Synthesis and X-ray structural studies of Cd(II) and Ni(II) complexes
of 5-(4-methoxy phenyl), 5-(2-pyridyl) and 5-(2-methoxy phenyl)-
1,3,4-oxadiazole-2-thione
⇑
⇑
M.K. Bharty , A. Bharti, R.K. Dani, R. Dulare, P. Bharati, N.K. Singh
Department of Chemistry, Banaras Hindu University, Varanasi 221005, India
a r t i c l e i n f o
a b s t r a c t
Article history:
Three new mixed ligand complexes [Cd(en)2(4-mpot)2] (1) [Ni(2-pytone)2(en)2] (2) and [Ni(2-mpo-
t)2(en)2] (3) {4-mpot = 5-(4-methoxy-phenyl)-1,3,4-oxadiazole-2-thione, 2-pytone = 5-(2-pyridyl)-1,3,4-
oxadiazole-2-thione, 2-mpot = 5-(2-methoxy-phenyl)-1,3,4-oxadiazole-2-thione} have been prepared
containing en as co-ligand. Potassium N-(4-methoxy benzoyl)-hydrazinecarbodithioate cyclized to 5-
(4-methoxy-phenyl)-1,3,4-oxadiazole-2-thiol on addition of tetrabutylammonium bromide which then
reacted with Cd(OAc)2ꢀ2H2O and ethylenediamine to form complex 1, whereas potassium N-(2-methoxy
benzoyl/pyridine-2-carbonyl)-hydrazinecarbodithioates (RCONHNHCSSK) underwent cyclization during
complexation in the presence of en to give the complexes of the corresponding 5-aryl-1,3,4-oxadiaz-
ole-2-thiones. The complexes have been characterized by physicochemical techniques and single crystal
X-ray structure determination. In the complexes the metal center has a six coordinate octahedral
arrangement coordinated by 4N atoms of two en and two covalently bonded N atoms of the oxadiaz-
ole-2-thione anions. All the complexes contain extended hydrogen bonding providing supramolecular
framework.
Received 6 September 2011
Received in revised form 7 December 2011
Accepted 8 December 2011
Available online 21 December 2011
Keywords:
5-Aryl-1,3,4-oxadiazole-2-thiones
Mixed ligand complexes
Cd(II) and Ni(II) complexes
Supramolecular architecture
Ó 2011 Elsevier B.V. All rights reserved.
1. Introduction
investigate the bonding mode of the ligand in the complexes. In
view of this, we have prepared and characterized the Cd(II) complex
The coordination chemistry of nitrogen–sulfur chelating ligands
is an emerging and rapidly developing area of research [1–3]. The
multifaceted chemistry of metal sulfur bonds are apparent in the
application of these compounds as catalyst in biological and non-
biological processes [4,5]. A class of nitrogen sulfur ligand such as
N-aroyl dithiocarbazates and their salts could be converted to
1,3,4-oxadiazole-2-thione, which are biologically important mole-
cules [6–8]. The oxadiazole molecules act as spacer via coordination,
hydrogen bonding and show intermolecular cooperative interaction
[9]. 1,3,4-oxadiazole derivatives, which belong to an important
group of heterocyclic compounds is the subject of extensive study
in the recent years [7,8]. They show diverse biological activities,
such as anti-tuberculostatic, anti-inflammatory, anti-fungal, anal-
gesic, and anti-convulsant [10–12]. Although some work has been
reported on the binary complexes of 5-phenyl-1,3,4-oxadiazole-2-
thione [13], 5-(4-pyridyl)-1,3,4-oxadiazole-2-thione [14–19] and
5-(2-pyridyl)-1,3,4-oxadiazole-2-thione [20], but scanty of infor-
mation is available on the mixed ligand complexes of these ligands.
Since 1,3,4-oxadiazole-2-thiones may exist in both thione and
thiol forms in solution [21,22], it will therefore be of interest to
of 5-(4-methoxy-phenyl)-1,3,4-oxadiazole-2-thione and Ni(II)
complexes of 5-(2-pyridyl)-1,3,4-oxadiazole-2-thione and 5-(2-
methoxy-phenyl)-1,3,4-oxadiazole-2-thione in the presence of
ethylenediamine which act as a co-ligand.
2. Experimental
2.1. Chemical and starting materials
Commercial reagents were used without further purification
and all experiments were carried out in open atmosphere. Picolinic
acid hydrazide (Sigma–Aldrich), CS2 (S D Fine Chemicals, India) and
KOH (Qualigens) were used as received. 2-Methoxy benzoic acid
hydrazide and [Ni(en)2(SCN)2] were prepared by reported methods
[23,24]. All the solvents were purchased from Merck and used after
purification. The yield calculation is based on the weight of the li-
gand or the initial starting material where intermediate were not
isolated.
