Molecules 2010, 15, 4423-4438; doi:10.3390/molecules15064423
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Synthesis of 2-(2-Aminopyrimidine)-2,2-difluoroethanols as
Potential Bioisosters of Salicylidene Acylhydrazides
Markus K. Dahlgren, Christopher T. Öberg, Erika A. Wallin, Pär G. Janson and
Mikael Elofsson *
Department of Chemistry, Umeå University, SE-90187 Umeå, Sweden
* Author to whom correspondence should be addressed; E-Mail: mikael.elofsson@chem.umu.se;
Tel.: +46-90-7869328.
Received: 19 May 2010; in revised form: 11 June 2010 / Accepted: 17 June 2010 /
Published: 21 June 2010
Abstract: Salicylidene acylhydrazides are inhibitors of type III secretion in several Gram-
negative pathogens. To further develop the salicylidene acylhydrazides, scaffold hopping
was applied to replace the core fragment of the compounds. The novel 2-(2-amino-
pyrimidine)-2,2-difluoroethanol scaffold was identified as a possible analog to the
salicylidene acylhydrazide core structure. The synthesis of a library of 2-(2-amino-
pyrimidine)-2,2-difluoro-ethanols is described in this paper.
Keywords: scaffold hopping; Reformatsky reaction; salicylidene acylhydrazide; type III
secretion
1. Introduction
Type III secretion (T3S) is a virulence system found in several clinically important Gram-negative
pathogens including Yersinia spp., Chlamydia spp., Shigella spp., Salmonella spp., Pseudomonas
aeruginosa, and enteropathogenic and enterohaemorrhagic Escherichia coli [1]. The bacteria use the
T3S machinery to secrete and translocate toxins into the cytoplasm of the eukaryotic target cell and
thereby create a niche that allows bacterial survival and growth. The T3S system is essential for the
bacteria to cause disease and compounds that inhibit T3S have the potential to be developed into novel
antibacterial agents [2,3]. Importantly, the T3S machinery can be inhibited without affecting growth
and this mode of action is distinct from clinically used antibiotics that all target bacterial growth.

Molecules 2010, 15
4424
Salicylidene acylhydrazides (Figure 1a) were identified in a screen for T3S inhibitors [4] and
subsequently it was shown that this compound class blocks T3S in Y. pseudotuberculosis, Shigella
flexneri, enterohaemorrhagic E. coli, Chlamydia spp., and Salmonella spp. [5-13]. While the
compounds are interesting as chemical probes to study T3S and clearly indicate a possibility to
develop novel antibacterial drugs, the salicylidene acylhydrazide core scaffold suffers from a number
of disadvantages. We have found that the salicylidene acylhydrazide T3S inhibitors generally display
limited solubility and modest potency. In addition, the scaffold suffers from poor patentability and
decomposes rapidly in slightly acidic environments. Salicylidene acylhydrazides have been included in
many commercially available screening libraries and as a result the compounds frequently appear in
publications and patents. Recently, a strategy based on statistical molecular design was used to
compute multivariate quantitative structure-activity relationship models for the salicylidene
acylhydrazides [14] and a desirable continuation is to further develop the compounds by modifying the
central scaffold. Compounds that mimic and replace the salicylidene acylhydrazide scaffold are of
importance since the compound class has delivered biologically active molecules in a number of
human and microbial systems as exemplified by several recent publications [15-26]. This paper
describes the synthesis of a library of 2-(2-aminopyrimidine)-2,2-difluoroethanols, identified from a
salicylidene acylhydrazide through scaffold hopping.
2. Results and Discussion
2.1. Scaffold Hopping from a Salicylidene Acylhydrazide
The global minimum conformation of a salicylidene acylhydrazide (Figure 1a) obtained with
Macromodel [27] was used as query scaffold in a scaffold hopping search using SHOP [28].
Figure 1. a) The query scaffold of a salicylidene acylhydrazide used for scaffold hopping;
b) The highest similarity ranked scaffold, identified in the scaffold hopping program; c)
The structure used for a substructure search in SciFinder.
NH2
N
NH2
N
O
OH
F
N
OH
F
N
O
H
N
b)
a)
c)
N
H
F
F
The conformation is planar with an intramolecular hydrogen bond between the phenolic proton and
the methylidine nitrogen (Figure 1a). Since the target of the salicylidene acylhydrazides has not been
identified, the search was performed at default settings (see Experimental section for details). The
reference database used contained 10,556 scaffolds and a total of 124,317 conformers. 2-(2-Amino-6-
phenylpyrimidin-4-yl)-2,2-difluoro-1-phenylethanol (4a, Figure 1b) was identified as the virtual
compound with highest similarity to the query scaffold. A SciFinder substructure search of 2-(2-
aminopyrimidin-4-yl)-2,2-difluoro-1-(methyl)ethanol (Figure 1c) (performed January 15, 2010) found

Molecules 2010, 15
4425
no records of compounds with this scaffold. Compound 4a and a number of analogs were thus targeted
for synthesis.
2.2. Synthesis of 2-(2-Amino-pyrimidine)-2,2-difluoro-ethanols
Retrosynthetic analysis identified alkynyl ketone 3 (Scheme 1) as a key intermediate, which upon
cyclization with guanidine would yield the target compound 4a following a published procedure [29].
The synthesis of enantiopure alkynyl ketone 3 had previously been described in the literature [30].
This synthetic approach would allow structural variation by selection of a set of benzaldehydes and
alkynyl lithium reagents.
Scheme 1. Synthesis of 2-(2-aminopyrimidine)-2,2-difluoroethanols.
OH
F
O
F
OH
O
O
O
F
II
I
OH
Br
R1
O
H
+
O
R1
R1
F
F
F
1a-d
1a) R1 = H (80%)
NH2
1b) R1 = m-OMe (59%)
1c) R1 = m-CF3 (80%)
1d) R1 = o-F (60%)
III or IV
V
5a-h
O
N
N
R2
R1
F
F
Li
VIII
NH2
N
OH
F
O
F
OH
F
O
R2
OH
F
N
VI
O
N
VII
R1
NH2
N
R2
R1
R2
F
R2 = Ph
n-propyl
R1
F
N
HO
OH
2a-d
2a) R1 = H (79%)
2b) R1 = m-OMe (68%)
2c) R1 = m-CF3 (75%)
2d) R1 = o-F (62%)
3 (43%)
4a-o
cyclopropyl
CH2NMe2
TMS
R2
R1
F
F
Reagents and Conditions: I) Et2Zn, MeCN, Wilkinson´s catalyst, r.t., 14 h (crude yields after
aqueous work-up); II) NaOH (1 M), CH2Cl2, r.t., 20 min; III) Oxalylchloride, DMF, CH2Cl2, then
MeNHOMe*HCl, TEA, r.t., 14 h; IV) PyBOP, DMF, TEA, then MeNHOMe*HCl, r.t., 14 h; V)
Me2AlCl, CH2Cl2, then MeNHOMe*HCl, r.t., 14 h; VI) THF, -78 ºC, 2 h; VII) guanidine
hydrochloride, base (Na2CO3 or K2CO3), MeCN, MWI, 120 ºC, 20 min; VIII) Dess-Martin
periodinane, CH2Cl2, r.t., 3 h.
A modified Reformatsky reaction of ethyl bromodifluoroacetate with benzaldehyde gave β-hydroxy
ester 1a in 80% crude yield, as described by Sato et al. [31]. The resulting crude β-hydroxy ester was
hydrolyzed to the corresponding carboxylic acid and subsequently converted into an acid chloride.
Using the acid chloride, the Weinreb amide 2a was synthesized in 79% yield. Using commercially
available lithiumphenylacetylide the Weinreb amide was alkynylated to give 3 in 43% yield following
a literature procedure [30]. We unsuccessfully attempted to reproduce the reported yield [30] by first
preparing the lithiumphenylacetylide from n-BuLi, then from freshly prepared LDA, and finally
increasing the amount of lithiumphenylacetylide. Using the protocol published by Tomkinson and co-
workers [29] 4a was obtained in 61% yield (Scheme 1).
Encouraged by the successful synthesis of 4a, a small library of analogs was targeted for synthesis.
Four different aldehydes were selected based on previous data obtained with salicylidene

