In this paper, we report the study of a novel p-aminoazobenzene based non-conjugated, benzoxazine polymer, poly([4-(6-tert-butyl-4H-benzo[e][1,3]oxazin-3-yl)phenyl]-phenyldiazene) (AZO-PBZ) synthesized using solvent free, thermally activated cationic ring opening polymerization. The thermal, photophysical, electrochemical, and photoconducting properties of the polymer were investigated. The optical absorption band edges of AZO-PBZ thin film was observed at 555 nm. Photoinduced charge transfer nature of AZO-PBZ was studied by analyzing the fluorescence spectra and performing photoconductivity experiments. Incorporation of [6, 6]-phenyl-C₆₁-butyric acid methyl ester denoted as PCBM into the polymer leads to quenching of the fluorescent intensity and exhibits significant photoconductivity. The photocurrent through the PCBM blend films was measured as a function of electric field to recognize the field dependence on carrier generation. Internal photocurrent efficiency of the polymer:PCBM blend samples was found to be in the order of 10^?5 and photoconductive sensitivity was of the order of 10^?11 S W^?1cm, which is adequate for photorefractivity.

Full text of DOI:10.1016/j.polymer.2018.01.028

Accepted Manuscript
Synthesis and experimental investigations on the photoconductivity of p-
aminoazobenzene based non-conjugated polybenzoxazine system
Jisha J. Pillai, Anshad Abbas, Sona Narayanan, K. Sreekumar, C. Sudha Kartha,
Rani Joseph
PII:
S0032-3861(18)30029-6
10.1016/j.polymer.2018.01.028
JPOL 20288
DOI:
Reference:
To appear in: Polymer
Received Date: 27 October 2017
Revised Date: 2 January 2018
Accepted Date: 9 January 2018
Please cite this article as: Pillai JJ, Abbas A, Narayanan S, Sreekumar K, Kartha CS, Joseph R,
Synthesis and experimental investigations on the photoconductivity of p-aminoazobenzene based non-
conjugated polybenzoxazine system, Polymer (2018), doi: 10.1016/j.polymer.2018.01.028.
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to
our customers we are providing this early version of the manuscript. The manuscript will undergo
copyediting, typesetting, and review of the resulting proof before it is published in its final form. Please
note that during the production process errors may be discovered which could affect the content, and all
legal disclaimers that apply to the journal pertain.

ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Synthesis and experimental investigations on the photoconductivity of p-
Aminoazobenzene based non-conjugated polybenzoxazine system
a
b
c
d
b
a*
Jisha J. Pillai, Anshad Abbas, Sona Narayanan, K. Sreekumar, C. Sudha Kartha, Rani
Joseph
a
Department of Polymer Science and Rubber Technology, Cochin University of Science and Technology, Cochin-
2, India. e-mail: gshajpillai@gmail.com, *rani@cusat.ac.in
2
b
Department of Physics, Cochin University of Science and Technology, Cochin-22, India. e-mail:
anshadlathara@gmail.com, karthasudha@gmail.com
c
School of Chemical Sciences, Mahatma Gandhi University, Kottyam-686 560, India. e-mail:
sonachalil@gmail.com
d
Department of Applied Chemistry, Cochin University of Science and Technology, Cochin-22, India. e-mail:
ksk@cusat.ac.in
Abstract
In this paper, we report the study of a novel p-aminoazobenzene based non-conjugated,
benzoxazine polymer, poly([4-(6-tert-butyl-4H-benzo[e][1,3]oxazin-3-yl)phenyl]-phenyldiazene)
(AZO-PBZ) synthesized using solvent free, thermally activated cationic ring opening
polymerization. The thermal, photophysical, electrochemical, and photoconducting properties of
the polymer were investigated. The optical absorption band edges of AZO-PBZ thin film was
observed at 555 nm. Photoinduced charge transfer nature of AZO-PBZ was studied by analyzing
the fluorescence spectra and performing photoconductivity experiments. Incorporation of [6, 6]-
phenyl-C -butyric acid methyl ester denoted as PCBM into the polymer leads to quenching of
6
1
the fluorescent intensity and exhibits significant photoconductivity. The photocurrent through
the PCBM blend films was measured as a function of electric field to recognize the field
dependence on carrier generation. Internal photocurrent efficiency of the polymer:PCBM blend
-5
samples was found to be in the order of 10 and photoconductive sensitivity was of the order of
-11
-1
1
0
S W cm, which is adequate for photorefractivity.
Keywords: polybenzoxazine, cationic ring opening polymerization, photoconductivity, donor-
acceptor polymer
1
. Introduction
In the past few decades, macromolecules with unique combination of both electronic and optical
properties have gained considerable attention in the field of optical storage media, dynamic
holography, photorefractive composites, photovoltaic and photoconducting devices due to
increasing need for low cost materials with structural flexibility, stability and processability
[1–4]. Despite a handful of reports on the synthesis and photoconducting properties of
conjugated polymer systems [5–7], only very few reports can be found in the literature on non-
conjugated polymers. Polybenzoxazines are such kind of polymers with non-conjugated skeleton
with benefit of inexpensive precursors including phenols, primary amines and formaldehyde as
an asset. The extraordinary molecular design flexibility together with the unique properties such
as, low cost, low water absorption, absence of byproducts, no need of catalyst, ease of synthesis
etc. make them highly attractive for future applications enabled them to be used in various fields
like aerospace, automotive industries, optical storage etc.[8–11]. Another remarkable
1