2.2. Physical measurements
Carbon, hydrogen and nitrogen contents were estimated on a
Carlo Erba 1108 model microanalyser. Magnetic susceptibility
measurements were performed at room temperature on a Cahn
⇑
Corresponding authors. Tel.: +91 5426702452; fax: +91 5422368127.
E-mail addresses: mkbharty@bhu.ac.in (M.K. Bharty), singhnk_bhu@yahoo.com
(N.K. Singh).
0022-2860/$ - see front matter Ó 2011 Elsevier B.V. All rights reserved.
doi:10.1016/j.molstruc.2011.12.015

M.K. Bharty et al. / Journal of Molecular Structure 1011 (2012) 34–41
35
Faraday balance using Hg[Co(NCS)4] as the calibrant. Electronic
spectra were recorded on a Shimadzu 1700 UV–Vis spectropho-
tometer as Nujol mulls. IR spectra were recorded in the 4000–
400 cmꢁ1 region as KBr pellets on a Varian Excalibur 3100-FT IR
spectrophotometer. 1H and 13C NMR spectra were recorded in
DMSO-d6 and CDCl3 on a JEOL AL 300 FT NMR spectrometer using
TMS as internal reference.
diagrams were generated by use of the ORTEP-3 for windows pro-
gram [28].
2.4. Synthesis
2.4.1. Synthesis of tetrabutylammonium 5-(4-methoxy phenyl)-1,3,4-
oxadiazole-2-thiol
Tetrabutylammonium 5-(4-methoxy-phenyl)-1,3,4-oxadiazole-
2-thiol was synthesized by adding CS2 (1.5 mL, 20 mmol) dropwise
to a suspension of 4-methoxy benzoic acid hydrazide (3.32 g,
20 mmol) in methanol (30 mL) in the presence of potassium
hydroxide (1.2 g, 20 mmol) and stirring the reaction mixture for
30 min at room temperature. The yellow solid product obtained
in the above reaction was dissolved in water and an aq. solution
of tetrabutylammonium bromide (3.22 g, 10 mmol) was added.
The resulting yellow solid was obtained which was filtered off
and dried. Yield (1.625 g, 60 %). Anal. Found: C, 66.72; H, 9.55; N,
9.30; S, 7.05 %. Calc. for C25H43N3O2S (449.69): C, 66.77; H, 9.63;
2.3. X-ray crystallography
Crystals suitable for X-ray analyses of the complexes 1, 2 and 3
were grown at room temperature. Data for complexes 1, 2 and 3
were recorded at 293(2) and 296(2) on an Oxford Diffraction Gem-
ini [25] and a Bruker three-circle diffractometer, respectively
equipped with a CrysAlis Pro./SMART 6000 CCD software using a
graphite mono-chromated MoKa (k = 0.71073 Å) radiation source.
The structures were solved by direct methods and refined (SHELX-
08) against all data by full matrix least-square on F2 using aniso-
tropic displacement parameters for all non-hydrogen atoms. All
hydrogen atoms were included in the refinement at geometrically
ideal position and refined with a riding model [26]. The MERCURY
package was used for molecular graphics [27]. Molecular structure
N, 9.34; S, 7.13 %. M.p.105 °C; IR (KBr,
m m(C@N),
, cmꢁ1): 1602s
1066s (NAN), 988s
m
m
(C@S). 1H NMR (CDCl3, TMS; d, ppm): 10.8
(s, 1H, NH), 3.80 (s, 3H, OCH3), 7.0–7.7 (m, 4H, C6H5), 1.0 (t, 3H,
CH3), 1.4 (sext, 2H, CH2), 1.6 (quint., 2H, CH2) 3.3 (t, 2H, NACH2).
13C NMR (CDCl3; d, ppm): 197.15 (CAS), 160.38 (C@N), 113.92
O
H
O
S-K+
N
NH2
N
H
CS2
MeOH
KOH
N
H
S
H3CO
O
H3CO
Tetrabutyl ammonium bromide
n-Bu
S
1
4
5
3
8
n-Bu
N
2
N
N
H3CO
n-Bu
6
9
7
n-Bu
.
Cd(OAc)2 2H2O
H2N
NH2
S
OCH3
O
N
N
O
N
en
Cd
Light yellow ppt
N
H3CO
NH2
H2N
S
Scheme 1. Synthesis of tetrabutylammonium 5-(4-methoxy phenyl)-1,3,4-oxadiazole-2-thiol and Cd(II) complex.
O
H
N
4
S-K+
O
3
1
5
6
N
H
2
NH2
+ CS2 + KOH
N
S
N
H
[K+(H2L)-]
N
7
Ni(OAc)2.4H2O
N
S
H2N
NH2
N
en
Brown ppt
N
O
MeOH
Ni
N
O
N
H2N
NH2
S
N
Scheme 2. Preparation of [Ni(2-pytone)2(en)2] (1).
