A Copper-Containing Polyoxometalate-Based Metal−Organic
Framework as an Efficient Catalyst for Selective Catalytic Oxidation
of Alkylbenzenes
Baijie Xu, Qian Xu, Quanzhong Wang, Zhen Liu, Ruikun Zhao, Dandan Li, Pengtao Ma,
Jingping Wang,* and Jingyang Niu*
Cite This: Inorg. Chem. 2021, 60, 4792−4799
Read Online
sı
*
Metrics & More
Article Recommendations
Supporting Information
ACCESS
ABSTRACT: A copper-containing polyoxometalate-based metal−organ-
ic framework (POMOF), CuI12Cl2(trz)8[HPW12O40] (HENU-7, HENU
= Henan University; trz = 1,2,4-triazole), has been successfully
synthesized and well-characterized. In addition, the excellent catalytic
ability of HENU-7 has been proved by the selective oxidation of
diphenylmethane. Under the optimal conditions, the diphenylmethane
conversion obtained over HENU-7 is 96%, while the selectivity to
benzophenone is 99%, which outperforms most noble-metal-free POM-
based catalysts. Moreover, HENU-7 is stable to reuse for five runs
without an obvious loss in activity and also can catalyze the oxidation of
different benzylic C−H with satisfactory conversions and selectivities,
which implied the significant catalytic activity and recyclability.
catalysts did have praiseworthy catalytic performance for
selective oxidation of DPM to BP.27−34 However, POMs suffer
from some intrinsic drawbacks, including low specific surface
area, high water solubility, and difficult separation (reuse),
which shackle the further industrial applications of
POMs.32,33,35−38 Therefore, a promising solution is to select
a proper carrier and load the POMs.39 Simultaneously, metal−
organic frameworks (MOFs), which have tunable nanospaces
providing satisfactory accommodation for multitudinous guest
species, have been regarded as a new class of porous
materials.40−45 Thanks to their inherent tunability, MOFs
have cumulative application in gas storage, magnetism,
fluorescence, and catalysis. Moreover, it is a good choice to
synthesize polyoxometalate-based metal−organic frameworks
(POMOFs), which not only skillfully combine the strength of
POMs and MOFs but also circumvent the aforementioned
limitations of POMs,1,46−52 by building POMs into the entire
framework as a part of the skeleton. Aside from this way,
POMs also could be encapsulated in the pores of
MOFs46,53−56 to support the skeleton of POMOFs.27 It is
well-known that POMOFs can be tailored by judicious choice
INTRODUCTION
■
The selective oxidation of benzylic C−H to the corresponding
CO bond has recently attracted increasing attention in both
academic and industrial research.1−3 In this connection, the
oxidation product of diphenylmethane (DPM), especially
benzophenone (BP), is considered as a key intermediate for
the manufacture of many high-value chemicals such as
pharmaceutical, dyes, agrochemical, and perfumes.4−6 Tradi-
tionally, BP was mainly produced by the Friedel−Crafts
acylation reaction of aromatic compounds using a stoichio-
metric amount of homogeneous strong protonic acids (for
example, HF, H2SO4, etc.) or Lewis acids (such as AlCl3,
FeCl3, and BF3), which suffered from the generation of
corrosive and poisonous wastes.7,8 Aside from the traditional
route, a variety of stoichiometric quantities of oxidizing agents,
such as CrO3 and KMnO4, have been widely used in this
transformation, but they are gradually phased out due to the
formation of pollution.9−11 As a result, it is really highly desired
to develop a new catalytic system with environmentally
friendly hydroperoxide oxidants (e.g., H2O2
3,12,13
or tert-butyl
hydroperoxide14−21) that have outstanding catalytic perform-
ance along with easy separation in this oxidation reaction.
Polyoxometalates (POMs), as a class of nanosized discrete
anionic metal-oxide clusters, have drawn enormous attention
and are applied widely in many fields (e.g., magnetism,
medicine, electrochemistry, and especially in catalysis) because
of their unique physicochemical properties.22−26 In recent
years, many researchers have demonstrated POM-based
Received: December 22, 2020
Published: March 14, 2021
https://dx.doi.org/10.1021/acs.inorgchem.0c03741
© 2021 American Chemical Society
Inorg. Chem. 2021, 60, 4792−4799
4792

Inorganic Chemistry
pubs.acs.org/IC
Article
of metal ions, bridging organic ligands, and POMs. Numerous
studies in the literature reported that transition metals,57−60
especially copper atoms,34,61−66 could be considered as active
catalytic centers in many important oxidation processes and
the introduction of transition metals may facilitate the
formation of novel POMOFs. Herein, the introduction of
copper atoms is significant from the viewpoint of both catalytic
effect and synthesis strategies. In addition, considering that the
precise choices of bridging organic ligands may help us to
obtain the desired framework, which have satisfactory size,
channel, and so on, the logical choice and design of organic
ligands are crucial.49,67−77 Owing to its diverse coordination
modes (Scheme 1), 1,2,4-triazole (trz), as a tridentate ligand,
Taking these into account, the classic POM {H3PW12O40·
nH2O} (abbreviated as PW12) was handpicked to assemble
with trz and copper acetate to prepare novel POMOFs, which
could be employed as efficient catalysts to oxidize DPM. As a
result, using the one-pot self-assembly method, we have
successfully synthesized a copper-containing POMOF based
on PW12, formulated as CuI12Cl2(trz)8[HPW12O40] (HENU-
7), in which PW12 anions as guest species are encapsulated in
the cavities of frameworks. Furthermore, HENU-7 not only
exhibits excellent reactivity in selective oxidation of DPM to
BP with high conversion and selectivity, which presents similar
or better performance than known noble-metal-free POM-
based catalysts in the literature (Table S4), but also could be
recycled for at least five runs without an obvious loss in
activity. It is worth mentioning that, in the scale-up
experiment, the DPM conversion obtained over HENU-7 is
89%, while the selectivity to BP is 96%, which shows that it is a
very promising alternative catalyst in industrial applications.
Scheme 1. Diverse Coordination Modes of trz
EXPERIMENTAL SECTION
■
Synthesis of HENU-7. H3PW12O40·nH2O (0.587 g, 0.195 mmol)
was dissolved in 5 mL of deionized water, followed by the addition of
Cu(OAc)2·2H2O (0.256 g, 1.28 mmol) with stirring the solution for
15 min. Stirring for another 30 min is essential after adding trz (0.091
g, 1.32 mmol) into the above-mentioned solution. Afterward, 2 M
HCl was added dropwise into the solution to maintain the pH value at
1.57. The mixture was transferred into a 25 mL Teflon-lined autoclave
and further heated at 160 °C for 96 h under autogenous pressure, and
finally cooling down to room temperature at the rate of 10 °C/h. The
dark block crystals could be obtained and further collected by
filtration, washed with deionized water, and dried. Yield: 48% based
on W. Elemental analysis (%) calcd for CuI12Cl2(trz)8[HPW12O40]
has recently attracted increasing attention in synthetic
chemistry.70,78−84 Besides, as the most stable and available
POMs, Keggin-type POMs have a quasi-spherical architecture
and plenty of surface oxygen atoms, which have been widely
studied.50,72,85−87
Figure 1. Ball-and-stick and polyhedral representations of HENU-7. (a) Ball-and-stick representations of {Cu4Cl(trz)4} macrocycle. (b) Four
{Cu4Cl(trz)4} macrocycles combine to form a bigger macrocycle. (c) The frameworks in HENU-7. (d) Ball-and-stick and polyhedral
representations of PW12 anions. (e, f) 3D framework of HENU-7. (color code: WO6, sea green; P, pink; W, green; C, black; N, blue; Cu, turquiose;
O, red; H, gray-25%; Cl, yellow; green and pink dotted lines in (a) and (b) represent the size of the window, respectively.)
