Abstract Graphic

ACCEPTED MANUSCRIPT
Selective “off-on” detection of Magnesium (II) ions using
naphthalimide-derived fluorescent probe
1
2
3
4
a
Huifang zhanga,1, Caixia Yina,*, Tao Liua,1, Jianbin Chaob, Yongbin Zhangb, Fangjun
Huob,**
5
6
aKey Laboratory of Chemical Biology and Molecular Engineering of Ministry of
Education, Key Laboratory of Materials for Energy Conversion and Storage of
Shanxi Province, Institute of Molecular Science, Shanxi University, Taiyuan, 030006,
China;bResearch Institute of Applied Chemistry, Shanxi University, Taiyuan, 030006,
China.
7
8
9
10
11
*Corresponding author: C.X. Yin, E-mail: yincx@sxu.edu.cn;
**Corresponding author: F.J. Huo, Email: huofj@sxu.edu.cn.
12
13
14
15
16
17
18
19
20
21
22
23
24
Abstract: A novel “off-on” fluorescent probe based on 1, 8-naphthalimide derivative
for the detection of Mg2+ in ethanol solution was designed and synthesized. The probe
displayed responses to Mg2+ with a fluorescence enhancement at 523 nm,
accompanying with a distinct fluorescence change from nearly colorless to bright
yellow-green. Besides, the probe showed a rapid detection process (45 s), high
fluorescence enhancement (up to 15-fold), a good binding constant (6.17×105 M-1)
and a low detection limit of Mg2+ (5.01×10-8 M). Moreover, density functional theory
(DFT) calculations were also performed to support the responding mechanism
between the probe and the coordination complex. In addition, the cell cytotoxicity
experiments suggested that the probe is nearly non-toxic and the fluorescence
scanning microscopic experiments demonstrated that the probe was capable of
monitoring at the intracellular Mg2+ level successfully.
Keywords: Fluorescent probe; off-on; Mg2+; DFT calculation; Bioimaging.

ACCEPTED MANUSCRIPT
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
1. Introduction
The magnesium (Mg2+) ion is an abundant divalent cation in the cells and
environment [1-2]. Intracellular Mg2+ plays important roles in many physiological
processes including the activities of ion channels in membrane proteins and regulation
of hundreds of enzymes such as RNA polymerases, ATPases, protein kinases,
phosphatases, glutathione synthase, and carboxylases and so on [3-18]. Moreover, a
decrease in Mg2+ concentration and abnormal metabolic processing of intracellular
Mg2+ has been implicated in the causes of gastrointestinal, renal losses,
hypocalcaemia and neurological manifestations, especially, a number of chronic
diseases, such as diabetes, osteoporosis, and coronary heart have been associated with
chronic low magnesium [19]. In the environment, high levels of Mg2+ will become
toxic to plants, which can enhance the role of antagonism between ions when crops
absorb the nutrient elements, while magnesium deficiency can affect plant growth and
development, which led to the decrease of productivity and quality in agriculture
[20-21]. Therefore, it is crucial to develop efficient analytical methods for detecting
and monitoring of Mg2+ at the level of cells and in the environment.
Based on that, the fluorescence measurements go into people’s research scope
and small molecules fluorescent probes gradually get an active focus of research in
biological and environment field. Small molecules fluorescent probes are able to bind
the analyte selectively with a change in the sensing system property, such as
absorption, emission and redox potentials [22-24]. Besides, they are usually very
sensitive, low cost, easily performed, capability of real-time detection [25-27]. Until

ACCEPTED MANUSCRIPT
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
now, various fluorescent probes for Mg2+ have been developed. These probes have
receptor groups based upon moieties including diaza-28-crown-6, benzo-15-crown-5,
calix[4]arene, Benzo chromene, Imdiazo-1, 10-phenanthroline and other [1, 7, 17,
28-39]. Most of the reported fluorescent probes for Mg2+ demonstrate poor selectivity
for Mg2+ over Ca2+ and are available only when the Mg2+ ion concentrations are much
high than Ca2+ ion [40].
Enlightened by this, we have driven 1, 8-naphthalimide to react with
2-hydrazinylbenzo[d]thiazole to generate O-hydroxyl Schiff base that possessing O
and N atoms with specific affinity to Mg2+ based on hard and soft acids and bases rule
(HSAB) and we choose O-hydroxyl Schiff base as recognizer to realize “off-on”
fluorescence recognition [41-44]. Herein we demonstrated the recognition
performance of probe for Mg2+ in ethanol solution, and the simple structure molecule
showed the rapid respond ability for Mg2+ with no interference from calcium ion as
we expected. Besides, the probe showed a rapid detection process (45 s), high
fluorescence enhancement (up to 15-fold), a good binding constant (6.17×105 M-1)
and a low detection limit of Mg2+ (5.01×10-8 M). Also the probe could detect the
intracellular Mg2+ in A549 cells by fluorescence bio-imaging under confocal laser
scanning microscopy. All of the above results make probe have a superior potential
for the detection of Mg2+ in complex bio-systems.
2. Experimental section
2.1 Instruments and materials
All chemicals and solvents were of analytical grade and bought from

