Article
Assessment of DNA Topoisomerase I Unwinding
Activity, Radical Scavenging Capacity, and
Inhibition of Breast Cancer Cell Viability of N-alkyl-
acridones and N,N′-dialkyl-9,9′-biacridylidenes
1
2
1,3
1,3
Marios G. Krokidis , Zara Molphy , Eleni K. Efthimiadou , Marianna Kokoli
,
1,†
1
4
1,
Smaragda-Maria Argyri , Irini Dousi , Annalisa Masi , Kyriakos Papadopoulos *,
Andrew Kellett and Chryssostomos Chatgilialoglu
2
1,4,
*
1
Institute of Nanoscience and Nanotechnology, N.C.S.R. “Demokritos”,
15310 Agia Paraskevi-Athens, Greece; m.krokidis@inn.demokritos.gr (M.G.K.);
efthim@chem.uoa.gr (E.K.E.); marianna_kokoli@yahoo.gr (M.K.), argyri@student.chalmers.se (S.-M.A.);
i.dousi@inn.demokritos.gr (I.D.)
School of Chemical Sciences and National Institute for Cellular Biotechnology, Dublin City University,
Glasnevin, 9 Dublin, Ireland; zara.molphy2@mail.dcu.ie (Z.M.); andrew.kellett@dcu.ie (A.K.)
Department of Chemistry, National and Kapodistrian University of Athens, 15784 Zografou, Greece
ISOF, Consiglio Nazionale delle Ricerche, Via Piero Gobetti 101, 40129 Bologna, Italy;
annalisa.masi@isof.cnr.it
2
3
4
* Correspondence: k.papadopoulos@inn.demokritos.gr (K.P.); chrys@isof.cnr.it (C.C.);
Tel.: +30-210-650-3647 (K.P.); Tel.: +39-051-639-8309 (C.C.)
Present address: Department of Chemistry and Chemical Engineering, Chemistry and Biochemistry,
†
Chalmers University of Technology, SE-41296, Gothenburg, Sweden.
Received: 20 April 2019; Accepted: 7 May 2019; Published: 8 May 2019
Abstract: The anticancer activity of acridone derivatives has attracted increasing interest, therefore,
a variety of substituted analogs belonging to this family have been developed and evaluated for
their anti-cancer properties. A series of N-alkyl-acridones 1–6 and N,N′-dialkyl-9,9′-biacridylidenes
7–12 with variable alkyl chains were examined for their topoisomerase I activity at neutral and
acidic conditions as well as for their binding capacity to calf thymus and possible radical trapping
antioxidant activity. It was found that at a neutral pH, topoisomerase I activity of both classes of
compounds was similar, while under acidic conditions, enhanced intercalation was observed. N-
alkyl-acridone derivatives 1–6 exhibited stronger, dose-dependent, cytotoxic activity against MCF-
7 human breast epithelial cancer cells than N,N′-dialkyl-9,9′-biacridylidenes 7–12, revealing that
conjugation of the heteroaromatic system plays a significant role on the effective distribution of the
compound in the intracellular environment. Cellular investigation of long alkyl derivatives against
cell migration exhibited 40–50% wound healing effects and cytoplasm diffusion, while compounds
with shorter alkyl chains were accumulated both in the nucleus and cytoplasm. All N,N′-dialkyl-
9,9′-biacridylidenes showed unexpected high scavenging activity towards DPPH or ABTS radicals
which may be explained by higher stabilization of radical cations by the extended conjugation of
heteroaromatic ring system.
Keywords: N,N′-dialkyl-9,9′-biacridylidenes; topoisomerase I; DNA intercalation; DNA binding;
radical scavenging capacity; cytotoxic activity
Biomolecules 2019, 9, 177; doi:10.3390/biom9050177
www.mdpi.com/journal/biomolecules

Biomolecules 2019, 9, 177
2 of 15
1. Introduction
Acridone derivatives have been applied in clinics as anti-tumor chemotherapeutics since the
1970s. The cytotoxicity of acridone and acridine-based compounds arise not only from their direct
binding to DNA but also from interactions with specific biological targets [1]. The unique planar ring
structure of these derivatives may allow them to act either as topoisomerase poisons or as G-
quadruplexes-DNA stabilizing agents. Additional telomerase and protein-kinase inhibitory activity
may also contribute to cytotoxic effects in cancer treatment [2]. Analogs with a 2,2′-bis-pyridyl group
substituted on the acridone scaffold or with a tetracyclic acridone structures, named as
zanthacridones, showed broad antitumor activity against numerous cancer cell lines [3]. Derivatives
with terminal ammonium substituents at C2 and C7 positions on the acridone moiety showed
significant activity against leukemia CCRF-CEM cells along with limited toxic effect against normal
cells proliferation [4]. These well-recognized properties of acridones are attributed to their semi-
planar heterocyclic structures as well as N-substitution, which facilitates unique interactions with
different molecular targets. For example, in a study by Xia et al., using MCF-7 xenograft mouse
model, it was indicated that acridone could induce cell apoptosis, inhibiting breast cancer resistance
protein (ABCG2), indicating strong in vivo potential [1]. A series of 2-fluoro N-substituted acridones
with varying alkyl side chain length have been reported, exhibiting promising cytotoxic effects
against sensitive and resistant cancer cell lines while their DNA-binding properties, based on their
affinity or intercalation with CT-DNA, were evaluated [5]. Among them, a tricyclic N-substituted
acridone with a fluorine group at the C-2 position additional to a secondary amine side chain
containing a tertiary amino group was responsible for marked cytotoxic activity [5]. A series of
substituted 9-aminoacridines were screened against MiaPaCa-2, SU86.86, and BXPC-3 pancreatic
cancer cells, presenting low micromolar antiproliferative properties in the three distinct cell lines.
Here, the resulting activity was derived from the induction of G1-S phase arrest, as the drug–DNA
complex formed blocked topoisomerase II binding activity, leading to catalytic inhibition of the
enzyme and the induction of apoptosis or programmed cell death [6]. In recent work by Zhang et al.,
a series of novel pyridyl-derived acridones were synthesized by combining a pyridyl moiety and the
acridone-4-carboxamide scaffold. The majority of these compounds possessed cytotoxicity against
K562 cells or inhibition of topoisomerase I activity, and induced apoptosis through mitochondrial
pathway dysregulation [2].