4793
https://dx.doi.org/10.1021/acs.inorgchem.0c03741
Inorg. Chem. 2021, 60, 4792−4799

Inorganic Chemistry
pubs.acs.org/IC
Article
Table 1. Effects of the Different Factors in the Catalytic Oxidation of DPM
b
c
d
entry
cat./mol %
TBHP /mmol (equiv)
T/°C
solvent
acetonitrile
conv. /%
sel. /%
a
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.2
0.3
0.4
0.6
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.25
3 (3)
3 (3)
3 (3)
3 (3)
3 (3)
3 (3)
3 (3)
3 (3)
3 (3)
3 (3)
3 (3)
3 (3)
2 (2)
2.5 (2.5)
3.5 (3.5)
4 (4)
3 (3)
3 (3)
3 (3)
3 (3)
30 (3)
75
75
75
75
75
75
75
75
75
75
75
75
75
75
75
75
65
85
75
75
75
96
67
70
40
50
57
48
35
85
92
94
96
83
88
90
92
82
96
89
91
89
99
95
99
92
98
98
99
89
98
98
99
99
93
99
98
99
98
99
98
97
96
2
3
4
5
6
7
8
9
dichloromethane
distilled water
ethanol
acetone
n-hexane
methanol
acetonitrile
acetonitrile
acetonitrile
acetonitrile
acetonitrile
acetonitrile
acetonitrile
acetonitrile
acetonitrile
acetonitrile
acetonitrile (1.5 mL)
acetonitrile (1 mL)
acetonitrile (5 mL)
10
11
12
13
14
15
16
17
18
19
20
e
21
a
b
Reaction conditions: DPM (1 mmol), catalyst (0.5 mol %), solvent (0.5 mL), TBHP (3 mmol), T = 75 °C, t = 24 h. TBHP = tert-butyl
c
hydroperoxide. GC conversion for target product BP was based on naphthalene as internal standard. All of the products were identified by GC−
MS spectra and GC spectra. Selectivity for BP. The scale-up experiment, reaction conditions: DPM (10 mmol), catalyst (0.25 mol %),
d
e
acetonitrile (5 mL), TBHP (30 mmol), T = 75 °C, t = 24 h.
(Mr = 4256.08): C, 4.52; H, 0.40; N, 7.90; P, 0.73; W, 51.84; Cu,
17.92; Cl, 1.67. Found: C, 4.53; H, 0.27; N, 7.97; P, 0.70; W, 51.86;
Cu, 17.90; Cl, 1.62. IR (KBr, cm−1): 3388 (w), 3120 (w), 1740 (w),
1601 (w), 1514 (s), 1286 (s), 1167 (w), 1084 (s), 968 (s), 893 (s),
801 (s).
General Procedure for the Oxidation of Alkylbenzenes. The
substrates (1 mmol), TBHP (5.5 mol L−1 in decane, 3 mmol), catalyst
(0.5 mol %), and acetonitrile (0.5 mL) were added into a glass
reaction tube; after that, the above-mentioned suspension liquid was
stirred and heated at the designed conditions in a WP-TEC-1020
parallel reactor from WATTCAS (Figure S5). Details of the reaction
conditions are described in each result. The products were
qualitatively detected by GC−MS. The conversion and selectivity
were monitored by GC based on naphthalene as the internal standard.
After the end of the reaction, the catalysts were washed by using
acetonitrile (3 × 5 mL) and then dried in an oven at 75 °C.
this way, each trz ligand bridges two adjacent Cu atoms to
form a {Cu4Cl(trz)4} macrocycle with a 5.025 × 5.025 Å
window (Figure 1a), in which the Cl atom is sited at the center
of this macrocycle. Moreover, N atoms outside trz ligands
bridged four proximal {Cu4Cl(trz)4} through Cu atoms, and
further extended to propagate a gridlike two-dimensional plane
structure with a size of 15.661 × 15.661 Å (Figure 1b). With
the help of Cu−O bonds, PW12 anions (Figure 1d) intercalate
into the cavity and connect two parallel adjacent planes
(Figure 1c), which form a three-dimensional network (Figure
1e). Crystallographic data and structural refinements of
HENU-7 are listed in Table S1. A similar structure has been
reported in 2016; Zhang et al. synthesized three pillar-layer CuI
coordination polymers, which used three different classic
POMs as the raw materials. The only difference is that HENU-
7 has one additional Cl atom and corresponding proton.84
Selective Oxidation of Alkylbenzenes. According to the
early studies,34,61−66 copper-containing POMOFs have ex-
hibited good catalytic performance for many oxidation
reactions, especially for selective oxidation of DPM, in which
copper atoms could act as catalytically active centers to drive
the oxidation process. Hence, HENU-7 was employed to
catalyze the selective oxidation of DPM to BP to evaluate its
catalytic ability. In order to optimize the reaction conditions to
obtain satisfactory conversion and selectivity, the impacts of
solvents, catalyst loading, dosage of oxidants, and reaction
temperature were investigated using HENU-7 as the catalyst.
The results are summarized in Table 1. First, through the
screening of solvent, it could be clearly observed the
conversion of DPM which was performed in acetonitrile is
RESULTS AND DISCUSSION
■
Structural Description. At a high temperature of 160 °C,
the self-assembly of PW12, copper acetate, and trz under
hydrothermal conditions generated the POMOF HENU-7.
The BVS results confirm the oxidation states of all P, W, and
Cu atoms (Table S2). Single-crystal X-ray diffraction analysis
reveals that HENU-7 crystallized in the monoclinic space
group C2/m. The asymmetric unit of HENU-7 is composed of
a quarter of [PW12]3−, four Cu+ ions (Cu1 and Cu3 site half-
occupied), two fourth Cl− ions, and two trz ligands. Copper
atoms have three types of coordination modes, which are
coordinated with nitrogen atoms, chlorine atom, and oxygen
atoms to structure a five-coordinated distorted triangular
bipyramidal/four-coordinated distorted tetrahedral/three-co-
ordinated “T”-type coordination configuration (Table S3). In
4794
https://dx.doi.org/10.1021/acs.inorgchem.0c03741
Inorg. Chem. 2021, 60, 4792−4799

Inorganic Chemistry
pubs.acs.org/IC
Article
much higher than that of other solvents, while all the
selectivities range from 92% to 99% (Table 1, entries 1−7).
