The Synthesis of 2-Aminobenzoxazoles Using
Reusable Ionic Liquid as a Green Catalyst under
Mild Conditions
Ya Zhou 1,†, Zhiqing Liu 1,†, Tingting Yuan 1, Jianbin Huang 1 and Chenjiang Liu 1,2,
*
1
School of Chemistry and Chemical Engineering, Xinjiang University and Key Laboratory of Oil and Gas
Fine Chemicals, Ministry of Education, Urumqi 830046, China; zhouya507@126.com (Y.Z.);
liuzhiqing507@163.com (Z.L.); Yuantingting507@126.com (T.Y.); huangjianbin507@126.com (J.H.)
Physics and Chemistry Detecting Center, Xinjiang University, Urumqi 830046, China
Correspondence: pxylcj@126.com; Tel.: +86-991-858-2901
2
*
†
The two authors contributed equally to this paper.
Academic Editor: Derek J. McPhee
Received: 9 March 2017; Accepted: 28 March 2017; Published: 2 April 2017
Abstract: A facile, green, and efficient method for the direct oxidative amination of benzoxazoles
using heterocyclic ionic liquid as catalyst has been developed. The reaction proceeded smoothly at
room temperature and gave the desirable 2-aminobenzoxazoles with good to excellent yields (up to
97%). The catalyst 1-butylpyridinium iodide can be easily recycled and reused with similar efficacies
for at least four cycles.
Keywords: 2-Aminobenzoxazoles; heterocyclic ionic liquid; recycled
1. Introduction
Amino-substituted azoles and their derivatives are ubiquitous in functional materials,
pharmaceuticals, and natural products [
been described as potent 5-HT3-receptor antagonists [
treatment of Alzheimer’s disease and schizophrenia. Furthermore, abundant other drug targets
have been addressed by 2-aminobenzoxazoles, such as 7 nicotinic acetylcholine receptor (nAchR)
agonist, 5-HT6-receptor antagonist, and MK-4305 in clinical trials against insomnia [ ]. Hence, the
1–
3]. Among them, the 2-aminobenzoxazoles have already
4,5], which are promising targets for the
α
6,7
development of effective methods to synthesize these compounds has attracted great attention. In this
regard, direct C–H amination reaction displaying an advantage in atom efficiency has been pioneered
by Cho (Scheme 1a), Monguchi, Wang, Kawano, Miyasaka, Xie and others in the past decade [8–20].
However, most of these methods could be realized only in the presence of copper, silver, manganese,
iron, cobalt. The toxicity and expense of transition metals might limit practical applications.
Recently, metal-free-catalyzed oxidative coupling reactions have undergone rapid advances
in order to solve drawbacks of transition metal catalysis [21–25]. Thus, the discovery of green
and sustainable oxidative C–H amination of benzoxazoles under metal-free conditions will be of
great value. Hypervalent iodine compounds have gained much attention in organic synthesis
as versatile and powerful oxidants [26–29]. For example, Chang and co-workers [30] employed
stoichiometric amounts of PhI(OAc)2, and Bhanage et al. [31]. used 2-iodoxybenzoic acid (IBX) to
get direct oxidative C–H bond amination of benzoxazoles. Moreover, much progress in the direct
oxidative amination of benzoxazoles has been achieved through the use of a combination of an
iodine source and oxidant [32–38]. For instance, a metal-free approach for the oxidative amination
of benzoxazoles using molecular iodine as a catalyst and tert-butyl hydroperoxide (TBHP) as an
oxidant was reported by Lamani and Prabhu [32]. At the same time, another report was presented
Molecules 2017, 22, 576; doi:10.3390/molecules22040576
www.mdpi.com/journal/molecules

Molecules 2017, 22, 576
2 of 9
by Nachtsheim’s group on the oxidative C–H amination of benzoxazoles under metal-free conditions
using tetrabutyl◦ammonium iodide (TBAI) as catalyst and aqueous solutions of H2O2 or TBHP as
co-oxidant at 80 C (Scheme 1b) [33]. These catalytic systems effectively overcome some drawbacks of
using stoichiometric amounts of hypervalent iodine compounds. Nevertheless, these approaches still
suffer from minor drawbacks, such as high temperature, long reaction time, and low yields. Therefore,
designing a highly mild, efficient, green, and recyclable catalyst system for the oxidative C–H amination
of benzoxazoles under metal-free conditions at room temperature is desperately needed.
