Copper(I) iodide-catalyzed synthesis of 1-benzothiophen-2-amines from 4-(2-bromophenyl)-1,2,3-thiadiazole

Full text of DOI:10.1134/S1070428015070283

ISSN 1070-4280, Russian Journal of Organic Chemistry, 2015, Vol. 51, No. 7, pp. 1040–1042. © Pleiades Publishing, Ltd., 2015.
Original Russian Text © M.L. Petrov, E.A. Popova, D.A. Androsov, 2015, published in Zhurnal Organicheskoi Khimii, 2015, Vol. 51, No. 7, pp. 1057–1059.
SHORT
COMMUNICATIONS
Copper(I) Iodide-Catalyzed Synthesis of 1-Benzothiophen-
2-amines from 4-(2-Bromophenyl)-1,2,3-thiadiazole
M. L. Petrov, E. A. Popova, and D. A. Androsov
St. Petersburg State Institute of Technology, Moskovskii pr. 26, St. Petersburg, 190013 Russia
e-mail: mLpetrov@lti-gti.ru
Received April 15, 2015
DOI: 10.1134/S1070428015070283
2-Dimethylamino-1-benzothiophen-6-ol is the key
intermediate product in the synthesis of the known
selective estrogen receptor modulator Raloxifene and
its analogs [1, 2]. However, procedures for the synthe-
sis of 2-amino-1-benzothiophenes have been poorly
explored. Nowadays, three methods for the preparation
of 2-amino-1-benzothiophene are known: (1) five-step
synthesis from thiosalicylic acid [3], (2) from 1-benzo-
thiophen-2-ylmagnesium chloride [4], and (3) reaction
of (2-bromophenyl)acetonitrile with Na2S2O3 in the
presence of palladium catalyst [5]. 2-(Morpholin-4-yl)-
1-benzothiophene was synthesized by addition of mor-
pholine to the C2–C3 bond of 1-benzothiophene with
subsequent aromatization by the action of sulfur [6].
2-(Piperidin-1-yl)-1-benzothiophene was prepared by
heating a mixture of 2-bromo-1-benzothiophene with
piperidine in a sealed ampule [7]. 6-Benzyloxy-N,N-di-
methyl-1-benzothiophen-2-amine was obtained in two
steps by treatment of a mixture of 4-benzyloxybenzal-
dehyde and N,N-dimethylthioformamide with lithium
diisopropylamide, followed by cycloaromatization
with methanesulfonic acid [8].
5-unsubstituted 4-(2-halophenyl)-1,2,3-thiadiazoles
with a base generates very unstable acetylenic thiolate
which react with nucleophiles like HNR2. The subse-
quent 5-exo-trig-cyclization of intermediate enethio-
lates should produce 2-amino-1-benzothiophenes.
We previously showed that 4-(2-chlorophenyl)- and
4-(2-bromophenyl)-1,2,3-thiadiazoles in the presence
of potassium carbonate and excess morpholine in
dimethylformamide lose nitrogen molecule to give
potassium 2-(2-halophenyl)ethynethiolates. Further
reaction with morpholine afforded the corresponding
potassium 2-(2-halophenyl)-1-(morpholin-4-yl)ethene-
thiolates which did not undergo intramolecular cycliza-
tion regardless of the halogen nature. The subsequent
acidification led to the formation of 2-(2-halophenyl)-
thioacetic acid morpholides. However, introduction of
a nitro group into the para position with respect to the
chlorine atom in 4-(2-chlorophenyl)-1,2,3-thiadiazole
resulted in successful synthesis of 2-dialkylamino-1-
benzothiophenes [10].
Herein we describe a new method for the prepara-
tion of 2-amino-1-benzothiophenes from 4-(2-bromo-
phenyl)-1,2,3-thiadiazole (1) [10] and secondary
amines (morpholine and piperidine) in the presence of
potassium carbonate and a catalytic amount of copper
We have recently proposed a new procedure for
the preparation of 2-amino-1-benzothiophenes from
4-(2-halophenyl)-1,2,3-thiadiazoles [9]. Treatment of
Scheme 1.
NR2
H+
HNR2
S– K+
S
HNR2, K2CO3
DMF, Δ
NR2
S– K+
Br
4a
N
–N2
N
Br
CuI
Br
S
Br
NR2
1
2
3a, 3b
S
5a, 5b
R2N = morpholin-4-yl (a), piperidin-1-yl (b).