Molecules 2010, 15
4426
acylhydrazides [5,14] and used to synthesize the crude products 1a-d. A fifth aldehyde, nicotinic
aldehyde, was also used as starting material but in our hands the Reformatzky reaction failed to
produce the target intermediate in acceptable yield. The acid chloride strategy used to prepare 2a
proved hard to reproduce. Using an alternative strategy 2a and 2c were synthesized from 1a and 1c
using the coupling reagent benzotriazol-1-yloxy)tripyrrolidinophosphonium hexafluorophosphate
(PyBOP) in 79% and 75% yield, respectively. The coupling reagent O-(7-azabenzotriazol-1-yl)-
N,N,N′,N′-tetramethyluronium hexafluorophosphate (HATU) was found to be as effective as PyBOP
(data not shown). These yields were reproducible but to avoid the two-step procedure of ester
hydrolysis and amide formation an alternative method using dimethylaluminum chloride to activate the
N,O-dimethylhydroxylamine, was used to prepare 2a, 2b, and 2d in 78%, 68%, and 62% yield,
respectively. The Weinreb amides 2a-d were purified by chromatography and isolated from the
corresponding aldehyde in 37–63% yield over two or three steps. Subsequently the Weinreb amides
2a-d were reacted with five different lithium acetylides (Scheme 1, Table 1).
Table 1. The final library of 2-(2-aminopyrimidine)-2,2-difluoroethanols.
ID
R1
R2
Yield†
4a
4b
4c
4d
4e
4f
H
Ph
26%
19%
11%
<1%
8%
H
n-Propyl
Cyclopropyl
CH2NME2
H
H
H
H
m-OMe
m-OMe
m-OMe
m-CF3
m-CF3
m-CF3
m-CF3
o-F
Ph
25%
12%
11%
42%
19%
24%
28%
9%
4g
4h
4i
n-Propyl
Cyclopropyl
Ph
4j
n-Propyl
Cyclopropyl
H
4k
4l
4m
4n
4o
Ph
o-F
n-Propyl
H
3%
o-F
12%
†Yield starting from Weinreb amides 2a-2d.
The products obtained using any lithiumacetylide other than lithiumphenylacetylide, rapidly
decomposed, even when stored dry in a freezer under a nitrogen atmosphere. Slight decomposition of
products was observed even for those products obtained using lithiumphenylacetylide. Therefore the
syntheses of compounds 4b-n (Scheme 1, Table 1) were all made from the crude products obtained
after alkynylation of 2a-d. For the final cyclization reaction with guanidine four different bases
(Li2CO3, Na2CO3, K2CO3, and Cs2CO3) were tested. There was no significant difference in yield when
Na2CO3 was exchanged with K2CO3. The cyclization reaction proceeded far slower when Li2CO3 was
used, while reactions performed with Cs2CO3 resulted in formation of several byproducts. Cyclization
with urea and thiourea, using the same conditions as for the guanidine cyclization, was attempted, but
the desired oxygen and sulfur analogs could not be obtained. To access additional analogs oxidation of

Molecules 2010, 15
4427
the secondary alcohol, using Dess-Martin periodinane, was performed for some of the compounds
(Scheme 1, Table 2). The resulting ketones were in equilibrium with the hydrates (Scheme 1) and
purification and characterization proved to be problematic.
The yields were generally low in the final step, starting from the Weinreb amides (<1%–42%). The
poor yields could be attributed to the instability of the alkynyl ketones and that the cyclization
reactions had to be performed using crude products. The resulting mixtures after the cyclization
reaction contained several impurities and generally required several purification steps, contributing to
the poor yields. All target compounds (4a-n) had a purity of at least 98% as determined by reversed
phase HPLC analysis and at least 95% as determined by 1H-NMR spectroscopy.
The final library of products (4a-o) was tested in a T3S-linked luciferase reporter gene assay in Y.
pseudotuberculosis, essentially as described previously [4]. Only two compounds (4e and 4o) showed
effect on the luciferase light emission with 40% inhibition at 1 mM and bacterial growth experiments
using Y. pseudotuberculosis showed that 4e and 4o did not inhibit growth at this concentration.
Table 2. The final library of ketones 5a-h.
ID
R1
R2
Yield†
5a
5b
5c
5d
5e
5f
H
Ph
98%
73%
68%
27%
54%
55%
38%
66%
H
n-Propyl
Cyclopropyl
H
H
H
m-CF3
m-CF3
m-CF3
m-CF3
Ph
n-Propyl
Cyclopropyl
H
5g
5h
†Yield starting from the target compounds 4a-c, 4e and 4i-l.
3. Experimental
3.1. General
Mass-spectra were recorded with an electrospray Waters Micromass ZG 2000 instrument using an
XTerra® MS C18, 5 μm particles, 4.6 × 50 mm column and an H2O/acetonitrile/0.2% formic acid
eluent system. Preparative reversed-phase HPLC was performed on a Beckman System Gold HPLC
with a Supelco Discovery BIO Wide Pore C18, 5 μm particles, 21.2 × 250 mm column, using an
H2O/acetonitrile eluent system with or without 0.1% trifluoroacetic acid and a flow rate of
10 mL min-1 and detection at 254 nm. Microwave heated reactions were performed in EmrysTM
process vials using a SmithCreatorTM microwave instrument from Biotage. HRMS analysis was
performed using a Waters Micromass GCT with an electron impact ion source (EI+), direct inlet
(20-400 deg.) or a Bruker microTOF with an ESI ion source in positive mode. 1H-NMR and 13C-NMR
spectra were recorded with Bruker DRX-400 (1H-NMR: 400 MHz; 13C-NMR: 100 MHz) or DRX-500
(1H-NMR: 500 MHz; 13C-NMR: 126 MHz) spectrometers. NMR experiments were conducted at
298 K in (CD3)2CO (residual solvent peak = 2.05 ppm (δH) and 29.84 ppm (δC)), MeOD (residual
solvent peak = 3.31 ppm (δH) and 49.00 ppm (δC)), or CDCl3 [residual solvent peak = 7.26 ppm (δH)

Molecules 2010, 15
4428
and 77.16 ppm (δC)]. Peak assignments could be established from complementary HMBC, HSQC and
COSY experiments. The secondary alcohol proton in the compounds 2a-d and 4a-o, and the amino
group protons of compounds 4a-o, and 5a-h could not be identified in many cases due to exchange
broadening with the solvent. Equilibrium between the ketones and their respective hydrates (5a-h)
13
were observed and while the mixtures were pure according to HPLC analysis, interpretable C-NMR
spectra could not be obtained. Therefore only 1H-NMR data are given for these compounds (5a-h). 1H-
13
NMR, C-NMR, are given for all other compounds, except 4d, that could not be fully characterized
due to lack of material. Low resolution electrospray ionization mass spectrometry (ESIMS) data are
given for compounds 4a-n and 5a-h. High resolution mass spectrometry (HRMS) data is given for 4o
and the Weinreb amides 2b-d, which did not ionize using the ESIMS instrument.
3.2. Scaffold Hopping
Conformational analysis of the salicylidene acylhydrazide was performed using the Macromodel
program [27]. Scaffold hopping using the program SHOP [28] at default settings was performed using
the global minimum conformation of the salicylidene acylhydrazide as query scaffold. The reference
database used was previously built using Maybridge´s building block collection from 2006 and using
the virtual reaction manager as described in SHOP [32]. The virtual reaction utility program in SHOP
assembles new core structures from fragments of building blocks [32]. The new compounds are
expected to be synthetically accessible in five or less steps. The reference database used contained
10,556 scaffolds and a total of 124,317 conformers.
3.3. Synthesis
3.3.1. General procedure for the synthesis of Reformatsky adducts 1a-d
Wilkinson’s catalyst (0.01 equivalents) was stirred in MeCN (20 mL) under N2 atmosphere in an ice
bath for 5 min. Ethyl bromodifluoroacetate (1.2 equivalents) and benzaldehyde (8–25 mmol,
1 equivalents) was added and the mixture was stirred for 5 min. Et2Zn (1M, hexanes, 1.2 equivalents)
was added in portions over 5 min and the reaction mixture was stirred overnight at r.t. The reaction
mixture was quenched with excess HCl (1 M) and the organic solvents were evaporated under reduced
pressure. The residue was dissolved in EtOAc and washed with HCl (1 M), NaHSO3 (aq, sat.), and
NaHCO3 (aq, sat.). The organic phase was dried with anhydrous MgSO4, filtered, and concentrated.
The NMR spectrum of the crude product confirmed that the desired β-hydroxy ester had been obtained.
The crude β-hydroxy ester was used directly in the next step.
3.3.2. Synthesis of Weinreb amide 2a via acid chloride formation in situ
NaOH (1 M, 40 mL) was added to a separation funnel containing the crude β-hydroxy ester 1a
(1.5 g, 6.5 mmol) in CH2Cl2 (10 mL), and the funnel was vigorously shaken for 10 min. The water
phase was acidified with HCl (1 M) and extracted with EtOAc. The organic phase was dried with
anhydrous MgSO4, filtered, and concentrated. Most of the resulting crude acid (1.06 g, 5.24 mmol)
was transferred to a round-bottom flask and CH2Cl2 (15 mL) was added. Under stirring in an ice-bath,
oxalyl chloride (0.52 mL, 5.96 mmol) and a few drops of DMF was added. After 30 min, pyridine

