronic transitions and the MOs involved, obtained from
TD-DFT calculations, are tabulated in (Table S3). The paramagnetic complexes 2 and 4 display
typically poor luminescence in 400 and 518 nm under the similar experimental condition with
3
luminescence quantum yield (φ, 0.04-0.05)(Table 1, Figure S11). Due to IL emission of the
anthraquinyl moiety, complex 4 has comparable luminescence which is also supported by spin density
calculation.
3.5. Triplet excited state and luminescence life-time
Initially we probed the existence of low-lying triplet excited state of the complexes (1-4)[24]. Triplet-
triplet annihilation (TTA) up-conversion generally requires a triplet photo-sensitizer for absorbing of the
excitation energy and triplet acceptor for the up-converted emission. Energy is transferred from the
9

photosensitizer to the acceptor by triplet-triplet energy transfer (TTET) process followed by the singlet
excited state of the acceptor is produced and the emission intensity of the acceptor is increased [40-44].
Typical increase emission spectrum of triplet perylene in MeCN was observed on photo-exposure in the
presence of the complexes (3, 4) (Figure S12). We assumed that photo-activated complexes quickly
relaxed into the low-lying triplet excited state which was quenched by perylene resulting in emissive
triplet perylene. Negligible emission of perylene was observed in the presence of the complexes in dark.
Higher emission intensity of triplet perylene in the presence of complex 4 indicated effective inter-
system crossing into triplet excited state. Similar observation was made for the complexes 1 and 2
(Figure S13).
Later we determined the steady state luminescence life-time of the complexes (2,4) at ambient
temperature in MeOH and the first order luminescence decay of the complexes gave the life-time in
nano second scale (Figure S14, Table 1). Although luminescence ligands were extremely short-lived
complexes (2,4) exhibited longer luminescence life-time i.e. 11.3 ns, and 11.7 ns respectively. Longer
luminescence life-time of the complexes could be due to the presence of low-lying and relatively long-
lived triplet excited state in the complexes 2 and 4.
3.6. Singlet oxygen (1O2) generation
Singlet oxygen (1O2) as ROS can be evidenced from a UV-visible spectral titration experiment. We
probed the generation of singlet oxygen (1O2) on photo-activation (Visible light, 400-700 nm, 10 Jcm-2)
by the complexes (1-4) by using diphenylisobenzofuran (DPBF) (Figure S15)[43-44]. We also have
determined the quantum yield of 1O2 generation by using Rose Bengal as a reference (Figure S16). UV-
Visible spectral titration was carried out to record the change in absorbance (A417nm) of DPBF (50 µM)
at max= 417 nm in DMF against visible-light exposure (400-700 nm, 10 J cm-2) time in the presence of
complexes (50 µM). Gradual decrease in A417nm of DPBF indicated photo-induced generation of singlet
oxygen from complexes (1-4). Several control experiments with DPBF alone and DPBF in the presence
of the complexes in dark excluded any possibility artifact. Degree of singlet oxygen (1O2) generation by
10

the complexes was graphically represented by plotting the extent of decrease in absorbance of DPBF
(A/A0) against photo-exposure time (t/sec), where A was the absorbance of DPBF at particular time
while A0 was the absorbance of DPBF at t= 0 sec. We observed almost linear decrease of absorbance of
1
3
DPBF with photo-exposure time and indicated photo-induced generation of O2 from O2 by the
complex via type II photo-process. The observed slope was different for the complexes (1-4) and the
plot qualitatively explained higher amount of singlet oxygen generation by the complex 4.
We quantified the singlet oxygen generation from the photo-activated complexes by determining the
quantum yield ((1O2)) for singlet oxygen generation in reference to Rose Bengal in DMSO at room
temperature (Table 1) [27]. The singlet oxygen quantum yield was determined to be in the range 0.2-0.6
for the complexes (1-4). Complex 4 generating higher amount of singlet oxygen (1O2) with quantum
yield of 0.6 could be potential for PDT applications.
3.7. TD-DFT calculations and singlet oxygen (1O2) generation
We performed TD-DFT calculations further to verify the type-II photo-process of the complexes as
predicted in several photo-physical studies and to correlate comparative efficiency of singlet oxygen
generation by the photo-activated complexes (1-4). Time-dependent density functional theory (TD-
DFT) calculations on the excited state of Cu(II)complexes (1-4) were carried out by using unrestricted
B3LYP density functional theory[45]. Gauss Sum program was used to calculate the contribution of
percentage of metal and ligands character involve corresponding in the HOMOs and LUMOs[46].The
excitation energies and oscillator strengths, as well as the excited state compositions for the two systems
presented were studied extensively.
Assuming type-II photo-process, initially we examined the presence of lowest lying excited triplet state
for all the complexes by carrying out self-consistent, unrestricted B3LYP calculations at both the
ground-state geometry as well as geometrically optimized triplet excited state. The vertical excitation
11