DNA supercoiling is generated by metabolism and typically tends to be overwound (positively
supercoiled) upstream of replication or transcription forks and underwound (negatively supercoiled)
downstream of these forks [7]. Topological constraints can be relieved enzymatically with DNase I
or DNA topoisomerases. DNA topoisomerases (topo) are ubiquitous enzymes that maintain cellular
function by modulating the topology of supercoiled DNA during processes including gene
transcription, DNA replication, recombination, and repair and, therefore, represent an attractive drug
target [8]. The enzyme first acts by cleaving one (topo-I) or two (topo-II) strands of DNA through a
transesterification reaction with active site tyrosine acting as the nucleophile that attacks the DNA
phosphodiester backbone. This results in the generation of a transient break, which permits
topological changes to occur within the cell prior to strand resealing. In recent years, many planar
polycyclic organic molecules have been identified to alter topo enzyme activity through catalytic
inhibition (camptothecin and derivatives of it) or poisoning (doxorubicin) [9,10]. Classical models for
the reversible binding of drug molecules to duplex DNA include (i) groove binding (major and
minor), (ii) intercalation, and (iii) insertion. Since these binding modes, in particular intercalation by
planar heterocycles, affect supercoiling, valuable binding information can be identified in the
presence of topoisomerase enzymes.
In the present work, we examined the topoisomerase I, DNA binding, cytotoxic effects, as well
as the radical trapping antioxidant activity of a series of N-alkyl-acridones and N,N′-dialkyl-9,9′-
biacridylidenes with short and long alkyl chains substitution (Figure 1). N,N′-dialkyl-biacridylidenes
7–12 were synthesized from the corresponding N-alkylacridones 1–6 by reductive coupling with zinc
powder in dry ethanolic hydrogen chloride solution or from lucigenin in alkaline methanolic solution
(derivative 8), while N-alkylacridones 1–6 from acridone and the corresponding alkyl bromides

Biomolecules 2019, 9, 177
3 of 15
under phase-transfer conditions [11–13]. Optical and confocal microscopy imaging was assessed to
clarify the role of alkyl side chain substitution in the intracellular localization of cytotoxic derivatives.
Figure 1. Chemical structures of N-alkyl-acridones 1–6 and N,N′-dialkyl-9,9′-biacridylidenes 7–12.
2. Materials and Methods
2.1. Materials, Chemical Compounds and Cell Cultures Conditions
HPLC-grade solvents were purchased from Merck (Steinheim, Germany) and Fisher Scientific
(Waltham, MA, USA). Ultrapure water (18.3 MΩcm), distilled, and deionized water (Milli-Q water)
were purified using a Milli-Q system (Merck-Millipore, Bedford, USA). High glucose Dulbecco’s
modified Eagle Medium (DMEM) was purchased from Sigma (St. Louis, MO, USA). Trypsin-EDTA,
L-glutamine, penicillin–streptomycin solution, and heat inactivated fetal bovine serum (FBS) were
obtained from Biochrom KG, (Berlin, Germany). Human Caucasian breast adenocarcinoma cell line
(MCF-7) was obtained from the American Type Culture Collection (ATCC; Manassas, VA, USA) and
cultured as monolayers in complete medium Dulbecco’s Modified Eagle’s Medium (DMEM, Sigma,
Steinheim, Germany) at 37 °C in an atmosphere of 5% (v/v) CO2 and 95% at relative humidity. Cells
2
were seeded in 75 cm plastic tissue culture flasks and cultured in DMEM supplemented with 10%
FBS, 2 mM L-glutamine, 100 U/mL penicillin, and 100 μg/mL streptomycin, washed with phosphate
buffered saline (PBS) and harvested by trypsinization with 0.05% (w/v) trypsin in PBS containing
0.02% (w/v) EDTA (Sigma, St. Louis, MO, USA).
2.2. Synthetic Procedures for the Preparation of N-alkylacridones 1–6 and N,N′-dialkyl-9,9′-biacridylidenes
7–12
Synthesis of N-alkylacridones (1–6), 30 mmol of the corresponding n-alkylbromide (methyl iodide for
1) were added under stirring to a mixture containing 3.9 g acridone (20 mmol), 20 mL aqueous
sodium hydroxide solution (50%), 40 mL toluene, and 2.0 g tetrabutylammonium bromide (6.2 mmol)
under reflux for ca. 10 h. After cooling, the reaction mixture was then worked up with ether and
water and the combined organic extracts were evaporated under reduced pressure (rot-evaporator).
The resulting yellow to orange colored products were collected and purified by crystallization from
1
ethanol or ether-petroleum ether. Chemical yields, 56 to 80%. 1: m.p. 201 °C; H NMR (CDC13, 250 M
Hz): δ (ppm) = 8.52 (d, J = 8.4 Hz, 2H), 7.65 (m, 2H), 7.43 (d, J = 8.1 Hz, 2H), 7.25 (m, 2H), 3.84 (s, 3H);
1
2: m.p. 100 °C; H NMR (CDC13, 250 M Hz): δ (ppm) = 8.5 (d, J = 8.4 Hz, 2H), 7.62 (m, 2H), 7.43 (d, J =
8.1 Hz, 2H), 7.25 (m, 2H), 7.25 (m, 4H), 4.24 (t, 2H, NCH2), 1.8 (m, 2H), 1.55 (m, 2H), 1.05 (t, 3H); 3:
1
m.p. 91 °C; H NMR (CDC13, 250 M Hz): δ (ppm) = 8.52 (d, J = 8.4 Hz, 2H), 7.64 (m, 2H), 7.44 (d, J =
1
8.1 Hz, 2H), 7.22 (m, 4H), 4.22 (t, 2H, NCH2), 1.83 (m, 2H), 1.44 (m, 8H), 0.92 (t, 3H); 4: m.p. 88 °C; H
NMR (CDC13, 250 M Hz): δ (ppm) = 8.52 (d, J = 8.4 Hz, 2H), 7.55 (m, 2H), 7.43 (d, J = 8.1 Hz, 2H), 7.24
1
(m, 4H), 4.23 (t, 2H, NCH2), 1.83 (m, 2H), 1.34 (m, 16H, 0.92 (t, 3H); 5: m.p. 86 °C; H NMR (CDC13,

Biomolecules 2019, 9, 177
4 of 15
250 M Hz): δ (ppm) = 8.54 (d, J = 8.4 Hz, 2H), 7.62 (m, 2H), 7.44 (d, J = 8.1 Hz, 2H), 7.24 (m, 4H), 4.22
1
(t, 2H, NCH2), 1.82 (m, 2H), 1.3 (m, 20H, 0.94 (t, 3H); 6: H NMR (CDC13, 250 M Hz): δ (ppm) = 8.52
(d, J = 8.4 Hz, 2H), 7.62 (m, 2H), 7.44 (d, J = 8.1 Hz, 2H), 7.24 (m, 4H), 4.22 (t, 2H, NCH2), 1.82 (m, 2H),
1.3 (m, 26H, 0.94 (t, 3H).