Different catalyst loadings (0.2−0.6 mol %) were conducted to
study the influence of dosage in the oxidation process. From
0.2 to 0.5 mol % of catalyst dosage, the conversions showed an
upward trend, while selectivity approximatively remained
unchanged (Table 1, entries 1 and 9−11). However, the
conversion remained unchanged when 0.6 mol % HENU-7
was used, which is probably due to the agglomeration of
catalysts (Table 1, entry 12).88,89 As a consequence, 0.5 mol %
was chosen as the final catalyst dosage. As is known to all,
oxidants play a crucial role in the oxidation process, and their
dosage has a significant effect on the conversion and selectivity.
Therefore, a range of equivalents of TBHP have been
evaluated, and 3 mmol of TBHP presented good performance
(Table 1, entries 1 and 13−16). Under the condition of the
above parameters, the temperature effect was investigated, and
the selective oxidation of DPM over HENU-7 at 75 °C
afforded a 96% conversion and a 99% selectivity. With the
further rise in temperature to 85 °C, a slight increase of
conversion could be observed. Hence, the optimal temperature
was locked at 75 °C for the further investigations (Table 1,
entries 1, 18, and 19). In addition, the dependence of catalytic
performances on the volume of solvent has been also studied
(Table 1, entries 1, 19, and 20), and the results demonstrated
that, by improving the solvent volume, the conversions
decreased gradually, which is presumably due to the
concentration decline of the substrate (oxidant).90,91 Notably,
the scale-up experience was also conducted; DPM (10 mmol)
could be transformed into BP with 89% conversion and 96%
selectivity at 75 °C for 24 h in the presence of 0.1 g of HENU-
7, which further implied the excellent catalytic performance
and the potential application of HENU-7 (Table 1, entry 21).
Given the above results, the optimal conditions (Table 1, entry
1) have been determined for the subsequent catalytic
evaluation.
Cu(OAc)2 behaved more active than PW12 and trz, which
implied the vital roles of the copper atoms within HENU-7 as
the efficient catalytic sites in this transformation (Table 2,
entries 2−4). Moreover, the significant difference between
HENU-7 and its raw materials for their catalytic trans-
formation of DPM to BP distinctly indicated the great
contribution of hierarchical structures of HENU-7 (Table 2,
entries 5 and 8).33,57 As far as we know, HENU-7 presents
similar or better performance than known noble-metal-free
POM-based catalysts in the literature (Table S4). In addition,
one of the earlier reported catalysts has been synthesized and
employed to catalyze this transformation (Table 2, entries 6
and 7; Table S4, entry 5).32 And under the optimal conditions,
the DPM conversion obtained over P2W15Co3 is 51%, while
the selectivity to BP is 98%. However, when the 0.3 mmol of
pyridine was added as the additive, the conversion increased a
lot (51% to 83%), which was still lower than that of HENU-7.
The excellent catalytic performance of HENU-7 has been
demonstrated by the comparison result (Table 2, entries 6−8).
Scope of Substrates. Encouraged by the above good
results of DPM oxidation by using TBHP as the oxidant, the
scope of substrates were also further surveyed, which
demonstrated the excellent catalytic ability of HENU-7. The
results are summarized in Table 3. In general, the variation of
Table 3. Oxidation Reaction of Different Substrates
To highlight the excellent catalytic performance of HENU-7,
some reactions were carried out at the optimal conditions. GC
analysis after the blank experience indicated that the desired
BP could be obtained in the absence of any catalysts with a low
conversion (31%), while the corresponding selectivity is 99%
(Table 2, entry 1). Furthermore, the raw materials of HENU-7
were also used as the catalysts, and results showed that
Table 2. Catalytic Activity of Different Samples for
Oxidation Reaction of DPM
a
Reaction conditions: substrates (1 mmol), TBHP (3 mmol), catalyst
b
(0.5 mol %), acetonitrile (0.5 mL), T = 75 °C, t = 24 h. GC
conversion for target product BP was based on naphthalene as
internal standard. All of the products were identified by GC−MS
spectra and GC spectra. Selectivity for ketone.
b
c
entry
cat.
reaction system
conv. /% sel. /%
a
1
31
35
81
34
63
51
83
96
99
93
98
99
90
98
99
99
c
2
3
4
5
PW12
Cu(OAc)2
trz
PW12/Cu(OAc)2/trz
P2W15Co3
P2W15Co3/pyridine
HENU-7
homogeneous
homogeneous
homogeneous
homogeneous
heterogeneous
homogeneous
heterogeneous
catalytic efficiency for the substrates is mainly attributed to the
diverse C−H bond reaction activities.33,92 Both electron-
acceptor −NO2 and electron-donor −OCH3 substituted
substrates showed satisfactory conversions (84% and 93%)
and selectivities (98% and 97%) (Table 3, entries 2 and 3),
however, which were lower than that of ethylbenzene under
the equal reaction conditions (Table 3, entry 1). Moreover, a
good result was obtained for 4-ethyltoluene with a 90%
conversion and full selectivity (Table 3, entry 4). In addition,
alkylbenzenes with a large volume or steric hindrance, such as
fluorine, tetralin, and 2-benzylpyridine, can also be transformed
into the corresponding ketone products by HENU-7, with the
d
6
7
d
8
a
Reaction conditions: DPM (1 mmol), TBHP (3 mmol), catalyst (0.5
b
mol %), acetonitrile (0.5 mL), T = 75 °C, t = 24 h. GC conversion
for target product BP was based on naphthalene as internal standard.
All of the products were identified by GC−MS spectra and GC
spectra. Selectivity for BP. P2W15Co3 = [Na(H2O)5](NH4)7-
[P2W15O56Co3(H2O)3(OH)3Re(CO)3]·13H2O. Pyridine as the
additive (0.3 mmol).32
c
d
4795
https://dx.doi.org/10.1021/acs.inorgchem.0c03741
Inorg. Chem. 2021, 60, 4792−4799

Inorganic Chemistry
pubs.acs.org/IC
Article
conversion ranging from 82% to 99% (Table 3, entries 5−7).
Notably, tetralin could be transformed into the corresponding
product (1-tetralone) with a 89% conversion and a 83%
selectivity. And the slight decrease of selectivity is probably due
to the formation of the byproduct (2,3-dihydro-1,4-naphtho-
quinone). Such good results demonstrated that HENU-7 was
applicable to selective oxidation of alkylbenzenes.
Catalytic Stability. Another important indicator to
evaluate the performance of a heterogeneous catalyst is its
reusability and reproducibility. For this purpose, a series of
consecutive reactions were performed over HENU-7 in the
transformation of DPM to BP. HENU-7 can be easily collected
by centrifugation after each catalytic run, washed with
acetonitrile, and dried in an oven. The recovered HENU-7
was applied in the subsequent runs, as shown in Figure 2b. In
ASSOCIATED CONTENT
■
sı
* Supporting Information
The Supporting Information is available free of charge at
https://pubs.acs.org/doi/10.1021/acs.inorgchem.0c03741.
Structures, BVS, PXRD, IR, TG, catalytic experiments
mass spectrum for the corresponding product, catalytic
device, and kinetic study (PDF)
Accession Codes
CCDC 2026862 contains the supplementary crystallographic
data for this paper. These data can be obtained free of charge
via www.ccdc.cam.ac.uk/data_request/cif, or by emailing
data_request@ccdc.cam.ac.uk, or by contacting The Cam-
bridge Crystallographic Data Centre, 12 Union Road,
Cambridge CB2 1EZ, UK; fax: +44 1223 336033.