Molecules 2010, 15
4429
(1.9 mL, 23.5 mmol) and N,O-dimethylhydroxylamine hydrochloride (0.62 g, 6.36 mmol) was added,
and the reaction was stirred at r.t. overnight under a N2 atmosphere. The reaction mixture was diluted
with EtOAc, washed with HCl (1 M), and NaHCO3 (aq, sat.). The aq. phases were extracted with
EtOAc separately. The combined organic phases were dried with anhydrous MgSO4, filtered, and
concentrated. The resulting oil was purified by column chromatography (heptane:EtOAc 3:1) to give
Weinreb amide 2a in 79% yield (1.02 g).
3.3.3. Typical procedure for the synthesis of Weinreb amides 2a and 2c, using PyBOP, exemplified by
the synthesis of 2c
NaOH (2 M, 50 mL) was added to a stirred solution of β-hydroxy ester 1c (4.38 g, 14.7 mmol) in
EtOH (100 mL) at r.t. After 1.5 h, the mixture was acidified using excess HCl (1 M) and the solution
was extracted with EtOAc. The organic phase was dried using anhydrous MgSO4, filtered, and
concentrated. The crude oil was co-evaporated with toluene and stored in vacuo before the resulting
crude acid was used directly in the next reaction. To the crude acid, N,O-dimethylhydroxylamine
hydrochloride (1.72 g, 17.6 mmol), PyBOP (9.17 g, 17.6 mmol), and pyridine (3.55 mL, 44 mmol)
were added, and the mixture was stirred in DMF (70 mL) at r.t. over night. The reaction mixture was
diluted with EtOAc and washed with HCl (1 M) and NaHCO3 (aq. sat.). The aq. phases were extracted
with EtOAc separately. The pooled organic phases were dried using anhydrous MgSO4, filtered, and
concentrated. The crude product was purified using column chromatography (heptane:EtOAc 1:1) to
give Weinreb amide 2c in 75% yield over two steps (4.58 g).
3.3.4. Typical procedure for the synthesis of Weinreb amides 2a, 2b, and 2d, using dimethyl
aluminium chloride, exemplified with the synthesis of 2d
To a solution of N,O-dimethylhydroxylamine hydrochloride (1.8 g, 18.5 mmol) in CH2Cl2 at -78 ºC
under N2 atmosphere, dimethyl aluminium chloride (22 mL, 0.9 M, heptane) was added and the
mixture was stirred for 1 h. Crude β-hydroxy ester 1d (1.41 g, 5.69 mmol) was added and the mixture
was stirred at -78 ºC for 30 min. The reaction mixture was then stirred at r.t. for 5.5 h at which time the
β-hydroxy ester had been completely consumed according to TLC analysis. The reaction mixture was
quenched with excess HCl (1 M) and diluted with EtOAc. The mixture was filtered through celite,
washed with HCl (1 M), NaHCO3 (aq, sat.), and extracted with EtOAc. The organic phase was dried
with anhydrous MgSO4, filtered, and concentrated. The crude product was purified using column
chromatography (heptane:EtOAc 4:1 -> 2:1) to give Weinreb amide 2d in 62% yield (0.927 g).
2,2-Difluoro-3-hydroxy-N-methoxy-N-methyl-3-phenyl-propionamide (2a). NMR data was in
accordance with the data given in the literature [30].
1
2,2-Difluoro-3-hydroxy-N-methoxy-3-(3-methoxyphenyl)-N-methylpropionamide (2b). H-NMR (400
MHz; acetone-d6): δ 7.30–7.24 (m, 1H), 7.07 (s, 1H), 7.03 (d, J = 7.6 Hz, 1H), 6.90 (bd,
J = 8.5 Hz, 1H), 5.43-5.33 (m, 1H), 5.23 (d, J = 5.3 Hz, 1H), 3.81 (s, 3H), 3.80 (s, 3H), 3.24 (s, 3H);
13C-NMR (126 MHz; acetone-d6): δ 163.6, 160.5, 139.3 (d, 3J(C,F) = 2.7 Hz), 129.8, 121.1, 116.9 (dd,

Molecules 2010, 15
4430
1J(C,F) = 258.9 Hz, 1J(C,F) = 253.9 Hz), 114.7, 114.5, 73.7 (dd, 2J(C,F) = 26.5 Hz, 2J(C,F) = 23.0 Hz),
62.3, 55.5, 33.7; ESI-HRMS [M+Na+]+ calcd. for [C12H15F2NNaO4]+: m/z: 298.0861; found: 298.0861.
2,2-Difluoro-3-hydroxy-N-methoxy-N-methyl-3-(3-trifluoromethylphenyl)-propionamide (2c). The
1
alcohol proton was exchange broadened. H-NMR (500 MHz; acetone-d6): δ 7.84 (s, 1H), 7.78 (d,
J = 7.6 Hz, 1H), 7.71 (d, J = 7.7 Hz, 1H), 7.63 (t, J = 7.7 Hz, 1H), 5.59 (dd, J = 17.2, J = 7.6 Hz, 1H),
3.82 (s, 3H), 3.26 (s, 3H); 13C-NMR (126 MHz; acetone-d6): δ 163.1 (bs), 139.1, 132.8, 130.7 (q,
3
3
2J(C,F) = 32.0 Hz), 129.8, 126.0 (q, J(C,F) = 3.7 Hz), 125.4 (q, J(C,F) = 3.6 Hz), 125.3 (q,
1J(C,F) = 271.2 Hz), 116.6 (dd, 1J(C,F) = 259.1 Hz, 1J(C,F) = 254.7 Hz), 73.0 (dd, 2J(C,F) = 27.1 Hz,
2J(C,F) = 23.7 Hz), 62.4, 33.4; ESI-HRMS [M+Na+]+ calcd. for [C12H12F5NNaO3]+: m/z: 336.0630;
found: 336.0630.
2,2-Difluoro-3-(2-fluorophenyl)-3-hydroxy-N-methoxy-N-methylpropionamide
(2d).
1H-NMR
(400 MHz, CDCl3): δ 7.70–7.55 (m, 1H), 7.40–7.28 (m, 1H), 7.24–7.13 (m, 1H), 7.10–6.99 (m, 1H),
5.71 (bd, J = 19.4 Hz, 1H), 3.84 (bs, 1H), 3.75 (s, 3H), 3.26 (s, 3H); 13C-NMR (126 MHz; acetone-d6):
δ163.3, 161.3 (d, 1J(C,F) = 245.8 Hz), 131.1 (d, 3*J(C,F) = 8.5 Hz), 130.9 (d, 3*J(C,F) = 3.8 Hz), 125.0
(d, 4*J(C,F) = 3.8 Hz), 125.0–124.8 (m, 1C) 116.6 (dd, 1J(C,F) = 259.1 Hz, 1J(C,F) = 254.4 Hz), 115.6
(d, 2J(C,F) = 22.6 Hz), 67.1-66.4 (m, 1C), 62.4, 33.6; ESI-HRMS [M+Na+]+ calcd. for
[C11H12F3NNaO3]+: m/z: 286.0661; found: 286.0662. *Tentative assignment.
3.3.5. Typical procedure for the synthesis of pyrimidines 4a-o, exemplified by the synthesis of 4j
n-BuLi (1.6 M, 3.0 mL, 4.8 mmol) was added dropwise to a stirred solution of diisopropylamine
(0.78 mL, 5.6 mmol) in THF at −78 ºC under a stream of N2. After 30 min, 1-pentyne (435 mg,
6.39 mmol) was added dropwise. After 1.5 h, a solution of Weinreb amide 2c (500 mg, 1.60 mmol) in
THF (5 mL) was added dropwise at −78 ºC. The reaction was quenched with NH4Cl (aq, sat., 5 mL)
followed by addition of excess NaHCO3 (aq, sat.). The THF was removed under reduced pressure. The
remaining aqueous mixture was extracted with EtOAc and the organic phase was subsequently washed
with brine, dried with MgSO4, filtered, and concentrated. The resulting crude alkynyl ketone was
heated using microwave irradiation (120 ºC, 20 + 30 min) with guanidine hydrochloride (457 mg,
4.78 mmol) and Na2CO3 (677 mg, 6.39 mmol) in MeCN (15 mL). The reaction was filtered and
purified by column chromatography (heptane:EtOAc 2:1 -> 1:1) to give pyrimidine 4j in 19% yield
(110 mg) over two steps.
4,4-Difluoro-5-hydroxy-1,5-diphenylpent-1-yn-3-one (3). NMR data was in accordance with the data
given in the literature [30].
1
2-(2-Amino-6-phenylpyrimidin-4-yl)-2,2-difluoro-1-phenylethanol (4a). H-NMR (400 MHz, MeOD):
δ 8.17–8.08 (m, 2H), 7.57–7.45 (m, 5H), 7.40–7.28 (m, 4H), 6.49 (s, 2H), 5.49–5.33 (m, 2H); 13C
2
2
NMR (100 MHz, CDCl3): δ 167.1, 164.7, 164.5 (dd, J(C,F) = 30.7 Hz, J(C,F) = 26.7 Hz), 138.3,
1
1
137.8, 131.8, 129.6, 129.1, 129.0, 128.6, 127.9, 119.1 (dd, J(C,F) = 250.4 Hz, J(C,F) = 246.1 Hz),
103.4 (t, 3J(C,F) = 4.6 Hz), 74.5 (t, 2J(C,F) = 26.8 Hz); ESIMS m/z calcd. [M+H+]+: 328; found: 328.