Synthesis of 9,9′-biacridylidenes (7, 9–12), to a stirred solution of 5.0 mmol N-alkylacridone and 2.28 g
zinc powder (35 mmol) in absolute ethanol (20 mL) and under an inert atmosphere, dried saturated
ethanolic hydrogen chloride solution (30 mL) was added dropwise while cooling with ice (0 °C). The
cooling bath was then removed and the reaction continued until most of the zinc was consumed. The
reaction was terminated by pouring the mixture into water. The crude product was filtered off and
rinsed well with water. Compounds were purified by crystallization from toluene and the chemical
1
yields of the crude products were in all cases 70 to 85%. The most typical signals appeared in H NMR
(CDC13, 250 M Hz) were δ = 4.01 (pseudo-t, 4H, NCH2), 6.65 (m, 4H), 7.03 (m, 4H) and 7.23 (m, 8H).
7: m.p. 385 °C; 9: m.p. 252 °C; 10: m.p. 156 °C; 11: m.p. 129 °C; 12 m.p. 118 °C. Synthesis of N-
methoxymethyl-N′-methyl-9,9′-biacridylidene, 8: Lucigenin (500 mg 1.0 mmol) and 1g NaOH (25.0
mmol) were dissolved in 50 mL methanol and the mixture was stirred under reflux. After 2 h, the
yellow precipitate was filtered off, washed with cold methanol, and dried under vacuum; chemical
1
yield 266 mg (64%); m.p. 275 °C; H NMR (CDC13, 250 M Hz): δ (ppm) = 3.56 (s, 3H, NCH3), 3.61 (s,
3H, OCH3), 5.42 (s, 2H, NCH2O), 6.82 (m, 4H), 7.08 (m, 4H), 7.27 (m, 8H).
2.3. Topoisomerase-I Mediated DNA Relaxation Assay
This experimental procedure was adapted from a method previously published elsewhere [14].
Briefly, acridones 1–6 and biacridylidenes 7–12 were initially dissolved in DMSO and further diluted
in either 80 mM HEPES (pH 7.2) or 80 mM phosphate buffer (pH 5.8). We exposed 400 ng of pUC19
plasmid DNA (NEB, N3041, Ipswich, MA, USA) to varying concentrations of drug (0.01–400 μM) for
30 min at room temperature in a final volume of 20 μL containing 80 mM HEPES (pH 7.2) or 80 mM
®
phosphate buffer (pH 5.8), 10× CutSmart buffer (NEB, B7204), and 100× BSA (NEB, B9000). Added
to the mixture, was 1 unit of topoisomerase I (E. coli) (NEB, M0301) and incubated for 20 min at 37
°C to ensure relaxation of the plasmid DNA. The reaction was stopped through the addition of SDS
and protein kinase, to a final concentration of 0.25% and 250 μg/mL, respectively. To remove protein
from the DNA, samples were then incubated for 30 min at 50 °C. DNA supercoiling was assessed by
agarose gel electrophoresis. A 6× loading buffer (Fermentas, Waltham, MA, USA) was added and the
reaction mixture was loaded onto a 1.2% agarose gel in the absence of ethidium bromide (EtBr).
Topoisomers of DNA were separated by electrophoresis in 1× TBE buffer at room temperature for
180 min at 40 V followed by 150 min at 50 V. The agarose gel was post-stained using an EtBr bath and
photographed using a UV trans-illuminator.
2.4. DNA Binding Studies
DNA-binding properties of analogues were investigated using UV–Vis absorbance
spectroscopy. All UV–Vis spectra were recorded on a JASCO V-650 spectrophotometer. In UV
titration experiments, the spectra of calf-thymus DNA (CT-DNA, Sigma, St. Louis, MO, USA) in the
presence of the compound have been recorded for a constant CT-DNA concentration in diverse
[complex] / [CT-DNA] mixing ratios (r). The intrinsic binding constant, Kb, of the complex with CT
DNA was determined through the UV spectra of the complex recorded for a constant complex
concentration in the absence and presence of CT-DNA for diverse r values. Each experiment was
repeated in triplicate. A solution of CT-DNA was prepared using 150 mM NaCl in 15 mM trisodium
citrate at pH 7.0, followed by stirring for 48 h at 4 °C. A260/A280 ratio at 1.47 and A260/A230 ratio at 15.39
(≥2) indicated that CT-DNA was sufficiently free from organic substances and 82.5% pure of protein
contamination [15,16]. The concentration of duplex DNA was determined following the Beer Lambert
−1
−1
Law, with a molar extinction coefficient of 6600 M cm and was calculated to 59.42 μM. Analogs
were diluted in a tris-citrate buffer (containing 150 mM NaCl and 15 mM trisodium citrate at pH 7.0)
in the presence of approximately 1.0% DMSO and incubation with CT-DNA was carried out for 24h.

Biomolecules 2019, 9, 177
5 of 15
2.5. DPPH and ABTS Radical Scavenging Activity Assays
The radical scavenging capacity of biacridylidenes 7–12 toward DPPH (1,1-diphenyl-2-picryl-
hydrazyl, Sigma, Steinheim, Germany) was determined according to the method of Brand-William
et al., [17] with some modifications. Briefly, 2.0 mL of 0.1 mM DPPH solution in ethanol was
incubated with 2.0 mL of varying concentrations of compounds 7–12 (10 to 200 μM). The reaction
mixture was stirred for 60 min at room temperature and the absorbance of the resulting solution was
read at 517 nm against a blank. The radical scavenging activity was measured as a decrease in the
absorbance of DPPH and was calculated using the following equation:
radical scavenging activity (%) = [(A0 – A) / A0] × 100
(1)
where: A0 represents the absorbance of DPPH in the absence of the analog and A the absorbance of
DPPH in the presence of biacridylidene compound. The ABTS assay was performed according to
known protocols with some modifications [18]. Initially, 2,2′-azino-bis-(3-ethylbenzothiazoline-6-
sulfonic acid) diammonium salt (ABTS, Sigma, Steinheim, Germany) was dissolved in a mixture of
water/ethanol (80:20) at a concentration of 7 mM and reacted with a 2.45 mM potassium persulfate
solution overnight at room temperature. The absorbance of ABTS radical cation was measured at 734
nm in the absence and presence of the tested compounds (10–250 μΜ) upon 60 min incubation at
room temperature. The IC50 values were defined as the amount of the radical scavenger necessary to
decrease the initial DPPH or ABTS concentration by 50%. Trolox and caffeic acid were used as
reference agents. All experiments were performed in triplicate.
