M.A. Carroll et al. / Journal of Fluorine Chemistry 128 (2007) 127–132
131
solvent was removed in vacuo to give the crude product.
Crystallisation gave 5 as a white crystalline solid (2.17 g,
4.63 mmol, 93%); mp 144–146 8C (from dichloromethane–
hexane); Anal. Calcd. for C17H16IO4F3: C, 43.6; H, 3.4. Found
C, 43.6; H, 3.5. IR (KBr): n 3082, 2839, 1656, 1564, 1440,
1286, 1174; dH (270 MHz; d6-Me2SO) 8.28 (1H, d, H60 J 8 Hz),
8.17 (1H, d, H6 J 9 Hz), 7.62 (1H, t, H40 J 8 Hz), 7.27 (1H, d,
H30 J 8 Hz), 7.07 (2H, m, H3/H50), 6.83 (1H, dd, H5 J 3, 9 Hz),
3.93 (3H, s, 20-OMe), 3.77 (3H, s, 4-OMe), 2.60 (3H, s, 2-CH3);
dC (68 MHz; d6-Me2SO) 162.7, 156.8, 143.4, 139.4 (C6), 137.6
(C60), 135.0 (C40), 123.8 (C50), 117.2 (C3), 115.2 (C5), 113.4
(C30), 110.7, 107.4, 57.4 (20-OMe), 56.1 (4-OMe), 25.4 (Me);
m/z (FAB) 356(M + H+, 16%), 355(M+, 100). [Found: M+,
355.0192. C15H16IO2 requires 355.0195].
0.05 mmol) in DMF (2.5 mL) were added to a carousel tube
[43] (predried at 140 8C, evacuated and flushed with nitrogen).
The carousel tube was then placed on a carousel reactor
preheated to 90 8C and heated for the required time. At the time
intervals stated in Table 5 aliquots (0.3 mL) were taken, cooled
to room temperature rapidly, diluted with DMF (0.4 mL) and
analysed by 19F NMR. The yield was calculated using 3-
trifluoromethylanisole as an internal standard.
Acknowledgement
We thank GE-Healthcare for funding and the EPSRC for
provision of the Swansea Mass Spectrometry Service.
References
4.3. Fluoridation procedure: Tables 1 and 7
[1] P.J. Stang, V.V. Zhdankin, Chem. Rev. 96 (1996) 1123–1178.
[2] A. Varvoglis, Hypervalent Iodine in Organic Synthesis, Academic Press,
London, 1997.
Iodonium salt 5 (0.022 g, 0.05 mmol) in the appropriate
solvent(1 mL), caesium fluoride (0.015 g, 0.1 mmol)inthesame
solvent (1.5 mL) and finally TEMPO (10 mol%) as a solution in
MeCN (0.1 mL) if required (Table 7) were added to a carousel
tube [43] (predried at 140 8C, evacuated and flushed with
nitrogen). The carousel tube was then placed on a carousel
reactor preheated to 90 8C and heated under nitrogen for 1.5 h.
Afterthistimethetubeswereremovedfromthe reactor, cooledto
room temperature rapidly and analysed by 19F NMR. The yield
was calculated using benzotrifluoride as an internal standard.
[3] A. Varvoglis, S. Spyroudis, Synlett (1998) 221–232.
[4] T. Wirth, U.H. Hirt, Synthesis (1999) 1271–1287.
[5] T. Wirth, Top. Curr. Chem. 224 (2003).
[6] M. van der Puy, J. Fluorine Chem. 21 (1982) 385–392.
´
´
[7] S. Martın-Santamarıa, M.A. Carroll, C.M. Carroll, C.D. Carter, V.W. Pike,
H.S. Rzepa, D.A. Widdowson, Chem. Commun. (2000) 649–650.
[8] M.A. Carroll, L.M. Kamara, D.A. Widdowson, V.W. Pike, J. Labelled
Compd. Radiopharm. 48 (2005) 519–520.
[9] M. Guillaume, A. Luxen, B. Nebeling, M. Argentini, J.C. Clark, V.W.
Pike, Appl. Radiat. Isot. 42 (1991) 749–762.
[10] A. Shah, D.A. Widdowson, V.W. Pike, J. Labelled Compd. Radiopharm.
39 (1997) 65–67.
