First preparation of enantiomerically pure sibutramine and its major metabolite, and determination of their absolute configuration by single crystal X-ray analysis

Article abstract of DOI:10.1016/S0957-4166(99)00511-X

Racemic sibutramine was resolved with dibenzoyl-D-tartaric acid, and the absolute stereochemistry of sibutramine was determined by single crystal X- ray crystallography of its dibenzoyl D-tartrate. The major active metabolite (desmethylsibutramine) was ob

Full text of DOI:10.1016/S0957-4166(99)00511-X

TETRAHEDRON:
ASYMMETRY
Pergamon
Tetrahedron: Asymmetry 10 (1999) 4477–4480
First preparation of enantiomerically pure sibutramine and its
major metabolite, and determination of their absolute
configuration by single crystal X-ray analysis
Qun K. Fang,a,∗ Chris H. Senanayake,a,∗ Zhengxu Han,a Cynthia Morency,a Paul Grover,a
Robert E. Malone,a Hal Bulter,a Stephen A. Wald a and T. Stanley Cameron b
aChemical Process Research and Development Sepracor Inc., 111 Locke Drive, Marlborough, MA 01752, USA
bDepartment of Chemistry, Dalhousie University, Halifax, NS, B3H 4J3, Canada
Received 25 October 1999; accepted 1 November 1999
Abstract
Racemic sibutramine was resolved with dibenzoyl-D-tartaric acid, and the absolute stereochemistry of sibu-
tramine was determined by single crystal X-ray crystallography of its dibenzoyl D-tartrate. The major active
metabolite (desmethylsibutramine) was obtained by demethylation of sibutramine with DEAD. Enantiomeric
purity of sibutramine was determined by HPLC on an Ultron ES-OVM column. © 1999 Elsevier Science Ltd.
All rights reserved.
Racemic sibutramine 1 (Fig. 1) is a new class of compounds for the treatment of obesity. It is a
serotonin and noradrenaline re-uptake inhibitor1 and is sold as the racemate form under the brand name
Meridia® (HCl monohydrate salt). Sibutramine has one stereogenic center, resulting in the existence of
two enantiomers. It is well documented that enantiomers often have different biological activities and
metabolic profiles (pharmacokinetics). To date, however, there has been no report in the literature for the
preparation of sibutramine (or desmethylsibutramine 2) enantiomers by any one of the following general
methods: (a) asymmetric synthesis; (b) resolution of the racemate with a chiral acid; (c) chiral column
HPLC separation. In order to explore the biological and pharmacological activities of the enantiomers
of sibutramine and its active metabolite, multigram quantities of these enantiomers are needed.2 Here,
we report the first efficient method for the preparation of both enantiomers of 1 and 2 by chiral acid
resolution.
Racemic sibutramine was readily prepared by following the literature procedures.3 Cycloalkyl-
ation of commercially available 4-chlorophenylacetonitrile with 1,3-dibromopropane yielded the 4-
chlorophenylcyclobutylnitrile, which was treated with isobutylmagnesium bromide in toluene, followed
by reduction with sodium borohydride to give the primary amine in 75% yield. The amine was then
∗
Corresponding authors. E-mail: kfang@sepracor.com
0957-4166/99/$ - see front matter © 1999 Elsevier Science Ltd. All rights reserved.
PII: S0957-4166(99)00511-X
tetasy 3146

