A Sense of Life: Computational and Experimental
Investigations with Models of Biochemical and
Evolutionary Processes
BUD MISHRA,1,3 RAOUL-SAM DARUWALA,1 YI ZHOU,1,2 NADIA UGEL,1
ALBERTO POLICRITI,8 MARCO ANTONIOTTI,1 SALVATORE PAXIA,1
MARC REJALI,1 ARCHISMAN RUDRA,1 VERA CHEREPINSKY,1 NAOMI SILVER,1
WILLIAM CASEY,1 CARLA PIAZZA,12 MARTA SIMEONI,12 PAOLO BARBANO,1
MARINA SPIVAK,1 JIAWU FENG,1 OFER GILL,1
MYSORE VENKATESH,1 FANG CHENG,1,2 BING SUN,1
IULIANA IONIATA,1 THOMAS ANANTHARAMAN,6 E. JANE ALBERT HUBBARD,2
AMIR PNUELI,1,3 DAVID HAREL,9 VIJAY CHANDRU,5 RAMESH HARIHARAN,5
MICHAEL WIGLER,3 FRANK PARK,7 SHIH-CHIEH LIN,3 YURI LAZEBNIK,3
FRANZ WINKLER,10 CHARLES R. CANTOR,11 ALESSANDRA CARBONE,4
and MIKHAEL GROMOV4
ABSTRACT
We collaborate in a research program aimed at creating a rigorous framework, experimental
infrastructure, and computational environment for understanding, experimenting with, ma-
nipulating, and modifying a diverse set of fundamental biological processes at multiple scales
and spatio-temporal modes. The novelty of our research is based on an approach that (i) re-
quires coevolution of experimental science and theoretical techniques and (ii) exploits a cer-
tain universality in biology guided by a parsimonious model of evolutionary mechanisms op-
erating at the genomic level and manifesting at the proteomic, transcriptomic, phylogenic,
and other higher levels. Our current program in “systems biology” endeavors to marry large-
scale biological experiments with the tools to ponder and reason about large, complex, and
1Department of Computer Science and Mathematics, Courant Institute of Mathematical Sciences, New York Uni-
versity, New York, New York.
2Department of Biology, New York University, New York, New York.
3Cold Spring Harbor Lab, Cold Spring Harbor, New York.
4Institut des Hautes Etudes Scientifiques, Le Bois-Marie, Bures-sur-Yvette, France.
5Strand Genomics, Bangalore, India.
6Department of Biostatistics and Medical Informatics, University of Wisconsin, Madison, Wisconsin.
7School of Mechanical and Aerospace Engineering, Seoul National University, Kwanak-Gu, Seoul, Korea.
8Dipartimento di Matematica ed Informatica, Universitá degli Studi di Udine, Udine, Italy.
9Faculty of Mathematics and Computer Science, The Weizmann Institute of Science, Rehovot, Israel.
10Research Institute for Symbolic Computation, University of Linz, RISC-Linz, Linz, Austria.
11Sequenom, Inc., San Diego, California.
12Dipartimento di Informatica, Universitá Cá Foscari di Venezia, Venice, Italy.
253

MISHRA ET AL.
subtle natural systems. To achieve this ambitious goal, ideas and concepts are combined
from many different fields: biological experimentation, applied mathematical modeling, com-
putational reasoning schemes, and large-scale numerical and symbolic simulations. From a
biological viewpoint, the basic issues are many: (i) understanding common and shared struc-
tural motifs among biological processes; (ii) modeling biological noise due to interactions
among a small number of key molecules or loss of synchrony; (iii) explaining the robustness
of these systems in spite of such noise; and (iv) cataloging multistatic behavior and adapta-
tion exhibited by many biological processes.
INTRODUCTION
HE INTRODUCTION OF INFORMATION TECHNOLOGY into biology and biotechnologyhas already transformed
and accelerated the nature of biological research. The impact of this transformation has been felt in the
T
areas of agriculture, pharmacology, disease diagnosis and prognosis, forensics, defense against biowarfare,
biometry, and, ultimately, in the manner in which we interact with our immediate natural environment. The
biggest impact of information technology thus far has been at the descriptive level, enabling the collection
of the bits and pieces of biological structures or part-lists that can be computed from the slew of data gen-
erated by modern high-throughput instruments. However, the contribution of information technology to
biological research is still relatively minor when compared to what can be achieved if we are able to un-
derstand the functional properties of these part-lists.
Recent progress in our observational and experimental abilities has allowed us to understand the largely
unobservable transparent structures of the cell. We are now able to catalog the genomic sequence of an or-
ganism, quantify the transcriptional states of a cell through microarrays, or even track photo-labeled single
in vitro in vivo
or
molecules
.
More recently, we have also become familiar with novel “computational” approaches that rely on si-
multaneous progress on many fronts: (a) vast amounts of computing power (through distributed or tightly-
coupled parallel computers) have become available; (b) accurate physical models at kinetic mass-action,
stochastic, spatio-temporal, and hybrid discrete/continuum levels can be created; (c) algorithmic efficiency
can be achieved through symbolic and qualitative computation; and (d) logical reasoning systems and other
analysis tools at multiple resolutions can be constructed with relative ease. These approaches borrow ideas
from computational theory and logic, systems and engineering sciences, and applied mathematics.
A determined drive to realize large-scale computational tools for systems biology has come through
DARPA’s BioComp/BioSPICE project involving several investigators. As part of this research effort, sev-
eral of us have been creating computational tools (e.g., Simpathica, NYU BIOSim, NYU BIOWave, and
XS-System), integrating these tools with the other tools in the larger effort (www.biospice.org), and par-
ticipating in design of the systems, languages, and experiments involved in this effort.
Thus, we posit that it is possible to create powerful simulation, analysis, and reasoning tools for work-
ing biologists that can be used in deciphering the functional properties of genomes, proteomes, cells, or-
gans, and organisms by drawing upon mathematical and computational approaches developed in the fields
of dynamical systems, kinetic analysis, computational theory, and logic. Thus, creating accurate and inte-
grated tools for this purpose has become one of the grand challenges in computer science today. Coevolu-
tion of experimentation technology and design methods is crucial, lest we repeat the unfortunate history of
“theoretical biology” from the early part of last century, which attempted to develop an abstract mathe-
matical theory for biology without recourse to experimentation (works of D’arcy Thompson, Alan Turing,
and Nicholas Refshavsky)
At present, there is no clear way to determine if the current body of biological facts is sufficient to ex-
plain the phenomenology. In the biological community, it is not uncommon to assume certain biological
problems to have achieved a cognitive finality without rigorous justification. In these particular cases, rig-
orous mathematical models with automated tools for reasoning, simulation, and computationcan be of enor-
mous help in uncovering cognitive flaws, qualitative simplifications, or overly generalized assumptions.
Ideal candidates for such study would include: the prion hypothesis, cell-cycle machinery (e.g., DNA repli-
254

