Communication
Design, synthesis and biological evaluation of a novel platinum(II) complex
possessing bioreductive groups for cancer therapy
Chengken Chena,b, Chunmei Gaoc, Zigao Yuanb,e,*, Yuyang Jiangb,d,e,**
a Department of Chemistry, Tsinghua University, Beijing 100084, China
bThe Ministry-Province Jointly Constructed Base for State Key Lab-Shenzhen Key Laboratory of Chemical Biology, The Graduate School at Shenzhen,
Tsinghua University, Shenzhen 518055, China
cCollege of Chemistry and Chemical Engineering, Shenzhen University, Shenzhen 518060, China
dDepartment of Pharmacology and Pharmaceutical Sciences, School of Medicine, Tsinghua University, Beijing 100084, China
eShenzhen Kivita Innovative Drug Discovery Institute, Shenzhen 518055, China
 Corresponding authors at Shenzhen Kivita Innovative Drug Discovery Institute, Shenzhen 518055, China.

Corresponding authors at the Ministry-Province Jointly Constructed Base for State Key Lab-Shenzhen Key Laboratory of Chemical Biology, The Graduate
School at Shenzhen, Tsinghua University, Shenzhen 518055, China.
E-mail addresses: yzg12@tsinghua.org.cn (Z. Yuan), jiangyy@sz.tsinghua.edu.cn (Y. Jiang).
Graphical abstract
A Pt(II) complex possessing bioreductive groups was constructed and evaluated as a more potent antitumor agent than cisplatin.
ARTICLE INFO
ABSTRACT
Cisplatin is one of the most successful antitumor agents, yet also restricted by its poor cellular
uptake and low selectivity. Since 3-(2-nitrophenyl) propionic acid (NPPA) has been reported
as a bioreductive prodrug moiety, herein we combined NPPA with cisplatin (compound 1) to
improve its lipophilicity and targetability and then to improve the antitumor outcomes. In
addition, compound 2 possessing 3-phenyl propionic acid (PPA) was also synthesized as a
comparison to test the influence of the NPPA to the cytotoxicity, since PPA was not a
bioreductive moiety. Bioevaluations showed that 1 displayed more potent antitumor potency
than cisplatin and 2, suggesting Pt(II) complexes possessing NPPA groups may be a good
strategy for future platinum drug discovery.
Article history:
Received
Received in revised form
Accepted
Available online
Keywords:
Platinum compounds
Bioreductive
Nitrophenylalkanoic group
Cellular uptake
Antitumor
Platinum-based drugs, such as cisplatin, carboplatin and oxaliplatin, are used worldwide in clinical cancer therapy (Fig. 1A) [1,2].
As one of the most successful anticancer drugs, cisplatin can be taken up by cells and bond with DNA to form DNA adducts, causing
DNA damage and resulting in cell death, so it is used to fight against a wide spectrum of solid neoplasms like ovarian, testicular,
bladder, colorectal, lung, and head and neck cancers [3]. However, due to the high activity of chloride ions, platinum(II) complexes are
instable and easily combined with nucleophiles such as glutathione, metallothioneins and other sulfur-containing amino acids, leading
to drug resistance [4-6]. Moreover, cisplatin has low lipophilicity, which leads to its low uptake. In addition, cisplatin can cause serious
adverse effects including dose-limiting nephrotoxicity, ototoxicity, as well as nausea and vomiting. Although some strategies have
been explored to develop novel platinum drugs (e.g., polynuclear Pt(II) complexes, Pt(IV) prodrugs) with reduced toxicities and
improved stability [7-11], it is still necessary to develop new approaches for platinum drugs.

Due to the rapid growth of cancer cells and the abnormal angiogenesis within them, solid tumors usually cause a hypoxic
microenvironment, which could be practically targeted by bioreductive prodrugs [12-15]. Up to now, several types of bioreductive
prodrugs have been developed, including nitro groups, quinones, N-oxides and transition metals (Fig. 1B) [16-19]. Nitrophenylalkanoic
acid has been recognized as a good bioreductive prodrug moiety [20], its derivatives are nontoxic or weakly toxic in normal tissues, but
decompose under convertible reduction and release antitumor agents [21,22]. Complexes containing nitrophenylalkanoic groups show
high selectivity to hypoxic cells [23,24]. For example, bioreductive paclitaxel prodrug (NPPA-PTX), which is stable in PBS and rat
plasma as well as in the blood circulation, can be completely converted to the active PTX in hypoxic tumor tissues and then exhibits its
antitumor activity [25]. Furthermore, researches have proposed that the activation process tends to be triggered in an acidic
environment, which suggests that it is more likely to be reduced at a low pH in tumor tissues [26].
