Full Paper
and quenched with NaHSO3 (1.4 g, 3m in H2O). The mixture was
warmed to room temperature and stirred for 45 min. The organic
layer was separated and concentrated in vacuo, and EtOAc was
added to redissolve the residue that formed. The aqueous layer
was extracted with EtOAc (3ꢃ), and the combined organic layers
were washed with H2O (1ꢃ) followed by brine, dried over Na2SO4,
filtered, and concentrated in vacuo. NaIO4 (1.0 g, 4.68 mmol) was
added to this crude diol in THF (30 mL) and H2O (15 mL) at room
temperature, and the mixture was stirred for 2 h. The resulting mix-
ture was carefully concentrated to less than half its volume by re-
moving THF under vacuum. The mixture was diluted with water
and extracted with EtOAc (3ꢃ). The combined organic extracts
were washed with brine, dried over Na2SO4, filtered, and concen-
trated in vacuo. Flash column chromatography of the crude prod-
uct over silica gel (10% EtOAc/hexane ! 45% EtOAc/hexane) af-
forded cis-bromolactol 9 (0.713 g, 91% over 2 steps) as a white
solid. Rf =0.39 (silica, 50% EtOAc/hexane); m.p. 52.8–56.18C;
[a]2D5 = +15.7 (c=0.71, CHCl3); IR (thin film): nmax =3421, 2936,
C21H23O379Br+ [M]+: 402.0831; found: 402.0827; m/z calcd for
C21H23O381Br+ [M]+: 404.0810; found: 404.0813 (intensity ratio 1:1).
Synthesis of bromophenol 14: 10% Pd on carbon (20% wt/wt,
55.2 mg), followed by 1,4-cyclohexadiene (1.6 mL, 17.1 mmol) was
added to a solution of 13 (0.276 g, 0.684 mmol) in absolute EtOH
(6 mL) at room temperature under an atmosphere of N2. The re-
sulting mixture was stirred at room temperature for 3 h, before it
was filtered through a pad of Celite, eluted with EtOAc, and con-
centrated in vacuo. Flash column chromatography of the crude
product over silica gel (10% EtOAc/hexane ! 40% EtOAc/hexane)
afforded bromophenol 14 (0.213 g, 99%) as a colorless viscous oil.
Rf =0.29 (silica, 30% EtOAc/hexane); [a]2D6 = +26.2 (c=0.27, CHCl3);
IR (thin film): nmax =2924, 2853, 1652, 1510, 1452, 1348, 1275, 1218,
1170, 1107, 968, 814 cmꢀ1 1H NMR (500 MHz, CDCl3): d=6.65 (s,
;
1H), 6.62 (s, 1H), 5.45 (s, 1H), 4.76 (d, J=5.5 Hz, 1H), 3.87 (s, 3H),
3.30 (d, J=10.0 Hz, 1H), 3.22–3.18 (m, 2H), 3.00 (dd, J=4.4,
17.6 Hz, 1H), 2.56–2.49 (m, 2H), 2.00 (d, J=10.7 Hz, 1H), 1.45 ppm
(s, 3H); 13C NMR (125 MHz, CDCl3): d=146.6, 143.4, 133.4, 125.4,
113.3, 111.0, 84.1, 78.0, 56.0, 41.4, 38.5, 35.3, 31.8, 26.2 ppm; ESI-
1591, 1512, 1456, 1419, 1379, 1263, 1229, 1140, 1020, 737 cmꢀ1
;
1H NMR (500 MHz, CDCl3): d=7.43 (d, J=7.6 Hz, 2H), 7.36 (t, J=
7.6 Hz, 2H), 7.30 (t, J=7.3 Hz, 1H), 6.81 + 6.80 (d each, J=8.2 Hz,
1H), 6.71 + 6.69 (d each, J=1.9 Hz, 1H), 6.66–6.63 (m, 1H), 5.52–
5.50 (m, 1H), 5.13 (s, 2H), 3.89 + 3.88 (s each, 3H), 3.81 + 3.44 (d1,
J1 =10.1 Hz + d2, J2 =10.7 Hz, 1H), 3.49 + 3.37 (d1, J1 =10.1 Hz +
d2, J2 =10.7 Hz, 1H), 3.09 + 2.81–2.71 (m each, 2H), 2.56 (dd, J=
10.8, 13.3 Hz, 1H), 2.41–2.27 (m, 1H), 2.00–1.92 + 1.81–1.76 (m
each, 1H), 1.46 + 1.36 ppm (s each, 3H); 13C NMR (125 MHz,
CDCl3): d=149.8, 149.7, 146.80, 146.8, 137.2, 133.1, 133.0, 128.5,
127.8, 127.3, 127.3, 120.6, 120.5, 114.4, 112.4, 97.8, 97.2, 83.6, 83.1,
71.2, 56.1, 56.0, 50.8, 47.9, 39.8, 39.5, 39.4, 39.3, 35.4, 34.8, 27.4,
25.0 ppm; HRMS (EI): m/z calcd for C21H25O479Br+ [M]+: 420.0936;
found: 420.0929; m/z calcd for C21H25O481Br+ [M]+: 422.0916;
found: 422.0922 (intensity ratio 25:22).
