Three 2D AgI-framework isomers with helical structures controlled by the
chirality of camphor-10-sulfonic acid†
Peng Guo*
Received 13th October 2010, Accepted 9th December 2010
DOI: 10.1039/c0dt01384f
Three 2D AgI-framework isomers were constructed from enantiopure camphor-10-sulfonic acids or
racemic camphor-10-sulfonic acids, together with achiral 4-aminobenzoic acids. In complex 1,
(+)-camphor-10-sulfonic acids bridge the single left-handed helices that are made up of Ag ions and
4-aminobenzoic acids, generating a homochiral 2D layer. In such a structure, the interweaving of triple
left-handed homohelices was also found. It is worth noting that the helicity of complex 2 could be
controlled by the handedness of the camphor-10-sulfonic acid. In complex 2, there are right-handed
helical structures, including single right-handed and triple right-handed helical structures connected by
(-)-camphor-10-sulfonic acids. For a comparative study, ( )-camphor-10-sulfonic acids were utilized to
synthesize complex 3, in which equal numbers of right-handed or left-handed double-helical chains are
created. All the complexes were characterized by single-crystal X-ray structure determination, powder
X-ray diffraction, IR, TGA and element analysis. Circular dichroism spectra of complexes 1 and 2 were
been studied to confirm the fact that enantiopure bridging ligands do not racemize.
Therefore, in order to guarantee the homochirality of an individual
single-crystal and bulk materials, enantiopure bridging ligands,
which are not prone to racemization, can be utilized.16
Introduction
Increasing attention is being paid to the design and synthe-
sis of homochiral solids because of their potential application
in asymmetric catalysis,1 enantioselective separation2 and non-
linear optics.3 Recently, the flourishing research field of MOFs
(metal–organic frameworks) has provided an avenue to construct
homochiral crystalline solids by the availability of enantiopure
bridging ligands.4–10 Unfortunately, undesirable achiral crystalline
solids are often obtained owing to ligand racemization.11 Chiral
MOFs can also be assembled by achiral ligands and metal ions;
however, two phenomena hamper their potential application in
enantioselective separation and asymmetric catalysis: one is that
the single-crystals are racemic twins (Flack parameter = 0.5)
rather than homochiral ones, although they crystallize in chiral
space groups; the other is that the bulk materials tend to form
conglomerates in which homochiral right-handed and left-handed
molecules crystallize in equal proportion.12,13 In such a system,
homochiral bulk materials can be created by chiral catalysis
induction, and then be tested by a combination of X-ray single-
crystal diffraction and CD (circular dichroism) spectroscopy,
which have been extensively investigated by Bu and Morris.14,15
Simultaneously, chirality and absolute helicity are often closely
linked with each other in the same structure, although they
are two distinct concepts.17 Metal–organic frameworks also can
provide a model to better understand the relationship between
chirality and helicity. Camphorsulfonic acids are appropriate
candidates because they integrate the merits of a quite inert
chiral center with a good acceptor of hydrogen bonding (carbonyl
group C O). The latter merit possesses the potential function
to regulate helicity through hydrogen bonding. Sulfonic acid
prefers to coordinate with AgI ions rather than other transition
metals (such as Fe2+, Co2+, Ni2+), especially in the presence
of auxiliary N-containing secondary ligands, which has been
systematically investigated and elaborately elucidated by several
groups.18–25
Herein, we report two homochiral silver camphor-10-sulfonic
acid frameworks, [Ag(L2)(L1)]n (1) and [Ag(L3)(L1)]n (2) [L1 = 4-
aminobenzoic acid, L2 = (+)-camphor-10-sulfonic anion, L3 =
(-)-camphor-10-sulfonic anion] (Scheme 1), and one achiral
silver camphor-10-sulfonic acid, [Ag(L4)(L1)]n (3), involving the
racemic ( )-camphor-10-sulfonic acid ligand. It is worth noting
that the orientation of homohelices could be regulated by the
handedness of the camphor-10-sulfonic acid. Only right-handed
(P) examples are found in complex 2, unique left-handed (M)
examples exist in complex 1, while there are P and M examples in
complex 3.
