Dendritic structures incorporating P, S, and Si
SYNTHESIS
AND
CHARACTERIZATION
OF
DENDRITIC
STRUCTURES
INCORPORATING PHOSPHORUS, SULFUR, AND SILICON
1
,2
1,2
1,2
1,2
Clément Padié , Aurélien Hameau , Carine Duhayon , Jean-Pierre Majoral , Anne-Marie
1
,2,*
Caminade
1
CNRS, LCC (Laboratoire de Chimie de Coordination), 205 route de Narbonne, BP 44099,
F-31077 Toulouse Cedex 4, France.
2
Université de Toulouse, UPS, INPT, F-31077 Toulouse Cedex 4, France.
*
Corresponding
E-mail
addresses:
clement.padie@gmail.com
(C.
Padié);
aurelien.hameau@lcc-toulouse.fr (A. Hameau); carine.duhayon@lcc-toulouse.fr (C.
Duhayon); jean-pierre.majoral@lcc-toulouse.fr (J.P. Majoral); anne-marie.caminade@lcc-
toulouse.fr (A.M. Caminade);
Dedicated to the memory of Prof. Dr. Reinhard Schmutzler
Abstract
Two new families of small phosphorus-containing dendrons, having as core either a phenol
protected by a t-butyldimethylsilyl group, or a terminal alkyne protected by a trimethylsilyl
group have been synthesized. Both families comprise P, S, and Si (and other elements) in their
structure. The structure of one of the smallest dendron, having a P(S)Cl terminal group, has
2
1
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
been determined by X ray crystallography, showing an almost planar arrangement of a large part
of the structure. The P(S)Cl terminal group is particularly suitable for further functionalization,
2
as illustrated by the grafting of amines, aldehydes, and dansyl derivatives. These functions were
grafted thanks to the reactivity of amines and phenols in basic conditions, demonstrating the
compatibility of these reactions with the presence of the protecting groups. Deprotection
attempts proved to be difficult, in particular for the purification of the deprotected products. All
1
13
31
compounds have been characterized at least by H, C, and P NMR.
Keywords
Dendron, dendrimer, protection/deprotection, phosphorus
2
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
INTRODUCTION
Dendrimers are hyperbranched macromolecules which have induced an increasing interest over
years, mainly due to their precisely defined structure, and the easy functionalization of their
1
2
terminal groups for diverse applications. In particular the so-called “dendrimer effect” may
modify the properties of the terminal functions, when considered alone or linked to a dendrimer.
In most cases, all the terminal groups of a dendrimer are identical. However, it is often desirable
to have two types (or more) of terminal groups, for instance a fluorescent group together with a
3
drug and water-solubilizing functions. In many cases, a stochastic functionalization on the
4
surface of the dendrimer is carried out to have multiple types of functions. Such approach is
paradoxical, as the synthesis of dendrimers is tedious to obtain pure compounds, whereas the
stochastic functionalization in the last step affords a mixture of compounds. Furthermore, the
batch-to-batch inconsistencies of such stochastic approach may also induce inconsistencies in the
5
biological response. Thus, it is highly desirable to develop tools for the precise diversification of
the terminal groups of dendrimers. Several approaches can be proposed, but dendrons (dentritic
wedges) have been used very early to diversify the terminal groups of dendrimers, by grafting
6
them to a core.
7
We are specialized since a long time in the synthesis of phosphorus-containing dendrimers.
Indeed, phosphorus is a very precious tool for the synthesis and the characterization of such
8
,9
complex molecules. With specific surface functionalizations, these phosphorus-containing
1
0,11
12
dendrimers have many properties, in particular for catalysis,
for materials, and above all for
1
3-15
16
biology.
We have already synthesized dendrons for obtaining Janus dendrimers (two faces
3
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
1
7
18
obtained by associating two dendrons by their core), or complex molecular architecture. We
report here the synthesis of new small dendrons, which were tentatively designed to be grafted to
the core of dendrimers, in order to obtain two types of functions in dendritic molecules. We have
synthesized dendrons in which the function at the core is protected by a silyl group, and the
surface functions can afford either solubility in water, or the possibility to continue the growing
of the dendron, or fluorescence properties. The protected function at the core of the dendrons is
either a phenol, particularly suitable for reacting with PCl functions, or a terminal alkyne,
2
suitable for Sonogashira couplings with halogenated aromatics, or for click chemistry.