MS: m/z calcd for C14H1679BrO3 [MꢀH]ꢀ: 311.0; found: 311.3.
ꢀ
General procedure for the Lewis acid catalyzed Marson type
Friedel–Crafts cyclization of 9: Activated 4 ꢁ molecular sieves
(1.0 gmmolꢀ1) were added to 9 (20–30 mg) under an atmosphere
of Ar, followed by CH2Cl2 (0.01–0.02m) to make a suspension. The
Lewis acid was weighed, either in the open or in an N2-filled Al-
drich AtmosBag glove bag, and transferred to the solution of 9 at
room temperature under Ar. The resulting mixture was stirred at
room temperature until TLC indicated the complete consumption
of 9. At higher catalyst loadings of Bi(OTf)3, the colorless solution
turns a persistent pink color, which indicates completion of the re-
action. The reaction mixture was poured into ice-cooled sat. aq.
NH4Cl with vigorous stirring, before the organic layer was separat-
ed. The aqueous layer was extracted with CH2Cl2 (2ꢃ). The com-
bined organic layers were washed with brine, dried over Na2SO4,
filtered, and concentrated in vacuo. Flash column chromatography
of the crude product over silica gel (5% EtOAc/hexane ! 18%
EtOAc/hexane) afforded bromobenzotetrahydrofuran 13 as a color-
less oil. Further elution at 22% EtOAc/hexane gave the bromolactol
dimeric ether 15 as a colorless viscous oil and benzobromohydrin
16 was obtained as a yellow oil with 30% EtOAc/hexane.
Synthesis of bromobenzotetrahydrofuran 13 (through SnCl4-
mediated Friedel–Crafts cyclization): SnCl4 (0.96 mL, 8.20 mmol)
was quickly added to a solution of 9 (0.685 g, 1.63 mmol) in CH2Cl2
(20 mL) at ꢀ788C. The solution gave a strong orange color after
10–15 min of stirring at ꢀ788C. The solution was stirred at ꢀ788C
for 75 min, before it was quenched with half-saturated Rochelle
salt aq. solution. The half-saturated Rochelle salt (90 g in 200 mL
H2O) was cooled to 08C with vigorous stirring. The reaction mix-
ture was lifted above the ꢀ788C dry ice/acetone bath, and its con-
tents were immediately poured into the half-saturated Rochelle
salt upon removing the rubber septum. After the transfer was
complete and the resulting organic layer became colorless in less
than 1 min, the mixture was diluted with some H2O, and the or-
ganic layer was separated. The aqueous layer was extracted with
CH2Cl2 (2ꢃ). The combined organic layers were washed with brine,
dried over Na2SO4, filtered, and concentrated in vacuo. Flash
