Attempted Isolation and Characterization of Diazirinone (N2CO)
Christopher J. Shaffer,† Brian J. Esselman,† Robert J. McMahon,*,† John F. Stanton,*,‡
and R. Claude Woods*,†
†Department of Chemistry, University of Wisconsin, 1101 University Avenue, Madison, Wisconsin
53706-1322, and ‡Institute for Theoretical Chemistry, Department of Chemistry and Biochemistry,
University of Texas, 1 University Station A5300, Austin, Texas 78712-0165
mcmahon@chem.wisc.edu; jfstanton@mail.utexas.edu; rcwoods@wisc.edu
Received December 14, 2009
Stimulated and intrigued by the report of the synthesis of diazirinone (1), a metastable adduct of N2
and CO, we carried out further experimental and theoretical studies aimed at the detailed spectro-
scopic characterization of this species. Our attempts to generate and detect diazirinone (1) in either
the condensed phase (using matrix isolation spectroscopy) or in the gas phase (using millimeter-wave
rotational spectroscopy), however, have been unsuccessful. Trapping the volatile products produced
from the reaction of 3-chloro-3-(p-nitrophenoxy)diazirine (5) with tetrabutylammonium fluoride
(TBAF) under matrix-isolation conditions affords chlorofluorodiazirine (8) and carbon monoxide
but fails to provide evidence for diazirinone (1). Moreover, sophisticated ab initio calculations of the
structure and fundamental vibrational frequencies of diazirinone (1) produce an estimate for the
fundamental band origin of the CdO stretch (2046 cm-1) that is ca. 100 cm-1 lower in frequency than
the experimental value previously attributed to this band. This discrepancy lies well outside any
expected solvent shift or calculation error at this level of theory. In an effort to reconcile our findings
with the earlier reports concerning diazirinone (1), we reconsidered the infrared spectral evidence
upon which the original claim of diazirinone synthesis was based. New experiments demonstrate that
these spectra may be explained and reproduced with a combination of solution-phase and gas-phase
absorptions of CO, without recourse to invoke diazirinone (1).
Introduction
7-norbornadienone,4 and tetranitrogen,5 provide opportu-
nities to probe the limits of chemical (in)stability. Each of
these molecules may undergo a highly exothermic decompo-
sition to its respective stable constituents, presenting a
potentially severe synthetic obstacle to isolation and char-
acterization. Comparison of diazirinone (1) and cyclopro-
penone provides insight concerning the nature of weakly
aromatic systems.6,7 The anticipated polarity of diazirinone
(1) makes it an interesting target to investigate via rotational
Diazirinone (1), the C2v conjugate of molecular nitrogen
and carbon monoxide, is an intriguing species, inasmuch
as it is a mixed dimer of the two most strongly bonded
diatomic molecules. Diazirinone (1), along with similar high-
energy, metastable compounds1 such as ethylenedione,2,3
(1) Hoffmann, R.; Hopf, H. Angew. Chem., Int. Ed. 2008, 47, 4474–4481.
€
(2) Schroder, D.; Heinemann, C.; Schwarz, H.; Harvey, J. N.; Dua, S.;
Blanksby, S. J.; Bowie, J. H. Chem.;Eur. J. 1998, 4, 2550–2557.
(3) Berson, J. A.; Birney, D. M.; Dailey, W. P.; Liebman, J. F. Mol.
Struct. Energ. 1988, 6, 391–441. , 445-446.
(4) LeBlanc, B. F.; Sheridan, R. S. J. Am. Chem. Soc. 1985, 107, 4554–
4556.
(5) Cacace, F.; de Petris, G.; Troiani, A. Science 2002, 295, 480–481.
(6) Korkin, A. A.; Balkova, A.; Bartlett, R. J.; Boyd, R. J.; Schleyer,
P. v. R. J. Phys. Chem. 1996, 100, 5702–5714.
(7) Skancke, A.; Liebman, J. F. J. Org. Chem. 1999, 64, 6361–6365.
DOI: 10.1021/jo9026462
r
Published on Web 02/12/2010
J. Org. Chem. 2010, 75, 1815–1821 1815
2010 American Chemical Society

Shaffer et al.