RESULTS AND DISCUSSION
Trimethylsilyl chloride reacts readily with alcohols and phenols, but the trimethylsilylethers are
too susceptible to solvolysis to be used as efficient protecting groups. However, the t-
4
19
butyldimethylsilyloxy group is ca. l0 times more hydrolytically stable, and is widely used as
protecting group. The protected 4-hydroxybenzaldehyde 1 is classically obtained by reaction
2
0
with t-butyldimethylchlorosilane. The condensation of 1 with the phosphorhydrazide 2 affords
easily the dendron 3-G (Scheme 1). This reaction generates water, but no hydrolysis on the
1
P(S)Cl function is observed. This stability towards water in the absence of base is in perfect
2
agreement with all our previous observations concerning this function in the chemistry of
7
,8,13,18
dendrimers.
Compound 3-G is in particular characterized by the presence of a singlet in
1
3
1
P NMR (δ = 63.3 ppm). The disappearance of the singlet corresponding to the aldehyde of 1 in
1
H NMR (δ = 9.87 ppm) on behalf of the appearance of another singlet (δ = 7.71 ppm)
corresponding to the CH = N group of dendron 3-G is characteristic of the condensation. It has
1
4
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
2
1-23
been shown that the P(S)Cl groups have a versatile reactivity with amines.
As an illustration
2
of this reactivity, the reaction with N,N-diethylethylenediamine has been attempted. Such
reaction was previously carried out on the terminal groups of several generations of phosphorus
dendrimers, to afford ammonium terminal groups, the tertiary amines being used for trapping
1
2,24
HCl generated by the substitution reaction on the P(S)Cl functions.
The resulting
2
compounds are most generally soluble in water and not in organic solvents. For practical
purposes, in the case of the reactivity of compound 3-G , we preferred to avoid the presence of
1
ammonium groups, to keep the solubility in organic solvents for reagents and products. Thus the
substitution reaction is carried out in the presence of potassium carbonate, for trapping HCl.
Dendron 4-G is obtained in this way (Scheme 1). This compound is in particular characterized
1
3
1
by the appearance of a new singlet in P NMR at δ = 71.4 ppm (Δδ = +8.1 ppm relative to 3-
G1).
The deprotection of the phenol of dendron 4-G has been attempted by adding 1.3 equiv. of
1
2
5
tetrabutylammonium fluoride (TBAF overnight at room temperature). No clear change could
1
be detected on the H NMR spectrum, which displayed the presence of large quantities of silyl
derivatives after work-up. However, the cleavage of the protecting group is clearly detected by
1
3
1
C{ H} NMR, with the presence of a new signal at 115.9 ppm for the carbon ortho to the OH
group, instead of 120.5 ppm for the carbon ortho to the OSi group in 4-G . Despite several
1
attempts to remove the t-butyldimethylsilyl derivatives from the reaction mixture, the
purification was unsuccessful, thus another approach to have a protected group at the core of
dendrons was attempted.
5
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
The new starting compound is the 4-ethynylbenzaldehyde, protected by a trimethylsilyl group on
2
6
the terminal alkyne (compound 5), terminal alkynes react easily with alkene halides or arene
2
7
halides by Sonogashira couplings. Compound 5 was obtained by Sonogashira coupling
2
8
between p-bromobenzaldehyde and trimethylsilylacetylene. The condensation reaction between
5
and the phosphorhydrazide 2 affords readily the dendron 6-G (Scheme 2).
1
This dendron is characterized by NMR as was 3-G , but it was also possible to grow single
1
crystals suitable for X-ray diffraction. The X-ray diffraction structure of dendron 6-G is shown
1
in Figure 1; the crystallographic data, the bond lengths and bond angles are gathered in Tables 1,
2
, and 3, respectively. At first glance, most part of the molecule is almost flat, from Si to S,
including also the carbon C10 linked to N2 (Figure 1B). The main deviations from the plane
defined by the carbon atoms of the aromatic ring are 0.31 Å for Si(1), 0.53 Å for P(1), and 0.35
Å for S(1). N2 is planar (sum of angles around N2 = 360°), and the N2-P1 bond length is short
(1.637 Å); it corresponds more to a double bond than to a single bond. Such behavior was
already observed in other X-ray diffraction structure of phosphorhydrazone-containing dendritic
2
9-32
structures,
and contributes to the planarity of the structure. The most acute angle in the
structure is the Cl1-P1-Cl2 angle (99.82°); this value is also comparable to that found in the
previously reported structures having such function.
