Efficient and chromatography-free methodology for the modular synthesis of oligo-(1H-pyrazol-4-yl)-arenes with controllable size, shape and steric bulk

Article abstract of DOI:10.1016/j.tetlet.2016.01.043

A novel methodology to synthesise oligo-(1H-pyrazol-4-yl)-arenes with controllable size, shape and steric bulk from 1-trityl-1H-pyrazol-4-ylboronate pinacol esters. This straightforward and efficient procedure can be applied to a variety of brominated aro

Full text of DOI:10.1016/j.tetlet.2016.01.043

Accepted Manuscript
Efficient and chromatography-free methodology for the modular synthesis of
oligo-(1H-pyrazol-4-yl)-arenes with controllable size, shape and steric bulk
Laurence J. Kershaw Cook, Rachel Kearsey, Jessica V. Lamb, Edward J. Pace,
Jamie A. Gould
PII:
S0040-4039(16)30043-0
DOI:
http://dx.doi.org/10.1016/j.tetlet.2016.01.043
TETL 47207
Reference:
Tetrahedron Letters
To appear in:
Received Date:
Revised Date:
Accepted Date:
25 November 2015
8 January 2016
12 January 2016
Please cite this article as: Kershaw Cook, L.J., Kearsey, R., Lamb, J.V., Pace, E.J., Gould, J.A., Efficient and
chromatography-free methodology for the modular synthesis of oligo-(1H-pyrazol-4-yl)-arenes with controllable
size, shape and steric bulk, Tetrahedron Letters (2016), doi: http://dx.doi.org/10.1016/j.tetlet.2016.01.043
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to our customers
we are providing this early version of the manuscript. The manuscript will undergo copyediting, typesetting, and
review of the resulting proof before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that apply to the journal pertain.

Efficient and chromatography-free methodology for the modular
synthesis of oligo-(1H-pyrazol-4-yl)-arenes with controllable size,
shape and steric bulk
Laurence J. Kershaw Cook, Rachel Kearsey, Jessica V. Lamb, Edward J. Pace and Jamie A. Gould*
School of Chemistry, University of Leeds, Leeds, LS2 9JT, UK
E-mail: j.a.gould@leeds.ac.uk
Keywords: Pyrazoles, Oligo-(1H-pyrazol-4-yl)-arenes, Pyrazolate metal-organic frameworks, Suzuki
coupling, Boronate pinacol esters
Abstract
A novel methodology to synthesise oligo-(1H-pyrazol-4-yl)-arenes with controllable size, shape and
steric bulk from 1-trityl-1H-pyrazol-4-ylboronate pinacol esters. This straightforward and efficient
procedure can be applied to a variety of brominated aromatic precursors in a manner which leaves
the pyrazole NH intact for further modification or coordination to metal ions. This will enable the
synthesis of novel bioactive molecules and molecular material precursors, all achievable without any
purification techniques beyond standard extraction and trituration.
Introduction
Pyrazoles are an important class of molecules due to their inherent bioactivity,1,2 leading to their
integration into pharmaceuticals,3 and agrochemicals.4 Pyrazoles have also attracted the interest of
inorganic/supramolecular chemists as they possess diverse coordination modes,5 making them ideal
tectons for generating molecular materials.6,7 The typical route to synthesise pyrazoles is via the
condensation of hydrazines with 1,3-dielectrophiles7–9 such as dicarbonyls, ynones, enones and β-
ketoesters. However, this methodology has limited regioselective control and relies upon the
integration of desired functional groups into the building blocks. This extends the number of synthetic
steps and can require the use of toxic/hazardous reagents.
Recently pyrazoles have been utilised as ligands to construct metal-organic frameworks (MOFs)
as their hydrolytically stable coordination bonds lead to materials with enhanced chemical and thermal
stability.10,11 The ligands most commonly utilised in MOFs are derived from 1H-pyrazole or 3,5-
dimethyl-1H-pyrazole, linked through the 4-position with phenylene spacers of fixed stereochemical
geometry.11–13 Within these materials, pyrazole is deprotonated to yield the pyrazolate anion which
bridges between two metal centres, with each N atom coordinating to a distinct metal ion. Materials
are also formed from ligands bearing carboxylic acids either directly at the 4-position or with a para-
phenyl spacer. The common route to synthesise oligo-(1H-pyrazol-4-yl)-arenes is to attach a oligo-
1,3-dielectrophile to an arene via the Vilsmeier-Haack-Arnold formylation reaction, isolating the oligo-

