Preservation of Bacillus firmus strain 37 and optimization of cyclodextrin biosynthesis by cells immobilized on loofa sponge

Article abstract of DOI:10.3390/molecules17089476

The preservation of Bacillus firmus strain 37 cells by lyophilization was evaluated and response surface methodology (RSM) was used to optimize the β-cyclodextrin (β-CD) production by cells immobilized on loofa sponge. Interactions were studied with the variables temperature, pH and dextrin concentration using a central composite design (CCD). Immobilization time influence on β-CD production was also investigated. B. firmus strain 37 cells remained viable after one year of storage, showing that the lyophilization is a suitable method for preservation of the microorganism. From the three-dimensional diagrams and contour plots, the best conditions for β-CD production were determined: temperature 60 °C, pH 8, and 18% dextrin. Considering that the amount of dextrin was high, a new assay was carried out, in which dextrin concentrations of 10, 15, and 18% were tested and the temperature of 60 °C and pH 8 were maintained. The results achieved showed very small differences and therefore, for economic reasons, the use of 10% dextrin is suggested. Increasing the immobilization time of cells immobilized on synthetic sponge the β-CD production decreased and did not change for cells immobilized on loofa sponge. The results of this research are important for microorganism preservation and essential in the optimization of the biosynthesis of CD.

Full text of DOI:10.3390/molecules17089476

Molecules 2012, 17, 9476-9488; doi:10.3390/molecules17089476
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Preservation of Bacillus firmus Strain 37 and Optimization of
Cyclodextrin Biosynthesis by Cells Immobilized on Loofa Sponge
1
1
1
Rúbia Pazzetto , Sabrina Barbosa de Souza Ferreira , Elder James Silva Santos ,
1
2
1,
Cristiane Moriwaki , Teresinha Aparecida Guedes and Graciette Matioli *
1
Department of Pharmacy, State University of Maringá (UEM), Av. Colombo, 5790,
Maringá-PR 87020-900, Brazil
2
Department of Statistics, State University of Maringá (UEM), Av. Colombo, 5790,
Maringá-PR 87020-900, Brazil
*
Author to whom correspondence should be addressed; E-Mail: gmatioli@uem.br;
Tel.: +55-44-3011-3868; Fax: +55-44-3011-4119.
Received: 28 April 2012; in revised form: 18 July 2012 / Accepted: 21 July 2012 /
Published: 8 August 2012
Abstract: The preservation of Bacillus firmus strain 37 cells by lyophilization was evaluated
and response surface methodology (RSM) was used to optimize the β-cyclodextrin (β-CD)
production by cells immobilized on loofa sponge. Interactions were studied with the
variables temperature, pH and dextrin concentration using a central composite design
(CCD). Immobilization time influence on β-CD production was also investigated. B. firmus
strain 37 cells remained viable after one year of storage, showing that the lyophilization is
a suitable method for preservation of the microorganism. From the three-dimensional
diagrams and contour plots, the best conditions for β-CD production were determined:
temperature 60 °C, pH 8, and 18% dextrin. Considering that the amount of dextrin was
high, a new assay was carried out, in which dextrin concentrations of 10, 15, and 18% were
tested and the temperature of 60 °C and pH 8 were maintained. The results achieved
showed very small differences and therefore, for economic reasons, the use of 10% dextrin
is suggested. Increasing the immobilization time of cells immobilized on synthetic sponge
the β-CD production decreased and did not change for cells immobilized on loofa sponge.
The results of this research are important for microorganism preservation and essential in
the optimization of the biosynthesis of CD.

