Molecules 2010, 15, 3171-3178; doi:10.3390/molecules15053171
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Convenient and Efficient Microwave-Assisted Synthesis of a
Methyl Derivative of the Fused Indoloquinoline Alkaloid
Cryptosanguinolentine
Robert M. Gengan 1,*, Pitchai Pandian 1,2,*, Chandraprakash Kumarsamy 2 and
Palathurai S. Mohan 2
1
Department of Chemistry, Steve Biko Campus, Durban University of Technology, Durban-4001,
South Africa
2
Department of Chemistry, School of Chemical Sciences, Bharathiar University, Coimbatore-
641046, Tamil Nadu, India; E-Mail: ps_mohan_in@yahoo.com (P.S.M.)
* Author to whom correspondence should be addressed; E-Mails: genganrm@dut.ac.za (R.M.G.);
pitchaipandian@gmail.com (P.P.); Tel.: +27 313732309; Fax: +27 312022671.
Received: 10 March 2010; in revised form: 2 April 2010 / Accepted: 7 April 2010 /
Published: 29 April 2010
Abstract: An efficient synthesis of a methyl derivative of the indoloquinoline alkaloid
cryptosanguinolentine based on microwave-assisted reactions is described. The
microwave-assisted synthesis of an intermediate 4-hydroxy-2-methylquinoline yielded
86% of the desired product and other intermediates prepared yielded high % of products in
shorter reaction times, under optimum conditions, as compared to traditional methods.
Keywords: cryptosanguinolentine; microwave; phase transfer catalysis
1. Introduction
The roots of Cryptolepis sanguinolenta, a plant indigenous to West Africa [1,2] have been used by
Ghanian traditional healers to treat various disorders, including outbreaks of fever due to malaria and
urinary tract infections [3–5]. The efficacy of a concoction of the roots stimulated researchers to isolate
the organic components present, characterize their structures and elucidate their biological activities.
Alkaloids such as the angular fused indoloquinoline alkaloid cryptosanguinolentine and the linear
indoloquinoline alkaloids cryptolentine and cryptotackieine were isolated and characterized [6]. These

Molecules 2010, 15
3172
compounds exhibit strong antiplasmodial activity and behave as DNA intercalating agents, thereby
inhibiting DNA replication and transcription. Crypto-sanguinolentine, a planar aromatic compound
with functional groups at positions suitable for intercalating with a DNA helix and thereby altering the
conformation of this helix [6] has received significant attention. Methyl derivatives of these types of
indoloquinoline alkaloids have been reported [7,8] to act as cytotoxic agents, liposomally-formulated
anticancer agents [9], and DNA-topoisomerase II inhibitors [10].
According to literature, the synthesis of cryptosanguinolentine by an intramolecular reaction of an
iminophosphorane with an isocyanate [11–13], by the regioselective thermocyclization of the
corresponding azide [14] or by ortho-metalation using a cross-coupling strategy [15] was used in the
1990s. Our research thrust in the synthesis of cryptosanguinolentine was initially based on a three step
photo-induced cyclization reaction giving excellent yield [16]. We subsequently developed a
convenient and efficient three step procedure using the Fischer indole strategy [17] which gave the
products in high yield. The Fischer indole methodology is one of the most important processes in
heterocyclic chemistry, leading to a large variety of hetero-polycyclic biologically active compounds
containing the indole nucleus and in some cases is the only method available for reaching target
structures. Our subsequent report on the synthesis of the methyl derivative of cryptosanguinolentine
was via a heteratom-directed photoannulation technique [18]. Recently we reported a five step
procedure using a simple starting material, viz., β anilinocrotonate, with the aid of a photochemical
reactor and a domestic microwave [19]. In continuation with the synthesis of the methyl derivative of
cryptosanguinolentine we herein report a more efficient synthetic scheme using microwave assisted
reactions to produce high yields of the intended products. The main benefits of performing reactions
under microwave conditions are the significant enhancement of reaction rates, higher product yields as
well as conforming to global demands for the use of green technology.