column chromatography of the crude product over silica gel (5%
EtOAc/hexane ! 18% EtOAc/hexane) afforded bromobenzotetra-
hydrofuran 13 (0.578 g, 88%) as a colorless oil. Rf =0.63 (silica,
30% EtOAc/hexanes); [a]2D5 = +106.7 (c=0.67, CHCl3); IR (thin film):
nmax =2943, 1607, 1510, 1452, 1325, 1267, 1223, 1119, 1049, 972,
Compound 15: Rf =0.47 (silica, 30% EtOAc/hexane); [a]2D6 =ꢀ61.4
(c=0.48, CHCl3); IR (thin film): nmax =3059, 2924, 2853, 1589, 1512,
1452, 1377, 1263, 1231, 1140, 1011, 961, 735 cmꢀ1
;
1H NMR
(500 MHz, CDCl3): d=7.44 (d, J=7.6 Hz, 2H), 7.36 (t, J=7.6 Hz, 2H),
7.30 (t, J=8.2 Hz, 1H), 6.82–6.80 (m, 1H), 6.69 (d, J=1.9 Hz, 1H),
6.67–6.63 (m, 1H), 5.56–5.54 + 5.45–5.44 (m each, 1H), 5.13 + 5.12
(s each, 2H), 3.89 + 3.88 (s each, 3H), 3.73 + 3.41–3.35 (d1, J1 =
10.1 Hz + m2, 2H), 2.81–2.73 (m, 1H), 2.58–2.32 + 2.02–1.96 (m
each, 3H), 1.86–1.82 + 1.77–1.72 (m each, 1H), 1.33 ppm (s, 3H);
13C NMR (125 MHz, CDCl3): d=149.8, 149.7, 146.8, 146.8, 137.3,
133.4, 133.1, 128.5, 127.8, 127.3, 120.7, 120.5, 114.4, 114.3, 112.7,
112.4, 99.8, 98.7, 83.3, 82.9, 71.2, 56.1, 56.1, 50.4, 48.2, 39.7, 39.0,
38.8, 35.6, 34.9, 29.7, 27.4, 24.5 ppm; HRMS (EI): m/z calcd for
C42H48O779Br2 [M]+: 822.1767; found: 822.1796; m/z calcd for
+
C21H25O479Br81Br+ [M]+: 824.1746; found: 824.1783; m/z calcd for
C21H25O481Br81Br+ [M]+: 826.1726; found: 826.1788 (intensity ratio
1:2:1).
866, 739 cmꢀ1 1H NMR (500 MHz, CDCl3): d=7.43 (d, J=7.0 Hz,
;
2H), 7.36 (t, J=7.6 Hz, 2H), 7.30 (t, J=7.3 Hz, 1H), 6.67 (s, 1H), 6.64
(s, 1H), 5.12 (d, J=12.0 Hz, 1H), 5.07 (d, J=12.0 Hz, 1H), 4.72 (d,
J=5.1 Hz, 1H), 3.86 (s, 3H), 3.30 (d, J=10.1 Hz, 1H), 3.21 (d, J=
10.1 Hz, 1H), 3.19 (d, J=5.0 Hz, 1H), 3.01 (dd, J=4.4, 17.7 Hz, 1H),
2.56 (brs, 1H), 2.52–2.48 (d, J=5.4 Hz, 1H), 2.00 (d, J=11.4 Hz, 1H),
1.45 ppm (s, 3H); 13C NMR (125 MHz, CDCl3): d=149.7, 146.2, 137.2,
132.8, 128.5, 127.8, 127.3, 126.8, 113.1, 112.2, 84.1, 78.1, 71.3, 56.1,
41.4, 38.5, 35.3, 31.8, 26.2 ppm; HRMS (EI): m/z calcd for
Compound 16: Rf =0.35 (silica, 30% EtOAc/hexane); [a]2D6 =ꢀ157.3
(c=0.15, CHCl3); IR (thin film): nmax =2955, 2922, 2853, 1510, 1454,
1379, 1260, 1227, 1119, 1022, 854, 739 cmꢀ1 1H NMR (500 MHz,
;
CDCl3): d=7.43 (d, J=6.9 Hz, 2H), 7.36 (t, J=7.6 Hz, 2H), 7.30 (t,
J=7.6 Hz, 1H), 6.70 (s, 1H), 6.62 (s, 1H), 6.42 (dd, J=1.9, 10.1 Hz,
1H), 5.74 (dd, J=4.4, 10.1 Hz, 1H), 5.11 (s, 2H), 3.88 (s, 3H), 3.61 (d,