Molecules 2010, 15
4431
2-(2-Amino-6-propylpyrimidin-4-yl)-2,2-difluoro-1-phenylethanol (4b). The alcohol and amine protons
1
were exchange broadened. H-NMR (500 MHz; acetone-d6): δ7.48–7.44 (m, 2H), 7.39–7.32 (m, 3H),
6.90 (s, 1H), 5.34 (dd, J = 17.5, 7.3 Hz, 1H), 2.77–2.68 (m, 2H), 1.74 (app. sextet, J = 7.5 Hz, 2H),
13
2
0.94 (t, J = 7.4 Hz, 3H); C-NMR (126 MHz; acetone-d6): δ 170.6, 167.2 (dd, J(C,F) = 31.3 Hz,
2J(C,F) = 27.9 Hz), 161.1, 137.7, 129.3, 129.0, 128.8, 118.8 (dd, 1J(C,F) = 251.2 Hz,
1J(C,F) = 247.3 Hz), 107.1 (t, 3J(C,F) = 4.2 Hz), 74.4 (dd, 2J(C,F) = 29.4 Hz, 2J(C,F) = 24.5 Hz), 37.6,
22.4, 13.7; ESIMS m/z calcd. [M+H+]+: 294; found: 295.
2-(2-Amino-6-cyclopropylpyrimidin-4-yl)-2,2-difluoro-1-phenylethanol (4c). The alcohol and amine
1
protons were exchange broadened. H-NMR (500 MHz; acetone-d6): δ 7.50–7.46 (m, 2H, PhH),
7.39–7.31 (m, 3H, PhH), 6.74 (s, 1H, pyrimidine-CH), 5.35 (dd, J = 18.1, 6.6 Hz, 1H, benzylic CH),
2.23–2.16 (m, 1H, cyclopropyl-CH), 1.34–1.27 (m, 2H, cyclopropyl-CH2), 1.26-1.16 (m, 2H, cyclo-
propyl-CH2); 13C-NMR (126 MHz; acetone-d6): δ 174.4, 164.8 (dd, 2J(C,F) = 31.9 Hz,
2J(C,F) = 26.9 Hz), 160.2, 137.6, 129.3, 129.0, 128.8, 118.6 (dd, 1J(C,F)= 251.8 Hz,
2
2
1J(C,F)= 247.4 Hz), 104.1 (bs), 74.3 (dd, J(C,F)= 29.7, J(C,F)= 24.3 Hz), 16.4, 13.1, 13.0; ESIMS
m/z calcd. [M+H+]+: 292; found: 292.
2-(2-Amino-6-dimethylaminomethylpyrimidin-4-yl)-2,2-difluoro-1-phenylethanol (4d). The alcohol
and amine protons were exchange broadened. 1H-NMR (500 MHz; acetone-d6): δ 7.46 (d, J = 7.1 Hz,
2H, PhH), 7.37–7.29 (m, 3H, PhH), 6.96 (s, 1H, pyrimidine-CH), 5.33 (dd, J = 18.0, 7.2 Hz, 1H,
benzylic CH), 4.37 (s, 2H, N-CH2), 2.99 (s, 6H, N-CH3); ESIMS m/z calcd. [M+H+]+: 309; found: 309.
2-(2-Aminopyrimidin-4-yl)-2,2-difluoro-1-phenylethanol (4e). The alcohol and amine protons were
exchange broadened. 1H-NMR (500 MHz; acetone-d6): δ 8.44 (d, J = 5.3 Hz, 1H), 7.46 (d, J = 7.1 Hz,
2H), 7.38-7.30 (m, 3H), 6.90 (d, J = 5.3 Hz, 1H), 5.36 (dd, J = 17.6, 7.3 Hz, 1H);13C-NMR (126 MHz;
acetone-d6): δ 165.4–165.0 (m, 1C), 163.0, 158.4, 138.0, 129.1, 129.1, 128.7, 118.8 (dd,
1
3
2
1J(C,F) = 250.6 Hz, J(C,F) = 246.3 Hz), 107.8 (t, J(C,F) = 4.1 Hz), 74.4 (dd, J(C,F) = 29.5,
2J(C,F) = 24.4 Hz); ESIMS m/z calcd. [M+H+]+: 252; found: 252.
2-(2-Amino-6-phenylpyrimidin-4-yl)-2,2-difluoro-1-(3-methoxyphenyl)ethanol (4f). The amine and
1
alcohol protons were exchange broadened. H-NMR (500 MHz; acetone-d6): δ 8.12 (bd, J = 6.6 Hz,
2H), 7.56-7.48 (m, 3H), 7.30 (s, 1H), 7.28-7.21 (m, 1H), 7.09-7.02 (m, 2H), 6.90-6.84 (m, 1H),
5.43–5.35 (m, 1H), 3.77 (s, 3H); 13C-NMR (126 MHz; acetone-d6): δ 167.2, 164.6, 164.5 (dd,
3
2J(C,F) = 30.2 Hz, 2J(C,F) = 26.6 Hz), 160.4, 139.8 (d, J(C,F) = 1.8 Hz), 137.8, 131.9, 129.6, 129.6,
1
1
128.0, 121.4, 119.1 (dd, J(C,F) = 250.1 Hz, J(C,F) = 246.7 Hz), 114.7, 114.5, 103.5 (t,
3J(C,F) = 4.5 Hz), 74.5 (dd, 2J(C,F) = 29.3 Hz, 2J(C,F) = 24.7 Hz), 55.5; ESIMS m/z calcd. [M+H+]+:
358; found: 358
2-(2-Amino-6-propylpyrimidin-4-yl)-2,2-difluoro-1-(3-methoxyphenyl)ethanol (4g). The amine and
alcohol protons were exchange broadened. 1H-NMR (400 MHz; acetone-d6): δ 7.27 (t, J = 7.9 Hz, 1H),
7.06–6.99 (m, 2H), 6.95 (s, 1H), 6.91 (ddd, J = 8.3 Hz, J = 5.6 Hz, J = 0.9 Hz, 1H), 5.31 (dd,
J = 17.3 Hz, J = 7.4 Hz, 1H), 3.79 (s, 3H), 2.83-2.73 (m, 2H), 1.81-1.69 (m, 2H), 0.95 (t, J = 7.3 Hz,