A SENSE OF LIFE
cation and repair, chromosome segregation, cell-cycle period control, and spindle pole duplication), mus-
cle contractility, processes involved in cancer (e.g., cell-cycle regulation, angiogenesis, DNA repair, apop-
tosis, cellular senescence, and tissue space modeling enzymes), signal transduction pathways, circadian
rhythms (especially the effect of small molecular concentration on their robustness), and many others.
We believe a modern computational and systems theory that provides a solid mathematical foundation
for biological systems is needed. While traditional systems theory focuses on simple behavioral attributes
(such as reachability or robustness) of small, idealized systems (e.g., linear time-invariant systems), and
classical computational theory focuses on the evolution of discretized, synchronous systems (e.g., finite
state automata or Boolean networks), the methods of systems biology must be based on many complex and
interconnected attributes.
We concentrate on four focus areas of research.
(a) Biochemical Process Theory
. Biochemical process theory seeks to create a unified framework in which
one can understand biochemical pathways and the evolutionary processes that shaped them. There are sev-
eral interrelated components. These include models derived from kinetic mass-action that focus on con-
centrations of chemicals; models derived from discrete events such as commitment, differentiation, and self-
renewal; models derived from cell-signaling; models derived from large populations of cells; and models
accounting for cellular compartmentalization and transport across membranes and between compartments.
The demands that these models impose on computer science go well beyond the biological areas and one
quickly finds oneself grappling with diverse issues related to the numerical, probabilistic, logical, and sym-
bolic aspects of computation, and, in particular, how they can be implemented on modern computer archi-
tectures.
(b) Evolutionary Processes, Genomes, and Pathway Models
. The biochemical processes that have evolved
in nature are governed by a set of simple processes that continue to alter genomes gradually. Duplication,
translocation, deletion, and mutation are examples of such genomic processes. The main effort here is to
develop a set of models with solid mathematical and biological foundations that allow for the systematic
understanding of these probabilistic processes and the constraints they impose on biological systems, as
well as the deciphering of the modular structure of large-scale biochemical processes. Furthermore, we ex-
ploit this structure through metamodeling and metalanguages for composing, transforming, and validating
the basic building blocks of the models.
(c) Advanced Tool Architectures
. Our toolkits comprise a set of reusable, inter-operating software modules
integrated within a bioinformatics language and environment. The system is freely distributed as open-
source software (as part of www.biospice.org) and allows the users to augment and share improved soft-
ware within the user community. The main tools address simulation, reasoning, and analysis of biochemi-
cal processes, but also integrate with genome and genome-evolution analysis tools.
(d) Experimental Research
. The program is founded upon large-scale
in vivo
in vitro
and experiments that
are able to reveal cognitive flaws, incompleteness, and false assumptions that may have been incorporated
into the model. In order to achieve this, we concentrate on time-course gene-expression data that can be
obtained through microarray analysis or similar methods based upon mass-spectroscopy. We also augment
our data with proteomic data whenever possible.
Thus, the coevolving experimental research guides the theory, tool development, and model validation.
The main emphasis is naturally placed on providing biologists and biotechnologists with the capability to
analyze large and complex biological systems and devise intelligent experiments without being forced to
deal with the mathematical details and complexity of the system. Hierarchy and composition are the basic
cornerstones of our tools, methods, and models.
BIOCHEMICAL PROCESS THEORY
Several biological and biochemical mechanisms can be modeled with relatively simple sets of differen-
tial algebraic equations (DAE’s). In the past, we have constructed and demonstrated to biologists the util-
ity of a powerful computational tool with the ability to query massive sets of numerical data obtained from
255

MISHRA ET AL.
in silico
experiments on complex biological systems. The initial design of the computational tool derives
its expressiveness, flexibility, and power from integrating many well-established and time-tested ap-
proaches in numerical analysis, symbolic computation, temporal logic, model checking, and visualization.
The basic system has been successively augmented into a new system, dubbed “XS-system” (Antoniotti
et al., 2002, 2003), as it extends the basic foundations provided by the “S-system models of biochemical
processes.” (See Voit, 2000, and also Antoniotti et al., 2002, Antoniotti et al., 2003, Cornish-Bowden,
1999, and Savageu, 1976.)
Our core design principles for XS-systems are based upon: (a) an elegant structure founded upon an ex-
tendable set of building blocks or models: for example, syntheses, degradations, reversible reactions, en-
zymatic reactions, reactions modulated by coenzymes, and reactions constrained by stoichiometric condi-
tions; (b) flexibility in terms of compositionality and hierarchy; (c) expressibility; and finally, (d) the
capability to create consistent semantics. Thus, in some sense, our rudimentary XS-system can be thought
of as “the RISC (reduced instruction set computer) of systems biology” and provides the foundation upon
which a complex language for systems biology can be built. For the same reasons, XS-systems also pro-
vide an elegant pedagogic tool for computer scientists and biologists to understand key biological processes
as well as the algorithms used to describe them.
We have extended the core XS-system with many useful modules—in fact, a key design criterion of our
system was the ease with which such new modules could be introduced. Obvious examples of these key
modules include Hill equations, saturation effects, concentration changes due to cell volume growth, the
effect of small numbers of molecules, and detailed models of transcription, RNA stability, and protein degra-
dation. In each case, the extended system also allows for various representations such as models based on
ODE’s (Ordinary Differential Equations), SDE’s (Stochastic Differential Equations), timed automata, or hy-
brid automata for each new module introduced, sometimes allowing for multiple representations with in-
structions on how a representation may be selected.
Our approach can be justified by simply noting that a vast number of models of interest to working bi-
ologists can be expressed and analyzed by the simplest core system. It is at this simplest core level that the
most interesting biological mechanisms reveal themselves and provide the most useful insights for more
experiments and more detailed or more complex models. As an anecdote, our group recently analyzed a
Caspase cascade model for apoptosis with Lazebnik-lab at Cold Spring Harbor Lab: using the XS-system,
a rough topological model was constructed and analyzed in less than half an hour. The model exhibited a
quadratic growth of C3A when Caspase-9 was active and a linear growth in the absence of Caspase-9—an
effect that was observed in the laboratory experiments(unpublishedresults). The simplest model also pointed
out the possible presence of several unmodeled molecules as the core model could not explain various well-
known thresholding effects. Thus, we contend that while we have left ample room for complexity in the
system, it is for the simplicity, elegance, and compositionality that we have strived.
A natural completion for the XS-system is an automaton summarizing the states along which the simu-
lated biochemical system evolves in time. The automaton, so generated, allows the user to view, manipu-
late, and reason about the system, using a well-integrated set of tools. As an example, we may consider the
case study of purine metabolism (Antoniotti et al., 2002; Voit, 2000) which illustrates the fact that the
“right” cellular behavior is often difficult to capture with an initial abstraction model (Fig. 1).
Our existing tools for studying biological processes are augmented with simple interfaces that allow a
biologist to input a model, visualize the functions of the biologicalprocesses, iteratively improve the model,
in silico
and construct “what-if”
experiments. Moreover, our tools have the ability to identify missing fea-
tures and partial or incomplete models through the model-checking algorithms for temporal logic.
Biological preliminaries
The genome of an organism, the genetic core of a cell, is a collection of genes in its DNA. The role of
a gene is to encode for protein structure. The sequence of amino acids, specified by DNA through the tran-
scription and translation processes, determines the three-dimensional structure and biochemical properties
of the proteins as well as the nature of their interactions. The proteins, in the form of transcription factors
and other operons, may in turn regulate gene expression. Other factors, such as mRNA stability, protein
degradation, post-translational modifications, and many other biochemical processes, tightly regulate the
256

