Corrosion inhibition of magnesium alloy in NaCl solution by ionic liquid: Synthesis, electrochemical and theoretical studies

Article abstract of DOI:10.1016/j.jallcom.2019.03.318

A new ionic liquid, benzyl triphenyl phosphonium bis(trifluoromethylsulfonyl)amide ([BPP][NTf₂]), for magnesium alloy is synthesized. The potential of [BPP][NTf₂] to be inhibitor is firstly estimated as compared with [P_6,6,6,14][NTf₂] by theoretical calculations. Then, the inhibition of AZ31B Mg alloy in 0.05 wt% NaCl solution is evaluated by [BPP][NTf₂] is investigated by Tafel linear polarization method, electrochemical impedance spectroscopy (EIS), and scanning electron microscopy (SEM). The most optimum inhibitor efficiency of [BPP][NTf₂] is 91.4% at room temperature. The adsorption of [BPP][NTf₂] on the surface of AZ31B Mg alloy obeys Langmuir isotherm with predominantly chemical adsorption. The corresponding result is further analyzed by the theory. The corrosive product is detected by Fourier transform infrared spectrum (FTIR). The possible inhibition mechanism is proposed, in which the effect of cation on inhibition is proposed in addition to the influence of anion.

Full text of DOI:10.1016/j.jallcom.2019.03.318

Accepted Manuscript
Corrosion inhibition of magnesium alloy in NaCl solution by ionic liquid: Synthesis,
electrochemical and theoretical studies
Huishuang Su, Yue Liu, Xing Gao, Yafeng Qian, Weijie Li, Tiegang Ren, Li Wang,
Jinglai Zhang
PII:
S0925-8388(19)31156-9
DOI:
https://doi.org/10.1016/j.jallcom.2019.03.318
JALCOM 50082
Reference:
To appear in: Journal of Alloys and Compounds
Received Date: 26 January 2019
Revised Date: 14 March 2019
Accepted Date: 22 March 2019
Please cite this article as: H. Su, Y. Liu, X. Gao, Y. Qian, W. Li, T. Ren, L. Wang, J. Zhang, Corrosion
inhibition of magnesium alloy in NaCl solution by ionic liquid: Synthesis, electrochemical and theoretical
studies, Journal of Alloys and Compounds (2019), doi: https://doi.org/10.1016/j.jallcom.2019.03.318.
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to
our customers we are providing this early version of the manuscript. The manuscript will undergo
copyediting, typesetting, and review of the resulting proof before it is published in its final form. Please
note that during the production process errors may be discovered which could affect the content, and all
legal disclaimers that apply to the journal pertain.

ACCEPTED MANUSCRIPT
Graphical Abstract
Corrosion inhibition of magnesium alloy in NaCl solution by ionic
liquid: Synthesis, electrochemical and theoretical studies
a
a
a
b
b
Huishuang Su , Yue Liu , Xing Gao , Yafeng Qian , Weijie Li ,
*a
*a
*a
Tiegang Ren , Li Wang , Jinglai Zhang
a
Henan Provincial Engineering Research Center of Green Anticorrosion
Technology for Magnesium Alloy
College of Chemistry and Chemical Engineering, Henan University,
Kaifeng, Henan 475004, P.R. China
b
National Center for Quality Supervision and Inspection of Magnesium
and Magnesium Alloy Products, Hebi, Henan 458030, P.R. China
*
Corresponding author E-mail: 1) Tiegang Ren, College of Chemistry and Chemical Engineering,
Henan University, Kaifeng, 475004, China. Tel: +86-371-22196667; Fax: +86-371-22196667.
E-mail: rtgang@126.com
2
) Li Wang, College of Chemistry and Chemical Engineering, Henan University, Kaifeng, 475004,
China. Tel: +86-371-22196667; Fax: +86-371-22196667. E-mail: chemwangl@henu.edu.cn
3
4
) Jinglai Zhang, College of Chemistry and Chemical Engineering, Henan University, Kaifeng,
75004, China. Tel: +86-371-22196667; Fax: +86-371-22196667. E-mail:
zhangjinglai@henu.edu.cn

ACCEPTED MANUSCRIPT
Corrosion inhibition of magnesium alloy in NaCl solution by ionic
liquid: Synthesis, electrochemical and theoretical studies
a
a
a
b
b
Huishuang Su , Yue Liu , Xing Gao , Yafeng Qian , Weijie Li ,
*a
*a
*a
Tiegang Ren , Li Wang , Jinglai Zhang
a
Henan Provincial Engineering Research Center of Green Anticorrosion
Technology for Magnesium Alloy
College of Chemistry and Chemical Engineering, Henan University,
Kaifeng, Henan 475004, P.R. China
b
National Center for Quality Supervision and Inspection of Magnesium
and Magnesium Alloy Products, Hebi, Henan 458030, P.R. China
ABSTRACT
new
A
ionic
liquid,
benzyl
triphenyl
phosphonium
bis(trifluoromethylsulfonyl)amide ([BPP][NTf ]), for magnesium alloy is
2
synthesized. The potential of [BPP][NTf ] to be inhibitor is firstly estimated as
2
compared with [P6,6,6,14][NTf ] by theoretical calculations. Then, the inhibition of
2
AZ31B Mg alloy in 0.05 wt% NaCl solution is evaluated by [BPP][NTf ] is
2
investigated by Tafel linear polarization method, electrochemical impedance
spectroscopy (EIS), and scanning electron microscopy (SEM). The most optimum
inhibitor efficiency of [BPP][NTf ] is 91.4% at room temperature. The adsorption of
2
[
BPP][NTf ] on the surface of AZ31B Mg alloy obeys Langmuir isotherm with
2
predominantly chemical adsorption. The corresponding result is further analyzed by
the theory. The corrosive product is detected by Fourier transform infrared spectrum
*
Corresponding author E-mail: 1) Tiegang Ren, College of Chemistry and Chemical Engineering,
Henan University, Kaifeng, 475004, China. Tel: +86-371-22196667; Fax: +86-371-22196667.
E-mail: rtgang@126.com
2
4
) Li Wang, College of Chemistry and Chemical Engineering, Henan University, Kaifeng,
75004, China. Tel: +86-371-22196667; Fax: +86-371-22196667. E-mail:
chemwangl@henu.edu.cn
3
4
) Jinglai Zhang, College of Chemistry and Chemical Engineering, Henan University, Kaifeng,
75004,
China.
Tel:
+86-371-22196667;
Fax:
+86-371-22196667.
E-mail:
zhangjinglai@henu.edu.cn
1