Ionic liquids (ILs) have attracted continuing interest from the majority of chemists. ILs were
usually used as green reaction media because of their unique chemical and physical properties,
such as high thermal stabilities, negligible vapor pressures, and nonflammability [39
ILs have been employed as solvents in transition-metal-catalyzed C–H activation reactions [45
–
44]. Recently,
49].
–
However, it is important to note that there are few examples of the C–H bond activation
reaction using classical heterocyclic ionic liquids as promoters or catalysts. We recently developed
the first oxidative cross-coupling reaction for C–C bond formation promoted by ionic liquid
1,3-dibutyl-1H-benzo[d][1,2,3]triazol-3-ium bromide [50]. Soon after, the first study using IL-catalyzed
C–H activation reaction for C–N bond formation has been disclosed [51]. Inspired by these works,
we herein report a mild, efficient, and metal-free strategy for C–H oxidative amination of benzoxazoles
by using heterocyclic ionic liquid 1-butylpyridinium iodide ([BPy]I) as catalyst, TBHP as oxidant,
and acetic acid as an additive at room temperature (Scheme 1c).
Scheme 1. Reported and designed routes for the oxidative amination of benzoxazoles. IL: ionic liquid;
TBHP: tert-butyl hydroperoxide. Equiv: equivalent.
2. Results and Discussion
The investigation started with the reaction of benzoxazole (1a) and morpholine (2a) as model
substrates (Table 1). In the presence of 5 mol% [BPy]I, 1.5 equiv. of TBHP, and 3 equiv. of acetic acid, the
reaction of 1a and 2a was proceeded at room temperature for 7 h to give 2-morpholinobenzo[d]oxazole
(3a) in 94% yield (Table 1, entry 1). Encouraged by the result, further optimization of the reaction
conditions was carried out. Unfortunately, when other ionic liquids (e.g., 1-butylpyridinium chloride
([BPy]Cl) and 1-butylpyridinium bromide ([BPy]Br)) were in this reaction system or the system was
run in the absence of catalyst, the response almost did not give satisfactory results (Table 1, entries 2–4).
Considering that ionic liquids have the advantage of being reusable, the dosage of the [BPy]I was
studied in an effort to reduce the reaction time. Gratifyingly, when the amount of the [BPy]I was
increased from 5 mol% to 15 mol% (Table 1, entries 1, 6), the reaction time decreased from 7 h to 3.5 h.
However, when the dosage of the [BPy]I was increased to 20 mol% (Table 1, entry 7), the reaction time
did not reduce. Thus, 15 mol% of [BPy]I was an adequate choice of catalyst for the reaction to achieve

Molecules 2017, 22, 576
3 of 9
high yields with less reaction time. Furthermore, four kinds of organic solvents were investigated,
and acetonitrile was found to be the optimal solvent (Table 1, entries 6, 8–10). In water and under
solvent-free condition, product 3a was obtained in lower yields of 57% and 51%, respectively (Table 1,
entries 11–12). Other oxidants, such as benzoyl peroxide (BPO), m-chloroperoxybenzoic acid (m-CPBA),
di-tert-butyl peroxide (DTBP), and H2O2 were used instead of TBHP (Table 1, entries 13–16), the effect
of reactions decreased dramatically and TBHP was proven to be the best oxidant.
a
Table 1. Optimizing the reaction conditions.
Oxidant b
Entry
Catalyst (mol%)
Solvent
Time (h)
Yield (%) c
1
2
3
4
5
[BPy]I (5)
[BPy]Cl (5)
[BPy]Br (5)
-
TBHP
TBHP
TBHP
TBHP
TBHP
TBHP
TBHP
TBHP
TBHP
TBHP
TBHP
TBHP
BPO
CH3CN
CH3CN
CH3CN
CH3CN
CH3CN
CH3CN
CH3CN
CH2Cl2
THF
toluene
H2O
Neat
CH3CN
CH3CN
CH3CN
CH3CN
7
7
7
7
94
Trace
N.R. d
N.R.
91
94
94
88
85
86
57
51
65
N.R.