1,3-electrophile as a bis- or tris-perchlorate salt. This potentially explosive intermediate is then
condensed with hydrazine to yield the final pyrazole ligand.10 Typical yields are between 34%10 and
41%.12
An alternative methodology to generate 4-aryl-1H-pyrazoles is via Suzuki coupling.14 This has
previously been utilised to synthesise the pyrazolecarboxylic acid ligands, 4-(1H-pyrazol-4-yl)benzoic
acid15 and 5-(1H-pyrazol-4-yl)isophthalic acid.16 Within these syntheses, the pyrazole NH groups were
protected using ethylvinylether and trityl chloride respectively, both of which can be readily cleaved
under acidic conditions. To date Suzuki coupling has not been utilised to synthesise extended oligo-
(1H-pyrazol-4-yl)-arenes. Sonogashira coupling has been used to synthesise a series of extended
bis-(1-Boc-1H-pyrazol-4-yl)-1,2-alkynes (Boc = tert-butyloxycarbonyl).15 However, the major drawback
of this methodology is that the Boc group cannot be removed by conventional methods and must be
removed under solvothermal conditions. There are currently no examples of Suzuki or Sonogashira
coupling to yield oligo-(1H-pyrazol-4-yl)-arenes based upon 3,5-dimethyl-1H-pyrazole. These
synthetic difficulties restrict the availability of pyrazole ligands, hindering the research of novel
pyrazolate derived molecular materials.
We therefore decided to develop an efficient modular Suzuki coupling methodology for the facile
attachment of 1H-pyrazole and 3,5-dimethyl-1H-pyrazole to arenes via the 4-position (Scheme 1).
This will permit the synthesis of a vast library of oligo-(1H-pyrazol-4-yl)-arenes, aiding the
advancement of pyrazolate MOFs, other pyrazole derived molecular materials, and natural
products/agrochemicals containing 4-aryl-1H-pyrazole or 4-aryl-3,5-dimethyl-1H-pyrazole.
Scheme 1. Our methodology for the synthesis of oligo-(1H-pyrazol-4-yl)-arenes from 4-bromo-1-trityl-
1H-pyrazoles via 1-trityl-1H-pyrazol-4-ylboronate pinacol esters.
Herein, we describe the development of a facile and high yielding modular synthesis of 4-(1H-pyrazol-
4-yl)benzoic acids and oligo-(1H-pyrazol-4-yl)-4-arenes from 4-bromo-1-trityl-1H-pyrazoles and 1-
trityl-1H-pyrazol-4-ylboronate pinacol esters respectively. This methodology can be achieved using
either 1H-pyrazole or 3,5-dimethyl-1H-pyrazole precursors, permitting steric control over the
pyrazolate-coordinating moiety. Furthermore the synthesis can be completed without the use of
column chromatography, with isolation possible through standard aqueous/organic extraction and
trituration. The effectiveness of this protocol is demonstrated by the synthesis of the novel oligo-(1H-
pyrazol-4-yl)-4-arenes; 1,3,5-tri(3,5-dimethyl-1H-pyrazol-4-yl)benzene (H3BTdmPz), 1,3,5-tris[4-
phenyl(1H-pyrazol-4-yl)]benzene (H3BTBPz) and 1,3,5-tris[4-phenyl-(3,5-dimethyl-1H-pyrazol-4-
yl)]benzene (H3BTBdmPz).
Our initial strategy focused upon the synthesis of 1H-pyrazole and 3,5-dimethyl-1H-pyrazole
derivatives of 4-(1H-pyrazol-4-yl)benzoic acid. This was achieved from the Suzuki coupling of trityl

