Molecules 2013, 18, 2018-2028; doi:10.3390/molecules18022018
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
The Degradation Mechanism of Toxic Atractyloside in Herbal
Medicines by Decoction
1
,
2
3,
Liang-Yu Chen *, Anren Hu and Chih-Jui Chang *
1
Department of Biotechnology, Ming-Chuan University, Guishan, Taoyuan 333, Taiwan
2
Department of Laboratory Medicine and Biotechnology, Tzu-Chi University, Hualien 970, Taiwan
3
Department of Molecular Biology and Human Genetics, Tzu-Chi University, Hualien 970, Taiwan
*
Authors to whom correspondence should be addressed: E-Mails: loknath@mail.mcu.edu.tw (L.-Y.C.);
cjchang@mail.tcu.edu.tw (C.-J.C.); Tel.: +886-3-350-7001 (ext. 3773) (L.-Y.C.);
Tel.: +886-3-856-5301 (ext. 2673) (C.-J.C.).
Received: 12 December 2012; in revised form: 31 January 2013 / Accepted: 1 February 2013 /
Published: 5 February 2013
Abstract: Atractyloside (ATR) is found in many Asteraceae plants that are commonly used
as medicinal herbs in China and other eastern Asian countries. ATR binds specifically to the
adenine nucleotide translocator in the inner mitochondrial membrane and competitively
inhibits ADP and ATP transport. The toxicity of ATR in medical herbs can be reduced by
hydrothermal processing, but the mechanisms of ATR degradation are not well understood.
In this study, GC-MS coupled with SPE and TMS derivatisation was used to detect ATR
levels in traditional Chinese medicinal herbs. Our results suggest that ATR molecules were
disrupted by decomposition, hydrolysis and saponification after heating with water
(
decoction) for a long period of time. Hydrothermal processing could decompose the
endogenous toxic compounds and also facilitate the detoxification of raw materials used in
the Chinese medicine industry.
Keywords: atractyloside; decoction; herbal medicines
1
. Introduction
Atractyloside (ATR) is one of a group of diterpenoid glycosides. ATR binds specifically to the
adenine nucleotide translocator in the inner mitochondrial membrane and competitively inhibits ADP
and ATP transport [1]. The toxicity and biochemistry of ATRs have been reviewed [2,3]. ATR is found

Molecules 2013, 18
2019
in many Asteraceae plants (Atractylis, Wedelia, and Xanthuim species) that are commonly used as
medical herbs in Chinese and other East Asian civilizations [2,4–6]. There is a predominant view in
Traditional Chinese Medicine (TCM) that herbal medicines are harmless and free of side effects because
they come from natural sources. Pharmacological clinical studies on humans showed that dried rhizomes
of A. macrocephala exerted a diuretic effect in patients with oedema, but not in normal subjects [7,8].
It has also been shown to be liver protective and a mild hypoglycaemic agent [9,10]. A. lancea is mainly
used for the treatment of indigestion and stomach disorders [11,12]. Xanthii Fructus (Cang-Er-Zi) is the
dried fruit of Xanthium strumarium L. and is used to treat sinusitis, headache and skin pruritus [6].
However, there have been certain cases of hepatic injury and even deaths associated with these medical
herbs [13–15]. The safe and effective use of medicinal herbs has therefore been identified as a research
priority [16,17].
The toxicity and chemical profiles of ATRs are highly dependent on the variations in both species and
processing [2,18]. Interest in these compounds was stimulated by the high toxicity of the sulphated
glucoside and aglycone, which has been responsible for many deadly poisonings [3,19,20].
4
-carboxyatractyloside (CATR), which is more toxic than ATR, is found in fresh, but not dried plants
because it is decarboxylated to ATR during ageing or desiccation [2,21]. The structures of ATR and its
analogue CATR are illustrated in Figure 1.
Figure 1. The chemical structures of atractyloside (R = H) and carboxyatractyloside (R = COOH).
