318
M. Mohammadikish et al. / Journal of Magnetism and Magnetic Materials 354 (2014) 317–323
reactions and also provide functional groups for immobilization of
desired catalytic species.
atmosphere. The mixture was refluxed for 12 h and the resultant
solid was magnetically separated, washed with methanol to
remove the unreacted residue of silylating reagent and then
vacuum dried at 80 1C.
Our current interest in the immobilization of molybdenum
complexes on different supports [25–29,33–35] led us to investi-
gate the preparation and characterization of a new covalently
attached molybdenum hybrid nanomaterial on the surface of silica
coated magnetite nanoparticles. The preparation of this hybrid
nanomaterial is based on successive Schiff base condensation of
amine modified silica coated magnetite nanoparticles with ter-
ephthaldehyde and thiosemicarbazide to give a supporting ligand
to which molybdenum was coordinated in final step. The main
advantage of the system is relatively strong interaction of molyb-
denum complex attached on the surface of magnetite nanoparti-
cles which prevent from leaching to reaction mixture during
catalytic reactions. The presence of thiosemicarbazide as good
donor ligand enhances the catalytic activity of the prepared
nanomaterial in the epoxidation of olefins. On the other hand,
due to the presence of magnetite core, the prepared hybrid
nanomaterial has superparamagnetic properties which make its
easy recovery and reuse in catalytic reactions.
2.1.2. Immobilization of thiosemicarbazide on the surface of silica
coated magnetite nanoparticles
The prepared AmpSCMNPs (2 g) suspended in 100 ml of
ethanol with sonication were mixed with excess of terephthalde-
hyde (4 mmol) and the resultant mixture was refluxed for 24 h.
The resultant solid (named as tereph-SCMNPs) was separated mag-
netically and washed with ethanol several times to remove the
unreacted residue of the terephthaldehyde. Afterwards, the
obtained tereph-SCMNPs (2 g) were suspended in ethanol
(100 ml) and thiosemicarbazide (4 mmol) was added under dry
nitrogen atmosphere. The mixture was refluxed for 24 h and the
resultant solid, named as thio-SCMNPs, was magnetically separated,
washed with methanol to remove the unreacted reagents and then
vacuum dried at 80 1C.
2.1.3. Immobilization of molybdenum complex on the surface of
magnetite nanoparticles
2. Experimental
Excess of MoO2(acac)2 (4 mmol) was dissolved in ethanol
(50 ml). The prepared thio-SCMNPs (2 g, dried in vacuum oven
at 80 1C) was then added to this solution with sonication and the
mixture was refluxed for 12 h. After separation with an external
magnet, the product was washed with methanol to remove
unreacted MoO2(acac)2. The resultant MoO2–thio-SCMNPs material
was then dried under vacuum at 80 1C.
2.1. Materials and instrumentation
All chemicals were purchased from Merck chemical company
and used without further purification. MoO2(acac)2 was prepared
according to literature [45] and its structure was confirmed by
spectroscopic methods.
Fourier transform infrared (FT-IR) spectra were recorded on
Rayleigh WQF-510 spectrophotometer using pellets of the materials
diluted with KBr. Chemical analyses of the samples were carried out
with VARIAN VISTA-MPX ICP-AES atomic absorption spectrometer.
The crystalline phase of the prepared nanomaterial was identified by
means of X-ray diffraction measurements using Cu Kα radiation
(λ¼1.54 Å) on a SIEFERT XRD 3003 PTS diffractometer in the 2θ range
of 10–801. Magnetic susceptibility measurements were carried out
using a vibrating sample magnetometer (VSM) (BHV-55, Riken, Japan)
in the magnetic field range of ꢀ8000 Oe to 8000 Oe at room
temperature. Thermogravimetric measurements were made on a
Perkin Elmer Diamond Thermogravimeter. The temperature was
increased to 700 1C using a rate of 10 1C/min in static air. The
transmission electron micrographs (TEM) of the nanoparticles were
recorded using a Philips EM 208 S instrument with an accelerating
voltage of 100 kV. Samples were prepared for TEM by placing droplets
of a suspension of the sample in acetone on a polymer microgrid
supported on a Cu grid. Scanning electron micrographs (SEM) of the
samples were taken with ZEISS-DSM 960A microscope with attached
camera.
2.2. Catalytic epoxidation of olefins in the presence of MoO2–thio-
SCMNPs
Epoxidation of olefins was carried out in a 25 ml round
bottomed flask equipped with a condenser and a magnetic stirrer.
Tert-butylhydroperoxide (80% in di-tertiary butyl peroxide) or
cumene hydroperoxide (80% in cumene) were used as oxidants.
In a typical procedure, to a mixture of catalyst (100 mg) and olefin
(8 mmol) in chloroform (10 ml) oxidant was added (14.4 mmol)
under nitrogen atmosphere and the mixture was refluxed for
appropriate time. Samples were withdrawn periodically and after
dilution with chloroform and cooling were analyzed using a gas
chromatograph (HP, Agilent 6890N) equipped with a capillary
column (HP-5) and a FID detector. Products were quantified using
isooctane (1 g, 8.75 mmol) as internal standard. GC–MS of pro-
ducts were recorded using a Shimadzu-14A fitted with a capillary
column (CBP5-M25). In order to perform the recovery test, the
epoxidation of cyclooctene was allowed to proceed 2 h. The
catalyst was then recovered magnetically at the reaction tempera-
ture and the solution was decanted into a clean 25 ml flask and
refluxed for 24 h. The conversions and selectivities were deter-
mined after 2 and 24 h.
2.1.1. Preparation of silica coated magnetite nanoparticles (SCMNPs)
and aminoropropyl modified SCMNPs (AmpSCMNPs)
The molybdenum content of recycled catalyst was measured
with above mentioned atomic absorption spectrometer after
digestion of the filtered catalyst in hydrochloric acid solution.
Magnetite nanoparticles (MNPs) were prepared according to
reported method [42]. For preparation of SCMNPs, the magnetite
nanoparticles (1 g) were dispersed in deionized water in a 250 ml
round-bottom flask with sonication and then an aqueous solution
of TEOS (10% (v/v), 80 ml) was added, followed by glycerol (50 ml).
The pH of the suspension was adjusted to 4.5 using glacial acetic
acid, and the mixture was then stirred and heated at 90 1C for 2 h
under a nitrogen atmosphere. After cooling to room temperature,
the silica coated magnetite nanoparticles was separated from the
reaction mixture using a permanent magnet and washed several
times with distilled water and methanol. The obtained SCMNPs
(2 g) were suspended in ethanol (100 ml) and then aminoropro-
pyltrimethoxysilane (2 ml) was added under dry nitrogen
3. Results and discussion
3.1. Preparation of MoO2–thio-SCMNPs nanomaterial
The sequence of reactions in the functionalization of magnetite
nanoparticles (MNPs) with molybdenum thiosemicarbazide derived
Schiff base complex has been shown in Fig. 1. First, the external
surface of MNPs was coated with a silica shell to obtain silica
coated magnetite nanoparticles (SCMNPs). Then, treatment of