ACCEPTED MANUSCRIPT
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
Sigma-Aldrich (St. Louis, MO) without further purification. The solutions of cation
were prepared from their chloride (CuCl2, ZnCl2, CrCl3, HgCl2, NiCl2, NaCl, KCl,
BaCl2, CaCl2, FeCl3, MnCl2, CoCl2, PbCl2, CdCl2, AlCl3 and MgCl2) and nitrate
(AgNO3). Fresh double distilled water was used throughout the experiment.
A pH meter (Mettler Toledo, Switzerland) was used to determine the pH.
Ultraviolet-visible (UV-vis) spectra were recorded on a Cary 50 Bio UV-Visible
spectrophotometer and fluorescence spectra were measured on F-7000 FL
fluorescence spectrophotometer. A PO-120 quartz cuvette (10 mm) was purchased
from Shanghai Huamei Experiment Instrument Plants, China. 1H NMR and 13C NMR
spectra were recorded on a Bruker AVANCE III-600 MHz and 150/151 MHz NMR
spectrometer (Bruker, Billerica, MA) respectively, using tetramethylsilane as the
internal standard for chemical shifts. ESI-MS was carried out on AB Triple TOF
5600plus System (AB SCIEX, Framingham, USA). MS was carried out on Thermo
Scientific Q Exactive. The cell viability assay was carried out by CCK-8 and
measured at 450 nm on a microplate reader. The bioimaging was imaged by laser
confocal fluorescence imaging using Airyscan confocal laser scanning microscope.
2.2 Preparation and characterization of the probe
2.2.1 Preparation and characterization of 2
The synthesis approach of probe is summarized in Scheme 1. A mixture of
4-bromo-1, 8-naphthalic anhydride (0.831 g, 3 mmol) and n-butylamine (0.219 g, 3
mmol) in ethanol (30 mL) was refluxed for 5 h. After the reaction was completed, the
reaction mixture was evaporated in vacuum and dried to obtain a solid product. Later

ACCEPTED MANUSCRIPT
91
92
on, the solid was purified by chromatography on a silica gel column in
1
dichloromethane resulted in a pale yellow solid product (0.877 g) in 88% yield. H
93
NMR (DMSO-d6, 600 MHz): δ (ppm): 8.53 (d, J = 7.9 Hz, 2H), 8.30 (d, J = 7.6 Hz,
1H), 8.19 (d, J = 7.7 Hz, 1H), 7.98 (t, J = 7.8 Hz, 1H), 4.02 (t, J = 7.3 Hz, 2H), 1.61
94
13
95
(m, 2H), 1.36 (m, 2H), 0.93 (t, J = 7.4 Hz, 3H). C NMR (DMSO-d6, 150 MHz): δ
96
(ppm): 163.2, 132.9, 131.9, 131.7, 131.3, 130.1, 129.5, 129.2, 128.6, 123.1, 122.3,
30.0, 20.3, 14.2 (Fig. S1).
97
98
2.2.2 Preparation and characterization of 3
99
To a 100 mL radius flask, compound 2 (0.664 g, 2 mmol) and sodium methoxide
(0.108 g, 2 mmol) in methanol (20 mL) was refluxed for 8 h while CuSO4·5H2O
served as catalyst. Then the crude product was evaporated in vacuum and the residue
was added HCl (1 mol/L, 30 mL) to crystallize out. Subsequently, a solid separated by
filtration was purified by chromatography on a silica gel column in dichloromethane
100
101
102
103
104
105
106
107
108
109
110
111
112
1
to give a white product (0.493 g) in 87% yield. H NMR (DMSO-d6, 600 MHz): δ
(ppm): 8.49 (d, J = 8.3 Hz, 1H), 8.46 (d, J = 7.2 Hz, 1H), 8.42 (d, J = 8.2 Hz, 1H),
7.79 (t, J = 7.8 Hz, 1H), 7.29 (d, J = 8.3 Hz, 1H), 4.12 (s, 3H), 4.01 (t, J = 7.4 Hz, 2H),
1.60 (m, 2H), 1.35 (d, J = 14.8, 7.4 Hz, 2H), 0.93 (t, J = 7.4 Hz, 3H). 13C NMR
(DMSO-d6, 150 MHz): δ (ppm): 164.0, 163.4, 160.7, 133.7, 131.5, 129.0, 128.7,
126.8, 123.2, 122.3, 114.7, 106.7, 57.1, 30.2, 20.3, 14.2 (Fig. S2).
2.2.3 Preparation and characterization of 4
Compound 3 (0.425 g, 1.5 mmol) was added to 55% HI solution with refluxing
at 140°C for 7 h, and then the mixture solution was cooled to room temperature. After