AUTHOR INFORMATION
■
Corresponding Authors
Jingping Wang − Henan Key Laboratory of Polyoxometalate
Chemistry, College of Chemistry and Chemical Engineering,
Henan University, Kaifeng, Henan 475004, China;
orcid.org/0000-0001-8079-5939; Email: jpwang@
henu.edu.cn
Jingyang Niu − Henan Key Laboratory of Polyoxometalate
Chemistry, College of Chemistry and Chemical Engineering,
Henan University, Kaifeng, Henan 475004, China;
orcid.org/0000-0001-6526-7767; Email: jyniu@
henu.edu.cn
Figure 2. (a) The line graphs of heterogeneous test of HENU-7. (b)
The histogram of conversion and selectivity for reused HENU-7 in
the oxidation of DPM.
its fifth catalytic run, the conversion is 94%, only 2% less than
its initial conversion value, which might be due to mass loss of
the catalysts during its rinsing procedure, indicative of good
stability of the catalyst HENU-7. The good stability of HENU-
7 is probably due to the robust framework of the classic POM
PW12, which supports the construction of POMOFs.27
Moreover, the recovered catalysts kept the integrity of the
framework after the oxidation process, which is proved by
PXRD (Figure S2). In addition, the hot filtration experiment
confirmed its heterogeneous system (Figure 2a). After the
removal of the catalyst, the increase of conversion was unsharp,
which proved the heterogeneous nature of this catalytic system.
Authors
Baijie Xu − Henan Key Laboratory of Polyoxometalate
Chemistry, College of Chemistry and Chemical Engineering,
Henan University, Kaifeng, Henan 475004, China;
orcid.org/0000-0002-0481-8614
Qian Xu − Henan Key Laboratory of Polyoxometalate
Chemistry, College of Chemistry and Chemical Engineering,
Henan University, Kaifeng, Henan 475004, China
Quanzhong Wang − Henan Key Laboratory of
Polyoxometalate Chemistry, College of Chemistry and
Chemical Engineering, Henan University, Kaifeng, Henan
475004, China; orcid.org/0000-0002-2571-0995
Zhen Liu − Henan Key Laboratory of Polyoxometalate
Chemistry, College of Chemistry and Chemical Engineering,
Henan University, Kaifeng, Henan 475004, China
Ruikun Zhao − Henan Key Laboratory of Polyoxometalate
Chemistry, College of Chemistry and Chemical Engineering,
Henan University, Kaifeng, Henan 475004, China
Dandan Li − Henan Key Laboratory of Polyoxometalate
Chemistry, College of Chemistry and Chemical Engineering,
Henan University, Kaifeng, Henan 475004, China
Pengtao Ma − Henan Key Laboratory of Polyoxometalate
Chemistry, College of Chemistry and Chemical Engineering,
Henan University, Kaifeng, Henan 475004, China;
orcid.org/0000-0002-0587-8635
CONCLUSION
■
In summary, through a one-pot self-assembly method, a
{Cu4Cl(trz)4}-based POMOF has been successfully prepared,
which encapsulated classic Keggin-type POM PW12 anions as
guest species. With TBHP as the oxidant, HENU-7 showed
excellent catalytic activity toward the selective oxidation of
DPM, where a 96% conversion and 99% selectivity could be
obtained. Moreover, HENU-7 is stable to duplicate the
oxidation reaction five times without an obvious loss in
activity, and HENU-7 also could catalyze the scale-up
experiment with a satisfactory conversion and selectivity. To
our best knowledge, HENU-7 outperforms most reported
noble-metal-free POM-based catalysts. In future work, much
efforts will be devoted to tailor novel POMOFs with excellent
stability and remarkable catalytic performance for oxidation
reactions.
Complete contact information is available at:
https://pubs.acs.org/10.1021/acs.inorgchem.0c03741
Notes
The authors declare no competing financial interest.
4796
https://dx.doi.org/10.1021/acs.inorgchem.0c03741
Inorg. Chem. 2021, 60, 4792−4799

Inorganic Chemistry
pubs.acs.org/IC
Article
in Competency of Manganese Nanocatalysts. Appl. Catal., A 2011,
399 (1−2), 75−86.
ACKNOWLEDGMENTS
■
We gratefully acknowledge financial support from the Natural
Science Foundation of China (Grants 21571050, 21573056,
21771053, and 21771054).
(19) Velu, S.; Shah, N.; Jyothi, T. M.; Sivasanker, S. Effect of
Manganese Substitution on the Physicochemical Properties and
Catalytic Toluene Oxidation Activities of Mg−Al Layered Double
Hydroxides. Microporous Mesoporous Mater. 1999, 33 (1−3), 61−75.
(20) Hu, X.; Liu, Y.; Huang, H.; Huang, B.; Chai, G.; Xie, Z.
Template-Free Synthesis of Graphene-like Carbons as Efficient
Carbocatalysts for Selective Oxidation of Alkanes. Green Chem.
2020, 22 (4), 1291−1300.
REFERENCES
■
(1) Balcells, D.; Clot, E.; Eisenstein, O. C−H Bond Activation in
Transition Metal Species from a Computational Perspective. Chem.
Rev. 2010, 110 (2), 749−823.
(2) Song, G.; Wang, F.; Li, X. C−C, C−O and C−N Bond
Formation via Rhodium(III)-Catalyzed Oxidative C−H Activation.
Chem. Soc. Rev. 2012, 41 (9), 3651−3678.
(3) Jiang, J.; Wang, J.-X.; Zhou, X.-T.; Chen, H.-Y.; Ji, H.-B.
Mechanistic Understanding towards the Role of Cyclohexene in
Enhancing the Efficiency of Manganese Porphyrin-Catalyzed Aerobic
Oxidation of Diphenylmethane: Mechanistic Understanding towards
the Role of Cyclohexene in Enhancing the Efficiency of Manganese
Porphyrin-Catalyzed Aerobic Oxidation of Diphenylme. Eur. J. Inorg.
Chem. 2018, 2018 (23), 2666−2674.
(4) Santhanaraj, D.; Suresh, C.; Selvamani, A.; Shanthi, K. A Detail
Kinetic Study on Vapour Phase Oxidation of Diphenylmethane over
Mesoporous V-KIT-6 Catalyst. Mol. Catal. 2017, 442, 1−11.
(5) Chen, K.; Zhang, P.; Wang, Y.; Li, H. Metal-Free Allylic/
Benzylic Oxidation Strategies with Molecular Oxygen: Recent
Advances and Future Prospects. Green Chem. 2014, 16 (5), 2344−
2374.
(21) Mohammadpour, P.; Safaei, E. Catalytic C−H Aerobic and
Oxidant-Induced Oxidation of Alkylbenzenes (Including Toluene
Derivatives) over VO2+ Immobilized on Core−Shell Fe3O4@SiO2 at
Room Temperature in Water. RSC Adv. 2020, 10 (40), 23543−
23553.