Molecules 2010, 15
4432
13
2
2
3H); C NMR (126 MHz; acetone-d6): δ 169.9, 167.9 (dd, J(C,F) = 31.6 Hz, J(C,F) = 26.8 Hz),
160.5, 160.4, 139.0 (d, 3J(C,F) = 1.8 Hz), 129.8, 121.3, 118.7 (dd, 1J(C,F) = 251.3 Hz, 1J(C,F) = 247.8 Hz),
3
3
2
114.7, 114.6, 107.1 (dd, J(C,F) = 4.9 Hz, J(C,F) = 3.2 Hz), 74.4 (dd, J(C,F) = 29.4 Hz,
2J(C,F) = 24.7 Hz), 55.5, 37.0, 22.5, 13.7;ESIMS m/z calcd. [M+H+]+: 324; found: 324
1
2-(2-Amino-6-cyclopropyl-pyrimidin-4-yl)-2,2-difluoro-1-(3-methoxy-phenyl)-ethanol (4h). H-NMR
(400 MHz; acetone-d6): δ 7.24 (t, J = 7.5 Hz, 1H, PhH), 7.06–6.99 (m, 2H, PhH), 6.91–6.83 (m, 1H,
PhH), 6.72 (s, 1H, pyridimidine-CH), 6.21 (s, 2H, NH2), 5.46–5.40 (m, 1H, OH), 5.38–5.28 (m, 1H,
benzylic-CH), 3.77 (s, 3H, methoxy-CH3), 1.99–1.89 (m, 1H, cyclopropyl-CH), 1.04–0.92 (m, 4H,
cyclopropyl-CH2); 13C NMR (126 MHz; acetone-d6; for C atom numbering used see Figure 2) δ 174.8
2
2
(C5), 164.1 (C3, dd, J(C,F) = 31.4 Hz, J(C,F) = 26.8 Hz), 161.5 (C6), 160.4 (C9), 139.3 (C7, d,
3J(C,F) = 1.8 Hz), 129.7 (C11), 121.3 (C10*), 118.7 (C2, dd, 1J(C,F) = 251.4 Hz, 1J(C,F) = 247.1 Hz),
3
2
114.7 (C8*), 114.6 (C12*), 104.6 (C4, t, J(C,F) = 4.4 Hz), 74.3 (C1, dd, J(C,F) = 29.4 Hz,
2J(C,F) = 24.0 Hz), 55.5 (C13), 16.7 (C14), 12.4 (C15*), 12.3 (C16*); ESIMS m/z calcd. [M+H+]+: m/z:
322; found: 322. *Tentative assignment.
Figure 2. Numbering of carbon atoms of compound 4h, used for assignment of 13C-NMR peaks.
NH2
6
OH
N
N
8
1
2
O
9
7
14
16
5
3
13
4
F
F
12
10
15
11
2-(2-Amino-6-phenylpyrimidin-4-yl)-2,2-difluoro-1-(3-trifluoromethylphenyl)ethanol (4i). The alcohol
1
and amine protons were exchange broadened. H-NMR (500 MHz; acetone-d6): δ 8.17–8.12 (m, 2H),
7.86 (s, 1H), 7.79 (d, J = 7.6 Hz, 1H), 7.69 (d, J = 7.8 Hz, 1H), 7.62 (t, J = 7.7 Hz, 1H), 7.55–7.49 (m,
13
3H), 7.35 (s, 1H), 5.58 (dd, J = 17.8, 6.5 Hz, 1H); C-NMR (126 MHz; acetone-d6): δ 167.4, 164.7,
2
2
3
164.0 (dd, J(C,F) = 30.6 Hz, J(C,F) = 26.3 Hz), 139.7 (d, J(C,F) = 1.2 Hz), 137.7, 133.0, 131.9,
2
3
130.5 (q, J(C,F) = 31.9 Hz), 129.6, 129.6, 128.0, 125.8 (q, J(C,F) = 3.7 Hz), 125.7 (q,
3J(C,F) = 3.8 Hz), 125.4 (q, J(C,F) = 271.6 Hz),119.0 (dd, J(C,F) = 250.6 Hz, J(C,F) = 246.1 Hz),
1
1
1
3
2
2
103.4 (t, J(C,F) = 4.4 Hz), 73.8 (dd, J(C,F) = 30.0 Hz, J(C,F) = 24.4 Hz); ESIMS m/z calcd.
[M+H+]+: 396; found: 396.
2-(2-Amino-6-propylpyrimidin-4-yl)-2,2-difluoro-1-(3-trifluoromethylphenyl)ethanol (4j). The alcohol
and amine protons were exchange broadened. 1H-NMR (500 MHz; acetone-d6): δ 7.80 (s, 1H), 7.75 (d,
J = 7.4 Hz, 1H), 7.69 (d, J = 7.5 Hz, 1H), 7.61 (t, J = 7.6 Hz, 1H), 6.78 (s, 1H), 5.50 (dd,
J = 17.3, 6.8 Hz, 1H), 2.62 (t, J = 7.6 Hz, 2H), 1.74-1.65 (m, 2H), 0.92 (t, J = 7.3 Hz, 3H).13C-NMR
(126 MHz; acetone-d6): δ 173.3, 164.0 (dd, 2J(C,F) = 30.6 Hz, 2J(C,F) = 26.7 Hz), 163.3, 139.5, 133.0,
130.6 (q, 2J(C,F) = 32.0 Hz), 129.7, 125.9 (q, 1J(C,F) = 3.7 Hz), 125.6 (q, 3J(C,F) = 3.8 Hz), 125.4 (q,
1
1
3
1J(C,F) = 271.3 Hz), 118.8 (dd, J(C,F) = 250.4 Hz, J(C,F) = 246.4 Hz), 106.8 (t, J(C,F) = 4.2 Hz),