ACCEPTED MANUSCRIPT
characteristic of benzoxazines is their undemanding polymerisability without the presence of a
o
catalyst or solvent at temperatures between 160- 240 C [12,13]. Ishida et al proposed the ring
opening polymerization of benzoxazine which proceeded through a cationic mechanism. The
final polymer obtained may have the structure of phenoxy, phenolic or both depending on the
polymerization conditions [14–17]. But the ring opening polymerization requires high
temperature which may result in the degradation of the polymer [18]. Aniline based
photoconducting polybenzoxazine was synthesized and its Photophysical and electrochemical
behavior was well explained elsewhere. The band gap of aniline based polybenzoxazine has been
reduced by experiencing intramolecule donor-acceptor concept in order to enhance its
photoconducting behavior [19]. Photoconductivity in polymeric systems is a complex process
involving absorption of radiation, generation of charge carriers, transport, recombination and
trapping [20–23]. The charge transport and photoconducting properties of these materials
whether it is conjugated or non conjugated, mainly depend on the structure and morphology of
the polymer chains.
The present paper reports the synthesis, characterization and photoconductivity studies of
Mannich phenolic type, p-aminoazobenzene based polybenzoxazine. Compared to previous
reports, higher molecular weight polymer was obtained by adopting in situ polymerization
without separating the monomer during the course of reaction [13]. Kishore et al. conducted the
photoconductivity studies on a series of polybenzoxazine systems and reported that the
incorporation of C60 resulted in an enhancement of photoconductivity [24]. The insolubility of
C60 results in phase separation which in turn adversely affects the performance of device
parameters. To overcome such insolubility issues of C , PCBM was used as sensitizer in the
6
0
present study which is a soluble derivative of fullerene having high electron affinity, mainly used
for spectral sensitivity in the visible region [25]. The large value of photoinduced birefringence,
photoinduced isomerization, non linear absorption and molecular re-orientation, makes azo
polymeric systems an important candidate for optical storage and processing applications [26].
The synthesis and characterization of benzoxazines, prepared by incorporating azobenzene
chromophoric groups into benzoxazines was reported earlier [27]. With the advantage of design
flexibility and cost effectiveness a modified version of polybenzoxazine based on azobenzene
will be a better alternative for the present scenario. The role of azo group on photoconductivity
properties of the system was understood by using p-aminoazobenzene as primary amine moiety
by attaching this group to the polymer backbone. Here the effect of PCBM as electron acceptor
on the photoconductivity of the azo polymer was also carried out as in reports [28]. Also,
photogeneration efficiency was calculated by monitoring the intensity and electric field
dependence of photocurrent was measured for the polymer-PCBM blend.
2
. Experimental Section
2
.1. Materials
All the solvents were purified according to standard procedures prior to use. The following
chemicals were used as received without further purification: 4-tertiary butyl phenol (97%,
Acros Organics), formaldehyde solution (37-41% w/v, Merck), sodium nitrite (Merck, AR
Grade), aniline (Merck, AR Grade), conc. hydrochloric acid (Merck, AR Grade), sodium acetate
crystal (Merck, AR Grade), glacial acetic acid (Merck, AR Grade), tetrabutyl ammonium
hexafluorophosphate (Bu NPF , Aldrich, >99%) where used as received. PCBM was purchased
4
6
from SolleneBV (purity >99.9%).
2