Trace
79
[BPy]I (10)
[BPy]I (15)
[BPy]I (20)
[BPy]I (15)
[BPy]I (15)
[BPy]I (15)
[BPy]I (15)
[BPy]I (15)
[BPy]I (15)
[BPy]I (15)
[BPy]I (15)
[BPy]I (15)
5
6
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
7
8 c
9
10
11
12
13
14
15
16
m-CPBA
DTBP
H2O2
a
Reaction conditions: 1a (0.672 mmol), 2a (1.344 mmol), oxidant (1.008 mmol), acetic acid (2.016 mmol) in 2 mL
b
solvent at room temperature. TBHP: tert-butyl hydroperoxide 70% in water, BPO: benzoyl peroxide, m-CPBA:
c
m-chloroperoxybenzoic acid, DTBP: di-tert-butyl peroxide, H2O2 30% in water, THF: tetrahydrofuran. Isolated
yield. d Not reaction. The optimized reaction conditions were 15 mol% [BPy]I as catalyst, 1.5 equiv. TBHP as oxidant,
and 3 equiv. acetic acid as additive in 2 mL CH3CN at room temperature for 3.5 h.
Under optimized reaction conditions, benzoxazole (1a) and various cyclic or acyclic secondary
amines (
Piperidine, thiomorpholine, 3-methylpiperidine, and 1-methylpiperazine reacted smoothly with
benzoxazole to form the corresponding amination products 3b 3c 3d, and 3e in good to excellent yields
2) were investigated to examine the scope of the process. The results are listed in Scheme 2.
,
,
(Scheme 2). The introduction of heteroatom and substituent on piperidine had no impact on the reaction
system. Subsequently, it was found that both electron-donating and electron-withdrawing groups on
the piperazine—such as methyl, phenyl, acetyl, ethoxycarbonyl, and tert-butoxycarbonyl—reacted
effectively with benzoxazole (1a) to provide the respective aminobenzoxazoles (Scheme 2, 3e: 90%,
3f: 97%, 3g: 91%, 3h: 82%, 3i: 95%). As is well known, 2-(N-alkylpiperazyl)benzoxazoles of this
type were already described as potent 5-HT3-receptor antagonists [2]. The coupling of benzoxazole
proceeded successfully with 1,2,3,4-tetrahydroisoquinoline to give the desired aminated product 3j in
93% yield (Scheme 2). In addition to cyclic amines, acyclic secondary amines such as diethylamine,
dibenzylamine, and diallylamine reacted well with benzoxazole to produce the desired products
3k–3m in good to excellent yields (Scheme 2). To our delight, oxidations or halogenations of the
methylene units, the aromatic ring, or the double bonds did not occur. It should be mentioned that
N,N-diallylbenzoxazol-2-amine (3m) was regarded as one of the useful organic synthetic intermediates.

Molecules 2017, 22, 576
4 of 9
Scheme 2. Amination reaction of benzoxazole with various secondary amines. Reaction conditions:
(0.672 mmol), (1.344 mmol), oxidant (1.008 mmol), acetic acid (2.016 mmol), [BPy]I (15 mol%),
CH3CN (2 mL), at room temperature, 3.5 h. Isolated yield. [BPy]I: 1-butylpyridinium iodide.
1
2
To further study the potential of our method, we turned our attention to the amination reaction
between various benzoxazoles and morpholine. The results are summarized in Scheme 3. Methyl-
and halogen-substituted benzoxazoles could be easily aminated to generate the desired products
4a–4d in up to 97% yield with perfect regioselectivity. To expand the potential of the present synthetic
methodology, a diversity of benzoxazoles including 5-methylbenzoxazole, 6-methylbenzoxazole, and
5-chlorobenzoxazole reacted satisfactorily with various linear and cyclic secondary amines such as
diallylamine, dibenzylamine, and tert-butyl piperazine-1-carboxylate to furnish the corresponding
2-aminobenzothiazole derivatives 4e–4i in good to excellent yields (84%–94%).
Scheme 3. Amination reaction of various benzoxazoles with secondary amines. Reaction conditions:
(
1) (0.672 mmol); (
2) (1.344 mmol), oxidant (1.008 mmol), acetic acid (2.016 mmol), [BPy]I (15 mol%),
CH3CN (2 mL), at room temperature, 3.5 h. Isolated yield.

Molecules 2017, 22, 576
5 of 9
To demonstrate the potential industrial utility of our protocol, the [BPy]I-catalyzed scale-up
reaction was performed. The direct oxidative amination of benzoxazole (1a) with morpholine was
easily carried out under the standard reaction conditions to generate the desired product 3a in 93%
isolated yield (Scheme 4).
Scheme 4. Gram-scale oxidative amination of benzoxazoles and morpholine.