2.6. MTT Assay
Cell viability was assessed in MCF-7 cells exposed to N-alkylacridones and N,N′-dialkyl-9,9′-
biacridylidenes using the MTT assay [19]. Briefly, cells were seeded in 96-well flat bottom microplates
4
(1.5 × 10 cells in 0.1 mL of medium/well) in triplicate, allowed to grow overnight until 70% confluent
in a controlled atmosphere (37 °C, 5% CO2 and 95% relative humidity), and then treated with a range
of concentrations of test compounds. For dissolution and dilution of the compounds, 0.05–0.2%
DMSO was utilized. After 24, 48, and 72 h of incubation, the medium was replaced with 0.1 mL of 3-
(4,5-dimethylthiazol-2-yl)-2,5-diphenyl tetrazolium bromide (MTT, Sigma, Steinheim, Germany)
solution (1 mg/mL diluted in DMEM) and the plate was incubated for another 4 h at 37 °C, 5% CO2.
The dark-blue formazan crystals, which are precipitated by viable cells, were dissolved in DMSO.
Results are expressed as a percentage (%) of growth with respect to control cells, using data from
three independent experiments, measured at 540 nm (reference filter 620 nm) using a microplate
reader (Sirio S, SEAC Radim group).
2.7. Wound Healing Assay
A wound healing assay was used to assess cell migration after treatment with test compounds
6
[20]. MCF-7 cells were seeded in six-well plates (1 × 10 cells per well) and wounds were created in
90% confluent cells using a sterile pipette tip. Afterwards, cells were washed with phosphate buffered
saline (PBS) to eliminate free-floating cells, medium was added, and the culture plates were incubated
at 37 °C. Experiments were conducted in triplicate. Wound healing was observed at 0 h, 24 h, and 48
h post-scratching, and representative images were obtained by a transmitted-light microscope
equipped for live-cell imaging (OMAX Trinocular Compound EPI-Fluorescence Microscope
M834FLR model on a ×4 magnification). The wound area percentage was calculated as the wound
area from t = 24 h or t = 48 h vs. the wound area from t = 0 h in each group.
2.8. Confocal Microscopy Imaging and Localization Study
6
2
Cells (5 × 10 cells/well) were grown on 0.22 cm glass cover slips (Fisher Scientific, Waltham,
MA, USA) placed into six-well cultured plates containing 1.5 mL of culture medium for 24 h at 37 °C.
The incubation of cells exposed to test analogs was for 3 h and 24 h at 37 °C. The cover slips were

Biomolecules 2019, 9, 177
6 of 15
then recovered, rinsed twice with PBS, fixed with 10% paraformaldehyde in PBS, and nuclei stained
with DAPI (Thermo Fisher Scientific, Waltham, MA, USA), 1% w/v in PBS. Subsequently, cover slips
were washed three times with PBS and analyzed for imaging using a confocal laser scanning
microscope ×60 magnifications (Leica TCS SP8 MP, inverted confocal microscope with Acousto-
Optical Beam Splitter, Wetzlar, Germany). Images were acquired with the spectral detector of the
microscope using appropriate emission wavelength ranges; DAPI stained nuclei were excited at 780
nm with a two-photon IR Mai Tai DeepSee Ti: Sapphire laser (Spectra-Physics/Newport, Santa Clara,
CA, USA) and emission was recorded between 420–500 nm. Cellular fluorescence was analyzed using
the Leica Application Suite software; LAS X software platform.
2.9. Statistical Analysis
The data are presented as the mean ± standard deviation of the experiments performed in
triplicate. Statistical comparisons were carried out using Student’s t test. p < 0.05 and p < 0.01 were
considered to be significant.
3. Results and Discussion
3.1. Topoisomerase-I Mediated DNA Relaxation Assay
Interactions between both DNA and a drug molecule are dependent on their respective
structural features, and interactions can be determined through several biochemical and biophysical
experimental methods [21]. To characterize the intercalative ability of acridone and biacrylidene
derivatives, topoisomerase-I (topo-I) mediated relaxation of negatively supercoiled DNA was
examined. Ethidium bromide (EtBr) is routinely used as a reference compound to evidence
topoisomerase I-induced DNA relaxation, while doxorubicin is employed a topoisomerase poison
[22]. At low concentrations of EtBr exposure, the intercalation of the planar cationic molecule into a
supercoiled plasmid induces complete relaxation of negatively supercoiled (SC) DNA resulting in a
slower DNA migration pattern through the agarose medium (0.5 μM). As the concentration of the
molecule is further increased, the DNA molecules wind in the opposite direction, inducing positively
SC DNA with an electrophoretic mobility close to that of negatively charged SC DNA (1–10 μM) [23].
The unwinding profile observed in the case of EtBr is signature of classical intercalation by the planar
heteroaromatic molecule. The concentration of a drug molecule required to produce fully relaxed
DNA varies from compound to compound, reflecting their respective binding affinities to negatively
SC DNA. The family of N-alkylacridones and N,N′-dialkyl-9,9′-biacrylidenes were investigated at
both neutral (pH 7.2) and acidic (pH 5.8) environments and directly compared to control agents EtBr,
doxorubicin, and simple unsubstituted acridone.
At a neutral pH, acridone derivatives 2–5 have no influence on DNA supercoiling in the presence
of topo-I (Figure S1). When the hydrocarbon tail of the N-alkyl-acridones increases in length from 12
to 15 carbon atoms (6) some evidence of unwinding was evident at higher concentrations (Figure 2a).
A similar effect can be observed in the case of the N,N′-dialkyl-9,9-biacridylidene series, when the
carbon chain length increases stepwise from 1 to 12 carbon atoms (7, 9, 10, 11, and 12) as shown in
Figure 2a and Figure S2). Under acidic conditions, a release of supercoiling from the plasmid can be
observed for pentadecyl-acridone 6 (Figure 2b). Similarly, when the hydrocarbon tail of
biacridylidene derivatives increases in length (analogues 7, 11 and 12) positively charged supercoils
appear at higher loading concentrations (Figure 2b).

Biomolecules 2019, 9, 177
7 of 15
Figure 2. Topoisomerase-I mediated DNA relaxation assay in the presence of increasing
concentrations (10–400 μΜ) of N-alkylacridone 6 and N,N′-dialkyl-9,9′-biacridylidenes 7, 11, and 12
at pH 7.2 (a) and pH 5.8 (b), respectively.