ACCEPTED MANUSCRIPT
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
that, the mixture was slowly poured into ice water, filtered and washed with distilled
water. The pale yellow solid thus obtained was dried under vacuum to give compound
(0.376 g) in 93% yield. 1H NMR (DMSO-d6, 600 MHz): δ (ppm): 11.88 (s, 1H), 8.54
(d, J = 8.3 Hz, 1H), 8.48 (d, J = 7.2 Hz, 1H), 8.36 (d, J = 8.1 Hz, 1H), 7.77 (t, J = 7.7
Hz, 1H), 7.16 (d, J = 8.1 Hz, 1H), 4.02 (t, J = 7.3 Hz, 2H), 1.60 (m, 2H), 1.34 (m, 2H),
0.92 (t, J = 7.3 Hz, 3H). 13C NMR (DMSO-d6, 150 MHz): δ (ppm): 164.1, 163.5,
160.7, 134.0, 131.6, 129.6, 129.3, 126.1, 122.8, 122.3, 113.1, 110.4, 30.2, 20.3, 14.2
(Fig. S3).
2.2.4 Preparation and characterization of 5
To a stirred trifluoroacetic acid (20 mL), compound 4 (0.269 g, 1 mmol) and
hexamethylenetetramine (0.182 g, 1.3 mmol) was added, and then the mixture was
refluxed at 120°C for 10 h. After the remained solution poured into the mixture
solution of CHCl3 (10 mL) and HCl (1 mol/L, 10 mL) and stirred overnight, separate
the organic phase with a separatory funnel and wash the aqueous phase three times
with CHCl3 (10 mL×3). The merged organic layer was dried with sodium sulfate and
evaporated in vacuum to dry to a solid. Then the solid was purified by column
chromatography on a silica gel (ethyl acetate: petroleum ether = 1: 3) to get a pale
1
yellow product (0.166 g) in 56% yield. H NMR (DMSO-d6, 600 MHz): δ (ppm):
10.37 (s, 1H), 8.70 (m, 2H), 8.57 (d, J = 7.3 Hz, 1H), 7.87 (t, J = 7.8 Hz, 1H), 4.02 (t,
J = 7.4 Hz, 2H), 1.60 (m, 2H), 1.35 (d, J = 14.8, 7.5 Hz, 2H), 0.93 (t, J = 7.4 Hz, 3H).
13C NMR (DMSO-d6, 150 MHz): δ (ppm): 194.5, 165.1, 163.7, 163.0, 134.0, 133.2,
131.7, 130.5, 127.4, 124.0, 122.8, 117.6, 113.6, 30.1, 20.3, 14.2 (Fig. S4).

ACCEPTED MANUSCRIPT
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
2.2.5 Preparation and characterization of 7
To a solution of 2-chlorobenzo[d]thiazole (0.169 g, 1 mmol) in ethanol, N2H4·H2O
(80%, 5 mmol) was dropwise added with refluxing at 80°C for 5h. When cooled to
room temperature, the mixture was filtered, washed and recrystallized with ethanol.
The white solid thus obtained and dried under vacuum to get compound 7 (0.154 g) in
93% yield. 1H NMR (DMSO-d6, 600 MHz): δ (ppm): 9.01 (s, 1H), 7.68 (d, J = 7.8 Hz,
1H), 7.32 (d, J = 8.0 Hz, 1H), 7.20 (t, J = 7.6 Hz, 1H), 6.98 (t, J = 7.5 Hz, 1H), 5.03 (s,
2H). 13C NMR (DMSO-d6, 151 MHz): δ (ppm): 174.4, 153.9, 130.9, 125.8, 121.4,
120.7, 118.3 (Fig. S5).
2.2.6 Preparation and characterization of the probe
A mixture of 5 (0.149 g, 0.5 mmol) and 7 (0.083 g, 0.5 mmol) in ethanol (15 mL)
was refluxed for 5 h. After the reaction was completed, the reaction mixture was
filtered, washed with ethanol and dried to obtain a yellow solid product (0.218 g) in
98% yield. 1H NMR (CDCl3-d1, 600 MHz): δ (ppm): 8.82 (s, 1H), 8.79 (d, J = 8.3 Hz,
1H), 8.75 (d, J = 7.2 Hz, 1H), 8.69 (s, 1H), 7.87 (t, J = 7.7 Hz, 1H), 7.80 (d, J = 7.9
Hz, 1H), 7.74 (d, J = 8.1 Hz, 1H), 7.63 (t, J = 7.7 Hz, 1H), 7.50 (t, J = 7.6 Hz, 1H),
4.20 (t, J = 7.4 Hz, 3H), 1.84 – 1.63 (m, 3H), 1.46 (dq, J = 15.0, 7.4 Hz, 3H), 1.00 (t,
J = 7.3 Hz, 4H). 13C NMR (CDCl3-d1, 151 MHz): δ (ppm): 167.7, 164.9, 164.2, 160.9,
160.6, 160.3, 160.0, 154.7, 138.1, 135.3, 134.5, 130.6, 130.2, 129.3, 127.3, 126.0,
122.9, 122.6, 122.5, 122.0, 117.4, 115.9, 115.4, 114.5, 111.8, 111.7, 41.0, 30.0, 20.3,
13.7. ESI–MS m/z: [Probe + H]+ Calcd. for C24H21N4O3S 445.13, Found 445.13. IR
(KBr): 3174, 2996, 2959, 2872, 1926, 1886, 1776, 1693, 1649, 1609, 1510, 1470,

