Fig. 2 Typical (a) output and (b) transfer curves for 8 solution
deposited from 0.5% w/w toluene at RT on OTS-treated SiO2.
Fig. 1 Molecular packing of 8 (a) and 9 (b) illustrating the packing
and p–p overlap.
long, were thermally evaporated, at 10ꢀ6 mBar, until a layer
thickness of 50 nm was obtained, yielding 9 transistors per
substrate. Gold was chosen since its work function, 5.1 eV,
closely matches the HOMO level of 8 and 9.
conjugated pentacene backbones of 3.48
A similar to
TIPSP.5,6 Although the interplanar distances are similar for
both 8 and 9, there is significant difference in the extent of
fused rings backbone overlap, with 9 being similar to TIPSP
whereas 8 shows a significantly greater overlap (Fig. 1). AFM
confirms the large difference in packing between 8 and 9
(ESIw). 8 is able to form a nearly continuous film when drop
cast from toluene solution onto an OTS modified silica
surface, whereas 9 wets only partially. Tapping mode of a
thin film of 8 reveals atomic steps of about 1.77 nm, indicating
that the molecule packs almost vertically to the substrate in an
atomic layer.
Compound 8 shows very high on/off ratios in excess of 107,
with maximum mSAT = 2.5 cm2 Vꢀ1 sꢀ1 (Fig. 2) and with
negligible hysteresis and stable low threshold voltage. This
device was one of the group of 9 OTFTs fabricated, the
mobility range being 0.6 to 2.5 cm2 Vꢀ1
mobility of 1.3 cm2 Vꢀ1 sꢀ1 and a standard deviation of
0.4 cm2 Vꢀ1
s
ꢀ1, with an average
s
ꢀ1. Compound 9 exhibits a maximum mSAT of
about 4 ꢂ 10ꢀ4 cm2 Vꢀ1 sꢀ1, due to poor film quality and less
favourable charge injection. Under equivalent conditions
TIPSP18 drop cast devices exhibit discontinuous film
Molecular orbital levels of 8 and 9 were measured using
cyclic voltammetry in acetonitrile, and UV-vis performed in
solution and of thin films (ESIw). Whilst the limitations of this
methodology are recognised, we are unable to determine the
reduction onset by CV since both materials undergo decom-
position on reduction. Results are summarised in Table 1.
It is known that charge transport in disordered crystalline
semiconductor obeys a semi-classical hopping charge transfer
theory,15 with factors such as translation along the short axis
and ring orientation influencing dramatically the electronic
performance of the electronic semiconductor.16 It has been
shown that increasing the extent of p–p overlap can result in
an increase in hole mobility at the same p–p stacking
distance.17 Since 8 shows a higher degree of p–p overlap and
the same p–p stacking distance of the conjugated backbone as
both 9 and TIPSP then a higher hole mobility would be
anticipated.
structures and gave maximum mSAT of B10ꢀ3 cm2 Vꢀ1 sꢀ1
.
To conclude, we have shown that 1,4,8,11-tetramethyl-6,13-
triethylsilylethynylpentacene can make excellent OFET’s, with
high mobilities and on/off ratios when solution processed
in air with improved device to device reproducibility as a
consequence of the extended p–p overlap. With optimisation
of formulation18 and device architecture it is believed that this
new family of compounds will enable all solution processed
devices with high performance and excellent reproducibility to
be fabricated.
The authors would like to acknowledge the UK Home
Office and the University of Manchester for funding and
W. Eccleston and M. Raja of the University of Liverpool
for access to clean room facilities.
Notes and references
Discrete bottom-gate, top-contact organic field effect
transistor (OFET) devices were fabricated on OTS treated
heavily n-doped silicon wafers comprising a 3000 A thermally
grown gate oxide layer. 8 and 9 were drop cast from 0.5 wt%
toluene solution and dried under ambient atmosphere at 70 1C
in an open laboratory with no post-thermal annealing. Gold
source and drain channel electrodes, 60 mm width and 2 mm
z Single crystals of compounds 8 and 9 were obtained by solvent
diffusion (solvent was 1,2,4-trichlorobenzene and antisolvent was
acetonitrile), mounted in inert oil and transferred to the cold gas
stream (150 K) diffractometer.
Crystal determination of compound 8: C42H50Si2, M = 611.00,
triclinic, a = 7.3024(2), b = 10.9762(3), c = 12.1090(4) A, a =
74.402(3)1, b = 89.953(2)1, g = 73.746(2)1, U = 894.55(5) A3, T =
ꢀ
100 K, space group P1 (no. 2), Z = 1, 13 549 reflections measured,
3297 unique (Rint = 0.077) which were all used in the calculations. The
final wR(F2) was 0.1991 (all data) and R1 0.0771 (I 4 3s(I)).
Crystal determination of compound 9: C48H62Si2, M = 695.16, a =
9.0135(6), b = 10.2107(5), c = 11.7743(8) A, a = 70.694(2)1, b =
84.900(2)1, g = 82.342(5)1, U = 1012.41(11) A3, T = 100 K, space
Table 1 Oxidation potentials of 8 and 9 versus SCE reference by
comparison to ferrocene and their optical band gap from thin film,
determined at an onset absorption peak. Gap is determined from UV
absorption edge in liquid state
ꢀ
group P1 (no. 2), Z = 1, 5600 reflections measured, 3548 unique
(Rint = 0.098) which were all used in the calculations. The final wR(F2)
was 0.2784 (all data) and R1 0.1180 (I 4 3s(I)).
Compound
8
9
1 M. M. Payne, S. R. Parkin, J. E. Anthony, C.-C. Kuo and
T. N. Jackson, J. Am. Chem. Soc., 2005, 127, 4986.
2 J. E. Anthony, J. S. Brooks, D. L. Eaton and S. R. Parkin, J. Am.
Chem. Soc., 2001, 123, 9482.
3 H. Klauk, M. Halik, U. Zschieschang, G. Schmid, W. Radlik and
W. Weber, J. Appl. Phys., 2002, 92, 5259.
Eonset/V
0.50
5.19
1.87
3.32
0.59
5.39
1.87
3.52
HOMO/eV
EG/eV
LUMO/eV
ꢁc
