The novel carbon based acid has been synthesized via one-step hydrothermal carbonization of furaldehyde and hydroxyethylsulfonic acid. A highly efficient procedure for the synthesis of fructone has been developed using the novel carbon based acid. The results showed that the catalyst possessed high activity for the reaction, giving a yield of over 95%. The advantages of high activity, stability, reusability and low cost for a simple synthesis procedure and wide applicability to various diols and β-keto esters make this novel carbon based acid one of the best choices for the reaction.

Full text of DOI:10.3390/molecules15085369

Molecules 2010, 15, 5369-5377; doi:10.3390/molecules15085369
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Highly Efficient Procedure for the Synthesis of Fructone
Fragrance Using a Novel Carbon based Acid
Baowei Hu 1, Chunqing Li 1, Sheng-Xian Zhao 2, Lin-Mei Rong 2, Shao-Qin Lv 2,
Xuezheng Liang 1,* and Chenze Qi 1,*
1
Shaoxing University, Shaoxing, 312000, China
2
Esteve Huayi Pharmaceutical Co., LTD., Shaoxing, 312000, China
* Authors to whom correspondence should be addressed; E-Mail: xzliang@usx.edu.cn (X.Z.L.);
qichenze@usx.edu.cn (C.Z.Q.); Tel.: +86-575-88345682; Fax: +86-575-88345682.
Received: 1 June 2010; in revised form: 21 July 2010 / Accepted: 26 July 2010 /
Published: 5 August 2010
Abstract: The novel carbon based acid has been synthesized via one-step hydrothermal
carbonization of furaldehyde and hydroxyethylsulfonic acid. A highly efficient procedure
for the synthesis of fructone has been developed using the novel carbon based acid. The
results showed that the catalyst possessed high activity for the reaction, giving a yield of
over 95%. The advantages of high activity, stability, reusability and low cost for a simple
synthesis procedure and wide applicability to various diols and β-keto esters make this
novel carbon based acid one of the best choices for the reaction.
Keywords: novel carbon based acid; fructone; synthesis
1. Introduction
Acid catalysts are of great importance to the chemical industries for the production of various
important chemicals and over 15 million tons of sulfuric acid is consumed annually as an unrecyclable
catalyst [1–6]. Consequently environmentally friendly and green processes are in highly demand and
various solid acids have been synthesized to replace the unrecyclable sulfuric acid. Recently,
sulfonated carbonaceous materials have received more and more attention in this respect [7–10]. These
materials were synthesized via carbonization and sulfonation. First, saccharides were incompletely
carbonized at high temperature (>400 °C) in an inert atmosphere for a long time. Then the sulfonation

Molecules 2010, 15
5370
was done to introduce the sulfonic acid groups onto the carbon and a carbon with an acidity of only
1 mmol/g was obtained by this method. Hydrothermal carbonization, which involves the hydrothermal
decomposition of various carbohydrates in aqueous solutions at low temperature, has the advantages of
being very cheap, mild, and absolutely “green” as it involves no organic solvents, catalysts or
surfactants [11]. Sulfonated carbon has been synthesized in our previous work using a hydrothermal
carbonization process [12], but the sulfonation must be carried out after carbonization to introduce the
sulfonic acid groups. Besides the harsh reaction conditions, the separation of the carbon material from
the concentrated sulfuric acid is still tedious task, which requires the dilution of the concentrated
2
sulfuric acid with a large amount of water, filtration of the solid product and washing out the SO4 -
ions. A novel carbon acid was synthesized from polyvinyl alcohol and hydroxyethylsulfonic acid in
our previous work, which displayed high activities in the traditional acid-catalyzed reactions [13]. Here
a novel carbon acid has been synthesized via a one-step hydrothermal carbonization of furaldehyde
and hydroxyethylsulfonic acid at 180 °C for 4 hours. The sulfonic acid groups were introduced to the
carbon during the carbonization process (Scheme 1). The catalytic activities of the novel carbon acid
were investigated via the synthesis of fructone, which is a ketal derived from ethyl acetoacetate and
ethylene glycol. The results showed that the novel carbon was very efficient for these reactions, giving
average yields over 95%.
Scheme 1. The synthesis of the novel carbon based acid.
furaldehyde
HO
O
HO3S
HO3S
SO3H
CHO
SO3H
SO3H
SO3H
OH
SO3H
HO
SO3H
HO3S
HO3S
hydroxyethylsulfonic acid
SO3H
2. Results and Discussion
2.1. Characterization of the Novel Carbon Based Acid
The formation of the carbon based acid involves the dehydration of furaldehyde and
hydroxyethylsulfonic acid as the first step. Furaldehyde is one of the glucose intermediates during the
hydrothermal process, which could be able to react with hydroxyethylsulfonic acid to introduce
sulfonic acid groups. Here, the sulfonic acid groups also could also be transformed to other groups
such as sulfonate and sulfone when glucose is used as the raw material. Other furan derivatives such as
methylfuran are unable to form solid products, so furaldehyde is chosen here as the raw material. Upon
dehydration (polymerization), microscopic carbon-containing spheres with sulfonic acid groups and
hydroxyl groups were formed. Subsequent loss of water by these assemblies leads to further
coalescence of microscopic spheres into larger spheres (Scheme 1) [14,15]. Here,
hydroxyethylsulfonic acid was used as the functional molecule to introduce the sulfonic acid groups to
the carbonaceous material, since it contained the necessary hydroxyl group for the intermolecular