ACCEPTED MANUSCRIPT
(FTIR). The possible inhibition mechanism is proposed, in which the effect of cation
on inhibition is proposed in addition to the influence of anion.
Keywords: Ionic liquid inhibitor; AZ31B Mg alloy; Electrochemical techniques;
First principle; Corrosion
1
. Introduction
Corrosion is an inevitable problem in industry and other relevant regions, which
has resulted in not only the detriment of materials but also considerable economic
losses. Although various methods have been applied to retard corrosion, the addition
of corrosion inhibitor is no doubt one of the most popular, convenient, and
cost-effective methods, especially in aqueous environment [1-3]. Up to now, many
organic compounds including π-electron group and heterocyclic atoms, including N,
O, P, and S have been developed to protect the metal in aggressive medium [4-5].
However, their usage has been restricted due to the global demand for sustainable
development and environmental protection. Ionic liquids (ILs) are one of the most
powerful alternatives due to their distinct properties including negligible vapor
pressure, chemical and thermal stability, and excellent tunable structures. Ionic
liquids would be taken as the “green” corrosion inhibitor because of the negligible
vapor pressure, which is more environmentally friendly as compared with highly
volatile organic inhibitor. The excellent chemical and thermal stability would prevent
the ionic liquid from decomposing. Additionally, unlimited potential derivatives
would be developed by modification of cation and anion with desired properties,
which is impossible for organic compounds. 1-allyl-3-octylimidazolium bromide
([AOIM]Br) [6], 1-butyl-3-methyl-1H-benzimidazolium iodide (BMBIMI) [7], and
2

ACCEPTED MANUSCRIPT
1
-octyl-3-methylimidazolium chlorides (OMIC) [8] have been applied to protect the
copper, mild steel, and aluminum. Rare ionic liquids have been taken as the
corrosion inhibitor for magnesium alloy [9].
Magnesium alloy has attracted much attention due to the light weight and the
high strength to weight. Moreover, Mg element is abundance in the earth’s crust. Mg
and its alloys would play more and more important role in fields in which weight
minimization is a priority, e.g., aerospace, auto-motive, and infrastructure [10-11].
However, the large scale applications of Mg alloys are restricted due to their
sensitive to corrosion significantly. The film would be formed on the surface of Mg
alloys, however, it could not provide any protection for them upon atmospheric
exposure. The common protection method is to perform chromate coating. The
toxicity of chromate promotes to search for other alternative corrosion inhibitors. As
compared with Fe and Cu, limited corrosion inhibitors have been reported for Mg
and its alloys due to their active chemical properties. Howlett et al. have reported
that
trihexyl(tetradecyl)phosphonium
bis(trifluoromethylsulfonyl)amide
trihexyl(tetradecyl)phosphonium bis
([P6,6,6,14][NTf ]) and
2
2
,4,4-trimethylpentylphosphinate (P6,6,6,14M PPh) could offer corrosion resistance for
3
AZ31 Mg alloy [12-13]. The expense of raw materials to synthesize [P6,6,6,14][NTf2]
is too expensive to meet the requirement of large scale applications. Thus, it is urgent
to develop cheap and efficient corrosion inhibitors for Mg alloys to promote their
applications. One of the most unique advantages for ionic liquids is that their
properties would be easily adjusted by combination of different cations and anions. It
is not an easy task to find the suitable cations and anions to compose ionic liquids
with the desired properties from millions of ions. Elucidation of the mechanism and
confirmation of the critical factor to control corrosion inhibition are beneficial to
3

ACCEPTED MANUSCRIPT
exploring the new corrosion inhibitor.
In this work, benzyl triphenyl phosphonium bis(trifluoromethylsulfonyl)amide
(
[BPP][NTf ]) (See Fig. 1) is firstly designed. Then, its properties are calculated by
2
combination of density functional theory (DFT) along with molecular dynamics
(
MD) simulation. As compared with the documented corrosion inhibitor
P6,6,6,14][NTf ], [BPP][NTf ] has an acceptable performance to be a potential
[
2
2
candidate for Mg alloys. After that, it is synthesized and the inhibitory effect is
evaluated for the AZ31B Mg alloy in 0.05 wt% NaCl solution by electrochemical
measurements, Fourier transform infrared (FTIR) spectroscopy, and surface analysis.
Finally, the possible inhibited mechanism is proposed. The central aim of this work
is to find out an efficient and cheap corrosion inhibitor for the AZ31B Mg alloy.
2
2
2
. Theory and experiment details
.1. Computational details
.1.1. MD simulation for [BPP][NTf2]
The 256 ion pairs of [BPP][NTf ] were put in a cubic box of around 100 Å ×
2
1
00 Å × 100 Å. The periodic boundary condition was applied for three dimensions
of cubic box. The nonbonded interactions were regraded by 15 Å cut-off, while the
long-range electrostatic interactions were handled by the particle mesh Ewald (PME)
method as well as long-range dispersion corrections [14]. Initially, the simulation
was performed under the isothermal-isobaric ensemble (NPT) at 298 K and 0.1 MPa.
To keep ion mobility, the temperature was enhanced to 700 K for 1000 ps. After that,
the system was cooled down to 298 K for 2 ns. Then, 5 ns simulation was performed
again to get the production equilibrium using a timestep of 2 fs. The MD trajector is
saved every 5000 timesteps. General Amber Force Field (GAFF) was applied in the
simulation [15]. The bonds involving hydrogen atoms were constrained with
4

ACCEPTED MANUSCRIPT
SHAKE [16]. Aforementioned simulation was completed by GROMACS 5.1.2
package [17].
2
.1.2. Calculations for [BPP][NTf2]
The structures of [BPP][NTf ] and [P
][NTf ] were optimized at the
6,6,6,14 2
2
Becke's three parameter exact exchange-functional combined with Perdew and Wang
method (B3PW91) with the 6-31G(d,p) basis set [18-20]. The frequency was
calculated to determine the rightness of ionic liquid structure. Above electronic
calculations were accomplished by Gaussian 09 program [21].
2
.1.3. Simulation for [BPP][NTf ]@Mg
2
To deeply understand the interfacial properties between [BPP][NTF ] and Mg
2
-
surface, [BPP][NTF ] is adsorbed on 8 × 5 × 8 Mg (1010) surface. The bottom four
2
layers of Mg were fixed and only the top four layers of Mg and adsorbed inhibitor
were optimized. Above the Mg surface, the vacuum buffer space was set about 10 Å.
[
BPP][NTF ]@Mg was optimized by projector-augmented wave methods. The
2
specific method is the generalized gradient approximation (GGA) along with
Perdew-Burke-Ernzerhof (PBE) exchange-correlation functional [22-23]. The
dispersion effect was considered by addition of Grimme D2 dispersion correction
[
24]. The optimization would be regarded as convergence when the energy cutoff
-1
and force on each atom were smaller than 0.1 eV Å . The electron density difference
(EDD) was also calculated to study the electronic properties. Vienna ab initio
simulation package (VASP) was employed to perform above calculations [25-28].
-
2
.1.4. MD simulation for [BPP][NTf ]@Mg(1010)/50 H O
2 2
[
BPP][NTF ], 50 H O, and 8 × 5 × 8 Mg supercell were placed in a cubic box
2 2
about 26 Å × 26 Å × 37 Å with periodic boundary conditions in all directions. The
5