JOCFeatured Article
SCHEME 1a
SCHEME 2
aComputed energies (kcal/mol) of N2CO isomers,6,8,9 relative to dia-
zirinone (1).
spectroscopy, which could provide insights into the structure
and bonding of this peculiar molecule. The laboratory rota-
tional spectrum of 1 would also provide the basis to search
for diazirinone as a possible component of the interstellar
medium via radioastronomy. These considerations motiva-
ted us to initiate the studies described herein.
matrix-isolated N2CO isomers (NCNO, CNNO, NCON).12
De Petris et al. generated an N2CO isomer in a neutrali-
zation-reionization mass spectrometry (NRMS) experi-
ment.9 Careful analysis suggests that the isomer generated
is triplet NNCO (33), and persuasive arguments rule out both
diazirinone (1) and nitrosyl cyanide (2). Concurrently,
diazirinone (1) was reported as an unanticipated product
obtained during the preparation of chlorofluorodiazirine.10
When 3-chloro-3-(p-nitrophenoxy)diazirine (5) was treated
with molten tetrabutylammonium fluoride (TBAF), the
expected products, chlorofluorodiazirine (8) and p-nitrophe-
nol, were obtained only as minor products, while p-fluoro-
nitrobenzene (7) was obtained as a major product, along
with a transient species exhibiting an infrared absorption at
2150 cm-1 (Scheme 2). As the reaction mixture warmed
toward room temperature, the absorption at 2150 cm-1
decayed over 5-10 min, while a near-simultaneous increase
of CO absorptions at 2116 and 2169 cm-1 was observed. The
mechanism shown in Scheme 2 was used to rationalize the
experimental observations, and it was concluded that the
transient species produced was diazirinone (1). Subsequent
studies to prepare other dihalodiazirines consistently
produced p-fluoronitrobenzene (7), from which it was
assumed that diazirinone was also produced. Diazirinone
Diazirinone (1) is the lowest energy isomer on the
N2CO potential energy surface, other than CO þ N2
(Scheme 1).3,6,8-11 Nitrosyl cyanide (2), which is an isolable
species, lies ca. 15 kcal/mol higher in energy.8,11 The open-
chain isomer NNCO (3) is not bound on the singlet PES but
is a low-lying minimum on the triplet PES. The enthalpy
barrier for the dissociation of diazirinone (1) to N2 and CO is
ca. 27 kcal/mol, while the exothermicity of the reaction is ca.
100 kcal/mol.8,11 The barrier is consistent with the rate of
thermal decomposition attributed to 1.10 Korkin et al. noted
an interesting difference between the N2CO PES and the
isoelectronic PES of N4.6 In the case of N2CO, the tetra-
hedron-like isomer 4 is much higher in energy (115 kcal/mol)
than diazirinone (1), which was rationalized in terms of the
inherent formal charges. In the case of N4, the tetrahedral
structure is 10 kcal/mol lower in energy than the distorted
structure that is analogous to diazirinone.
In terms of experimental studies, Maier and co-
workers reported the photochemistry and spectroscopy of
(8) Korkin, A. A.; Schleyer, P. v. R.; Boyd, R. J. Chem. Phys. Lett. 1994,
227, 312–320.
(9) de Petris, G.; Cacace, F.; Cipollini, R.; Cartoni, A.; Rosi, M.; Troiani,
A. Angew. Chem., Int. Ed. 2005, 44, 462–465.
(10) Moss, R. A.; Chu, G.; Sauers, R. R. J. Am. Chem. Soc. 2005, 127,
2408–2409.
(11) Zhu, R. S.; Lin, M. C. J. Phys. Chem. A 2007, 111, 6766–6771.
(12) Maier, G.; Reisenauer, H. P.; Eckwert, J.; Naumann, M.; De Marco,
M. Angew. Chem., Int. Ed. Engl. 1997, 36, 1707–1709.
1816 J. Org. Chem. Vol. 75, No. 6, 2010

Shaffer et al.
JOCFeatured Article
FIGURE 1. Infrared spectrum (Ar, 10 K) of the volatile components from the reaction of p-nitrophenoxychlorodiazirine (5) and Bu4NþF- in
acetonitrile. Top: spectrum of volatile products that passed directly through a gas trap at 77 K without condensing. Bottom: spectrum obtained
after warming the trap to 263 K. All peaks can be assigned to either CO (2140 cm-1) or acetonitrile. Both plots are set to the same scale but are
offset by 2.5 absorbance units to allow for comparison.
was not isolated as a pure compound in any of these
studies.10,13-19
Utilizing a procedure similar to that described in the litera-
