Palladium-Catalyzed [4+2] and [5+2] Annulation for the Synthesis of Tetrahydroquinolines and 1,4-Benzoxazepines

Article abstract of DOI:10.1002/ejoc.202000262

Palladium-catalyzed [4+2] and [5+2] annulations of propargyl carbonates with malonate-tethered anilines and 2-aminobenzylic alcohols were developed, giving the corresponding tetrahydroquinolines and 1,4-benzoxazepines, respectively, in good to excellent yields.

Full text of DOI:10.1002/ejoc.202000262

European Journal of Organic Chemistry
Accepted Article
Accepted Article
Title: Palladium-Catalyzed [4+2] and [5+2] Annulation for the Synthesis
of Tetrahydroquinolines and 1,4-Benzoxazepines
Authors: Zhao-Fei Zhang, Yan Zhang, Chun-Lin Zhang, and Song Ye
This manuscript has been accepted after peer review and appears as an
Accepted Article online prior to editing, proofing, and formal publication
of the final Version of Record (VoR). This work is currently citable by
using the Digital Object Identifier (DOI) given below. The VoR will be
published online in Early View as soon as possible and may be different
to this Accepted Article as a result of editing. Readers should obtain
the VoR from the journal website shown below when it is published
to ensure accuracy of information. The authors are responsible for the
content of this Accepted Article.
To be cited as: Eur. J. Org. Chem. 10.1002/ejoc.202000262
Link to VoR: https://doi.org/10.1002/ejoc.202000262
01/2020

10.1002/ejoc.202000262
European Journal of Organic Chemistry
COMMUNICATION
Palladium-Catalyzed [4+2] and [5+2] Annulation for the Synthesis
of Tetrahydroquinolines and 1,4-Benzoxazepines
Zhao-Fei Zhang,[a],[b] Yan Zhang,[a] Chun-Lin Zhang,*,[a] and Song Ye*,[a],[b]
[a]
Dr. Z.-F. Zhang, Y. Zhang, Dr. C-L. Zhang, S. Ye
Beijing National Laboratory for Molecular Sciences, CAS Key Laboratory of Molecular Recognition and Function, Institute of Chemistry, Chinese Academy
of Sciences, 100190 Beijing, China
E-mail: zhangchunlin@iccas.ac.cn; songye@iccas.ac.cn
Dr. Z.-F. Zhang, S. Ye
[b]
University of Chinese Academy of Sciences, Beijing 100049, China.
Supporting information for this article is given via a link at the end of the document.((Please delete this text if not appropriate))
Abstract: Palladium-catalyzed [4+2] and [5+2] annulations of
propargyl carbonates with malonate-tethered anilines and 2-
aminobenzylic alcohols were developed, giving the corresponding
tetrahydroquinolines and 1,4-benzoxazepines, respectively, in good
to excellent yields.
Tetrahydroquinoline and benzoxazepine derivatives are
ubiquitous structural motifs in numerous bioactive products and
pharmaceuticals (Figure 1).[1] Consequently, significant attention
has been devoted to the synthesis of these molecules. Many
synthetic methods for tetrahydroquinolines have been developed,
including hydrogenation of quinolines,[2] aza-Diels-Alder
reactions,[3] and Reissert-type reactions.[4] Benzoxazepines can
be accessed by Beckmann or Schmidt rearrangements,[5]
transition-metal catalyzed cross-coupling.[6]
Scheme 1. Palladium catalyzed annulations for the synthesis of
tetrahydroquiolines and 1,4-benzoxazepines.
The model reaction of malonate-tethered aniline 1a and
propargyl carbonate 2a was investigated under palladium
catalysis (Table 1). We were happy to find the desired [4+2]
annulation product 3a was formed in 62% NMR yield when the
reaction was carried out using 10 mol% Pd2dba3•CHCl3 and 20
mol% DPPF as the catalyst and ligand at 80 oC in toluene (entry
1). A series of bisphophine ligands were then screened (entries
2-7) and DPPP performed best to give 3a in 92% yield (entry 3).
o
Lowering the reaction temperature to 40 C decreased the yield
(entry 8). Screening of the solvent revealed that 1,4-dioxane was
the best of choice, giving 3a in near-quantitative yield (entries 8-
10). The excellent yield (99%) was kept when the loading of
palladium catalyst was reduced to 3 mol% (entry 11). Further
reducing of the loading of Pd catalyst to 1 mol% resulted in
decreased yield (70%, entry12). Other typical metal complex,
such as Pd(OAc)2, [Pd(η3-C3H5)Cl]2 and Ni(cod)2 could not give
better results (entries 13-15). Control experiments revealed that
the reaction did not occur in the absence of palladium or ligand
(entries 16-17).
Figure 1. Selected biologically active tetrahydroquinolines and 1,4-
benzazepines.
The
palladium-catalyzed
cyclization
of
propargylic
compound,[7] particularly of propargylic carbonates,[8] via the key
intermediate of π-propargyl palladium has been well developed
for the synthesis of various cyclic compounds. In this paper, we
reported a palladium-catalyzed [4+2] annulation of propargylic
carbonates with malonate-tethered anilines[9] to give
tetrahydroquinoline (Scheme 1, reaction a). The corresponding
[5+2] annulation of propargylic carbonates with 2-aminobenzylic
alcohols to give 1,4-benzoxazepines was also realized (Scheme
1, reaction b).
1
This article is protected by copyright. All rights reserved.