protected 4-bromopyrazoles with (4-(methoxycarbonyl)-phenyl)boronic acid based upon previous
methodologies,14,17 but with minor adjustment. This facile route gives yields in excess of 95% for both
4-bromo-1H-pyrazole and 4-bromo-3,5-dimethyl-1H-pyrazole precursors. The formation of the
corresponding 4-(1H-pyrazol-4-yl)benzoic acid species is then completed by Suzuki coupling using
catalytic Pd(PPh3)4 in 1,4-dioxane with K3PO4·2H2O. Complete reaction can be achieved with as little
as 0.5 mol% catalyst loading, demonstrating the high activity of these species without the need for
expensive or customised Pd ligands. This is in contrast to previous reports of Suzuki coupling with 4-
bromo-1-trityl-1H-pyrazole, where up to 10 mol% loading was required for successful reaction.14–17
Deprotection of the trityl and ester groups is achieved sequentially without the need for subsequent
purification. Removal of the ester groups after trityl deprotection permits the extraction of all by-
products into the organic phase, leaving sodium 4-(1H-pyrazol-4-yl)benzoate salts within the aqueous
medium which can be trivially protonated to yield the corresponding acids in excellent yields (Scheme
2).
Scheme 2. Synthesis of 4-(1H-pyrazol-4-yl)benzoic acids from 1-trityl-1H-4-bromopyrazoles and
subsequent deprotection using TFA in CH2Cl2/MeOH. Quoted yields for 5 and 6 are for the combined
coupling and deprotection steps.
Although phenylboronic acids containing various functional groups have shown high conversion to
the Suzuki coupled products,14 it was found that this chemistry does not extend to aryl species
containing more than one boronic acid group. Substrates attempted to employ under Suzuki coupling
conditions with 4-bromo-1-trityl-1H-pyrazole (1) and 4-bromo-3,5-dimethyl-1-trityl-1H-pyrazole (2)
include 1,4-benzenediboronic acid, 4,4′-biphenyldiboronic acid and 1,3,5-tris-(4-phenylboronic
acid)benzene (Table 1).18 However, little or no reaction was observed with either 1 or 2, even with
increased catalyst loading. In order to circumvent this issue an alternative strategy was employed,
coupling 1-trityl-1H-pyrazol-4-ylboronate pinacol esters to polybrominated arenes. The wide scope of
this innovative strategy allows for modular construction of new compounds based upon the
brominated arene precursor.
Table 1. Attempts for generating 4-(1H-pyrazol-4-yl)benzoic acids, extended bis-1,4- and tris-1,3,5-
aryl-1H-pyrazol-4-yls based upon pyrazole and 3,5-dimethylpyrazole using the approach outlined in

Scheme 2 from 1-trityl-1H-4-bromopyrazoles. Quoted yields are for the combined coupling and
deprotection steps
5, 4-(1H-pyrazol-4-yl)benzoic acid, 75%
6, 4-(3,5-dimethyl-1H-pyrazol-4-yl)benzoic acid, 90%
7, H2BDPz, 0%
8, H2BDdmPz, 0%
9, H2BPDPz, 0%
10, H2BPDPz, 0%
11, H2BPDPz, 0%
12, H3BTdmPz, 0%
Pinacol esters were synthesised as previous reports suggest that pyrazol-4-ylboronic acids are not
air-stable19 while pinacol esters provide ease of workup.20 Initially the formation of trityl protected
analogues of 1-methyl-1H-pyrazol-4-ylboronic acid pinacol ester lithium ate complex were attempted
based upon the method by Mullens,19 as these compounds are reported to have high stability and
Suzuki coupling activity. However we were unable to isolate these species from either 1 or 2.
Successful formation of 1-trityl-1H-pyrazol-4-ylboronate pinacol ester (3) was achieved from a one-
pot reaction in THF via lithium-halogen exchange, addition of triisopropyl borate and subsequent
encapsulation of the boronic acid with pinacol to yield the final compound. The analogous reaction
can also be completed with 2, yielding 3,5-dimethyl-1-trityl-1H-pyrazol-4-ylboronate pinacol ester (4),
permitting control over the steric bulk of the pyrazole subunit. Suzuki coupling of the 1-trityl-1H-
pyrazol-4-ylboronate pinacol esters with polybrominated arenes is typically achieved using 1 mol%
Pd(PPh3)4 in 1,2-dimethoxyethane (DME), with yields of up to 87% in 18 hours (Scheme 3 and Table
2). Removal of the trityl group is achieved using TFA in an analogous manner to the preparation of
1H-pyrazol-4-ylbenzoic acids described above (Scheme 3).
Scheme 3. Synthesis of 1,4-bis(1H-pyrazol-4-yl)benzenes from 1-trityl-1H-pyrazolyl-4-boronate
pinacol esters and subsequent deprotection using TFA in CH2Cl2/MeOH. Quoted yields for 7 and 8
are for the combined coupling and deprotection steps.
Using this methodology, a series of oligo-(1H-pyrazol-4-yl)-arenes with linear and trigonal geometries
were synthesised based upon the 1H-pyrazole and 3,5-dimethyl-1H-pyrazole subunit (Table 2). We