Molecules 2010, 15
5371
dehydration. The acidity of the novel acid carbon was 2.4 mmol/g, which was determined through
neutralization titration. The material had much higher acidity than that of the sulfonated carbonaceous
materials obtained via the sulfonation of the inactive carbon surface. The acid strength of the catalyst
was determined by thermodesorption of chemisorbed ammonia (NH3-TPD). The result showed that the
catalyst had great acid strength, as ammonia was only desorbed at 400 to 600 °C.
The X-ray Photoelectron Spectroscopy (XPS) spectrum analysis showed a S content of 7.2%, with a
single S 2p peak attributable to sulfonic acid groups at 168 eV, which indicated that almost all the S
existed in the forms of such sulfonic acid groups. On the other hand, the acidity of 2.4 mmol/g required
the S content of 7.68%, which was higher than the actual content. These results indicated that there
were still a few other acidic groups such as carbonyl acid groups in the carbonaceous material and the
O content was as high as 27%, which also indicated that there were still many oxygen-containing
groups in the material. Furthermore, the acidity remained even after the material has been treated with
boiling water for more than 15 h, which further confirmed that the sulfonic acid groups were attached
to the carbonaceous material.
The Fourier Transform Infrared (FT-IR) spectrum of the carbonaceous material is shown in
Figure 1. The absorbances at 1,040 and 940 cm-1 confirmed the existence of the sulfonic acid groups.
The FT-IR spectrum also showed that the carbon materials contain various other functionalities
including carboxylate (1,704 cm-1), Ar-H (3,020 cm-1), C-O groups (1,204 cm-1) and C=C groups
(1,604 cm-1).
Figure 1. The IR spectrum of the carbon based acid.
Ar-H
C=C
C=O
S=O
C-O
3500
3000
2500
2000
1500
1000
W avenumbers(cm-1)
The scanning electron microscopy (SEM) images of the carbon based acid show that the resulting
particles grew in size with the reaction time, reaching a diameter of 5–10 μm, as depicted in
Figures 2(a,b), which is quite different from the amorphous structures of the sulfonated carbonaceous
materials reported by Hara [9–10]. The large size of the carbon spheres also made the recycle of the
material very simple and a filtration without suspension of the reaction mixture was enough. The BET
surface of the material was 148 m2/g, which is much higher than that of sulfonated carbonaceous
materials (10–30 m2/g). The materials displayed micrometer sized microporous carbon spheres and
there were many micro-sized carbon spheres attached to the surface of the big carbon spheres to form a