ACCEPTED MANUSCRIPT
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
1423, 1388, 1367, 1347, 1315, 1258, 1226, 1183, 1128, 1082, 1067, 1018, 950, 925,
889, 873, 822, 783, 741, 720, 687, 656, 597, 581, 552, 529, 501, 460, 450, 429 (Fig.
S6).
<Inserted Scheme 1>
2.3. Solutions preparation and optical measurements
The stock solutions (0.4 mM) of the probe in DMSO and stock solutions (0.4
mM) of the chlorizated salts of Cu2+, Ag+, Zn2+, Cr3+, Hg2+, Ni2+, Na+, K+, Ba2+, Ca2+,
Fe3+, Mn2+, Co2+, Pb2+, Cd2+, Al3+ and Mg2+ in aqueous solution were prepared
respectively. Test solution was prepared by placing 50µL of the probe stock solution
into a quartz cuvette upon the addition of various analytes and diluting the solution to
2 mL with ethanol at room temperature. UV–Vis and fluorescence spectra were
obtained in ethanol solution. And any changes in the fluorescence intensity are
monitored using a fluorescence spectrometer (λem = 523 nm, λex = 397 nm, slit: 5 nm/5
nm). Statistical analysis of the data was carried out using Origin 9.1.
2.4. Cell experiments
A549 cells were grown in Dulbecco’s Modified Eagle’s medium supplemented
with 12% Fetal Bovine Serum and 1% antibiotics at 37 °C in humidified environment
of 5% CO2 at 37 °C. Cells were plated on 6-well plate and allowed to adhere for 24 h.
Before the experiments, cells were washed with PBS 3 times. Different concentrations
of the probe were loaded into each well, with three duplicates for each concentration
(the final concentration of probe in well was 0, 1, 2, 3, 5, 15, 20 µM, respectivily) for
5 and 10 h. The study of the cellular toxicity of probe was carried out by using the

ACCEPTED MANUSCRIPT
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
Cell Counting Kit-8 (CKK-8) assay.
Probe dissolved in DMSO (50 µL, 0.4 mM) was added to the cell medium
(2mL) at 10 µM final concentration. After incubating for 30 min, excess probe was
gently washed with phosphate buffered saline (PBS, pH=7.4) three times. Meanwhile,
another portion of A549 cells pre-treated with probe was treated with Mg2+ (2 µM)
and incubated for further 30 min at 37 °C and then washed cells with PBS buffer three
times. Cell experiment was imaged with confocal microscopy at green channel.
3. Results and discussion
3.1. Recognition ability toward magnesium ion
3.1.1 Selectivity behavior of probe for Mg2+
The selectivity behavior for one kind of analyte over other substances is one of
the most important characteristics of the fluorescent probe. As shown in Fig. 1, the
fluorescence intensity of probe was weak when excited at 397 nm, no distinct
fluorescence intensity increased with addition of common important metal ions for
human: Cu2+, Ag+, Zn2+, Cr3+, Hg2+, Ni2+, Na+, K+ , Ba2+, Ca2+, Fe3+, Mn2+ , Co2+, Pb2+,
Cd2+, VO2+, and Al3+ up to 2 equiv. compared with Mg2+（Fig. S7 and S8）. We also
carried out the competitive experiments to further study the selectivity behavior and
the results showed that the probe could detect Mg2+ selectively (Fig. S11). The probe
for Mg2+ at about 523 nm displayed an obvious enhancement of fluorescence intensity
in ethanol solution at room temperature immediately, this “off-on” mechanism could
be attributed to the O-hydroxyl Schiff base that possessing O and N atoms with
specific affinity to Mg2+.

ACCEPTED MANUSCRIPT
201
202
203
204
205
206
207
208
209
210
<Inserted Figure 1>
3.1.2 Sensitivity behavior of probe for Mg2+
To evaluate the sensitivity of probe, we had titrated different concentration of
Mg2+ to probe with UV-vis absorption spectra and fluorescence spectra. Fig. 2 (a)
showed that the probe (10 µM) exhibited one absorption at 450 nm in the absence of
Mg2+, and with the addition of Mg2+ (0-2 µM), the absorption at 393 nm increased
gradually, accompanied with a decrease at 480 nm. Accordingly, as shown in Fig. 2
(b), upon excitation at 397 nm, the probe (10 µM) displays a weak emission band
centered at 523 nm. Addition of Mg2+ (0-2 µM) significantly increases the
fluorescence intensity with a 15-fold enhancement in fluorescence observed.
211
212
213
214
215
216
217
218
219
220
221
<Inserted Figure 2>
To investigate the detection limit of probe for Mg2+, probe (10 µM) was treated
with various concentrations of Mg2+ (0-2 µM) and the relative emission intensity at
523 nm in ethanol solution was plotted as a function of the Mg2+ concentration.
Subsequent data analysis revealed an excellent linear relationship (R2 = 0.9975)
between the relative fluorescence intensity at 523 nm and the Mg2+ concentration (Fig.
3). From the linear increase in the Mg2+-dependent fluorescence intensity of probe,
the detection limit (DL) of probe for Mg2+ was found to be 5.01×10-8 M (DL =
K×SD/S, where K= 3; SD is the standard deviation of the blank solution; S is the
slope of the calibration curve), which was enough for practical application in
detecting Mg2+ at the level of cells [45].
222
<Inserted Figure 3>