A SENSE OF LIFE
FIG. 1. The pathway to the left depicts the classical (but incomplete) model of purine metabolism. Using the XS-
system and the approaches described earlier, one can automatically create the model and perform model checking on
the resulting qualitative automaton to show that the model fails to satisfy the temporal logic formula encoding robust-
ness (bottom left). This reasoning process and manipulations with the XS-system ultimately led to a more complete
model that does satisfy the robustness formula.
time-constants involved in the resulting biochemical machinery. (See Alberts et al., 1995, and Cantor and
Smith, 1999.)
E
An enzyme, , is a protein which can enhance the activity of a chemical reaction by attaching to a sub-
A
P
strate, , and making the formation of the product, , energetically easier:
E 1 A
EA R E 1 P
In general, equations of this kind take the form
K
1 C 1 D
A 5 K C D 2 K A B
‚
A 1 B
and [ ]
2[ ][ ]
1[ ][ ]
K
2
A
K C D
where the rate of change of ’s concentration is given by the difference of the “synthesis rate” ( _[ ][ ])
K
A B
and the “dissociation rate” ( 1[ ][ ]).
257

MISHRA ET AL.
XS-systems
Using a system of first-order differential equations (in explicit form), one can construct a general model
of a complex biochemical reaction involving many genes and proteins.
n
X
X
n
m
The basic ingredients of our XS-system are the dependent variables 1, . . . ,
and the indepen-
X
X
D
D
m. Let 1, . . . ,
n
1
n 1 m
dent variables 11, . . . ,
be the domains where the
m
variables take val-
n
n
1
ues. We augment the form described in Voit, 2000, with a set of algebraic constraints which serve to char-
acterize the conditions under which a given set of equations is derived from a set of maps.
The basic differential equations constituting the system take the following power law form:
n1m
n1m
?
Xgj ij 2 bi
Xjh
ij
Xi 5 ai
(1)
P
P
j5
j5
1
1
and
n1m
C X t
1( ), . . . ,
X
t
5
glj
Xkfljk
5
0
(
m( ))
(2)
l
n
1
^
j
P
1
2
k5
1
a
b
where the i’s and i’s are called rate constants. These rate constants govern the positive and negative con-
g
tributions to a given substance. The lj’s called rate constraints; these act concurrently with the exponents
fljk n 1 m
to delimit the evolution of the system over a specified (
)–dimensional surface.
The set of differential equations in our XS-system can always be rewritten (recast) in a special canoni-
cal form by purely algebraic transformations and a further inclusion of a set of algebraic constraint equa-
tions. Canonical forms have several advantages over more general forms of equations, since they can be
more easily manipulated, integrated, and interpreted in mathematical terms. Thus, the XS-system model we
use has a simple canonical form: a list of expressions, each describing the rate of change of a given quan-
tity in a model (say, the concentration of a reactant), plus a set of equations describing some constraints on
the relationships among some of the parameters characterizing the model. Each of the rate-describing ex-
pressions has a very simple form as well: it is simply binomial—the difference between two algebraic power-
products (or monomials), one representing synthesis and the other, dissociation.
A system of differential equations of the form described above can be integrated either symbolically or
by numerical approximation.Frequently,standard approximationtechniquessuffice; however, in some cases,
novel algorithmic techniques are required. Both symbolic and numerical cases are considered in our pro-
gram on an equal footing, as we believe that without the reliance upon symbolic computational methods
and composition properties, a system of this kind will ultimately fail when scaled to more realistic situa-
tions.
Traces and trace automata
We describe the semantics of an XS-system using an automaton that captures the qualitative features of
the biological system. The automaton is constructed as follows: a snapshot of the system variables consti-
tutes a possible state of the automaton. Transitions are inferred from traces of the system variables’ evolu-
tion. Final states are those states in which the simulation reaches a recognizable end, and are supposed to
represent the equilibrium points for the metabolic pathway being modeled.
More interesting states (with deteriorating computational efficiency implications) are constructed by
grouping together several time instants according to simple rules, such as a linearization rule that groups
states where the rate of change is within a user-defined parameter.
A major focus of our research is the question of how to tame the complexity of such automata by “col-
lapsing the models” symbolically or modularly representing the models. This approach allows for studying
multiple evolutions and experiments differing in rate constants and kinetic orders in parallel (within a sin-
gle structure).
Note that the automata proposed here are not necessarily unique, and one may consider more complex
automata with different semantics that are amenable to different kinds of logical analysis. For instance, we
may extend the theory to: timed automata, hybrid automata, communicating automata, and “algebraic dif-
ferential automata,” where the states and state transitions are described by algebraic rules only. We aim to
exploit these symbolic structures to create better reasoning systems: for example, variants of CAD (Cylin-
drical Algebraic Decomposition) to create qualitative automata, Morse-theoretic models of transitions be-
258

