A Highly Active Heterogeneous Palladium Catalyst for the Suzuki–
Miyaura and Ullmann Coupling Reactions of Aryl Chlorides in
Aqueous Media**
Bizhen Yuan, Yingyi Pan, Yingwei Li,* Biaolin Yin, and Huanfeng Jiang*
À
Palladium-catalyzed carbon-carbon (C C) coupling reactions
of aryl halides, such as Suzuki–Miyaura and Ullmann
reactions, are very important as versatile routes to construct-
ing biaryl units in organic synthesis.[1] Although homogeneous
palladium catalysts has been extensively investigated, indus-
trial applications of these reactions remain challenging
because the catalysts are expensive, cannot be recycled, and
are difficult to separate from the product mixture,[1,2] which is
a particular drawback for applications in the pharmaceutical
industry; heterogeneous palladium catalysts are a promising
solution to these problems. A number of solid materials,[3]
such as carbon structures,[4] polymers,[5] and mesoporous
silica[6] have been employed as supports for palladium.
Numerous heterogeneous palladium catalysts have been
utilized in the coupling reactions of aryl bromides or
iodides;[1b] nevertheless, only a very limited number of such
palladium catalysts have been reported for coupling reactions
with aryl chlorides.[7] From a practical point of view, the use of
aryl chlorides is desirable because they are inexpensive and
readily available.[1] However, the activation of aryl chlorides
is much more difficult than aryl bromides or iodides.
Furthermore, the reported coupling reactions were mostly
carried out in organic solvents. From a sustainable chemistry
viewpoint, the use of water instead of volatile organic solvents
is particularly important. Therefore, the development of
heterogeneous catalysts that can activate aryl chlorides and
facilitate the coupling reactions of aryl chlorides in aqueous
media is highly desirable.[1]
reports on MOFs as catalysts and even fewer reports on
supporting noble metal nanoparticles (NPs) on MOFs as
catalysts for heterogeneous catalysis.[10] A palladium-contain-
ing MOF (Pd-MOF) has been reported to be an active
catalyst for the Suzuki–Miyaura coupling reaction of aryl
bromides.[11] To the best of our knowledge, there are currently
no reports of employing MOFs as supports for metal NPs in
Suzuki–Miyaura and Ullmann coupling reactions of aryl
chlorides.
Herein, we report the water-mediated coupling reactions
of aryl chlorides over a heterogeneous palladium catalyst,
which is deposited on a zeolite-type MOF. This work
represents the first example of an active catalyst, comprised
of a MOF as a support for metal NPs, for the coupling
reactions of aryl chlorides. We have chosen MIL-101 (Cr3-
(F,OH)(H2O)2O[(O2C)-C6H4-(CO2)]3·nH2O
(n ꢀ 25))
because it has a large surface area (BET, ca. 4000 m2 gÀ1),[12]
which is desirable for depositing small palladium NPs.
Furthermore, the hybrid pore surface, which constitutes
both hydrophilic and hydrophobic networks,[13] and the large
pore size (ca. 30 ꢀ) may facilitate the selective adsorption of
an aryl substrate in water and mass transfer inside the pores.
Moreover, MIL-101 is stable when exposed to indoor ambient
air and treated with various organic solvents.[12,14]
MIL-101 was synthesized and purified according to the
reported procedure.[12] Supported palladium NPs were pre-
pared by impregnation of activated MIL-101 with a Pd(NO3)2
precursor that was diluted in N,N-dimethylformamide (for
experimental details, see the Supporting Information). The
palladium loading (ca. 1 wt%) did not result in any apparent
loss of crystallinity in the X-ray diffraction patterns (see the
Supporting Information), indicating that the integrity of the
MIL-101 framework was maintained. The TEM image, shown
in Figure 1, shows that the palladium NPs were highly
Metal-organic frameworks (MOFs) have emerged as a
particular class of functional materials owing to their high
surface area, porosity, and chemical tunability.[8] Because of
these properties, MOFs have promising applications in
heterogeneous catalysis. However, over the past decade,
most of the research efforts have been focused on preparing
new MOFs and studying their applications in gas storage and
separation.[9] So far, there are a relatively limited number of
[*] B. Z. Yuan, Y. Y. Pan, Prof. Y. W. Li, Dr. B. L. Yin, Prof. H. F. Jiang
School of Chemistry and Chemical Engineering
South China University of Technology
Guangzhou 510640 (China)
Fax: (+86)20-2223-6337
E-mail: liyw@scut.edu.cn
jianghf@scut.edu.cn
[**] This work was supported by the NSF of China (20803024, 20936001,
and 20625205), and the program for New Century Excellent Talents
in Universities (NCET-08-0203).
Supporting information for this article is available on the WWW
under http://dx.doi.org/10.1002/anie.201000576.
Figure 1. TEM images of Pd/MIL-101 before the reaction (left) and
after five cycles (right).