1040

COPPER(I) IODIDE-CATALYZED SYNTHESIS OF 1-BENZOTHIOPHEN-2-AMINES
1041
Scheme 2.
O
O
K2CO3, CuI
DMF, Δ
N
N
N
O
–N2
S
S
S– K+
Br
Br
4a
3a
5a
(I) iodide. The amount of the latter was 20 mol % with
respect to thiadiazole 1. Decomposition of 4-(2-bromo-
phenyl)-1,2,3-thiadiazole (1) by the action of potas-
sium carbonate and excess secondary amine in di-
methylformamide with liberation of nitrogen gave
potassium 2-(2-bromophenyl)ethynethiolate (2) which
then reacted with secondary amine to produce potas-
sium 2-(2-bromophenyl)-1-aminoethenethiolate 3a or
3b. The subsequent intramolecular cyclization via nu-
cleophilic replacement of the bromine atom by thiolate
sulfur in the presence of copper(I) iodide afforded
2-(morpholin-4-yl)- and 2-(piperidin-1-yl)-1-benzo-
thiophenes 5a and 5b (Scheme 1).
8.0 Hz), 7.64 d (7-H, J = 8.0 Hz). 13C NMR spectrum
(DMSO-d6), δC, ppm: 50.8 (NCH2), 66.0 (CH2O), 99.3
(C3), 121.3 (C4), 121.7 (C7), 122.1 (C6), 125.0 (C5),
132.3 (C9), 140.8 (C8), 157.9 (C2).
b. Likewise, the reaction of 0.1 g (0.333 mmol) of
thiomorpholide 4a with 0.07 g (0.5 mmol) of K2CO3
and 0.014 mg (0.067 mmol) of CuI in 3 mL of DMF
gave 0.052 g (71%) of 5a.
2-(Piperidin-1-yl)-1-benzothiophene (5b). A mix-
ture of 0.2 g (0.828 mmol) of thiadiazole 1, 0.344 g
(2.49 mmol) of K2CO3, 0.21 g (2.49 mmol) of piperi-
dine, and 0.032 g (0.165 mmol) of copper(I) iodide in
3 mL of DMF was stirred for 4 h at 80°C under argon.
The mixture was cooled and poured into 50 mL of
a saturated solution of ammonium chloride. The pre-
cipitate was filtered off, washed with a saturated solu-
tion of ammonium chloride (3×10 mL) and water
(3×10 mL), and dissolved in 30 mL of chloroform. The
solution was washed with brine (2×20 mL) and water
(2×20 mL) and dried over calcined Na2SO4, the sol-
vent was distilled off under reduced pressure, and the
residue was purified by chromatography in a 3×10-cm
column charged with silica gel L (100–160 μm) using
hexane–ethyl acetate (4:1) as eluent. A fraction with
Rf 0.54 (hexane–ethyl acetate, 5:1) was collected.
Yield 0.088 g (49%), fine colorless crystals, mp 98.5–
The intermediate formation of potassium 2-(2-bro-
mophenyl)-1-aminoethenethiolates 3a was proved by
the synthesis of compound 5a from 2-(2-bromophe-
nyl)thioacetic acid morpholide (4a), which was accom-
plished under the same conditions, by heating in di-
methylformamide in the presence of potassium carbon-
ate and copper(I) iodide (Scheme 2).
The structure of 5a and 5b was confirmed by the
1H and 13C NMR and mass spectra, as well as by com-
parison with published data [6, 7].
2-(Morpholin-4-yl)-1-benzothiophene (5a).