Ionic liquids have several advantages compared with other catalysts; for example, they
are recyclable and environmentally friendly. The coupling reaction of 5-methylbenzoxazole and
morpholine was chosen as a model system to study the reusability of the [BPy]I as catalyst under the
standard reaction conditions. After the reaction was finished, ethyl acetate and water were added, and
then the [BPy]I was recovered from the water layer and reused after drying in vacuo. The [BPy]I was
utilized repeatedly at least four times without any significant loss of activity (Figure 1).
Figure 1. Recycling reactions.
In order to elucidate the reaction mechanism, control experiments were carried out. When
the radical scavenger BHT (2,6-di-tert-butyl-4-methylphenol, 3 equiv.), ethene-1,1-diyldibenzene
(3 equiv.), or TEMPO (2,2,6,6-tetramethylpiperidine-N-oxyl, 3 equiv.) were added to the reaction
mixture under the optimal conditions, the yield of 3a was not decreased. Thus, the reaction may not
be a radical reaction. Subsequently, N-iodomorpholine hydroiodide was prepared. Then, the reaction
of benzoxazole (0.672 mmol, 1 equiv.) and N-iodomorpholine hydroiodide (0.672 mmol, 1 equiv.)
with acetic acid (2.016 mmol, 3 equiv.) as an additive in 2 mL CH3CN at room temperature for 3.5 h
afforded the desired product 3a in 25% yield (Table 2, entry 1). When the dosage of N-iodomorpholine
hydroiodide was increased from 1 equiv. to 2 equiv., the desired amination product was obtained in
53% yield (Table 2, entry 2). It is worth noting that the reaction of 1a and 2a underwent smoothly in
the presence of 15 mol% N-iodomorpholine hydroiodide, 1.5 equiv. TBHP, and 3 equiv. acetic acid to
give 2-morpholinobenzo[d]oxazole (3a) in 95% yield (Table 2, entry 3). All of the above results indicate
that the activation of the morpholine (2a) via in situ preparation of a highly reactive N-I bond from
[BPy]I and TBHP seems plausible.

Molecules 2017, 22, 576
6 of 9
Table 2. Reactivity of N-Iodomorpholine Hydroiodide C.HI a.
Yield (%) b
Entry
1a (Equiv.)
C.HI (Equiv.)
2a (Equiv.)
TBHP (Equiv.)
1
2
3
1
1
1
1
2
0.15
0
0
2
0
0
1.5
25
53
95
a
b
Reaction conditions: 1a (0.672 mmol), acetic acid (2.016 mmol), CH3CN (2 mL), room temperature, 3.5 h;
Isolated yield.
Based on the above results and existing literature [33], a plausible mecha−nism is proposed as
shown in Scheme 5. Initially, [BPy]I is oxidized by TBHP to form [BPy]+[I(OAc)2]
(A) in the presence
of acetic acid, and then releases acetylhypoiodite
morpholine with highly potent I+ source
. Immediately following, the reaction of C and benzoxazole
affords . Finally, the desired amination reaction product 3a can be obtained after the elimination of
B. Subsequently, C is generated by combining
B
D
hydrogen iodide.
Scheme 5. The proposed mechanism. HOAc: acetic acid.
3. Experimental Section
A reaction vessel was charged with acetic acid (2.016 mmol) and TBHP (70% in water, 1.008
mmol) in acetonitrile (2 mL). After the addition of [BPy]I (0.1008 mmol), benzoxazole (0.672 mmol)
and secondary amines (1.344 mmol) were added. Then, the reaction mixture was stirred at room
temperature for 3.5 h. After the reaction finished, the mixture was extracted with dichloromethane
(5 × 10 mL), and the combined organic phases were dried over anhydrous Na2SO4. The solvent was
evaporated under vacuum, and the crude residue was purified by column chromatography on silica
gel. Aqueous phase was dried in a vacuum evaporator to recover the ionic liquid and directly reused
in subsequent runs.
4. Conclusions
In summary, we have found an IL-catalyzed direct oxidative amination of benzoxazoles under
metal-free conditions at room temperature. This mild catalytic system is suitable for the oxidative
amination reactions between a wide range of secondary amines and benzoxazoles. In addition,
the inexpensive and environmentally friendly ionic liquid [BPy]I can be easily recycled and reused for
four runs without any obvious loss of catalytic activity. ILs-catalyzed C–H bond activation is ongoing
in our group.

Molecules 2017, 22, 576
7 of 9
Acknowledgments: This work was supported by Grants from the Key Laboratory of Xinjiang Uyghur
Autonomous Region (2015KL014), NSFC (21572195, 21502162, and 21262035), and Xinjiang University students
innovative training program (201510755012).
