Hexaazatrinaphthylenes with Different Twists
Sunil Choudhary,[c, d] Cristian Gozalvez,[a] Alexander Higelin,[e] Ingo Krossing,[c, e]
Manuel Melle-Franco,[f] and Aurelio Mateo-Alonso*[a, b]