Molecules 2012, 17
9477
Keywords: microorganism preservation; response surface methodology; cyclodextrin;
loofa sponge; cells immobilization; Bacillus firmus
1
. Introduction
Microbiological tests are carried out in many industries such as the pharmaceutical, food and
clinical ones. These microorganisms need to be preserved for application of defined quantities and to
obtain the desired product. In all cases the cost of preservation, maintenance and the length of time
cultures remain viable determine the chosen preservation technique [1–3].
The purpose of this preservation is to keep the cultures without morphological, physiological or
genetic changes, as well as maintaining their viability and stability [4]. Drying has been the preferred
method for long term storage of cultures for decades, though the technique if not free of cell viability
losses. There are several drying methods and, despite the worldwide use of these technologies, no
generic method for all applications is known [3]. The current industry standard for preserving
microorganisms is freeze drying or lyophilization, and the anhydrous product obtained can be stored,
tightly sealed under vacuum or under a protective atmosphere for long periods of time with good
activity against rehydration [5].
Preserved microorganisms are usually resuspended in appropriate culture medium and used in the
biosynthesis of industrial products. Recently many methods of statistical experimental design have
been used in the optimization of bioprocesses. Among them, response surface methodology (RSM) is a
viable method to identify the effect of individual variables in order to determine optimal conditions for
a multivariable system and increase its efficiency [6]. For many authors, statistical optimization is a
common practice and has been a good solution for the optimal values determination of parameters such
as pH, temperature, fermentation time, inoculum size, substrates concentration, and other components
of the fermentation medium of biotechnological processes [6–8].
The immobilization of microorganisms on loofa sponge for the production of cyclodextrins (CDs)
was studied [9], but until the moment, no reports on the use of RSM to optimize the fermentation
conditions have been found in the literature.
CDs are cyclic oligosaccharides composed of glucopyranose units linked by α-(1,4)-glycosidic
bonds that form a cylindrical structure with industrial applications in various fields. On account of
their hydrophobic cavities, which can incorporate hydrophobic compounds, they can change the
physical and chemical properties of guest molecules, such as solubility and stability [10–12]. They are
produced from starch by the action of the enzyme cyclodextrin glycosyltransferase (CGTase) by a
cyclization reaction. CGTase also catalyzes glycosylation reactions, which converts water-insoluble
and unstable aromatic compounds into the corresponding water-soluble and stable compounds to
improve their bioavailability and pharmacological properties [13,14].
The use of CDs has increased significantly, mainly in the food industry. These molecules have been
widely used for stabilization of flavours and protection of sensitive compounds from degradation
induced by light or oxygen, thereby increasing the storage time; for vitamins and dyes solubilization;
for elimination of unpleasant odours or tastes, microbiological contamination and other undesirable

Molecules 2012, 17
9478
compounds and, for cholesterol removal from animal products thus improving their nutritional
characteristics [15].
Cell immobilization is the physical confinement of whole cells with the preservation of certain
catalytic activities and has been applied in many biochemical processes [16,17]. Among the advantages
of immobilized cell systems are the elimination of extraction and enzyme purification steps, repeated
and prolonged use of cells, higher yields of enzyme activity, better operational stability and easy
separation of cells from the fermentation medium [16,18].
Loofa sponge, obtained from the dried fruit of Luffa cylindrica, has been used successfully as a
matrix for cell immobilization, because it is a biodegradable material, porous, resistant, and
low cost. Furthermore, it is readily available and the immobilization method for this matrix is
simple [19,20]. The use of low cost matrices allows the immobilization method to be implemented
with minimal additional production cost [21]. Another support recently used in the immobilization of
microbial cells is synthetic sponge. This sponge has a polyurethane composition that is resistant and
hydrophobic. When used as an immobilization support, it acts as an inert matrix and does not interfere
with cell properties [22].
The present work was aimed to evaluate the preservation of Bacillus firmus strain 37 cells by
lyophilization and apply RSM to optimize the fermentation conditions for the production of
β-cyclodextrin (β-CD). In this paper, the optimized parameters were pH, temperature, and dextrin
concentration. Influence of immobilization time on β-CD production by cells immobilized on loofa
sponge and synthetic sponge was also analyzed.
2
. Results and Discussion
2
.1. Immobilization of Bacillus firmus Strain 37 Cells on Loofa Sponge
Loofa sponge fibers uninoculated with B. firmus strain 37 are shown in Figure 1A. One colony of
the bacteria can be observed attached to a fiber with an approximate size of 2 mm (Figure 1B). With
the SEM it was possible to verify that a large number of cells adhered to the loofa sponge
(
Figure 1C,D). The immobilization occurred spontaneously with the adhesion/adsorption microbes on
the natural support through electrostatic interactions [23].
The innovative use of loofa sponge, an environmentally friendly matrix, for immobilization of
B. firmus strain 37 resulted in a high β-CD production, as showed by Pazzetto et al. [9]. Since a large
number of cells were able to adhere on the surface of the loofa sponge fibers, innovative studies of
microorganism preservation and optimization of the β-CD production process are necessary and were
conducted in this work.
2
.2. Bacillus firmus Strain 37 Preservation by Lyophilization
The β-CD production by B. firmus strain 37 was similar after one year of storage, reaching a value
of 19.04 ± 1.4 mM β-CD after the lyophilization procedure and 15.02 ± 1.8 mM β-CD after one year
of storage (Figure 2).