2. Results and Discussion
The optimum microwave conditions for the preparation of 4-hydroxy-2-methylquinoline (2) from β-
anilinocrotonate (1) (Scheme 1) were optimised; compound 1 was heated directly without any solvent
for three minutes at 250 watts and 180 ºC. The solid was collected, purified and the yield recorded as
86%. Compound 2 was confirmed by its IR spectrum, which exhibited a broad characteristic O-H
1
stretch at 3,062 cm-1and CH3 C-H stretching at 2,767 cm-1; its H-NMR spectrum displayed a CH3
singlet at δ 2.49, and a broad singlet at δ 11.60 for the O-H proton. Our earlier investigations [19] of
the yield of 2 via a domestic microwave was marginally lower (80%).
3-Iodo-4-hydroxy-2-methylquinoline (3) was prepared from the reaction of 2 with a mixture of
iodine, potassium iodide and sodium hydroxide in tetrahydrofuran. The product identity was confirmed
1
from its H-NMR data by the disappearance of the singlet at δ 5.90 due to the C-3 proton of the 4-
quinolone. Thereafter 3 was refluxed with phosphorous oxychloride under microwave irradiation for 1
minute at 150 watts and 85 ºC to produce 4 in 95% yield. The yield was the same as our previous
report [19], however the reaction time was significantly reduced compared to the classic solvent reflux
methodology. Compound 4 was confirmed by its IR spectrum which showed the appearance of C-Cl
stretching at 758 cm-1, as well as the disappearance of the broad OH signal. This was further confirmed

Molecules 2010, 15
3173
by the disappearance of the OH peak in the 1H-NMR spectrum and the appearance of δ 110.78 for the
corresponding carbon in 13C-NMR spectrum.
The amination of 4 to 5 was a simple room temperature reaction performed by stirring 4 in a
mixture of aniline in ethanol to produce a pale yellow solid 5; this was recrystallized from chloroform
and the yield recorded as 98%. The characteristic N-H stretching at 3334 cm-1 in the IR spectrum, a
1
broad singlet at δ 8.56 for the N-H proton in the H-NMR and a C3 signal at δ 51.97 in the 13C-NMR
spectrum confirms the identity of compound 5.
For the next step in the reaction scheme, compound 5 was taken in up water and mixed with
triphenylphosphine, sodium carbonate, palladium acetate with tricaprylyl methyl ammonium chloride
(TCMAC) and was refluxed at 80 ºC under microwave irradiation. The spectral data of 6 matched the
compound obtained from the photochemical cyclization method we reported recently [19]; the
elimination of iodine due to ring closure was confirmed by the appearance of a C-3 signal at δ 126.73
13
in the C-NMR spectrum. The yield (83%) of 6 was higher than that obtained by the photochemical
procedure. To our knowledge, this is the first time this cyclization reaction has been performed. The
improved yield is due to the eco-friendly methodology that we used: a microwave assisted reaction
using water as the solvent, phase transfer catalysis, and palladium acetate catalysis for a regio- and
stereoselective product.
Scheme I. Synthesis of 5,6-dimethyl-5H-indolo[3,2-c]quinoline 7 from β-anilinocrotonate 1.
OH
COOC2H5
250watts,
180oC, 3min
N
CH3
N
1
CH3
2
THF, I2,
KI,NaOH
OH
Cl
N
I
I
POCl3, 150watts,
85oC, 1min
N
CH3
CH3
4
3
Aniiline,
Ethanol,rt
HN
HN
N
PPh3, Na2CO3,
TCMAC, H2O,
200 watts, 100oC,
I
5 min
N
CH3
CH3
6
5
10
9
Me2SO4, K2CO3, DMF,
250 watts, 120oC
10a
N
8
1
11b
11a
4a
6b 7
6a
2
3
6
N
CH3
4
CH3
7

Molecules 2010, 15
3174
The final step in the synthesis of the methyl substituted cryptosanguinolentine 7 involved selective
methylation of the N atom of the quinoline skeleton. This was accomplished by reacting 6 with
dimethyl sulphate and potassium carbonate under microwave conditions (250 watts, 120 ºC for 3 min).
The yield of 7 however, was marginally higher than in our previous report [19]. The methylation
product was confirmed by the appearance of a singlet at δ 3.75 in the 1H-NMR spectrum.