3.2. DNA binding Study
Serial dilutions of each analog were incubated with CT-DNA. Titrations were performed by
maintaining the analog concentration and varying [CT-DNA] by adding (R = [CT-DNA] /
[Compound] = 1:50, 1:10, 1:5, 1:2). UV–Vis spectra of the samples incubated with CT-DNA were
recorded at 37 °C for 24 h, indicating that a new complex formed between the compounds and the
double-helix of CT-DNA. The intrinsic binding constant, Kb was calculated using the following
equation:
[DNA]/(εa − εf) = [DNA]/(εb − εf) + 1/Kb(εb − εf),
(2)
where εa, εf, and εb are the apparent, free, and bound complex extinction coefficients, respectively. εf
was determined from the calibration curve of the analogues following Beer’s law, whereas εa is the
ratio between the measured absorbance and the analogue concentration (Absorbance/compound
concentration). The plot of [DNA]/(εa − εf) versus [DNA] has a slope of 1/(εb − εf) and the intercept is
equal to 1/Kb(εb − εf); Kb is the ratio of the slope to the intercept [24]. In the intercalative binding mode,
the π* orbital of the intercalated ligand can couple with the π orbital of the DNA base pairs, thus,
decreasing the ππ* transition energy and resulting in bathochromism. Moreover, the coupling π
orbital is partially filled by electrons, thus, decreasing the transition possibilities and concomitantly
results in hypochromism. Generally, the binding of an intercalative molecule to DNA is accompanied
by hypochromism and/or significant red-shift (bathochromism) in the absorption spectra due to the
strong stacking interaction between the aromatic chromophore of the compound and DNA base pairs
with the extent of hypochromism and red-shift commonly consistent with the strength of the
intercalative interaction [25].The hyperchromic effect may be ascribed to external contact
(electrostatic binding) or to partial unwinding of the helical structure of DNA, exposing more bases
of DNA. Increasing concentrations of CT-DNA led to a modified absorption pattern in a selection of
analogs from each family, as illustrated in Figure 3. Compounds were diluted in a mixture of DMSO
(0.8% for 2, and 1% for 9) in tris-citrate buffer (containing 150 mM NaCl and 15 mM trisodium citrate
at pH 7.0). Hyperchromicity was observed in N-butylacridone 2, whereas hypochromicity was
indicated at the N,N′-dibutyl-9,9′-biacridylidene 9. The Kb values were calculated (Table 1) and found
to be similar to the reported data for the classical intercalator ethidium bromide, as its binding

Biomolecules 2019, 9, 177
8 of 15
7
−1
constant is in the order of 10 M [26]. The above results show the binding of N-alkylacridones and
N,N′-dialkyl-9,9′-biacridylidenes to CT-DNA is likely to occur via intercalation. Binding properties
of the above derivatives with CT-DNA were also investigated after 48 h incubation. The results,
however, revealed that 24 h incubation is adequate for the compounds to bind CT-DNA. The binding
constant (Kb) in 24 h was also found to be stronger than that in 48 h (Table 1).
Figure 3. Absorption spectra of N-butylacridone 2 and N,N′-dibutyl-9,9′-biacridylidene 9 in 15 mM
trisodium citrate-150 mM NaCl buffer (pH 7.0) in the presence of increasing amounts of CT-DNA
after 24 h incubation. (a) R= [CT-DNA] / [acridone 2] = 1/50, 1/10, 1/5, and 1/2 and the linear fit of
[DNA]/(ea − ef) vs. [DNA] for the titration of CT-DNA with acridone 2; (b) R= [CT-DNA] /
[biacridylidene 9] = 1/50, 1/10, 1/5, and 1/2 and the linear fit of [DNA] / (ea − ef) vs. [DNA] for the
titration of CT-DNA with biacridylidene 9.
Table 1. Kb values of N-butylacridone 2 and N,N′-dibutyl-9,9′-biacridylidene 9 and the observed
change in UV–Vis absorption spectra after incubation with CT-DNA for 24 and 48 h respectively.
6
−1
6
−1
Kb × 10 (M )
Kb × 10 (M )
Compound λmax (nm) Change in Absorbance
Incubation 24 h Incubation 48 h
2
9
255.5
258.5
Hyperchromicity
Hypochromicity
4.0
66.7
2.0
22.2
3.3. DPPH and ABTS Radical Scavenging Activity
Primary antioxidants are usually aromatic alcohols (phenols or polyphenols), which neutralize
free radicals and other reactive oxygen species (ROS) via electron transfer or hydrogen atom transfer
[26–28]. Similar behavior can be attributed, to a lesser extent, to secondary aromatic amines (anilines),
which contain labile hydrogen atoms on the nitrogen atom. Studies on the antioxidant activity of
diphenylamine derivatives showed that indeed the antioxidant effect of these derivatives lies in their
NH functional group [29]. The reactivity of secondary amines, such as 9,10-dihydroacridine or
unsubstituted 9,9′-dihydroacridine toward peroxyl radicals, was about five orders of magnitude
lower than the corresponding value of the well-known antioxidant trolox. Kinetic measurements
including various dihydroacridines revealed that the radical scavenging effect was essentially

Biomolecules 2019, 9, 177
9 of 15
attributed to the N−H bond despite the fact that in 9,10-dihydroacridine the calculated C−H bond
dissociation enthalpy at C9 is about 11 kcal/mol lower than the N−H [30]. The radical trapping activity
of N,N′-unsubstituted or N,N′-substituted 9,9′-biacridylidenes, has to our knowledge not been
explored. To our surprise, biacriylidenes 7–12 presented high radical scavenging activities towards
DPPH and ABTS radicals, in some cases similar to that of trolox (Table 2). This behavior may be
attributed to strong donating ability of labile electrons at N-atoms of the heteroaromatic system and
stabilization of nitrogen or carbon radicals through the extended conjugation of the aromatic system.
Their radical scavenging activities are expressed as IC50 or trolox-equivalent antioxidant capacity
values (TEAC-values). TEAC values were calculated by dividing the mean value of IC50 of a
compound through the IC50 of trolox. A lower TEAC value indicates a higher radical scavenging
activity.
Table 2. Free radical-scavenging activity of N,N′-dialkyl-9,9-biacridylidenes derivatives measured by
DPPH and ABTS assay, respectively. Experiments were performed in triplicate. Results were
expressed as IC50 ± standard deviation or TEAC values.
