2474
Helvetica Chimica Acta – Vol. 95 (2012)
Synthesis of AzaaromaticꢀBorane Intramolecular Complexes by Palladium-
Catalyzed Reaction of Azaaromatic Halides with Alkynyl(triaryl)borates
by Naoki Ishida, Mizuna Narumi, and Masahiro Murakami*
Department of Synthetic Chemistry and Biological Chemistry, Kyoto University, Katsura,
Kyoto 615-8510, Japan
(phone: þ 81-75-383-2747; fax: þ 81-75-383-2748; e-mail: murakami@sbchem.kyoto-u.ac.jp)
Dedicated to Professor Dieter Seebach on the occasion of his 75th birthday
A diversity-oriented method to synthesize (E)-azastilbenes having an intramolecular BꢀN
coordination bond from alkynyl(triaryl)borates and azaaromatic halides is described. The obtained p-
conjugated compounds exhibit an intense blue fluorescence and a high electron affinity, indicating their
potential to be used as n-type light-emitting materials.
Introduction. – Aza-p-conjugated compounds equipped with an intramolecular
BꢀN coordination bond have attracted growing attention because of their interesting
properties such as a high electron affinity [1], an intense fluorescence [2], and
photochromism [3][4]. The conventional methods for their synthesis typically consist
of initial lithiation of a parent N-containing p-conjugated framework and the following
nucleophilic substitution reaction with haloboranes. However, electron-deficient
azaaromatics such as isoquinolines and pyrazines are prone to undergo undesired side
reactions upon treatment with lithiating agents [5]. A new method for the synthesis of a
wide variety of azaaromaticꢀborane complexes is yet to be developed [6].
We previously developed the Pd-catalyzed reaction of alkynyl(aryl)borates (aryl ¼
Ar1) with aryl halides (aryl ¼ Ar2) [7]. Two aryl groups, Ar1 and Ar2, were incorporated
across the CꢁC bond to produce (trisubstituted alkenyl)boranes. This protocol was
successfully applied to the synthesis of amineꢀborane complexes [8] and pyridine N-
oxideꢀborane complexes [9]. Herein, we describe a diversity-oriented method for the
synthesis of (E)-azastilbene derivatives having an intramolecular BꢀN coordination
bond from alkynyl(triaryl)borates and azaaromatic halides. The obtained p-conjugated
compounds exhibit an intense blue fluorescence and a high electron affinity,
demonstrating their potential to be used as n-type light-emitting materials.
Results and Discussion. – 2-Bromoquinoline (1a) and alkynylborate 2a were
reacted under the slightly modified conditions of the previously reported Pd-catalyzed
reaction [7b][9]1). A toluene solution (1 ml) of 1a (0.20 mmol), 2a (0.20 mmol), and
(DPEPhos)Pd(p-allyl)Cl (DPEPhos ¼ bis[2-(diphenylphosphino)phenyl]ether¼ (ox-
ydi-2,1-phenylene)bis(diphenylphosphine); 5 mol-%) was heated at 608 for 5 h
1
)
The preliminary screening of ligands revealed that DPEPhos gave a result superior to other ligands
such as XANTPhos, BINAP, and DPPF.
ꢀ 2012 Verlag Helvetica Chimica Acta AG, Zꢁrich

Helvetica Chimica Acta – Vol. 95 (2012)
2475
(Scheme 1). The reaction efficiently took place, and the following chromatography
afforded analytically pure quinolineꢀborane complex 3 in 88% yield.
Scheme 1
The broad scope of this Pd-catalyzed reaction was compiled in Table 1. Not only 2-
bromoquinoline (1a), but also 8-bromoquinoline (1b) participated in the reaction to
furnish six-membered azaboracycle 4 in 81% yield (Entry 1). Isoquinoline, pyrimidine,
and pyrazine moieties were all suitably and underwent the present reaction (Entries 2 –
5), whereas these are prone to decompose upon lithiation [5]. The alkynylborates 2d –
2f, which are equipped with various aryl groups, undergoing the Pd-catalyzed reaction,
afforded the corresponding azaaromaticꢀborane complexes 10 – 12 (Entries 7 – 9).
Excellent functional-group compatibility was demonstrated by the reaction of 2-
bromopyridines bearing functional groups which were potentially reactive towards Pd
catalysts. The pinacolatoboryl moiety was tolerated on the pyridine ring, yielding
pinacolatoboryl-substituted pyridineꢀborane complex 13 in 82% yield (Scheme 2).