selected these geometries as they are the most common within MOF ligands. This includes pyrazoles
which have been previously used as ligands to synthesise pyrazolate-derived MOFs (7-11), and novel
compounds (12-14). Entries 13 and 14 are 1H-pyrazole/3,5-dimethyl-1H-pyrazole analogues of the
carboxylic acid MOF ligand 1,3,5-tris(4-carboxyphenyl)benzene (H3BTB). We envisage that both
H3BTBPz and H3BTBdmPz could be utilised for the synthesis of novel pyrazolate MOFs with identical
topologies to either MOF-17721 or the mixed ligand material UMCM-1,22 but with enhanced chemical
stability known to be derived from metal-pyrazolate coordination.
Table 2. Substrates tested for the generation of extended linear bis-1,4- and trigonal tris-1,3,5- aryl-
1H-pyrazol-4-yls based upon pyrazole and 3,5-dimethylpyrazole from 1-trityl-1H-pyrazol-4-ylboronate
pinacol esters. Quoted yields are for coupling and subsequent deprotection.
7, H2BDPz, 63%
8, H2BDdmPz, 87%
9, H2BPDPz, 61%
10, H2BPDPz, 61%
11, H2BPDPz, 61%
12, H3BTdmPz, 45%
13, H3BTBPz 73%
14, H3BTBdmPz, 69%
In summary, we report a Suzuki coupling methodology that permits the synthesis of a wide range
of oligo-(1H-pyrazol-4-yl)-arenes with controlled size, geometry and steric bulk based upon the choice
of brominated building block and pyrazol-4-ylboronate pinacol ester. This procedure will permit the
advancement of pyrazole derived molecular materials, natural products, pharmaceuticals and
agrochemicals containing 4-aryl-1H-pyrazole or 4-aryl-3,5-dimethyl-1H-pyrazole.