Radical Scavenging Activity (μM)
1
1
Analog
DPPH-Assay
ABTS-Assay
IC50 ± sd (TEAC) IC50 ± sd (TEAC)
7
8
16.98 ± 0.88 (1.03) 32.32 ± 1.90 (3.68)
33.7 ± 2.1 (2.00)
9.33 ± 0.42 (1.07)
9
30.2 ± 1.17 (1.44) 21.45 ± 1.15 (1.14)
28.350 ± 3.1 (1.69) 16.88 ± 1.25 (1.92)
17.73 ± 0.53 (1.05) 12.43 ± 0.86 (1.42)
16.02 ± 0.56 (0.96) 24.1 ± 1.11 (1.52)
10
11
12
Caffeic acid 6.95 ± 0.46 (0.42)
8.67 ± 0.36 (0.99)
8.78 ± 0.29 (1.0)
Trolox 16.76 ± 0.54 (1.0)
1
Data are the mean value of three different determinations; trolox-equivalent antioxidant capacity
(TEAC) values in parenthesis were calculated by dividing the mean of IC50 value of the analog
through the IC50 value of trolox.
3.4. MTT Assay
This colorimetric assay is based on the reduction of the yellow water-soluble tetrazolium salt
(MTT) into an insoluble crystalline blue formazan product by cellular oxidoreductases of viable cells.
This transformation is not possible on dead cells, therefore, the resulting formazan crystal formation
is proportional to the number of viable cells with an active metabolism. MTT assay was therefore
employed to measure cell metabolic activity in MCF7 cells exposed to N-alkyl-acridones (1–6) and
N,N′-dialkyl-9,9′-biacridylidenes (7–12). The compounds were found to clearly effect cell viability as
concentration increased in the range of 0.01 and 100 μΜ, over 24, 48, and 72 h. As illustrated in Figure
4, N-alkylacridones showed significant activity in a dose-depended manner at 24 h. N-Methylaridone
1 exhibited the strongest effect with an IC50 value of 6.75 μΜ (Table 3), derivatives 2 and 3, containing
respective butyl and heptyl groups, followed thereafter (10.1 and 11.67 μΜ), while analogs 4, 5, and
6 had similar cytotoxic behavior (IC50 13.80, 14.81 and 14.13 μΜ, respectively). On the other hand,
N,N′-dialkyl-9,9′-biacridylidenes exhibited similar dose dependent activity, with attenuated viability
status compared with the previous six acridone derivatives (Figure 4). Compounds 7 and 8 including
methyl and methoxy-methyl groups in their scaffold were characterized by IC50 values 19.13 and
15.65 (Table 3) while 9–12 containing butyl, heptyl, decyl, and dodecyl alkyl chains, respectively,
exhibited weaker cytotoxic effects with IC50 values at higher concentrations (28.40–33.95 μM, Table
3). Furthermore, all compounds were tested in a time-dependent manner of the doses applied. As
presented in Figure 4, acridone derivatives 1 to 6 and biacridylidenes 7 to 12 present significant, dose-
dependent inhibition of cell growth. Methyl acridone 1, the most potent among the tested derivatives,
pinpointed 100 μΜ as the maximum inhibitory effect on cell growth (20% at 48 h and 18% at 72h,
respectively) compared to control cells (Figure 4). However, analogs 2, at the same concentration,

Biomolecules 2019, 9, 177
10 of 15
reduced viability rates significantly (approximately 75–65%) while biacridylidene analogs 7–12
presented inhibition rates of 58–38% at 48h and 40–52% at 72 h, respectively.
Figure 4. Dose-dependent response of MCF-7 epithelial breast cancer cells to test compounds 1–12.
The concentration range was from 0.01 to 100 μM and the incubation time was 24, 48, and 72 h in a
serum containing medium. Under the same conditions, results are presented as percentage of growth
in respect to the control cells. Each point represents the mean ± standard deviation from the
experiments in triplicate. Asterisks mark the statistically significant levels using the Student t-test: *p
<0.05, **p <0.01, respectively, as compared to control cells.

Biomolecules 2019, 9, 177
11 of 15
Table 3. IC50 Values (μΜ) for N-alkyl-acridone and N,N′-dialkyl-9,9-biacridylidene analogs treated
with MCF-7 breast cancer cells for 24, 48, and 72 h incubation. As no total inhibition was observed for
some derivatives the corresponding values could be given as relative IC50.
Analog 24 h 48 h 72 h
1
2
3
4
5
6.75
1.77
0.02
1.89
3.32
3.78
4.27
5.16
10.01 4.07
11.67 5.30
13.80 8.07
14.81 7.74
14.13 8.74
6
7
8
19.13 11.75 9.57
15.65 8.78 6.70
9
28.40 18.45 10.60
30.95 17.29 14.05
34.54 23.10 14.64
33.95 23.40 14.38
10
11
12
3.5. Wound-Healing Assay
The wound healing (scratch repair) assay represents a simple approach commonly used to
measure basic cell migration parameters and cell–cell interactions mimicking to some extent in vivo
conditions, identifying the degree of migration of cancer cells caused by treatments [31,32]. MCF-7
cells were seeded and allowed to reach 90% confluence. Cells were then wounded by scratching with
a sterile pipette in the presence or absence of test derivatives and representative images were taken
at 0, 24, and 48 h after the initial scratch was performed (Figure 5a). Control cells were healed after
48 while butyl-acridone 2 and heptyl-acridone 4 showed increased migration effectiveness compared
to biacridylidenes 9 and 11 (60% vs. 50–55%, respectively, Figure 5c).

Biomolecules 2019, 9, 177
12 of 15
Figure 5. (a) Representative images show the scratch (wound) at t ꢀ= ꢀ0,24 and 48 h with/without drug
treatments. Treatment with alkyl-acridones (2 and 4) and biacridylidenes (9 and 11) impairs migration
of MCF-7 cells. Untreated cells efficiently restore the monolayer after 48 h. (b) Quantification of
restored surface from three images for each timepoint in the absence/presence of analogs. (c) Graph
illustrating the % wound healing in MCF-7 cells upon treatment with the compounds after 24 and 48
h. Data represent mean ± standard deviation for three different experiments.
