A. O’Byrne, P. Evans / Tetrahedron 64 (2008) 8067–8072
8071
J¼6.5 Hz, CH3), 1.23–1.36 (6H, m, CH2), 1.45–1.52 (1H, m, CH2), 1.62–
1.69 (1H, m, CH2), 2.90 (3H, s, CH3), 4.03–4.06 (1H, m, CH-2), 5.69
(1H, dd, J¼5.5, 9.5 Hz, CH-3), 6.38 (1H, d, J¼9.5 Hz, CH-4), 6.43 (1H,
d, J¼7.5 Hz, ArH), 6.59 (1H, t, J¼7.5 Hz, ArH), 6.88 (1H, dd, J¼1.5,
7.5 Hz, ArH), 7.09 (1H, dt, J¼1.5, 7.5 Hz, ArH); dC (125 MHz, CDCl3)
14.1 (CH3), 22.6 (CH2), 23.8 (CH2), 32.1 (CH2), 33.9 (CH2), 36.4 (CH3),
60.7 (CH), 109.8 (CH), 116.1 (CH), 121.8 (C), 125.2 (CH), 125.7 (CH),
126.7 (CH), 129.0 (CH), 145.3 (C); HRMS calcd for C15H20N (Mꢁ1)
requires 214.1596; found 214.1585. Further elution gave 2-pentyl-
quinoline 1412 (55 mg, 6%) as a yellow oil. Rf¼0.6 (cyclohexane–
EtOAc; 9:1); dH (400 MHz, CDCl3) 0.78 (3H, t, J¼7.0 Hz, CH3),
1.22–1.30 (4H, m, CH2), 1.67 (2H, pent, J¼7.5 Hz, CH2), 2.85 (2H, t,
J¼7.5 Hz, CH2), 7.16 (1H, d, J¼8.5 Hz, CH-3), 7.34 (1H, t, J¼8.0 Hz,
ArH), 7.55 (1H, t, J¼8.0 Hz, ArH), 7.63 (1H, d, J¼8.0 Hz, ArH), 7.92
(1H, d, J¼8.5 Hz, CH-4), 7.94 (1H, d, J¼8.0 Hz, ArH); dC (100 MHz,
CDCl3) 13.9 (CH3), 22.5 (CH2), 29.5 (CH2), 31.7 (CH2), 39.2 (CH2),
121.3 (CH), 125.6 (CH), 126.6 (C), 127.4 (CH), 128.7 (CH), 129.3 (CH),
136.2 (CH), 147.7 (C), 163.0 (C); HRMS calcd for C14H18N (Mþ1)
requires 200.1439; found 200.1430.
3.87 (3H, s, CH3), 3.89 (3H, s, CH3), 4.98 (1H, d, J¼5.0, CH), 5.76 (1H,
d, J¼5.0 Hz, CH), 6.83–6.86 (1H, m, ArH), 6.93–6.96 (2H, m, ArH); dC
(100 MHz, CDCl3) 52.3 (CH), 55.9 (CH3), 56.0 (CH3), 78.8 (CH), 109.8
(CH), 110.8 (CH), 119.6 (CH), 130.4 (C), 149.0 (C), 149.5 (C); HRMS
calcd for
360.9045.