Considering the aforementioned information, and in continuation of our interest in the development of new anticancer compounds
[27-31], herein we intend to combine nitrophenylalkanoic acid and cisplatin to develop novel bioreductive Pt(II) drug and compound 1
containing 3-(2-nitrophenyl) propionic acid (NPPA) was constructed. Besides, to assess the advantage of bioreductive reactivation for
antitumor potency, compound 2 containing 3-phenyl propionic acid (PPA) was also synthesized as a control (Fig. 2A). We proposed
that the nitrophenylalkanoic ester group in compound 1 would be helpful to improve lipophilicity and hypoxia-targeting ability,
thereby enhancing the cellular uptake and improving antitumor potency compared to that of cisplatin.
Fig. 1. (A) Chemical structures of the clinically used platinum drugs. (B) Chemical structures of bioreductive prodrugs.
Fig. 2. (A) Chemical structures of target compounds 1 and 2. (B) Synthesis route of compounds 1 and 2.

Fig. 3. 1H NMR of complexes NPPA and its product 1.
The synthesis of target compounds 1 and 2 was shown in Fig. 2B. Firstly, 3-(2-nitrophenyl) propionic acid (NPPA) was synthesized
according to the reported method [32]. Secondly, 1 and 2 were synthesized via the combination of cis-[Pt(NH3)2(H2O)2]2+ with NPPA
sodium or PPA sodium. NMR spectroscopy has been applied to characterize the structures of Pt(II) complexes 1 and 2. As shown in
Fig. 3, it is obvious that the chemical shifts of H1 and H2 on NPPA are 3.04 and 2.60 ppm respectively, but they are 2.99 and 2.35 ppm
in complex 1, respectively, which indicated that NPPA has been added to the Pt(II) anion [33]. Also, the appearance of NH3 signal and
the disappearance of OH signal on NPPA further confirmed the structure of complex 1. HPLC was used to measure the purity of
complexes 1 and 2 (Figs. S7 and S11 in Supporting information). All the electrospray ionization mass (ESI-MS) spectra of the
complexes (Figs. S6 and S10 in Supporting information) gave main peaks corresponding to [M+Na]+ or [M-H]− ions, which composed
of a few isotopic peaks owing to the presence of platinum isotopes, suggesting the successful synthesis of 1 and 2.
Fig. 4. Possible activation mechanism of compound 1 before and after it enters the cells.
ESI-MS is a highly sensitive method to investigate the binding ability of compounds and DNA. As we know, the preferred DNA
binding site of cisplatin is the N7 position of guanine bases [34,35]. To investigate whether 1 could display the similar DNA binding
activity as cisplatin, the binding of 1 to 2'-deoxyguanosine (2'-dG) as a DNA analogue was analyzed by ESI-MS, with cisplatin as a
positive control. In the presence of nitroreductase (NTR) and NADPH only Pt/2'-dG-bisadduct could be found after 24 h (Fig. S12 in
Supporting information). In comparison, both Pt/2'-dG-bisadduct and Pt/2'-dG-monoadduct were observed in 2'-deoxyguanosine with
cisplatin or 1 after 2 days (Figs. S13 and S14 in Supporting information), which indicated the ability of cisplatin and 1 binding to DNA
and supported that guanine bases were the target position of cisplatin and 1, and also suggest that NTR can accelerate the
decomposition of 1 and improve the binding ability with DNA.
The proposed activation mechanism of compound 1 in cells was shown in Fig. 4. Compound 1 can be taken up by cells via active
transport and passive permeability [36,37], then the nitro groups of 1 are reduced by reductase such as NTR and gradually generate
hydroxylamine or amino derivatives [25,38,39]. The nitrogen atom of hydroxylamine or amino derivative can attack its carbonyl
group, ultimately releasing cis-[Pt(NH3)2(H2O)2]2+ through intramolecular cyclization. To investigate whether the reductive products
o
were generated, we dissolved compound 1 in water and then treated it with NTR and NADPH at 37 C for 24 h. The resulting mass

spectrum from LC-MS (Figs. S15 and S16 in Supporting information) showed the appearance of reductive products (3,4-dihydro-
2(1H)-quinolinone and its hydroxylamine derivative). Notably, we also found the signal of cis-[Pt(NH3)2(H2O)2]2+, indicating the
successful activation of compound 1 by NTR.
Table 1
Cytotoxicity of compound 1 and 2 against several cancer cell lines.