3.6. Confocal Microscopy Imaging and Localization Study
Both the substitution and the role of the carbon chain length on the intracellular localization of
selected compounds were investigated using confocal microscopy. Control acridone (ACR) revealed
a strong dose-dependent cytotoxic profile in MCF-7 cells with an IC50 value of 0.27 μΜ (Figure S3),
while it presented a well-characterized localization in a greater extent in the cell nucleus and less in
the cytoplasm as illustrated in Figure 6. MCF-7 cells were incubated with 1 μM of each analog for 3
h and the corresponding autofluorescence was depicted. Accumulation of 2 both in the nucleus and
cytoplasm is shown in Figure 6, while analog 4, which contains a longer alkyl chain, is mainly
accumulated in the cytoplasm. The N,N′-biacridylidene 9 incorporating butyl as an alkyl chain
allowed a small percentage of accumulation in the nucleus upon 3 h of incubation. On the other hand,
derivative 11, which includes a longer alkyl chain on the molecular scaffold, appeared to be diffused
primarily in the cytoplasm (Figure 6). To further examine any correlation between the time of
treatment and the resulting intracellular distribution, cells were treated with test derivatives for 24 h.
Exposure to analog 9 and 11 caused no appreciable effect, revealing that a small percentage of the
compound could penetrate the nucleus membrane. Analog 11 diffused into the cytoplasm while
analog 9 still exhibited small nuclear localization with a greater accumulation of the compound
remaining in the cytoplasm.

Biomolecules 2019, 9, 177
13 of 15
Figure 6. Determination of intracellular distribution of analogs 2, 4, 9, and 11 in MCF-7 breast cancer
cells. Acridone (ACR) was used as a control. Cells were treated with 1 μM of each derivative and after
3 h of incubation, cells were imaged by confocal microscopy. Blue is the DAPI (4′,6-diamidino-2-
phenylindole) nuclear stain.
4. Conclusions
Acridone analogs are well known chemotherapeutic agents that can interact with nucleic acids.
As such, structural modifications around this scaffold is of great interest, and facilitates the tuning of
DNA intercalative properties [33]. The present study identified the topoisomerase I unwinding
activity, DNA binding properties, and cytotoxic activity against MCF-7 breast cells of a series of N-
alkylacridones and N,N′-dialkyl-9,9′-biacridylidenes substituted with varying alkyl chains. The
topoisomerase-I mediated DNA relaxation assay can be successfully employed to determine the
intercalating propensity of a drug molecule by observing the ability of topo-I to mediate relaxation
of a topologically constrained negatively supercoiled DNA molecule. Our study revealed the
promising potential mainly of the short alkyl substituted analogs after concentration dependent
cytotoxicity screening on the selective cancer cell line. According to fluorescence microscopy, these
compounds accumulated both in the nucleus and cytoplasm and potently inhibited cell proliferation
instead of the longer substituted analogs which largely remained in the cytoplasm. These studies

Biomolecules 2019, 9, 177
14 of 15
revealed that most alkyl-based acridone derivatives have potent cytotoxic activity compared with
biacridylidenes with longer alkyl substituents. By interacting with DNA and inhibiting
topoisomerases activity, biological activity was established for small planar polycyclic aromatic
molecules, such as acridone, representing a promising lead moiety for the development of novel
effective anticancer DNA binding agents.
Supplementary Materials: The following are available online at www.mdpi.com/xxx/s1, Figure S1:
Topoisomerase-I mediated DNA relaxation assay of control acridone and N-alkylacridones 2–5 at pH 7.2; Figure
S2: Topoisomerase-I mediated DNA relaxation assay of N,N′-dialkyl-9,9′-biacridylidenes 8, 9 and 10 at pH 7.2;
Figure S3: Dose-dependent response of MCF-7 epithelial breast cancer cells to control acridone; Figure S4:
Intracellular distribution of 9 and 11 after 24 h; Table S1: Free radical-scavenging activity of N,N′-dialkyl-9,9′-
biacridylidenes calculated by the DPPH-assay; Table S2: Free radical-scavenging activity of N,N′-dialkyl-9,9′-
biacridylidenes calculated by the APTS-assay.
Author Contributions: Conceptualization, C.C., A.K., M.G.K., Z.M., E.K.E., K.P.; writing—original draft
preparation: M.G.K., Z.M., A.K. and C.C.; supervision: C.C., K.P., A.K.; formal analysis: M.K., S.-M.A., I.D. A.M.;
validation: C.C., A.K., K.P., M.G.K., E.K.E.; funding acquisition: C.C., K.P., A.K.; investigation: C.C., A.K., K.P.,
M.G.K., Z.M. and E.K.E.
Funding: This research has been co-financed in part by the European Union (European Social Fund - ESF) and
Greek National Funds through the Operational Program KRIPIS Action of the National Strategic Reference
Framework (NSRF). AK and ZM acknowledge support from the Science Foundation Ireland (15/CDA/3648).
Acknowledgments: We thank Dr. Michalis Zachariadis from the Confocal Microscopy Unit of the Institute of
Biology and Applications, NCSR Demokritos for technical help.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
Xia, Y.F.; Chu, H.J.; Kuang, G.F.; Jiang, G.J.; Che, Y.C. Inhibition effects of acridone on the growth of breast
cancer cells in vivo. Eur. Rev. Med. Pharmacol. Sci. 2018, 22, 2356–2363.
2.
Bin, Z.; Kang, C.; Ning, W.; Chunmei, G.; Qinsheng, S.; Lulu, L.; Yuzong, C.; Chunyan, T.; Hongxia, L.;
Yuyang, J. Molecular design, synthesis and biological research of novel pyridyl acridones as potent DNA-
binding and apoptosis-inducing agents. Eur. J. Med. Chem. 2015, 93, 214–226.
3.
4.
Gensicka-Kowalewska, M.; Cholewiński, G.; Dzierzbicka, K. Recent developments in the synthesis and
biological activity of acridine/acridone analogues RSC Adv. 2017, 7, 15776–15804.
Gao, C.; Zhang, W.; He, S.; Li, S.; Liu, F.; Jiang, Y. Synthesis and antiproliferative activity of 2,7-diamino l0-
(3,5-dimethoxy)benzyl-9(10H)-acridone derivatives as potent telomeric G-quadruplex DNA ligands.
Bioorg. Med. Chem. 2011, 19, 3312–3319.
5.
6.
Mayur, Y.C.; Zaheeruddin; Peters, G.J.; Lemos, C.; Kathmann, I.; Prasad, V.V. Synthesis of 2-fluoro N(10)-
substituted acridones and their cytotoxicity studies in sensitive and resistant cancer cell lines and their
DNA intercalation studies. Arch. Pharm. 2009, 342, 640–650.
Goodell, J.R.; Ougolkov, A.V.; Hiasa, H.; Kaur, H.; Remmel, R.; Billadeau, D.D.; Ferguson, D.M. Acridine-
based agents with topoisomerase II activity inhibit pancreatic cancer cell proliferation and induce
apoptosis. J. Med. Chem. 2008, 51, 179–182.