Molecules 2012, 17
9479
Figure 1. Photographs showing (A) uninoculated fibrous network of loofa sponge;
B) colony of B. firmus strain 37 grown on loofa sponge fibers; and (C, D) scanning electron
(
micrograph of B. firmus strain 37 immobilized on surface of a single loofa sponge fiber.
The detail in the superior position of the pictures A and B is a graduated scale in millimeters.
A
B
C
D
Figure 2. Evaluation of B. firmus strain 37 preservation by lyophilization. β-CD
production by cells newly lyophilized (■) and after one year of storage (●).
20
16
12
8
4
0
0
24
48
72
96
120
144
168
Time (hours)
Moriwaki et al. [4] used other methods for storing B. firmus strain 37: periodical sampling in solid
culture medium, addition of a cell suspension in sterile soil and freezing at −70 °C. The methodology
of periodical sampling in solid culture medium was not suitable, contrary to the other two methods,
which were satisfactory for the storage and preservation of the strain.

Molecules 2012, 17
9480
Starting from lyophilized cells of B. firmus strain 37 and subsequent immobilization on loofa
sponge [9], the β-CD production almost doubled compared by the same bacteria frozen and stored at
−
2 2 2 2
80 °C and immobilized on silica-titanium (SiO /TiO ) and silica-manganese (SiO /MnO ) [24],
demonstrating the superiority both the immobilization on loofa sponge and the microorganism
maintenance method [9].
2
.3. Optimization of β-Cyclodextrin Production by Immobilized Cells on Loofa Sponge
A statistical experimental design (RSM) was used to optimize the conditions for β-CD production
by cells of B. firmus strain 37 immobilized on loofa sponge. With the data from this design, a
predictive equation was obtained after the analysis of variance (ANOVA), which is an appropriate
model for β-CD production and is given below [Equation (1)]:
2
β-CD (mM) = 10.6479186 + 0.075210265*Temp − 1.1270724*Temp + 2.77578322*pH −
2
2
0
.37020298*pH + 1.94899810*Dex + 0.678564219*Dex + 2.72874876*Temp*pH +
.193707857*Temp*Dex + 0.588017160*pH*Dex
(1)
0
where Temp is the temperature and Dex is the dextrin concentration. The coefficient of determination
2
(
R ) for β-CD production was 0.79, indicating that the statistical model explained 79% of the
variability in the response.
The optimal level of each variable and the effect of their interactions on β-CD production were
studied by plotting the three-dimensional diagrams and contour plots of calculated response surfaces
from the interactions among the three variables (Figure 3). From these response graphs, it was apparent
that the best conditions for this process corresponded to a temperature of 50 °C or above (Figure 3A,B),
higher pH values (Figure 3A,C), and the highest dextrin concentrations (Figure 3B,C). When a normal
probability plot of residuals was constructed, a selection was made for the normality assumption,
which was satisfactory, since nearly all the residuals fell approximately along a straight line (Figure 3D).
2
2
Considering that the closer the value of R is to 1.0, the better the model predicts the response, the R
obtained here also shows that the model has acceptable predictive ability.
Figure 3. Statistical optimization of β-CD production using RSM. (A) pH and temperature;
(
B) dextrin and temperature; (C) dextrin and pH; and (D) normal probability plot of
residuals.