Molecules 2010, 15
4433
2
2
73.8 (dd, J(C,F) = 29.7 Hz, J(C,F) = 24.5 Hz), 39.4, 22.4, 13.9.ESIMS m/z calcd. [M+H+]+: 362;
found: 362.
2-(2-Amino-6-cyclopropylpyrimidin-4-yl)-2,2-difluoro-1-(3-trifluoromethylphenyl)ethanol (4k). The
alcohol and amine protons were exchange broadened. 1H-NMR (500 MHz; acetone-d6): δ 7.82 (s, 1H),
7.76 (d, J = 7.6 Hz, 1H), 7.70 (d, J = 7.8 Hz, 1H), 7.62 (t, J = 7.7 Hz, 1H), 6.78 (s, 1H), 5.51 (dd,
J = 18.0, 6.2 Hz, 1H), 2.10-2.06 (m, 1H), 1.16-1.07 (m, 4H); 13C-NMR (126 MHz; acetone-d6): δ
2
175.4, 163.2-162.6 (m, 2C), 139.5, 133.0, 130.7 (q, J(C,F) = 31.9 Hz), 129.7, 125.9 (q,
3
1
3J(C,F) = 3.7 Hz), 125.7 (q, J(C,F) = 3.6 Hz), 125.4 (q, J(C,F) = 271.3 Hz), 118.6 (dd,
1J(C,F) = 251.0 Hz, 1J(C,F) = 246.5 Hz), 105.1, 73.7 (dd, 2J(C,F) = 30.0 Hz, 2J(C,F) = 24.4 Hz), 17.1,
11.8; ESIMS m/z calcd. [M+H+]+: 360; found: 360.
2-(2-Aminopyrimidin-4-yl)-2,2-difluoro-1-(3-trifluoromethylphenyl)ethanol (4l). The alcohol and
amine protons were exchange broadened. 1H-NMR (400 MHz; acetone-d6): δ 8.50 (d, J = 5.4 Hz, 1H),
7.82 (s, 1H), 7.76 (d, J = 7.6 Hz, 1H), 7.71 (d, J = 7.8 Hz, 1H), 7.62 (t, J = 7.7 Hz, 1H), 6.98 (d,
J = 5.3 Hz, 1H), 5.52 (dd, J = 17.8, 6.5 Hz, 1H); 13C-NMR (100 MHz; acetone-d6): δ 165.5 (dd,
2
3
2J(C,F) = 32.0 Hz, J(C,F) = 26.8 Hz), 162.4, 157.6, 139.3 (d, J(C,F) = 1.5 Hz), 133.0, 130.6 (q,
2J(C,F) = 32.1 Hz), 129.7, 126.0 (q, J(C,F) = 3.8 Hz), 125.6 (q, J(C,F) = 3.7 Hz), 125.3 (q,
3
3
1J(C,F) = 271.2), 118.6 (dd, J(C,F) = 251.1 Hz, J(C,F) = 246.6 Hz), 107.8 (dd, J(C,F) = 5.3 Hz;
1
1
3
3J(C,F) = 3.4 Hz), 73.6 (dd, J(C,F) = 30.0 Hz, J(C,F) = 24.3 Hz); ESIMS m/z calcd. [M+H+]+: 320;
2
2
found: 320.
2-(2-Amino-6-phenylpyrimidin-4-yl)-2,2-difluoro-1-(2-fluorophenyl)ethanol (4m). The amine and
1
alcohol protons were exchange broadened. H-NMR (400 MHz; acetone-d6): δ 8.18–8.11 (m, 2H),
7.77–7.71 (m, 1H), 7.55–7.48 (m, 3H), 7.43–7.35 (m, 2H), 7.29–7.23 (m, 1H), 7.15–7.09 (m, 1H), 5.82
(dd, J = 19.5 Hz, J = 4.5 Hz, 1H); 13C-NMR (126 MHz; acetone-d6): δ 167.2, 164.9, 164.2 (ddd,
2
3
1
2J(C,F) = 31.6 Hz, J(C,F) = 25.3 Hz, J(C,F) = 1.9 Hz), 161.5 (d, J(C,F) = 245.4 Hz), 137.9 (d,
3J(C,F) = 1.8 Hz), 131.8 (d, 3J(C,F) = 1.8 Hz), 131.0 (d, 3J(C,F) = 1.8 Hz), 131.0 (d, 3J(C,F) = 1.8 Hz),
129.6 (d, 3J(C,F) = 1.8 Hz), 128.0 (d, 3J(C,F) = 1.8 Hz), 125.5 (d, 2J(C,F) = 13.5 Hz), 124.9, 119.1 (t,
1J(C,F) = 248.7 Hz), 115.6 (dd, J(C,F) = 22.6 Hz, J(C,F) = 1.8 Hz), 103.4, 67.5 (dd,
2J(C,F) = 32.8 Hz, 2J(C,F) = 23.7 Hz); ESIMS m/z calcd. [M+H+]+: m/z: 346; found: 346
2
3
2-(2-Amino-6-propylpyrimidin-4-yl)-2,2-difluoro-1-(2-fluorophenyl)ethanol (4n). The alcohol proton
was exchange broadened. 1H-NMR (400 MHz; acetone-d6): δ 7.70 (bt, J = 7.4 Hz, 1H), 7.43–7.36 (m,
1H), 7.24 (td, J = 7.5 Hz, J = 1.0 Hz, 1H), 7.11 (ddd, J = 10.5 Hz, J = 8.3 Hz, J = 1.1 Hz, 1H), 6.76 (s,
1H), 6.53 (bs, 2H), 5.75 (dd, J = 19.1 Hz, J = 4.8 Hz, 1H), 2.62–2.57 (m, 2H), 1.70 (h, J = 7.5 Hz, 2H),
0.93 (t, J = 7.4 Hz, 3H); 13C-NMR (126 MHz; acetone-d6): δ 174.3, 164.5, 163.0 (dd,
2J(C,F) = 31.6 Hz, 2J(C,F) = 26.1 Hz), 161.4 (dd, 1J(C,F) = 245.8 Hz, 3J(C,F) = 2.7 Hz) 130.9, 131.0,
2
3
1
125.5 (d, J(C,F) = 13.5 Hz), 124.9 (t, J(C,F) = 2.7 Hz), 119.0 (t, J(C,F) = 248.2 Hz), 115.6 (dd,
2J(C,F) = 22.7 Hz, J(C,F) 2 Hz), 106.6 (t, J(C,F) = 2.7 Hz), 67.4 (t, J(C,F) = 28.3 Hz), 40.4, 22.4,
14.0; ESIMS m/z calcd. [M+H+]+: m/z: 312; found: 312
3
3
2

Molecules 2010, 15
4434
1
2-(2-Aminopyrimidin-4-yl)-2,2-difluoro-1-(2-fluorophenyl)ethanol (4o). H-NMR (400 MHz; acetone-
d6): δ 8.42 (d, J = 4.9 Hz, 1H), 7.72 (t, J = 7.4 Hz, 1H), 7.44–7.34 (m, 1H), 7.25 (t, J = 7.4 Hz, 1H),
7.16–7.06 (m, 1H), 6.85 (d, J = 4.9 Hz, 1H), 6.47 (s, 2H), 5.79 (bd, J = 19.6 Hz, 1H), 5.50 (s, 1H); 13C-
NMR (100 MHz; acetone-d6): δ 164.7-164.5 (m, 1C), 163.1 (dd, 2J(C,F) = 32.6 Hz,
2J(C,F) = 25.7 Hz), 161.3 (d, 1J(C,F) = 245.7 Hz), 160.8, 131.0 (d, 3J(C,F) = 8.6 Hz), 130.9–130.8 (m,
1C), 125.4 (bd, 2J(C,F) = 13.7 Hz), 124.9 (d, 3J(C,F) = 3.5 Hz), 118.9 (dd, 1J(C,F) = 250.0 Hz, 1J(C,F)
= 245.4 Hz), 115.6 (d, 2J(C,F) = 22.3 Hz), 107.7-107.6 (m, 1C), 67.6-66.9 (m, 1C); EI-HRMS [M+H]+
calcd. for [C12H10N3OF3]: m/z: 269.0776; found: 269.0773
3.3.6. Typical procedure for the synthesis of ketones 5a-h, exemplified by the synthesis of 5f
To a stirred solution of 2-amino pyrimidine 4j in CH2Cl2 (1 mL), Dess-Martin periodinane (47 mg,
110 μmol) was added at r.t. After 3 h, the reaction was concentrated and purified by column
chromatography (heptane:EtOAc 4:1 -> 2:1) followed by preparative HPLC to give ketone 5f in 55%
yield (11 mg).
2-(2-Amino-6-phenylpyrimidin-4-yl)-2,2-difluoro-1-phenylethanone (5a). 1H-NMR (400 MHz;
acetone-d6): δ 8.25–8.21 (m, 2H), 8.06–8.03 (m, 2H), 7.71–7.66 (m, 2H), 7.57–7.51 (m, 5H); ESIMS
m/z calcd. [M+H+]+: 326; found: 326.
2-(2-Amino-6-propylpyrimidin-4-yl)-2,2-difluoro-1-phenylethanone (5b). 1H-NMR (500 MHz;
acetone-d6): δ 8.00 (d, J = 7.5 Hz, 2H), 7.69 (tt, J = 7.5, 1.2 Hz, 1H), 7.53 (br t, J = 8.0 Hz, 2H), 7.06 (s,
1H), 2.67 (t, J = 7.6 Hz, 2H), 1.79-1.71 (m, 2H), 0.96 (td, J = 7.4, 0.7 Hz, 3H); ESIMS m/z calcd.
[M+H+]+: 292; found: 292.
1
2-(2-Amino-6-cyclopropylpyrimidin-4-yl)-2,2-difluoro-1-phenylethanone (5c). H-NMR (500 MHz;
acetone-d6): δ 8.01 (d, J = 7.7 Hz, 2H), 7.68 (t, J = 7.4 Hz, 1H), 7.53 (t, J = 7.9 Hz, 2H), 7.07 (s, 1H),
2.10–2.08 (m, 2H), 1.10–1.05 (m, J = 2.7 Hz, 4H); ESIMS m/z calcd. [M+H+]+: 290; found: 290.
1
2-(2-Aminopyrimidin-4-yl)-2,2-difluoro-1-phenylethanone (5d). H-NMR (500 MHz; acetone-d6): δ
8.55 (d, J = 4.9 Hz, 1H), 8.00 (d, J = 7.6 Hz, 2H), 7.71–7.68 (tt, J = 7.5, 1.2 Hz, 1H), 7.54 (t,
J = 7.9 Hz, 2H), 7.12 (d, J = 4.9 Hz, 1H); ESIMS m/z calcd. [M+H+]+: 250; found: 250.
1
2-(2-Amino-6-phenylpyrimidin-4-yl)-2,2-difluoro-1-(3-trifluoromethylphenyl)ethanone (5e). H-NMR
(400 MHz; acetone-d6): δ 8.34–8.30 (m, 2H), 8.26–8.21 (m, 2H), 8.08–8.02 (m, 1H), 7.82 (t,
J = 8.0 Hz, 1H), 7.71 (s, 1H), 7.64–7.61 (m, 1H), 7.58–7.51 (m, 2H); ESIMS m/z calcd. [M+H+]+: 394;
found: 394.
1
2-(2-Amino-6-propylpyrimidin-4-yl)-2,2-difluoro-1-(3-trifluoromethylphenyl)ethanone (5f). H-NMR
(400 MHz; acetone-d6): δ 8.30–8.27 (m, 2H), 8.05 (d, J = 7.9 Hz, 1H), 7.81 (t, J = 7.8 Hz, 1H), 7.05 (s,
1H), 6.33 (s, 2H), 2.65 (t, J = 7.6 Hz, 2H), 1.80-1.68 (m, 2H), 0.95 (t, J = 7.4 Hz, 3H); ESIMS m/z
calcd. [M+H+]+: 360; found: 360.