ACCEPTED MANUSCRIPT
2
.2. Instruments and measurements
1
1
H Nuclear magnetic resonance ( HNMR) spectrum was recorded on a Bruker 400 MHz
as solvent. FT-IR spectrum of the
spectrometer with TMS as internal standard using CDCl
polymer was taken on a Bruker 550 Spectrometer with spectral range of 4000-400 cm . Spectra
were recorded at a resolution of 4 cm with 32 scans. The polymer sample was finely ground
with KBr powder and pressed into pellets. UV-Visible spectra were recorded on Thermo
Scientific Evolution 201 UV-Visible spectrophotometer. Fluorescence spectra of the samples
were taken using Fluoromax-3 fluorimeter. Thermogravimetric analysis (TG/DTG) was recorded
3
-1
-1
o
on Q-50, TA instrument at a heating rate of 20 C/min under nitrogen atmosphere. The CHN
analysis was done from Elementar Vario EL III CHNSO elemental analyzer. Gel permeation
chromatography (GPC) against polystyrene standards was performed in toluene as eluent on a
Waters High Pressure GPC unit with 515 HPLC pump, styragel column and 2414 refractive
index detector. A typical concentration of 0.25 mg of polymer was dissolved in 5 mL of toluene
was used for performing GPC studies. The electrochemical experiments were performed in dry
4 6
acetonitrile with Bu NPF as supporting electrolyte using BAS Epsilon Electrochemical analyzer
with scan rate of 100 mV/s. The steady state photocurrent measurements were done using
Keithly-236 Source Measure Unit and Optically pumped semiconductor laser (488 nm,
Coherent) was used as laser source.
2
2
.3. Synthesis methods
.3.1. Synthesis of p-aminoazobenzene (PAZB)
p-aminoazobenzene was synthesized according to the reported procedure (Scheme 1) [29].
Aniline (2 g, 21.7 mmol) was added drop wise to a solution of 37% conc. HCl (6.5 mL) and
o
diazotized with an aqueous solution of sodium nitrite (1.51 g, 21.7 mmol) at 0-5 C. The mixture
was stirred for 1h. An yellow transparent diazonium salt solution was obtained. The coupling
solution was prepared by treating aniline (2 g, 21.7 mmol) with hydrochloric acid (1N, 22 mL)
o
under vigorous stirring at 0-5 C. The diazonium salt solution was added drop wise to the
o
o
coupling solution keeping the temperature at 0-5 C. The system was kept stirred at 5 C for
further 3h. The final solution was added slowly to ammonia solution (1N, 30 mL) and an yellow-
orange precipitate of azo compound was obtained. The precipitate was filtered and washed
several times with water containing a small amount of sodium bicarbonate (pH 8). The
precipitate was collected by filtration and washed with deionized water and dried under vacuum.
Yellow orange crystal obtained was recrystallized from ethanol.
+
Yield: 73%; LC-MS (Mw-197, M ). Elemental Analysis: Calculated %: C 73.09; H 5.61; N
2
1.31. Found (%): C 72.92; H, 5.99; N, 20.98.
2
.3.2. Synthesis of poly([4-(6-tert-butyl-4H-benzo[e][1,3]oxazin-3-yl)phenyl]-phenyldiazene)
(
AZO-PBZ).
The synthesis of the polymer is shown in Scheme 2. A mixture of 4-tertiarybutyl phenol (10.6 g,
0 mmol) and formaldehyde solution (11 mL, 175 mmol) taken in a two necked round bottom
7
o
flask, were heated to 40 C for 5 h. PAZB (13.8 g, 80 mmol) was added slowly to the above
mixture. The mixture was stirred at 180 C for 12 h and cooled to room temperature. Deen Stark
o
apparatus was used to collect water as byproduct so as to keep the temperature of the reaction
o
mixture at 180 C. The dark orange solid obtained was dissolved in chloroform and re-
precipitated from methanol. The precipitated polymer was filtered, washed with water, dried at
3

ACCEPTED MANUSCRIPT
room temperature and further purified by soxhlet extraction with methanol and dried under
vacuum. Yield: 83%.
2
.4. Photoconductivity sample preparation
Figure 2 Schematic diagram of sandwich cell structure
Figure 1 Chemical structure of sensitizer, PCBM
Thin films of AZO-PBZ: PCBM blend were prepared from the blend solution in which AZO-
PBZ to PCBM (Figure 1) ratio was 1:0.5. The blend solution of polymer and sensitizer was
prepared in distilled chloroform by bath sonication method. A clear solution was obtained by
filtering the dissolved solution using 0.45µm PTFE filter. To prepare neat films, the clear
solution was subsequently spin coated on ITO coated glass substrates. The prepared films had a
thickness of 1µm. Conductivity studies were done on sandwich cell structure (Figure 2.) made by
vacuum deposition of silver on shadow-masked film samples. The silver electrode has a
2
thickness of 50 nm. The active area of the device (defined by the silver contact) was 0.03 cm .
2
.5. Photocurrent measurement
The steady state photocurrent measurements were done using Keithly 236 Source measure unit.
The photocurrent action spectrum was measured using the various excitation wavelengths from a
Fluoromax-3 fluorimeter. The photocurrents corresponding to different wavelengths were
normalized for constant incident flux. The current through the device prior to illumination (Dark
current) was subtracted from current measured under illumination to give the photocurrent (JPH
=
J - J ). Both measurements were done in an air conditioned laboratory maintaining a constant
L
D
o
temperature of 25±0.5 C. The photoconductivity in polymers depends both on the intensity of
illumination and the external electric field and dependence of photocurrent on these parameters
were analyzed using the photon flux of wavelength 488 nm.
3
3
. Results and Discussion
.1. Polymer synthesis
Poly([4-(6-tert-butyl-4H-benzo[e][1,3]oxazin-3-yl)phenyl]-phenyldiazene) was synthesized by
thermally activated cationic ring opening polymerization. The reaction was performed in a single
step by reacting stoichiometric ratio of tertiarybutyl phenol, p-aminoazobenzene and
formaldehyde without using any catalyst and without separating the monomer during the course
of reaction.
4
Scheme 1: Synthesis of p-aminoazobenzene (PAZB)