energies of low-lying doublet and triplet states of the complexes (1-4) were presented in Table 2. The
nature of the low-lying excited states was determined to be typically MLCT and ILCT type and
corresponding HOMO had significantly metallic character while LUMO was localized in the ligands.
Doublet excited (D1) state, populated upon absorption of visible light (D0→D1), efficiently populated
further the low-lying triplet excited state (T1) via strong inter-system crossing. Energy difference
between low-lying doublet excited and triplet excited states of complexes (1-4) were 0.63 eV, 0.35 eV,
0.89 eV and 0.19 eV (Table 2, Figure 2). Therefore, we predicted better and faster inter-system crossing
for the complex 4 probing the effect of bulky t-butyl group and anthraquinyl moiety for effective
intersystem crossing in the complex and explain the significantly higher singlet oxygen (1O2) quantum
yield (0.62).
3.8. Cellular uptake and cellular localization
Green luminescence of the complexes (1, 4) was explored to study the cellular incorporation in
HaCaTcells. The remedial effect of a drug is often related with its cellular uptake [47]. Complex 1 and 4
showed some increase in the cellular uptake compared to their free ligands (L3, L4). This observation
reveals a crucial role of the metal in transporting the photosensitizer into the cells. We had standardized
the incubation time for in vitro studies before light irradiation by cellular incorporation assay by FACS
(Figure 4). The studies revealed predominant incorporation of the complex in 4h of incubation. The shift
in the band position of the complexes (1, 4) in HaCaT cells clearly indicates that the complexes have a
higher cellular uptake compared to their free ligands (L3, L4).
Co-localization experiments were done to measure the intracellular presence of complex 4. Only
complex 4 has been selected to determine the intracellular distribution pattern by confocal microscopy
as the cellular incorporation of other complexes and ligands were comparatively lower upon 4h
incubation. Nuclear localization was observed from the merged images of the complex 4 (15μM) when
treated with 4′,6-diamidino-2-phenylindole (DAPI) as the nuclear staining dye after 4 h of incubation in
12

dark (Figure 5).The merged image of the complex 4 and with nucleus staining dye 4′, 6-diamidino-2-
phenylindole (DAPI) revealed selective localization of the complex into the nucleus of the cell.
3.9. Cytotoxicity and photodynamic effect
The ability of mitochondrial dehydrogenases in the viable cells to cleave the tetrazolium rings of 3-(4,5-
dimethylthiazol-2-yl)-2,5-diphenyltetrazolium bromide (MTT) into dark violet membrane impermeable
crystals of formazan was explored to probe cytotoxicity of the complexes in vitro in MCF-7 (human
breast carcinoma) and HaCaT(human keratinocyte)cell lines in the dark and visible light (400-700 nm,
10 Jcm-2) (Table 3, Figure S17)[23,24]. Cells were initially incubated with the complexes (1-4) in dose
dependent manner at 370C for 4 h in the dark followed by photo-irradiation with visible light (400-700
nm, 10 Jcm-2) for 1 hour. IC50 values were determined from the non-regression analysis of the dose-
response plot for the complexes (1-4) and are presented in Table 3. We observed remarkable effect of
visible light (400-700 nm, 10 Jcm-2) on the cytotoxicity of the complexes (1-4) to both MCF-7 and
HaCaT cells with IC50 values in the range 2.5-11.5 µM (Figure 6). Effect of ligands (L1-L4) alone, Cu
(OAc)2.H2O or visible light (400-700 nm, 10 Jcm-2) on cytotoxicity to MCF-7 or HaCaT cells was
insignificant and this excluded any artefact related to the cytotoxicity data. Complex 4 bearing
anthaquinyl ligand exhibited remarkable photo-cytotoxicity with IC50 value of 2.5 µM and we observed
>19-fold enhancement in cytotoxicity in comparison to dark (IC50>50 µM) in HaCaT cells (photo-
cytotoxicity index). Dual photosensitizing ability of S-coordination and anthraquinyl ligands in copper
(II)-bound form could be responsible for such remarkable photocytotoxicity. Photofrin®, FDA
approved first generation PDT drug, however, exhibited photodynamic effect to HeLa cells with IC50 of
4.3 µM and photocytotoxicity index ~10.23 The relative order of photocytotoxicity of the complexes
was 4>2>3>1 which was directly correlated to the singlet oxygen quantum yield of the complexes (1-4)
(Table 1).We observed remarkably reduced dark toxicity of the complexes (1-4) unlike other copper (II)
complexes in previous findings [24-28]. Dark-toxicity of the copper (II) complexes was related to the
facile redox chemistry of the complexes in biological redox window. However, reduction potential of
13