10.1002/ejoc.202000262
European Journal of Organic Chemistry
COMMUNICATION
Table 1. Optimization of the Reaction Conditions. [a]
Entry
1
[M]
Ligand
DPPF
DPPE
DPPP
DPPB
Xantphos
DPEphos
XPhos
DPPP
DPPP
DPPP
DPPP
DPPP
DPPP
DPPP
DPPP
DPPP
/
Solvent
toluene
toluene
toluene
toluene
toluene
toluene
toluene
toluene
THF
Yield (%)[b]
Pd2dba3·CHCl3
Pd2dba3·CHCl3
Pd2dba3·CHCl3
Pd2dba3·CHCl3
Pd2dba3·CHCl3
Pd2dba3·CHCl3
Pd2dba3·CHCl3
Pd2dba3·CHCl3
Pd2dba3·CHCl3
Pd2dba3·CHCl3
Pd2dba3·CHCl3
Pd2dba3·CHCl3
Pd(OAc)2
62
89
92
80
24
31
24
70
98
>99
2
Scheme 2. Synthesis of tetrahydroquinolines 3.
3
4
With the optimized condition in hand, a series of malonate-
tethered anilines was then tested for the palladium catalyzed
[4+2] annulation reaction (Scheme 2). It was found that the N-
benzenesulfonyl group worked as well as the N-tosyl group,
giving the corresponding tetrahydroquinoline (3b) in high yield.
Besides diethyl, dimethyl malonate-tethered anilines worked as
well (3c), while diisopropyl malonate resulted in some decreased
yield (3d). Both electron-donating groups and electron-
withdrawing groups were well tolerated on the anilines, giving
the corresponding products (3e-3i) in good to high yields.
Interestingly, the malonate-tethered 2-aminopyridine (1j) worked
as well to give the corresponding tetrahydronaphthyridine 3j in
good yield, which is a core structure for various bioactive
compounds.[10]
5
6
7
8c
9
10
11[d]
12[f]
13[d]
14[d]
15[d]
16
17
dioxane
dioxane
dioxane
dioxane
dioxane
dioxane
dioxane
dioxane
>99 (98[e]
)
70[e]
37
70
10
0
[Pd(η3-C3H5)Cl]2
Ni(cod)2
/
Pd2dba3·CHCl3
0
Scheme 3. Synthesis of benzazepine 5.
[a] Reaction condition: 1a (0.2 mmol, 83.0 mg), 2a (0.26 mmol, 40 L),
Cs2CO3 (0.2 mmol), Pd2dba3•CHCl3 (0.02 mmol), ligand (0.04 mmol), N2
atmosphere. [b] NMR yield using 1,3,5-trimethoxybenzene as an internal
standard. [c] The reaction was conducted at 40 oC. [d] 3 mol % [M] and 6
mol % ligand were used. [e] Isolated yield. [f] 1 mol% [M] and 2 mol% ligand
were used.
The [5+2] annulation of malonate-tethered aniline 4 with one
more carbon linkage was also carried out in the standard
conditions, which afforded the desired benzazepine 5 in 81%
yield (Scheme 3).
Scheme 4. Synthesis of 1,4-benzoxazepines 7.
2
This article is protected by copyright. All rights reserved.

