Organic Process Research & Development
Article
degassed. Separately, THF (339 L), 31 (24.2 kg, 41.4 mol), 13
(15.1 kg, 51.3 mol, 1.24 equiv), and di-tert-butyl dicarbonate
(2.33 kg, 10.7 mol, 0.26 equiv) were combined, and the mixture
was degassed 5 times and heated to 40 °C. Next, the catalyst
[1,1′-bis(di-tert-butylphosphino)]ferrocene palladium(II) di-
chloride (Pd-118) (0.40 kg, 0.61 mol, 0.015 equiv) was
added, followed by the degassed aqueous potassium phosphate
tribasic solution. The mixture was stirred at 45 °C for a total of
70 min, resulting in complete conversion to product. The
mixture was cooled to 20 °C, and the phases were separated.
The organic layer was vacuum-distilled at 60 °C, and 225 L of
distillate was collected. The mixture was stirred at 55 °C for 2
h, cooled to 20 °C within 3 h, and held at this temperature for
19 h. The slurry was filtered, and the reactor and wet cake were
washed with a mixture of THF (30 L) and water (30 L). The
product was dried on a filter dryer under vacuum and a stream
of N2. This wet cake (14.3% loss on drying) was divided into
two equal portions (16.3 kg each), suspended in a mixture of
THF (420 L) and water (20 L), and heated to 60 °C. To this
mixture was added thiol-functionalized silica gel (3.87 kg). The
mixtures were stirred at 60 °C for 6 h and filtered, and the
reactor was rinsed with 60 °C THF (20 L). The filtrate (846 L)
was vacuum-distilled at 60 °C to one-third of the original
volume. To the concentrate was added IPA (223 L), and then
the mixture was vacuum-distilled. This step was repeated with
additional IPA (223 L) at 60 °C. The resultant concentrate was
cooled to 10 °C within 2 h and held at this temperature for 17
h, after which the slurry was filtered and the wet cake was
washed with cold IPA. The product was dried in a filter dryer
with vacuum and a stream of N2, resulting in 17 (25.12 kg, 99.7
area %, 86.9 wt %, 80.8% yield) with low metal content (14
108.9, 108.7, 108.4, 108.2, 107.8, 35.5, 21.7. HR-MS: calcd for
C30H22F2N6O3 + H, 553.1794; found, 553.1788.
ASSOCIATED CONTENT
■
S
* Supporting Information
1H and 13C NMR spectra for the compounds in Scheme 12
along with experimentals for Schemes 1, 5, and 6. This material
AUTHOR INFORMATION
Corresponding Author
■
Notes
The authors declare no competing financial interest.
ACKNOWLEDGMENTS
■
We thank David Mitchell, Sau-Chi Betty Yan, Mike Prunier,
Janet Boggs, Todd Simard, Bob Murff, Jim Ray, John Howell,
Pat Pollock, Dave Robbins, Steve Myers, Jeff Wei, Lori Hilden,
Susan Reutzel-Edens, Zac Gunter, and Steve Bandy for their
contributions.
REFERENCES
■
(1) Stewart, G. W.; Brands, K. M. J.; Brewer, S. E.; Cowdon, C. J.;
Davies, A. J.; Edwards, J. S.; Gibson, A. W.; Hamilton, S. E.; Katz, J. D.;
Keen, S. P.; Mullens, P. R.; Scott, J. P.; Wallace, D. J.; Wise, C. S. Org.
Process Res. Dev. 2010, 14, 849−858.
(2) Liu, X.; Newton, R. C.; Scherle, P. A. Expert Opin. Invest. Drugs
2011, 20, 1225−1241.
(3) Yan, S. B.; Peek, V. L.; Ajamie, R.; Buchanan, S. G.; Graff, J. R.;
Heidler, S. A.; Hui, Y.; Huss, K. L.; Konicek, B. W.; Manro, J. R.; Shih,
C.; Stewart, J. A.; Stewart, T. R.; Stout, S. L.; Uhlik, M. T.; Um, S. L.;
Wang, Y.; Wu, W.; Yan, L.; Yang, W. J.; Zhong, B.; Walgren, R. A.
Invest. New Drugs 2013, 31, 833−844.
(4) (a) Jacobsen, P.; Huber, L. Ber. Dtsch. Chem. Ges. 1908, 41, 660−
671. (b) Troendlin, F.; Werner, R.; Ruechardt, C. Chem. Ber. 1978,
111, 367−378. (c) Ruechardt, C.; Hassmann, V. Liebigs Ann. Chem.
1980, 908−927.
(5) Pesti, J. A.; LaPorte, T.; Thornton, J. E.; Spangler, L.; Buono, F.;
Crispino, G.; Gibson, F.; Lobben, P.; Papaioannou, C. G. Org. Process
Res. Dev. 2014, 18, 89−102.
(6) v. Auwers, K.; Pfuhl, W. Ber. Dtsch. Gem. Ges. 1925, 58B, 1360−
1369.
(7) (a) Studer, M.; Baumeister, P. Catalytic Hydrogenation of
Aromatic Nitro Compound. WO 9636597, Nov 21, 1996.
(b) Baumeister, P.; Blaser, H.; Studer, M. Catal. Lett. 1997, 49,
219−222. (c) Lamatsch, B. Preparation of Sparingly Soluble Aromatic
Amines. WO 9936462, July 22, 1999.