Our previous studies suggested that the cytotoxicity of the herbs was attenuated after hydrothermal
processing (also called decoction), and we also demonstrated molecular degradation of ATR using mass
spectral analysis [22], but the complete mechanism of ATR toxicity is still not fully understood.
In clinical practice, crude herbal medicines are prepared (infused and extracted with hot water) before
ingestion of the TCMs. After ingestion, the TCM extracts are likely to be breaking down by action of
the gastric juice, a strongly acid and colorless fluid. Therefore, to mimic the process of extraction and
digestion of TCM extracts, we analyzed the ATR degradation mechanism under two conditions
(
temp and pH) in this study. We used a modified GC/MS method for detecting ATR in TCMs and
characterised the kinetic degradation of ATR as a possible mechanism for reducing its toxicity. Based on
our results, hydrothermal processing could decompose the endogenous toxic compounds and also
facilitate the detoxification of raw materials used in the Chinese medicine industry. In addition,
acidification could also assist in the degradation, stimulating a detoxification pathway by the action of
gastric acid secretions in the stomach. The results from this study will help us to assess the safety and
risks of medicinal herbs in the pharmaceutical industry and ethnopharmacology [23,24].

Molecules 2013, 18
2020
2
. Results and Discussion
2.1. Quantitation of ATR in Herbs
The results of evaluation of ATR levels in herbs are listed in Table 1. A. gummifera L. and Calliepis
laureola DC are used in traditional medicine by people of the Mediterranean regions and South Africa,
respectively. The high levels of ATR in two TCM herbs (Atractylodes lancea and Atractylodes
macrocephala) were determined and compared to other Asteraceae plants. Additionally, Xanthii
Fructus is considered to be acutely toxic because it contains CATR rather than ATR. There are genetic,
histological, environmental, and time of harvest factors that influence the ATR content of botanical
samples. Our results specified that, due to the presence of toxic materials, TCMs should be collected and
stored for an extended period of time before use, because the level of toxic compounds decreases with
ageing. Furthermore, the toxic molecule could be degraded by the decocting used in the ethno
pharmaceutical procedure.
Table 1. ATR content of plants.
a
Specimen
ATR ± s.d. (μg/g)
8980 ± 148
9230 ± 175
2570 ± 153
N.D.
Reference
This study
This study
This study
[21]
Atractylode lancea (n = 3
Atractylode macrocephala (n = 3)
Xanthii Fructus (n = 3)
Calliepis laureola
Atractylode gummifera
0.12%–1.57%
[3]
a
b
Contents of ATR are based on dried weight. N.D. represents not detectable, less than the limit of detection
LOD = 3 × s.d.).
(
2
.2. Cytotoxicity of Herb Extracts and Effects of Decoction
To evaluate the cytotoxicity of the herbal extracts (HEs), cells were treated with various
concentrations of HE (50, 100, or 800 μg/mL). The method for preparing the HEs is described in
Section 3.2. The resultant cell viability was determined by MTT assay after treatment for 48 h. As
shown in Figure 2, cell viability was significantly decreased by 800 μg/mL HE treatment. If we only
consider the amount of ATR in HEs, the cytotoxicity of ATR was observed at the relatively low
dosage (about 1 μg/mL). Moreover, the Xanthii Fructus extract reduced cell viability in a
dose-dependent manner. This result implied that higher levels of intensely toxic compounds could be
extracted by water from Xanthii Fructus than from the dried rhizomes of the Atractylis species.
Decoction is a very convenient process when applied to TCMs. To analyse the effect of hydrothermal
processing, aqueous extracts of the three herbs were also heated to boiling for 3 h. The cytotoxicity of
the HEs at 100 μg/mL was then evaluated by MTT assay. Interestingly, the toxicity of the herbal extracts
was reduced significantly. According to literature reports [3], many endogenous toxins are unstable
under conditions of high temperature, oxidation, or light irradiation [25]. Our results also demonstrate
the effect of decocting the 100 μg/mL HEs of A. macrocephala and Xanthii Fructus on retaining cell
viability. This suggests that appropriate processing could attenuate the toxicity of crude herbs and this is
likely to be through the degradation of ATR.