C10H12O3Br2Na (MþNa) requires 360.9051; found
3.14. trans-5-(2-Bromovinyl)benzo[d][1,3]dioxole 1913
trans-3-Benzo[1,3]dioxol-5-yl-acrylic acid 16 (1.15 g, 6.00 mmol,
1 equiv), sodium bromide (1.85 g, 18.00 mmol, 3 equiv), sodium
carbonate (0.63 g, 6.00 mmol, 1 equiv) and oxone (3.69 g,
6.00 mmol, 1 equiv) were dissolved in acetonitrile (60 mL) and H2O
(40 mL) and the reaction stirred for 3 h. EtOAc (50 mL) was added
and the aqueous and organic layers were separated. The aqueous
layer was further extracted with EtOAc (2ꢃ50 mL). The combined
organic layers were dried over MgSO4, filtered and the solvent re-
moved under reduced pressure. Purification by flash column
chromatography (cyclohexane–EtOAc; 15: 1) afforded the title
compound 19 (681 mg, 50%) as a white solid; mp 39–42 ꢂC; Rf¼0.7
(cyclohexane–EtOAc; 2:1); nmax (neat/cmꢁ1) 3074, 3011, 2896,
2779, 2694, 2601, 2443, 2361, 2205, 2045, 1855, 1612, 1586, 1503,
1489, 1446, 1351, 1250, 1212, 1184, 1122, 1101, 1039, 930, 859, 820,
795, 770, 739, 713, 682, 634, 602, 568, 529; dH (400 MHz, CDCl3)
5.96 (2H, s, CH2), 6.59 (1H, d, J¼14.0 Hz, CH), 6.74–6.75 (2H, m,
ArH), 6.80–6.81 (1H, m, ArH), 7.00 (1H, d, J¼14.0 Hz, CH); dC
(100 MHz, CDCl3) 101.2 (CH2), 104.5 (CH), 105.4 (CH), 108.4 (CH),
120.9 (CH), 130.3 (C), 136.7 (CH), 147.7 (C), 148.1 (C); HRMS cacld for
C9H7O2Br requires 225.9629; found 225.9621. Further elution gave
1-benzo[1,3]dioxol-5-yl-2,2-dibromoethanol 2014 (933 mg, 48%) as
3.12. 1-Methyl-2-pentyl-1,2,3,4-tetrahydroquinoline
(angustureine) 11b,4b
A mixture of 1-methyl-2-pentyl-1,2-dihydroquinoline (923 mg,
4.29 mmol, 1 equiv) and 10% w/w Pd/C (250 mg, ca. 5 mol %) in
EtOAc (25 mL) was stirred under hydrogen (ca. 1 atm) for 24 h. The
reaction mixture was filtered through Celite and washed with
EtOAc (2ꢃ25 mL). Solvent removal under reduced pressure gave
angustureine 1 (920 mg, 99%) as a yellow oil. Rf¼0.5 (cyclohexane–
EtOAc; 19:1); nmax (neat/cmꢁ1) 3022, 2931, 2859, 1602, 1500; dH
(500 MHz, CDCl3) 0.94 (3H, t, J¼7.0 Hz, CH3), 1.27–1.48 (7H, m, CH2),
1.60–1.67 (1H, m, CH2),1.90–1.94 (2H, m, CH2-3), 2.69 (1H, ddd, app.
dt, J¼4.5, 16.5 Hz, CH2-4), 2.84 (1H, ddd, J¼7.0, 10.5, 16.5 Hz, CH2-4),
2.96 (3H, s, CH3), 3.24–3.28 (1H, m, CH-2), 6.56 (1H, d, J¼7.5 Hz,
ArH), 6.61 (1H, t, J¼7.5 Hz, ArH), 6.99 (1H, d, J¼7.5 Hz, ArH), 7.11
(1H, t, J¼7.5 Hz, ArH); dC (125 MHz, CDCl3) 14.1 (CH3), 22.7 (CH2),
23.7 (CH2), 24.6 (CH2), 25.8 (CH2), 31.3 (CH2), 32.1 (CH2), 38.0 (CH3),
59.0 (CH), 110.5 (CH), 115.3 (CH), 122.0 (C), 127.1 (CH), 128.7 (CH),
145.5 (C); HRMS calcd for C15H24N (Mþ1) requires 218.1909; found
218.1898.
a yellow oil. Rf¼0.4 (cyclohexane–EtOAc; 2:1); nmax (neat/cmꢁ1
)
3482, 3076, 3006, 2901, 1730, 1681, 1604, 1504, 1489, 1445, 1357,
1248, 1143, 1096, 1038, 931; dH (400 MHz, CDCl3) 4.94 (1H, d,
J¼5.0 Hz, CH), 5.72 (1H, d, J¼5.0 Hz, CH), 5.98 (2H, s, CH2), 6.80 (1H,
d, J¼8.0 Hz, ArH), 6.87 (1H, dd, J¼1.5, 8.0 Hz, ArH), 6.92 (1H, d,
J¼1.5 Hz, ArH); dC (100 MHz, CDCl3) 55.1 (CH), 78.7 (CH), 101.3
(CH2), 107.2 (CH), 108.1 (CH), 120.8 (CH), 131.7 (C), 147.7 (C), 148.0
(C); Anal. Calcd for C9H8O3Br2: C, 33.37; H, 2.49%; found, C, 33.78; H,
2.56%.