ACCEPTED MANUSCRIPT
Mg supercell is fixed in the following simulation. The simulation was performed for
1
000 ps with a time step of 1fs in the isothermal-isochoric ensemble (NVT) at 298 K.
The electron static interactions and Van der Waals were treated by the consistent
valence force field (CVFF) [29], while the non-bonded energies were calculated by
the popular atom based summation. Above simulation was carried out by the
FORCITE module implemented in Materials Studio 7.0 package [30].
2
.2. Synthesis and detection of [BPP][NTf2]
BPP][NTf ] was synthesized by only two steps including alkylation reaction
[
2
and ion exchange reaction (See Scheme 1): triphenylphosphine (2.62 g, 10.00 mmol)
and benzyl chloride (1.26 g, 10.00 mmol) were added into a three-necked round
bottom flask. The obtained mixtures were stirred at 100°C for 24 h under N2
atmosphere. After the reaction, the reactor was cooled to ambient temperature to
obtain the white solid benzyl triphenyl phosphonium chloride (BPPCl) (yield: about
1
00%), which was used without any further purification for the next step.
BPPCl (0.58 g, 1.50 mmol) and Lithium bis(trifluoromethane sulfonimide)
(
LiNTf , 0.47 g, 1.64 mmol) were dissolved in MeOH (20 mL). The mixtures were
2
stirred at room temperature for 3 h-4 h, the resulting solution was evaporated to
obtain the white solid. After that, the solid was washed with distilled water (20
mL×5) and dried in vacuum to obtain [BPP][NTf ] (yield: 92.2%).
2
1
The structure of [BPP][NTf ] was determined by H NMR and MS, and the data
2
was provided as follows (See Fig. S1) [31]:
1
yield 92.2%. H NMR (400 MHz, CDCl ) δ: 7.82 (m, p-Ph-, 3H,), 7.66 (td, J =
3
7
.7, 3.4 Hz, m-Ph-, 6H), 7.52 (dd, J = 12.6, 7.8 Hz, o-Ph-, 6H), 7.29 (d, J = 2.2 Hz,
Ph-CH -, 1H), 7.18 (t, J = 7.6 Hz, Ph-CH -, 2H), 6.90 (m, Ph-CH -, 2H), 4.36 (d, J =
2
2
2
+
-
1
4.1 Hz, Ph-CH -, 2H). MS (ESI) m/z: 353.21 [BPP] ; 279.95 [NTf ] .
2 2
6

ACCEPTED MANUSCRIPT
2
.3. Materials and sample preparation
AZ31B Mg alloy plates with dimension of 1 cm × 1 cm × 0.5 cm with a
composition of Al(2.5 wt%-3.5 wt%), Zn(0.6 wt%-1.4 wt%), Mn(0.2 wt%-1.0 wt%),
Si(0.08 wt%), Ca(0.04 wt%), Cu(0.01 wt%), Fe(0.003 wt%), Ni(0.001 wt%), other
elements(0.30 wt%), and the rest Mg were used as the substrate in this work. The
AZ31B Mg alloy specimens were prepared before each experiment. They were
abraded by various grades of abrasive paper, rinsed with doubly distilled water, then
degreased by acetone and finally dried. Each AZ31B Mg alloy specimen with a
ready shiny surface was used for the respective experimental measurement within 1
hour. In order to make the circuit connection, the copper wire is connected to one
surface of the Mg alloy samples. The AZ31B Mg alloy panels were all sealed with a
2
epoxy resin mixture except for an area of 1 cm unmasked. The AZ31B Mg alloy
panels immersed in 0.05 wt% NaCl solution with the [BPP][NTf ] concentrations of
2
0
.01, 0.05, 0.15, and 0.30 mM. Freshly prepared solution was used for each
measurement to ensure the accuracy.
2
.4. Electrochemical measurements
The following electrochemical measurements were performed by CHI650E
electrochemical workstation in a typical three electrode electrochemical setup. A
platinum electrode bare, a AZ31B Mg alloy electrode, and saturated calomel
electrode (SCE) were acted as the counter electrode (CE), the working electrode
(
WE), and reference electrode, respectively. For impedance spectra, the open circuit
potential (OCP) was set within the frequency domain of 10 kHz to 1 Hz by applying
mV sine wave AC voltage. Polarization curves were provided at scan rate of 10
5
−
1
mV s in a range of -2000 mV ~ -1000 mV of OCP. The electrochemical impedance
spectroscopy (EIS) data were performed by Zview 2.0 software.
7

ACCEPTED MANUSCRIPT
2
.5. FTIR spectroscopic studies
FTIR spectra were recorded in Bruker FTIR spectrometer (VERTEX 70).
AZ31B Mg alloy specimens with pretreated surfaces as described in above section
were exposed to 0.05 wt% NaCl solution with 0.30 mM [BPP][NTf ] for 87 h. The
2
thin adsorption layer formed on Mg alloy surface was cleaned with distilled water.
The rubbed product was mixed with a small amount of KBr powder in mortar. A KBr
disk was prepared using this powder. The pure [BPP][NTf ] was mixed with KBr to
2
prepare the disk.
2
.6. Surface analysis
For more intuitive surface analysis, AZ31B Mg alloy specimens with pretreated
surfaces as described in above section were exposed to 0.50 wt% NaCl solution
without and with 0.05 mM of [BPP][NTf ]. After 48 h of immersion, the specimens
2
were taken out. Then, the corrosion products were removed by chromic solution
(
200 g/L CrO + 10 g/L AgNO ) for 10-15 mins and washed with distilled water.
3 3
Then, they were air-dried for 40 min. Scanning electron microscope (SEM) images
retrieved from the polished AZ31B Mg surface as well as that without and with
[
BPP][NTf ] by the JSM-7610F SEM.
2
3
. Results and discussion
3
.1. Primary judgment
According to the previous report, the enhancement of coverage range would
form an effective protected surface to isolate the metal and the environment. As a
result, the corrosion is greatly inhibited. Besides the long alkyl chain, the inclusion
of π-group is an alternative method to accomplish aforementioned goal. A new ionic
liquid, [BPP][NTf ], is designed as the potential inhibitor for AZ31B Mg alloy.
2
Before to perform the corresponding measurements, some theoretical calculations
8

