and
j
were considered.
was plotted as a function of frequency. The real part e0 and
imaginary part e00 of the complex permittivity maintained almost a
constant over 0.1–18 GHz except for the little fluctuation above
14 GHz. It was found that the complex permittivity for nanorods
was higher than that of nanospheres. In the metal–insulator
composites, the space charge and the dipole polarization could be
ascribed to the polarization phenomena. The space charge polariza-
tion often takes place in the interface between the metal core and
the insulator matrix. The free electrons from the metal fractions
promote the charge accumulation at the interfaces and the higher
permittivity is attained due to the improved electrical conductivity.
Nanorods have larger specific surface area, which might result to
more space charge polarization so that higher complex permittivity
compared to nanospheres. The dielectric and magnetic loss tangent
P
N1 mi
ðy,fÞ
/m
iS ¼
ð6Þ
N
An equivalent scalar permeability of mı can then be calculated by
taking the Eigen value of the permeability tensor:
ꢂ
ꢃ
mi ¼ Eigenvalue /
miS
ð7Þ
Magnetic particles with certain volume fraction P are dispersed in
a nonmagnetic matrix (paraffin wax). The effective permeability
(
m
eff) for composite can be calculated by normal Bruggeman’s
effective medium theory [21,22]
mi
ꢁmeff
1ꢁmeff
1þ2meff
p
þð1ꢁpÞ
¼ 0
ð8Þ
mi þ2meff
can be expressed as tan dE¼ / ¼ /
e00 e0 and tan dM m00 m0, respectively,
which means the ratio of energy loss to the energy storage.
Fig. 4(b) shows frequency dependence of the dielectric and magnetic
loss tangent of Ni nanospheres and conical nanorods composites. It
can be seen that the value of magnetic loss is much higher than that
of dielectric loss, illustrating that the main loss for the composites in
the range of 0.1–18 GHz is magnetic loss. Furthermore, the magnetic
loss tangent appears peaks with the increase of frequency. The peak
for the nanospheres has the maximum value about 0.5 higher than
that of conical nanorods. However, the peaks for conical nanorods
are wider and appear in higher frequency range compared to that of
nanospheres, which means conical nanorods might be more suitable
to be a broad band microwave absorber.
Fig. 3 (solid lines) shows theoretical fitting curves of the
complex permeability for Ni nanospheres (Fig. 3(a)) and Ni
conical nanorods (Fig. 3(b)). We suppose that the saturation
magnetization 4pMs is 4.90 kG based on the experimental data
of VSM for both nanospheres and nanorods, the damping para-
meters are 0.50 for nanospheres and 0.65 for nanorods from the
width of the natural resonance peak. It was found that the fitting
curves match satisfactorily with the experimental data when the
He¼0.187 kOe for nanospheres and 0.700 kOe for conical nanor-
ods. The He of Ni conical nanorods is much higher than that of Ni
nanospheres, which shows good agreement with the discussion
on Hc. Moreover, from the Kittel [8] model for natural resonance,
the natural resonance peak varies linearly with He, which is the
sum of crystalline anisotropy, shape anisotropy, surface aniso-
tropy, etc. In our case, Ni nanospheres and conical nanorods have
the same crystal structure and close particle size, so that the
major difference between the two samples is their morphology.
Ni conical nanorods have larger shape anisotropy which origi-
nated from demagnetization effect can increase He dramatically.
This is why Ni conical nanorods have larger He and higher
resonance frequency compared to Ni nanospheres.
The reflection loss (RL) of a microwave absorbing layer backed
by a perfect conductor was calculated by the following equations:
ꢄ
ꢄ
ꢄ
ꢄ
ꢄ
ꢄ
ꢄ
ꢄ
ðZinꢁ1Þ
ðZin þ1Þ
RLðdBÞ ¼ 20log10
ð9Þ
ꢀ
ꢁ
ꢅ ꢀ
ꢁ
ꢆ
1=2
mr
er
2
p
c
fd
1=2
Zin
¼
tanh j
ð
mrer
Þ
ð10Þ
where RL is a ratio of reflected power to incident power in dB, Zin
In order to explore the microwave absorbing properties of the
composites, both magnetic and dielectric loss should be considered.
As shown in Fig. 4(a), the complex permittivity of Ni nanoparticles
is the normalized input impedance relative to the impedance in
e0–je00 and mr m0–jm00 is the complex permittivity
free space, er¼ ¼
and complex permeability of the absorber material, d is the
thickness of the absorber, and c and f are the velocity of light
and the frequency of microwave in free space, respectively. The RL
curves were shown in Fig. 5 for both Ni nanospheres and conical
nanorods. The RL was less than –10 dB in the 6.7–9.5 GHz for
conical nanorods while more than –8 dB in the whole frequency
range for nanospheres with thickness of 2.5 mm. The values less
than –10 dB indicates that more than 90% of the introduced
microwaves are absorbed, so this value is the target value to be
attained for the absorber’s applications. More importantly, the
thickness of the sample is smaller than that of the usual ferrite
material indicating that the Ni conical nanorods may be good
microwave absorption filler in broad frequency band.
Fig. 4. Frequency dependences of the complex permittivity (a); frequency depen-