the complex 4 (E1/2 = -0.46 V) is far beyond the biological redox window to inhibit reduction of copper
(II) into copper (I) by cellular thiols and thereby not able to produce cytotoxic hydroxyl radical in dark
[46]. Reduction potential of Cu(II)/Cu(I) couple in aqueous DMF was high enough for glutathione to
reduce Cu(II) into Cu(I) of complex 4. This was confirmed by UV-visible spectral titration of the
complex 4 in aqueous DMSO against increasing concentration of glutathione (Figure S18). This resulted
in reducing the dark-toxicity and enhanced photocytotoxicity index >19.
3.10. In vitro ROS generation
Quantification of intracellular ROS (1O2) generation was probed in our present study by flow cytometric
analysis (FACS) on HaCaT cancer cells using non-polar cell permeable 2′,7′-dichlorofluorescein
diacetate (DCFH-DA) dye (Figure S19)[48].The dye after hydrolysis by the intracellular esterase, was
converted into highly green fluorescent 2′,7′-dichlorofluorescein (DCF) (λem = 525 nm) on oxidation by
intracellular ROS or ROS generated in situ, emitting green light. Degree of photocytotoxicity of the
complexes (1-4) was due to their ability to generate singlet oxygen (1O2) on photosensitization. Increase
or shift in the fluorescence intensity was the measure of ROS generation. A change in fluorescence
intensity of the HaCaT cells treated with the complexes 1 and 4 (5 µM) upon visible light exposure
(400-700 nm, 10 Jcm-2, 1 h) compared to the HaCaT cell alone gave us the measure of intensity of ROS
generation. Complexes showed enhancement in the fluorescence intensity of DCF upon light compared
to dark. We observed negligible shift in the fluorescence intensity of DCF in HaCaT cells treated with
the complex 4 in dark while greater shift in fluorescence band of DCF was observed for HaCaT cells
treated with the complex 4 in visible light. The result predicted the photo-activated generation of 1O2 as
ROS in vitro as the key cytotoxic species.
3.11. Apoptosis
14

It was very important to explore the nature of ROS-induced cell death. Apoptosis is a programmed cell
death and unlike necrosis, does not induce any host immune response and toxic effects to the
surrounding normal tissues. Therefore, apoptosis is more desirable cell death process for clinical
applications. We performed Annexin-V-FITC/PI assay using flow cytometry to characterize the cell
death process (Figure 7, Figure S20). Annexin-V-FITC/PI assay is based on the ability of Annexin- V to
bind to phosphatidylserine which is a marker of apoptosis when it is on the outer leaflet of the plasma
membrane. The single positive population has cells that are in early apoptosis and double positive
population has cells that are in late apoptosis with compromised cell membrane. When most active
complex 4 (5μM) treated with HaCaT cells, it was observed that the 65% in late apoptotic in visible
light and 21% in dark respectively [49].
4. Conclusions
Overall, we prepared four new anthraquinone-based copper (II) complexes to explore singlet oxygen
(1O2) mediated in vitro photodynamic activity to HaCaT and MCF-7 cells. The complexes exhibited
reduced dark toxicity (IC50> 50 µM). We probed in vitro ROS generation on photo-activation of the
complexes that was leading to late apoptosis in HaCaT cells. We focused on the structural aspects of the
complexes in modulating the toxicity in dark and in visible light. Based on the results obtained by
photo-physical studies and TD-DFT calculations for the photo-activated complexes, we predicted a type
II photo-process leading to the generation of singlet oxygen (1O2) from 3O2 by energy transfer. Presence
of relatively low-lying, long-lived triplet excited states for the complexes led to facile energy transfer to
triplet oxygen (3O2) to generate (1O2). Low energy gap (0.19 eV) between D1 and T1 facilitating faster
intersystem crossing to sufficiently long-lived triplet excited state (T1) (τ, 11.7 ns), efficient quenching
of T1 by 3O2 to generate 1O2 ((1O2), 0.6) and remarkable photo-cytotoxicity (IC50, 2.5 µM) has led the
complex 4 is of paramount importance in developing next-generation copper(II)-based PDT agents.
Acknowledgements
15