State Key Laboratory of Rare Earth Resource Utilizations, Changchun
Institute of Applied Chemistry, Chinese Academy of Sciences, Changchun,
130022, P. R. China. E-mail: pguo@ciac.jl.cn; Tel: +86 0431-85262941
† Electronic supplementary information (ESI) available. CCDC reference
numbers 793353–793355. For ESI and crystallographic data in CIF or
other electronic format see DOI: 10.1039/c0dt01384f
1716 | Dalton Trans., 2011, 40, 1716–1721
This journal is
The Royal Society of Chemistry 2011
©

View Article Online
X-Ray Crystallography
The X-ray intensity data of compounds 1 and 2 were collected
on a Bruker SMART APEX CCD diffractometer with graphite
˚
monochromatized Mo-Ka radiation (l = 0.71073 A) operating
at 2.0 kW (50 kV, 40 mA). The structures were solved by the
direct method of SHELXS-9726 and refined with full-matrix
least-squares techniques using the SHELXL-97 program27 within
WINGX.28 The hydrogen atoms attached to carbons and nitrogens
were generated geometrically, while those attached to oxygens were
located from difference Fourier maps and refined with isotropic
displacement parameters. All non-hydrogen atoms were refined
with anisotropic displacement parameters. Crystal data and details
of the structure determination for complexes 1–3 are listed in
Table 1. Selected bond lengths and angles are given in Table 2, and
the hydrogen bonds for complexes 1–3 are described in Table 3.
Results and discussion
Scheme 1 The structures of the ligands in this work.
Description of the structure
Experimental section
Structure descriptions of complexes 1 and 2. Complex 1
crystallizes in chiral space group P212121, and there is one
crystallographically independent AgI ion, one L2 ligand and one
L1 ligand. The AgI ion shows a distorted five coordinate square
pyramidal configuration (z = 0.044)29 with O2 and N1 atoms
from the L1 ligand, and O3 and O5 atoms from the L2 ligand
in a square configuration, and O3 from another L2 ligand in an
apical position (Fig. 1). It is of particular interest to note that
the left-handed 21 helices along the a axis are constructed from
AgI ions and L1 ligands (Fig. 2). The bond angle of Ag1–N1–C1
(112.53(15)◦) and the torsion angle of C1–N1–Ag1–O2 (28.54◦)
are mainly responsible for the construction of the left-handed 21
Materials
All the reagents and solvents employed were commercially avail-
able and used as received without further purification. All other
reagents of analytical grade were purchased and used without
further purification.
Physical measurements
IR spectra were obtained from KBr pellets on a Perkin-Elmer
580B IR spectrometer in the 400–4000 cm-1 region (SI). Elemental
analyses (C, H and N) were performed using a VarioEL analyzer.
Thermogravimetric analyses (TGA) were performed on a Perkin-
Elmer TG-7 analyzer heated from 40 to 800 C under nitrogen.
Powder X-ray diffraction data were collected on a Bruker D8-
˚
helix, with a pitch of about 6.252 A, which is reinforced through
O3 and O5 atoms from the L2 ligand. The unique m2-O3 atom
from L2 makes a great contribution to form a 2D homochiral
layer by the connection of adjacent homohelices along the b axis
(Fig. 3(a)).
◦
˚
AVANCE diffractometer equipped with Cu-Ka (l = 1.5418 A)
radiation at a scan speed of 6◦ min-1. Experimental patterns were in
good agreement with the corresponding simulated ones, indicating
the phase purity of the as-synthesized products.
Synthesis
Synthesis of complex 1. An aqueous solution (10 mL) of (+)-
camphor-10-sulfonic acids (0.095 g, 0.5 mmol) was added to solid
Ag2CO3 (0.069 g, 0.25 mmol) and stirred for several minutes
until no further CO2 was given off. 10 mL of ethanol containing
4-aminobenzoic acid (0.070 g, 0.5 mmol) was added to the
aqueous solution. Colorless crystals of complex 1 were obtained
by evaporation of the solution for 5 d at room temperature (52%
yield). Anal. calc. for the complex 1 (Mr = 476.30): C, 42.87; H,
4.66; N, 2.94. Found: C, 43.10; H, 4.78; N, 3.01%.
Synthesis of complexes 2 and 3. These complexes were obtained
by the same method with (-)-camphor-10-sulfonic acids and
racemic camphor-10-sulfonic acids instead of (+)-camphor-10-
sulfonic acids, respectively. Anal. calc. for the complex 2 (Mr =
476.30): C, 42.87; H, 4.66; N, 2.94. Found: C, 42.91; H, 4.72; N,
3.12%. Anal. calc. for the complex 3 (Mr = 476.30): C, 42.87; H,
4.66; N, 2.94. Found: C, 42.75; H, 4.56; N, 2.82%.