4.4. Fluoridation procedure: Tables 2, 3 and 6
[11] A. Shah, V.W. Pike, D.A. Widdowson, J. Chem. Soc., Perkin Trans. 1
(1998) 2043–2045.
The fluoride source (0.1 mmol), radical scavenger solution
(appropriate mol% in MeCN, 0.1 mL) and iodonium salt 5
(0.022 g, 0.05 mmol) in DMF (2.5 mL) were added to a carousel
tube [43] (predried at 140 8C, evacuated and flushed with
nitrogen). The carousel tube was then placed on a carousel
reactor preheated to 90 8C and heated for 1.5 h. After this time
the tubes were removed from the reactor, cooled to room
temperature rapidly and analysed by 19F NMR. The yield was
calculated using 3-trifluoromethylanisole as an internal standard.
[12] F.R. Wu¨st, T. Kniess, J. Labelled Compd. Radiopharm. 46 (2003) 699–
713.
[13] F.R. Wu¨st, A. Hohne, P. Metz, Org. Biomol. Chem. 3 (2005) 503–507.
[14] F. Wu¨st, J.M.H.M. Reul, T. Rein, A. Abel, G. Sto¨cklin, J. Labelled Compd.
Radiopharm. 44 (2001) S12–S14.
[15] V.W. Pike, F.I. Aigbirhio, J. Chem. Soc., Chem. Commun. (1995) 2215–
2216.
[16] J. Ermert, C. Hocke, T. Ludwig, R. Gail, H.H. Coenen, J. Labelled Compd.
Radiopharm. 47 (2004) 429–441.
[17] S. Freeman, J.F. Alder, Eur. J. Med. Chem. 37 (2002) 527–539.
[18] A. Luxen, M. Guillaume, W.P. Melega, V.W. Pike, O. Solin, R. Wagner,
Nucl. Med. Biol. 19 (1992) 149–158.
4.5. Fluoridation procedure: Table 4
[19] E.S. Garnett, G. Firnau, C. Nahmias, Nature 305 (1983) 137–138.
[20] H.F. VanBrocklin, M. Blagoev, A. Hoepping, J.P. O’Neil, M. Klose, P.A.
Schubiger, S. Ametamey, Appl. Radiat. Isot. 61 (2004) 1289–1294.
Caesium fluoride (0.015 g, 0.1 mmol), TEMPO (10 mol%)
as a solution in MeCN (0.1 mL) and iodonium salt 5 (0.022 g,
0.05 mmol) in DMF (2.5 mL) were added to a carousel tube
[43] (predried at 140 8C, evacuated and flushed with nitrogen).
The carousel tube was then placed on a carousel reactor
preheated to the relevant temperature and heated for 1.5 h.
After this time the tubes were removed from the reactor, cooled
to room temperature rapidly and analysed by 19F NMR. The
yield was calculated using 3-trifluoromethylanisole as an
internal standard.
´
´
[21] M.A. Carroll, S. Martın-Santamarıa, V.W. Pike, H.S. Rzepa, D.A. Wid-
dowson, J. Chem. Soc., Perkin Trans. 2 (1999) 2707–2714.
[22] V.V. Grushin, Acc. Chem. Res. 25 (1992) 529–536.
[23] V.V. Grushin, I.I. Demkina, T.P. Tolstaya, J. Chem. Soc., Perkin Trans. 2
(1992) 505–511.
[24] M.A. Carroll, unpublished results.
[25] A. McKillop, D. Kemp, Tetrahedron Lett. 45 (1989) 3299–3306.
[26] M.A. Carroll, V.W. Pike, D.A. Widdowson, Tetrahedron Lett. 41 (2000)
5393–5396.
[27] M.-L. Hu, Y.-K. Chen, L.-C. Chen, M. Sano, Nutr. Biochem. 6 (1995)
504–508.
[28] G.M. Williams, M.J. Iatropoulos, J. Whysner, Food Chem. Tox. 37 (1999)
1027–1038.
4.6. Fluoridation procedure: Table 5
[29] E. Mendis, N. Rajapakse, S.-E. Kim, J. Agric. Food Chem. 53 (2005) 581–
587.
Caesium fluoride (0.015 g, 0.1 mmol), TEMPO (10 mol%)
as a solution in MeCN (0.1 mL) and iodonium salt 5 (0.022 g,
[30] D.J. McPhee, M. Campredon, M. Lesage, D. Griller, J. Am. Chem. Soc.
111 (1989) 7563–7567.