3. Experimental Section
3.1. General methods
Melting points are uncorrected. Infrared spectra were recorded on a Perkin-Elmer Paragon 1000
1
FTIR spectrophotometer as potassium bromide discs, unless otherwise indicated. H-NMR spectra
were obtained on a Bruker 500 MHz, 400 MHz or 300 MHz instrument in either CDCl3 or DMSO-D6
solutions using tetramethylsilane as an internal standard. J Values are given in Hz. Mass spectra were
obtained at the Indian Institute of Chemical Technology, Hyderabad, India. Column chromatography
utilized Merck silica gel 60 and hexane and ethyl acetate as eluants. All the basic chemicals were
purchased from Merck (South Africa) and Fluka (South Africa). The Microwave used is a CEM
Microwave synthesizer.
3.2. Preparation of β-anilinocrotonate (1)
Freshly distilled aniline (0.25 mol) and ethyl acetoacetate (0.25 mol) were mixed, 5–10 drops of
concentrated hydrochloric acid was added and the mixture was gently shaken at room temperature.
This mixture was left aside and within a few minutes it became turbid thereby indicating the liberation
of water due to a condensation reaction. At this stage, the mixture was placed inside a vacuum
desiccator over concentrated sulphuric acid and kept for 2–3 days. A deep yellow oily liquid 1, was
separated and dried over anhydrous sodium sulphate.
3.3. Synthesis of 4-hydroxy-2-methylquinoline (2)
Dried ethyl-β-anilinocrotonate (1, 25 mL) was subjected to microwave heating for 3 min at
250 watts and 150 ºC in the synthetic microwave oven. The solid formed was washed with ethyl
acetate (200 mL), followed by a mixture of chloroform and petroleum ether (30:10) to give a pure
1
white powder. Yield 11.82 g (86%); m.p. 256 ºC; IR (KBr) [υmax cm-1] 3062 (O-H), 2767 (C-H); H-
NMR (DMSO-D6, 300 MHz, DMSO-D6 = 2.50 ppm) δ 2.49 (s, 3H, CH3), δ 5.90 (s, 1H, H-3), δ 7.26
(t, 1H, H-6), δ 7.49 (d,1H, H-5, J = 7.2 Hz), δ 7.60 (t, 1H, H-7, J = 7.6 Hz), δ 8.02 (d,1H, H-8,
J = 8.0 Hz), δ 11.60 (bs, 1H, OH).
3.4. Synthesis of 4-hydroxy-3-iodo-2-methylquinoline (3)
A mixture of 2-phenylquinolin-4(1H)-one 2 (0.5 g, 2.26 mmol), iodine (1.15 g, 4.52 mmol) and
sodium carbonate (0.36 g, 3.43 mmol) in THF (20 mL) was stirred at room temperature for 12 h and

Molecules 2010, 15
3175
then poured into a saturated ice-cold aqueous sodium thiosulphate solution. The precipitate was
collected, washed with water and recrystallized to afford compound 3. Yield 0.920 g (75%);
1
m.p. 190 ºC; IR (KBr)[υmax cm-1] 3257 (O-H), 2916 (C-H); H-NMR (DMSO-D6, 400 MHz,
DMSO-D6 = 2.50 ppm) δ 2.49 (s, 3H, CH3), δ 7.37 (t, 1H, C6-H, J = 7.2 Hz), δ 7.55 (d, 1H, H-5,
J = 8.4 Hz), δ 7.69 (t, 1H, H-7, J = 8.0 Hz), δ 8.09 (d, 1H, H-8, J = 8.0 Hz), δ 12.20 (s, 1H, OH).
3.5. Synthesis of 4-chloro-3-iodo-2-methylquinoline (4)
A mixture of 4-hydroxy-3-iodo-2-methylquinoline (3, 1.43 g, 0.005 mol) in phosphorus oxychloride
(4 mL) was heated under reflux for 1 min at 150 watts and 80 ºC. The mixture was cooled to room
temperature, slowly added to ice-water and neutralized with a dilute NaOH solution. The precipitate
thus obtained was filtered and dried. Yield 1.42 g (95%); m.p. 70 ºC; IR (KBr) [υmax cm-1] 1550 (C=N),
1338 (C-I), 758 (C-Cl); 1H-NMR (CDCl3, 400 MHz, CDCl3 = 7.24 ppm) δ 3.02 (s, 3H, CH3), δ 7.56 (t,
1H, H-6, J = 7.2 Hz), δ 7.74 (t, 1H, H-7, J = 8.0 Hz), δ 8.00 (d, 1H, H-5, J = 8.0Hz), δ 8.20 (d, 1H, H-
8, J = 8.0Hz); 13C-NMR (CDCl3, 100 MHz, CDCl3 = 70.00 ppm) δ 155.13 (C-2), 27.34 (CH3), 110.78
(C-3), 157.50 (C-4), 131.77 (C-4a), 120.45 (C-5), 124.33 (C-6), 127.62 (C-7), 129.15 (C-8), 149.34
(C8a), 144.79 (C-1´), 119.42 (C-2´ & C-2´´), 115.71(C-3´& C-3´´), 120.11 (C4´).