However, we envisage this methodology will have the greatest impact within the field of MOFs, as it
permits facile synthesis of pyrazolate MOF ligands. This could be used to further study known
materials, or it could be utilised to synthesise a wide range of new pyrazolate MOFs with control of
porosity and functionality via the reticular approach currently used in carboxylate-MOF chemistry. The
utilisation of pyrazole ligands for the synthesis of new MOFs is an important next step within the field
where materials with increased stability is a priority, specifically for industrial application where long
lifetimes of materials are essential.23
Acknowledgments
We thank the EPSRC for funding through the Directed Assembly Network (PP 14 11 04), and the
University of Leeds for financial support.
Supplementary data
Supplementary data (experimental procedures & NMR spectra) associated with this article can be
found in the online version.
References and notes
1. Kasiotis, K.M.; Tzanetou, E.N.; Haroutounian, S.A. Front. Chem. 2014, 2, 1–7.
2. Küçükgüzel, Ş.G.; Şenkardeş, S. Eur. J. Med. Chem. 2015, 97, 786–815.
3. Terrett, N.K.; Bell, A.S.; Brown, D.; Ellis, P. Bioorganic Med. Chem. Lett. 1996, 6, 1819–1824.
4. Jeanguenat, A. Pest Manag. Sci. 2013, 69, 7–14.
5. Halcrow, M.A. Dalton Trans. 2009, 2059–2073.
6. Pérez, J.; Riera, L. Eur. J. Inorg. Chem. 2009, 4913–4925.
7. Roberts, T.D.; Little, M.A.; Kershaw Cook, L.J.; Halcrow, M.A. Dalton Trans. 2014, 43, 7577–
7588.
8. Kim, B.R.; Sung, G.H.; Ryu, K.E.; Lee, S.-G.; Yoon, H.J.; Shin, D.-S.; Yoon, Y.-J. Chem.
Commun. 2015, 51, 9201–9204.
9. Fustero, S.; Sánchez-Roselló, M.; Barrio, P.; Simón-Fuentes, A. Chem. Rev. 2011, 111, 6984–
7034.
10. Colombo, V.; Galli, S.; Choi, H.J.; Han, G.D.; Maspero, A.; Palmisano, G.; Masciocchi, N.; Long,
J.R. Chem. Sci. 2011, 2, 1311–1319.
11. Tonigold, M.; Lu, Y.; Bredenkötter, B.; Rieger, B.; Bahnmüller, S.; Hitzbleck, J.; Langstein, G.;
Volkmer, D. Angew. Chem. Int. Ed. 2009, 48, 7546–7550.
12. Choi, H.J.; Dincă, M.; Long, J.R. J. Am. Chem. Soc. 2008, 130, 7848–7850.
13. Herm, Z.R.; Wiers, B.M.; Mason, J.A.; van Baten, J.M.; Hudson, M.R.; Zajdel, P.; Brown, C.M.;
Masciocchi, N.; Krishna, R.; Long, J.R. Science 2013, 340, 960–964.
14. Ichikawa, H.; Nishioka, M.; Arimoto, M.; Usami, Y. Heterocycles 2010, 81, 1509–1516.

15. Padial, N.M.; Quartapelle Procopio, E.; Montoro, C.; López, E.; Oltra, J.E.; Colombo, V.; Maspero,
A.; Masciocchi, N.; Galli, S.; Senkovska, I.; Kaskel, S.; Barea, E.; Navarro, J.A.R. Angew. Chem.
Int. Ed. 2013, 52, 8290–8294.
16. Gao, W.-Y.; Cai, R.; Pham, T.; Forrest, K. A.; Hogan, A.; Nugent, P.; Williams, K.; Wojtas, L.;
Luebke, R.; Weseliński, Ł.J.; Zaworotko, M.J.; Space, B.; Chen, Y.-S.; Eddaoudi, M.; Shi, X.; Ma,
S. Chem. Mater. 2015, 27, 2144–2151.
17. Anderson, E.D.; Boger, D.L. J. Am. Chem. Soc. 2011, 133, 12285–12292.
18. Wan, J.; Zheng, C.-J.; Fung, M.-K.; Liu, X.-K.; Lee, C.-S.; Zhang, X.-H. J. Mater. Chem. 2012, 22,
4502–4510.
19. Mullens, P.R. Tetrahedron Lett. 2009, 50, 6783–6786.
20. Wong, K.-T.; Chien, Y.-Y.; Liao, Y.-L.; Lin, C.-C.; Chou, M.-Y.; Leung, M. J. Org. Chem. 2002, 67,
1041–1044.
21. Chae, H.K.; Siberio-Pérez, D.Y.; Kim, J.; Go, Y.; Eddaoudi, M.; Matzger, A.J.; O’Keeffe, M.;
Yaghi, O.M. Nature 2004, 427, 523–527.
22. Koh, K.; Wong-Foy, A.G.; Matzger, A.J. Angew. Chem. Int. Ed. 2008, 47, 677–680.
23. Czaja, A.U.; Trukhan, N.; Müller, U. Chem. Soc. Rev. 2009, 38, 1284–1293.

Graphical abstract