Molecules 2010, 15
5372
strawberry-like structure (Figure 2a). The carbonaceous material obtained from furaldehyde formed
carbon spheres with a smooth surface (Figure 2c). Unlike the carbon derived from polyvinyl alcohol,
which was dehydrated easily in an acid enviroment due the rich amount of hydroxyl groups, here
hydroxyethylsulfonic acid appears to stabilize the first formed small droplets depicted in Scheme 1,
thus many micrometer sized carbon spheres are formed late in the process, which might not occur in
the pure furaldehyde case. Later on in the process, the micro-sized carbon spheres attached to the
surface of the early-formed big carbon spheres to form the observed strawberry-like structures [16].
Figure 2. The SEM images of the carbon based acid with the reaction time of 4 h.
a
b
c
Figures 2a and 2b refer to the carbon from furaldehyde and hydroxyethylsulfonic acid; Figure 2c
refers to the carbon from furaldehyde alone
2.2. The Catalytic Activities for the Synthesis of Fructone
2.2.1. The Effect of the Reaction Time on the Yield
The effect of the reaction time on the yield was investigated first (Figure 3). It can be seen from the
figure that the catalyst was very efficient for the reaction, with the yield reaching the maximum 2.5 h
later and the selectivity then decreased quickly when the reaction time became longer due to the
hydrolysis of the product in a competitive reaction.
Figure 3. The effect of the reaction time on the reaction.
100
95
90
85
80
Selectivity
Conversion
75
70
65
60
0.5
1.0
1.5
2.0
2.5
3.0
3.5
tim e/h

Molecules 2010, 15
5373
2.2.2. The Effect of the Molar Ratio of the Reactants on the Yield
The molar ratio of the reactants was another factor that was considered. It can be seen from Table 1
that the conversion increased when the amount of 1,2-ethanediol increased. We presume that the
intermolecular collisions which form the product increased with the addition of 1,2-ethanediol.
However, the conversion increased little when the amount of 1,2-ethanediol was increased further and
the reaction reached the equilibrium, so the best molar ratio is 1:1.5.
Table 1. The effect of the molar ratio on the reaction.
n(ethyl acetoacetate)/n(ethylene glycol) 1:1.0 1:1.2 1:1.5 1:2.0
Conversion/%
Selectivity/%
85.6 91.4 98.7 99.3
98.3 98.6 99.3 98.7
2.2.3. The Effect of the Catalyst Amount on the Yield
The catalyst amount was also very important for the reaction (Table 2). There were not enough
active sites for the reaction to take place efficiently when the catalyst amount was too low. On the
other hand, the side reaction of the hydrolysis which can also be catalyzed by the acid catalyst could
also take place when too much catalyst was employed, so the optimal amount of the catalyst was found
to be 0.05 g.
Table 2. The effect of the catalyst amount on the yield.
Catalyst usage/g 0.01 0.03 0.05 0.07
Conversion/%
Selectivity/%
97.0 97.4 98.7 98.7
98.3 98.6 99.3 98.7
2.2.4. The Effect of the Solvents on the Yield
In order to improve the yield of the reaction, a Dean-Stark apparatus was used to continuously
remove the water formed from the reaction mixture. Here three solvents were chosen for the reaction
(Table 3). Cyclohexane was the best choice for the reaction. Toluene was not as efficient for the as the
selectivity much lower than for others due to the high boiling point which made the reaction happen at
a higher temperature, which benefits the hydrolysis.
Table 3. The effect of the solvents on the yield.
Solvent
cyclohexane toluene isooctane
Conversion/%
Selectivity/%
98.7
99.3
95.3
85.1
96.4
93.0
2.2.5. The Results with Different Diols
The reactions of various diols with ethyl acetoacetate were also carried out (Table 4). It can be seen
that the novel catalyst was very efficient for these reactions, with average conversions over 95% and