Author Contributions: Chenjiang Liu conceived the idea of this piece of research; Zhiqing Liu, Ya Zhou and
Chenjiang Liu designed the experiments; Ya Zhou, Zhiqing Liu and Tingting Yuan performed the chemical
experiments; Ya Zhou and Zhiqing Liu performed the spectra analyses; Ya Zhou, Zhiqing Liu, Jianbin Huang and
Chenjiang Liu wrote the paper.
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
2.
3.
4.
5.
6.
Kablaoui, N.; Patel, S.; Shao, J.; Demian, D.; Hoffmaster, K.; Berlioz, F.; Vazquez, M.L.; Moore, W.M.;
Nugent, R.A. Novel benzoxazole inhibitors of mPGES-1. Bioorg. Med. Chem. Lett. 2013, 23, 907–911.
[CrossRef] [PubMed]
Liu, K.G.; Lo, J.R.; Comery, T.A.; Zhang, G.M.; Zhang, J.Y.; Kowal, D.M.; Smith, D.L.; Di, L.; Kerns, E.H.;
Schechter, L.E.; et al. Identification of a series of benzoxazoles as potent 5-HT6 ligands. Bioorg. Med.
Chem. Lett. 2009, 19, 1115–1117. [CrossRef] [PubMed]
Ningaiah, S.; Bhadraiah, U.K.; Keshavamurthy, S.; Javarasetty, C. Novel pyrazoline amidoxime and their
1,2,4-oxadiazole analogues: Synthesis and pharmacological screening. Bioorg. Med. Chem. Lett. 2013, 23,
4532–4539. [CrossRef] [PubMed]
Gao, M.Z.; Wang, M.; Hutchins, G.D.; Zheng, Q.H. Synthesis of new carbon-11 labeled benzoxazole
derivatives for PET imaging of 5-HT3 receptor. Eur. J. Med. Chem. 2008, 43, 1570–1574. [CrossRef]
[PubMed]
Yoshida, S.; Shiokawa, S.; Kawano, K.I.; Ito, T.; Murakami, H.; Suzuki, H.; Sato, Y. Orally Active Benzoxazole
Derivative as 5-HT3 Receptor Partial Agonist for Treatment of Diarrhea-Predominant Irritable Bowel
Syndrome. J. Med. Chem. 2005, 48, 7075–7079. [CrossRef] [PubMed]
O’Donnell, C.J.; Rogers, B.N.; Bronk, B.S.; Bryce, D.K.; Coe, J.W.; Cook, K.K.; Duplantier, A.J.; Evrard, E.;
Hajós, M.; Hoffmann, W.E.; et al. Discovery of 4-(5-Methyloxazolo[4,5-b]pyridin-2-yl)-1,4-diazabicyclo
[3.2.2]nonane (CP-810,123), a Novel
α7 Nicotinic Acetylcholine Receptor Agonist for the Treatment of
Cognitive Disorders in Schizophrenia: Synthesis, SAR Development, and in Vivo Efficacy in Cognition
Models. J. Med. Chem. 2010, 53, 1222–1237. [PubMed]
7.
Cox, C.D.; Breslin, M.J.; Whitman, D.B.; Schreier, J.D.; McGaughey, G.B.; Bogusky, M.J.;
Roecker, A.J.; Mercer, S.P.; Bednar, R.A.; Lemaire, W.; et al.
Discovery of the Dual Orexin
Receptor Antagonist [(7R)-4-(5-Chloro-1,3-benzoxazol-2-yl)-7-methyl-1,4-diazepan-1-yl] [5-methyl-2-(2H
-1,2,3-triazol-2-yl)phenyl] methanone (MK-4305) for the Treatment of Insomnia. J. Med. Chem. 2010, 53,
5320–5332. [CrossRef] [PubMed]
8.
9.
Cho, S.H.; Kim, J.Y.; Lee, S.Y.; Chang, S. Silver-Mediated Direct Amination of Benzoxazoles: Tuning the
Amino Group Source from Formamides to Parent Amines. Angew. Chem. Int. Ed. 2009, 48, 9127–9130.
[CrossRef] [PubMed]
Kim, J.Y.; Cho, S.H.; Joseph, J.; Chang, S. Cobalt- and Manganese-Catalyzed Direct Amination of Azoles
under Mild Reaction Conditions and the Mechanistic Details. Angew. Chem. Int. Ed. 2010, 122, 10095–10099.