When 2 equiv. of 2,5-dibromopyridine 1i was used, the 2-Br group reacted in
preference to the 5-Br group, as was the case with the Pd-catalyzed cross-coupling
reactions (Scheme 3) [10]. The 5-bromopyridineꢀborane complex 14 was obtained in
78% yield. These boryl and Br groups remaining in the products served as footholds for
the subsequent SuzukiꢀMiyaura cross-coupling reaction. Treatment of 13 and 14 with a
catalytic amount of Pd[P(t-Bu)3]2 in the presence of NaOH in THF/H2O provided
bipyridne 15 in 84% yield (Scheme 4).
Scheme 2
Thus, a wide variety of azaaromaticꢀborane intramolecular complexes were
successfully synthesized through the Pd-catalyzed reaction of alkynylborates with
azaaromatic halides. We next examined the electrochemical properties of the
quinolineꢀborane complex 3 to demonstrate a high electron affinity of the products.
Table 2 contains its characteristic properties in comparison with Alq (¼tris(8-
hydroxyquinolinato)aluminum), the most conventional fluorescent material with a
high electron affinity. The cyclic voltammogram of quinolineꢀborane complex 3
showed a reversible reduction wave with the potential peak Vpc of ꢀ 1.80 V, which was

2476
Helvetica Chimica Acta – Vol. 95 (2012)
Table 1. Aza-p-Conjugated Compounds Having BꢀN Coordination Bonda)
Entry Azaaromatic
halides 1
Alkynylborates 2
Products
Yield
[%]
1
1b
2a
4
84
2
1c
2a
5
81
3
4
1d
1e
2a
2b
6
7
80
67
5
1f
2b
8
43
6
7
1g
1a
2c
9
87
89
2d
10

Helvetica Chimica Acta – Vol. 95 (2012)
2477
Table 1 (cont.)
Entry Azaaromatic
halides 1
Alkynylborates 2
Products
Yield
[%]
8
1a
2e
11
66
9
1a
2f
12
84
a) Reaction conditions: 1.0 equiv. of aryl halide, 1.0 equiv. of alkynylborate, 5 mol-% (DPEPhos)Pd(p-allyl)Cl,
toluene (0.2m), 608, 5 h.
Scheme 3
Scheme 4
less negative than that of Alq (ꢀ2.14 V under the same conditions). The LUMO level
of 3 was calculated as 3.8 eV, which was significantly higher than that of Alq (3.0 eV).
These results indicate that 3 has an even higher electron affinity than Alq. The
photophysical properties are also compiled in Table 2. The quinolineꢀborane complex
3 showed a sky blue fluorescence (lmax 473 nm in CH2Cl2) with the quantum yield of
0.26, whereas Alq exhibited a green fluorescence (lmax 526 nm, F 0.17) [11]. These
electrochemical and photochemical properties demonstrated the potential usefulness
of this class of molecules as the n-type blue light-emitting materials.

2478
Helvetica Chimica Acta – Vol. 95 (2012)
Table 2. Photophysical and Electrochemical Properties of 3
Compounds
Vpc/Va)
HOMO/eVb)
LUMO/eVc)
lem/nm
F
3
Alq
ꢀ 1.80
ꢀ 2.14
6.6
5.7
3.8
3.0
473d)
526e)
0.26d)
0.17e)
a) In g-butyrolactone with Bu4NClO4 at a scan rate of 100 mVsꢀ1. Potentials vs. Fc/Fcþ. b) Determined by
c
e
UPS. ) Calculated from the HOMO and the UVabsorption edge. d) Taken from [8]. ) Taken from [11].
In summary, we have synthesized (E)-azastilbenes having an intramolecular BꢀN
coordination by the Pd-catalyzed reaction of azaaromatic halides with alkynyl(tri-
aryl)borates. This method is versatile enough to incorporate a wide variety of aza-
aromatics including those vulnerable to the conventional lithiating conditions. The
obtained p-conjugated compounds exhibit a strong fluorescence and a high electron
affinity, i.e., with a potential to be used as the n-type light-emitting materials.
This work was supported in part by NEDO and a Grant-in-Aid for Scientific Research from MEXT.