Molecules 2013, 18
Figure 2. Viability was assessed using an MTT assay after 48 h treatment with the indicated
2021
agents. Media only was used as the control. Values represent means and standard deviation
of 4 independent experiments. *, p < 0.05; **, p < 0.01, control versus HEs. # indicates a
significant different between the HE treatments and decocted 100 μg/mL herbal extract,
p < 0.05.
2
.3. Hydrolysis of ATR and Mass Spectral Interpretations
In ethnopharmacology, natural materials are usually formulated and processed before their use as
medicines. However, evaluation of toxic compound stability in processing is very difficult because of
the complex reactions of the materials [26,27]. Pure ATR and phosphate buffers were used to avoid
interference and optimise experimental conditions.
The GC chromatograms obtained from the TMS derivatives of ATR standards demonstrated that
degradation of ATR could generate multiple products during hydrothermal processing. As shown in
Figure 3, two new peaks were observed in the chromatogram of acidified and 120 min hydrothermally
+
treated ATR. The major peak (retention time of 23.747 min) was designated as H ATR. The other peak
at 15.295 min was little increased and designated as H*V.
The mass spectrum of ATR (retention time of 16.836 min) was characterised by ion fragments at m/z
3
16, 647, and 663 in Figure 4A. The molecular structure of ATR derivatives should contain at least one
+
sulphate group. The mass spectrum of H ATR was characterised by ion fragments at m/z 289 and 447 in
Figure 4B.
In a previous study to detect acidified ATR in a patient poisoned with Callipepis laureola, the organic
solvent ethyl acetate was used to extract lipophilic compounds [19]. However, the acidification of
sonicated extract would transform isovalerate ester to acetate ester in ATR. The hydrolysis of isovalerate
and sulphate groups was increased by acidification and hydrothermal processing. Here, we used a solid
phase extraction (SPE) technique to avoid any transesterification reactions such as biodiesel production.

Molecules 2013, 18
2022
Figure 3. Chromatograms obtained from the TMS derivatives of the hydrolyzed ATR
in red) with the spiked ATR of 100 μg/mL and the internal standard (IS) for comparison.
(
Figure 4. Mass spectra of ATR (A) and H+ATR (B).

Molecules 2013, 18
2023
Figure 4. Cont.
2
.4. Degradation of ATR by Hydrothermal Processing
Based on the mass spectrum (Figure 4B), the sulphate group could not be observed due to the
+
hydrothermal treatment. Additionally, the structure of the TMS derivative of H ATR should have a new
hydroxyl group from the hydrolysis of the isovalerate group in the glycoside moiety. Also, the H*V
peak in the chromatograms (in Figure 3) is considered as a TMS derivative of isovaleric acid.
Therefore, we suggest that the sulphate groups and the isovalerate ester are highly associated with ATR
degradation, as shown in Figure 5.
Figure 5. The degradation mechanism of ATR salt by acidification and heating.
It is difficult to dissect the detailed mechanisms of ATR degradation in herbal extracts, especially
in high concentrations. The components are complicated and aggregation is always a problem. Besides,

Molecules 2013, 18
2024
at higher concentrations of herbal extracts, we cannot rule out the possibility that any cytotoxic effects
might due to other components in the extracts. In this study, we only focused on the degradation
mechanisms of ATR during herbal medicine preparation. Spiked HEs were used to mimic the process
of extraction. To reduce perturbation from other components in HEs and to amplify the ATR signal,
we added 100 μg/mL of ATR to 0.4% of herbal extracts (diluted from 4% HE stock). The time course
of ATR degradation by hydrothermal treatment is shown in Figure 6. At high and moderate
temperatures, degradation of ATR was observed and this increased with incubation time. Acidification
also enhanced the efficiency of degradation. The use of SPE in the sample preparation procedure could
avoid the esterification errors derived from the traditional method with liquid-liquid extractions. The
performance of the GC/MS method with SPE was validated by previous studies, which reported a
good sensitivity and the 87%–103% recovery of HE spiked 100 μg/mL ATR [22].