3.6. Synthesis of 4-anilino-3-iodo-2-methylquinoline (5)
4-Chloro-3-iodo-2-methylquinoline (4, 1.51 g, 0.005 mol) and aniline (0.93 mL, 0.01 mol) were
dissolved in dry ethanol (30 mL). The initial colour of the reaction mixture was colourless, but
changed into yellow after some 15 min. The reaction was monitored by thin layer chromatography (tlc)
and the formation of product was confirmed by the appearance of a new spot with Rf equal to the
standard. The reaction mixture was stirred for a further 30 min, filtered, dried and recrystallized from
1
chloroform. Yield 1.29 g (98%); m.p. 180 ºC; IR (KBr) [υmax cm-1] 3334 (N-H); H-NMR (CDCl3,
400 MHz, CDCl3 = 7.24 ppm) δ 3.18 (s, 3H, CH3), δ 7.07 (d, 2H, Ph-H-2′& H-2′′, J = 8.0 Hz), δ 7.22
(t, 2H, H-3′& H-3′′, J = 8.0 Hz), δ 7.38 (m, 3H, H-5, H-6 & H-7, J = 8.0 Hz), δ 7.54 (d, 1H, H-8,
13
J = 8.0Hz), δ 7.72 (t, 1H, H-4′, J = 7.2Hz), δ 8.56 (bs, 1H, NH); C-NMR (CDCl3, 100 MHz,
CDCl3 = 70.00 ppm) δ 159.01 (C-2), 13.05 (CH3), 51.97 (C-3), 148.27 (C-4), 125.16 C-4a)-, 124.33
(C-6), 129.76 (C-7 & C-8), 147.39 (C-8a), 131.08 (C-1´), 96.43 (C-2´& C-2´´), 129.46 (C-3´ & C-3´´),
125.82 (C-4´& C-5).
3.7. Synthesis of 6-methyl-11H-indolo[3,2-c]quinoline (6)
A mixture of compound 5 (1.96 g, 0.0024 mol), triphenylphosphine (0.12 g, 0.0046 mol),
palladium(II) acetate (0.03 g, 0.0001 mol) and sodium hydrogen carbonate (0.62 g, 0.0074 mol) and
tricaprylmethylammonium chloride as phase transfer catalyst was refluxed in water at 100 ºC for 5 min
at 200 watts. The mixture was allowed to cool to room temperature, poured into water and then
acidified to pH 2–3 with dilute hydrochloric acid. The mixture was extracted several times with ethyl
acetate and the combined organic extracts were washed with water, dried with anhydrous sodium
sulphate, filtered and evaporated under reduced pressure giving 6-methyl-11H-indolo[3,2-c]quinoline

Molecules 2010, 15
3176
1
(6). Yield 0.95 g (83%); m.p. 210 ºC; IR (KBr)[υmax cm-1] 3307 (N-H); H-NMR (DMSO-D6,
500 MHz, DMSO-D6 = 2.50 ppm) δ 2.43 (s, 3H, CH3), δ 7.33–7.88 (m, 7H, Ar-H), δ 8.07 (d, 1H, H-
13
4), δ 10.51 (bs, 1H, NH); C-NMR (DMSO-D6, 125 MHz, DMSO-D6 = 40.0 ppm) δ 127.41 (C-1), δ
124.69 (C-2), δ 126.73 (C-3), δ 129.44 (C-4), δ 150.17 (C-4a), δ 154.75 (C-6), δ 23.14 (CH3), δ
122.57 (C-6a), δ 126.78 (C-6b), δ 120.29 (C-7), δ 124.43 (C-8), δ 119.54 (C-9), δ 118.64 (C-10), δ
135.67 (C-10a), δ 136.73 (C-11a), δ 130.11 (C-11b).