Molecules 2010, 15
5374
selectivity over 98%. The conversion decreased when the chain of the diols became due to the steric
effect and the ring strain. The reaction between ethyl acetoacetate and 1,4-butanediol was also lees
efficient as the seven-membered ring product formed was not as stable as the traditional five or six
membered ring compounds.
Table 4. The results of various diols.
Diols
1,2-ethanediol 1,2-propandeniol 1,4-butanediol
Conversion/%
Selectivity/%
98.7
99.3
95.4
99.2
93.7
98.9
2.2.6. The Results of Different β-keto Esters
The reactions of various β-keto esters with 1,2-ethanediol were then carried out (Table 5). It can be
seen that the novel catalyst was very efficient for these reactions, with the average conversion being
over 95% and the selectivity being over 99%. The conversion decreased slightly when the chain of the
β-keto esters became longer because of the steric effect and the ring strain. The results showed that the
catalyst had wide applicability for different β-keto esters, giving high yields in all cases.
Table 5. The results of various β-keto esters.
β-keto esters
Conversion/%
Selectivity/%
O
O
99.1
99.3
O
O
O
98.5
97.8
97.2
96.5
99.2
99.3
99.1
99.3
O
O
O
O
O
O
O
O
O
O
2.2.7. A Comparative Study of Different Catalysts
A comparative study of the catalytic activities of the novel catalyst and reported catalysts was
undertaken using the reaction between ethyl acetoacetate and 1,2-ethanediol (Table 6) as a model.
Table 6. Comparison of different catalysts.
Catalyst
Acid carbon H2SO4 PTSA Hβ Nafion
Catalyst amount/g
Reaction time/h
Conversion/%
Selectivity/%
0.05
2.5
0.05
2.0
0.05
2.0
0.1
3.0
0.1
2.5
97.4
99.3
98.5
62.3
97.3 92.1
67.3 98.9
94.2
98.7

Molecules 2010, 15
5375
Hβ zeolite with a n(SiO2)/n(Al2O3) ratio = 30 was synthesized in our laboratory according to the
methods in [17]. Nafion with an acidity of 67 mg (KOH)/g was obtained from Fluka. The
homogeneous catalysts were not as efficient as the heterogeneous catalysts because of the hydrolysis.
The novel catalyst was the most efficient, showing the highest conversion and selectivity with the
lowest amount of catalyst and the shortest reaction time.
2.3. The Reuse of the Novel Catalyst
One important property of the catalyst is immiscibility with organic compounds or solvents, thus
making the recovery of the catalyst very convenient. After the reactions the catalyst was recovered by
simple filtration after cooling the reaction mixture to room temperature. The recovered activity of the
catalyst was carefully investigated through the reaction of ethyl acetoacetate and 1,2-ethenediol
(Figure 4). The results showed the high stability of the catalyst. The yields and the sample composition
remained unchanged, even after the sample had been recycled six times.
Figure 4. The reuse of the catalyst.
100
95
90
85
80
75
70
65
60
1
2
3
4
5
6
Ru n
3. Experimental
3.1. General
All organic reagents were commercial products of the highest purity available (>98%) and were
used for the reactions without further purification. Cyclohexanone, acetic acid, n-butanol, ethyl
acetoacetate, 1,2-ethanediol, 1,4-butanediol, 1,3-propanediol and hydroxyethylsulfonic acid were
purchased from Sinopharm Chemical Reagent Co, Ltd.
3.2. Synthesis of the Carbonaceous Material
A mixture of furaldehyde (10 g), hydroxyethylsulfonic acid (5 g) and deionized water (80 mL) was
placed in a 100 mL Teflon-lined stainless steel autoclave, which were heated in an oven at 180 °C for
4 h. The resulting products were filtered, washed with water and methanol, and dried in a vacuum oven
at 100 °C for 4 hours.
3.3. Typical Procedure for Synthesis of Fructone (Scheme 2)
Ethyl acetoacetate (0.1 mol), cyclohexane (10 mL) 1,2-ethendiol (0.15 mol) and the catalyst were
mixed up in a three necked round bottomed flask equipped with a magnetic stirrer and a thermometer,