A SENSE OF LIFE
tween steady states, or differential algebraic elimination theory for input-output behavior and their usage
in collapsing (Mishra, 2000, and Mishra, 2002).
Reasoning with temporal logic
A simple and natural example of a logical property of many biological systems is the one describing the
existence of a steady-state. Informally, a system is in a “steady-state” when nothing “changes” in the sys-
tem as time passes. Very often, the biologist knows not only that, in the absence of external stimuli, such
a state must be reached sooner or later, but also the relative values of substances involved in such a state.
Another natural property involves the boundedness of the reactant concentrations involved in a biological
process and may need to be ascertained as a precondition to other interesting properties, such as the exis-
tence of a limit-cycle, multiple stable solutions, metastability, or hysteresis (Bhalla and Iyengar, 1999, and
Wigler and Mishra, 2002).
A simple reasoning tool, based on the notion of model checking, may analyze a single trace of the au-
tomaton results, where the single trace is created from only one “set-up” (e.g., initial conditions, a set of
values for the parameters, and a set of signaling events) for the system being analyzed. In order to allow
more than one trace, it is necessary to consider different “set-ups,” for example, many possible values for
the parameters, such as rate constants and kinetic orders. These multiple “set-ups” may be defined para-
metrically (symbolically), deterministically sampled over a cartesian grid, or randomly sampled with re-
spect to some reasonable distribution.
Fundamental to temporal logic (Gabbay et al., 1994, Mishra, 2002, and Mishra and Clarke, 1985) is the
notion that time-dependent terms from natural language, such as “eventually” and “always,” can be given
a precise meaning (semantics) in terms of the abstract behavior of the system under discourse. As an ex-
The concentration of guanosine triphosphate GTP is equal to
ample, consider the following sentence: “
(
)
x
.” Given a biological system in equilibrium, the above sentence may or may not be true at any or all in-
stants of time. In particular, we can easily construct sentences (in a suitable natural language) that express
the fact that, given a certain set of initial conditions, the above sentence will eventually hold true. Tempo-
ral logic precisely formalizes the meaning of the term “eventually” (and other such “modes”: “always,” “in-
finitely often,” and “almost always”), and the resulting semantics lead to a precise model-checking algo-
rithm for determining the validity of temporal logic sentences in the context of our trace automaton. We
have also augmented the traces with time-frequency analysis using Linear Discriminant Bases (LDB), Lo-
cal Karhunen-Loeve (LKL), and other techniques based on multi-resolution wavelet analysis. Temporal
logic, thus enriched, allows us to understand the dynamic properties of the biological processes and to “clus-
ter” different components of the system that may be co-regulated or anti-regulated.
Reasoning with statecharts
We have also been collaboratively investigating how to use the visual formalism of statecharts (Damm
and Harel, 2001, Efroni et al., 2003, Harel, 1987, Harel and Gery, 1997, Harel and Marelly, 2003, Harel et
al., 2003, Kam et al., 2001, and Kam et al., 2003) to address the challengeof analyzingbiochemicalprocesses.
For instance, under this formalism, we have presented a detailed model for T cell activation using state-
charts within the general framework of object-oriented modeling. Encouraged by our early successes, we
have embarked upon a far more ambitious project—applying the same methodology to constructing a full
C. el-
detailed model of the developmental processes that lead to the formation of the egg-laying system in
egans
.
We have demonstrated that the statechart-based approach is applicable to the challenge of modeling large
numbers of biological processes in a hierarchical fashion and relating the various cellular events within the
spatial and temporal context in which they occur to each other. Such models are useful for investigating
the behavior of a system under many given scenarios, raising questions that were not thought of before and
confronting questions which, because of their complexity, cannot be addressed by standard laboratory tech-
niques and/or pure intuition alone. We believe that the statechart formalism integrates elegantly with for-
mal verification methods and allows one to test whether the formal representation of the model fulfills the
requirements that emerge from existing biological data.
259

MISHRA ET AL.
Open questions
Several interesting questions remain to be further explored:
• Reactions Models: We have primarily focused on a simple ODE model using DAE’s, and narrowed
this even further to a model based on XS-systems. Does this imply a significant deviation from real-
ity (Bhalla and Iyengar, 1999, and Guat et al., 2002)? How can a stochastic model representing small
numbers of molecules that interact pair-wise and randomly be incorporated (Wigler and Mishra, 2002)?
We have already devised an efficient spatial Gillespie-like algorithm to perform stochastic computa-
tions and used it successfully to understand a stem-cell model. We need to further explore how to com-
bine the SDE models with the algebraic-constrained DAE models.
• Hybrid Systems: Certain interactions are purely discrete, and after each such interaction, the system
dynamics may change. For a hybrid model of this kind the underlying automaton must be modified for
each such mode. How do these enhancements modify the basic symbolic model?
• Spatial Models: The cellular interactions are highly specific to their spatial locations within the cell.
How can these be modeled with symbolic cellular-automata? How can we account for the dynamics
due to changes in the cell volume? The time constants associated with diffusion may vary from loca-
tion to location; how can that be modeled?
• State Space (Product Space): A number of interacting cells can be modeled by product automata. In
addition to the classical “state-explosion problem,” we also need to pay attention to the variable struc-
ture due to (a) cell division, (b) apoptosis, and (c) differentiation.
• Communication: How do we model communication among cells mediated by interactions between
extra-cellular factors and external receptors?
• Hierarchical Models: As we go to more and more complex cellular processes, a clear understanding
can be obtained only through modularized hierarchical models. What are the ideal hierarchical mod-
els? How do we model a population of cells with related statistics?
• Symbolic Verification: If a biologist wishes to reason about a system with logical queries in an ap-
propriate query language (e.g., temporal logic), what are the best query languages? What are the best
algorithms that take advantage of the symbolic structures (Mishra, 2000, and Mishra, 2002)? What are
the correct ways to solve problems associated with (a) model equivalence, (b) experimental analysis,
and (c) reachability analysis?
EVOLUTIONARY PROCESSES, GENOMES, AND PATHWAY MODELS
Regulatory and metabolic processes in biology do not occur in isolation, nor are they static in nature.
Hence, a better understanding of biology is hinged on a deep information-theoretic study of evolving
genomes and their roles in governing metabolic and regulatory pathways.
Various biochemical and cellular processes—including point mutation, recombination, gene conversion,
replication slippage, DNA repair, translocation, imprinting, and horizontal transfer—constantly act on
genomes and drive the genomes to evolve dynamically. These alterations in the genomic sequences can fur-
ther lead to the corresponding changes in the higher-level cellular information (transcriptome, proteome,
interactome), and are crucial in explaining the myriads of biological phenomena in the higher-level cellu-
lar processes. (See Bailey et al., 2002, Buldyrev et al., 1993, Gerstein et al., 2001, Lucito et al., 2000, Ohno,
1970, Paxia et al., 2002, Peng et al., 1992, and Vulic et al., 1999.)
We have created a parsimonious mathematical model to explain various observations on the statistical
structure of genomes (e.g., mer-frequency distribution in genomes) and its implications to the topology of
the regulatory processes. Our model, based on the “evolution by duplication” theory originally proposed by
Ohno in the 1970’s (Ohno, 1970), is an extension of a Polya’s urn model and considers genome evolution
as a stochastic process with three main events: substitution, deletion, and duplication. A simpler model,
based on evolving Eulerian graphs, fits nicely with real-world data for mer-frequency distributions. These
results suggest that despite the highly diversified evolutionary environment for different organisms, the es-
sential composition of the evolutionary dynamic, metabolic, and regulatory processes is commonly shared.
260