Approximately 40% of ATR could be removed by hydrothermal processing at 98 °C (without
boiling) and pH 2.3 for 2 h. Detoxification resulted from decomposition, hydrolysis and saponification
of toxic analytes, which reacted in an aqueous solution of a natural mixture. The effects of
hydrothermal processing could explain why reports of intoxication are rare from brewing and drinking
herbs in TCMs.
Figure 6. The degradation of ATR by acidification and heating. After acidification and
heating for 120 min, the residue of ATR is decreased significantly (the p value is less 0.05).
3
. Experimental
3
.1. Chemicals, Reagents and Apparatuses
The potassium salt of atractyloside, 5α-androstane-3β,17β-diol (as internal standard) and the
derivative reagent trimethylsilyl imidazole (TMSI) were purchased from Sigma Chemical-Aldrich
St. Louis, MO, USA). Ethyl acetate, methanol and pyridine (Silylation grade) were obtained from
(
Merck (Darmstadt, Germany). All other chemicals were of analytical grade and used without further
purification. Water was purified using Millipore Milli-Q water filtration system (Millipore, Bedford,
MA, USA). The standard solutions of ATR were 100 and 1,000 μg/mL and were stored in the dark at

Molecules 2013, 18
2025
−20 °C. A 12-port vacuum manifold and HyperSep C18 SPE cartridge (200 mg bed weight per 3 mL
volume) were used for extractions and were purchased from Thermo Scientific Corp (Folsom, CA, USA).
3.2. Sample Preparation and Aqueous Infusion
Xanthii Fructus and the rhizomes of A. macrocephala and A. lancea were collected from the
wilderness in Taiwan. These fresh samples were identified by morphological classification and genetic
polymorphisms by Kuo-Chieh Ho, Institute of Plant Biology, National Taiwan University, then
freeze-dried and weighed. The voucher sample was deposited in Dr. Liang-Yu Chen lab, Department
of Biotechnology, Ming-Chuan University. Atractylode lancea: No. 114, Atractylode macrocephala:
No. 115, Xanthii Fructus: No. 116.
The dried botanical samples were pulverised to powder before the infusion process (water
extraction). Four grams of pulverised powder was sonicated for 30 s, extracted with 40 mL of water by
stirring at room temperature for 30 min, and then centrifuged at 1,500 × g for 5 min. The extraction was
repeated three times. The extracts were collected and filtered through a 0.45 μm PVDF filter,
concentrated with a vacuum evaporator and freeze-dried. Each sample was re-dissolved in 100 mL of
water and designated as the stock solution of 4% herbal extract which was used subsequently to assess
the degradation of ATR.
For MTT assay and experiments quantitating ATR in herbs experiments, 500 g of pulverised
powder was extracted in 500 mL of water by stirring at room temperature for 1 h. The extraction was
repeated three times. The extracts were collected and filtered through a 0.45 μm PVDF filter,
concentrated with a vacuum evaporator and freeze-dried. The powder was dissolved in media to make
different concentrations (50, 100 and 800 μL/mL) of herbal extracts for experiments in Section 3.3.
3
.3. MTT Assay
The human cervical cancer cell line HeLa was cultured in DMEM supplemented with 10% foetal
bovine serum (Hyclone; Logan, UT, USA) at 37 °C with 5% CO incubation. Cells were cultured in
2
9
8
6-well plates and treated with 100 μL of different concentrations of herbal extracts (50, 100 and
00 μL/mL) for 48 h. In addition, cells were treated with 100 μL/mL herbal extracts that had been
processed hydrothermally by boiling for 3 h. Following incubation, the medium in each well was
exchanged, and the cells were incubated with 40 μL of MTT solution (5 mg/mL) for 4 h. Next, 250 μL of
DMSO was added to extract the MTT formazan. The reaction products were measured at 540 nm by a
9
6-well plate ELISA reader (GE Healthcare, Fremont, CA, USA) and the absorbance values used to
calculate the % viability cells relative to the control. In order to determine whether there were
significant differences in cell viability a T-test was performed.