Molecules 2012, 17
9481
Figure 3. Cont.
D
Vignoli et al. [25] constructed a statistical model that could explain 81% of the variability in the
response, similar to that obtained in this study (79%); and, bearing in mind that this is a biological
experiment, also concluded that the model showed a reasonable predictive ability.
Therefore, from the analysis of Figure 3 and the responses obtained in practice, the optimal process
conditions were determined to be temperature 60 °C, pH 8, and 18% dextrin. Considering that the
amount of dextrin was high, a new assay was carried out, in which dextrin concentrations of 10, 15,
and 18% were tested and the temperature of 60 °C and pH 8 were maintained. The results obtained
were 19.26 mM, 19.14 mM, and 20.35 mM of β-CD produced for the dextrin concentrations of 10, 15,
and 18%, respectively, which showed very small differences in the β-CD production, so for economic
reasons, the use of 10% dextrin is suggested. Thus, the obtained results confirmed that the
fermentation process conditions used previously by Pazzetto et al. [9] are suitable. In this same work,
they evaluated the operational stability of B. firmus strain 37 cells immobilized on loofa sponge discs
and was reported that at the end of 10 days of process 63% of the initial production of β-CD was
maintained. The RSM indicated accuracy and applicability when it was used to optimize the
production of α-amylase by Streptomyces erumpens cells immobilized on loofa sponge [8]. Kumar and
Satyanarayana [26] immobilized sporangiospores of Thermomucor indicae-seudaticae on alginate to
produce glucoamylase, and used the RSM to optimize the production. The use of optimized parameters
led to an increase of 41 to 60% in enzyme production, depending on the type of reactor. In both
studies, the statistical models explained around 97% of the variability in the response.
2
.4. Effect of Immobilization Time of Bacillus firmus Strain 37 Cells on Loofa Sponge for
β-Cyclodextrin Production
The immobilization time of B. firmus strain 37 for a period of one to four days on loofa sponge was
evaluated by Pazzetto et al. [9], under the same conditions of this study, except that the initial biomass
was 70 mg of lyophilized cells. One day of immobilization was enough for the adhesion of bacterial
cells to the fibers of the sponge, because there was no difference in the β-CD production between the
different times. In this study, prolonged periods of immobilization were evaluated (10, 20 and

Molecules 2012, 17
9482
3
0 days) and the β-CD production by cells immobilized on loofa and synthetic sponges was compared.
Again, the increase in the immobilization time for cells immobilized on loofa sponge was not effective,
showing that the β-CD production is not influenced by the immobilization time.
The increase in the immobilization time for cells immobilized on synthetic sponge decreased
the β-CD production. A similar behavior was observed with the free cells. However, for cells
immobilized on loofa sponge, this increase in the contact time between cells and matrices was
indifferent, reaching an average production of 18.14 mM of β-CD (Figure 4).
Figure 4. Effect of immobilization time on β-CD production by free and immobilized
cells. ( ) 10 days; ( ) 20 days; and ( ) 30 days.
25
20
15
10
5
0
Free cells
Loofa sponge
Synthetic sponge
Similar results were found with the Streptomyces clavuligerus and Fusarium moniliforme
immobilization on loofa sponge. There was no increase in weight of the discs after 48 h of
immobilization, suggesting that the spaces of the sponge for microorganisms adhesion were saturated
at this time [20,27]. To Chlorella sorokiniana uptake of nickel (II) from aqueous solutions, the cells
were immobilized on loofa sponge for 10 days and, after, were taken from the culture flasks, washed
thoroughly with fresh culture medium to remove any free algal cells, transferred to fresh medium and
incubated 24 days for uniform algal growth along the surface of the fibers [28].
3. Experimental
3.1. General
β-Cyclodextrin and phenolphthalein were purchased from Sigma (St. Louis, MO, USA). Soluble
starch from potato (article 101,252) was purchased from Merck (Darmstadt, Germany). Maltodextrin
Dextrin 10 from maize starch, article 31,410) was obtained from Fluka (Buchs, Switzerland). Loofa
(
sponges were purchased in local market (Maringá, PR, Brazil). All other chemicals used were of
analytical grade. The bacterial suspensions were freeze-dried in a Christ Beta 1–16 freeze dryer.
Scanning electron micrographs were obtained from a scanning electron microscope Shimadzu model
SS 550 with an acceleration voltage of 10 kV. The β-CD concentrations were measured using a Tecnal
SP 1105 spectrophotometer (Piracicaba, Brazil).