ACCEPTED MANUSCRIPT
are carried out to predict its potential to be inhibitor. The schematic and optimized
structures of [BPP][NTf ] are plotted in Fig. 1. Due to the absence of covalent bond
2
between cation and anion for [BPP][NTf ], there are many possible configurations
2
for it. To further confirm the rightness of optimized structure, the radial distribution
function (RDF) and spatial distribution function (SDF) are obtained by the MD
simulation. As shown in Fig. S2, the anion should be around two phenyl groups.
Moreover, the distances between P atom and N1/S2/S3 atoms are 5.05 Å, 5.65 Å,
and 5.65 Å, which is in good agreement with the optimized parameters of 4.29 Å for
P···N1, 5.23 Å for P···S2, and 5.25 Å for P···S3. It testifies that the configuration
optimized by B3PW91/6-31G(d,p) level is reliable. Correspondingly, it is reasonable
to believe that the following calculated results would be satisfactory on the basis of
the optimized structures.
The highest occupied molecular orbital (HOMO, H) and lowest unoccupied
molecular orbital (LUMO, L) are listed in Table 1 along with H-L energy gap (ꢀE),
electronegativity (χ), dipole moment (ꢀ), and electrophilicity index (ω) in gas phase.
The EHOMO of [BPP][NTf ] is the higher than that of [P6,6,6,14][NTf ] indicating the
2
2
better ability to donate electrons. In contrast, the ELUMO of [BPP][NTf ] is the lower
2
than that of [P6,6,6,14][NTf ] suggesting the larger possibility to accept electrons. As a
2
result, the ꢀE of [BPP][NTf ] is the smaller as compared with that of [P6,6,6,14][NTf2]
2
suggesting the more activity [32]. The higher HOMO energy level implies the better
ability to donate the electrons. In contrast, the lower LUMO energy level indicates
the larger possibility to accept electrons. Correspondingly, the larger chemical
reactivity would be expected for the inhibitor due to the smaller ꢀE. Moreover, the
[
BPP][NTf ] has the larger dipole moment (ꢀ), which is favorable to form a strong
2
adsorption on the metal surface leading to the better inhibition. Additionally,
9

ACCEPTED MANUSCRIPT
[
BPP][NTf ] has the larger electronegativity (χ) and electrophilicity index (ω) as
2
compared with [P6,6,6,14][NTf ]. All calculated data indicate that [BPP][NTf ] would
2
2
be perhaps more efficient than [P6,6,6,14][NTf ]. More importantly, the raw materials
2
to synthesize [BPP][NTf ] are abundant and cheap. The synthetic steps are simple
2
along with the benign reaction condition. In general, the [BPP][NTf ] is a promising
2
alternative for [P6,6,6,14][NTf2].
3
.2. Electrochemical impedance spectroscopy (EIS)
The Nyquist plot of AZ31B Mg alloy in 0.05 wt% NaCl solution, which is
normally employed to simulate the marine atmospheric environment, in the presence
and absence of [BPP][NTf ] is shown in Fig. 2. As compared with the curve without
2
inhibitor, the diameter of convex arcs is increased with the increment of [BPP][NTf2]
concentration. The increased magnitude of capacity loops is not the same. Taken the
blank solution as a criterion, the enlarged extent of diameter of capacity loop is the
largest when the [BPP][NTf ] concentration is increased to 0.30 mM. AZ31B Mg
2
alloy surface would get more protection and corrosion resistance is more efficient
when concentration of [BPP][NTf ] researches 0.30 mM. However, the general
2
shape is similar for all inhibited concentration indicating that the corrosion
mechanism is not altered with the addition of [BPP][NTf ]. The corrosion is
2
controlled just by retarding the reaction rate with the addition of [BPP][NTf2].
The corresponding Bode phase angle as well as impedance plots from the EIS
measurements are plotted in Fig. 3. As compared with the low-frequency impedance
in the solution without [BPP][NTf ], the corresponding values increase with the
2
concentration improvement of [BPP][NTf ]. Moreover, the frequency range with the
2
maximum phase angle becomes larger suggesting effective adsorption of
[
BPP][NTf ] on the AZ31B Mg alloy surface. Corresponding equivalent circuits to
2
1
0

ACCEPTED MANUSCRIPT
analyze the impedance is shown in Fig. 4, in which R is the solution resistance, R is
s
p
polarization resistance, and CPE is constant phase element.
The impedance parameters obtained from the equivalent circuits are listed in
Table 2 with more detailed analysis. C (double capacitance) can be calculated
dl
according to CPE, fmax, and a by the following equation [33-37]:
a−1
Cdl = CPE×(2
π
f )
(2)
max
where a is the depression coefficient, fmax is the frequency at which imaginary
impedance is maximal in Nyquist plot. The percentage inhibition efficiency (ηE)
obtained by the EIS test was calculated by the following relationship:
Rp(inh) − Rp
ηE% =
×100
(3)
Rp(inh)
where Rp(inh) and R are the values of polarization resistance with and without the
p
2
-2
inhibitor. The chi-squared (χ ) values in Table 2 are lower than 1×10 indicating that
the fitted data are in good coincidence with the experimental data. As compared with
the uninhibited system, both R and R values are increased in the presence of
s
p
[
BPP][NTf ]. Moreover, their values enhance with the increase of [BPP][NTf ]
2 2
concentration. However, the R is increased by 99.3 ꢁ, which is much smaller than
s
the increasing extent for R (6986.1 ꢁ). The increasing R suggests that the corrosion
p
p
of AZ31B Mg alloy electrode is remarkably retarded in the presence of [BPP][NTf2].
The decreasing of CPE and C could be attributed to the decreased exposure of
dl
electrode surface area and/or the increased thickness of the adsorption layer. The
water molecules are blocked by [BPP][NTf ] far away from the AZ31B Mg alloy
2
interface leading to the less active sites for the corrosion. The inhibition efficiency is
still over 70% even when the concentration of [BPP][NTf ] is 0.01 mM. The
2
optimum inhibition efficiency reaches 91.4% when the concentration of [BPP][NTf2]
1
1