3
.4. Stability of ATR during Decoction
The spiked HEs were prepared by adding 100 μg/mL of ATR to 0.4% of herbal extracts (diluted
from 4% HE stock). One aliquot was left untreated and stored at ambient temperature (approximately 22 °C)
as a control. Five 200 mL aliquots of 100 μg/mL ATR spiked HE of A. macrocephala were prepared to
evaluate the kinetic stability of ATR by heating and acidification. Samples of spiked HE were adjusted

Molecules 2013, 18
2026
to pH 6.8 or pH 2.3 in 100 mM phosphate buffered saline (PBS), and the solutions were incubated at
8 °C or 65 °C, respectively. Three 2 mL samples were collected at 15, 30, 60, 90, 120, 300 min. The
samples were then extracted using SPE and derivatised for GC/MS analysis.
9
3.5. Extraction and GC-MS Analysis
Three 2.0 mL aliquots of the solutions collected in Section 3.4 were transferred into 10 mL
polypropylene centrifuge tubes and acidified with hydrochloric acid (2 mL, 2.0 N). After vortexing,
samples were centrifuged at 1,500 × g for 5 min. Cartridges were conditioned by deionised water after
methanol washing for solid phase extraction, and two consecutive elution (2 mL each) were performed
with a mixture of methanol (80:20, v/v) containing 2% ammonium hydroxide. The extracts were then
evaporated to dryness at 40 °C under a stream of nitrogen.
The dry residues were resuspended in 0.5 mL of methanol and transferred to derivatising vials. After
the solvent was again evaporated to dryness with nitrogen, 200 μL of pyridine and TMSI was added. The
derivatisation was performed at 100 °C for 2 h before GC-MS analysis.
Analyses were performed with a HP-6890 gas chromatograph and a HP-5973 mass-selective detector
(MSD) from Agilent Technologies (Palo Alto, CA, USA) equipped with a capillary gas chromatography
column DB-1MS (30 m × 0.25 mm I.D., 0.25 μm film thickness) (J&W Scientific, Folsom, CA, USA).
The injection volume was 2 μL at splitless mode, and the inlet temperature was 250 °C. The carrier gas
was helium at a flow rate of 1 mL/min, and the oven temperature was programmed as follows: initial
temperature at 210 °C for 3 min and increased at 10 °C/min up to 270 °C, then increased at 30 °C/min
until 310 °C, and then held for 15 min. The analysis was performed in the EI mode, and the ionisation
voltage was fixed at 70 eV. The scan acquisition (m/z 50–800) of MSD was performed by the HP
chemistation software. Quantitative data were calculated by the internal standard method based on
integrated area of peaks in selected ion monitoring (SIM) mode.
4
. Conclusions
It is proposed that ATR makes a major contribution to the cytotoxic properties of the species
Atractylis. GC-MS with SPE and TMS derivatisation allows for the detection of ATR in traditional
Chinese medicinal herbs. This method is ideal for general screening through forensic analysis or as a
quantitative evaluation of hazard analysis and critical control point (HACCP) in pharmaceutical safety.
The structure of ATR molecules was disrupted by heating with water (decoction) for a long period of
time. This study validates the degradation of ATR as a possible mechanism for reducing its toxicity.
Hydrothermal processing could also facilitate the detoxification of the raw materials used in the Chinese
medicine industry.
Acknowledgements
The authors are grateful for financial support from the National Science Committee, Taiwan, under
contract No. NSC 100-2113-M-130-001-MY2.

Molecules 2013, 18
2027
Conflict of Interest
The authors declare no conflict of interest.
References
1
.
Lemasters, J.J.; Sowers, A.E. Phosphate dependence and atractyloside inhibition of mitochondrial
oxidative phosphorylation. The ADP-ATP carrier is rate-limiting. J. Biol. Chem. 1979, 254,
248–1251.