We thank the Science and Engineering Research Board, Government of India, New Delhi for financial
support [ECR-2016-000839/CS], Board of Research in Nuclear Science (BRNS), Govt. of India
(37(2)/14/18/2017-BRNS) and NIT Manipur for providing infrastructure. We sincerely thank Prof.
Akhil R. Chakravarty, IISc Bangalore for providing the facility of cellular studies. We thank Prof.
Abhijit Saha, UGC-DAE Consortium for Scientific Research, Kolkata for measuring luminescent decay
for the complexes. We also sincerely thank Mr. A. K. Srivastava for helping us to carry out cyclic
voltammetric study.
Electronic supplementary information (ESI):
IR, Q-TOF ESI mass and luminescence spectra of complexes; IR, UV-visible, luminescence spectra of
the complexes (1-4), cyclic-voltammetric plot; UV-visible spectral measurement using DPBF and Rose
Bengal with complexes; Steady state luminescence decay for the complexes; ROS generation studies;
cellular localization; Geometrically optimized structure of the complexes with HOMO-LUMO
stereographs; Cell viability assay and MTT plots; Annexin-VFITC/PI assay; Table on. IC50 values of
selected copper (II) complexes, selected UV–Vis energy transitions at the TD-DFT/B3LYP level,
cytotoxicity of the complexes in HaCaT and MCF -7 cells.
References
1. (a) D.E.Dolmans, D.Fukumura and R.K. Jain, Nat. Rev. Cancer.3(2003) 380-387. (b) A. P.
Castano, P. Mroz and M. R. Hamblin, Nat. Rev. Cancer.6(2006) 535–545.
2. (a)W. Fan, P. Huang and X. Chen, Chem. Soc. Rev. 45(2016) 6488–6519. (b) F.
Heinemann, J. Karges, and G. Gasser, Acc. Chem. Res.50(2017) 2727–2736.
3. (a) J. P. Celli, B. Q. Spring, I. Rizvi, C. L. Evans, K. S. Samkoe, S. Verma, B. W. Pogue
and T. Hasan, Chem. Rev.110(2010) 2795–2838. (b) J. D. Knoll, B. A. Albani and C.
Turro, Acc. Chem. Res.48(2015) 2280–2287. (c) J. M. Dąbrowski and L. G. Arnaut,
Photochem. Photobiol. Sci.14(2015) 1765–1780.
16

4. N. L. Oleinick, R. L. Morris and I. Belichenko, Photochem. Photobiol. Sci.1(2002) 1–21.
5. S. Bonnet, Dalt. Trans.47(2018) 10330–10343.
6. (a) M. Ochsner, J. Photochem. Photobiol. B Biol.32(1996) 3–9. (b) The data was obtained
from FDA (Food and Drug Administration), http://www.accessdata.fda.gov
/drugsatfdadocs/label/2008/020451s019lbl.pdf
7. A. Ormond and H. Freeman, Materials (Basel).6(2013) 817–840.
8. J. Mao, Y. Zhang, J. Zhu, C. Zhang and Z. Guo, Chem. Commun. 8(2009) 908-910.
9. S. S. Lucky, K. C. Soo and Y. Zhang, Chem. Rev.115(2015) 1990–2042.
10. M. Ethirajan, Y. Chen, P. Joshi and R. K. Pandey, Chem. Soc. Rev.40(2011) 340–362.
11. (a)M. K. Raza, K. Mitra, A. Shettar, U. Basu, P. Kondaiah, A. R. Chakravarty, Dalton
Trans. 45(2016) 13234-13243.(b) H. Ali and J. E. van Lier, Chem. Rev.99(1999) 2379–
2450.
12. (a) I. Romero-Canelón and P. J. Sadler, Inorg. Chem.52 (2013) 12276–12291. (b)N.J.
Farrer, L. Salassa and P. J. Sadler, Dalton. Trans. (2009) 10690-10701. (c) A. Garai, A.
Gandhi, V. Ramu,M. K. Raza, P. Kondaiah, A. R Chakravarty,ACS Omega3(2018) 9333-
9338.
13. (a) L. B. Josefsen and R. W. Boyle, Met.-Based Drugs. 2008(2008) 276109. (b) B.
Bertrand, K. Passador, C. Goze, F. Denat, E. Bodio and M. Salmain, Coord. Chem.
Rev.358(2018) 108–124.
14. U.Schatzschneider, Eur. J. Inorg. Chem.2010(2010)1451–1467.
15. A.R. Chakravarty and M. Roy, Prog. Inorg. Chem.57(2012) 119-202.
16. K. Szaciłowski, W. Macyk, A. Drzewiecka-Matuszek, M. Brindell and G. Stochel, Chem.
Rev.105(2005) 2647–2694.
17. U. Bhattacharyya, B. Kumar, A. Garai, A. Bhattacharyya, A. Kumar, S. Banerjee, P.
Kondaiah, A. R. Chakravarty, Inorg. Chem.56(2017) 12457-12468.
17