ACCEPTED MANUSCRIPT
223
224
225
226
227
228
Moreover, the Job’s plot analysis using fluorescence intensity changes indicated
a 1:2 complex ratio between Mg2+ and probe, where the products between molar
fractions and the intensity of the fluorescence emission were plotted against molar
fractions of under the condition of a constant total concentration. When the molar
fraction of probe/(probe+[Mg2+]) was 2/3, the emission intensity of probe-Mg2+
reached maximum (Fig. 4 and Fig. S9) [46-47].
229
230
231
232
233
234
235
<Inserted Figure 4>
The stability constant for probe-Mg2+ was calculated from the Benesi-Hildebrand
plots based on the standard equation: A0/(A-A0) ={εr/(εr-εc)} (1/K[Mg2+]+1), where A0
is the absorption of probe in the absence of Mg2+, and (A-A0) is the discrepancy of
absorption between the absence and presence of Mg2+; [Mg2+] is the concentration of
Mg2+ (Fig. 5) [48-49]. The stability constant Ks is given by the ratio of intercept/slop,
Ks = 6.17×105 M-1 (R2 = 0.9866) using the linear analysis.
236
237
238
239
240
241
242
243
<Inserted Figure 5>
Time-dependent modulation in the fluorescence spectra of probe was monitored
in the presence of 2 equiv. of Mg2+. The kinetic study showed that the fluorescence
emission at 523 nm was immediately initiated and leveled off within 45 s, displaying
a rapid response between probe and Mg2+ under the selected experimental conditions
(Fig. 6).
<Inserted Figure 6>
3.3 Proposed mechanism between probe and Mg2+

ACCEPTED MANUSCRIPT
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
To gain insight into the sensing mechanism of probe towards Mg2+, a series of
experiments were carried out. Firstly, according to a Job’s plot analysis at 523 nm,
when the molar fraction of probe/( probe+[Mg2+]) was 2/3, the emission intensity of
probe-Mg2+ reached maximum, which further demonstrated a 2: 1 complexation
stoichiometry for [probe-Mg2+] was established (Fig. 4). Besides, the product of
1
13
probe-Mg2+ was also synthesized and characterized, the H NMR, C NMR and MS
were all certified the proposed mechanism Fig. S10. The identification of the
coordination product in the ESI-MS analysis further certified the proposed mechanism:
a peak at m/z = 909.22 was clearly observed, corresponding to [probe+Mg-H]-
perfectly (Fig. 7).
<Inserted Figure 7>
Furthermore, the optimized configuration of probe and probe-Mg2+ was
calculated by Density Functional Theory (DFT) (Fig. 8). The structure for the
probe-Mg2+ complex was calculated, based on the 1:2 stoichiometric between Mg2+
and probe. In view of the participation of possible anions, the optimized structure
(probe-Mg2+) shows that one Mg2+ ion essentially coordinated with two oxygen atoms
of hydroxyl (d(Mg O)= 1.93192 and 1.93185 Å), two nitrogen atom of amino (d(Mg N)
=
…
…
2.12106 and 2.12114 Å), and the bond angle of the geometry are 108.14549º,
101.67700º, 88.44547º and 88.45404º respectively, which means a distorted
tetrahedral coordination geometry. Therefore, the computational results further
confirm the complexation occurs between probe and Mg2+, which are in agreement
with the conclusion above.

ACCEPTED MANUSCRIPT
<Inserted Figure 8>
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
All of above presumed that the “off-on” fluorescence could be attributed to the
coordination of hydroxyl group and N atom in C＝N to Mg2+ with 2:1 stoichiometry.
The proposed detection mechanism is shown in Scheme 2.
<Inserted Scheme 2>
3.4 Cell experiments
For the better practical application of the cellular probe, we studied the
concentration employed which could disturb living systems minimally. The cytotoxity
of probe was determined using the Cell Counting Kit-8 (CCK-8) by incubation with
A549 cells. The experiment showed that there is no significant cytotoxic responses
(cell viability ≥ 80%) for all of the tested cells after incubation for 5 h and 10 h with
different concentration of the probe (the final concentration of probe in well was 0, 1,
2, 3, 5, 15, 20 µM) (Fig. 9).
<Inserted Figure 9>
In order to evaluate the reaction of probe to intracellular Mg2+, cellular imaging
studies were also carried out (Fig. 10). As shown in Fig. 10b, A549 cells incubated
with 10 µM of probe for 30 min at 37 ℃ showed nearly no fluorescence. In a further
experiment it was found that A549 cells displayed bright green fluorescence when the
cells were first incubated with 10µM of probe for 30 min and then incubated with 2
µM Mg2+ for 30 min at 37 ℃ (Fig. 10e). These imaging experiments indicated that
the probe can be used to detect Mg2+ in imaging modality.
<Inserted Figure 10>

ACCEPTED MANUSCRIPT
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
4. Conclusions
In summary, we have developed a novel “off-on” fluorescent probe based on 1,
8-naphthalimide derivative for the detection of Mg2+ with highly selectivity and
sensitivity in ethanol solution. Moreover, the probe showed a rapid detection process
(45 s), high fluorescence enhancement (up to 15-fold), a good binding constant
(6.17×105 M-1) and a low detection limit of Mg2+ (5.01×10-8 M). Optical properties,
1H NMR, ESI-MS and DFT calculations also showed response mechanism towards
Mg2+ as a 1: 2 binding mode at ethanol media. The cell cytotoxicity experiments
fluorescence scanning microscopic experiments demonstrated that the probe can be
used to detect intracellular Mg2+ in living A549 cells.
Acknowledgments
The work was supported by the National Natural Science Foundation of China (No.
21472118, 21672131), Talents Support Program of Shanxi Province (2014401),
Shanxi province Outstanding Youth Fund (2014021002) and Scientific Instrument
Center of Shanxi University.
303
304
305
306
307
308
309
310
311
312