Experimental Part
General. Unless otherwise noted, all chemicals and anh. solvents were obtained from commercial
suppliers. Toluene was dried over sodium benzophenone ketyl. (DPEPhos)Pd(p-allyl)Cl [12] and
alkynyl borates 2 [9] were prepared according to the reported procedures. Column chromatography
(CC): silica gel 60 N (Kanto). Prep. TLC: Silica gel 60 PF254 (Merck). Gel permeation chromatography
(GPC): Japan Analytical Industry LC-908 or LC-9204. NMR Spectra: Varian Gemini 2000 (1H: 300 and
13C: 75 MHz), Varian Mercury vx (1H: 400 and 13C: 100 MHz), JEOL JNM-A500 (1H: 500 and 13C:
150 MHz), or Varian 400-MR Auto Tune X5 (11B: 128 MHz) spectrometers; unless otherwise noted,
CDCl3 was used as a solvent; chemical Shifts in d ppm referenced to a residual CDCl3 (d 7.26 for 1H, d
1
77.0 for 13C), CD3CN (d 1.94 for H, d 1.32 for 13C), and BF3 · OEt2 (d 0.00 for 11B). HR-MS: Applied
Biosystems Voyager Elite or JEOL JMS-HX110A spectrometer.
Alkynylborate 2b. 1H-NMR (CD3CN): 2.22 (s, 1 H); 3.00 (s, 12 H); 7.24 – 7.30 (m, 3 H); 7.37 – 7.43 (m,
12 H); 7.53 (d, J ¼ 7.2, 6 H); 7.62 (d, J ¼ 7.8, 6 H). 13C-NMR (CD3CN): 56.0; 125.5; 127.1; 127.4; 129.5;
135.9; 136.1; 143.4. 11B-NMR (CD3CN): ꢀ 12.6. HR-FAB-MS: 495.2293 ([M ꢀ (Me4N)]ꢀ, C38H28Bꢀ;
calc. 495.2284).
Alkynylborate 2f. 1H-NMR (CD3CN): 2.21 (s, 1 H); 2.92 (s, 12 H); 6.90 – 6.91 (m, 6 H); 7.13 – 7.14 (m,
6 H). 13C-NMR (CD3CN): 56.0; 124.5; 127.2; 128.6. 11B-NMR (CD3CN): ꢀ 18.0. HR-FAB-MS: 285.0031
([M ꢀ (Me4N)]ꢀ, C14H10BSꢀ3 ; calc.285.0038).
Pd-Catalyzed Reaction of 2-Bromoquinoline (1a) with Alkynylborate 2a. A Typical Procedure. In an
oven-dried flask was placed (DPEPhos)Pd(p-allyl)Cl (3.6 mg, 5 mmol) and 2a (34.7 mg, 0.10 mmol).
The flask was then evacuated and purged by Ar three times. A toluene soln. (0.5 ml) of 2-
bromoquinoline (21.2 mg, 0.10 mmol) was added to the flask, and then the mixture was stirred at 608.
After 5 h, H2O was added. The resulting mixture was extracted with CH2Cl2 (3 ꢂ ), washed with H2O
(once), brine (once), dried (MgSO4), and concentrated. The residue was purified by prep. TLC to give
quinolineꢀborane complex 3 (34.8 mg, 0.088 mmol, 88% yield). The spectra of the obtained 3 were
identical to the reported data [8].
QuinolineꢀBorane Complex 4. 1H-NMR (CDCl3): 7.03 – 7.19 (m, 12 H); 7.32 – 7.35 (m, 4 H); 7.43 (dd,
J ¼ 8.4, 6.0, 1 H); 7.66 – 7.68 (m, 3 H); 8.33 (dd, J ¼ 8.1, 1.5, 1 H); 8.79 (dd, J ¼ 8.4, 2.1, 1 H). 13C-NMR
(CDCl3): 121.0; 124.88; 124.94; 125.2; 125.9; 127.1; 127.3; 127.9; 129.1; 129.4; 130.0; 133.6; 134.0; 138.7;
141.0; 146.0; 149.5. Two kinds of C-atoms bound to B-atom were not detected due to quadrupolar
relaxation. 11B-NMR (CDCl3): 1.7. HR-EI-MS: 395.1848 (Mþ, C29H22BNþ; calc. 395.1845).