10.1002/ejoc.202000262
European Journal of Organic Chemistry
COMMUNICATION
The investigation was continued by using 2-amino benzyl
alcohol 6 as the 1,5-bisnucleophile for the reaction, which led to
synthesis of the corresponding 1,4-benzoxazepines (7a-7e) in
good yields (Scheme 4).[11]
Scheme 5 Synthesis of piperazines
In addition, the reaction of benzene-1,2-diamine and ethane-
1,2-diamine worked well for the reaction, giving the
corresponding piperazines 8a and 8b, respectively, in good
yields (Scheme 5).[8h]
Scheme 6. Further chemical transformations.
The resulted highly functionalized tetrahydroquinolines
affords many possible further chemical transformations. For
example, the N-tosyl group in compound 3c could be removed
by Mg/MeOH (Scheme 6, reaction a). Compound 3f could
readily undergo the cross-coupling reactions with phenylboronic
acid and aniline to give the corresponding products 10 and 11,
respectively, in good to high yields.[13]
The structure of compound 3c was determined by X-ray
analysis of its single crystal (Figure 2).[12]
In summary, the palladium-catalyzed [4+2] and [5+2]
annulations of propargyl carbonate with malonate-tethered
anilines and 2-aminobenzylic alcohol were developed, giving the
corresponding tetrahydroquinolines and 1,4-benzoxazepines,
respectively, in good to high yields. The reaction features ready
available starting materials, efficient construction of six- and
seven-membered heterocycles with potential bioactivities.
Acknowledgements ((optional))
This work was supported by Beijing National Laboratory for
Molecular Sciences (BNLMS-CXXM-202003), the National
Natural Science Foundation of China (Nos 21521002,
21831008).
Figure 2. X-ray structure of 3c
Keywords: Tetrahydroquinolines • 1,4-Benzoxazepines •
Annulation • Palladium Catalysis • Propargyl carbonates
[1] a) H. L. Yale, B. Beer, J. Pluscec, E. R. Spitzmiller, J. Med. Chem.
1970, 13, 713; b) J. Bonjoch, D. Solé, Chem. Rev. 2000, 100,
3455; c) F. Zhu, Y. Du, J. Chen, B. Chen, Y. Zhu, X. Zhai, S. Xu,
W. Zhou, Chromatographia 2009, 69, 1315; d) V. Sridharan, P. A.
Suryavanshi, J. C. Menéndez, Chem. Rev. 2011, 111, 7157; e) L.
Chen, P. T. Wilder, B. Drennen, J. Tran, B. M. Roth, K. Chesko, P.
Shapiro, S. Fletcher, Org. Biomol. Chem. 2016, 14, 5505; f) Z.-L.
Zang, S. Karnakanti, S. Zhao, P. Hu, Z. Wang, P.-L. Shao, Y. He,
Org. Lett. 2017, 19, 1354.
Scheme 6. Scale up reaction.
The reaction could be easily scaled up to 3.0 mmol, giving
the tetrahedroquinoline 3c in 1.19 g, 96% yield (Scheme 6).
[2] a) W.-B. Wang, S.-M. Lu, P.-Y. Yang, X.-W. Han, Y.-G. Zhou, J.
Am. Chem. Soc. 2003, 125, 10536; b) M. Rueping, A. P.
Antonchick, T. Theissmann, Angew. Chem. Int. Ed. 2006, 45,
3683; c) Z.-Y. Han, H. Xiao, X.-H. Chen, L.-Z. Gong, J. Am. Chem.
3
This article is protected by copyright. All rights reserved.

