APPLIED PHYSICS LETTERS 97, 141905 ͑2010͒
Deok-Yong Cho,1,a͒ Hyung-Suk Jung,2 Jeong Hwan Kim,2 and Cheol Seong Hwang2,b͒
1CSCMR and FPRD, Department of Physics and Astronomy, Seoul National University,
Seoul 151-747, Republic of Korea
2WCU Hybrid Materials Program, Department of Materials Science and Engineering, and Inter-university
Semiconductor Research Center, Seoul National University, Seoul 151-744, Republic of Korea
͑Received 30 August 2010; accepted 15 September 2010; published online 5 October 2010͒
The local atomic structure and electronic structure of amorphous ZrO2 ͑a-ZrO2͒ thin film were
examined using the Zr K- and O K-edge x-ray absorption spectroscopy and x-ray photoelectron
spectroscopy. It was found that a monoclinic local structure is stabilized in several nanometers-thick
a-ZrO2 films due to the structural disorder. The distinct local structure in a-ZrO2 from the ordinary
tetragonal ZrO2 ͑t-ZrO2͒ films results in different electronic structure with a decrease in the band
gap by 0.5 eV. The reduced band gap and dielectric constant of a-ZrO2 suggest inferior gate leakage
current performances compared to the t-ZrO2 films. © 2010 American Institute of Physics.
A high dielectric constant ͑k͒ is essential for gate oxides
in metal-oxide-semiconductor field effect transistors because
it prevents the current leakage through the gate oxide. Fol-
lowing the intensive research to find oxides with higher k
and reasonably large band gaps, the Hf-based oxide system is
currently being used as the gate dielectric in several high
performance logic chips.1 Recently, Zr-based oxides are also
drawing an increasing amount of attention because they are
expected to exhibit similar electrical performances with a
more superior interface, which may lead to an improvement
in interface related reliability properties compared to the Hf-
based oxides.2–4 Thus it is undoubtedly important to study
their electronic structure theoretically and experimentally.
The bulk hafnia ͑HfO2͒ and zirconia ͑ZrO2͒ are remark-
ably alike in terms of electrochemical properties. They have
a monoclinic crystal structure ͑m;P21/c͒ at room tempera-
ture with almost identical lattice constants.5,6 The similarity
originates from the identical valences ͑+4͒ and orbital con-
figurations ͑d0͒, along with the similar ionic radii ͑within
difference of only 0.02 Å͒ of the Hf and Zr ions.7 When in
nanoscale structures such as ultrathin films ͑which are only
several nanometers thick͒ or nanoparticles, however, their
preferred crystal structures are different from each other; the
HfO2 nanostructure still prefers the monoclinic structure
while the ZrO2 nanostructure favors a tetragonal structure
lization mechanism of the tetragonal structure has been ex-
ploited extensively but is still rather controversial; perhaps, it
could be summarized as a combination of the effects of sur-
gate oxide is frequently desired due to its homogeneous and
isotropic electrical properties. In a HfO2 thin film, the dielec-
tric properties are rarely influenced by amorphization be-
cause the monoclinic local structure is preserved even in the
amorphous phase, which is why the k of amorphous HfO2
͑a-HfO2͒ is roughly similar to that of monoclinic HfO2
͑m-HfO2͒.14 However, this experimental study shows that in
amorphous ZrO2 ͑a-ZrO2͒ thin films, a monoclinic local
structure is re-stabilized due to the structural disorder, so the
k of the a-ZrO2 film would become similar to that of m-ZrO2
͑kϳ20͒, which is much lower than that of t-ZrO2.14 This
suggests that a-ZrO2 may have inferior dielectric perfor-
mance compared to crystalline t-ZrO2 in next-generation
high-k dielectric applications.
ZrO2 films were prepared on a Si wafer by plasma
enhanced atomic layer deposition ͑PEALD͒ using
Zr͓N͑C2H5͒͑CH3͔͒ as the Zr-precursor and plasma-
4
activated O2 as the oxygen source at a wafer temperature
of 280 °C. The film thickness was controlled by tuning the
number of the PEALD cycles and was confirmed by ellip-
sometry. The 40 and 80-Å-thick as-grown films were amor-
phous, which was confirmed by the absence of Bragg peaks
in grazing angle x-ray diffraction ͑GAXRD͒. Postdeposition-
annealing ͑PDA͒ was also performed at 950 °C in a N2
ambiance to make the films crystalline. The GAXRD con-
firmed that the PDA films crystallized with a tetragonal sym-
metry ͑P42/nmc͒. The local structures were examined by
Zr K-edge x-ray absorption spectroscopy ͑XAS͒ and the
x-ray absorption near-edge structure ͑XANES͒ was ana-
lyzed. The electronic structure and chemistry were examined
by O K-edge XAS and x-ray photoelectron spectroscopy
͑XPS͒. The Zr K- and O K-edge XAS were performed at the
3C1 and 2A beamlines in the Pohang Light Source ͑PLS͒,
respectively. The XPS was performed using a monochro-
matic Al K␣ source, after cleaning the film surfaces with a
moderate Ar-ion sputtering ͑acceleration voltage Ͻ0.5 keV͒.
Figure 1 shows the Zr K-edge XANES of the ͑a͒ PDA
and ͑b͒ as-deposited ZrO2 films.15 The overall XANES fea-
tures are almost thickness independent; the results of the 80-
Å-thick PDA and as-deposited films are quite similar to those
of the 40-Å-thick PDA and as-deposited films, respectively.
It has been reported the k value in Zr-based oxides is
mainly determined from the local atomic structure, although
the charge transfer between the adjacent clusters or structural
units also have a minor influence.11,12 The k value of t-ZrO2
is about two times larger ͑kϳ40͒ than that of m-ZrO2 ͑k
ϳ20͒ due to the difference in local structure.13 Therefore, it
is much encouraged to use tetragonal ZrO2 for Zr-based ox-
ide gate dielectrics to obtain a higher k. Also an amorphous