Molecules 2010, 15
4435
1
2-(2-Amino-6-cyclopropylpyrimidin-4-yl)-2,2-difluoro-1-(3-trifluoromethylphenyl)ethanone (5g). H-
NMR (400 MHz; acetone-d6): δ 8.31–8.26 (m, 2H), 8.05 (d, J = 8.1 Hz, 1H), 7.82 (t, J = 8.2 Hz, 1H),
7.09 (s, 1H), 2.11–2.07 (m, 1H), 1.08–1.02 (m, 4H); ESIMS m/z calcd. [M+H+]+: 358; found: 358.
2-(2-Aminopyrimidin-4-yl)-2,2-difluoro-1-(3-trifluoromethylphenyl)ethanone
(5h).
1H-NMR
(500 MHz; acetone-d6): δ 8.59 (d, J = 5.0 Hz, 1H), 8.32–8.29 (m, 2H), 8.06 (d, J = 7.9 Hz, 1H),
7.84–7.81 (m, 1H), 7.16 (d, J = 5.0 Hz, 1H); ESIMS m/z calcd. [M+H+]+: 318; found: 318.
4. Conclusions
In conclusion, we have demonstrated the synthesis of a small library of 2-(2-amino-pyrimidin-4-yl)-
2,2-difluoro-1-(phenyl)ethanols. While the synthetic procedure give low yields in the last step, the
yields are generally sufficient to produce enough material for biological screening and evaluation.
The target compounds 4a-o did not inhibit T3S at concentrations that warrant further investigation.
A possible explanation to the lack of activity might be due to that the compounds do not mimick
crucial properties of the salicylidene acylhydrazides. The bioactive conformation of the salicylidene
acylhydrazides is unknown and different weights could have been applied to the parameters in SHOP
if information about the binding had been available. Although the compound databases contained more
than 10,556 compounds in around 124,317 conformations, the chemical space sampled might have
been insufficient in order to find biologically active salicylidene acylhydrazide analogs. The
compounds were evaluated in cell-based assays and even if the compounds mimic the bioactive
conformation of the salicylidene acylhydrazides and can bind to the target protein(s), a number of
factors, such as low membrane permeability, bacterial efflux, metabolism, or poor distribution of the
compounds could still render them inactive. Another factor that might play a role is the metal chelating
capacity of the salicylidene acylhydrazides [9], which may be part of the mode of action. The metal
chelating ability of 4a-o is likely to be substantially different.
The synthesized target compounds 4a-o belong to a structure class that to our knowledge has not
been published to date. The compounds have high aqueous solubility compared to the salicylidene
acylhydrazides. No precipitation was detected at 200 μM for the entire library and at 1 mM for 4e and
4o, whereas many of the active T3S inhibiting salicylidene acylhydrazides start to precipitate at
concentrations above 100 μM. The logarithm of solubility in water was calculated, using the program
MOE [33], to be around -3 for 4e and 4o while as low as -6 for 4i. The compounds 4a-o all fulfill
Lipinski´s rules (molecular weight 251-395, two donor atoms, 4-5 acceptor atoms, and logP 1.6-4.5)
and the compounds do not decompose under acidic workup (HCl, 1 M).
The 2-(2-amino-pyrimidin-4-yl)-2,2-difluoro-1-(methyl)ethanol scaffold is novel and it can be of
general interest to include compounds such as the ones presented in high throughput screening
collections. Additionally the scaffold can be of special interest in projects where salicylidene
acylhydrazides have shown biological activity in mammalian and microbial systems [15-26].
Acknowledgements
We thank the Swedish National Research Council, the Swedish Governmental Agency for
Innovation Systems (VINNOVA), the Carl Trygger foundation, and Creative Antibiotics for support.

Molecules 2010, 15
4436
References
1. Hueck, C.J. Type III protein secretion systems in bacterial pathogens of animals and plants.
Microbiol. Mol. Biol. Rev. 1998, 62, 379-433.
2. Rasko, D.A.; Sperandio, V. Anti-virulence strategies to combat bacteria-mediated disease. Nat.
Rev. Drug Discov. 2010, 9, 117-128.
3. Baron, C. Antivirulence drugs to target bacterial secretion systems. Curr. Opin. Microbiol. 2010,
13, 100-105.
4. Kauppi, A.M.; Nordfelth, R.; Uvell, H.; Wolf-Watz, H.; Elofsson, M. Targeting bacterial
virulence: Inhibitors of type III secretion in Yersinia. Chem. Biol. 2003, 10, 241-249.
5. Nordfelth, R.; Kauppi, A.M.; Norberg, H.A.; Wolf-Watz, H.; Elofsson, M. Small-molecule
inhibitors specifically targeting type III secretion. Infect. Immun. 2005, 73, 3104-3114.
6. Muschiol, S.; Bailey, L.; Gylfe, A.; Sundin, C.; Hultenby, K.; Bergstrom, S.; Elofsson, M.; Wolf-
Watz, H.; Normark, S.; Henriques-Normark, B. A small-molecule inhibitor of type III secretion
inhibits different stages of the infectious cycle of Chlamydia trachomatis. Proc. Natl. Acad. Sci.
USA 2006, 103, 14566-14571.
7. Wolf, K.; Betts, H.J.; Chellas-Gery, B.; Hower, S.; Linton, C.N.; Fields, K.A. Treatment of
Chlamydia trachomatis with a small molecule inhibitor of the Yersinia type III secretion system
disrupts progression of the chlamydial developmental cycle. Mol. Microbiol. 2006, 61, 1543-1555.
8. Bailey, L.; Gylfe, A.; Sundin, C.; Muschiol, S.; Elofsson, M.; Nordstrom, P.; Henriques-Normark,
B.; Lugert, R.; Waldenstrom, A.; Wolf-Watz, H.; Bergstrom, S. Small molecule inhibitors of type
III secretion in Yersinia block the Chlamydia pneumoniae infection cycle. FEBS Lett. 2007, 581,
587-595.
9. Slepenkin, A.; Enquist, P.A.; Hagglund, U.; de la Maza, L.M.; Elofsson, M.; Peterson, E.M.
Reversal of the antichlaraydial activity of putative type III secretion inhibitors by iron. Infect.
Immun. 2007, 75, 3478-3489.
10. Negrea, A.; Bjur, E.; Ygberg, S.E.; Elofsson, M.; Wolf-Watz, H.; Rhen, M. Salicylidene
acylhydrazides that affect type III protein secretion in Salmonella enterica serovar Typhimurium.
Antimicrob. Agents Chemother. 2007, 51, 2867-2876.
11. Hudson, D.L.; Layton, A.N.; Field, T.R.; Bowen, A.J.; Wolf-Watz, H.; Elofsson, M.; Stevens,
M.P.; Galyov, E.E. Inhibition of type III secretion in Salmonella enterica serovar typhimurium by
small-molecule inhibitors. Antimicrob. Agents. Chemother. 2007, 51, 2631-2635.
12. Veenendaal, A.K.J.; Sundin, C.; Blocker, A.J. Small-molecule type III secretion system inhibitors
block assembly of the shigella type III secreton. J. Bacteriol. 2009, 191, 563-570.
13. Tree, J.J.; Wang, D.; McInally, C.; Mahajan, A.; Layton, A.; Houghton, I.; Elofsson, M.; Stevens,
M.P.; Gally, D.L.; Roe, A.J. Characterization of the effects of salicylidene acylhydrazide
compounds on type III secretion in Escherichia coli O157:H7. Infect. Immun. 2009, 77,
4209-4220.
14. Dahlgren, M.K.; Zetterström, C.E.; Gylfe, A.; Linusson, A.; Elofsson, M. Statistical molecular
design of a focused salicylidene acylhydrazide library and multivariate QSAR of inhibition of
type III secretion in the Gram-negative bacterium Yersinia. Bioorg. Med. Chem. 2010, 18,
2686-2703.