(22) Lu, J.; Ma, X.; Wang, P.; Feng, J.; Ma, P.; Niu, J.; Wang, J.
Synthesis, Characterization and Catalytic Epoxidation Properties of a
New Tellurotungstate(IV)-Supported Rhenium Carbonyl Derivative.
Dalton Trans. 2019, 48 (2), 628−634.
(23) Ma, X.; He, P.; Xu, B.; Lu, J.; Wan, R.; Wu, H.; Wang, Y.; Ma,
P.; Niu, J.; Wang, J. Pyrazine Dicarboxylate-Bridged Arsenotungstate:
Synthesis, Characterization, and Catalytic Activities in Epoxidation of
Olefins and Oxidation of Alcohols. Dalton Trans. 2019, 48 (34),
12956−12963.
(24) Xu, Q.; Niu, Y.; Wang, G.; Li, Y.; Zhao, Y.; Singh, V.; Niu, J.;
Wang, J. Polyoxoniobates as a Superior Lewis Base Efficiently
Catalyzed Knoevenagel Condensation. Mol. Catal. 2018, 453, 93−99.
(25) Wu, H.; Wan, R.; Si, Y.; Ma, P.; Wang, J.; Niu, J. A Helical
Chain-like Organic−Inorganic Hybrid Arsenotungstate with Color-
Tunable Photoluminescence. Dalton Trans. 2018, 47 (6), 1958−1965.
(26) Xu, Q.; Xu, B.; Kong, H.; He, P.; Wang, J.; Kannan, T.; Ma, P.;
Wang, J.; Niu, J. Synthesis and Characterization of a Crown-Shaped
36-Molybdate Cluster and Application in Catalyzing Knoevenagel
Condensation. Inorg. Chem. 2020, 59 (15), 10665−10672.
(27) Zou, C.; Zhang, Z.; Xu, X.; Gong, Q.; Li, J.; Wu, C.-D. A
Multifunctional Organic−Inorganic Hybrid Structure Based on Mn III
− Porphyrin and Polyoxometalate as a Highly Effective Dye
Scavenger and Heterogenous Catalyst. J. Am. Chem. Soc. 2012, 134
(1), 87−90.
(28) Li, J.-K.; Huang, X.-Q.; Yang, S.; Ma, H.-W.; Chi, Y.-N.; Hu, C.-
W. Four Alkoxohexavanadate-Based Pd-Polyoxovanadates as Robust
Heterogeneous Catalysts for Oxidation of Benzyl-Alkanes. Inorg.
Chem. 2015, 54 (4), 1454−1461.
(29) Hu, J.; Dong, J.; Huang, X.; Chi, Y.; Lin, Z.; Li, J.; Yang, S.; Ma,
H.; Hu, C. Immobilization of Keggin Polyoxovanadoniobate in
Crystalline Solids to Produce Effective Heterogeneous Catalysts
towards Selective Oxidation of Benzyl-Alkanes. Dalton Trans. 2017,
46 (25), 8245−8251.
(6) Yamaguchi, J.; Yamaguchi, A. D.; Itami, K. C−H Bond
Functionalization: Emerging Synthetic Tools for Natural Products
and Pharmaceuticals. Angew. Chem., Int. Ed. 2012, 51 (36), 8960−
9009.
(7) Bezouhanova, C. P. Synthesis of Aromatic Ketones in the
Presence of Zeolite Catalysts. Appl. Catal., A 2002, 229 (1−2), 127−
133.
(8) Olah, G. A. In Friedel-Crafts and Related Reactions, Vols. I−IV;
Wiley-Interscience: New York, 1963−1964.
(9) Lam, W. W. Y.; Yiu, S.-M.; Lee, J. M. N.; Yau, S. K. Y.; Kwong,
H.-K.; Lau, T.-C.; Liu, D.; Lin, Z. BF3 -Activated Oxidation of Alkanes
−
by MnO4 . J. Am. Chem. Soc. 2006, 128 (9), 2851−2858.
(10) Muzart, J. Chromium-Catalyzed Oxidations in Organic
Synthesis. Chem. Rev. 1992, 92 (1), 113−140.
(11) Cullis, C. F.; Ladbury, J. W. Kinetic studies of the oxidation of
aromatic compounds by potassium permanganate. Part III. Ethyl-
benzene. J. Chem. Soc. 1955, 2850−2854.
(12) Srour, H.; Le Maux, P.; Chevance, S.; Simonneaux, G. Metal-
Catalyzed Asymmetric Sulfoxidation, Epoxidation and Hydroxylation
by Hydrogen Peroxide. Coord. Chem. Rev. 2013, 257 (21−22), 3030−
3050.
(30) Farzaneh, F.; Moghzi, F. Investigation of the Catalytic Behavior
of a Cu Coordination Polymer Capped Polyoxometalate as an
Oxidation Catalyst. React. Kinet., Mech. Catal. 2015, 115 (1), 175−
185.
(31) Huang, X.; Li, J.; Shen, G.; Xin, N.; Lin, Z.; Chi, Y.; Dou, J.; Li,
D.; Hu, C. Three Pd-Decavanadates with a Controllable Molar Ratio
of Pd to Decavanadate and Their Heterogeneous Aerobic Oxidation
of Benzylic C−H Bonds. Dalton Trans. 2018, 47 (3), 726−733.
(32) Ma, X.; Wang, P.; Liu, Z.; Xin, C.; Wang, S.; Jia, J.; Ma, P.; Niu,
J.; Wang, J. Oxyfunctionalization of Alkanes Based on a Tricobalt(II)-
Substituted Dawson-Type Rhenium Carbonyl Derivative as Catalyst.
Inorg. Chem. 2020, 59 (13), 8690−8698.
(13) Lu, C.; Fu, Z.; Liu, Y.; Liu, F.; Wu, Y.; Qin, J.; He, X.; Yin, D. A
Moderate and Efficient Method for Oxidation of Ethylbenzene with
Hydrogen Peroxide Catalyzed by 8-Quinolinolato Manganese(III)
Complexes. J. Mol. Catal. A: Chem. 2010, 331 (1−2), 106−111.
(14) Khenkin, A. M.; Neumann, R. Redirection of Oxidation
Reactions by a Polyoxomolybdate: Oxydehydrogenation Instead of
Oxygenation of Alkanes with Tert -Butylhydroperoxide in Acetic Acid.
J. Am. Chem. Soc. 2001, 123 (26), 6437−6438.
(15) Vetrivel, S.; Pandurangan, A. Side-Chain Oxidation of
Ethylbenzene with Tert-Butylhydroperoxide over Mesoporous Mn-
MCM-41 Molecular Sieves. J. Mol. Catal. A: Chem. 2004, 217 (1−2),
165−174.
(33) Li, D.; Ma, X.; Wang, Q.; Ma, P.; Niu, J.; Wang, J. Copper-
Containing Polyoxometalate-Based Metal−Organic Frameworks as
Highly Efficient Heterogeneous Catalysts toward Selective Oxidation
of Alkylbenzenes. Inorg. Chem. 2019, 58 (23), 15832−15840.