18. (a) U. Basu, I. Khan, A. Hussain, P. Kondaiah and A. R. Chakravarty, Angew. Chemie - Int.
Ed. 51(2012) 2658–2661. (b) A. Garai, I. Pant, S. Banerjee, B. Banik, P. Kondaiah, A. R.
Chakravarty, Inorg. Chem.55(2017) 6027–6035.
19. (a) S. Banerjee and A. R. Chakravarty, Acc. Chem. Res.48(2015) 2075–2083. (b) S.
Banerjee, A. Dixit, A. A. Karande and A. R. Chakravarty, Dalt. Trans.45(2016) 783–796.
20. S. B. Chanu, S. Banerjee and M. Roy, Eur. J. Med. Chem.125 (2017) 816–824.
21. A. K. Renfrew, E. S. O’Neill, T. W. Hambley and E. J. New, Coord. Chem. Rev. 2017.
(doi.org/10.1016/j.ccr.2017.11.027).
22. A. K. Renfrew, N. S. Bryce and T. W. Hambley, Chem. Sci.4(2013) 3731–3739.
23. S. Saha, R. Majumdar, M. Roy, R. R. Dighe and A. R. Chakravarty, Inorg. Chem.48(2009)
2652–2663.
24. (a) D. Musib, M. K. Raza, S. Kundu and M. Roy, Eur. J. Inorg. Chem.2018(2018) 2011-
2018. (b) D. Musib, S. Banerjee, A. Garai, U. Soraisam and M. Roy,
ChemistrySelect.3(2018) 2767–2775.
25. (a) C. Al Hageh, M. Al Assaad, Z. El Masri, N. Samaan, M. El-Sibai, C. Khalil and R. S.
Khnayzer, Dalt. Trans.47(2018) 4959–4967 (b) N. Mukherjee, S. Podder, S. Banerjee, S.
Majumdar, D. Nandi and A. R. Chakravarty, Eur. J. Med. Chem.122(2016) 497–509. (c) N.
Mukherjee, S. Podder, K. Mitra, S. Majumdar, D. Nandi and A. R. Chakravarty, Dalt.
Trans. (2018) 823–835.
26. R.-K. Lin, C.-I. Chiu, C.-H. Hsu, Y.-J. Lai, P. Venkatesan, P.-H. Huang, P.-S. Lai and C.-C.
Lin, Chem. Eur. J.24(2018) 4111–4120. (b) K. Laws, G. Bineva-Todd, A. Eskandari, C. Lu,
N. O’Reilly and K. A. Suntharalingam, Angew. Chem. Int. Ed.57(2018) 287–29.
27. (a) A. Bhattacharyya, A. Dixit, S. Banerjee, B. Roy, A. Kumar, A. A. Karande and A. R.
Chakravarty, RSC Adv.6(2016) 104474–104482. (b) R. Lin, C. Chiu, C. Hsu, Y. Lai, P.
Venkatesan, P. Huang, P. Lai and C. Lin, Chem. Eur. J. 24(2018) 4111-4120. (c) D. V.
18