1
2
3
4
. Obatomi, D.K.; Bach, P.H. Biochemistry and toxicology of the diterpenoid glycoside atractyloside.
Food Chem. Toxicol. 1998, 36, 335–346.
.
.
Daniele, C.; Dahamna, S.; Firuzi, O.; Sekfali, N.; Saso, L.; Mazzanti, G. Atractylis gummifera L.
poisoning: An ethnopharmacological review. J. Ethnopharmacol. 2005, 97, 175–181.
Cao, H.; Chen, X.; Sun, H.; Sakurai, T.; Zhou, J.; Sun, W.; Lv, H.; Wang, X.
Pharmacokinetics-based elucidation on disparity in clinical effectiveness between varieties of Zhi
Zhu Wan, a Traditional Chinese Medical formula. J. Ethnopharmacol. 2010, 128, 606–610.
Meng, H.; Li, G.Y.; Dai, R.H.; Ma, Y.P.; Zhang, K.; Zhang, C.; Li, X.; Wang, J.H. Two new
polyacetylenic compounds from Atractylodes chinensis (DC.) Koidz. J. Asian Nat. Prod. Res.
5
6
.
.
2
010, 13, 346–349.
Han, T.; Zhang, Q.Y.; Zhang, H.; Wen, J.; Wang, Y.; Huang, B.K.; Rahman, K.; Zheng, H.C.;
Qin, L.P. Authentication and quantitative analysis on the chemical profile of Xanthium fruit
(
Cang-Er-Zi) by high-performance liquid chromatography-diode-array detection tandem mass
spectrometry method. Anal. Chim. Acta 2009, 634, 272–278.
7
.
Kim, C.K.; Kim, M.; Oh, S.D.; Lee, S.M.; Sun, B.; Choi, G.S.; Kim, S.K.; Bae, H.; Kang, C.;
Min, B.I. Effects of Atractylodes macrocephala Koidzumi rhizome on 3T3-L1 adipogenesis and
an animal model of obesity. J. Ethnopharmacol. 2011, 137, 396–402.
8
9
.
.
Jiang, H.; Shi, J.; Li, Y. Screening for compounds with aromatase inhibiting activities from
Atractylodes macrocephala Koidz. Molecules 2011, 16, 3146–3151.
Lee, J.C.; Lee, K.Y.; Son, Y.O.; Choi, K.C.; Kim, J.; Kim, S.H.; Chung, G.H.; Jang, Y.S.
Stimulating effects on mouse splenocytes of glycoproteins from the herbal medicine Atractylodes
macrocephala Koidz. Phytomedicine 2007, 14, 390–395.
1
0. Shan, J.J.; Tian, G.Y. Studies on Physico-chemical properties and hypoglycemic activity of
complex polysaccharide AMP-B from Atractylodes macrocephala Koidz. Acta Pharm. Sin. 2003,
3
8, 438–441.
11. Duan, J.A.; Wang, L.; Qian, S.; Su, S.; Tang, Y. A new cytotoxic prenylated dihydrobenzofuran
derivative and other chemical constituents from the rhizomes of Atractylodes lancea DC.
Arch. Pharm. Res. 2008, 31, 965–969.
12. Wang, H.X.; Liu, C.M.; Liu, Q.; Gao, K. Three types of sesquiterpenes from rhizomes of
Atractylodes lancea. Phytochemistry 2008, 69, 2088–2094.
1
3. Stickel, F.; Patsenker, E.; Schuppan, D. Herbal hepatotoxicity. J. Hepatol. 2005, 43, 901–910.
4. Bouziri, A.; Hamdi, A.; Menif, K.; Ben Jaballah, N. Hepatorenal injury induced by cutaneous
application of Atractylis gummifera L. Clin. Toxicol. (Phila.) 2010, 48, 752–754.