ACCEPTED MANUSCRIPT
is 0.30 mM. In general, [BPP][NTf ] is an effective inhibitor for the corrosion of
2
AZ31B Mg alloy in NaCl solution.
3
.3. Potentiodynamic polarization measurements
The potentiodynamic polarization curves of AZ31B Mg alloy in 0.05 wt% NaCl
solution in the absence and presence of different concentrations of [BPP][NTf ] are
2
shown in Fig. 5. There is a significant drop for both cathodic and anodic current
densities suggesting that the corrosion is effectively inhibited. The potential curves
shifts towards the more negative potentials as compared with the system without
inhibitor indicating that the cathodic reaction is predominantly retarded.
Kinetic parameters such as the corrosion potential (E ), corrosion current
corr
density (i ), anodic and cathodic Tafel slopes (β and β respectively) are listed in
corr
a
c
Table 3. The percentage inhibition efficiency (η %) is evaluated by the relationship:
P
icorr − icorr(inh)
ηp % =
×100
(4)
icorr
where icorr is the corrosion current density without inhibitor and icorr(inh) is the
corrosion current density with inhibitor. The deviation of Ecorr between the inhibited
and uninhibited system is larger than 85 mV, which implies that the [BPP][NTf ] is a
2
cathodic inhibitor. The variations for both β and β upon addition of [BPP][NTf ]
a
c
2
imply that the reduction of both the anodic dissolution and hydrogen evolution
reaction rather than only the surface blocking. The η % values increase with the
p
increasing concentration of [BPP][NTf ] up to 87.4%, which is consistent with the
2
result evaluated from EIS result.
3
.4. Adsorption isotherm
Since the adsorption ability of [BPP][NTf ] on the AZ31B Mg alloy surface is
2
important to the inhibition efficiency, the adsorption behavior is evaluated by the
1
2

ACCEPTED MANUSCRIPT
adsorption isotherms. The plot of C /θ against inhibitor concentration Cinh (Fig. 6)
inh
yields a straight line with correlation coefficient of 0.999 and slope of 1.08,
confirming that the adsorption of [BPP][NTf ] on AZ31B Mg alloy surface follows
2
the Langmuir adsorption isotherm [38-42]:
Cinh
1
=
+ Cinh
(5)
θ
Kads
where θ is surface coverage, Cinh is the inhibitor concentration, and Kads is the
equilibrium constant of the adsorption process. Calculated Kads value for [BPP][NTf2]
5
-1
-1
is 1.37×10 M . The larger K (> 100 M ) means the stronger adsorption leading to
ads
the more efficient inhibitor, which is calculated according to relationship [39-42]:
0
ads
1
− ꢀG
Kads
=
exp(
)
(6)
5
5.5
RT
where the value 55.5 is the molar concentration of water in the solution, T = 298 K,
0
R is the gas constant, and
ꢀ
G
is the standard Gibbs free energy of adsorption.
ads
0
The negative
ꢀ
G
value indicates that the adsorption of [BPP][NTf ] on the
ads
2
AZ31B Mg alloy surface would happen spontaneously resulting in the stability
0
adsorbed film. Moreover, the
ꢀ
G
value is -39 kJ/mol, which is close to -40
ads
kJ/mol, implies that the chemisorption is the main adsorption of [BPP][NTf ] on the
2
AZ31B Mg alloy surface [43].
According to the MD simulation, the initial adsorption configuration of
-
[
BPP][NTf ]@Mg(1010)/50 H O system is depicted in Fig. S3 and the variation of
2 2
distances between H26 atom in [BPP][NTf ] and Mg atom from the first layer of Mg
2
surface is plotted in Fig. 7. The shortest equilibrium distance between Mg and H26
atom is 1.54 Å, which is less than their sum of Van der Waals radius. The
1
3

ACCEPTED MANUSCRIPT
-
[
BPP][NTf ] would be adsorbed on the Mg surface. The [BPP][NTf ]@Mg(1010) is
2 2
also optimized by the PBE method. The binding energy between [BPP][NTf ] and
2
-
Mg(1010) surface is -201.60 kJ/mol indicating that the adsorption is spontaneous.
To gain more insight into the electronic properties of the [BPP][NTf ]@Mg(10
2
-
1
0) interface, the electron density difference (EDD) is investigated, which is defined
by the following equation:
ꢀ
ρ = ρtotal − (ρMg + ρinh
)
(7)
in which ρtotal is the total electron density of the system, ρMg is the electron density
for clean surface of Mg, and ρinh is the electron density of isolated [BPP][NTf ]. As
2
shown in Fig. 8, there is clear electron exchange between [BPP][NTf ] and Mg
2
surface indicating the strong interaction between [BPP][NTf ] and Mg surface. It is
2
in good agreement with the experimental result that the adsorption of [BPP][NTf2]
on the Mg surface is mainly contributed by chemisorption although there is no clear
covalent bond formed between [BPP][NTf ] and Mg surface. Since the formation or
2
break of chemical bond could not be simulated by the MD, only the effect of
adsorption is considered. In the latter section, the chemical reaction between ionic
liquids would be discussed. The inhibitor mechanism is complex, which should not
belong to one or two items.
3
.5. SEM analysis
The high resolution photographs of the directly polished AZ31B Mg alloy
specimen, AZ31B Mg alloy immersed in 0.50 wt% NaCl, and AZ31B Mg alloy
immersed in 0.50 wt% NaCl solution with 0.05 mM [BPP][NTf ] are presented in
2
Fig. 9, respectively. As shown in Fig. 9, AZ31B Mg alloy surface is severely
1
4