10.1002/ejoc.202000262
European Journal of Organic Chemistry
COMMUNICATION
Soc. 2009, 131, 9182; d) T. Wang, L.-G. Zhuo, Z. Li, F. Chen, Z.
Ding, Y. He, Q.-H. Fan, J. Xiang, Z.-X. Yu, A. S. C. Chan, J. Am.
Chem. Soc. 2011, 133, 9878; e) X.-F. Cai, W.-X. Huang, Z.-P.
Chen, Y.-G. Zhou, Chem. Commun. 2014, 50, 9588; f) Á.
Vivancos, M. Beller, M. Albrecht, ACS Catal. 2018, 8, 17.
[3] a) D. Keck, S. Vanderheiden, S. Bräse, Eur. J. Org. Chem. 2006,
2006, 4916; b) G. Dagousset, J. Zhu, G. Masson, J. Am. Chem.
Soc. 2011, 133, 14804.
[4] a) M. Takamura, K. Funabashi, M. Kanai, M. Shibasaki, J. Am.
Chem. Soc. 2001, 123, 6801; b) Z. Sun, S. Yu, Z. Ding, D. Ma, J.
Am. Chem. Soc. 2007, 129, 9300.
[5] G. L. Grunewald, V. H. Dahanukar, P. Ching, K. R. Criscione, J.
Med. Chem. 1996, 39, 3539.
[6] a) B. H. Yang, S. L. Buchwald, Org. Lett. 1999, 1, 35; b) Z. Xu, K.
Li, R. Zhai, T. Liang, X. Gui, R. Zhang, RSC Adv. 2017, 7, 51972.
[7] a) J.-R. Labrosse, P. Lhoste, D. Sinou, Org. Lett. 2000, 2, 527; b)
S. Wang, L. Zhang, J. Am. Chem. Soc. 2006, 128, 8414; c) S.
Wang, L. Zhang, J. Am. Chem. Soc. 2006, 128, 14274; d) H.-P. Bi,
X.-Y. Liu, F.-R. Gou, L.-N. Guo, X.-H. Duan, X.-Z. Shu, Y.-M.
Liang, Angew. Chem. Int. Ed. 2007, 46, 7068; e) L.-N. Guo, X.-H.
Duan, X.-Y. Liu, J. Hu, H.-P. Bi, Y.-M. Liang, Org. Lett. 2007, 9,
5425; f) N. Marion, S. P. Nolan, Angew. Chem. Int. Ed. 2007, 46,
2750; g) H. Ohno, A. Okano, S. Kosaka, K. Tsukamoto, M. Ohata,
K. Ishihara, H. Maeda, T. Tanaka, N. Fujii, Org. Lett. 2008, 10,
1171; h) A. Furstner, Chem. Soc. Rev. 2009, 38, 3208; i) L.-N.
Guo, X.-H. Duan, Y.-M. Liang, Acc. Chem. Res. 2011, 44, 111.
[8] a) M. Yoshida, M. Fujita, T. Ishii, M. Ihara, J. Am. Chem. Soc.
2003, 125, 4874; b) M. Yoshida, M. Higuchi, K. Shishido, Org. Lett.
2009, 11, 4752; c) M. Yoshida, C. Sugimura, K. Shishido, Org. Lett.
2011, 13, 3482; d) M. Yoshida, S. Ohno, K. Namba, Angew. Chem.
Int. Ed. 2013, 52, 13597; e) M. Yoshida, C. Sugimura, Tetrahedron
Lett. 2013, 54, 2082; f) T. D. Montgomery, A. E. Nibbs, Y. Zhu, V.
H. Rawal, Org. Lett. 2014, 16, 3480; g) A. E. Nibbs, T. D.
Montgomery, Y. Zhu, V. H. Rawal, J. Org. Chem. 2015, 80, 4928;
h) T. D. Montgomery, V. H. Rawal, Org. Lett. 2016, 18, 740; i) L.
Ding, R.-D. Gao, S.-L. You, Chem. Eur. J. 2019, 25, 4330; j) X.-L.
Min, X.-R. Xu, Y. He, Org. Lett. 2019, 21, 9188; k) A. Kawase, H.
Omura, T. Doi, H. Tsukamoto, Chem. Lett. 2019, 48, 1402.
[9] a) G. Kang, M. Yamagami, S. Vellalath, D. Romo, Angew. Chem.
Int. Ed. 2018, 57, 6527; b) S. Denis, K. Boguslaw, L. Paul, D.
Norbert, Lett. Org. Chem. 2006, 3, 371.
[10] a) M. A. Seefeld, W. H. Miller, K. A. Newlander, W. J. Burgess,
W. E. DeWolf, P. A. Elkins, M. S. Head, D. R. Jakas, C. A. Janson,
P. M. Keller, P. J. Manley, T. D. Moore, D. J. Payne, S. Pearson, B.
J. Polizzi, X. Qiu, S. F. Rittenhouse, I. N. Uzinskas, N. G. Wallis,
W. F. Huffman, J. Med. Chem. 2003, 46, 1627; b) J. Wang, M. J.
Breslin, P. J. Coleman, M. E. Duggan, C. A. Hunt, J. H.
Hutchinson, C.-T. Leu, S. B. Rodan, G. A. Rodan, L. T. Duong, G.
D. Hartman, Bioorg. Med. Chem. Lett. 2004, 14, 1049; c) T.-g.
Nam, C. L. Rector, H.-y. Kim, A. F. P. Sonnen, R. Meyer, W. M.
Nau, J. Atkinson, J. Rintoul, D. A. Pratt, N. A. Porter, J. Am. Chem.
Soc. 2007, 129, 10211.
[11] a) M. Yar, E. M. McGarrigle, V. K. Aggarwal, Org. Lett. 2009, 11,
257; b) S. M. Lynch, L. Tafesse, K. Carlin, P. Ghatak, B. Shao, H.
Abdelhamid, D. J. Kyle, Bioorg. Med. Chem. Lett. 2015, 25, 48.
[12] CCDC 1994587 (3c) contains the supplementary
crystallographic data for this paper.
[13] a) C. Liu, M. Szostak, Angew. Chem. Int. Ed. 2017, 56, 12718;
b) Y. Wang, C. Zheng, S.-L. You, Angew. Chem. Int. Ed. 2017, 56,
15093.
4
This article is protected by copyright. All rights reserved.

10.1002/ejoc.202000262
European Journal of Organic Chemistry
COMMUNICATION
Entry for the Table of Contents
Key Topic: N-heterocycles Synthesis
A general strategy for the synthesis of tetrahydroquinolines and 1,4-benzoxazepines has been developed via palladium-catalyzed
[4+2] and [5+2] annulations of propargyl carbonates with malonate-tethered anilines and 2-aminobenzylic alcohols. A series of six-
and seven-membered heterocycles with potential bioactivities was obtained in good to excellent yields.
Institute and/or researcher Twitter usernames: ((optional))
5
This article is protected by copyright. All rights reserved.