A SENSE OF LIFE
Genome evolution processes
Ohno’s theory is well supported by molecular biology. There are various molecular mechanisms that can
cause gene duplication. These include (a) unequal crossing over, (b) DNA polymerase slippage, and (c) het-
erologous recombination. If we assume that the target gene of every duplication is randomly chosen from
the genes that are already in the genome, then we have a realization of a Polya’s urn model. Therefore, un-
der the “evolution by duplication” theory, genome evolution can be viewed as a stochastic duplication
process that leads to a highly correlated structure in the genomes and repeated motifs in the regulatory net-
work topologies.
In our Eulerian graph model, each mer-species of a particular length is represented by a node. Whenever
two non-overlapping mers are immediately adjacent to each other in the genome, they are connected by a
directed edge. Therefore, the in- and out-degree of a node indicates the copy number of the corresponding
mer in the genome. Genome evolution is modeled by graph evolution, which is composed of three possi-
ble processes (Fig. 2).
This simple model possesses enough expressive power to explain the genome structures in many species
as well as how they can be connected in a phylogeny. Furthermore, essentially the same structures lead to
higher level models for protein-protein interaction and regulatory networks, without obscuring the essence
and parsimony of the evolution processes.
Genome grammar
In order to study the evolution processes of the kind just described in more detail, we have also devel-
oped an efficient backend for low-level simulation tasks in genomic evolution (Paxia et al., 2002). The cur-
rent system can be easily enhanced to also model and derive statistics for protein–protein interaction and
pathway structure. The simulated genomes and their statistical analysis also play a central role in design-
ing and validating bioinformatics tools as well as in population studies in relation to linkage analysis. Our
simulation environment uses advanced programming techniques such as lazy computation, efficient index-
ing, metadata manipulation, and deterministic randomization to achieve a spectacular improvement over
similar naive implementations. This environment addresses the following concerns:
• Large Data Sizes: The sequences we deal with are huge, ranging from a few hundred mega-bases (a
single chromosome) to a few giga-bases (multiple genomes). Furthermore, when performing popula-
deletion duplication
, and
substitution
. In each process, the tar-
FIG. 2. The three processes during graph evolution:
,
i
k
get node (clear circle) is chosen with preference for nodes with larger degrees: if the -th node has degree i, the prob-
ki
}
^
ability of it being chosen is proportional to
. In deletion (A), a pair of edges of the target node (thick
N
kj
j51
black arrows), one incoming and one outgoing, is randomly chosen and deleted, and a new edge (thick black arrow) is
added between the ascendent and descendent nodes (black filled circles). In duplication (B), new edges are added be-
tween the target node and the ascendent/descendent nodes (black filled circles) of an edge (thick black arrow) randomly
chosen to be deleted. In substitution (C), a randomly chosen pair of edges of the target node (thick black arrows), one
incoming and one outgoing, is rewired to a randomly chosen substitute node (gray filled circle with a thick boundary).
Note that all the processes during graph evolution preserve the equality of the in-degree and out-degree of each node.
261

MISHRA ET AL.
tion simulation studies, we deal with multiple (potentially, a few billion) copies which change at every
generation.
• Large Data Movements: The mutations we consider (e.g., transpositions and deletions) are expensive
to simulate in a naive way. This is a serious problem, which forces researchers to abandon detailed
simulation at a base-pair resolution, and opt instead to simulate the changes in the positions of just a
few markers on the sequence.
Genome evolution, using the simulation engine described above, is studied through an “abstract machine”
(the genome grammar; Fig. 3) that provides a quick means of specifying sequences with specific statistical
properties. This simple programming language, with basic types consisting of sequences, transformations
(i.e., mutations), numbers (encoding both deterministic and probabilistic events), and primitive operations,
allows one to generate sequences with very specific probability distributions.
Language for interaction
The genome of an organism admits a simple mathematical description and a convenient representation
in a computer (with augmented annotation). In contrast, there is no simple way of describing the cell, ei-
ther statically or temporally (dynamically). We have been creating a formalism of combinatorial and nu-
merical (entropic) structures on spaces of sequences which reflect, to some degree, the organization and
functions of DNA and proteins. This formalism, called genoplex, distinguishes specific subsets of segments
(e.g., exons within an ORF or CIS-regulatory elements) and assigns to each subset labels indicating the na-
ture of the relationship among the elements within that subset.
Open questions
Several interesting questions remain to be further explored:
• Models of Biochemical Processes Involved in Evolution: The key genome duplication processes and
their biology remain poorly understood. How can we accurately model such processes as (a) unequal
crossing over, (b) DNA polymerase slippage, and (c) heterologous recombination? Do the evolution
dynamics drive the statistical structures of the genomes to a limit distribution, or do they themselves
acquire other derived dynamic properties? How do these processes interact with processes involved in
selection? How are they modified in a disease? For instance, in a polyclonal tumor, oncogenes tend to
acquire higher copy numbers, while tumor suppressor genes tend to be deleted (Lucito et al., 2000).
How can we understand these processes in the disease state or in mutants?
• Evolutionary Selection at Proteome Level: Our genome models and genome grammar need to be fur-
ther modified to model duplications of the protein domains. How can we use these properties to create a
precise understanding of the protein-protein interaction data obtained from “two-hybrid” experiments?
FIG. 3. A genome grammar example.
262