(8) (a) Brethericks Handbook of Reactive Chemical Hazards, 6th ed.;
Urben, P. G., Ed.; Butterworth-Heinemann: Boston, 1999; p 746.
(b) Bright, R.; Dale, D. J.; Dunn, P. J.; Hussain, F.; Kang, Y.; Mason,
C.; Mitchell, J. C.; Snowden, M. J. Org. Process Res. Dev. 2004, 8,
1054−1058. (c) Dunn, P. J.; Hoffmann, W.; Kang, Y.; Mitchell, J. C.;
Snowden, M. J. Org. Process Res. Dev. 2005, 9, 956−961.
(9) (a) Rawal, V. H.; Cava, M. P. Tetrahedron Lett. 1985, 26, 6141−
6142. (b) Choy, J. C.; Jaime-Figueroa, S.; Muchowski, J. M.; Wagner,
P. J. Deprotection of N-Boc Compounds Using Heat in a Fluorinated
Alcohol Solution. EP 2070889, April 12, 2008.
1
ppm Pd; <1 ppm Pt, Zn; 5.5 ppm Fe). H NMR (DMSO-d6,
400 MHz): δ 11.95 (s, 1H), 8.62 (s, 1H), 8.46 (d, 1H, J = 8.0
Hz), 8.40 (s, 1H), 8.19 (s, 1H), 7.97 (m, 2H), 7.44 (m, 4H),
7.34 (s, 1H), 7.28 (d, 1H, J = 9.2 Hz), 6.92 (t, 1H, J = 9.2 Hz),
6.69 (d, 1H, J = 8.0 Hz), 4.10 (s, 3H), 2.06 (s, 3H), 1.58 (s,
9H). 13C NMR (DMSO-d6, 100 MHz): δ 163.0, 161.6, 160.7,
153.3, 147.4, 146.9, 144.0, 143.2, 139.6, 139.5, 137.1, 134.8,
132.1, 130.1, 130.0, 128.9, 122.6, 121.4, 119.8, 117.0, 116.7,
116.5, 109.5, 109.0, 107.8, 85.2, 35.6, 27.4, 21.7. HR-MS: calcd
for C35H30F2N6O5 + H, 653.2319; found, 653.2313.
N-(3-Fluoro-4-((1-methyl-6-(1H-pyrazol-4-yl)-1H-inda-
zol-5-yl)oxy)phenyl)-1-(4-fluorophenyl)-6-methyl-2-oxo-
1,2-dihydropyridine-3-carboxamide (1, LY2801653). Ab-
solute ethanol (430 L), 17 (25.0 kg, 33.30 mol), and a seed of
the correct form (87 g, 0.005 equiv) were combined. The
resultant suspension was heated to reflux, and 1,8-
diazabicyclo[5.4.0]undec-7-ene (DBU) (6.14 kg, 40.3 mol,
1.21 equiv) was added. The mixture was refluxed for 9 h
(resulting in 99.92% conversion), cooled to 10 °C over 14 h,
and stirred at 10 °C for 2.5 h. The slurry was filtered on a filter
dryer, and the reactor and wet cake were washed with cold
ethanol (54 L). The product was dried in a filter dryer by
applying vacuum and a stream of N2, resulting in 1 (18.54 kg,
1
99.4 area %, 98.75 wt %, 99.5% yield). H NMR (DMSO-d6,
400 MHz): δ 12.98 (s, 1H), 11.93 (s, 1H), 8.46 (d, 1H, J = 7.6
Hz), 8.16 (s, 1H), 8.03 (s, 1H), 8.00 (s, 1H), 7.96 (dd, 1H, J =
2.4 Hz, J = 13.2 Hz), 7.91 (s, 1H), 7.45 (m, 4H), 7.25 (m, 2H),
6.86 (t, 1H, J = 9.6 Hz), 6.68 (d, 1H, J = 8.0 Hz), 4.07 (s, 3H),
2.05 (s, 3H). 13C NMR (DMSO-d6, 100 MHz): δ 163.2, 163.0,
161.5, 160.7, 153.4, 153.2, 151.0, 147.5, 143.0, 140.1, 140.0,
138.0, 137.3, 134.5, 134.4, 134.1, 131.9, 130.1, 130.0, 127.4,
124.1, 121.8, 119.7, 117.0, 116.8, 116.7, 116.4, 116.1, 116.0,
(10) (a) Lebedev, A. Y.; Khartulyari, A. S.; Voskoboynikov, A. Z. J.
Org. Chem. 2005, 70, 596−602. (b) Pabba, C.; Wang, H.; Mulligan, S.
R.; Chen, Z.; Stark, T. M.; Gregg, B. T. Tetrahedron Lett. 2005, 46,
7553−7557. (c) Duncan, N. C.; Garner, C. M. Tetrahedron Lett. 2011,
52, 5214−5216. (d) Dong, C.; Xie, L.; Mou, X.; Zhong, Y.; Su, W. Org.
Biomol. Chem. 2010, 8, 4827−4830.
(11) (a) Shafir, A.; Buchwald, S. L. J. Am. Chem. Soc. 2006, 128,
8742−8743. (b) Corte, J. R.; Fang, T.; Decicco, C. P.; Pinto, D. J. P.;
509
dx.doi.org/10.1021/op400317z | Org. Process Res. Dev. 2014, 18, 501−510