[CrossRef]
10. Monguchi, D.; Fujiwara, T.; Furukawa, H.; Mori, A. Direct Amination of Azoles via Catalytic C–H, N–H
Coupling. Org. Lett. 2009, 11, 1607–1610. [CrossRef] [PubMed]
11. Wang, Q.; Schreiber, S.L. Copper-Mediated Amidation of Heterocyclic and Aromatic C–H Bonds. Org. Lett.
2009, 11, 5178–5180. [CrossRef] [PubMed]
12. Miyasaka, M.; Hirano, K.; Satoh, T.; Kowalczyk, R.; Bolm, C.; Miura, M. Copper-Catalyzed Direct
Sulfoximination of Azoles and Polyfluoroarenes under Ambient Conditions. Org. Lett. 2011, 13, 359–361.
[CrossRef] [PubMed]
13. Kawano, T.; Hirano, K.; Satoh, T.; Miura, M. A New Entry of Amination Reagents for Heteroaromatic C-H
Bonds: Copper-Catalyzed Direct Amination of Azoles with Chloroamines at Room Temperature. J. Am.
Chem. Soc. 2010, 132, 6900–6901. [CrossRef] [PubMed]
14. Matsuda, N.; Hirano, K.; Satoh, T.; Miura, M. Copper-Catalyzed Direct Amination of Electron-Deficient
Arenes with Hydroxylamines. Org. Lett. 2011, 13, 2860–2863. [CrossRef] [PubMed]

Molecules 2017, 22, 576
8 of 9
15. Xie, Y.J.; Qian, B.; Xie, P.; Huang, H.M. Cooperative Catalysis with Aldehydes and Copper: Development
and Application in Aerobic Oxidative CH Amination at Room Temperature. Adv. Synth. Catal. 2013, 355,
1315–1322. [CrossRef]
16. Wertz, S.; Kodama, S.; Studer, A. Cooperative Catalysis with Aldehydes and Copper: Development and
Application in Aerobic Oxidative CH Amination at Room Temperature. Angew. Chem. Int. Ed. 2011, 50,
11511–11515. [CrossRef] [PubMed]
17. Wang, J.; Hou, J.T.; Wen, J.; Yu, X.Q. Iron-catalyzed direct amination of azoles using formamides or amines
as nitrogen sources in air. Chem. Commun. 2011, 47, 3652–3654. [CrossRef] [PubMed]
18. Xu, J.; Li, J.R.; Wei, Z.; Zhang, Q.; Shi, D.X. Direct amination of azoles using CuCl2 complexes of amines
under mild conditions. RSC. Adv. 2013, 3, 9622–9624. [CrossRef]
19. Li, Y.M.; Liu, J.; Xie, Y.S.; Zhang, R.; Jin, K.; Wang, X.N.; Duan, C.Y. Nickel-catalyzed C–H direct amination of
benzoxazoles with secondary Amines. Org. Biomol. Chem. 2012, 10, 3715–3720. [CrossRef] [PubMed]
20. Cioffi, C.L.; Lansing, J.J.; Yüksel, H. Synthesis of 2-Aminobenzoxazoles Using Tetramethyl Orthocarbonate
or 1,1-Dichlorodiphenoxymethane. J. Org. Chem. 2010, 75, 7942–7945. [CrossRef] [PubMed]
21. Parumala, S.K.R.; Peddinti, R.K. Iodine catalyzed cross-dehydrogenative C–S coupling by C(sp2)–H bond
activation: Direct access to aryl sulfides from aryl thiols. Green Chem. 2015, 17, 4068–4072. [CrossRef]
22. Yang, K.; Ke, M.L.; Lin, Y.G.; Song, Q.L. Sulfonamide formation from sodium sulfinates and amines or
ammonia under metal-free conditions at ambient temperature. Green Chem. 2015, 17, 1395–1399. [CrossRef]
23. Zhang, X.B.; Wang, L. TBHP/I2-promoted oxidative coupling of acetophenones with amines at room
temperature under metal-free and solvent-free conditions for the synthesis of α-ketoamides. Green Chem.