Belykh, A. S. Kozlov, Y. I. Pylina, I. S. Khudyaeva, А. S. Benditkis and A. A. Krasnovsky,
Macroheterocycles. 12(2019) 68-74.
28. (a) T. K. Goswami, S. Gadadhar, M. Roy, M. Nethaji, A. A. Karande and A. R.
Chakravarty, Organometallics. 31(2012)3010–3021. (b) T. K. Goswami, B. V. S. K.
Chakravarthi, M. Roy, A. A. Karande and A. R. Chakravarty, Inorg. Chem. 50 (2011)
8452–8464. (c) B. Maity, M. Roy, B. Banik, R. Majumdar, R. R. Dighe and A. R.
Chakravarty, Organometallics.29(2010)3632–3641.
29. I. Ali, W. A. Wani, K. Saleem,, Metal-Organic, and Nano-Metal Chemistry.43 (2013) 1162-
1170.
30. E. M. Malik and C. E. Müller, Med. Res. Rev.36 (2016) 705-748.
31. X. Zhang, W. Zong, W. Cheng and X. Han, J. Met. Chem. B. 6 (2018) 5243-5247.
32. X. Qu, C. Wan, H. -C. Becker, D. Zhong and A. H. Zewail,Proc., Natl. Acad. Sci. U.S.A.98
(2001) 14212-14217.
33. S. C. N. Montoya, L. R. Comini, M. Sarmiento, C. Becerra, I Albesa, G. A. Argüello, J. L.
Cabrera, J. Photochem. Photobiol. B: Biology.78(2005) 77-83.
34 D. D. Perrin, W. L. F. Armarego and D. R. Perrin, Purification of Laboratory Chemicals,
Pergamon Press, Oxford, 1980.
35 (a) S. Durmus, B. M. Ates, O. Atakol, F. Ercan, and Z. Kristallogr.220 (2005) 973-976. (b)
M. Aksu, S. Durmus, M.Sarı, K. C. Emregul, I. Svoboda, H. Fuess and O. Atakol, J. Therm.
Anal. Calorim. 90 (2007) 541-547. (c) A. Soliman and G. G. Mohamed, Thermochim. Acta.
421(2004) 151-159.
36 (a) N. Dupont, Y.F. Ran, H.P. Jia, J. Grilj, J. Ding, S.X. Liu, S. Decurtins and A.
Hauser,Inorg. Chem.50(2011) 3295-3303. (b) C. J. Moody, C. W. Rees and R. Thomas,
Tetrahedron.48(1992) 3589-4628. (c) R. Lopez, B. Loeb, T. Boussie and T. J. Meyer,
Tetrahedron Lett.37 (1996) 5437-5440.
19

37 (a) M. Steiner and A. Duerkop, Analyst.136(2011) 148-154. (b) D. M. Murphy, K.
McNamara, P. Richardson, V. Sanchez-Romaguera , R. E. P. Winpenny and L. J.
Yellowlees, Inorg. Chim. Acta.374(2011) 435-441.
38 A. Bhunia, S. Manna, S. Mistri, A. Paul, R. K. Manne, M. Kumar Santra, V. Bertolasi and
S. C. Manna, RSC Adv. 5 (2015) 67727-67737.
39 K. Nakamoto, Infrared and Raman Spectra of Inorganic and Coordination Compounds: Part
A: Theory and Applications in Inorganic Chemistry, 6th Ed., 2008, John Wiley & Sons,
Inc.(ISBN: 9780471743392).
40 J. Sun, F. Zhong, X. Yi and J. Zhao, Inorg. Chem. 52 (2013) 6299–6310.
41 T. N. Singh-Rachford, F. N. Castellano, Coord. Chem Rev. 254(2010) 2560-2573.
42 J. Zhao, S. Ji and H. Guo, RSC Adv. 1(2011) 937-950.
43 W. Wu, J. Zhao, H. Guo, J. Sun, S. Ji and Z. Wang, Chem. - A Eur. J.18(2012)1961–1968.
44 J. E. Yarnell,A.Chakraborty,M. Myahkostupov,K. M. Wrightand F. N. Castellano, Dalton
Trans.2018(doi:10.1039/C8DT02496K).
45 (a) M. J. Frisch, G. W. Trucks, H. B. Schlegel, G. E. Scuseria, M. A. Robb, J. R.
Cheeseman, G. Scalmani, V. Barone, B. Mennucci, G. A. Petersson, H. Nakatsuji, M.
Caricato, X. Li, H. P. Hratchian, A. F. Izmaylov, J. Bloino, G. Zheng, J. L. Sonnenberg, M.
Hada, M. Ehara, K. Toyota, R. Fukuda, J. Hasegawa, M. Ishida, T. Nakajima, Y. Honda, O.
Kitao, H. Nakai, T. Vreven, J. A. Montgomery Jr., J. E. Peralta, F. Ogliaro, M. Bearpark, J.
J. Heyd, E. Brothers, K. N. Kudin, V. N. Staroverov, R. Kobayashi, J. Normand, K.
Raghavachari, A. Rendell, J. C. Burant, S. S. Iyengar, J. Tomasi, M. Cossi, N. Rega, J. M.
Millam, M. Klene, J. E. Knox, J.B. Cross, V. Bakken, C. Adamo, J. Jaramillo, R. Gomperts,
R. E. Stratmann, O. Yazyev, A. J. Austin, R. Cammi, C. Pomelli, J. W. Ochterski, R. L.
Martin, K. Morokuma, V. G. Zakrzewski, G. A. Voth, P. Salvador, J. J. Dannenberg, S.
Dapprich, A. D. Daniels, O. Farkas, J. B. Foresman, J. V. Ortiz, J. Cioslowski, and D. J.
Fox,Gaussian 09, 2009, Rev. A.02. Gaussian, Inc., Wallingford; D. D. Roy, A. K. Todd,
20