Molecules 2012, 17
9483
3
.2. Culture Conditions and Microorganism Reactivation Procedure
A solid medium composed of (% w/v): 1.0 soluble starch; 0.5 polypeptone; 0.5 yeast extract;
.1 K HPO ; 0.02 MgSO ·7H O; 0.01 Congo red stain; 1.0 Na CO ; and 1.5 agar, was used for
0
2
4
4
2
2
3
cultivation of B. firmus strain 37, isolated from the soil of a cassava plantation by Matioli et al. [29].
With the colonies formed was prepared bacterial suspensions which were frozen and freeze-dried. The
lyophilized cells were stored in a freezer and used in the immobilization procedure. The microorganism
reactivation was carried out in 250 mL Erlenmeyer flasks containing 30 mg of lyophilized cells and
5
0 mL of liquid culture medium of similar composition to that of the solid medium, except for the agar
and stain. The flasks were incubated at 37 °C in an orbital shaker (120 rpm) for 24 h.
3.3. Immobilization Procedure
The immobilization of B. firmus on loofa sponge was carried out according to the method
developed by Meleigy and Khalaf [20] for production of gibberellic acid by F. moniliforme, with some
modifications. Loofa sponge, obtained from the dried fruit of Luffa operculata and free of seeds, was
cut into discs about 23–25 mm in diameter and 2–4 mm thick. The discs were soaked in boiling water
for 30 min, washed thoroughly with tap water, and left for 24 h in distilled water, changed three times.
They were then oven-dried at 70 °C and sterilized in an autoclave at 121 °C for 20 min.
For the immobilization of B. firmus on synthetic sponge, discs of this matrix were cut in the same
size as the loofa discs, put to boiling for 10 min, washed with distilled water, dried at room temperature
and sterilized by autoclaving at 121 °C for 20 min [9].
The immobilization process occurred by the addition of three loofa or synthetic sponge discs to the
medium containing the reactivated cells. The matrices and bacterial cells stayed in contact for 24 h at
3
7 °C in an orbital shaker at 100 rpm. To obtain the free biomass, the reactivated cells were separated
from the medium by centrifugation and used as controls.
3
.4. Scanning Electron Microscopy
The cell immobilization on loofa sponge was evaluated by Scanning Electron Microscopy (SEM)
using Shimadzu SS 550 microscope (Shimadzu Corporation, Kyoto, Japan) according to the method
described by Moriwaki et al. [30], using a scanning electron microscope with an acceleration voltage
of 10 kV. The pictures were taken of a single fiber after washing.
3
.5. Evaluation of Bacillus firmus Strain 37 Preservation by Lyophilization
B. firmus strain 37 was initially grown on solid medium and incubated at 37 °C for 48 h. The colonies
formed were removed from the culture medium and a bacterial suspension was prepared. One mL of
this suspension was transferred to small glass vials. The samples were frozen and freeze-dried.
Then, the lyophilized cells were stored in a freezer. The cells were reactivated, centrifuged and a
β-CD production was conducted at 60 °C in an incubator with shaking at 100 rpm, and 10%
maltodextrin (w/v) in 50 mM Tris-HCl and 5 mM CaCl , pH 8.0 for 144 h, with 30 mg of cells newly
2
lyophilized and cells with one year of storage. Aliquots of 1 mL were collected daily, diluted in 1 mL
of distilled water and boiled for subsequent quantification of the β-CD produced.