A SENSE OF LIFE
• Evolutionary Selection at Interactome Level: How can we take our models to the next level to un-
derstand the relations among the transcription factors, regulatory elements, and genes? These models
will be essential for interpreting gene-expression profiles obtained from microarray experiments.
• Motifs and their Robustness: What are the common motifs in regulatory pathways? Why is there a
preponderance of a few motifs, and not all the possible ones? What are the common modules? How
are they organized? Are topological descriptions of these motifs sufficient for understanding their func-
tions? How can we study pathways, such as RAS/PKC/MAPK or the ones involved in cell cycle, to
understand their multiple modes? Why are these motifs and their modes so robust?
• Hierarchical Organization: How can we design a language for describing, modifying, and trans-
forming biological models that can take advantage of these intriguing but elegant structures? Can we
use these properties to design mutants, double-mutants, “knock-outs,” and other experimental systems
to validate and understand our models?
ADVANCED TOOL ARCHITECTURES
In the domain of most immediate interest, namely, post-genomic biology, the conventional concept of a
distributed set of tools, made available through a web-browser interface, fails to adequately respond to the
challenges, complexity, and exponentially-growing demands. Thus, we aim at applying our expertise to cre-
ate a tool architecture that has the following properties: (a) flexibly composable software-modules, (b) sup-
ports for multiple scripting languages, software libraries, and multiple computer architectures, (c) free-for-
mat databases, inter-operating between multiple formats, (d) capabilities for rapid prototyping to handle
new experiments, and (e) easy integration of domain-knowledge.
Below, we describe some of the tools that address a few of the issues described above.
Valis
Valis is an environment for exploring problems in bioinformatics. The core components of the Valis proj-
ect are the underlying database structure and the algorithmic development platform. The Valis database al-
lows the user to analyze very large genetic sequences. Data structures that allow fast string matching to
support analyses like mer-frequency analysis have been limited to sequences of approximately 100 million
base pairs (Mbp). The Valis database allows for the creation of annotated sequences that are much larger
than this limit. Many similar database systems rely on large binary object support in standard relational
databases and on fixed formats of limited varieties to represent the necessary annotations for this analysis.
It is our experience, however, that in exploring genetic data, annotations are often of arbitrary size and for-
mat. The underlying Valis database allows the use of sets, types, and reference counting in the annotation
scheme while keeping both the storage requirements and the run-time cost of manipulating the annotated
sequences low. The algorithmic development platform is another innovative area of the Valis system.
The Valis environment can be reviewed as a novel cross-language scripting platform. Algorithms im-
plemented by a research group in one language can be utilized as building blocks in scripts by others. Valis
currently supports scripting in many languages: Perl, Python, ECMAScript (JavaScript), Visual Basic, R
(public domain S-plus), and Octave. Scripts can leverage one of the many public domain software libraries
that we have incorporated into Valis. It also incorporates the Gnu Scientific Library (GSL) for additional
support with standard numerical algorithms. Valis provides numerous visualization tools that allow the user
to quickly display sequences, maps, microarray data, tables, graphs, and annotations. These widgets can be
customized from the scripts.
Simpathica
Simpathica and the related XS-system allow the user to describe and interact with biochemical reactions.
The system consists of three major components: the frontend, used for describing the model concisely; the
core, used for creating internal representations of the model; and the backend, used for deriving the prop-
erties of the model of interest.
263

MISHRA ET AL.
Using a simple graphical or textual representation like SBML (Systems Biology Markup Language) or MDL
(Model Description Language), a mathematical description in terms of DAE (differential algebraic description),
ODE, PDE, SDE, or Stochastic interactions is implemented in a Gillespie-like algorithm. Simpathica also cre-
ates an alternate description of the system and related data. When the system consists of many modules, they
are represented individually, at many levels of abstraction, and with rules for compositionality.
The system supports a wide range of analysis tools: model checking with a propositional branching-
time temporal logic, time-frequency analysis tools with wavelets, linear discriminant bases, Karhunen-
Loeve analysis, clustering using wavelet-bases, information-theoretic approaches to measure the signif-
icance of the system components, and approaches based on statistical learning theory. All these systems,
and a database for trajectory (with an architecture similar to NYUMAD) were developed under the larger
BioComp/BioSPICE (supported by DARPA) effort and are available on the web (www.biospace.org).
NYUMAD
We have also developed a system to maintain and analyze biological abundance data (e.g., microarray
expression levels or proteomic data) along with the associated experimental conditions and protocols. The
prototype system is called the NYU MicroArray Database (NYUMAD) and is in the process of being ex-
panded to deal with many other related experiments. It uses a relational database management system for
data storage and has a flexible database schema that has been designed to store any type of abundance data
along with general research data, such as experimental conditions and protocols. The database schema is
defined using standard SQL (Structured Query Language) and is therefore portable to any SQL database
platform. NYUMAD supports the MAGE-ML standard (www.mged.org/Workgroups/MAGE/mage-
ml.html) for the exchange of gene expression data, defined by the Microarray Gene Expression Data Group
(MGED), and is accessible via the web.
NYUMAD is a secure repository for both public and private data. Users can control the visibility of their
data, so that initially the data might be private, but after the publication of the results the data can be made
visible to the larger research community. Data analysis tools are supplemented with visualization tools. The
goal is to not only provide a set of existing techniques but to continually incorporate increasingly sophis-
ticated and mathematically robust methods in data analysis and to provide links and integration with our
other tools, such as the Valis system.
Further development
Other areas that need to be further developed in our tool architecture include:
• Extension of the Database: As the systems described here evolve to encompass more complex and
general models, they must acquire abilities to integrate other novel data sources: for example, pro-
teomic data, ChIP (Chromatin Immuno-Precipitation) data, and mass-spectroscopic data. In response
to these demands, the database schemas must be generalized and new XML-based formats introduced.
Both Valis and Simpathica systems must be able to integrate new sources of experimental data as well
as provide more cogent forms of visualization.
• Integration: We expect new bioinformatics systems to become continually available either in the pub-
lic domain or from our collaborators. We need to develop a framework to integrate them into the larger
system effortlessly.
• Dissemination: Finally, there are many issues involved in how other users and developers can access
and improve the system collaboratively.
EXPERIMENTAL RESEARCH
A computational system developed for biological sciences and biotechnology will fail to be relevant if
it does not recognize the observational and experimental nature of its sister fields since its very conception.
“Experimentation without imagination and imagination without recourse to experimentation” would yield
either myopic anecdotes or barren theories.
264