(34) Feng, Y.; Ding, C.; Fan, H.; Zhong, Z.; Qiu, D.; Shi, H.
Employing a New 12-Connected Topological Open-Framework
Copper Borovanadate as an Effective Heterogeneous Catalyst for
Oxidation of Benzyl-Alkanes. Dalton Trans. 2015, 44 (43), 18731−
18736.
(16) Visuvamithiran, P.; Shanthi, K.; Palanichamy, M.; Murugesan,
V. Direct Synthesis of Mn-Ti-SBA-15 Catalyst for the Oxidation of
Ethylbenzene. Catal. Sci. Technol. 2013, 3 (9), 2340−2348.
(17) Arshadi, M.; Ghiaci, M.; Rahmanian, A.; Ghaziaskar, H.; Gil, A.
Oxidation of Ethylbenzene to Acetophenone by a Mn Catalyst
Supported on a Modified Nanosized SiO2/Al2O3Mixed-Oxide in
Supercritical Carbon Dioxide. Appl. Catal., B 2012, 119−120, 81−90.
(18) Arshadi, M.; Ghiaci, M. Highly Efficient Solvent Free Oxidation
of Ethylbenzene Using Some Recyclable Catalysts: The Role of Linker
4797
https://dx.doi.org/10.1021/acs.inorgchem.0c03741
Inorg. Chem. 2021, 60, 4792−4799

Inorganic Chemistry
pubs.acs.org/IC
Article
(35) Rezvani, M. A.; Shokri Aghbolagh, Z.; Hosseini Monfared, H.;
Khandan, S. Mono Mn(II)-Substituted Phosphotungstate@modified
Graphene Oxide as a High-Performance Nanocatalyst for Oxidative
Demercaptanization of Gasoline. J. Ind. Eng. Chem. 2017, 52, 42−50.
(36) Blanc, A.; de Frémont, P. When Gold Cations Meet
Polyoxometalates. Chem. - Eur. J. 2019, 25 (41), 9553−9567.
(37) Rezvani, M. A.; Shokri Aghbolagh, Z.; Hosseini Monfared, H.;
Khandan, S. Mono Mn(II)-Substituted Phosphotungstate@modified
Graphene Oxide as a High-Performance Nanocatalyst for Oxidative
Demercaptanization of Gasoline. J. Ind. Eng. Chem. 2017, 52, 42−50.
(38) Dolbecq, A.; Dumas, E.; Mayer, C. R.; Mialane, P. Hybrid
Organic-Inorganic Polyoxometalate Compounds: From Structural
Diversity to Applications. Chem. Rev. 2010, 110 (10), 6009−6048.
(39) Gao, Y.; Lv, Z.; Gao, R.; Zhang, G.; Zheng, Y.; Zhao, J.
Oxidative Desulfurization Process of Model Fuel under Molecular
Oxygen by Polyoxometalate Loaded in Hybrid Material CNTs@
MOF-199 as Catalyst. J. Hazard. Mater. 2018, 359, 258−265.
(40) Zhang, Z.; Su, X.; Yu, F.; Li, J. Three Novel Metal-Organic
Frameworks Based on Flexible Porphyrin Tetracarboxylic Acids as
Highly Effective Catalysts. J. Solid State Chem. 2016, 238, 53−59.
(41) Buru, C. T.; Li, P.; Mehdi, B. L.; Dohnalkova, A.; Platero-Prats,
A. E.; Browning, N. D.; Chapman, K. W.; Hupp, J. T.; Farha, O. K.
Adsorption of a Catalytically Accessible Polyoxometalate in a
Mesoporous Channel-Type Metal−Organic Framework. Chem.
Mater. 2017, 29 (12), 5174−5181.
(42) Li, H.; Yao, S.; Wu, H.-L.; Qu, J.-Y.; Zhang, Z.-M.; Lu, T.-B.;
Lin, W.; Wang, E.-B. Charge-Regulated Sequential Adsorption of
Anionic Catalysts and Cationic Photosensitizers into Metal-Organic
Frameworks Enhances Photocatalytic Proton Reduction. Appl. Catal.,
B 2018, 224, 46−52.
(43) Niu, S.; Wang, Z.; Zhou, T.; Yu, M.; Yu, M.; Qiu, J. A
Polymetallic Metal-Organic Framework-Derived Strategy toward
Synergistically Multidoped Metal Oxide Electrodes with Ultralong
Cycle Life and High Volumetric Capacity. Adv. Funct. Mater. 2017, 27
(5), 1605332.
(44) Tang, Y.-J.; Gao, M.-R.; Liu, C.-H.; Li, S.-L.; Jiang, H.-L.; Lan,
Y.-Q.; Han, M.; Yu, S.-H. Porous Molybdenum-Based Hybrid
Catalysts for Highly Efficient Hydrogen Evolution. Angew. Chem.,
Int. Ed. 2015, 54 (44), 12928−12932.
(52) Wang, X.; Tian, A.; Wang, X. Architectural Chemistry of
Polyoxometalate-Based Coordination Frameworks Constructed from
Flexible N-Donor Ligands. RSC Adv. 2015, 5 (51), 41155−41168.
(53) Yu, R.; Kuang, X.-F.; Wu, X.-Y.; Lu, C.-Z.; Donahue, J. P.
Stabilization and Immobilization of Polyoxometalates in Porous
Coordination Polymers through Host−Guest Interactions. Coord.
Chem. Rev. 2009, 253 (23−24), 2872−2890.
(54) Wu, C.-D.; Zhao, M. Incorporation of Molecular Catalysts in
Metal-Organic Frameworks for Highly Efficient Heterogeneous
Catalysis. Adv. Mater. 2017, 29 (14), 1605446.
(55) He, W.-W.; Li, S.-L.; Zang, H.-Y.; Yang, G.-S.; Zhang, S.-R.; Su,
Z.-M.; Lan, Y.-Q. Entangled Structures in Polyoxometalate-Based
Coordination Polymers. Coord. Chem. Rev. 2014, 279, 141−160.
̀
(56) Vila-Nadal, L.; Cronin, L. Design and Synthesis of
Polyoxometalate-Framework Materials from Cluster Precursors. Nat.
Rev. Mater. 2017, 2 (10), 17054.
(57) Guo, C.-C.; Liu, X.-Q.; Liu, Y.; Liu, Q.; Chu, M.-F.; Zhang, X.-
B. Studies of Simple μ-Oxo-Bisiron(III)Porphyrin as Catalyst of
Cyclohexane Oxidation with Air in Absence of Cocatalysts or
Coreductants. J. Mol. Catal. A: Chem. 2003, 192, 289−294.
(58) Guo, C.-C.; Chu, M.-F.; Liu, Q.; Liu, Y.; Guo, D.-C.; Liu, X.-Q.
Effective Catalysis of Simple Metalloporphyrins for Cyclohexane
Oxidation with Air in the Absence of Additives and Solvents. Appl.
Catal., A 2003, 246 (2), 303−309.
(59) Santhanaraj, D.; Suresh, C.; Selvamani, A.; Shanthi, K. A
Comparison Study between V-SBA-15 and V-KIT-6 Catalysts for
Selective Oxidation of Diphenylmethane. New J. Chem. 2019, 43 (29),
11554−11563.