Molecules 2012, 17
.6. Cyclodextrin Production by Immobilized Cells
After the immobilization procedure described above, the matrices were washed in sterile saline
9484
3
and transferred to 250 mL Erlenmeyer flasks containing reaction medium, which consisted of 50 mL
of maltodextrin solutions at different concentrations and in combination with different pHs and
temperatures, which will be detailed in the following section. The production was conducted for
5
1
days, in an orbital shaker at 100 rpm. Aliquots of 1 mL were collected after 120 h of assay, diluted in
mL of distilled water, and boiled for later quantification of β-CD.
3
.7. Optimization of Conditions for β-Cyclodextrin Production by Immobilized Cells
The conditions for β-CD production by CGTase from B. firmus strain 37 immobilized by adsorption
on loofa sponge were optimized by RSM, by selecting the levels of three independent variables:
temperature, pH, and dextrin concentration. A factorial central composite design (CCD) was
constructed in which each factor was studied at two different levels. For temperature, the levels 40 °C
and 60 °C were defined, for pH the levels 6 and 8, and for the dextrin concentration the levels 5% and
15%. These levels were coded as +1 and −1 as shown in Table 1. Two axial points (−α, +α) were
added, which corresponded to the temperature levels of 33 °C and 67 °C, the pH levels of 5 and 9,
and the dextrin concentration levels of 2% and 18%. In addition to these, the central point was
implemented, which corresponded to the levels of 50 °C, pH 7, and 10% dextrin concentration.
Fifty mL of CD production medium were prepared in individual 250 mL Erlenmeyer flasks, in
different combinations of levels and variables. The experiments were conducted for 5 days as
described in the previous section, and the β-CD concentration was determined and taken as the
response variable.
Table 1. Experimental design and results of CCD for the response surface methodology.
β-CD Production (mM)
Experiments Temperature
pH
Dextrin
Experimental
8.830
Predicted
8.540
1
2
3
4
5
6
7
8
9
−1
1
−1
−1
1
−1
−1
−1
−1
1
6.462
2.846
−1
1
7.410
7.458
1
14.561
11.869
8.879
12.678
10.874
5.955
−1
1
−1
−1
1
1
−1
1
1
11.404
20.727
9.129
12.144
18.140
8.288
1
1
−α
+α
0
0
0
1
0
1
2
3
4
5
6
0
0
1.906
8.501
1
1
1
1
1
1
−α
+α
0
0
1.640
5.983
0
0
12.421
6.380
13.833
9.249
0
−α
+α
0
0
0
11.875
11.418
11.836
14.761
10.648
10.648
0
0
0
0
0

Molecules 2012, 17
9485
Table 1. Cont.
β-CD Production (mM)
Experiments Temperature
pH
Dextrin
Experimental
Predicted
10.648
10.648
10.648
10.648
10.648
10.648
1
1
1
2
2
2
7
8
9
0
1
2
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
11.889
11.370
12.273
12.202
12.580
11.687
3
.8. Influence of Immobilization Time on β-Cyclodextrin Production
β-CD production by cells immobilized on loofa sponge and synthetic sponge was evaluated at
different immobilization times. After the reactivation of 30 mg lyophilized cells, three matrices discs
were added to the culture media which were kept at 37 °C for 5 days. Then, the discs were removed
and transferred to fresh media, where they remained for over 5 days. This process was performed
several times until reaching final immobilization times of 10, 20, and 30 days. After immobilization,
β-CD production was carried out according to section 3.6, keeping 10% dextrin concentration,
temperature of 60 °C, and pH 8. Then, the amount of β-CD produced was determined as described
below. The same procedure was performed with free cells.
3
.9. Colorimetric Determination of β-Cyclodextrin
The assay was carried out by mixing sample (0.5 mL) and 0.06 mM phenolphthalein solution (2.5 mL)
containing 0.12 M carbonate-bicarbonate buffer that was prepared at the dosage moment from a
stock solution of 3 mM phenolphthalein in 95% ethanol. The absorbance was read at 550 nm and
for the blank, the sample was replaced by distilled water. The β-CD concentration was determined by
discoloration of phenolphthalein solution which occurs after the complexation with β-CD [30].
3
.10. Statistical Analysis
The results of β-CD production in the CCD experiments were submitted to analysis of variance and
a surface response second order was fit, using the program Statistica 8.0/2008 (Stat Soft, Inc., Tulsa,
OK, USA).
4
. Conclusions
Lyophilization showed to be a suitable method for the microorganism preservation, especially for
B. firmus strain 37 cells that remained viable for one year of storage. The use of RSM allowed the
construction of a statistical model of acceptable predictive ability for β-CD production using
immobilized B. firmus strain 37 cells on loofa sponge and showed the factorial CCD enabled to
find the appropriate parameters for the fermentation process conditions. An increase of the
immobilization time of cells on loofa sponge did not change the β-CD production. The results obtained
in this research are relevant because microorganism preservation from different sources is important