Helvetica Chimica Acta – Vol. 95 (2012)
2479
IsoquinolineꢀBorane Complex 5. 1H-NMR (CDCl3): 7.18 – 7.42 (m, 14 H); 7.73 – 7.81 (m, 3 H); 7.84 –
7.87 (m, 2 H); 7.92 (s, 1 H); 8.10 (d, J ¼ 6.6, 1 H); 8.51 (d, J ¼ 7.5, 1 H). 13C-NMR (CDCl3): 117.8; 118.4;
123.8; 125.8; 126.8; 127.1; 127.5; 128.19; 128.21; 128.5; 128.8; 132.5; 133.8; 134.7; 137.0; 138.7; 160.8. Two
kinds of C-atoms bound to B-atom were not detected due to quadrupolar relaxation. 11B-NMR (CDCl3):
3.7. HR-APCI-MS: 396.1914 ([M þ H]þ, C29H23BNþ; calc. 396.1918).
1
IsoquinolineꢀBorane Complex 6. H-NMR (CDCl3): 7.09 – 7.22 (m, 10 H); 7.34 – 7.37 (m, 4 H); 7.43
(td, J ¼ 8.4, 0.9, 1 H); 7.58 – 7.61 (m, 2 H); 7.65 – 7.70 (m, 2 H); 7.75 – 7.79 (m, 2 H); 8.93 (s, 1 H). 13C-NMR
(CDCl3): 114.6; 121.3; 125.3; 125.8; 126.5; 127.0; 127.4; 127.8; 128.0; 128.2; 129.1; 133.2; 133.8; 138.3;
138.9; 147.2; 153.9. Two kinds of C-atoms bound to B-atom were not detected due to quadrupolar
relaxation. 11B-NMR (CDCl3): 3.8. HR-EI-MS: (C29H22BN (M)þ 395.1845) 395.1843.
PyrimidineꢀBorane Complex 7. 1H-NMR (CDCl3): 7.07 (dd, J ¼ 5.4, 4.8, 1 H); 7.29 – 7.63 (m, 26 H);
7.84 – 7.87 (m, 2 H); 8.52 (dd, J ¼ 6.6, 5.7, 1 H); 8.88 (dd, J ¼ 4.5, 2.1, 1 H). 13C-NMR (CDCl3): 115.1;
121.5; 126.4; 126.79; 126.88; 126.92; 127.0; 127.4; 128.6; 128.7; 129.4; 134.2; 136.6; 138.9; 140.4; 141.3;
142.1; 150.0; 161.2; 168.4. Two kinds of C-atoms bound to B-atom were not detected due to quadrupolar
relaxation. 11B-NMR (CDCl3): 2.9. HR-EI-MS: 574.2578 (Mþ, C42H31BNþ2 ; calc. 574.2583).
1
PyrazineꢀBorane Complex 8. H-NMR (CDCl3): 7.31 – 7.64 (m, 26 H); 7.83 (d, J ¼ 8.4), 8.27 (br. s,
1 H); 8.44 (br. s, 1 H); 9.01 (br. s, 1 H). 13C-NMR (CDCl3): 117.8; 126.5; 126.8; 126.91; 126.92; 127.0;
127.5; 128.6; 128.7; 129.1; 134.1; 135.8; 136.8; 139.1; 140.2; 140.4; 141.3; 141.9; 143.3; 146.4; 154.0; 185.3.
11B-NMR (CD3CN): 3.4. HR-ACPI-MS: 575.2650 ([M þ H]þ, C42H32BNþ2 ; calc. 575.2653).
1
PyridineꢀBorane Complex 9. H-NMR (CDCl3): 2.17 (s, 3 H); 7.03 – 7.05 (m, 1 H); 7.11 – 7.31 (m,
13 H); 7.48 (dt, J ¼ 8.4, 1.5, 1 H); 7.53 (d, J ¼ 8.0, 2 H); 7.93 (t, J ¼ 8.0, 1 H); 8.23 (d, J ¼ 5.6, 1 H).
13C-NMR (CDCl3): 11.8; 117.7; 119.5; 125.5; 126.1; 127.2; 127.5; 127.9; 128.3; 133.3; 140.3; 140.9; 143.1;
161.8. Two kinds of C-atoms bound to B-atom were not detected due to quadrupolar relaxation. 11B-
NMR (CDCl3): 3.4. HR-EI-MS: 359.1854 (Mþ, C26H22BNþ; calc. 359.1845).