Molecules 2010, 15
4437
15. Manvar, A.; Malde, A.; Verma, J.; Virsodia, V.; Mishra, A.; Upadhyay, K.; Acharya, H.;
Coutinho, E.; Shah, A. Synthesis, anti-tubercular activity and 3D-QSAR study of coumarin-4-
acetic acid benzylidene hydrazides. Eur. J. Med. Chem. 2008, 43, 2395-2403.
16. Yang, H.Y.; Shen, Y.; Chen, J.H.; Jiang, Q.F.; Leng, Y.; Shen, J.H. Structure-based virtual
screening for identification of novel 11 beta-HSD1 inhibitors. Eur. J. Med. Chem. 2009, 44,
1167-1171.
17. Liu, W.Y.; Li, H.Y.; Zhao, B.X.; Shin, D.S.; Lian, S.; Miao, J.Y. Synthesis of novel ribavirin
hydrazone derivatives and anti-proliferative activity against A549 lung cancer cells. Carbohydr.
Res. 2009, 344, 1270-1275.
18. Vicini, P.; Incerti, M.; La Colla, P.; Loddo, R. Anti-HIV evaluation of benzo[d]isothiazole
hydrazones. Eur. J. Med. Chem. 2009, 44, 1801-1807.
19. Mircus, G.; Hagag, S.; Levdansky, E.; Sharon, H.; Shadkchan, Y.; Shalit, I.; Osherov, N.
Identification of novel cell wall destabilizing antifungal compounds using a conditional
Aspergillus nidulans protein kinase C mutant. J. Antimicrob. Chemother. 2009, 64, 755-763.
20. Romeiro, N.C.; Aguirre, G.; Hernandez, P.; Gonzalez, M.; Cerecetto, H.; Aldana, I.; Perez-Silanes,
S.; Monge, A.; Barreiro, E.J.; Lima, L.M. Synthesis, trypanocidal activity and docking studies of
novel quinoxaline-N-acylhydrazones, designed as cruzain inhibitors candidates. Bioorg. Med.
Chem. 2009, 17, 641-652.
21. Cosconati, S.; Marinelli, L.; Trotta, R.; Virno, A.; Mayol, L.; Novellino, E.; Olson, A.J.;
Randazzo, A. Tandem application of virtual screening and NMR experiments in the discovery of
brand new DNA quadruplex groove binders. J. Am. Chem. Soc. 2009, 131, 16336-16337.
22. He, L.Y.; Zhang, L.; Liu, X.F.; Li, X.H.; Zheng, M.Y.; Li, H.L.; Yu, K.Q.; Chen, K.X.; Shen, X.;
Jiang, H.L.; Liu, H. Discovering potent inhibitors against the beta-hydroxyacyl-acyl carrier
protein dehydratase (FabZ) of Helicobacter pylori: Structure-based design, synthesis, bioassay,
and crystal structure determination. J. Med. Chem. 2009, 52, 2465-2481.
23. Patkar, C.G.; Larsen, M.; Owston, M.; Smith, J.L.; Kuhn, R.J. Identification of inhibitors of
Yellow fever virus replication using a replicon-based high-throughput assay. Antimicrob. Agents
Chemother. 2009, 53, 4103-4114.
24. Marlo, J.E.; Niswender, C.M.; Days, E.L.; Bridges, T.M.; Xiang, Y.; Rodriguez, A.L.; Shirey,
J.K.; Brady, A.E.; Nalywajko, T.; Luo, Q.; Austin, C.A.; Williams, M.B.; Kim, K.; Williams, R.;
Orton, D.; Brown, H.A.; Lindsley, C.W.; Weaver, C.D.; Conn, P.J. Discovery and
characterization of novel allosteric potentiators of M-1 muscarinic receptors reveals multiple
modes of activity. Mol. Pharmacol. 2009, 75, 577-588.
25. Patel, V.; Mazitschek, R.; Coleman, B.; Nguyen, C.; Urgaonkar, S.; Cortese, J.; Barker, R.H.;
Greenberg, E.; Tang, W.P.; Bradner, J.E.; Schreiber, S.L.; Duraisingh, M.T.; Wirth, D.F.; Clardy,
J. Identification and characterization of small molecule inhibitors of a class I histone deacetylase
from Plasmodium falciparum. J. Med. Chem. 2009, 52, 2185-2187.
26. Peterson, Q.P.; Hsu, D.C.; Goode, D.R.; Novotny, C.J.; Totten, R.K.; Hergenrother, P.J.
Procaspase-3 activation as an anti-cancer strategy: Structure-activity relationship of procaspase-
activating ompound 1 (PAC-1) and its cellular co-localization with caspase-3. J. Med. Chem.
2009, 52, 5721-5731.

Molecules 2010, 15
4438
27. MacroModel, version 9.5, Schrödinger LLC, 120 West 45th Street, Tower 45, New York, NY,
USA, 10036-4041.
28. SHOP, version 1.0, Molecular Discovery Ltd., 215 Marsh Road, HA5 5NE Pinner, Middlesex,
U.K.
29. Bagley, M.C.; Hughes, D.D.; Lubinu, M.C.; Merritt, E.A.; Taylor, P.H.; Tomkinson, N.C.O.
Microwave-assisted synthesis of pyrimidine libraries. Qsar Comb. Sci. 2004, 23, 859-867.
30. Iseki, K.; Asada, D.; Kuroki, Y. Preparation of optically active alpha,alpha-difluoro-beta-
hydroxyketones. J. Fluorine Chem. 1999, 97, 85-89.
31. Sato, K.; Tarui, A.; Kita, T.; Ishida, Y.; Tamura, H.; Omote, M.; Ando, A.; Kumadaki, I.
Rhodium-catalyzed Reformatsky-type reaction of ethyl bromodifluoroacetate. Tet. Lett. 2004, 45,
5735-5737.
32. Bergmann, R.; Liljefors, T.; Sorensen, M.D.; Zamora, I. SHOP: Receptor-Based Scaffold
HOPping by GRID-Based Similarity Searches. J. Chem. Info. Model. 2009, 49, 658-669.
33. Molecular Operating Environment, (MOE), version 2008.10, Chemical Computing Group Inc.,
Suite 910 - 1010 Sherbrooke St. W, Montreal, Quebec, Canada H3A 2R7.
Sample Availability: Please contact the corresponding author.
© 2010 by the authors; licensee MDPI, Basel, Switzerland. This article is an Open Access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/3.0/).