ACCEPTED MANUSCRIPT
Scheme 2 : Synthesis of AZO-PBZ
AZO-PBZ has individual electron rich units in its main chain so that it can be treated as a hole
transporting agent and aromatic ring having azo group appears as a pendant. Tertiary butyl group
th
present in the 4 position of phenol is used to avoid the crosslinking of polymer chains which
may reduce the performance of AZO-PBZ towards optical properties. AZO-PBZ polymer was
prepared in high yield (83 %) and the monomer p-aminoazobenzene was synthesized by
diazotization method according to the literature [29]. AZO-PBZ polymer is soluble in organic
solvents like toluene, chloroform, xylene and tetrahydrofuran at room temperature and exhibits
good thin film forming properties for device applications. The polymer synthesized in this study
is not expected to form high molecular weight because the reactive site of the phenolic moiety
has been blocked by bulky tertiary butyl group. Hence, AZO-PBZ is soluble in common organic
solvents, makes it possible to record solution state NMR, GPC analysis and absorption studies.
The weight average molecular weight (Mw) of the polymer was 3124 with a polydispersity index
of 1.82. Aniline based polybenzoxazine with low molecular weight was reported earlier [13].
3
.2. Structural characterization
1
H NMR spectrum of the polymer is shown in Figure 3. The peak at 1.28 ppm corresponds to
methyl protons of the tertiary butyl group. The resonance peak at 4.35 ppm is assigned to
methylene units (Ar-CH -N) of oxazine ring Mannich base bridge. Aromatic signals of the
2
tertiary butyl phenol unit and benzene ring attached to azo group appear from 6.72 to 7.93 ppm.
The tertiary butyl group present in the phenol moiety and the aromatic protons remain in the
polymer chain could confirm the presence of polybenzoxazine unit in the final structure of the
1
polymer. H NMR analysis clearly indicated that phenoxy structure is completely transformed
into phenolic structure by rearrangement. It has been also reported that phenoxy methylene units
are highly labile and finally transformed into relatively stable phenolic methylene groups. The
signal at 4.35 ppm clearly demonstrates the existence of true phenolic methylene groups [30].
5

ACCEPTED MANUSCRIPT
1
Figure 3. H NMR spectrum of AZO-PBZ
Figure 4. FT-IR spectrum of AZO-PBZ
The FT-IR spectrum of the corresponding polymer also supported the evidences of the successful
achievement of complete ring opening of benzoxazine monomer (Figure 4). Vibrational
assignments of various benzoxazine based polymers were reported [30]. The broad peak at 3393
-1
cm could confirm the formation of hydroxyl peak corresponds to the phenolic moiety of the
-1
polybenzoxazine chain. The band centered at 1125 cm is assigned to the asymmetric stretching
vibration of C-N-C linkage. The stretching vibrations of N=N absorption bands is typically
-
1
-1
located at 1461 cm . No correlatable band was observed in the region of 1050-1010 cm ,
indicating the lack of aliphatic C-O stretching in the polymer which confirms that Mannich
phenolic type base bridge present in the repeating unit of the polymer backbone. The presence of
-
1
a band at 1267 cm is due to aromatic C-O stretching frequency of phenols which is in good
agreement with the phenolic type structure of the polymer chain [30].
3
.3. Thermal Analysis
Thermal stability of AZO-PBZ was studied by TG/DTG curves of the polymer under nitrogen
exposure and is shown in Figure 5. The TG/DTG traces of the polymer showed that more than
one decomposition events occurred during the thermal degradation of AZO-PBZ. Initial
o
o
degradation process starting around 200 C and reached its maximum rate of 0.38 %/ C at
2
o
70 C due to the cleavage of Mannich base [31] which is the consequence of evaporation of
amine. The second weight loss corresponding to the degradation of phenol moieties appeared at
o
o
o
3
60 C with a maximum rate of 0.07 %/ C at 405 C. These peaks attributed to primary
decomposition products involve the cleavage of C-N and C-O linkages [18,31] present in the
o
polymer structure. The peak appeared above 450 C is associated with secondary decomposition
products due to the functionalities which are not incorporate in to the polymer chain [18]. From
o
the figure it is seen that AZO-PBZ was fairly stable up to 200 C. This could be due to the amine
evaporation and Mannich base cleavage of the polymer backbone [27].
6

ACCEPTED MANUSCRIPT
Figure 5 TG/DTG plot of AZO-PBZ
3
.4. Photophysical properties
The UV-Vis absorption spectra of AZO-PBZ in solution and as thin film which was prepared on
ITO coated glass substrates are shown in Figure 6. The band below 350 nm corresponds to
transition of the aromatic ring present in the structure of the polymer. The polymer
backbone has electron rich t-butyl substituted phenyl ring which acts as a donor and p-
aminoazobenzene acts as an electron acceptor. The peak at higher wavelength region is attributed
to the formation of intramolecular charge transfer complex. The optical edge of the polymer in
solution was at 506 nm from which the optical band gap (
The absorption onset of the polymer film is at 555 nm, corresponding to an optical band gap of
.23 eV so that AZO-PBZ can be loosely defined as a narrow band gap polymer [32], which
) was calculated to be 2.45 eV.
2
corresponds to the combined contribution of n- and intramolecular charge transfer electronic
transition of azobenzene chromospheres. The absorption spectrum of the polymer in film form
appeared slightly red shifted as a result of interchain interactions in the solid film [33].
Figure 6 Absorption spectra of (a) AZO-PBZ dissolved in
chloroform and (b) AZO-PBZ as thin films on
ITO coated glass plate.
7

