B. Alcaide, P. Almendros et al.
General Procedure for PdII-catalyzed coupling of g-allenols 4 with allyl
bromides—preparation of fused tetrahydrooxepines 7: PdCl2
(0.005 mmol) was added to a stirred solution of the corresponding g-alle-
nol 4 (0.10 mmol) and the appropriate allyl bromide (0.50 mmol) in N,N-
dimethylformamide (0.6 mL). The reaction mixture was stirred under
argon until disappearance of the starting material (TLC). Water (0.5 mL)
was added before extraction with ethyl acetate (3ꢃ4 mL). The organic
phase was washed with water (2ꢃ2 mL), dried (MgSO4), and concentrat-
ed under reduced pressure. Chromatography of the residue with elution
with hexanes/ethyl acetate mixtures gave analytically pure fused tetrahy-
drooxepines 7.
Experimental Section
General methods: 1H NMR and 13C NMR spectra were recorded with
Bruker Avance 300, Varian VRX 300S, or Bruker AC 200 instruments.
NMR spectra were recorded in CDCl3 solutions, except when otherwise
stated. Chemical shifts are given in ppm relative to TMS (1H, 0.0 ppm) or
CDCl3 (13C, 76.9 ppm). Low- and high-resolution mass spectra were
taken with a HP 5989 A spectrometer in electronic impact (EI) or elec-
trospray (ES) modes unless otherwise stated. Specific rotations ([a]D) are
given in 10ꢀ1 degcm2 gꢀ1 at 208C, and concentrations (c) are expressed in
g per 100 mL. All commercially available compounds were used without
further purification.
General Procedure for the AuIII-catalyzed cyclizations of g-allenols (ꢀ)-
4a, (+)-4c, and (+)-4g—preparation of fused tetrahydrofurans 5: AuCl3
(0.05 mmol) was added under argon to a stirred solution of the corre-
sponding g-allenol 4 (1.0 mmol) in dichloromethane (1.0 mL). The result-
ing mixture was stirred at room temperature until disappearance of the
starting material (TLC). The reaction was then quenched with brine
(1.0 mL), the mixture was extracted with ethyl acetate (3ꢃ5 mL), and
the combined extracts were washed twice with brine. The organic layer
was dried (MgSO4) and concentrated under reduced pressure. Chroma-
tography of the residue with elution with ethyl acetate/hexanes mixtures
gave analytically pure tetrahydrofuran adducts 5. Spectroscopic and ana-
lytical data for a representative compound of type 5 follow.[21]
Fused tetrahydrooxepine (+)-7d: g-Allenic alcohol (+)-4c (20 mg,
0.06 mmol), after chromatography of the residue with hexanes/ethyl ace-
tate 3:1, gave the tetrahydrooxepine (+)-7d (22 mg, 94%) as a colorless
oil. [a]D =+5.2 (c=2.3 in CHCl3); 1H NMR (300 MHz, CDCl3, 258C):
d=5.74 (m, 2H), 5.17 (m, 2H), 5.08 (m, 2H), 5.04 (m, 1H), 4.53 (d, J=
4.4 Hz, 1H), 4.52 (m, 1H), 4.25 (dt, J=5.1, 1.5 Hz, 1H), 3.96 (dt, J=16.3,
1.7 Hz, 1H), 3.63 (dd, J=9.3, 4.4 Hz, 1H), 3.62 (m, 1H), 2.66 and 2.48
(dd, J=16.0, 6.0 Hz, each 1H), 1.69 (s, 3H), 0.96 (s, 9H), 0.12 and
0.07 ppm (s, each 3H); 13C NMR (75 MHz, CDCl3, 258C): d=166.1,
134.2, 131.5, 131.3, 126.3, 118.3, 115.2, 81.3, 74.0, 72.5, 61.8, 44.3, 34.2,
25.7, 18.0, 14.1, ꢀ4.8, ꢀ4.9 ppm; IR (CHCl3): n˜ =1744 cmꢀ1; MS (ES):
m/z (%): 364 (100) [M+H]+, 363 (17) [M]+; elemental analysis calcd
(%) for C20H33NO3Si (363.6): C 66.07, H 9.15, N 3.85; found: C 66.20, H
9.10, N 3.82.
Fused tetrahydrofuran (+)-5c: g-Allenic alcohol (+)-4c (50 mg,
0.15 mmol), after chromatography of the residue with hexanes/ethyl ace-
tate 4:1, gave the tetrahydrofuran (+)-5c (28 mg, 58%) as a colorless oil.