ACCEPTED MANUSCRIPT
corroded by 0.50 wt% NaCl solution in the absence of [BPP][NTf ] leading to
2
porous and rough surface. When the [BPP][NTf ] is included in the 0.50 wt% NaCl
2
solution, the specimen surface is less corroded. Some original abrading scratches
could also be observed indicating that [BPP][NTf ] performs efficient inhibition for
2
the corrosion of AZ31B Mg alloy in 0.50 wt% NaCl solution.
3
.6. Possible corrosion and inhibition mechanism
The dissolution of Mg is mainly aroused by the following reactions, which has
been reported in several previous literature [44-46]:
+
-
2
H + 2e → H (cathodic partial reaction)
(8)
(9)
2
+
-
2
Mg → 2Mg + 2e (anodic partial reaction)
+
2+
-
2
Mg + 2H O → 2Mg + 2OH + H (chemical reaction)
(10)
(11)
(12)
2
2
+
2+
-
2
Mg +2H + 2H O → 2Mg + 2OH + 2H (overall reaction)
2 2
2
+
-
Mg + 2OH → Mg(OH) (product formation)
2
-1
As shown in Fig. 10, the appearance of band at 3700 cm in corrosion product is
attributed to the O-H stretching indicating the formation of Mg(OH) . The above
2
results testified that the Mg surface has been corroded. However, the formed
Mg(OH) is porous film on the Mg surface, which could not provide satisfactory
2
protection for the Mg alloy. When the [BPP][NTf ] is involved in the NaCl solution,
2
-1
the intensity at 3700 cm is obviously decreased indicating that the formation of
Mg(OH) is greatly suppressed. Alternatively, the hole of Mg(OH) is filled by other
2
2
-
components, which would also keep the Mg alloy from corroding. The NTf anion
2
would decompose into the small species by the cleavage of S-N bond, S-C bond, or
C-F bond [47-48]:
-
-
2-
3 2
-
-
N(SO CF ) + e → N(SO CF ) → •NSO CF + SO CF
(13)
(14)
2
3 2
2
2
3
2
3
-
-
-
-
N•SO CF + e → NSO + CF
2
3
2
3
1
5

ACCEPTED MANUSCRIPT
-
-
-
-
SO CF + e → SO + CF
3
(15)
(16)
2
3
2
-
-
-
-
CF SO NSO CF + e → F + •CF SO NSO CF
3
3
2
2
3
2
2
2
2
+
-
which has been reported in previous literature. The Mg would react with F to form
-1
MgF , which is insoluble. The band at 468 cm in corrosion product indicates the
2
existence of Mg-F bond. The MgF would fill up the hole of Mg(OH) film to isolate
2
2
the Mg alloy surface to the water. Correspondingly, the further corrosion is inhibited.
In contrast, the effect of cation is simply considered to be covered in the metal
+
surface to separate the metal and corrosion species. The cation C H CH P(C H )
5 3
6
5
2
6
-
would be reduced to C H CH anion, which is optimized at the B3PW91/6-31G (d,p)
6
5
2
level. The P-C bond is elongated to be 4.32 Å, which is much larger than that in the
+
C H CH P(C H ) cation suggesting the disrupt of P-C bond into the following
6
5
2
6
5 3
products:
C H CH P(C H ) + 2e → P(C H ) + C H CH
2
+
-
-
(17)
6
5
2
6
5 3
6
5 3
6
5
The ꢀG (Gibbs free energy) of eq. (17) is -114.69 kJ/mol indicating that it would
be performed spontaneously. Then, the Mg(C H CH )Cl would be formed to retard
6
5
2
the further corrosion.
. Conclusion
BPP][NTf ] is designed and synthesized to be corrosion inhibitor for Mg alloy.
4
[
2
The [BPP][NTf ] could effectively suppress corrosion of AZ31B Mg alloy in 0.05
2
wt% NaCl solution with the largest inhibition efficiency up to 91.4%. It is regarded
as cathodic inhibitor following the Langmuir adsorption behavior. The inhibition
performance is further testified by the SEM observations. Combination of first
principle and MD simulations, the interaction between [BPP][NTf ] and Mg surface
2
is elucidated, which is accordance with the experimental result. Finally, the
inhibition mechanism is proposed according to the FTIR and DFT calculations. The
1
6

ACCEPTED MANUSCRIPT
influence of cation is elucidated, which is not only the cover in the Mg alloy surface.
Acknowledgement
We thank the National Supercomputing Center in Shenzhen (Shenzhen Cloud
Computing Center) for providing computational resources and softwares. This work
was supported by the National Natural Science Foundation of China (21503069,
2
1676071).
References
[
1] S.A. Umoren, U.M. Eduok, Application of carbohydrate polymers as corrosion
inhibitors for metal substrates in different media: A review, Carbohyd. Polym.
140 (2016) 314-341.
[
[
2] Y. Zhu, M.L. Free, R. Woollam, W. Durnie, A review of surfactants as corrosion
inhibitors and associated modeling, Prog. Mater. Sci. 90 (2017) 159-223.
3] K. Zhang, B. Xu, W. Yang, X. Yin, Y. Liu, Y. Chen, Halogen-substituted
imidazoline derivatives as corrosion inhibitors for mild steel in hydrochloric
acid solution, Corros. Sci. 90 (2015) 284-295.
[
4] B. Ramezanzadeh, S.Y. Arman, M. Mehdipour, B.P. Markhali, Analysis of
electrochemical noise (ECN) data in time and frequency domain for comparison
corrosion inhibition of some azole compounds on Cu in 1.0 M H SO solution,
2
4
Appl. Surf. Sci. 289 (2014) 129-140.
[
[
5] S. Şafak, B. Duran, A. Yurt, G. Türkoğlu, Schiff bases as corrosion inhibitor for
aluminium in HCl solution, Corros. Sci. 54 (2012) 251-259.
6] Y. Qiang, S. Zhang, L. Guo, X. Zheng, B. Xiang, S. Chen, Experimental and
theoretical studies of four allyl imidazolium-based ionic liquids as green
inhibitors for copper corrosion in sulfuric acid, Corros. Sci. 119 (2017) 68-78.
7] X. Zheng, S. Zhang, W. Li, L. Yin, J. He, J. Wu, Investigation of
[
1
7