and M. M. John, Gauss View 5.0.8., 2009, Gaussian, Inc., Wallingford; A. D. Becke,
J.Chem. Phy.98(1993) 5648. (b) GaussView 5.0 (Gaussian Inc., Wallingford, CT, USA),
2009.
46 D. S. Sigman, A. Mazumdar and D. M. Perrin, Chem. Rev.93(1993) 2295-2316.
47 M. K.Raza,S. Gautam,P. Howlader,A. Bhattacharyya,P.Kondaiah,and A. R.
Chakravarty,Inorg. Chem. 57(2018) 14374-14385.
48 (a) B. Ali, M. A. Iqbal, ChemistrySelect.2 (2017) 1586-1604. (b) L. B. Josefsen, R. W.
Boyle, Met. Based Drugs. 154(2008) 1-3.
49 M. K. Raza, S. Gautam, A. Garai, K. Mitra, P. Kondaiah, A. R Chakravarty,Inorg. Chem.
56(2017) 11019-11029.
Table 1. Selected photophysical data for the complexes (1–4).
Complexes
ex/nm
1
2
3
4
394(127), 660(67)
404(945),
650(350)
421(212),
610(174)
397(971),
670(189)
( / Lmol-1cm-1)[a]
em / nm[b]
452
443
400
518

Ф[c]
-
0.157
-
0.042
0.34
11.3
-
0.292
-
0.0562
0.629
11.7
Ф(1O2)[d]
τL/RT(ns)[e]
[a]10% v/vH2O-DMSO at 20 °C; [b]10% v/vH2O-DMSO at 20 °C; [c]fluorescence quantum yields of
the complexes in MeOH and anthracene (ΦF, 0.27 in ethanol) as standard; [d]singlet oxygen quantum
yield of the complexes with DPBF and Rose Bengal as standard in DMSO at 20 °C; [e]Luminescence
lifetime of the complexes in MeOH at RT[ex (laser), 375 nm].
21

Table2.Selected lowlying excited states, Calculated Energies (E), and Dominant Orbital Excitation from
TDDFT Calculations for all Cu(II) complexes lowlying doublet and triplet state Calculated at
TDDFT/B3LYP/631G(d,p)/LanL2DZ level.
State
Orbital excitation
Character
-E[a] (a.u)
1
2
3
4
T1
D1
T1
D1
T1
D1
T1
D1
HOMO3(β)-LUMO1(β)(97%)
HOMO1(β)-LUMO5(β)(28%)
HOMO 4(β)-LUMO(β)(25%)
HOMO1(β)-LUMO2(β)(96%)
HOMO2(β )-LUMO2(β)(40%)
HOMO(β)-LUMO3(β)(40%)
HOMO6(β)-LUMO(β)(31%)
HOMO2(β)-LUMO2(β)(46%)
MLCT
MLCT
1408.4681
1408.4456
2279.3424
2279.3296
1722.9072
1722.8741
2517.1343
2517.1279
ILCT/MLCT
MLCT
ILCT/MLCT
ILCT/MLCT
ILCT
MLCT
[a]The energy value corresponds to the absolute energy of the respective states.
Table 3. Cytotoxicity data (IC50/µM) of the complexes in dark and on visible light exposure
Complexes
HaCaT Cell line
MCF-7 Cell line
IC50 / µM
IC50 / µM
Dark[a]
Light[b]
Photo-
Dark[a]
Light[b]
Photo-
cytotoxicity
index(PI)
index(PI)
44.45
(±4.32)
7.56(±0.14)
5
26.81
(±2.16)
4.53
(±0.32)
5
1
>50.0
>50.0
6.81(±0.21)
>7
>4
33.15
(±1.18)
3.81
(±0.13)
10
6
2
3
11.56(±0.35)
36.43
(±4.27)
5.45
(±0.23)
>50.0
ND
2.57(±0.30)
ND
>19
>50.0
3.03
(±0.25)
>16
4
Cu(OAc)2.H2O
>50.0
>50.0
L3
L4
ND
ND
ND
ND
>50.0
>50.0
>50.0
>50.0
[a]IC50 values correspond to 24 h incubation in dark. [b]IC50 values correspond to 4 h incubation in the dark
followed by 1 h photo exposure to visible light (400-700 nm,10 J cm-2, post incubation 19 h). ND: Not
determined
22