ACCEPTED MANUSCRIPT
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
References
[1] Maguire ME, Cowan JA. Magnesium chemistry and biochemistry. Biometals
2002; 15: 203-210.
[2] Komatsu H, Miki T, Citterio D, Kubota T, Shindo Y, Kitamura Y, Suzuki K. Single
molecular multianalyte (Ca2+, Mg2+) fluorescent probe and applications to
bioimaging. J Am Chem Soc 2005; 127: 10798-10799.
[3] Swaminathan R. Magnesium metabolism and its disorders. Clin Biochem Rev
2003; 24: 47-66.
[4] Jahnen-Dechent W, Ketteler M. Magnesium basics. Clin Kidney J 2012; 5: i3-i14.
[5] Yin HJ, Zhang BC, Yu HZ, Zhu L, Feng Y, Zhou MZ, Guo QX, Meng XM.
Two-photon fluorescent probes for biological Mg2+ detection based on
7-substituted coumarin. J Org Chem 2015; 80: 4306-4312.
[6] Cowan JA. Structural and catalytic chemistry of magnesium-dependent enzymes.
Biometals 2002; 15: 225-235.
[7] Kim HM, Yang PR, Seo M, Yi JS, Hong JH, Jeon SJ, Ko YG, Lee KJ, Cho BR.
Magnesium ion selective two-photo fluorescent probe based on
a
benzo[h]chromene derivative for in vivo imaging. J Org Chem 2007; 72:
2088-2096.
[8] Hartwig A. Roles of magnesium in genomic stability. Mutat Res 2001; 475:
113-121.
[9] O’Rourke B, Preston PH, Marban E. Phosphorylation-independent modulation of
L-type calcium channels by magnesium-nucleotide complexes. 1992; 257:

ACCEPTED MANUSCRIPT
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
245-248.
[10] Politi HC, Preston RR. Is it time to rethink the role of Mg2+ in membrane
excitability? Neuroreport. 2003; 14: 659-668.
[11] Dai LJ, Ritchie G, Kerstan D, Kang HS, Cole DE, Quamme GA. Magnesium
transport in the renal distal conboluted bubule. Physiol Rev 2001; 81: 51-84.
[12] Schmitz C, Perraud A, Johnson CO, Inabe K, Smith MK, Penner R, Kurosaki T,
Fleig A, Scharenberg AM. Refulation of vertebrate cellular Mg2+ homeostasis by
TRPM7. Cell 2003; 113: 191-200.
[13] Dong Y, Li JF, Jiang XX, Song FY, Cheng YX, Zhu CJ. Na+ triggered
fluorescence sensors for Mg2+ detection based on a coumarin salen moiety. Org
Lett 2011; 13: 2252-2255.
[14] Rubin H. The logic of the membrane, magnesium, mitosis (MMM) model for the
regulation of animal cell proliferation. Arch Biochem Biophys 2007; 458: 16-23.
[15] Shoda T, Kikuchi K, Kojima H, Urano Y, Komatsu H, Suzuki K, Nagano T.
Development of selective, visible light-excitable, fluorescent magniesium probes
with a novel fluorescence switching mechanism. Analyst 2003; 128: 719-723.
[16] Rubin H. Magnesium: the missing element in molecular views of cell
proliferation control. Bioessays 2005; 27: 311-320.
[17] Komatsu H, Iwasawa N, Citterio D, Suzuki Y, Kubota T, Tokuno K, Kitamura Y,
Oka K, Suzuki K. Design and synthesis of highly sensitive and selective
fluorescein-derived magnesium fluorescent probes and application to
intracellular 3D Mg2+ imaging. J Am Soc 2004; 126: 16353-16360.

ACCEPTED MANUSCRIPT
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
[18] Gwanyanya A, Amuzescu B, Zakharov SI, Macianskiene R, Sipido KR, Bolotina
VM, Vereecke J, Mubagwa K. Magnesium-inhibited, TRPM6/7-like channel in
cardiac myocytes: permeation of divalent cations and pH-mediated regulation. J
Physiol 2004; 559: 761-776.
[19] Fabbrizzi L, Poggi A. Sensors and switches from supramolecular chemistry.
Chem Soc Rev 1995; 24: 197-202.
[20] Yu TT, Sun P, Hu YJ, Ji YG, Zhou HP, Zhang BW, Tian YP, Wu JY. A novel and
simple fluorescence probe for detecting main group magnesium ion in HeLa
cells and Arabidopsis. Biosensors and Bioelectronics 2016; 86: 677-682.
[21] Tang RJ, Zhao FG, Garcia VJ. Tonoplast CBL-CIPK calcium signaling network
regulates magnesium homeostasis in Arabidopsis. Proc Natl Acad Sci 2015; 112:
3134-3139.
[22] Silva AP, Gunaratne HQN, Gunnlargsson T, Huxley AJM, McCoy CP,
Rademacher JT, Rice TE, Signaling recognition events with fluorescent sensors
and switches. Chem Rev 1997; 97: 1515-1566.
[23] Gupta VK, Singh AK, Kumawat LK, Thiazole schiff base turn-on fluorescent
chemosensor for Al3+ ion. Sens Actrators B 2014; 195: 98-108.
[24] Li JF, Yin CX, Huo FJ, Development of fluorescent zinc chemosensors based on
various fluorophores and their applications in zinc recognition. Dyes and
Pigments 2016; 131: 100-133.
[25] Yang YT, Yin CX, Huo FJ, Chao JB, A selective fluorescent probe for detection
of gold (III) ions and its application to bioimaging. RSC Adv 2013; 3:

ACCEPTED MANUSCRIPT
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
9637-9640.
[26] Kand D, Kalle AM, Varma SJ, Talukdar P, A chromenoquinoline-based
fluorescent off-on thiol probe for bioimaging. Chem Common 2012; 48:
2722-2724.
[27] Huo FJ, Yin CX, Yang YT, Su Jing, Chao JB, Liu DS, Ultraviolet-visible light
(UV-vis)-reversible but flluorescence-irreversible chemosensor for copper in
water and its application in living cells. Anal Chem 2012; 84: 2219-2223.
[28] Farruggia G, Iotti S, Prodi L, Montalti M, Zaccheroni N, Savage PB, Trapani V,
Sale P, Wolf FI. 8-Hydroxyquinoline derivatives as fluorescent sensors for
magnesium in living cells. J Am Chem Soc 2006; 128: 344-350.
[29] Yang YM, Zhao Q, Feng W, Li FY. Luminescent chemodosimeters for
bioimaging. Chem Rev 2013; 113: 192-270.
[30] Liu Y, Han M, Zhang HY, Yang LX, Jiang W. A proton-triggered on-off-on
fluorescent chemosensor for Mg (II) via twisted intramolecular charge transfer.
Org Lett 2008; 10: 2873-2876.
[31] Liu Y, Duan ZY, Zhang HY, Jiang XL, Han JR. Selective bingding and inverse
fluorescent behavior off magnesium ion by podand possessing plural
imidazo[4,5-f]-1,10-phenanthroline groups and its Ru (II) complex. J Org Chem
2005; 70: 1450-1455.
[32] Hama H, Morozumi T, Nakamura H. Novel Mg2+-responsive chemosensor based
on benzo-15-crown-5 possessing 1-naphthaleneacetamide moiety. Tetrahedron
Lett 2007; 48: 1859-1861.

ACCEPTED MANUSCRIPT
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
[33] Song KC, Choi MG, Ryu DH, Kim KN, Chang SK. Ratiometric chemosensing of
Mg2+ ions by a calix[4]arene diamide derivative. Tetrahedron Lett 2007; 48:
5397-5400.
[34] Yu CW, Fu QY, Zhang J. Synthesis and characterization of a Mg2+-selective
fluorescent probe. Sensors 2014; 14: 12560-12567.
[35] Park EJ, Brasuel M, Behrend C, Philbert MA, Kopelman R. Ratiometric optical
PEBBLE nanosensors for real-time magnesium ion concentrations inside viable
cells. Anal Chem 2003; 75: 3784-3791.
[36] Jin L, Sun ZY, Li AL, Jin Q, Wei M, Assembly of
8-aminonaphthalene-1,3,6-trisulfonate intercalated layered double hydroxide
film for the selective detection of Mg2+. Sensors Actuators B 2012; 161:
714-720.
[37] Li L, Yun S, Zhao YH, Mu L, Zeng X, Carl R, Wei G. A single chemosensor for
multiple analytes: fluorogenic and ratiometric absorbance detection of Zn2+,
Mg2+ and F-, and its cell imaging. Sensors Actuators B 2016; 226: 279-288.
[38] Liu ZD, Xu HJ, Chen SS, Sheng LQ, Zhang H, Hao FY, Su PF, Wang WL.
Solvent-dependent ‘turn-on” fluorescence chemosensor for Mg2+ based on
combination of C=N isomerization and inhibition of ESIPT mechanisms.
Specrochim Acta Part A 2015; 149: 83-89.
[39] Devaraj S, Tsui YK, Chiang CY, Yen YP. A new dual functional sensor: highly
selective colorimeric chemosensor for Fe3+ and fluorescent sensor for Mg2+.
Specrochim Acta Part A 2012; 96: 594-599.