Molecules 2010, 15
5376
and a Dean-Stark apparatus was used to remove the water continuously from the reaction mixture. The
mixture was refluxed for the specified period. The reaction progress was monitored by GC. On
completion, the catalyst was recovered by filtration and washing with acetone, then dried at 353 K for
about 1 h. The qualitative analysis of the liquid reaction mixture was carried out on a GC-MS. The
quantitative analysis of the extract solution was carried out on a temperature-programmed Shimadzu
GC-14C gas chromatograph. The conversion and selectivity were determined by GC using an internal
standard method based on ethyl acetoacetate.
Scheme 2. The reaction equation.
O
O
Novel catyalyst
Reflux
O
O
O
+
OH OH
O
O
4. Conclusions
A highly efficient process for the synthesis of fructone had been developed using a novel carbon
acid as catalyst. After optimizing the reaction conditions, a comparative study with other catalysts and
of the reuse of the catalyst were undertaken. The results showed that the novel catalyst shows great
advantages over commonly used catalysts such as H2SO4, PTSA, Hβ zeolite and Nafion. The
operational simplicity, low cost of the catalyst used, high activity, applicability to large-scale reactions
and reusability makes the catalyst one of the best choices for the reaction.
Acknowledgements
This work was supported by the Shaoxing Key Discipline Foundation, China, Zhejiang Provincial
Natural Science Foundation No.Y4080481 and Shaoxing Science and technology projects
(2009A21056).
References
1. Anastas, P.T.; Kirchhoff, M.M. Origins, current status, and future challenges of green chemistry.
Acc. Chem. Res. 2002, 35, 686–694.
2. DeSimone, J.M. Practical Approaches to Green Solvents. Science 2002, 297, 799–803.
3. Harton, B. Green Chemistry Puts Down Roots. Nature 1999, 400, 797–799.
4. Anastas, P.T.; Zimmermann, J.B. Design through the 12 principles of green engineering. Environ.
Sci. Technol. 2003, 37, 94A–101A.
5. Clark, J.H. Solid Acids for Green Chemistry. Acc. Chem. Res. 2002, 35, 791–797.
6. Misono, M.; Acad, C.R. Heterogeneous catalysis. Sci. Ser. Iic. 2000, 3, 471–475.
7. Nakajima, K.; Okamura, M.; Kondo, J.N.; Domen, K.; Tatsumi, T.; Hayashi, S.; Hara, M.
Amorphous Carbon Bearing Sulfonic Acid Groups in Mesoporous Silica as a Selective Catalyst.
Chem. Mater. 2009, 21, 186–193.
8. Comerford, J.W.; Clark, J.H.; Macquarrie, D.J.; Breeden, S.W. Amidation of Carboxylic Acid
with Amines by K60 Silica. Chem. Commun. 2009, 2562–2564.

Molecules 2010, 15
5377
9. Toda, M.; Takagaki, A.; Okamura, M.; Kondo, J.N.; Domen, K.; Hayashi, S.; Domen, K.; Hara,
M. Biodiesel made with sugar catalyst. Nature 2005, 438, 178.
10. Hara, M.; Yoshida, T.; Takagaki, A.; Takata, T.; Kondo, J.N.; Domen, K.; Hayashi, S. Carbon
material as a strong protonic acid. Angew. Chem., Int. Ed. 2004, 43, 2955–2958.
11. Titirici, M.-M.; Thomas, A.; Antonietti, M. Replication and Coating of Silica Templates by
Hydrothermal Carbonization. Adv. Funct. Mater. 2007, 17, 1010–1018.
12. Liang, X.Z.; Yang, J.G. Synthesis of a Novel Carbon Based Strong Acid Catalyst Through
Hydrothermal Carbonization. Catal. Lett. 2009, 132, 460–463.
13. Liang, X.Z.; Xiao, H.Q.; Shen, Y.M.; Qi, C.Z. One-step synthesis of novel sulfuric acid groups
functionalized carbon via hydrothermal carbonization. Mater. Lett. 2010, 64, 953–955.
14. Sevilla, M.; Fuertes, A.B. Chemical and structural properties of carbonaceous products obtained
by hydrothermal carbonization of saccharides. Chem. Eur. J. 2009, 15, 4195–4203.
15. Bo, H.; Yu, S.-H.; Wang, K.; Liu, L.; Xu, X.-W. Functional carbonaceous materials from
hydrothermal carbonization of biomass: an effective chemical process. Dalton. Trans. 2008, 40,
5414–5423.
16. Demir-Cakan, R.; Baccile, N.; Antonietti, M.; Titirici, M.M. Carboxylate-Rich Carbonaceous
Materials via One-Step Hydrothermal Carbonization of Glucose in the Presence of Acrylic Acid.
Chem. Mater. 2009, 21, 484–490.
17. Wadlinger, R.L.; Kerr, G.T.; Rosinski, E. Catalytic composition of a crystalline zeolite. U.S.
Patent 3,308,069, 7 March 1967.
Sample Availability: Samples are available from the authors.
© 2010 by the authors; licensee MDPI, Basel, Switzerland. This article is an Open Access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/3.0/).