OH
O
O
N
N
L1
N
N
CuII
N
N
N
CuII
S
SH
S
1, 2
3, 4
O
N
N
N
N
N
N
N
OH
O
L2
=
N
N
SH
L3
L4
Scheme 1. Schematic representation of the complexes [Cu(L1)B] (1-2) and [Cu(L2)B] (3-4), where L1 =
2-(2-mercaptophenylimino)methyl)phenol, L2
butylphenol and B= 1,10-phenanthroline (L3) and anthraquinyl-dipyridoquinoxaline (L4).
=
2-(2- mercaptophenylimino)methyl)-4,6-di-tert-
23

Figure 1. UV-visible spectra of the complexes 1 - 4 in 10% (v/v) H2O-DMSO. Inset showed d-d
bands.
Figure 2. Schematic representation of type-II photo-processes in complexes (1-4).
24

Figure 3. Isosurfaces of the spin density of the complexes (1-4) at the optimized T1 excited-state
geometry (isovalue ± 0.0004) calculated at the Calculated at TD-DFT//B3LYP/6-31G(d)/LanL2DZ
level in gas phase with Gaussian 09W.
25

Figure 4. FACS analysis on quantitative cellular uptake of L3, L4 and complexes 1, 4 in HaCaT cells,
with cells untreated as a control. The shift in the band position of the complexes 1, 4 in HaCaT cells
indicates that the complexes have a higher cellular uptake compared to their free ligands L3, L4.Color
legends are shown in the figure.
Figure 5. Confocal images of HaCaT cells. (a) Bright field images; (b) HaCaT cells stained with
nuclear localizing dye (DAPI); (c) HaCaT cells treated with the complex 4 (15µM); (d) merged image
indicating nuclear localization of complex 4.
26

Figure 6. Bar diagram depicting the PDT effect of the complexes (1-4) in MCF-7 breast cancer and
HaCaT skin keratinocyte cells in refrence to IC50 values determined from MTT assay [Visible Light:
400-700 nm, 10 Jcm-2, Photo-irradiation Time: 1 h ].
27

Figure 7. Annexin-V-FITC/PI assay showing the percent population of early apoptotic cells stained by
annexin-V-FITC alone (lower right quadrant), dead cells stained by propidium iodide alone (upper left
quadrant), or late apoptotic cells stained by both Annexin-V-FITC and PI (upper right quadrant) in
HaCaT cells alone or treated with complex4 in the dark (D) or after exposure to visible light (400− 700
nm, 10 Jcm-2).
28

Nucleus targeting anthraquinone-based copper(II)
complexes as the potent PDT agents: Synthesis, photo-
physical and theoretical evaluation
Longjam Reena Devi,† Md Kausar Raza‡, Vanitha Ramu‡, Dulal Musib,†, Joshila Devi† and
Mithun Roy*,†
†Department of Chemistry, National Institute of Technology, Manipur, Langol 795004, Imphal
(Manipur), India
‡Department of Inorganic and Physical Chemistry, Indian Institute of Science, Bangalore 560012
(India)
Synopsis: The present work explored structural aspects of copper (II) complexes for PDT of copper-
based photo-chemotherapeutics. Nucleus targeting complexes have shown remarkable cytotoxicity in
visible-light to HaCaT cells (IC50 ~ 2-11 µM) with significantly reduced dark toxicity (IC50>50 µM)
unlike other copper (II) complexes.
1
Table of Content Text: The present work explored nuclear localization; O2 mediated in vitro photo-
cytotoxicity with reduced dark toxicity of the anthraquinone-based copper (II) complexes.
Contents Fig.
29