3.8. Synthesis of 5,6-dimethyl-5H-indolo[3,2-c]quinoline (7)
A mixture of compound 6 with dimethyl sulphate (1.5 mL) was taken up in dimethylformamide
(10 mL) and potassium carbonate (500 mg) was added. The whole mixture was subjected to
microwave heating for 3 min at 250 watts and 120 ºC. The completion of the reaction was monitored
by tlc. The mixture was then poured into crushed ice (300 mL) and extracted with ethyl acetate
(100 mL × 3). The combined organic layers was subjected to silica gel column chromatography with a
gradient elution with petroleum ether and ethyl acetate in a 35:65 ratio, and the mass of 5,6-dimethyl-
5H-indolo[3,2-c]quinoline (7) was recorded. Yield 1.08 g (86%); m.p. 189 ºC; IR (KBr)[υmax cm-1]
1626 (C=N) ; 1H-NMR (DMSO-D6, 500 MHz, DMSO-D6 = 2.50 ppm) δ 2.43 (s, 3H, C6–CH3), δ 3.75
(s, 3H, C5–CH3), δ 7.36–7.92 (m, 7H, Ar-H), δ 8.26 (d, 1H, H-4, J 8.2Hz); 13C-NMR (DMSO-D6, 125
MHz, DMSO-D6 = 40.0 ppm) δ 127.41 (C-1), δ 124.69 (C-2), δ 126.73 (C-3), δ 129.44 (C-4), δ
150.17 (C-4a), δ 154.75 (C-6), δ 23.14 (CH3), δ 122.57 (C-6a), δ 126.78 (C-6b), δ 120.29 (C7), δ
124.43 (C-8), δ 119.54(C-9), δ 118.64 (C-10), δ 135.67 (C-10a), δ 136.73 (C-11a ), δ 130.11 (C-11b).
4. Conclusions
The use of microwave irradiation provided an efficient, rapid and practical method for the synthesis
of a methyl derivative of the indoloquinoline alkaloid cryptosanguinolentine. Higher yields were
obtained for all intermediates as well as the final product.
Acknowledgements
We would like to thank the Durban University of Technology and the National Research
Foundation for financial support of this work.
References
1. Sharaf, M.H.M.; Schiff, P.L.; Tackie, A.N.; Phoebe, C.H.; Martin, G.E. Two new indoloquinoline
alkaloids from Cryptolepis sanguinolenta: cryptosanguinolentine and cryptotackieine. J.
Heterocycl. Chem. 1996, 33, 239–243.
2. Cimanga, K.; De Bruyne, T.; Pieters, L.; Claeys, M.; Vlietinick, A. New alkaloids from
Cryptolepis sanguinolenta. Tetrahedron Lett. 1996, 37, 1703–1706.
3. Karou, D.; Savadogo, A.; Canini, A.; Yameogo, S.; Montesano, C.; Simpore, J.; Colizzi, V.;
Traore, A.S. Antibacterial activity of alkaloids from Sida acuta. Afr. J. Biotechnol. 2006, 5,
195–200.

Molecules 2010, 15
3177
4. Ansah. C.; Gooderham, N.J. The popular herbal antimalarial, extract of Cryptolepis sanguinolenta,
is potently cytotoxic. Toxicol. Sci. 2002, 70, 45–251; and the references cited therein.
5. Bierer, D.E.; Fort, D.M.; Mendez, C.D.; Luo, J.; Imbach, P.A.; Dubenko, L.G.; Jolad, S.D.;
Gerber, R.E.; Litvak, J.; Lu, Q.; Zhang, P.; Reed, M.J.; Waldeck, N.; Bruening, R.C.; Noamesi,
B.K.; Hector, R.F.; Carlson, T.J.; King, S.R. Ethnobotanical-directed discovery of the
antihyperglycemic properties of cryptolepine: Its isolation from Cryptolepis sanguinolenta,
synthesis, and in vitro and in vivo activities. J. Med. Chem. 1998, 41, 894–901.