ACCEPTED MANUSCRIPT
When the polymer was blended with the sensitizer PCBM, the absorption spectrum of the
blended film exhibited a red shift compared to that of pristine film. The incorporation of
sensitizer PCBM with AZO-PBZ resulted in a significant enhancement in the absorption
coefficient (Figure 7) of the blend film. The absorption spectrum of the PCBM thin film is also
shown the inset of Figure 7. The optical absorption spectrum of the AZO-PBZ: PCBM blend
films could be considered as the simple superposition of the absorption spectra of these two
components. There is no indication of the substantial interaction between the polymer and
sensitizer in its ground state. This can be confirmed by measuring the dark electrical conductivity
of the pristine and blend films. Both the samples possess the same value of electrical
conductivity which confirms this statement. Thus, the AZO-PBZ:PCBM blend films form a
neutral electron donor-acceptor complex in which the overlapping of the electronic wave
function in the ground state is negligible.
Figure 7 Absorption spectra of (a) pristine AZO-PBZ thin film and
(
b) AZO-PBZ:PCBM blend film (1:0.5). Inset shows the
absorption spectrum of PCBM thin film. All films were prepared
on ITO coated glass plate.
3
.5. Fluorescence quenching
The fluorescence spectrum of the AZO-PBZ was studied, by exciting with photons of
wavelength 380 nm, in solution and in film, with and without adding PCBM. The fluorescence
spectra of AZO-PBZ dissolved in chloroform and as thin film prepared on ITO coated glass
substrates are shown in Figure 8. The emission maximum occurs at 597 nm. Incorporation of
PCBM molecules leads to a drastic quenching of the fluorescent intensity of the blend films
(figure 9).
Figure 8 Fluorescence spectra of (a) AZO-PBZ
dissolved in chloroform and (b) AZO-PBZ thin film
prepared on ITO coated glass plates
Figure 9 Fluorescence spectra of (a) AZO-PBZ
thin film and (b) AZO-PBZ:PCBM blend films for
the ratio 1:0.5
8

ACCEPTED MANUSCRIPT
The absorption onset of PCBM in solid state is at 425 nm [34]. There is no significant overlap
between the emission band of AZO-PBZ and absorption band of PCBM which ruled out the
possibility of energy transfer process leading to the quenching of the fluorescence intensity
[19,35]. AZO-PBZ:PCBM blend films exhibited enhanced conductivity during irradiation. So
the quenching of the fluorescence intensity can be attributed to the photoinduced intermolecular
charge transfer of electrons from AZO-PBZ to the sensitizer, PCBM. The AZO-PBZ:PCBM
blend films therefore can be of much use in photoconductive applications.
3
.6. Electrochemical properties
Electrochemical properties of AZO-PBZ were investigated using cyclic voltammetry. CV was
o
performed at 25 C in a solution of Bu NPF (0.1M) in dry acetonitrile at 100 mV/s under
4
6
nitrogen atmosphere. The experimental set up includes a three electrode configuration with
2
Ag/AgCl reference electrode, a platinum working electrode (0.08 cm ) coated with the thin
polymer film and a platinum wire as counter electrode. The highest occupied molecular orbital
(
HOMO) and lowest unoccupied molecular orbital (LUMO) energy levels of the AZO-PBZ
polymer can be estimated from the onset of oxidation ( ) and reduction ( ) potentials
36]. From the value of ( ) and ( ), the HOMO and LUMO as well as the
electrochemical band gap (E ) of the polymer were calculated by the following equation [37].
[
g
HOMO = - (
LUMO = - (
+4.71) eV ------------------ (1)
+ 4.71) eV ------------------ (2)
- ) eV ------------------- (3)
E
g
= (
The onset of oxidation of AZO-PBZ was found to occur at 0.88 V corresponding to ionization
potential value of -5.58 eV. HOMO and LUMO levels of the polymer obtained from the
electrochemical measurement were -5.58 eV and -3.56 eV respectively. Therefore, band gap of
the polymer is calculated to be 2.20 eV which is a lower value than that of the optical energy gap
(2.45 eV) obtained from absorption onset. The incorporation of azo group increases a slight
increase of HOMO level, may be due to the contribution of electron rich units in its structure.
AZO-PBZ exhibited an optical band gap of 2.45 eV much lower than poly(vinylcarbazole) (4.10
eV), a well known photoconductor [38].
3
.7. Steady state photocurrent measurement
The spectral dependence of the steady state photocurrent was measured as explained in the
experimental section. AZO-PBZ sandwich cell was found to be a poor conductor of electricity in
its intrinsic state and the observed dark current was much low. The incorporation of PCBM
molecules resulted in a considerable increase in the optical absorption which leads to a
noticeable change in the photocurrent through the sample. This increase in photocurrent in the
blend films indicates the effective photosensitization, increase in quantum efficiency of the
charge carriers and its transport through the films.
The photocurrent action spectrum was recorded for the blend films in which AZO-PBZ to PCBM
ratio was 1:0.5, by irradiating with photons of wavelength from 300 nm (4.14 eV) to 700 nm
(1.77 eV) at an applied electric field of 10V/µm. The action spectrum measured for both the
9

