252
A. Martinez et al. / Journal of Catalysis 234 (2005) 250–255
◦
Scheme 2. Synthesis of complex 2. (a) Allyl bromide, CH Cl –H O, n-Bu NOH, 95%; (b) n-BuLi, Et O, (CH ) CO, −78 C, 65%;
2
2
2
4
2
3 2
◦
(c) NAH-THF, diethylene glycol ditosylate, DMF, 55%; (d) TMEDA, n-BuLi, Et O, DMF, −90 C, 40%; (e) Pd(PPh ) , MeOH, K CO , 86%;
2
3 4
2
3
(f) (1R,2R)-(−)-diaminocyclohexane, Mn(OAc) · 4H O, EtOH; (g) air, NaCl, 82%.
2
2
of 3 was protected with an allyl group to yield 4 [11]. Lithi-
ation of 4 with n-BuLi followed by quenching with acetone
produced 5 [12]. This key step corresponds to introduction
of the bulky substituents in positions 3 and 3ꢀ of the fi-
nal salen ligand. The polyether linker was introduced by
a Williamson reaction to yield 6 [13]. A diformylation re-
action followed by the deprotection of the phenol group
under mild conditions led to 7 [10,14]. The template syn-
thesis of complex 2 was achieved by mixing stoichiometric
amounts of 7, (1R,2R)-(−)-trans-1,2-diaminocyclohexane,
and Mn(OAc)2 · 4H2O, with subsequent air oxidation and
axial ligand exchange.
an acyclic olefin conjugated to an aryl group, the epoxida-
tion is nonstereospecific and affords a mixture of cis- and
trans-epoxides. A stepwise process with formation of a rad-
ical intermediate was proposed to rationalize these results
[16,17]. Using chromene as substrate, we tested the catalytic
activities of complex 2 with several oxygen atom donors
(Table 1, entries 10, 15, and 16). We obtained the best re-
sults with sodium hypochlorite in a quantitative yield with
a 100% selective formation of the corresponding epoxide
and an enantiomeric excess of 93% (Table 1, entry 10). The
ee values were 81% with PhIO and 82% with H2O2 (Ta-
ble 1, entries 15 and 16), the reaction being rather slow with
the green oxidant H2O2. In a general trend, the best ee val-
ues were obtained with NaOCl as an oxygen atom donor
for complex 2 (Table 1, entries 2 and 10), whereas com-
plex 1 gave a better stereoinduction with PhIO as oxidant
(Table 1, entries 5 and 14). These results suggest that the
nature of the active high-valent species will differ depend-
ing on the nature of the catalyst and the oxidant. In the case
of complex 1 associated with PhIO, the PhI group could be
involved in the transition state of the “Mn(salen)-oxo like”
species (PhIO–(salen)MnV=O or (salen)MnIV–OIPh), thus
inducing a better stereoinduction than with NaOCl. With cat-
alyst 2 bearing bulky substituents in positions 3 and 3ꢀ of the
ligand, such species are perhaps less involved, because of
steric hindrance, and a pure (salen)MnV=O could be the ma-
jor oxygen-transfer agent. But several other minor oxidizing
species should be involved, as proposed in the literature [17],
explaining the differences observed for the enantiomeric ex-
cesses.
3.2. Enantioselective epoxidation of cis-disubstituted
olefins
An evaluation of the catalytic activity of complex 2 was
performed with three cis-disubstituted olefins. Typical reac-
tion conditions were complex 2 (5 mol%), substrate (1 eq.),
an oxygen atom donor (NaOCl, PhIO, 2 eq. or H2O2, 3 eq.),
and the axial ligand 4-phenylpyridine N-oxide (4-PPNO,
5 eq. with respect to the catalyst). The reactions were car-
ried out at 0 ◦C for 2 h; the results are reported in Table 1.
With the three olefins used and sodium hypochlorite as ox-
idant, asymmetric induction was obviously increased for
complex 2 compared with catalyst 1 (Table 1, entries 1–2,
7–8, and 9–10). This is due mainly to the introduction of
bulky substituents in the close proximity to positions 3
and 3ꢀ of the ligand. With 1,2-dihydronaphthalene as sub-
strate, the yields of epoxide and naphthalene are in the same
range for both catalysts (entries 1–2). Naphthalene is the
main byproduct in this catalytic oxidation and results from
a dehydrogenation reaction [15]. For cis-β-methylstyrene
and 2,2ꢀ-dimethylchromene as substrates, catalyst 2 gives
slightly better conversions and epoxide yields (entries 7–8
and 9–10, respectively). In the case of cis-β-methylstyrene,
3.3. Recyclability of catalyst 2
We also tested the stability under the oxidative condi-
tions of complex 2. We have already reported that com-
plex 1 was not recyclable. The reuse of catalyst 2 was im-
