Undeniably, the photoconversion efficiency of the pho-
tovoltaic devices is relatively low. We attribute this to the
small Schottky junction area as well as the long distance the
photogenerated carriers have to travel, which are pre-
determined by the device configurations. In this connection,
graphene suspension that compose of small graphene sheets
(0.5–5 lm) was placed at the interspace of the SiNW array
before the transfer of MLG film [Fig. 2(e)], in order to facili-
tate carrier separation and transport by enlarging the contact
area. Indeed, C1 exhibits a much improved short-circuit cur-
rent density (Jsc) of 154.5 lA cmꢀ2 [Fig. 2(f)], nearly seven
times of that of A2. Accordingly, a large ˛ value of 2.15% is
achieved for this device. It should be mentioned that the fill
factors (FF) of our MLG/SiNW devices (0.19-0.26) are still
much lower than the commercial Si solar cells (ꢂ0.80). The
load resistance comes from the MLG film and the electrode
contact might be responsible for the low value.
FIG. 3. (Color online) Photoresponse of devices A4 (a) and B2 (b) at zero
bias. (c) and (d) are energy diagrams of p-MLG/n-SiNW and n-MLG/p-
SiNW Schottky junctions upon light illumination, respectively. UG/USi and
EFG/EFSi denote the work functions and Fermi energy levels of graphene/
SiNW. vSi is the electron affinity of silicon. EC and EV are the conduction
band and valence band of silicon, respectively.
In conclusion, Schottky junction solar cells composed of
MLG films and SiNW arrays were fabricated. Devices with
both p-MLG/n-SiNW and n-MLG/p-SiNW structures were
investigated and they show pronounced photovoltaic effects
under the light illumination. Optimization to the devices
leads to a photoconversion efficiency of 2.15%. The simple
and low-cost fabrication process of the MLG/SiNW Schottky
junctions makes it a promising candidate for future high-
performance solar cell applications.
operate at zero bias voltage. Besides the fast rise edge, a
slow rise edge is observed for device B2. Doping induced
defects in the graphene is likely responsible for this result
since the trap centers have to be filled upon light illumination
before the system can finally reach equilibrium.14
Figs. 3(c) and 3(d) show the energy band diagrams of
p-MLG/n-SiNW and n-MLG/p-SiNW, respectively. As a
result of the formation of Schottky barrier at the MLG/SiNW
interface, partial carriers in SiNWs tend to move to the gra-
phene side and consequently the energy levels near the
SiNW surface will bend upward (for n-SiNW) or downward
(for p-SiNW), causing the formation of space-charge region
and built-in electric field near the MLG/SiNW interface.
Upon light illumination, the photogenerated electron-hole
pairs will be separated within the built-in field region, and
the resulted free electrons and holes will move towards
opposite directions, which results in the generation of the
photocurrent. This model suggests that the MLG films serve
not only as transparent electrodes but also as important
active layers in the devices.
This work was supported by the National Natural Sci-
ence Foundation of China (Nos. 60806028, 51172151,
20901021, 61106010, 21101051), the Program for New Cen-
tury Excellent Talents in University of the Chinese Ministry
of Education (NCET-08-0764), the Major Research Plan of
the National Natural Science Foundation of China (No.
91027021), and National Basic Research Program of China
(No. 2012CB932400).
1E. Garnett and P. D. Yang, Nano Lett. 10, 1082 (2010).
2J. S. Jie, W. J. Zhang, K. Q. Peng, G. D. Yuan, C. S. Lee, and S. T. Lee,
3V. Sivakov, G. Andr, A. Gawlik, A. Berger, J. Plentz, F. Falk, and S. H.
4K. Q. Peng, X. Wang, X. L. Wu, and S. T. Lee, Nano Lett. 9, 3704 (2009).
5J. S. Huang, C. Y. Hsiao, S. J. Syu, J. J. Chao, and C. F. Lin, Sol. Energy
It is noted that though longer SiNW array is beneficial
to the light trapping and absorption, which is essential for
high-performance solar cells, it does not follow that increase
in length will necessarily lead to higher photoconversion ef-
ficiency, considering the severe surface carrier recombina-
tion induced by the large amount of surface defects.1 This
can explain well why the devices made of SiNW array with
medium length (A2, A4) display the highest efficiency. Fur-
thermore, the device performance is also associated with the
electrical properties of the MLG films. As discussed before,
HNO3 treatment or N-doping on the MLG films can increase
the Schottky barrier by improving the graphene’s conductiv-
ity, which will further cause the broadening of the space-
charge region in SiNW and the strengthening of the built-in
field. As a result, the photogenerated carriers could be sepa-
rated and transport more efficiently, giving rise to the higher
photoconversion efficiency.
6X. M. Li, H. W. Zhu, K. L. Wang, A. Y. Cao, J. Q. Wei, C. Y. Li, Y. Jia,
Z. Li, X. Li, and D. H. Wu, Adv. Mater. 22, 2743 (2010).
7G. F. Fan, H. W. Zhu, K. L. Wang, J. Q. Wei, X. M. Li, Q. K. Shu, N.
8R. R. Nair, P. Blake, A. N. Grigorenko, K. S. Novoselov, T. J. Booth, T.
Stauber, N. M. T. Peres, and A. K. Geim, Science 320, 1308 (2008).
9M. L. Zhang, K. Q. Peng, X. Fan, J. S. Jie, R. Q. Zhang, S. T. Lee, and N.
10X. S. Li, W. W. Cai, J. H. An, S. Y. Kim, J. H. Nah, D. X. Yang, R. Piner,
A. Velamakanni, I. W. Jung, E. Tutuc, S. K. Banerjee, L. Colombo, and R.
S. Ruoff, Science 324, 1312 (2009).
11D. C. Wei, Y. Q. Liu, Y. Wang, H. L Zhang, L. P. Huang, and G. Yu,
12A. Reina, X. T. Jia, J. Ho, D. Nezich, H. Son, V. Bulovic, M. S. Dressel-
13S. K. Bae, H. K. Kim, Y. B. Lee, X. F. Xu, J. S. Park, Y. Zheng, J.
Balakrishnan, T. Lei, H. R. Kim, Y. I. Song, Y. J. Kim, K. S. Kim, B.
Ozyilmaz, J. H. Ahn, B. H. Hong, and S. Iijima, Nat. Nanotechnol. 10,
1038 (2010).