1

Molecules 2013, 18
2028
1
1
5. Haller, C.A.; Dyer, J.E.; Ko, R.; Olson, K.R. Making a diagnosis of herbal-related toxic hepatitis.
West. J. Med. 2002, 176, 39–44.
6. Cheng, H.M.; Li, C.C.; Chen, C.Y.; Lo, H.Y.; Cheng, W.Y.; Lee, C.H.; Yang, S.Z.; Wu, S.L.;
Hsiang, C.Y.; Ho, T.Y. Application of bioactivity database of Chinese herbal medicine on the
therapeutic prediction, drug development, and safety evaluation. J. Ethnopharmacol. 2010, 132,
4
29–437.
1
1
7. Burns, J.J.; Zhao, L.; Taylor, E.W.; Spelman, K. The influence of traditional herbal formulas on
cytokine activity. Toxicology 2010, 278, 140–159.
8. Kedrov, A.; Hellawell, A.M.; Klosin, A.; Broadhurst, R.B.; Kunji, E.R.; Muller, D.J. Probing the
interactions of carboxy-atractyloside and atractyloside with the yeast mitochondrial ADP/ATP
carrier. Structure 2010, 18, 39–46.
1
9. Laurens, J.B.; Bekker, L.C.; Steenkamp, V.; Stewart, M.J. Gas chromatographic-mass
spectrometric confirmation of atractyloside in a patient poisoned with Callilepis laureola.
J. Chromatogr. B Biomed. Sci. Appl. 2001, 765, 127–133.
2
2
0. Steenkamp, P.A.; Harding, N.M.; van Heerden, F.R.; van Wyk, B.E. Identification of atractyloside
by LC-ESI-MS in alleged herbal poisonings. Forensic Sci. Int. 2006, 163, 81–92.
1. Steenkamp, P.A.; Harding, N.M.; van Heerden, F.R.; van Wyk, B.E. Determination of
atractyloside in Callilepis laureola using solid-phase extraction and liquid chromatography-
atmospheric pressure ionisation mass spectrometry. J. Chromatogr. A 2004, 1058, 153–162.
2. Chu, C.; Ho, K.; Hu, A.; Chiu, C.; Wu, H.; Ye, S.; Chen, L. Toxicity attenuation of Atractyloside
in traditional Chinese medicinal herbs after hydrothermal processing. Bot. Stud. 2012, 53, 459–465.
3. Jiang, Y.; David, B.; Tu, P.; Barbin, Y. Recent analytical approaches in quality control of
traditional Chinese medicines—A review. Anal. Chim. Acta 2010, 657, 9–18.
2
2
2
2
4. Chau, C.F.; Wu, S.-H. The development of regulations of Chinese herbal medicines for both
medicinal and food uses. Trends Food Sci. Technol. 2006, 17, 313–323.
5. Buscemi, S.; Rosselli, S.; Bruno, M.; Vivona, N.; Piozzi, F. Photoinduced functionalization of
diterpenes: Transformation of the C-20 methyl of atractyligenin into a carbomethoxymethyl or
carbamoylmethyl group. J. Photochem. Photobiol. A 2003, 155, 145–149.
2
6. Franje, C.A.; Chang, S.K.; Shyu, C.L.; Davis, J.L.; Lee, Y.W.; Lee, R.J.; Chang, C.C.; Chou, C.C.
Differential heat stability of amphenicols characterized by structural degradation, mass
spectrometry and antimicrobial activity. J. Pharm. Biomed. Anal. 2010, 53, 869–877.
7. Toh, D.F.; New, L.S.; Koh, H.L.; Chan, E.C. Ultra-high performance liquid chromatography/
time-of-flight mass spectrometry (UHPLC/TOFMS) for time-dependent profiling of raw and
steamed Panax notoginseng. J. Pharm. Biomed. Anal. 2010, 52, 43–50.
2
Sample Availability: Samples of the Atractylode lancea, Atractylode macrocephala, Xanthii Fructus are
available from the authors.
©
2013 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
http://creativecommons.org/licenses/by/3.0/).
(