a. A mixture of 0.1 g (0.414 mmol) of thiadiazole 1,
0.174 g (0.5 mmol) of potassium carbonate, 0.075 g
(0.828 mmol) of morpholine, and 0.016 g (0.083 mmol)
of copper(I) iodide in 3 mL of dimethylformamide was
stirred for 4 h at 80°C under argon. The mixture was
cooled and poured into water, the precipitate was
filtered off, washed with a saturated solution of ammo-
nium chloride (3×10 mL) and water (3×10 mL), and
dissolved in chloroform. The solution was dried over
calcined Na2SO4, the solvent was distilled under
reduced pressure, and the residue was purified by
chromatography in a 3×10-cm column charged with
silica gel L (100–160 μm) using hexane–ethyl acetate
(4:1) as eluent. A fraction with Rf 0.55 (hexane–ethyl
acetate, 2:1) was collected. Yield 0.075 g (82%), fine
1
100°C [7]. H NMR spectrum (DMSO-d6), δ, ppm:
1.53–1.61 m (2H, NCH2CH2CH2), 1.61–1.71 m (4H,
NCH2CH2), 3.17–3.27 m (4H, NCH2), 6.26 s (3-H),
6.98–7.07 m (6-H), 7.15–7.24 m (5-H), 7.43 d (4-H,
J = 7.0 Hz), 7.65 d (7-H, J = 8.0 Hz). 13C NMR spec-
trum (DMSO-d6), δC, ppm: 23.9 (NCH2CH2CH2), 25.1
(NCH2CH2), 51.7 (NCH2), 98.4 (C3), 120.8 (C4), 121.2
(C7), 122.0 (C6), 124.9 (C5), 132.1 (C9), 141.3 (C8),
158.3 (C2). Mass spectrum, m/z (Irel, %): 218.0997
[M + H]+. C13H16NS. Calculated: M 218.1003.
The melting points were measured on a Boetius
1
melting point apparatus. The H and 13C NMR spectra
were recorded on a Bruker DPX-400 spectrometer at
400.13 and 100.16 MHz, respectively. The high-reso-
lution mass spectrum of 5b (electrospray ionization)
was obtained on a Micromass 70-VSE instrument. The
progress of reactions was monitored by TLC on
1
colorless crystals, mp 179–181°C [6]. H NMR spec-
trum (CDCl3), δ, ppm: 3.27 t (4H, NCH2, J = 5.0 Hz),
3.90 t (4H, CH2O, J = 5.0 Hz), 6.26 s (3-H), 7.09–
7.17 m (6-H), 7.23–7.32 m (5-H), 7.51 d (4-H, J =
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 51 No. 7 2015

PETROV et al.
1042
3. Stacy, G.W., Wollner, T.E., and Villaescusa, F.W.,
Silicagel 60 F254 plates; spots were visualized under
UV light or by treatment with iodine vapor. The
solvents used were purified and dried according to
standard procedures.
J. Org. Chem., 1965, vol. 30, p. 4074.
4. Del Amo, V., Dubbaka, S.R., Krasovskiy, A., and
Knochel, P., Angew. Chem., Int. Ed., 2006, vol. 45,
p. 7838.
This study was performed in the framework of
a state contract of the Ministry of Education and
Science of the Russian Federation.
5. Hou, C., He, Q., and Yang, C., Org. Lett., 2014, vol. 16,
p. 3040.
6. Grandclaudon, P. and Lablache-Combier, A., J. Org.
Chem., 1978, vol. 43, p. 4379.
7. Brower, K.R. and Amstutz, E.D., J. Org. Chem., 1954,
REFERENCES
vol. 19, p. 411.
1. Grese, T.A., Pennington, L.D., Sluka, J.P., Adrian, M.D.,
Cole, H.W., Fuson, T.R., Magee, D.E., Phillips, D.L.,
Rowley, E.R., Shetler, P.K., Short, L.L., Venugo-
palan, M., Yang, N.N., Sato, M., Glasebrook, A.L., and
Bryant, H.U., J. Med. Chem., 1998, vol. 41, p. 1272.
8. Ablenas, F.J., George, B.E., Maleki, M., Jain, R., Hop-
kinson, A.C., and Lee-Ruff, E., Can. J. Chem., 1987,
vol. 65, p. 1800.
9. Petrov, M.L. and Androsov, D.A., Russ. J. Org. Chem.,
2013, vol. 49, p. 479.
10. Androsov, D.A., Popova, E.A., Petrov, M.L., and Po-
2. Lee, K.C., Moon, B.C., Lee, J.H., Chung, K.-H.,
Katzenellenbogen, J.A., and Chi, D.Y., Bioorg. Med.
Chem., 2003, vol. 11, p. 3649.
nyaev, A.I., Russ. J. Gen. Chem., 2014, vol. 84, p. 2405.
RUSSIAN JOURNAL OF ORGANIC CHEMISTRY Vol. 51 No. 7 2015