[a]D =+68.6 (c=0.5 in CHCl3); 1H NMR (300 MHz, CDCl3, 258C): d=
5.96 (dd, J=17.6, 11.0 Hz, 1H), 5.76 (m, 1H), 5.29 (m, 1H), 5.23 (m,
2H), 5.16 (d, J=3.7 Hz, 1H), 5.08 (dd, J=11.0, 0.7 Hz, 1H), 4.11 (s, 1H),
3.93 (d, J=3.7 Hz, 1H), 3.90 and 3.54 (m, each 1H), 1.31 (s, 3H), 0.92 (s,
9H), 0.11 ppm (s, 6H); 13C NMR (75 MHz, CDCl3, 258C): d=162.1,
142.2, 131.6, 119.5, 113.4, 91.7, 86.6, 75.2, 66.1, 43.6, 25.8, 25.7, 24.0, ꢀ4.8,
ꢀ5.0 ppm; IR (CHCl3): n˜ =1746 cmꢀ1; MS (ES): m/z (%): 324 (100)
[M+H]+, 323 (10) [M]+; elemental analysis calcd (%) for C17H29NO3Si
(323.5): C 63.12, H 9.04, N 4.33; found: C 63.00, H 8.99, N 4.36.
Fused tetrahydrooxepine (+)-7e: g-Allenic alcohol (+)-4g (34 mg,
0.07 mmol), after chromatography of the residue with hexanes/ethyl ace-
tate 2:1, gave the tetrahydrooxepine (+)-7e (23 mg, 66%) as a colorless
oil. [a]D =+39.0 (c=1.3 in CHCl3); 1H NMR (300 MHz, CDCl3, 258C):
d=7.39 and 6.73 (d, J=8.5 Hz, each 2H), 7.07 (m, 10H), 6.62 (d, J=
9.8 Hz, 1H), 5.53 (m, 1H), 4.89 (m, 3H), 4.84 (d, J=4.4 Hz, 1H), 4.66
and 3.96 (d, J=15.4 Hz, each 1H), 4.20 (m, 1H), 4.11 (dd, J=9.8, 4.4 Hz,
1H), 3.83 (s, 3H), 2.40 ppm (d, J=6.6 Hz, 2H); 13C NMR (75 MHz,
CDCl3, 258C): d=165.2, 164.7, 163.3, 137.5, 135.3, 135.0, 134.9, 132.9
(2C), 131.3 (2C), 129.0, 128.6 (2C), 128.0 (2C), 127.6 (2C), 126.8 (2C),
121.8, 116.4, 113.1 (2C), 113.0, 82.6, 73.8, 73.5, 61.6, 55.3, 45.2, 35.8 ppm;
IR (CHCl3): n˜ =1745, 1730 cmꢀ1; MS (ES): m/z (%): 496 (100) [M+H]+,
495 (15) [M]+; elemental analysis calcd (%) for C31H29NO5 (495.6): C
75.13, H 5.90, N 2.83; found: C 75.27, H 5.85, N 2.80.
General procedure for the LaIII-catalyzed cyclization of g-allenols 4:
La[NACHTUNGTRENUNG(SiMe3)2]3 (0.05 mmol) was added under argon to a stirred solution
of the corresponding g-allenol 4 (1.0 mmol) in toluene (10.0 mL). The re-
sulting mixture was stirred at reflux temperature until disappearance of
the starting material (TLC). The reaction was then filtered through a
celite plug before being concentrated under reduced pressure. Chroma-
tography of the residue with elution with ethyl acetate/hexanes mixtures
gave analytically pure adducts 6, 13, and 14.
LaIII-catalyzed cyclization of g-allenol (ꢀ)-4a—preparation of fused dihy-
dropyrans (+)-6a and (+)-epi-6a: g-Allenic alcohol (ꢀ)-4a (99 mg,
0.31 mmol), after chromatography of the residue with hexanes/ethyl ace-
tate 4:1, afforded the less polar compound (+)-6a (52 mg, 44%) and the
more polar compound epi-6a (5 mg, 4%).
General Procedure for the AuIII-catalyzed cyclization of (methoxymethyl)-
oxy allenes 3—preparation of fused tetrahydrooxepines 11: AuCl3
(0.025 mmol) was added under argon to a stirred solution of the corre-
sponding methoxymethyl-substituted allene 3 (0.5 mmol) in dichlorome-
thane (0.5 mL). The resulting mixture was stirred at room temperature
until disappearance of the starting material (TLC). The reaction was then
quenched with brine (0.5 mL), the mixture was extracted with ethyl ace-
tate (3ꢃ3 mL), and the combined extracts were washed twice with brine.