ACCEPTED MANUSCRIPT
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
[40] Fujii T, Shindo Y, Hotta K, Citterio D, Nishiyama S, Suzuki K, Oka K. Design
and synthesis of a FLAsH-type Mg2+ fluorescent probe for specific protein
labeling. J Am Chem Soc 2014; 136: 2374-2381.
[41] Zhang MY, Lu W, Zhou JT, Du GH, Jiang LM, Ling J, Shen ZQ. A simple and
effective fluorescent chemosensor for the cascade recognition of Zn2+ and
-
H2PO4 ions in protic media. Terrahedron 2014; 70: 1011-1015.
[42] Joo EY, Kim H, Hong SB. Hippocampal substructural vulnerability to sleep
disturbance and cognitive impairment in patients with chronic primary insomnia:
Magnetic resonance imaging morphometry. Sleep 2014; 37: 1189-1198.
[43] Rogolino D, Carcelli M, Bacchi A, Comjpari C, Contardi L, Fisicaro E, Gatti A,
Sechi M, Stevaert A, Naesens L. A versatile salicyl hydrazonic ligand and its
metal complexes as antiviral agents. J Inorg Biochem 2015; 150: 9-17.
[44] Sedai B, Heeg MJ, Winter CH. Magnesium complexes containing β-ketiminate
and β-diketiminate ligands with dimethylamino substituents on the ligand core
nitrogen atoms. J Organomet Chem 2008; 693: 3495-3503.
[45] Yin CX, Qu LJ, Huo FJ. A pyridoxal-based chemosensor for visual detection of
copper ion and its application in bioimaging. Chin J Chem 2014; 25: 1230-1234.
[46] Zhang HF, Yin CX, Liu T, Zhang YB, Huo FJ. “Turn-on” fluorescent probe
detection of Ca2+ ions and applications to bioimaging. Spectrochim Acta Part A
2017; 180: 211-216.
[47] Xu MH, Lin J, Hu QS, Pu L. Fluorescent sensors for the enantioselective
recognition of mandelic acid: signal amplification by dendritic branching. J Am

ACCEPTED MANUSCRIPT
445
446
447
448
449
450
Chem Soc 2002; 124: 14239-14246.
[48] Vengaian KM, Britto CD, Sekar K, Sivarama G, Singaravadivel S. Fluorescence
“on-off-on” chemosnesor for selective detecton of Hg2+ and S2-: application to
bioimaging in living cells. RSC Adv 2016; 6: 7668-7673.
[49] Vengaian KM, Britto CD, Sekar K, Sivarama G, Singaravadivel S.
Phenothiazing-diaminomalenonitrile based colorimetric and fluorescence
“turn-off-on” sensing of Hg2+ and S2-. Sensors Actuators B 2016; 235: 232-240.
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467

ACCEPTED MANUSCRIPT
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
Figure captions
Scheme 1 The synthesis route of the probe.
Fig. 1 (a) Optical density two-dimensional graph of the probe (10 µmol/L) in ethanol
solution in the presence of 2 equiv. various metal ions. (b) Photographs of the visual
color and the fluorescence under illumination at 365 nm. From left to right: Probe,
Cu2+, Ag+, Zn2+, Cr3+, Hg2+, Ni2+, Na+, K+ , Ba2+, Ca2+, Fe3+, Mn2+ , Co2+, Pb2+, Cd2+,
Al3+, and Mg2+.
Fig. 2 (a) UV-vis spectra of the probe (10 µM) with the addition of Mg2+ (0-2 µM) in
ethanol solution. (b) Fluorescence spectral change of the probe (10 µM) upon addition
of Mg2+ (0-2 µM) in ethanol solution (λex = 397 nm, λem =523 nm, slit: 5 nm/5 nm).
Insert: photographs of probe before (left) and after (right) addition of Mg2+.
Fig. 3 Plot of emission intensity at 523 nm of probe as a function of Mg2+
concentration in ethanol solution.
Fig. 4 Job’s plot for probe-Mg2+ complex at 523 nm in ethanol solution and the total
concentration of probe and Mg2+ is 15 µM.
Fig. 5 Benesi-Hildebrand plots of probe-Mg2+ complex in ethanol solution.
Fig. 6 Reaction time profiles of probe in the presence of Mg2+ in ethanol solution.
Fig. 7 The MS of probe-Mg2+ in the DMSO.
Fig. 8 Calculated structure for the probe (a) and the complex [probe-Mg2+] (b) by
Gaussian05.
Scheme 2 Proposed sensing process of the probe for Mg2+
Fig. 9 CCK-8 assay of A549 cells treated with probe at different concentrations for 5

ACCEPTED MANUSCRIPT
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
h and 10 h.
Fig. 10 Confocal fluorescence images in A549 cells. Fluorescence image of A549
cells incubated with probe (10 µM) for 30 min at 37 °C (a-c); Cells pretreated with
probe and then incubated with 2 µM Mg2+ for 30 min at 37 °C (d-e).

ACCEPTED MANUSCRIPT
512
Scheme 1
O
O
O
O
N
3
O
O
N
O
NH2
CH3ONa
CH3OH/CuSO4
Br
OCH3
Br
2
1
O
N
O
O
N
O
O
N
O
HI
HMTA/TFA
HCI/H2O
S
N
N
CHO
N
H
OH
OH
OH
N1
5
4
S
N
NH2NH2
NH2
NH
S
N
Cl
6
7
513
514
Fig. 1 (a)
515
516
(b)
517
518
519
520

ACCEPTED MANUSCRIPT
521
Fig. 2
522
523
(a)
524
525
(b)
526
527

ACCEPTED MANUSCRIPT
528
Fig. 3
529
530
Fig. 4
531
532
533
534
535

ACCEPTED MANUSCRIPT
536
Fig. 5
537
538
Fig. 6
539
540
541
542

ACCEPTED MANUSCRIPT
543
Fig. 7
544
545
Fig. 8
546
547
548
549
550
551
552