ACCEPTED MANUSCRIPT
1-butyl-3-methyl-1H-benzimidazolium iodide as inhibitor for mild steel in
sulfuric acid solution, Corros. Sci. 80 (2014) 383-392.
[
[
[
8] Q. Zhang, Y. Hua, Corrosion Inhibition of aluminum in hydrochloric acid
solution by alkylimidazolium ionic liquids, Mater. Chem. Phys. 119 (2010)
5
7-64.
9] J. Hu, D. Zeng, Z. Zhang, T. Shi, G.L. Song, X. Guo,
-Hydroxy-4-methoxy-acetophenone as an environment-friendly corrosion
2
inhibitor for AZ91D magnesium alloy, Corros. Sci. 74 (2013) 35-43.
10] M. Esmaily, J.E. Svensson, S. Fajardo, N. Birbilis, G.S. Frankel, S. Virtanen, R.
Arrabal, S. Thomas, L.G. Johansson, Fundamentals and advances in
magnesium alloy corrosion, Prog. Mater. Sci. 89 (2017) 92-193.
[
[
11] Z. Zeng, N. Stanford, C.H.J. Davies, J.F. Nie, N. Birbilis, Magnesium extrusion
alloys: a review of developments and prospects, Int. Mater. Rev. (2018) 1-36.
12] P. Huang, J.A. Latham, D.R. MacFarlane, P.C. Howlett, M. Forsyth, A review
of ionic liquid surface film formation on Mg and its alloys for improved
corrosion performance, Electrochim. Acta 110 (2013) 501-510.
[
13] P.C. Howlett, S. Zhang, D.R. MacFarlane, M. Forsyth, An investigation of a
phosphinate-based ionic liquid for corrosion protection of magnesium alloy
AZ31, Aust. J. Chem. 60 (2007) 43-46.
[
[
14] T. Darden, D. York, L. Pedersen, Particle mesh Ewald: an N·Log(N) method for
Ewald sums in large systems, J. Chem. Phys. 98 (1993) 10089-10092.
15] J. Wang, R.M. Wolf, J.W. Caldwell, P.A. Kollman, D.A. Case, Development
and testing of a general amber force field, J. Comput. Chem. 25 (2004)
1157-1174.
[
16] J.P. Ryckaert, G. Ciccotti, H.J. Berendsen, Numerical integration of the
1
8

ACCEPTED MANUSCRIPT
cartesian equations of motion of a system with constraints: molecular dynamics
of n-alkanes, J. Comput. Phys. 23 (1977) 327-341.
[
17] D. Van Der Spoel, E. Lindahl, B. Hess, G. Groenhof, A.E. Mark, H.J.
Berendsen, GROMACS: fast, flexible, and free, J. Comput. Chem. 26 (2005)
1701-1718.
[
[
18] A.D. Becke, Density-functional thermochemistry. III. the role of exact exchange,
J. Chem. Phys. 98 (1993) 5648-5652.
19] J.P. Perdew, K. Burke, Y. Wang, Generalized gradient approximation for the
exchange-correlation hole of a many-electron system, Phys. Rev. B 54 (1996)
16533-16539.
[
[
20] P.M. Gill, B.G. Johnson, J.A. Pople, M.J. Frisch, The performance of the
Becke-Lee-Yang-Parr (B-LYP) density functional theory with various basis sets,
Chem. Phys. Lett. 197 (1992) 499-505.
21] M.J. Frisch, G.W. Trucks, H.B. Schlegel, G.E. Scuseria, M.A. Robb, J.R.
Cheeseman, G. Scalmani, V. Barone, B. Mennucci, G.A. Petersson, H.
Nakatsuji, M. Caricato, X. Li, H.P. Hratchian, A.F. Izmaylov, J. Bloino, G.
Zheng, J.L. Sonnenberg, M. Hada, M. Ehara, K. Toyota, R. Fukuda, J.
Hasegawa, M. Ishida, T. Nakajima, Y. Honda, O. Kitao, H. Nakai, T. Vreven,
J.A. Montgomery, J.E. Peralta Jr, F. Ogliaro, M. Bearpark, J.J. Heyd, E.
Brothers, K.N. Kudin, V.N. Staroverov, R. Kobayashi, J. Normand, K.
Raghavachari, A. Rendell, J.C. Burant, S.S. Iyengar, J. Tomasi, M. Cossi, N.
Rega, J.M. Millam, M. Klene, J.E. Knox, J.B. Cross, V. Bakken, C. Adamo, J.
Jaramillo, R. Gomperts, R.E. Stratmann, O. Yazyev, A.J. Austin, R. Cammi, C.
Pomelli, J.W. Ochterski, R.L. Martin, K. Morokuma, V.G. Zakrzewski, G.A.
Voth, P. Salvador, J.J. Dannenberg, S. Dapprich, A.D. Daniels, O. Farkas, J.B.
1
9

ACCEPTED MANUSCRIPT
Foresman, J.V. Ortiz, J. Cioslowski, D.J. Fox, Gaussian 09, Revision D.01,
Gaussian Inc., Wallingford CT, 2009.
[
[
22] J.P. Perdew, K. Burke, M. Ernzerhof, Generalized gradient approximation made
simple, Phys. Rev. Lett. 77 (1996) 3865-3868.
23] R. Elmér, M. Berg, L. Carlén, B. Jakobsson, B. Norén, A. Oskarsson, G.
Ericsson, J. Julien, T.F. Thorsteinsen, M. Guttormsen, G. Løvhøiden, V. Bellini,
+
E. Grosse, C. Müntz, P. Senger, L. Westerberg, K emission in symmetric heavy
ion reactions at subthreshold energies, Phys. Rev. Lett. 77 (1996) 4884-4886.
24] S. Grimme, Semiempirical GGA-type density functional constructed with a
long-range dispersion correction, J. Comput. Chem. 27 (2006) 1787-1799.
25] G. Kresse, J. Furthmüller, Efficiency of ab-initio total energy calculations for
metals and semiconductors using a plane-wave basis set, Comp. Mater. Sci. 6
[
[
(1996) 15-50.
[
[
26] G. Kresse, J. Furthmüller, Efficient iterative schemes for ab initio total-energy
calculations using a plane-wave basis set, Phys. Rev. B 54 (1996) 11169-11186.
27] G. Kresse, J. Hafner, Ab initio molecular-dynamics simulation of the
liquid-metal-amorphous-semiconductor transition in germanium, Phys. Rev. B
49 (1994) 14251-14269.
[
[
28] G. Kresse, J. Hafner, Ab initio molecular dynamics for liquid metals, Phys. Rev.
B 47 (1993) 558-561.
29] J. Bartley, N. Huynh, S.E. Bottle, H. Flitt, T. Notoya, D.P. Schweinsberg,
Computer simulation of the corrosion inhibition of copper in acidic solution by
alkyl esters of 5-carboxybenzotriazole, Corros. Sci. 45 (2003) 81-96.
30] Materials Studio, Accelrys Software, Inc, San Diego, CA, 2010.
31] R. Arvai, F. Toulgoat, B.R. Langlois, J.Y. Sanchez, M. Médebielle, A simple
[
[
2
0