4478
Q. K. Fang et al. / Tetrahedron: Asymmetry 10 (1999) 4477–4480
Fig. 1.
converted to sibutramine by Eschweiler–Clarke methylation. After a chiral analytical separation of sibu-
tramine was achieved by HPLC with a chiral stationary phase column (ES-OVM),4 screening of common
resolving agents (e.g. tartaric acid, ditoluyl tartaric acid, dibenzoyl tartaric acid, and mandelic acid) in
various solvents (methanol, ethyl acetate, toluene, and isopropyl alcohol) was conducted. Dibenzoyl
tartaric acid in ethyl acetate was found to be an excellent choice to resolve racemic sibutramine, as
outlined in Scheme 1.
Scheme 1.
Racemic sibutramine was treated with one equivalent of dibenzoyl-D-tartaric acid in ethyl acetate
at 60°C for 30 min to give a crystalline solid. The solid was enriched (+)-sibutramine dibenzoyl-D-
tartaric salt with 70 to 93% ee. Further crystallization in isopropyl alcohol yielded the diastereomeric
salt with >99.5% ee in 40% overall yield ([α]D=+71.2, c 0.9, MeOH). Sibutramine HCl salt ([α]D=+3.3,
c 1.5, H2O) was prepared from the diastereomerically pure dibenzoyl tartrate by treatment with sodium
hydroxide, followed by the addition of HCl/Et2O. The (−)-isomer of sibutramine was isolated from
the enriched mother liquor, and further enriched with dibenzoyl-L-tartaric acid to give (−)-sibutramine
dibenzoyl-L-tartrate.
By slow crystallization of (+)-sibutramine dibenzyl-D-tartrate (ee >99.5%) from ethanol, crystals
suitable for X-ray structural analysis were obtained. The structure of the dibenzoyl-D-tartrate salt was
found to have the R configuration corresponding to (+)-sibutramine dibenzoyl-D-tartrate (Fig. 2).
Since multigram enantiomerically pure sibutramine is available by this efficient resolution method,
it would be convenient to obtain the enantiomers of its active metabolite 2 by demethylation provided
no racemization occurs during the process. It was found that commonly used demethylation reagents
(e.g. alkyl chloroformates) failed to yield any desmethylsibutramine, but gave a complex mixture of
elimination and rearrangement products. However, we were delighted to discover that when sibutramine
was treated with DEAD5 (1.2 equiv.) in toluene at 50°C for 10 h, followed by treatment of hydrochloric
acid in ethanol under reflux, desmethylsibutramine was isolated in a 70% yield as shown in Scheme 2.

Q. K. Fang et al. / Tetrahedron: Asymmetry 10 (1999) 4477–4480
4479
Fig. 2. X-Ray structure of the salt (dibenzoyl-D-tartaric acid was omitted in the figure)
Scheme 2.
Demethylation of sibutramine with DEAD was proven to proceed with retention of stereochemistry,
and no racemization was observed. When (+)-desmethylsibutramine hydrochloride ([α]D=+5, c 0.5,
H2O), prepared from (R)-(+)-sibutramine (99% ee) with DEAD was alkylated under Eschweiler–Clarke
methylation conditions, the product (sibutramine) had R configuration (99% ee).
In summary, an efficient resolution method for the preparation of both enantiomers of enantiomerically
pure sibutramine was developed. Desmethylsibutramine was conveniently prepared in multigram quan-
tity by demethylation of sibutramine with DEAD, with complete retention of the configuration. Based on
single crystal X-ray structural analysis, the (+)-isomer of sibutramine HCl salt has the R configuration,
as well as (+)-desmethylsibutramine HCl salt established by demethylation. Current efforts focus on the
asymmetric synthesis of sibutramine and its derivatives.
Acknowledgements
We are grateful to Dr. Alex Jurgens from Sepracor Canada Limited for his involvement in this work,
and to Ms. Susan Gillis for her contribution in the preparation of this manuscript.
References
1. Buckett, W. R.; Thomas, P. C.; Luscomb, G. P. Prog. Neuropsychopharmacol. Biol. Psychiatry 1988, 12, 575.
2. Young, J. W. PCT WO940047 and WO9400114.

4480
Q. K. Fang et al. / Tetrahedron: Asymmetry 10 (1999) 4477–4480
3. (a) Jeffery, J. E.; Kerrigan, F.; Miller, T. K.; Smith, G. J.; Tometzki, G. B. J. Chem. Soc., Perkin Trans. 1 1996, 2583. (b)
Butler, D. E.; Pollate, J. J. Org. Chem. 1971, 36, 1308.
4. Ultron ES-OVM column, 5 µm, 15 cm×4.6 mm. Mobile phase: 0.01 M NaH2PO4 (pH 7)/MeCN=7:3. Retention time: R-
isomer 4.6 min, S-isomer 5.4 min.
5. Smissman, E. E.; Makriyannis, A. J. Org. Chem. 1973, 38, 1652.