A SENSE OF LIFE
We also note that the current demands from industrial and governmental applications (e.g., homeland se-
in silico
curity, rational drug discovery, and population studies) cannot simply rely on
tools without con-
comitant trials on real biological substrates. Our experience with such trials on real biological systems will
inspire confidence (from the other practitioners in the community) that the toolkit being made available by
our team has indeed been field-tested.
Time-Course in vitro and in vivo data
The most interesting data points for our study will be time-course data, describing the genome, tran-
scriptome, and proteome within a single cell, or an even more detailed picture, if the technology to perform
compartmentalized single cell analysis becomes available. In the absence of such technology, we have to
make do with mRNA collected from a small population of cells, where individual cells within the popula-
tion may be moving through the cell cycle in an unsynchronized manner. Of course, without the proteomic
data, transcriptomes tell less than half the story. The dynamics within the cell cannot be adequately de-
scribed by the abundance data. We need to know all the important “time-constants,” taking into account
such effects as mRNA stability, protein degradation, multi-merization, and modification. Nonetheless, the
experimental systems considered here can be easily extended with further technological improvements.
Microarray and gene-chip technologies provide an approach (to monitor the whole genome on a single
chip) for studying interactions among thousands of genes simultaneously under many different experimen-
tal conditions. However, in many applications the key problem has been statistical noise in the data, at-
tributable to non-specific hybridization, cross-hybridization, competition, diffusion of the target on the sur-
face, or base-specific structural variations of the probe. A better understanding of this noise will come from
the kinetic analysis of the base-pairing, denaturing, and diffusion processes; these processes are extensively
studied by us, in order to deconvolve the transcriptional dynamics associated with cellular functions.
One can replace the hybridization-based gene expression analysis by any technology that allows rudi-
mentary processes for “resequencing,” that is, checking whether a particular DNA strand is composed of a
given known sequence of bases. Sequenom has developed one such gene expression technology using their
mass-spectroscopy based approach to “resequencing.” (See Ding and Cantor, 2003.) The technology has
many advantages: it creates less noisy data as it does not suffer from various kinds of error processes listed
earlier for microarrays; it could potentially calibrate for mRNA stability; and finally, as more and more
genes are identified, it could be easily adapted to account for the new transcriptomes.
It is quite obvious to us that our tools can be used in other applications too: (a) gene discovery, (b) dis-
ease diagnosis, (c) drug discovery (pharmacogenomics), or (d) toxicological research. Hence, they are de-
veloped with a flexible structure.
Experimental systems
Below, we describe two representative experimental systems that we are studying at length. Additional
systems we are exploring include whole-genome ChIP assays, processes involved in apoptosis, circadian
clocks, RAS/PKC/MAPK pathways, cell cycle models, the immune system, positional-information based
models and their effects on patterning and segmentation, processes involved in developmental biology,
processes involved in DNA replication, repair, and recombination, and many others.
• Co-Cultivation Experiments: Cells have a complex system of interacting signal transduction path-
ways by which external stimuli, such as hormones, growth factors, or cell–cell and cell–matrix con-
tacts, direct the function of intracellular proteins and gene expression. Until recently it has been im-
possible to view as an ensemble the complex responses cells make to these various stimuli. However,
with the advent of DNA microarrays and because of the development of inducible gene expression sys-
tems and short interfering RNA systems, it is now possible to perturb the expression of one specific
gene at a time in the cell and measure the cell’s response. For instance, in order to obtain a clearer pic-
ture of how the RAS oncogene (a gene that, when mutated, can contribute to cancerous growth) be-
haves, we can study how it induces various transcriptional changes (Wigler, 1990). RAS is a central
component of many signal transduction pathways, and the induction of RAS causes a large number of
changes within cells, the exact changes depending on the host cell in which it is induced. We can ask
265

MISHRA ET AL.
whether the changes in gene expression induced by RAS are the indirect consequence of the produc-
tion of extracellular factors, which then act upon the cell producing them and its neighbors. One way
of differentiating direct from indirect changes is by their temporal order, with early responses being
direct, and some later responses being indirect. To examine this hypothesis more clearly, we look at
the response of mixed populations of cells. One cell component is engineered to induce RAS expres-
sion following stimulation with an artificial insect hormone. The other component is of the same cell
type, but not RAS inducible. After induction, the two populations are separated, and their responses
examined by the analysis of microarray data. This may be a generally applicable technique to discover
the existence of factors involved in cell–cell communication.
• Stem-Cell Experiments: The dynamics of stem cell proliferation are poorly defined, yet stem cells
are vital for growth, healing, and the general homeostasis of many animal and plant tissues. Thus, stud-
C. elegans
ies to address the basic biology of stem cells are paramount. The nematode
venient and well-characterized system to study stem cells (Hubbard and Greenstein, 2000). The adult
C. elegans
provides a con-
germ line is a polarized tissue with a distal stem-cell population at the end of the tube-like
gonad and differentiated cells located further proximally. Cell division in the distal zone gives rise to
germ cells that enter the meiotic pathway and eventually form gametes (eggs and sperm). Actively di-
viding cells (a mitotic process) are observed some 20–25 cell-diameters away from the distal tip, de-
spite the membrane-bound nature of the ligand hypothesized to be responsible for signaling through a
Notch-like pathway. A plausible model for such zone-division between mitotic and meiotic cells in the
gonad has not been experimentally confirmed and has remained elusive.
C. elegans
We are building and testing a rigorous computational model with analysis tools for
germ
line stem-cell growth, based on real observations of cell division patterns in the distal mitotic zone.
For each possible hypothesis, a probabilistic model capturing the “spatio-temporal, hybrid, and sto-
in
chastic” nature of this problem is created and can be verified through the Simpathica system and
vivo
experiments involving wild types and several mutants.
Further development
Other areas that need to be further developed include the following:
• A Taxonomy of Models and Experiments: Clearly, the example experiment systems that we, as a
group, can adequately address represent only a small fraction of the many diverse systems that biolo-
gists are interested in. We must pay special attention to educating current and future generations of bi-
ologists in how to extend these examples. In particular, we must show by example how experiments
and theories can coevolve in biology.
• Novel Experimental Systems: We must expect the biochemical techniques to continue to make sig-
nificant improvements in the coming decades, perhaps enabling very fast whole-genome sequencing
(Lai et al., 1999), high-throughput measurements of transcriptional and translational profiles, and even
real-time monitoring of activities of single cells in a population. How can these new experimental sys-
tems be interfaced to our project seamlessly?
• Generating Falsifiable Experiments: As we gather many isolated models addressing different aspects
of biology, a coherent picture will emerge, and yet, it will point to new mysteries and paradoxes. These
can be resolved by proposing experiments that will either strengthen hypotheses consistent with the
existing theories or falsify certain beliefs. Thus, a major component of our work must also focus on
creating a knowledge base that can allow the researchers to access our current knowledge and quickly
assess if there are inconsistencies.
ACKNOWLEDGMENTS
The work reported in this paper was supported by grants from DARPA’s BioComp project (“Algorith-
mic Tools and Computational Frameworks for Cell Informatics”) and AFRL contract (contract F30602-01-
2-0556).
266