6. Blinov, K.; Elyashberg, M.; Martirosian, E.R.; Molodtsov, S.G.; Williams, A.J.; Tackie, A.N.;
Sharaf, M.M.H.; Schiff, P.L.; Crouch, R.C.; Martin, G.E.; Hadden, C.E.; Guido, J.E.; Mills, K.A.
Quindolinocryptotackieine: the elucidation of a novel indoloquinoline alkaloid structure through
the use of computer-assisted structure elucidation and 2D NMR. Magn. Reson. Chem. 2003, 41,
577–584; and the references sited therein.
7. Peczyriskc-Czoch,W.; Pognan, F.; Kaczmarck, L.; Boratyriski, J. Synthesis and structure-activity
relationship of methyl-substituted indolo[2,3-b]quinolines: Novel cytotoxic, DNA topoisomerase
II inhibitors. J. Med. Chem. 1994, 37, 3503–3510.
8. Sundaram, G.S.M.; Venkatesh, C.; Kumar, U.K.S.; Ila, H.; Junjappa, H. A concise formal
synthesis of alkaloid cryptotackiene and substituted 6H-indolo[2,3-b]quinolines, J. Org. Chem.
2004, 69, 5760–5762.
9. Jaromin, A.; Kozubek, A. Liposomal formulation of DIMIQ, potential antitumor indolo[2,3-
b]quinoline agent and its cytotoxicity on hepatoma morris 5123 cells. Drug Delivery 2008, 15,
49–56; and the references cited therein.
10. Kaczmarek, L.; Peczynska-Czoch, W.; Opolski, A.; Wietrzyk, J.; Marcinkowska, E.; Boratynski,
J.; Osiadacz, J. Methoxy- and methyl-, methoxy- 5,6,11-trimethyl-6H-indolo[2,3-b]quinolinium
derivatives as novel cytotoxic agents and DNA topoisomerase II inhibitors. Anticancer Res. 1998,
18, 3133–3138.
11. Molina, P.; Fresneda, P.M.; Delgado, S. Iminophosphorane-mediated synthesis of the alkaloid
cryptotackieine. Synthesis 1999, 2, 326–329.
12. Molina, P.; Alajarin, M.; Vidal, A. New methodology for the preparation of pyrrole and indole
derivatives via iminophosphoranes: synthesis of pyrrolo[1,2-a]quinoxalines, indolo[3,2-
c]quinolines and indolo[1,2-c]quinazolines. Tetrahedron 1990, 46, 1063–1078.
13. Fresneda, M.; Molina, P.; Delgado, S. A divergent approach to cryptotackieine and
cryptosanguinolentine alkaloids. Tetrahedron Lett. 1999, 40, 7275–7278.
14. Trecourt, F.; Mongin, F.; Mallet, M.; Queguiner, G. Substituted 8-methoxyquinolines:
regioselective bromination, coupling reactions and cyclization to an 11H-indolo[3,2-C]quinoline.
Synth. Commun. 1995, 25, 4011–4024.
15. Timari, G.; Soos, T.; Hajos, G. A Convenient synthesis of two new indoloquinoline alkaloids.
Synlett 1997, 1067–1068.
16. Kumar, R.N.; Suresh, T.; Mohan, P.S.
A
photochemical route to synthesize
cryptosanguinolentine. Tetrahedron Lett. 2002, 43, 3327–3328.
17. Dhanabal, T.; Sangeetha, R.; Mohan, P.S. Fischer indole synthesis of the indoloquinoline
alkaloid: cryptosanguinolentine. Tetrahedron Lett. 2005, 46, 4509–4510.

Molecules 2010, 15
3178
18. Dhanabal, T.; Sangeetha, R.; Mohan, P.S. Heteroatom directed photoannulation: synthesis of
indoloquinoline alkaloids: cryptolepine, cryptotackieine, cryptosanguinolentine, and their methyl
derivatives. Tetrahedron 2006, 62, 6258–6263.
19. Pitchai, P.; Mohan, P.S.; Gengan, R.M. Photo induced synthesis of methyl derivative of
cryptosanguinolenine. Indian J. Chem. Sec.B. Org. Chem. Incl. Med. Chem. 2009, 48B, 692–696.
Sample Availability: Samples of the compounds are available from the authors.
© 2010 by the authors; licensee MDPI, Basel, Switzerland. This article is an open-access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/3.0/).