2012, 14, 2141–2145. [CrossRef]
24. Huang, H.; Chen, W.H.; Xu, Y.; Li, J. I /TBHP catalyzed Csp3–N/Csp2–N bond formation via oxidative
−
coupling with benzophenone imine in water. Green Chem. 2015, 17, 4715–4719. [CrossRef]
25. Zeng, J.W.; Liu, Y.C.; Hsieh, P.A.; Huang, Y.T.; Yi, C.L.; Badsara, S.S.; Lee, C.F. Metal-free cross-coupling
reaction of aldehydes with disulfides by using DTBP as an oxidant under solvent-free conditions. Green
Chem. 2014, 16, 2644–2652. [CrossRef]
26. Wen, J.W.; Wei, W.; Xue, S.N.; Yang, D.S.; Lou, Y.; Gao, C.Y.; Wang, H. Metal-Free Oxidative Spirocyclization
of Alkynes with Sulfonylhydrazides Leading to 3-Sulfonated Azaspiro[4,5]trienones. J. Org. Chem. 2015, 80,
4966–4972. [CrossRef] [PubMed]
27. Panda, N.; Mattan, I.; Nayak, D.K. Synthesis of Dibenzofurans via C H Activation of o-Iodo Diaryl Ethers.
−
J. Org. Chem. 2015, 80, 6590–6597. [CrossRef] [PubMed]
28. Tinnis, F.; Stridfeldt, E.; Lundberg, H.; Adolfsson, H.; Olofsson, B. Metal-Free N-Arylation of Secondary
Amides at Room Temperature. Org. Lett. 2015, 17, 2688–2691. [CrossRef] [PubMed]
29. Danneman, M.W.; Hong, K.B.; Johnston, J.N. Oxidative Inter-/Intermolecular Alkene Diamination of
Hydroxy Styrenes with Electron-Rich Amines. Org. Lett. 2015, 17, 2558–2561. [CrossRef] [PubMed]
30. Joseph, J.; Kim, J.Y.; Chang, S. A Metal-Free Route to 2-Aminooxazoles by Taking Advantage of the Unique
Ring Opening of Benzoxazoles and Oxadiazoles with Secondary Amines. Chem. Eur. J. 2011, 17, 8294–8298.
[CrossRef] [PubMed]
31. Wagh, Y.S.; Tiwari, N.J.; Bhanage, B.M. Metal-free synthesis of 2-aminobenzoxazoles using hypervalent
iodine reagent. Tetrahedron Lett. 2013, 54, 1290–1293. [CrossRef]
32. Lamani, M.; Prabhu, K.R. Iodine-Catalyzed Amination of Benzoxazoles: A Metal-Free Route to
2-Aminobenzoxazoles under Mild Conditions. J. Org. Chem. 2011, 76, 7938–7944. [CrossRef] [PubMed]
33. Froehr, T.; Sindlinger, C.P.; Kloeckner, U.; Finkbeiner, P.; Nachtsheim, B.J. A Metal-Free Amination of
Benzoxazoles The First Example of an Iodide-Catalyzed Oxidative Amination of Heteroarenes. Org. Lett.
2011, 13, 3754–3757. [CrossRef] [PubMed]
34. Gao, W.J.; Li, W.C.; Zeng, C.C.; Tian, H.Y.; Hu, L.M.; Little, R.D. Electrochemically Initiated Oxidative
Amination of Benzoxazoles Using Tetraalkylammonium Halides as Redox Catalysts. J. Org. Chem. 2014, 79,
9613–9618. [CrossRef] [PubMed]
35. Wagh, Y.S.; Sawant, D.N.; Bhanage, B.M. Metal-free N-iodosuccinimide-catalyzed mild oxidative C–H bond
amination of benzoxazoles. Tetrahedron Lett. 2012, 53, 3482–3485. [CrossRef]
36. Wang, R.; Liu, H.; Yue, L.; Zhang, X.K.; Tan, Q.Y.; Pan, R.L. Transition metal-free direct amination of
benzoxazoles using formamides as nitrogen sources. Tetrahedron Lett. 2014, 55, 2233–2237. [CrossRef]

Molecules 2017, 22, 576
9 of 9
37. Wang, X.; Xu, D.Q.; Miao, C.X.; Zhang, Q.H.; Sun, W. N-Bromosuccinimide as an oxidant for
the transition-metal-free synthesis of 2-aminobenzoxazoles from benzoxazoles and secondary amines.