ACCEPTED MANUSCRIPT
positive and negative polarities of ITO, is shown in Figure 10. When the ITO electrode is
negatively biased, the AZO-PBZ:PCBM films exhibited an enhanced photocurrent over the
entire spectral range.
Figure 10 Action spectra of AZO-PBZ:PCBM
blend films for the polymer to PCBM ratio 1: 0.5
for different polarities of ITO at 10 V/µm
The onset of action spectrum is at 1.90 eV (653 nm). Photocurrent increases with photon
energies and a maximum photoresponse was obtained for 2.66 eV (470 nm). For photons with
energy greater than 2.66 eV, photocurrent was found to be decreasing. The photocurrent
gradually decreased for energy greater than 3 eV (414 nm). The maximum spectral response was
obtained at the onset of the optical absorption of the pristine AZO-PBZ film. The blend films
exhibited an increase in photocurrent at 430 nm, which corresponded to the onset of absorption
of PCBM thin film.
The dependence of photocurrent on intensity of illumination was studied using a laser beam of
wavelength 488 nm by applying an electric field of 10 V/µm (Figure 11). The intensity of the
laser beam was varied using a polarizer. The power law dependence of the photocurrent on the
intensity of the incident light beam was found to be slightly sub linear;
, and it is the
general behavior of most of the amorphous semiconducting materials [39,40].
Figure 11 Intensity dependence of photocurrent of AZO-
PBZ:PCBM blend films with polymer to PCBM ratio
10
1
:0.5 by irradiating with laser beam of wavelength 488
nm at an applied electric field of 10 V/µm

ACCEPTED MANUSCRIPT
The photogeneration efficiency and photoconductive sensitivity of the PCBM blend films were
calculated as a function of the electric field by measuring the photocurrent through the sample.
Figure 12 Electric field dependence of internal
photogeneration efficiency of AZO-PBZ:PCBM blend
films with polymer to PCBM ratio 1:0.5 by irradiating with
laser beam of wavelength 488 nm with intensity of 125
Figure 13 Electric field dependence of photoconductive
sensitivity of AZO-PBZ:PCBM blend films with polymer to
PCBM ratio 1:0.5 by irradiating with laser beam of
2
wavelength 488 nm with intensity of 125 mW/cm
2
mW/cm
Photogeneration efficiency ( ) is defined as the number of measured charge carriers per
absorbed photon [41], which is calculated using the expression,
-
---------------- (4)
where, is the light intensity, is the thickness of the sample, is the absorption coefficient
and is the wavelength of light used. Photoconductive sensitivity is defined as the
photoconductivity per unit light intensity and was calculated using the equation,
----------------- (5)
-
where,
is the applied voltage. The photocurrent measurements were carried out on PCBM
blend thin films by varying the electric field through the samples at an illumination intensity of
-2
1
25 mWcm . The samples can withstand electric fields upto 40 V/µm and beyond this the
samples undergo dielectric breakdown. Photoconductive sensitivity and photogeneration
efficiency were calculated and is plotted as function of the electric field (Figure. 12 and Figure.
1
3). It is observed that, at low electric fields, the photocurrent and the photogeneration efficiency
exhibited a linear power law dependence with the electric field and at higher electric fields it is
super linear ( ). This strong dependence of photogeneration on the electric field suggests the
relevance of Onsager’s thoery of geminate ion pair dissociation [42,43]. The calculated values of
-11
the photoconductive sensitivity are of the order of 10 and photogeneration efficiency is of the
-5
order of 10 .
11

ACCEPTED MANUSCRIPT
4
. Conclusions
P-aminoazobenzene based non-conjugated benzoxazine polymer, Poly([4-(6-tert-butyl-4H-
benzo[e][1, 3] oxazin-3-yl) phenyl]-phenyldiazene) (AZO-PBZ) was successfully synthesized by
solventless, thermally activated cationic ring opening polymerization. The steady state
photocurrent measurements revealed that, this low band gap polymer when blended with PCBM,
exhibited good photoresponse over the entire spectral range. Both internal photocurrent
efficiency and photoconductive sensitivity strongly depend on the external electric field. Internal
-5
photocurrent efficiency of the blend film is of the order of 10 and photoconductive sensitivity
-11
-1
is of the order of 10 S W cm. These values are promising when a photorefractive material is
concerned and for the fulfilment of such materials. The other important parameter electro-optic
co-efficient has to be considered which is in progress.
Acknowledgement
The author gratefully acknowledge financial support from Kerala State Council for
Science,Technology and Environment (KSCSTE) Emeritus Scientist Scheme and University
Grants Commission Researh Fellowships in Sciences for Meritorious Students (UGC-RFSMS).
References
[
[
1]
2]
Y.W. Su, S.C. Lan, K.H. Wei, Organic photovoltaics, Mater. Today. 15 (2012) 554–562.
H.J. Bolink, C. Arts, V. V Krasnikov, G.G. Malliaras, G. Hadziioannou, Novel
Bifunctional Molecule for Photorefractive Materials, Sci. York. 39 (1997) 1407–1413.
J.L. Maldonado, V.M. Herrera-Ambriz, M. Rodríguez, G. Ramos-Ortíz, M.A. Meneses-
Nava, O. Barbosa-García, R. Santillan, N. Farfán, Reversible holography and optical
phase conjugation for image formation/correction using highly efficient organic
photorefractive polymers, J. Appl. Res. Technol. 13 (2015) 537–542.
[3]
[
4]
5]
R.P. Xu, Y.Q. Li, J.X. Tang, Recent advances in flexible organic light-emitting diodes, J.
Mater. Chem. C. 4 (2016) 9116–9142.
S. Narayanan, A. Abbas, S.P. Raghunathan, K. Sreekumar, C.S. Kartha, R. Joseph,
Theoretical and experimental investigations on the photoconductivity and nonlinear
[
optical properties of donor–acceptor
π
conjugated copolymer, poly(2,5-(3,4-
ethylenedioxythiophene)-alt-2,7-(9,9-dioctylfluorene)), RSC Adv. 5 (2015) 8657–8668.
A. Abbas, J.J. Pillai, S. Narayanan, K. Sreekumar, R. Joseph, C. Sudha Kartha, Study on
the photoconductive properties of charge carriers in donor-acceptor copolymer P(EDOT-
FL) and P(EDOT-FL):PCBM blend, Synth. Met. 233 (2017) 52–57.
6
]
[7]
L. Smilowitz, N.S. Sariciftci, R. Wu, C. Gettinger, A.J. Heeger, F. Wudl, Photoexcitation
spectroscopy of conducting polymer-C60 composites: Photoinduced electron transfer,
Phys. Rev. B. 47 (1993) 13835–13842.
[
[
[
8]
H. Ishida, H.Y. Low, A Study on the Volumetric expansion of benzoxazine based
phenolic resin, Macromolecules. 30 (1997) 1099–1106.
B. Kiskan, N.N. Ghosh, Y. Yagci, Polybenzoxazine based composites as high
performance materials, Polym. Int. 60 (2011) 167–177.
9]
10] L.C. Lin, H.J. Yen, C.J. Chen, C.L. Tsai, G.S. Liou, Novel triarylamine based
12