A SENSE OF LIFE
REFERENCES
Molecular Biology of the Cell
ALBERTS, B., BRAY, D., LEWIS, J., et al. (1995).
, 3rd ed. (Garland, New York).
ANTONIOTTI, M., POLICRITI, A., UGEL, N., et al. (2002). xS-systems: eXtended S-systems and algebraic differ-
ential automata for modeling cellular behavior. Presented at the InternationalConference on High-PerformanceCom-
puting, Bangalore, India.
ANTONIOTTI, M., PARK, F., POLICRITI, A., et al. (2003). Foundations of a query and simulation system for the
modeling of biochemical and biological processes. Presented at the Pacific Symposium on Biocomputing, Hawaii.
ANTONIOTTI, M., PARK, F., POLICRITI, A., et al. (2003). Simulating large biochemical and biological processes
and reasoning about their behavior. Presented at the International Conference on Systems Biology, Sweden.
ANTONIOTTI, M., POLICRITI, A., UGEL, N., et al. (2003). Model building and model checking for biochemical
processes. Cell Biochemistry and Biophysics (CBB) 38, 271–286.
BAILEY, J.A., GU, Z., CLARK, R.A., et al. (2002). Recent segmental duplicationsin the human genome. Science 297,
1003–1007.
BHALLA, U.S., and IYENGAR, R. (1999). Emergent properties of networks of biological signaling pathways. Science
283, 381–387.
BULDYREV, S.V., GOLDBERGER, A.L., HAVLIN, S., et al. (1993). Fractal landscapes and molecular evolution:
modeling the myosin heavy chain gene family. Biophysics 65, 2673.
Genomics: The Science and Technology Behind the Human Genome Project
CANTOR, C., and SMITH, C. (1999).
(Wiley, New York.)
Fundamentals of Enzyme Kinetics
CORNISH-BOWDEN, A. (1999).
(Portland Press, London.)
DAMM, W., and HAREL, D. (2001). LSCs: breathing life into message sequence charts. Formal Methods in System
Design 19, 45–80.
DING, C., and CANTOR, C.R. (2003). A high-throughputgene expression analysis technique using competitive PCR
and matrix-assistedlaser desorption ionization time-of-flight. MS. Proceedings of the National Academy of Sciences
USA 100, 3059–3064.
EFRONI, S., HAREL, D., and COHEN, I.R. (2003). Towards rigorous comprehension of biological complexity: mod-
eling, execution, and visualizationof thymic T cell maturation. Genome Research (special issue on systems biology).
Tempral Logic: Mathematical Foundations and
GABBAY, D.M., HODKINSON, I., and REYNOLDS, M. (1994).
Computational Aspects, Volume 1
(Clarendon Press, Oxford.)
GERSTEIN, M., QIAN, J., and LUSCOMBE, N.M. (2001). Protein family and fold occurrence in genomes: power-
law behavior and evolutionary model. Journal of Molecular Biology 313, 673–681.
GUET, C.C., ELOWITZ, M.B., HSING, W.H., et al. (2002). Combinatorial synthesis of genetic networks. Science 296,
1466–1470.
HAREL, D. (1987). Statecharts:a visual formalism for complex systems. Science of Computer Programming 8, 231–274.
HAREL, D., and GERY, E. (1997). Executable object modeling with statecharts. Volume 30, Computer 31–42.
Lecture Notes in Computer Science
HAREL, D., EFRONI, S., and COHEN, I.R. (2003). Reactive animation.
Verlag, New York).
(Springer-
Come, Let’s Play: Scenario-Based Programming Using LSCs and the Play-
HAREL, D., and MARELLY, R. (2003).
Engine
(Springer-Verlag, New York).
HUBBARD, E.J.A., and GREENSTEIN, D. (2000). The
opmental biology. Developmental Dynamics 218, 2–22.
Caenorhabditis elegans
gonad: a test tube for cell and devel-
KAM, N., HAREL, D., and COHEN, I.R. (2001). Modeling biological reactivity: statecharts vs. Boolean Logic. Pre-
sented at the Second International Conference on Systems Biology (ICSB2001).
C. elegans
KAM, N., HAREL, D., KUGLER, H., et al. (2003). Formal modeling of
development: a scenario-basedap-
proach. Presented at Computational Methods in Systems Biology, First International Workshop.
Plasmodium falciparum
LAI, Z., JING, J., ASTON, C., et al. (1999). A shotgun optical map of the entire
genome. Na-
ture Genetics 23, 309–313.
LUCITO, R., WEST, J., REINER, A., et al. (2000). Detecting gene copy number fluctuations in tumor cells by mi-
croarray analysis of genomic representations. Genome Research 10, 1726–1736.
MISHRA, B. (2002). A symbolic approach to modelling cellular behavior. Presented at the International Conference
on High-Performance Computing, Bangalore, India.
Geometrical Foundations of Robotics
MISHRA, B. (2000). Computational differentialalgebra.
apore, 111–145.
(World-Scientific,Sing-
MISHRA, B., and CLARKE, E.M. (1985). Hierarchical verificationof asynchronouscircuits using temporal logic. The-
oretical Computer Science 38, 269–291.
Evolution by Gene Duplication
OHNO, S. (1970).
(Springer-Verlag, New York).
267

MISHRA ET AL.
PAXIA, S., RUDRA, A., ZHOU, Y., et al. (2002). A random walk down the genomes: DNA evolution in VALIS. Com-
puter 35, 73–79.
PENG, C.-K., BULDYREV, S.V., GOLDBERGER, A.L., et al. (1992). Long-rangecorrelationsin nucleotidesequences.
Nature 356, 168–170.
Biochemical System Analysis: A Study of Function and Design in Molecular Biology
SAVAGEAU, M.A. (1976).
(Ad-
dison-Wesley, New York).
Computational Analysis of Biochemical Systems
VOIT, E.O. (2000).
(Cambridge University Press, Cambridge).
VULIC, M., LENSKI, R.E., and RADMAN, M. (1999). Mutation, recombination, and incipient speciation of bacteria
in the laboratory. Proceedings of the National Academy of Sciences USA 96, 7348–7351.
WIGLER, M. (1990). Oncoproteins. GAPs in understanding Ras. Nature 346, 696–697.
WIGLER, M., and MISHRA, B. (2002). Wild by nature. Science 296, 1407–1408.
Address reprint requests to:
Dr. Bud Mishra
715 Broadway, Rm. 1002
New York, NY 10003
E-mail:
mishra@nyu.edu
268
