ABSTRACT: A universal multiꢀstage cascade CSTR has been developed which is suitable for a
wide range of continuousꢀflow processes. Coined by our group the ‘Freactor’ (freeꢀtoꢀaccess
reactor), the new reactor integrates the efficiency of pipeꢀflow processing with the advanced
mixing of a CSTR, delivering a general ‘plugꢀandꢀplay’ reactor platform which is wellꢀsuited to
multiphasic continuousꢀflow chemistry. Importantly, the reactor geometry is easily customized to
accommodate reactions requiring long residence times (≥ 3 hours tested).