Org. Biomol. Chem. 2014, 12, 3108–3113. [CrossRef] [PubMed]
38. Yotphan, S.; Beukeaw, D.; Reutrakul, V. A Convenient One-Pot Synthesis of N-Substituted 2-Aminoazole
Derivatives. Synthesis 2013, 45, 936–942. [CrossRef]
39. Martins, M.P.; Frizzo, C.; Moreira, D.; Zanatta, N.; Bonacorso, H. Ionic Liquids in Heterocyclic Synthesis.
Chem. Rev. 2008, 108, 2015–2050. [CrossRef] [PubMed]
40. Zhang, Q.; Shreeve, J.M. Energetic Ionic Liquids as Explosives and Propellant Fuels: A New Journey of Ionic
Liquid Chemistry. Chem. Rev. 2014, 114, 10527–10574. [CrossRef] [PubMed]
41. Zhang, Q.; Zhang, S.; Deng, Y. Recent advances in ionic liquid catalysis. Green Chem. 2011, 13, 2619–2637.
[CrossRef]
42. Giernoth, R. Task-Specific Ionic Liquids. Angew. Chem. Int. Ed. 2010, 49, 2834–2839. [CrossRef] [PubMed]
43. Taheri, A.; Liu, C.H.; Lai, B.B.; Cheng, C.; Pan, X.J.; Gu, Y.L. Brønsted acid ionic liquid catalyzed facile
synthesis of 3-vinylindoles through direct C3 alkenylation of indoles with simple ketones. Green Chem. 2014
16, 3715–3719. [CrossRef]
,
44. Glasnov, T.N.; Holbrey, J.D.; Kappe, C.O.; Seddon, K.R.; Yan, T. Methylation using dimethylcarbonate
catalysed by ionic liquids under continuous flow conditions. Green Chem. 2012, 14, 3071–3076. [CrossRef]
45. Li, J.X.; Yang, W.F.; Yang, S.R.; Huang, L.B.; Wu, W.Q.; Sun, Y.D.; Jiang, H.F. Palladium-Catalyzed Cascade
Annulation to Construct Functionalized
7219–7222. [CrossRef] [PubMed]
β- and γ-Lactones in Ionic Liquids. Angew. Chem. Int. Ed. 2014, 53,
46. Ehlers, P.; Petrosyan, A.; Baumgard, J.; Jopp, S.; Steinfeld, N.; Ghochikyan, T.V.; Saghyan, A.S.; Fischer, C.;
Langer, P. Synthesis of 2,5-Diarylpyrroles by Ligand-Free Palladium-Catalyzed CH Activation of Pyrroles in
Ionic Liquids. ChemCatChem 2013, 5, 2504–2511. [CrossRef]
47. Baslé, O.; Borduas, N.; Dubois, P.; Chapuzet, J.M.; Chan, T.H.; Lessard, J.; Li, C.J. Aerobic and Electrochemical
Oxidative Cross-Dehydrogenative-Coupling (CDC) Reaction in an Imidazolium-Based Ionic Liquid.
Chem. Eur. J. 2010, 16, 8162–8166. [CrossRef] [PubMed]
48. Biffis, A.; Gazzola, L.; Tubaro, C.; Basato, M. Alkyne Hydroarylation in Ionic Liquids Catalyzed by
Palladium(II) Complexes. ChemSusChem 2010, 3, 834–839. [CrossRef] [PubMed]
49. Li, J.X.; Yang, S.R.; Jiang, H.F.; Wu, W.Q.; Zhao, J.W. Palladium-Catalyzed Coupling of Alkynes with
Unactivated Alkenes in Ionic Liquids: A Regio-and Stereoselective Synthesis of Functionalized 1,6-Dienes
and Their Analogues. J. Org. Chem. 2013, 78, 12477–12486. [CrossRef] [PubMed]
50. Li, H.; Liu, C.J.; Zhang, Y.H.; Sun, Y.D.; Wang, B.; Liu, W.B. Green Method for the Synthesis
of Chromeno[2,3-c]pyrazol-4(1H)-ones through Ionic Liquid Promoted Directed Annulation of
5-(Aryloxy)-1H-pyrazole-4-carbaldehydes in Aqueous Media. Org. Lett. 2015, 17, 932–935. [CrossRef]
[PubMed]
51. Liu, W.B.; Liu, C.J.; Zhang, Y.H.; Sun, Y.D.; Abdukadera, A.; Wang, B.; Li, H.; Ma, X.C.; Zhang, Z.P. Reusable
ionic liquid-catalyzed oxidative coupling of azoles and benzylic compounds via sp3 C–N bond formation
under metal-free conditions. Org. Biomol. Chem. 2015, 13, 7154–7158. [CrossRef] [PubMed]
Sample Availability: All samples are available from the authors.
©
2017 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