QuinolineꢀBorane Complex 10. 1H-NMR (CDCl3): 3.73 (s, 6 H); 3.76 (s, 3 H); 6.73 – 6.79 (m, 6 H);
7.08 (s, 1 H); 7.27 (d, J ¼ 8.4, 4 H); 7.34 – 7.44 (m, 2 H); 7.46 – 7.50 (m, 2 H); 7.62 (d, J ¼ 8.8, 1 H); 7.79 (dd,
J ¼ 7.8, 1.0, 1 H); 7.92 (d, J ¼ 8.8, 1 H); 8.26 (d, J ¼ 8.8, 1 H). 13C-NMR (CDCl3): 54.8; 55.1; 113.0; 113.5;
118.1; 120.0; 122.8; 125.3; 126.1; 128.5; 126.1; 128.5; 129.9; 131.1; 131.8; 134.4; 140.8; 141.5; 157.5; 160.0;
162.1. Two kinds of C-atoms bound to B-atom were not detected due to quadrupolar relaxation. 11B-
NMR (CDCl3): 4.0. HR-EI-MS: 485.2164 (Mþ, C32H28BNO3þ ; calc. 485.2162).
QuinolineꢀBorane Complex 11. 1H-NMR (CDCl3): 6.81 – 6.95 (m, 6 H); 7.08 (s, 1 H); 7.18 – 7.23 (m,
4 H); 7.32 – 7.37 (m, 2 H); 7.42 – 7.49 (m, 2 H); 7.71 (d, J ¼ 8.7, 1 H); 7.76 – 7.79 (m, 1 H); 7.86 – 7.89 (m,
1 H); 8.39 (d, J ¼ 8.7, 1 H). 13C-NMR (CDCl3): 114.3 (d, J(C,F) ¼ 19.1); 115.2 (d, J(C,F) ¼ 21.3); 118.2;
121.9; 122.7; 126.0; 126.4; 128.8; 129.8 (d, J(C,F) ¼ 8.1); 131.6; 134.6 (d, J(C,F) ¼ 6.5); 135.2; 141.4; 141.6;
161.6 (d, J(C;F) ¼ 241.5); 162.0; 163.0 (d, J(C,F) ¼ 247.5). Two kinds of C-atoms bound to B-atom were
not detected due to quadrupolar relaxation. 11B-NMR (CDCl3): 3.6. HR-EI-MS: 449.1562 (Mþ,
C32H19BNFþ3 ; calc. 449.1563).
QuinolineꢀBorane Complex 12. 1H-NMR (CDCl3): 6.90 – 6.93 (m, 1 H); 7.02 – 7.05 (m, 3 H); 7.23 –
7.32 (m, 6 H); 7.37 (t, J ¼ 7.8, 1 H); 7.46 – 7.54 (m, 2 H); 7.74 (d, J ¼ 7.8, 1 H); 8.16 (d, J ¼ 8.4, 1 H); 8.22 (d,
J ¼ 8.1, 1 H). 13C-NMR (CDCl3): 118.1; 119.8; 122.4; 125.7; 126.3; 126.4; 127.2; 127.7; 128.0; 128.6; 130.4;
130.8; 131.6; 141.2; 141.8; 142.2; 161.4. 11B-NMR (CDCl3): 0.5. HR-EI-MS: 413.0545 (Mþ, C23H16BNSþ3 ;
calc. 413.0538).
PyridineꢀBorane Complex 13. 1H-NMR (CDCl3): 1.33 (s, 12 H); 7.19 – 7.29 (m, 10 H); 7.37 – 7.40 (m,
4 H); 7.51 (d, J ¼ 8.0, 1 H); 7.64 – 7.67 (m, 2 H); 8.23 (d, J ¼ 8.0, 1.2, 1 H); 8.63 (s, 1 H). 13C-NMR
(CDCl3): 24.8; 84.5; 118.7; 121.2; 125.7; 127.4; 128.1; 128.4; 128.5; 134.0; 138.5; 145.9; 148.7; 161.9. Three
kinds of C-atoms bound to B-atom were not detected due to quadrupolar relaxation. 11B-NMR (CDCl3):
3.3; 28.7. HR-ACPI-MS: 472.2611 ([M þ H]þ, C31H32B2NO2þ ; calc. 472.2614).