Complex
IC50 (μmol/L)a
HepG2
RFc
Hcc827
A549
A549/CDDP
67.02 ± 1.71
30.22 ± 1.22
42.39 ± 2.87
NDb
Cisplatin
1
2
48.54 ± 2.27
7.56 ± 0.58
16.88 ± 0.84
>100
28.10 ± 0.87
9.15 ± 0.19
25.53 ± 0.84
NDb
23.11 ± 0.67
33.26 ± 0.65
31.91 ± 0.95
>200
2.90
0.91
1.33
NDb
NPPA
a Compound concentration required to inhibit cell proliferation by 50%.
b Undetectable.
c The ratio between IC50 values calculated for the resistant cells and those obtained with the sensitive ones.
Fig. 5. Platinum contents of cisplatin, 1 and 2 in cancer cells after 6 h and 12 h.
The cytotoxicity of compounds 1 and 2 against several cancer cells was evaluated by the MTT method with cisplatin and NPPA as
controls. The IC50 values (the concentration of compounds which causes death in 50% of cells) were shown in Table 1. After 72 h
incubation, NPPA displayed hardly cytotoxicity against all tested cells, while 1 and 2 showed better or similar cytotoxicity against all
tested cancer cells compared to cisplatin. In particular, 1 was about 6.4 and 3.1 times more effective than cisplatin against HepG2 and
HCC827 cells, respectively. Although 1 and 2 had higher IC50 values compared to that of cisplatin against A549 cells, they showed
better cytotoxicity against A549/DDP cells than cisplatin with RF values of 0.91 and 1.33 compared to 2.90, respectively. As a whole,
the cytotoxicity of 1 is more potent than 2, which indicated that the bioreductive activity may contribute much to the cytotoxicity, as 2
can only be hydrolyzed but not bioreducible. Compound 2 displayed better anti-proliferative activity than cisplatin, which might
attribute to the improved lipophilicity compared to cisplatin by introducing phenylpropionic acid group. All these results indicated the
success of our design.
In order to certify that our compounds had improved lipophilicity compared with cisplatin, the Pt contents of cisplatin, 1 and 2 in all
tested cells were analyzed using ICP-MS after 6 h or 12 h of incubation. As shown in Fig. 5 and Table S1 (Supporting information), the
Pt contents of 1 had a high value (51.42 ng/106 cells) in HCC827 cells after 6 h, and had a great increase after 12 h. In comparison,
cisplatin showed a lower value in HCC827 cells after 6 h, and reach the value of over 50 ng/106 cells after 12 h. Also, the Pt content of
1 in HepG2 cells is 3.0 times higher than that of cisplatin after 6 h, and can keep in a high level after 12 h. It meant 1 can be quickly
taken up by HCC827 and HepG2 cells than cisplatin. In addition, the platinum contents of all three complexes in A549 and
A549/CDDP were kept in a low value, which indicated a low availability against these two cells.
Fig. 6. Representative flow cytometric diagrams of apoptotic HepG2 cells after 72 h treatment with cisplatin and 1.

In order to evaluate whether compound 1 could induce apoptosis like cisplatin does, we then conducted an Annexin-V/PI binding
assay. HepG2 cells were treated with 1 for 72 h at different concentrations, with cisplatin as a positive control. As shown in Fig. 6, a
few (5.07 %) apoptotic cells were present in the negative control group (DMSO). The apoptosis population rose to 37.0 %, 77.9 % and
81.6 % after treatment with 1 at 1 μmol/L, 5 μmol/L and 10 μmol/L, respectively. However, cisplatin only induced 23.1 %, 36.0 % and
63.2 % apoptosis populations at 1 μmol/L, 5 μmol/L and 10 μmol/L, respectively. It meant 1 is a more potent proapoptotic agent than
cisplatin.
In this study, we proposed a novel strategy by introducing the bioreductive group NPPA into Pt(II) compounds, and then designed
and synthesized two target compounds. Compound 1 showed better cytotoxicity, higher cellular uptake and more potent proapoptotic
potency in HepG2 cells than that of cisplatin and 2, indicating that Pt(II) complexes containing bioreductive groups can be an
alternative strategy for novel platinum drug development, and compound 1 represents a good lead compound for further antitumor drug
discovery.
Acknowledgment
The authors would like to thank Shenzhen Sci & Tech Bureau (No. JCYJ20160301153959476 and JCYJ20160324163734374).
References
[1] D. M. Cheff and M. D. Hall, J. Med. Chem. 60 (2017) 4517-4532.
[2] M. Galanski, Recent Pat. Anti-Canc. 1 (2006) 285-295.
[3] D. Xu, Z. Xi, L. Zhao, et al., Inorg. Chem. Front 1 (2014) 149-152.