7.
8.
9.
Wang, J.C. Cellular roles of DNA topoisomerases: A molecular perspective. Nat. Rev. Mol. Cell Biol. 2002, 3,
430–440.
Khadka, D.B.; Cho, W.J. Topoisomerase inhibitors as anticancer agents: A patent update. Expert Opin. Ther.
Pat. 2013, 23, 1033–1056.
Pommier, Y. Topoisomerase I inhibitors: Camptothecins and beyond. Nat. Rev. Cancer 2006, 6, 789–802.
10. Pommier, Y.; Leo, E.; Zhang, H.; Marchand, C. DNA topoisomerases and their poisoning by anticancer and
antibacterial drugs. Chem. Biol. 2010, 17, 421–433.
11. K. Papadopoulos, K.; Nikokavouras, J. Reactions of lucigenin in protic solvents in the presence of amines,
J. Prakt. Chem.-Chem. Zeitung 1994, 336, 506–509.
12. Papadopoulos K.; Nikokavouras, J. Synthesis of N,N′-dialkyl-9,9′-biacridylidenes and 9,9′-biacridinium
nitrates containing long alkyl chains. J. Prakt. Chem. 1993, 335, 633–636.

Biomolecules 2019, 9, 177
15 of 15
13. Papadopoulos K.; Nikokavouras, J. Synthesis of novel protected hemiaminal N-methoxymeothyl-N′-
methyl-9,9′-biacridylidene from lucigenin. Tetrahedron. Lett. 1993, 34, 1371–1372.
14. Zuin Fantoni, N.; Molphy, Z.; Slator, C.; Menounou, G.; Toniolo, G.; Mitrikas, G.; McKee, V.; Chatgilialoglu,
C.; Kellett, A. Polypyridyl-based copper phenanthrene complexes: A new type of stabilized artificial
chemical nuclease. Chem.–Eur. J. 2019, 25, 221–237.
15. Raman, N.; Pothiraj, K.; Baskaran, T. DNA interaction, antimicrobial, electrochemical and spectroscopic
studies of metal(II) complexes with tridentate heterocyclic Schiff base derived from 2′-
methylacetoacetanilide. J. Mol. Struct. 2011, 1000, 135–144.
16. El-Asmy, H.A.; Butler I.S., Mouhri Z.S.; Jean-Claude B.J.; Emmam, M.S.; Mostafa, I. Synthesis,
characterization and DNA interaction studies of new complexes containing 2-mercaptobenzothiazole and
different dinitrogen or phosphorous aromatic donors. Inorg. Chim. Acta 2016, 441, 20–33.
17. Brand-Williams, W.; Cuvelier, M.E.; Berset, C. Use of a free radical method to evaluate antioxidant activity
LWT. Food Sci. Tech. 1995, 28, 25–30.
18. Floegela, A.; Kim, D-O.; Chung, S-J.; Koo, S.I.; Chun, O.K. Comparison of ABTS/DPPH assays to measure
antioxidant capacity in popular antioxidant-rich US foods. J. Food Comp. Anal. 2011, 24, 1043–1048.
19. Mosmann, T. Rapid colorimetric assay for cellular growth and survival: Application to proliferation and
cytotoxicity assays. J. Immunol. Meth. 1983, 65, 55–63.
20. Liang, C.C.; Park, A.Y.; Guan, J.L. In vitro scratch assay: A convenient and inexpensive method for analysis
of cell migration in vitro. Nat. Protoc. 2007, 2, 329–333.
21. Kellett, A.; Molphy, Z.; Slator, C.; McKee, V.; Farrell, N.P. Molecular methods for assessment of non-
covalent metallodrug-DNA interactions. Chem. Soc. Rev. 2019, 48, 971–988.
22. Slator, C.; Molphy, Z.; McKee, V.; Kellett, A. Triggering autophagic cell death with a di-manganese(II)
developmental therapeutic. Redox Biol. 2017, 12, 150–161.
23. Slator, C.; Molphy, Z.; McKee, V.; Long, C.; Brown, T.; Kellett, A. Di-copper metallodrugs promote NCI-60
chemotherapy via singlet oxygen and superoxide production with tandem TA/TA and AT/AT
oligonucleotide discrimination. Nucleic Acids Res. 2018, 46, 2733–2750.
24. Shahabadi, N.; Mohammadi, S.; Alizadeh, R. DNA interaction studies of a new platinum(II) complex
containing different aromatic dinitrogen ligands. Bioinorg. Chem. Appl. 2011, 2011, 429241.
25. Waring, M. J. Complex formation between ethidium bromide and nucleic acids. J. Mol. Biol. 1965, 13, 269–
282.
26. Zhang, H.; Tsao, R. Dietary polyphenols, oxidative stress and antioxidant and anti-inflammatory effects.
Curr. Opin. Food Sci. 2016, 8, 33–42.
27. Velena, A.; Zarkovic, N.; Troselj, G.K.; Bisenieks, E.; Krauze, A.; Poikans, J.; Duburs, G. 1,4-
Dihydropyridine derivatives: Dihydronicotinamide analogues-model compounds targeting oxidative
stress. Oxid. Med. Cell. Longev. 2016, 2016, 1892412.
28. Csepregi, K.; Neugart, S.; Schreiner, M.; Hideg, É. Comparative evaluation of total antioxidant capacities
of plant polyphenols. Molecules 2016, 21, 208.
29. Sugihara, T.; Rao, G.; Hebbel, R.P. Diphenylamine: An unusual antioxidant. Free Radic. Biol. Med. 1993, 14,
381–387.
30. Mulder, P.; Litwinienko, G.; Lin, S.; MacLean, P.D.; Barclay, L.R.; Ingold, K.U. The L-type calcium channel
blockers, hantzsch 1,4-dihydropyridines, are not peroxyl radical-trapping, chain-breaking antioxidants.
Chem. Res. Toxicol. 2006, 19, 79–85.
31. Cory, G. Scratch-wound assay. Methods Mol. Biol. 2011, 769, 25–30.
32. Jonkman, J.E.; Cathcart, J.A.; Xu, F.; Bartolini, M.E.; Amon, J.E.; Stevens, K.M.; Colarusso, P. An
introduction to the wound healing assay using live-cell microscopy. Cell Adh. Migr. 2014, 8, 440–451.
33. Zhang, B.; Li, X.; Li, B.; Gao, C.; Jiang, Y. Acridine and its derivatives: A patent review (2009–2013). Expert
Opin. Ther. Pat. 2014, 24, 647–664.
© 2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