3.15. 2-[2-(3,4-Dimethoxyphenyl)ethyl]-1-methyl-1,2,3,4-
tetrahydroquinoline (cuspareine) 22,4c
3.13. trans-4-(2-Bromovinyl)-1,2-dimethoxybenzene 179
trans-(3,4-Dimethoxy)cinnamic acid 15 (1.25 g, 6.00 mmol,
1 equiv), sodium bromide (1.85 g, 18.00 mmol, 3 equiv), sodium
carbonate (0.63 g, 6.00 mmol, 1 equiv) and oxone (3.69 g,
6.00 mmol, 1 equiv) were dissolved in acetonitrile (60 mL) and H2O
(40 mL) and the reaction stirred for 3 h. EtOAc (50 mL) was added.
The resultant organic layer was separated and the aqueous layer
was extracted with EtOAc (2ꢃ50 mL). The combined organic layers
were dried over MgSO4, filtered and the solvent removed under
reduced pressure. Purification by flash column chromatography
(cyclohexane–EtOAc; 15: 1) afforded the title compound 17 (741 mg,
51%) as a white solid; mp 48–50 ꢂC; Rf¼0.5 (cyclohexane–EtOAc;
2:1); nmax (neat/cmꢁ1) 3075, 3002, 2957, 2935, 2909, 2835, 1603,
1578, 1514, 1461, 1441, 1418, 1329, 1264, 1246, 1205, 1190, 1158, 1140,
1026, 941, 855, 813, 773; dH (300 MHz, CDCl3) 3.89 (3H, s, CH3), 3.91
(3H, s, CH3), 6.63 (1H, d, J¼14.0 Hz, CH), 6.80–6.87 (3H, m, ArH),
7.03 (1H, J¼14.0, CH); dC (100 MHz, CDCl3) 55.7 (CH3), 55.8 (CH3),
104.2 (CH), 108.5 (CH), 111.1 (CH), 119.3 (CH), 128.9 (C), 136.7 (CH),
149.0 (C), 149.2 (C); HRMS cacld for C10H11O2Br requires 241.9942;
found 241.9946. Further elution gave 2,2-dibromo-1-(3,4-dime-
thoxyphenyl)ethanol 18 (702 mg, 34%) as a white solid; mp 42–
43 ꢂC; Rf¼0.4 (cyclohexane–EtOAc; 2:1); nmax (neat/cmꢁ1) 3482,
3004, 2960, 2936, 2837, 2599, 1717, 1677, 1595, 1515, 1463, 1420,
1341, 1265, 1237, 1141, 1094, 1080, 1025, 962; dH (300 MHz, CDCl3)
trans-4-(2-Bromovinyl)-1,2-dimethoxybenzene
17
(1.00 g,
4.10 mmol, 1 equiv) was dissolved in diethylether (30 mL) under
nitrogen at ꢁ78 ꢂC. To this a 1.7 M solution of tert-butyllithium in
pentane (4.80 mL, 8.20 mmol, 2 equiv) was added and the reaction
stirred for 1 min. This solution was then added dropwise to quin-
oline 5 (0.48 mL, 4.10 mmol, 1 equiv) dissolved in THF (30 mL)
under nitrogen at room temperature. Stirring was maintained at
room temperature for 10 min, then the reaction was brought to 0 ꢂC
and methyliodide (0.51 mL, 8.20 mmol, 2 equiv) was added drop-
wise. Stirring was maintained for 2 h. Saturated aqueous NH4Cl
(50 mL) and dichloromethane (50 mL) were added and the re-
sultant aqueous layer was further extracted with dichloromethane
(2ꢃ50 mL). The combined organic layers were dried over MgSO4,
filtered and the solvent removed under reduced pressure. Excess
quinoline 5 was removed by flash column chromatography (cy-
clohexane–EtOAc; 30:1). The crude product 21 was then dissolved
in EtOH (80 mL) and 10% w/w Pd/C (435 mg, ca. 10 mol %) was
added, the reaction was stirred under H2 (ca. 1 atm) for 72 h. The
reaction mixture was then filtered through Celite and washed with
EtOAc (2ꢃ50 mL). The solvent was removed under reduced pres-
sure and purification by flash column chromatography (cyclohex-
ane–EtOAc; 99:1) afforded the title compound 2 (664 mg, 52%) as
a yellow oil. Rf¼0.5 (cyclohexane–EtOAc; 2:1); nmax (neat/cmꢁ1
)