ACCEPTED MANUSCRIPT
polybenzoxazines with a donor–acceptor system for polymeric memory devices, Chem.
Commun. 50 (2014) 13917–13920.
[
11] C. Aydogan, B. Kiskan, S.O. Hacioglu, L. Toppare, Y. Yagci, Electrochemical
manipulation of adhesion strength of polybenzoxazines on metal surfaces: from strong
adhesion to dismantling, RSC Adv. 4 (2014) 27545.
[12] J.A. Cid, Y.X. Wang, H. Ishida, Cationic Polymerization of Benzoxazine Monomers by
Boron Trifluoride Complex, Polym. Polym. Compos. 7 (1999) 409–420.
[
13] R. Dhanya, V.C. Kishore, K. Sreekumar, C.S. Kartha, R. Joseph, Photophysical and
Electrochemical Investigations on Photoconducting Poly(6-tert-butyl-3,4-dihydro-2H-1,3-
benzoxazine), Macromol. Symp. 277 (2009) 112–118.
[
14] H. Kimura, A. Matsumoto, K. Ohtsuka, Studies on new type of phenolic resin Curing
reaction of bisphenolA based benzoxazine with epoxy resin using latent curing agent and
the properties of the cured resin, Journ Appl Polym Sci. 109 (2008) 1248–1256..
15] C.S. Liao, J.S. Wu, C.F. Wang, F.C. Chang, Modification of polymer substrates with low
surface free energy material by low-temperature cured polybenzoxazine, Macromol.
Rapid Commun. 29 (2008) 52–56.
[
[16] F. Kasapoglu, I. Cianga, Y. Yagci, T. Takeichi, Photoinitiated Cationic Polymerization of
Monofunctional Benzoxazine, J. Polym. Sci. Part A Polym. Chem. 41 (2003) 3320–3328.
[17] P. Chutayothin, H. Ishida, Cationic Ring-Opening Polymerization of 1 , 3-Benzoxazinesꢀ:
Mechanistic Study Using Model Compounds, Macromolecules. 43 (2010) 4562–4572.
[18] H. Ishida, D.P. Sanders, Regioselectivity of the ring-opening polymerization of
monofunctional alkyl-substituted aromatic amine-based benzoxazines, Polymer, 42 (2001)
3
115–3125.
[
[
[
19] V.C. Kishore, R. Dhanya, K. Sreekumar, R. Joseph, C.S. Kartha, Spectral distribution of
photocurrent in poly(6-tert-butyl-3-methyl-3,4-dihydro-2H-1,3-benzoxazine), Synth. Met.
1
58 (2008) 676–680.
20] A. C. Arango, S. A. Carter, P.J. Brock, Charge transfer in photovoltaics consisting of
interpenetrating networks of conjugated polymer and TiO nanoparticles, Appl. Phys. Lett.
4 (1999) 1698–1700.
2
7
21] W. Huang, W. L. Yu, H. Meng, J. Pei, S.F.Y. Li, New Series of Blue-Light-Emitting
Polymers Constituted of 3-Alkylthiophenes and 1,4-Di(1,3,4-oxadiazolyl)phenylene,
Chem. Mater. 10 (1998) 3340–3345..
[
[
[
22] O. Ostroverkhova, W.E. Moerner, Organic Photorefractivesꢀ: Mechanisms , Materials ,
and Applications, Chem. Rev. 104 (2004) 3267–3314.
23] Y. Zhang, T. Wada, H. Sasabe, Carbazole photorefractive materials, J. Mater. Chem. 8
(1998) 809–828.
24] V.C. Kishore, Development Of Photorefractive Polymersꢀ: Evaluation of photoconducting
and electro-optic properties, Ph.D. Thesis, Cochin University of Science and Technology,
Kochi, Kerala (2008).
[
[
[
25] J. Thomas, C.W. Christenson, P.A. Blanche, M. Yamamoto, R.A. Norwood, N.
Peyghambarian, Photoconducting polymers for photorefractive 3D display applications,
Chem. Mater. 23 (2011) 416–429.
26] Y. Zhang, T. Wada, L. Wang, H. Sasabe, Main-Chain Polymers with Nonlinear Optical
Chromophores as a Slipped Shoulder-to-Shoulder Arrangement, Polym. J. 29 (1997) 685–
6
92.
27] B. Kiskan, F. Dogan, Y.Y. Durmaz, Y. Yagci, Synthesis , Characterization and
13