(60) Wang, A.; Zhou, W.; Sun, Z.; Zhang, Z.; Zhang, Z.; He, M.;
Chen, Q. Mn(III) Active Site in Hydrotalcite Efficiently Catalyzes the
Oxidation of Alkylarenes with Molecular Oxygen. Molecular Catalysis
2021, 499, 111276.
(61) Kar, A. K.; Srivastava, R. Selective Synthesis of Cu−Cu2O/C
and CuO−Cu2O/C Catalysts for Pd-Free C−C, C−N Coupling and
Oxidation Reactions. Inorg. Chem. Front. 2019, 6 (2), 576−589.
(62) Li, Y.; Lee, T. B.; Wang, T.; Gamble, A. V.; Gorden, A. E. V.
Allylic C−H Activations Using Cu(II) 2-Quinoxalinol Salen and Tert
-Butyl Hydroperoxide. J. Org. Chem. 2012, 77 (10), 4628−4633.
(63) Koval, I. A.; Gamez, P.; Belle, C.; Selmeczi, K.; Reedijk, J.
Synthetic Models of the Active Site of Catechol Oxidase: Mechanistic
Studies. Chem. Soc. Rev. 2006, 35 (9), 814.
(64) Li, H.; Wang, F.; Cai, W.; Zhang, J.; Zhang, X. Hydro-
chlorination of Acetylene Using Supported Phosphorus-Doped Cu-
Based Catalysts. Catal. Sci. Technol. 2015, 5 (12), 5174−5184.
(65) Allen, S. E.; Walvoord, R. R.; Padilla-Salinas, R.; Kozlowski, M.
C. Aerobic Copper-Catalyzed Organic Reactions. Chem. Rev. 2013,
113 (8), 6234−6458.
(66) Zhao, M.; Zhang, X.-W.; Wu, C.-D. Structural Transformation
of Porous Polyoxometalate Frameworks and Highly Efficient
Biomimetic Aerobic Oxidation of Aliphatic Alcohols. ACS Catal.
2017, 7 (10), 6573−6580.
(67) Li, X.-X.; Wang, Y.-X.; Wang, R.-H.; Cui, C.-Y.; Tian, C.-B.;
Yang, G.-Y. Designed Assembly of Heterometallic Cluster Organic
Frameworks Based on Anderson-Type Polyoxometalate Clusters.
Angew. Chem., Int. Ed. 2016, 55 (22), 6462−6466.
(68) Zheng, S.-T.; Zhang, J.; Li, X.-X.; Fang, W.-H.; Yang, G.-Y.
Cubic Polyoxometalate-Organic Molecular Cage. J. Am. Chem. Soc.
2010, 132 (43), 15102−15103.
(45) Xia, G.; Liu, D.; Zheng, F.; Yang, Y.; Su, J.; Chen, Q.
Preparation of Porous MoO2 @C Nano-Octahedrons from a
Polyoxometalate-Based Metal−Organic Framework for Highly
Reversible Lithium Storage. J. Mater. Chem. A 2016, 4 (32),
12434−12441.
(46) Li, D.; Ma, P.; Niu, J.; Wang, J. Recent Advances in Transition-
Metal-Containing Keggin-Type Polyoxometalate-Based Coordination
Polymers. Coord. Chem. Rev. 2019, 392, 49−80.
̀
(47) Miras, H. N.; Vila-Nadal, L.; Cronin, L. Polyoxometalate Based
Open-Frameworks (POM-OFs). Chem. Soc. Rev. 2014, 43 (16),
5679−5699.
(48) Rodriguez-Albelo, L. M.; Rousseau, G.; Mialane, P.; Marrot, J.;
Mellot-Draznieks, C.; Ruiz-Salvador, A. R.; Li, S.; Liu, R.; Zhang, G.;
Keita, B.; Dolbecq, A. ε-Keggin-Based Coordination Networks:
Synthesis, Structure and Application toward Green Synthesis of
Polyoxometalate@graphene Hybrids. Dalton Trans. 2012, 41 (33),
9989−9999.
(49) Zheng, S.-T.; Zhang, J.; Yang, G.-Y. Designed Synthesis of
POM−Organic Frameworks from {Ni 6 PW 9 } Building Blocks under
Hydrothermal Conditions. Angew. Chem., Int. Ed. 2008, 47 (21),
3909−3913.
(50) Li, X.; Zhou, K.; Tong, Z.; Yang, J.; Sheng, N.; Li, J.; Sha, J.
Keggin Polyoxometalates Based Hybrid Compounds Containing
Helix/Nanocages for Colorimetric Biosensing. J. Solid State Chem.
2018, 265, 372−380.
(51) Maksimchuk, N.; Timofeeva, M.; Melgunov, M.; Shmakov, A.;
Chesalov, Y.; Dybtsev, D.; Fedin, V.; Kholdeeva, O. Heterogeneous
Selective Oxidation Catalysts Based on Coordination Polymer MIL-
101 and Transition Metal-Substituted Polyoxometalates. J. Catal.
2008, 257 (2), 315−323.
(69) Wang, Y.-R.; Huang, Q.; He, C.-T.; Chen, Y.; Liu, J.; Shen, F.-
C.; Lan, Y.-Q. Oriented Electron Transmission in Polyoxometalate-
Metalloporphyrin Organic Framework for Highly Selective Electro-
reduction of CO2. Nat. Commun. 2018, 9 (1), 4466.
(70) Yang, X.; Zhu, P.; Ren, J.; Chen, Y.; Li, X.; Sha, J.; Jiang, J.
Surfactant-Assisted Synthesis and Electrochemical Properties of an
Unprecedented Polyoxometalate-Based Metal−Organic Nanocaged
Framework. Chem. Commun. 2019, 55 (9), 1201−1204.
(71) Yang, P.; Zhao, W.; Shkurenko, A.; Belmabkhout, Y.; Eddaoudi,
M.; Dong, X.; Alshareef, H. N.; Khashab, N. M. Polyoxometalate−
Cyclodextrin Metal−Organic Frameworks: From Tunable Structure
4798
https://dx.doi.org/10.1021/acs.inorgchem.0c03741
Inorg. Chem. 2021, 60, 4792−4799

Inorganic Chemistry
pubs.acs.org/IC
Article
to Customized Storage Functionality. J. Am. Chem. Soc. 2019, 141 (5),
1847−1851.
(72) Li, S.; Zhang, L.; Lan, Y.; O’Halloran, K. P.; Ma, H.; Pang, H.
Polyoxometalate-Encapsulated Twenty-Nuclear Silver-Tetrazole
Nanocage Frameworks as Highly Active Electrocatalysts for the
Hydrogen Evolution Reaction. Chem. Commun. 2018, 54 (16), 1964−
1967.
(73) Lin, X.; Zhang, M.; Zhu, M.; Huang, H.; Shi, C.; Liu, Y.; Kang,
Z. Engineering a Polyoxometalate-Based Metal Organic Framework
with More Exposed Active Edge Sites of Ag for Visible Light-Driven
Selective Oxidation of Cis-Cyclooctene. Inorg. Chem. Front. 2018, 5
(10), 2493−2500.