Molecules 2012, 17
9486
for many areas of research and clinical sciences, such as microbiology and biotechnology. Besides, the
optimization of the fermentation process is essential in these areas and for many industries.
Acknowledgments
The authors are thankful to the Brazilian Agencies CAPES, CNPq and Fundação Araucária for their
financial support of this work.
References
1.
2.
3.
4.
Hays, H.C.W.; Millner, P.A.; Jones, J.K.; Rayner-Brandes, M.H. A novel and convenient
self-drying system for bacterial preservation. J. Microbiol. Methods 2005, 63, 29–35.
Krumnow, A.A.; Sorokulova, I.B.; Olsen, E.; Globa, L.; Barbaree, J.M.; Vodyanoy, V.J.
Preservation of bacteria in natural polymers. J. Microbiol. Methods 2009, 78, 189–194.
Morgan, C.A.; Herman, N.; White, P.A.; Vesey, G. Preservation of micro-organisms by drying:
A review. J. Microbiol. Methods 2006, 66, 183–193.
Moriwaki, C.; Mazzer, C.; Pazzetto, R.; Matioli, G. Avaliação de métodos para manutenção e
preservação de bactéria esporulada produtora da enzima CGTase. Acta Sci. Health Sci. 2009, 31,
1
13–119.
5
.
.
Bjerketorp, J.; Hakansson, S.; Belkin, S.; Jansson, J.K. Advances in preservation methods:
Keeping biosensor microorganisms alive and active. Curr. Opin. Biotechnol. 2006, 17, 43–49.
Ratnam, B.V.V.; Subba Rao, S.; Damodar Rao, M.; Narasimha Rao, M.; Ayyanna, C.
Optimization of medium constituents and fermentation conditions for the production of ethanol
from palmyra jaggery using response surface methodology. World J. Microbiol. Biotechnol. 2005,
6
2
1, 399–404.
7
8
.
.
.
Alam, M.Z.; Jamal, P.; Nadzir, M.M. Bioconversion of palm oil mill effluent for citric acid
production: Statistical optimization of fermentation media and time by central composite design.
World J. Microbiol. Biotechnol. 2008, 24, 1177–1185.
Kar, S.; Swain, M.R.; Ray, R.C. Statistical optimization of alpha-amylase production with
immobilized cells of Streptomyces erumpens MTCC 7317 in Luffa cylindrica L. sponge discs.
Appl. Biochem. Biotechnol. 2009, 152, 177–188.
9
1
1
1
1
Pazzetto, R.; Delani, T.C.O.; Fenelon, V.C.; Matioli, G. Cyclodextrin production by Bacillus firmus
strain 37 cells immobilized on loofa sponge. Process Biochem. 2011, 46, 46–51.
0. Biwer, A.; Antranikian, G.; Heinzle, E. Enzimatic production of cyclodextrins. Appl. Microbiol.
Biotechnol. 2002, 59, 609–617.
1. Del Valle, E.M.M. Cyclodextrins and their uses: A review. Process Biochem. 2004, 39,
1
033–1046.
2. Yu, B.; Wang, J.; Zhang, H.; Jin, Z. Investigation of the interactions between the hydrophobic
cavities of cyclodextrins and pullulanase. Molecules 2011, 16, 3010–3017.
3. Satoh, T.; Miyataka, H.; Yamamoto, K.; Hirano, T. Synthesis and physiological activity of novel
tocopheryl glycosides. Chem. Pharm. Bull. 2001, 49, 948–953.