ACCEPTED MANUSCRIPT
Thermally- Activated Curing of Azobenzene-Containing Benzoxazines, Des. Monomers
Polym. 11 (2008) 473–482.
[
28] R. Dhanya, Development Of Photorefractive Polymersꢀ: Synthesis And Characterization
Of Polymers With Donor-pi-Acceptor Groups, Ph.D. Thesis, Cochin University of
Science and Technology, Kochi, Kerala (2008).
[
[
[
29] R. Dalton, Y. Shi, W.H. Steier, New polymers with large and stable second-order
nonlinear-optical effects, Macromolecules. 24 (1991) 5421–5428.
30] Y. Wang, H. Ishida, Synthesis and properties of new thermoplastic polymers from,
Macromolecules. 33 (2000) 2839–2847.
31] H.Y. Low, H. Ishida, Mechanistic study on the thermal decomposition of
polybenzoxazines: Effects of aliphatic amines, J. Polym. Sci. Part B Polym. Phys. 36
(1998) 1935–1946.
[
[
[
32] E. Bundgaard, F.C. Krebs, Low band gap polymers for organic photovoltaics, Sol. Energy
Mater. Sol. Cells. 91 (2007) 954–985.
33] D. Ayuk, M. Egbe, C.P. Roll, E. Birckner, U. Grummt, R. Stockmann, E. Klemm, Side
Chain Effects in Hybrid PPV / PPE Polymers, Macrolmolecules. 2 (2002) 3825–3837.
34] K. Vandewal, A. Gadisa, W.D. Oosterbaan, S. Bertho, F. Banishoeib, I. Van Severen, L.
Lutsen, T.J. Cleij, D. Vanderzande, J. V. Manca, The relation between open-circuit
voltage and the onset of photocurrent generation by charge-transfer absorption in polymer:
Fullerene bulk heterojunction solar cells, Adv. Funct. Mater. 18 (2008) 2064–2070.
35] J. Cabanillas-Gonzalez, T. Virgili, G. Lanzani, S. Yeates, M. Ariu, J. Nelson, D.D.C.
Bradley, Photophysics of charge transfer in a polyfluorene/violanthrone blend, Phys. Rev.
B - Condens. Matter Mater. Phys. 71 (2005) 1–8.
[
[36] J. L. Bredas, J.E. Norton, J. Cornil, V. Coropceanu, Molecular understanding of organic
solar cells: the challenges., Acc. Chem. Res. 42 (2009) 1691–1699.
[37] Z. K. Chen, W. Huang, L. H. Wang, E. T. Kang, B.J. Chen, C.S. Lee, S.T. Lee, A family
of electroluminescent silyl-substituted poly(
characterization, and structure−property relationships, Macromolecules. 33 (2000) 9015–
025.
38] J. Sworakowski, J. Ulanski, 4 Electrical properties of organic materials, Physical Chem.
9 (2003) 87–125.
39] V.C. Kishore, R. Dhanya, C.S. Kartha, K. Sreekumar, R. Joseph, Photoconductivity in
molecularly doped poly(methylmethacrylate) sandwich cells, J. Appl. Phys. 101 (2007).
40] J.C. Scott, L.T. Pautmeier, W.E. Moerner, Photoconductivity studies of photorefractive
polymers, J. Opt. Soc. Am. B. 9 (1992) 2059.
41] B. Lynn, P.A. Blanche, N. Peyghambarian, Photorefractive polymers for holography, J.
Polym. Sci. Part B Polym. Phys. 52 (2014) 193–231.
42] J.A. Osaheni, S.A. Jenekhe, N. York, J. Perlstein, Photogeneration of Charge Carriers in
Bilayer Assemblies of Conjugated Rigid-Rod Polymers, J. Phys. Chem. 98 (1994) 12727–
p
phenylenevinylene)s: synthesis,
9
[
[
[
[
[
9
1
2736.
[43] L. Onsager, Initial recombination of ions, Phys. Rev. 54 (1938) 554–557.
14

ACCEPTED MANUSCRIPT
Highlights
‹
Photoconducting, non conjugated p-aminoazobenzene based polybenzoxazine was
synthesized successfully via solventless, cationic ring opening polymerization.
‹
‹
Polymer was characterized by optical and electrochemical methods.
The dependence of photocurrent on intensity of illumination and applied electric
field was investigated.
‹
Achieved good internal photocurrent efficiency and photoconductive sensitivity in
AZO-PBZ: PCBM blend.