(74) Sun, W.; He, C.; Liu, T.; Duan, C. Synergistic Catalysis for
Light-Driven Proton Reduction Using a Polyoxometalate-Based Cu−
Ni Heterometallic−Organic Framework. Chem. Commun. 2019, 55
(26), 3805−3808.
(75) Shi, D.; Zheng, R.; Liu, C.-S.; Chen, D.-M.; Zhao, J.; Du, M.
Dual-Functionalized Mixed Keggin- and Lindqvist-Type Cu24-Based
POM@MOF for Visible-Light-Driven H2 and O2 Evolution. Inorg.
Chem. 2019, 58 (11), 7229−7235.
(76) Li, X.-X.; Liu, J.; Zhang, L.; Dong, L.-Z.; Xin, Z.-F.; Li, S.-L.;
Huang-Fu, X.-Q.; Huang, K.; Lan, Y.-Q. Hydrophobic Polyoxometa-
late-Based Metal-Organic Framework for Efficient CO2 Photo-
conversion. ACS Appl. Mater. Interfaces 2019, 11 (29), 25790−25795.
(77) Sun, W.; An, B.; Qi, B.; Liu, T.; Jin, M.; Duan, C. Dual-
Excitation Polyoxometalate-Based Frameworks for One-Pot Light-
Driven Hydrogen Evolution and Oxidative Dehydrogenation. ACS
Appl. Mater. Interfaces 2018, 10 (16), 13462−13469.
(87) Yang, X.-Y.; Wei, T.; Li, J.-S.; Sheng, N.; Zhu, P.-P.; Sha, J.-Q.;
Wang, T.; Lan, Y.-Q. Polyoxometalate-Incorporated Metallapillarar-
ene/Metallacalixarene Metal-Organic Frameworks as Anode Materials
for Lithium Ion Batteries. Inorg. Chem. 2017, 56 (14), 8311−8318.
(88) Lei, J.; Zheng, N.; Luo, F.; He, Y. Purification of automobile
exhaust gas by activated carbon supported Fe3+ modified nano-TiO2
and its application on asphalt pavement. Road Mater. Pavement Des.
2020. DOI: 10.1080/14680629.2020.1763831.
(89) Subramonian, W.; Wu, T. Y.; Chai, S.-P. Photocatalytic
Degradation of Industrial Pulp and Paper Mill Effluent Using
Synthesized Magnetic Fe2O3 -TiO2: Treatment Efficiency and
Characterizations of Reused Photocatalyst. J. Environ. Manage.
2017, 187, 298−310.
(90) de Azambuja, F.; Parac-Vogt, T. N. Water-Tolerant and Atom
Economical Amide Bond Formation by Metal-Substituted Polyox-
ometalate Catalysts. ACS Catal. 2019, 9 (11), 10245−10252.
(91) Taghizadeh, M.; Mehrvarz, E.; Taghipour, A. Polyoxometalate
as an Effective Catalyst for the Oxidative Desulfurization of Liquid
Fuels: A Critical Review. Rev. Chem. Eng. 2020, 36 (7), 831−858.
(92) Jiang, J.; Wang, J.-X.; Zhou, X.-T.; Chen, H.-Y.; Ji, H.-B.
Mechanistic Understanding towards the Role of Cyclohexene in
Enhancing the Efficiency of Manganese Porphyrin-Catalyzed Aerobic
Oxidation of Diphenylmethane: Mechanistic Understanding towards
the Role of Cyclohexene in Enhancing the Efficiency of Manganese
Porphyrin-Catalyzed Aerobic Oxidation of Diphenylme. Eur. J. Inorg.
Chem. 2018, 2018 (23), 2666−2674.
(78) Li, M.; Cong, L.; Zhao, J.; Zheng, T.; Tian, R.; Sha, J.; Su, Z.;
Wang, X. Self-Organization towards Complex Multi-Fold Meso-
Helices in the Structures of Wells−Dawson Polyoxometalate-Based
Hybrid Materials for Lithium-Ion Batteries. J. Mater. Chem. A 2017, 5
(7), 3371−3376.
(79) Sha, J.-Q.; Li, M.-T.; Yang, X.-Y.; Sheng, N.; Li, J.-S.; Zhu, M.-
L.; Liu, G.-D.; Jiang, J. New Route toward POM[6]Catenane
Members for Lithium-Ion Batteries. Cryst. Growth Des. 2017, 17
(7), 3775−3782.
(80) Sha, J.; Zhu, P.; Yang, X.; Li, X.; Li, X.; Yue, M.; Zhou, K.
Polyoxometalates Templated Metal Ag−Carbene Frameworks Anodic
Material for Lithium-Ion Batteries. Inorg. Chem. 2017, 56 (19),
11998−12002.
(81) Li, M.-T.; Yang, X.-Y.; Li, J.-S.; Sheng, N.; Liu, G.-D.; Sha, J.-
Q.; Lan, Y.-Q. Assembly of Multifold Helical Polyoxometalate-Based
Metal−Organic Frameworks as Anode Materials in Lithium-Ion
Batteries. Inorg. Chem. 2018, 57 (7), 3865−3872.
(82) Sha, J.-Q.; Yang, X.-Y.; Chen, Y.; Zhu, P.-P.; Song, Y.-F.; Jiang,
J. Fabrication and Electrochemical Performance of Polyoxometalate-
Based Three-Dimensional Metal Organic Frameworks Containing
Carbene Nanocages. ACS Appl. Mater. Interfaces 2018, 10 (19),
16660−16665.
(83) Zhao, X.; Zhang, S.; Yan, J.; Li, L.; Wu, G.; Shi, W.; Yang, G.;
Guan, N.; Cheng, P. Polyoxometalate-Based Metal-Organic Frame-
works as Visible-Light-Induced Photocatalysts. Inorg. Chem. 2018, 57
(9), 5030−5037.
(84) Lu, X.-X.; Luo, Y.-H.; Liu, Y.-S.; Ma, W.-W.; Xu, Y.; Zhang, H.
Assembly of Three Stable POM-Based Pillar-Layer CuI Coordination
Polymers with Visible Light Driven Photocatalytic Properties.
CrystEngComm 2016, 18 (20), 3650−3654.
(85) Mirzaei, M.; Eshtiagh-Hosseini, H.; Alipour, M.; Frontera, A.
Recent Developments in the Crystal Engineering of Diverse
Coordination Modes (0−12) for Keggin-Type Polyoxometalates in
Hybrid Inorganic−Organic Architectures. Coord. Chem. Rev. 2014,
275, 1−18.
(86) Huang, Q.; Wei, T.; Zhang, M.; Dong, L.-Z.; Zhang, A.-M.; Li,
S.-L.; Liu, W.-J.; Liu, J.; Lan, Y.-Q. A Highly Stable Polyoxometalate-
Based Metal-Organic Framework with π−π Stacking for Enhancing
Lithium Ion Battery Performance. J. Mater. Chem. A 2017, 5 (18),
8477−8483.
4799
https://dx.doi.org/10.1021/acs.inorgchem.0c03741
Inorg. Chem. 2021, 60, 4792−4799