ACCEPTED MANUSCRIPT
access to metallic or onium bistrifluoromethanesulfonimide salts. Tetrahedron
65 (2009) 5361-5368.
[
32] S. Yesudass, L.O. Olasunkanmi, I. Bahadur, M.M. Kabanda, I.B. Obot, E.E.
Ebenso, Experimental and theoretical studies on some selected ionic liquids
with different cations/anions as corrosion inhibitors for mild steel in acidic
medium, J. Taiwan Inst. Chem. E. 64 (2016) 252-268.
[
[
33] F. Mansfeld, Recording and analysis of AC impedance data for corrosion
studies, Corrosion 36 (1981) 301-307.
34] C.H. Hsu, F. Mansfeld, Technical note: concerning the conversion of the
constant phase element parameter Y into a capacitance, Corrosion 57 (2001)
0
747-748.
[
[
[
35] Q. Qu, S. Jiang, W. Bai, L. Li, Effect of ethylenediamine tetraacetic acid
disodium on the corrosion of cold rolled steel in the presence of benzotriazole
in hydrochloric acid, Electrochim. Acta 52 (2007) 6811-6820.
36] H.H. Hassan, Inhibition of mild steel corrosion in hydrochloric acid solution by
triazole derivatives: Part II: time and temperature effects and thermodynamic
treatments, Electrochim. Acta 53 (2007) 1722-1730.
37] J. Zhao, G. Chen, The synergistic inhibition effect of oleic-based imidazoline
and sodium benzoate on mild steel corrosion in a CO -saturated brine solution,
2
Electrochim. Acta 69 (2012) 247-255.
[
[
38] F.W. Schapink, M. Oudeman, K.W. Leu, J.N. Helle, The adsorption of thiourea
at a mercury-electrolyte interface, T. Faraday. Soc. 56 (1960) 415-423.
39] A.A. El-Awady, B.A. Abd-El-Nabey, S.G. Aziz, Kinetic-thermodynamic and
adsorption isotherms analyses for the inhibition of the acid corrosion of steel by
2
1

ACCEPTED MANUSCRIPT
cyclic and open-chain amines, J. Electrochem. Soc. 139 (1992) 2149-2154.
[
[
40] O. Ikeda, H. Jimbo, H. Tamura, Adsorption of tetramethylthiourea at the
mercury/water interface, J. Electroanal. Chem. 137 (1982) 127-141.
41] E. Khamis, F. Bellucci, R.M. Latanision, E.S.H. El-Ashry, Acid corrosion
inhibition of nickel by 2-(triphenosphoranylidene) succinic anhydride,
Corrosion 47 (1991) 677-686.
[
[
[
42] H.P. Dhar, B.E. Conway, K.M. Joshi, On the form of adsorption isotherms for
substitutional adsorption of molecules of different sizes, Electrochim. Acta 18
(1973) 789-798.
43] A. Zarrouk, B. Hammouti, A. Dafali, F. Bentiss, Inhibitive properties and
adsorption of purpald as a corrosion inhibitor for copper in nitric acid medium,
Ind. Eng. Chem. Res. 52 (2013) 2560-2568.
44] R.C. Zeng, Y. Hu, S.K. Guan, H.Z. Cui, E.H. Han, Corrosion of magnesium
alloy AZ31: the influence of bicarbonate, sulphate, hydrogen phosphate and
dihydrogen phosphate ions in saline solution, Corros. Sci. 86 (2014) 171-182.
45] G. Song, Recent progress in corrosion and protection of magnesium alloys, Adv.
Eng. Mater. 7 (2005) 563-586.
[
[
46] J. Hu, D. Zeng, Z. Zhang, T. Shi, G.L. Song, X. Guo,
2-Hydroxy-4-methoxy-acetophenone as an environment-friendly corrosion
inhibitor for AZ91D magnesium alloy, Corros. Sci. 74 (2013) 35-43.
47] P.C. Howlett, E.I. Izgorodina, M. Forsyth, D.R. MacFarlane, Electrochemistry
at negative potentials in bis(trifluoromethanesulfonyl)amide ionic liquids, Z.
Phys. Chem. 220 (2006) 1483-1498.
[
[
48] C.C. Nguyen, S.W. Woo, S.W. Song, Understanding the interfacial processes at
silicon-copper electrodes in ionic liquid battery electrolyte, J. Phys. Chem. C
2
2

ACCEPTED MANUSCRIPT
116 (2012) 14764-14771.
2
3

ACCEPTED MANUSCRIPT
Table 1 Chemical parameters for optimized [BPP][NTf ] and [P
][NTf ] at the B3PW91/6-31G(d,p) level.
6,6,6,14 2
2
Inhibitor
ELUMO (eV)
EHOMO (eV)
∆E (eV)
ꢀ
χ
ω
[
BPP][NTf2]
-2.01
-6.87
-7.02
4.86
7.60
17.74
4.44
2.03
[
P6,6,6,14][NTf2]
0.58
15.09
3.22
0.68

ACCEPTED MANUSCRIPT
Table 2 Electrochemical parameters obtained from Nyquist and Bode plots for AZ31B Mg alloy electrode in 0.05 wt% NaCl without and with
different concentrations of [BPP][NTf2].
2
C
Rs
Rp
CPEdl
a
Cdl
χ
ηE
(%)
-
θ
2
2
-1
n
-2
-1
n
-2
(
mM)
( Ω cm )
545.6
536.2
582.3
612.7
644.9
( Ω cm )
659.9
2489
(µΩ S cm )
(µΩ S cm )
-3
-3
-3
-3
-3
Blank
16.110
0.967
0.935
0.936
0.883
0.886
13.8
6.5
6.8
8.3
7.5
9.66×10
4.42×10
3.49×10
1.02×10
1.82×10
-
0
0
0
0
.01
.05
.15
.30
8.546
73.5
79.4
85.8
91.4
0.735
0.794
0.858
0.914
3203
8.630
4643
12.091
7646
10.330

ACCEPTED MANUSCRIPT
Table 3 Electrochemical parameters obtained from potentiodynamic polarization curves for AZ31B Mg alloy electrode in 0.05 wt% NaCl
without and with different concentrations of [BPP][NTf2].
2
C (mM)
Ecorr (V)
-1.276
-1.388
-1.404
-1.431
-1.452
icorr (µA/cm )
βc (V/dec)
4.558
βa (V/dec)
2.341
ηp (%)
-
Blank
12.30
0
0
0
0
.01
.05
.15
.30
3.727
8.661
4.550
69.7
78.0
79.8
87.4
2.707
10.980
12.232
20.079
6.914
2.484
8.129
1.549
14.502

ACCEPTED MANUSCRIPT
Fig. 1. The schematic and optimized structures of [BPP][NTf2].

ACCEPTED MANUSCRIPT
Fig. 2. Nyquist plot for AZ31B Mg alloy electrode in 0.05 wt% NaCl without and
with different concentrations of [BPP][NTf2].