Molecules 2012, 17
9487
1
4. Shimoda, K.; Akagi, M.; Hamada, H. Production of β-maltooligosaccharides of α- and
δ-tocopherols by Klebsiella pneumoniae and cyclodextrin glucanotransferase as anti-allergic
agents. Molecules 2009, 14, 3106–3114.
1
1
5. Astray, G.; Gonzalez-Barreiro, C.; Mejuto, J.C.; Rial-Otero, R.; Simal-Gándara, J. A review on
the use of cyclodextrins in food. Food Hidrocolloid 2009, 23, 1631–1640.
6. Abdel-Naby, M.A.; Reyad, R.M.; Abdel-Fattah, A.F. Biosynthesis of cyclodextrin glucosyltransferase
by immobilized Bacillus amyloliquefaciens in batch and continuous cultures. Biochem. Eng. J.
2
000, 5, 1–9.
1
1
1
7. Karel, S.F.; Libicki, S.B.; Robertson, C.R. The immobilization of whole cells: Engineering
principles. Chem. Eng. Sci. 1985, 40, 1321–1354.
8. Hemachander, C.; Bose, N.; Puvanakrishnan, R. Whole cell immobilization of Ralstonia pickettii
for lipase production. Process Biochem. 2001, 36, 629–633.
9. Iqbal, M.; Saeed, A.; Edyvean, R.G.J.; Sullivan, B.O.; Styring, P. Production of fungal biomass
immobilized loofa sponge (FBILS)-discs for the removal of heavy metal ions and chlorinated
compounds from aqueous solution. Biotechnol. Lett. 2005, 27, 1319–1323.
2
0. Meleigy, S.A.; Khalaf, M.A. Biosynthesis of gibberellic acid from milk permeate in repeated
batch operation by a mutant Fusarium moniliforme cells immobilized on loofa sponge. Bioresour.
Technol. 2009, 100, 374–379.
2
1. Ogbonna, J.C.; Tomiyama, S.; Tanaka, H. Development of a method for immobilization of
non-flocculating cells in loofa (Luffa cylindrica) sponge. Process Biochem. 1996, 31, 737–744.
2. Domíngues, A.; Rivela, I.; Couto, S.R.; Sanromán, M.A. Design of a new rotating drum
bioreactor for ligninolytic enzyme production by Phanerochaete chrysosporium grown on an inert
support. Process Biochem. 2001, 37, 549–554.
2
2
2
2
2
3. Kourkoutasa, Y.; Bekatoroua, A.; Banatb, I.M.; Marchantb, R.; Koutinasa, A.A. Immobilization
technologies and support materials suitable inalcohol beverages production: A review. Food
Microbiol. 2004, 21, 377–397.
4. Mazzer, C.; Ferreira, L.R.; Rodella, J.R.T.; Moriwaki, C.; Matioli, G. Cyclodextrin production by
Bacillus firmus strain 37 immobilized on inorganic matrices and alginate gel. Biochem. Eng. J.
2
008, 41, 79–86.
5. Vignoli, J.A.; Celligoi, M.A.P.C.; Silva, R.S.F. Development of a statistical model for sorbitol
production by free and immobilized Zymomonas mobilis in loofa sponge Luffa cylindrical.
Process Biochem. 2006, 41, 240–243.
6. Kumar, P.; Satyanarayana, T. Optimization of culture variables for improving glucoamylase
production by alginate-entrapped Thermomucor indicae-seudaticae using statistical methods.
Bioresour. Technol. 2007, 98, 1252–1259.
2
7. Saudagar, P.S.; Shaligram, N.S.; Singhal, R.S. Immobilization of Streptomyces clavuligerus on
loofa sponge for the production of clavulanic acid. Bioresour. Technol. 2008, 99, 2250–2253.
8. Akhtar, N.; Iqbal, J.; Iqbal, M. Removal and recovery of nickel (II) from aqueous solution by
loofa sponge-immobilized biomass of Chlorella sorokiniana: Characterization studies. J. Hazard.
Mater. 2004, 108, 85–94.
2
2
9. Matioli, G.; Zanin, G.M.; Moraes, F.F. Characterization of cyclodextrin glycosyltransferase from
Bacillus firmus strain No. 37. Appl. Biochem. Biotechnol. 2001, 91–93, 643–654.

Molecules 2012, 17
9488
3
0. Moriwaki, C.; Pelissari, F.M.; Gonçalves, R.A.C.; Gonçalves, J.E.; Matioli, G. Immobilization of
Bacillus firmus strain 37 in inorganic matrix for cyclodextrin production. J. Mol. Catal. Enzyme
007, 49, 1–7.
2
Sample Availability: Samples of the compounds are available from the authors.
©
2012 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
http://creativecommons.org/licenses/by/3.0/).
(