The organic layer was dried (MgSO4) and concentrated under reduced
pressure. Chromatography of the residue with elution with ethyl acetate/
hexanes mixtures gave analytically pure tetrahydrooxepine adducts 11.
Fused dihydropyran (+)-6a: Colorless oil; [a]D =+33.2 (c=0.5 in
CHCl3); 1H NMR (300 MHz, CDCl3, 258C): d=7.31 (m, 5H), 5.05 (d,
J=5.0 Hz, 1H), 4.47 and 4.31 (d, J=15.0 Hz, each 1H), 3.83 (dd, J=5.0,
1.5 Hz, 1H), 3.75 (d, J=1.5 Hz, 1H), 1.80 and 1.44 (d, J=0.9 Hz, each
3H), 0.81 (s, 9H), ꢀ0.06 and ꢀ0.08 ppm (s, each 3H); 13C NMR
(75 MHz, CDCl3, 258C): d=165.9, 146.8, 135.7, 129.0 (2C), 128.4 (2C),
128.1, 106.8, 78.1, 67.1, 61.3, 44.8, 25.9, 25.7, 18.0, 16.9, ꢀ4.6, ꢀ4.8 ppm;
IR (CHCl3): n˜ =1746 cmꢀ1; MS (ES): m/z (%): 374 (100) [M+H]+, 373
(11) [M]+; elemental analysis calcd (%) for C21H31NO3Si (373.6): C
67.52, H 8.36, N 3.75; found: C 67.65, H 8.31, N 3.79.
Fused tetrahydrooxepine (+)-11b: Methoxymethyl-substituted allene
(ꢀ)-3 f (55 mg, 0.11 mmol), after chromatography of the residue with
hexanes/ethyl acetate 2:1, gave the tetrahydrooxepine (+)-11b (27 mg,
58%) as
a
colorless oil. [a]D =+26.3 (c=0.6 in CHCl3); 1H NMR
(300 MHz, CDCl3, 258C): d=7.80 and 7.60 (d, J=8.5 Hz, each 2H), 7.20
(m, 3H), 7.04 (m, 2H), 6.33 (d, J=9.8 Hz, 1H), 5.27 (m, 1H), 4.76 (d, J=
4.4 Hz, 1H), 4.62 and 4.13 (d, J=15.4 Hz, each 1H), 4.64 and 4.12 (m,
each 1H), 3.99 (dd, J=9.5, 4.4 Hz, 1H), 1.60 ppm (s, 3H); 13C NMR
(75 MHz, CDCl3, 258C): d=164.6, 162.2, 135.3, 132.2, 131.7, 131.8 (2C),
131.3 (2C), 128.7 (2C), 127.9, 127.7, 127.6 (2C), 122.7, 82.5, 75.1, 70.9,
61.3, 45.3, 20.3 ppm; IR (CHCl3): n˜ =1744, 1728 cmꢀ1; MS (ES): m/z (%):
443 (100) [M+2+H]+, 441 (11) [M+H]+; elemental analysis calcd (%)
for C22H20BrNO4 (442.3): C 59.74, H 4.56, N 3.17; found: C 59.62, H 4.53,
N 3.20.
Fused dihydropyran (+)-epi-6a: Colorless oil; [a]D =+14.6 (c=0.2 in
CHCl3); 1H NMR (300 MHz, CDCl3, 258C): d=7.28 (m, 5H), 4.94 (d,
J=5.0 Hz, 1H), 4.78 and 4.33 (d, J=15.5 Hz, each 1H), 4.48 (m, 1H),
4.12 (dd, J=5.0, 3.8 Hz, 1H), 1.84 (m, 3H), 1.63 (t, J=1.2 Hz, 3H), 0.90
(s, 9H), 0.07 and ꢀ0.01 ppm (s, each 3H); IR (CHCl3): n˜ =1746 cmꢀ1
;
Fused tetrahydrooxepine (+)-11c: Methoxymethyl-substituted allene
(+)-3i (40 mg, 0.08 mmol), after chromatography of the residue with hex-
anes/ethyl acetate 3:1, gave the tetrahydrooxepine (+)-11c (23 mg, 62%)
as a colorless oil. [a]D =+27.5 (c=0.7 in CHCl3); 1H NMR (300 MHz,
MS (ES): m/z (%): 374 (100) [M+H]+, 373 (9) [M]+; elemental analysis
calcd (%) for C21H31NO3Si (373.6): C 67.52, H 8.36, N 3.75; found: C
67.66, H 8.42, N 3.70.