[4] S. Dilruba and G. V. Kalayda, Cancer Chemoth. Pharm. 77 (2016) 1103-1124.
[5] T. C. Johnstone, K. Suntharalingam and S. J. Lippard, Chem. Rev. 116 (2016) 3436-3486.
[6] N. Graf and S. J. Lippard, Adv. Drug Del. Rev. 64 (2012) 993-1004.
[7] X. Han, J. Sun, Y. Wang, et al., Med. Res. Rev. 35 (2015) 1268-1299.
[8] D. S. Bolotin, M. Y. Demakova, A. Legin, et al., New J. Chem. 41 (2017) 6840-6848.
[9] Z. Chen, S. Zhang, J. Zhang, et al., New J. Chem. 41 (2017) 6760-6768.
[10] Z. Chen, S. Zhang, Z. Zhu, et al., New J. Chem. 41 (2017) 6340-6348.
[11] X.Q. Quan, L. Kang, X.Z. Yin, et al., Chin. Chem. Lett. 26 (2015) 695-699.
[12] W. A. Denny, Expert Opin. Ther. Pat. 15 (2005) 635-646.
[13] C. P. Guise, A. M. Mowday, A. Ashoorzadeh, et al., Chin. J. Cancer 33 (2014) 80-86.
[14] W. R. Wilson and M. P. Hay, Nat. Rev. Cancer 11 (2011) 393-410.
[15] J. L. Bryant, S. L. Meredith, K. J. Williams, et al., Lung Cancer 86 (2014) 126-132.
[16] M. R. Albertella, P. M. Loadman, P. H. Jones, et al., Clin. Cancer. Res. 14 (2008) 1096-1104.
[17] Y. G. J. M. Mark, W. R. William, H. Andrew, A. Karen, J. M. Teresa, J. B. Michael, BMC Cancer 11 (2011) 1-12.
[18] W. A. Denny, Eur. J. Med. Chem. 36 (2001) 577-595.
[19] D. C. Ware, B. D. Palmer, W. R. Wilson, et al., J. Med. Chem. 36 (1993) 1839-1846.
[20] Y. Chen and L. Hu, Med. Res. Rev. 29 (2009) 29-64.
[21] L. Hu, X. Wu, J. Han, et al., Bioorg. Med. Chem. Lett. 21 (2011) 3986-3991.
[22] B. Liu and L. Hu, Biorg. Med. Chem. 11 (2003) 3889-3899.
[23] K. Shyam, P. G. Penketh, M. Shapiro, et al., J. Med. Chem. 42 (1999) 941-946.
[24] K. Shyam, P. G. Penketh, R. H. Loomis, et al., Eur. J. Med. Chem. 33 (1998) 609-615.
[25] P. Song, X. Yao, T. Zhong, et al., Oncotarget 7 (2016) 48467-48480.
[26] Y. Jiang and L. Hu, Bioorg. Med. Chem. Lett. 18 (2008) 4059-4063.
[27] Z. Yuan, S. Chen, C. Chen, et al., Eur. J. Med. Chem. 138 (2017) 1135-1146.
[28] W. Li, Q. Sun, L. Song, et al., Eur. J. Med. Chem. 141 (2017) 721-733.
[29] C. Ding, D. Li, Y.W. Wang, et al., Chin. Chem. Lett. (2017) 1220-1227.
[30] C. Ding, S. Chen, C. Zhang, et al., Biorg. Med. Chem. 25 (2016) 27-37.
[31] B. Chu, F. Liu, L. Li, et al., Cell Death & Disease 6 (2015) e1686.
[32] S. Trofymchuk, A. Bezdudny, Y. Pustovit, et al., J. Fluorine Chem. 171 (2015) 174-176.
[33] H. Baruah, C. S. Day, M. W. W. And, et al., J. Am. Chem. Soc. 126 (2004) 4492-4493.
[34] C. F. Chin, Q. Tian, M. I. Setyawati, et al., J. Med. Chem. 55 (2012) 7571-7582.
[35] R. K. Pathak, S. Marrache, J. H. Choi, et al., Angew. Chem. 53 (2014) 1963-1967.
[36] M. D. Hall, M. Okabe, D. W. Shen, et al., Annu. Rev. Pharmacol. Toxicol. 48 (2008) 495-535.
[37] T. C. Johnstone, J. J. Wilson and S. J. Lippard, Inorg. Chem. 52 (2013) 12234-12249.
[38] L. J. O'Connor, C. Cazareskörner, J. Saha, et al., Nat. Protoc. 11 (2016) 781-794.
[39] C. Cazareskörner, I. M. Pires, I. D. Swallow, et al., ACS Chem. Biol. 8 (2013) 1451-1459.