PyridineꢀBorane Complex 14. 1H-NMR (CDCl3): 7.17 – 7.38 (m, 15 H); 7.62 – 7.64 (m, 2 H); 7.90 (dd,
J ¼ 8.8, 2.0, 1 H); 8.36 (d, J ¼ 2.0, 1 H). 13C-NMR (CDCl3): 114.3; 120.1; 120.2; 126.1; 127.6; 128.2; 128.4;
128.7; 133.8; 138.2; 142.9; 144.2; 148.4; 159.0; 183.3. 11B-NMR (CDCl3): 4.2. HR-ACPI-MS: 424.0857
([M þ H]þ, C25H20BNBrþ; calc. 424.0867).
PyridineꢀBorane Complex 15. In an oven-dried flask was placed 13 (23.6 mg, 0.050 mmol), 14
(21.2 mg, 0.050 mmol), and NaOH (6.5 mg, 1.5 mmol). The flask was then evacuated and purged by Ar

2480
Helvetica Chimica Acta – Vol. 95 (2012)
three times. A THF soln. (0.5 ml) of Pd[P(t-Bu)3]2 (1.3 mg, 2.5 mmol) and subsequently H2O (5 ml) were
added, and then the mixture was stirred at 608. After 1 h, H2O was added. The mixture was extracted with
CH2Cl2 (3 ꢂ ), washed with H2O (once), brine (once), dried (MgSO4), and concentrated. The residue
1
was purified by prep. TLC, and GPC to gave 15 (28.9 mg, 0.042 mmol, 84% yield). H-NMR (CDCl3):
7.16 – 7.30 (m, 28 H); 7.55 – 7.62 (m, 6 H); 7.85 (dd, J ¼ 8.4, 2.0, 2 H); 8.33 (d, J ¼ 1.6, 2 H). 13C- and 11B-
NMR could not be recorded due to the low solubility. HR-ACPI-MS: 689.3268 ([M þ H]þ, C50H39B2N2þ ;
calc. 689.3294).
REFERENCES
[1] A. Wakamiya, T. Taniguchi, S. Yamaguchi, Angew. Chem., Int. Ed. 2006, 45, 3170.
[2] K. Yoshino, N. Kano, T. Kawashima, Chem. Commun. 2007, 559.
´
[3] Y.-L. Rao, H. Amarne, S.-B. Zhao, T. M. McCormick, S. Martic, Y. Sun, R.-Y. Wang, S. Wang, J. Am.
Chem. Soc. 2008, 130, 12898.
[4] A. Loudet, K. Burgess, Chem. Rev. 2007, 107, 4891; Y.-L. Rao, S. Wang, Inorg. Chem. 2011, 50, 12263.
[5] K. Okada, R. Suzuki, M. Oda, J. Chem. Soc., Chem. Commun. 1995, 2069; A. Alexakis, F. Amiot,
Tetrahedron: Asymmetry 2002, 13, 2117.
[6] T. S. De Vries, A. Prokofjevs, J. N. Harvey, E. Vedejs, J. Am. Chem. Soc. 2009, 131, 14679; J. F. Vivat,
H. Adams, J. P. A. Harrity, Org. Lett. 2010, 12, 160; N. Ishida, T. Moriya, T. Goya, M. Murakami, J.
´
´
´
Org. Chem. 2010, 75, 8709; A. Ros, B. Estepa, R. Lopez-Rodrꢂguez, E. Alvarez, R. Fernandez, J. M.
Lassaletta, Angew. Chem., Int. Ed. 2011, 50, 11724; S. Kawamorita, T. Miyazaki, H. Ohmiya, T. Iwai,
M. Sawamura, J. Am. Chem. Soc. 2011, 133, 19310.
[7] a) N. Ishida, T. Miura, M. Murakami, Chem. Commun. 2007, 4381; b) N. Ishida, Y. Shimamoto, M.
Murakami, Org. Lett. 2009, 11, 5434.
[8] N. Ishida, M. Narumi, M. Murakami, Org. Lett. 2008, 10, 1279.
[9] N. Ishida, W. Ikemoto, M. Narumi, M. Murakami, Org. Lett. 2011, 13, 3008.
[10] J. W. Tilley, S. Zawoiski, J. Org. Chem. 1988, 53, 386.
[11] R. Pohl, P. Anzenbacher Jr., Org. Lett. 2003, 5, 2769.
[12] A. M. Johns, M. Utsunomiya, C. D. Incarvito, J. F. Hartwig, J. Am. Chem. Soc. 2006, 128, 1828.
Received October 3, 2012