Dendron 6-G is the starting point for the synthesis of two other dendrons, by using the well-
1
3
3-36
established reactivity of phenols with the P(S)Cl function,
in the presence of bases. The first
2
phenol used is 4-hydroxybenzaldehyde (7), which is one of the building blocks for the classical
3
7,38
growing of the phosphorhydrazone dendrimers.
The reaction carried out in the presence of
6
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
cesium carbonate, affords readily dendron 8-G (Scheme 3). This dendron is in particular
1
3
1
characterized by P NMR, which displays a signal at δ = 60.1 ppm. The difference with the
signal of the starting compound (δ = 62.7 ppm for 6-G ) is relatively small, but an intermediate
1
signal at ca 69 ppm, corresponding to the monosubstitution, was observed during the monitoring
of the reaction.
Dendron 6-G was also used as starting material for the grafting of dansyl derivatives. Such
1
3
,39
derivative was chosen as fluorescent dendritic compounds are of particular interest.
We have
already synthesized the phenol dansyl compound 9, and used it for the synthesis of several types
4
0,41
of fluorescent dendritic structures.
The reaction with dendron 6-G is carried out in the
1
3
1
presence of cesium carbonate as the base, to afford dendron 10-G (Scheme 3). The P NMR
1
spectrum of 10-G displays a singlet at δ = 62.4 ppm. In this case also, an intermediate signal at
1
ca 69 ppm was observed during the course of the reaction, corresponding to the
monosubstitution; this signal disappeared progressively, on behalf of the increase of the signal
corresponding to the full substitution.
Several attempts have been carried out for the deprotection of the alkyne group of dendrons 8-G1
4
2
43
and 10-G , using classical methods. Potassium carbonate in methanol, or TBAF in THF
1
induces the degradation of the product (cleavage of some P-O-Aryl groups) before the end of the
4
4
deprotection. Cesium fluoride and crown ether in THF induce no reaction.
EXPERIMENTAL
General
7
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
All manipulations were carried out with standard high-vacuum and dry-argon techniques. The
solvents were freshly dried and distilled (THF and diethylether over sodium/benzophenone,
pentane and CH Cl over phosphorus pentoxide). Preparative chromatography was performed
2
2
1
13
31
with Merck Kieselgel. H, C, and P NMR spectra were recorded with Bruker AC 200,
AC250, ARX250 spectrometers. All spectra were measured at 25°C in the indicated deuterated
solvents. Proton and carbon chemical shifts (δ) are reported in ppm and coupling constants (J)
are reported in Hertz (Hz). The signals in the spectra are described as s (singlet), d (doublet), t
31
(
triplet), and m (multiplet). References for NMR chemical shifts are 85% H PO for P NMR
3 4
1
13
and SiMe for H and C NMR. The numbering used for NMR assignments is depicted in Figure
4
20
30 28
41
2
. Compounds 1, 2, 5, and 9 were synthesized according to methods previously reported.
Synthesis of dendron 3-G1.
A solution [0.20 mol/L] of compound 2 in chloroform (130 mL, 26 mmol) was added at 0°C to a
solution of compound 1 (4.85 g, 21.0 mmol) in dichloromethane (20 mL). The resulting solution
was stirred for 2 h. at room temperature, then concentrated to a few mL. This concentrated
solution was purified by column chromatography on silica gel, with dichloromethane as eluent.
The solution was evaporated to dryness, then the resulting powder was dissolved in pentane, and
left slowly evaporated, to afford dendron 3-G as a white powder in 56% yield.
1
3
1
1
1
3
-G : P{ H} NMR (CDCl ): δ = 63.3 (s) ppm. H NMR (CDCl ): δ = 0.26 (s, 6H, CH Si), 1.04
1 3 3 3
3
3
2
(
s, 9H, CH C), 3.50 (d, J = 14.3 Hz, 3H, CH NP), 6.92 (d, J = 8.6 Hz, 2H, C ), 7.67 (d,
3 HP 3 HH 0
3
3
13
1
JHH = 8.6 Hz, 2H, C ), 7.71 (s, 1H, CH = N) ppm. C{ H} NMR (CDCl ): δ = -4.4 (s, CH Si),
0
3
3
2
2
4
1
8.3 (s, CCH ), 25.7 (s, CCH ), 31.7 (d, J = 13.2 Hz, CH NP), 120.5 (s, C ), 127.5 (s, C ),
3 3 CP 3 0 0
8
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
3
3
1
1
28.9 (s, C ), 141.9 (d, J = 20 Hz, CH = N), 157.8 (s, C ) ppm. MS (DCI/NH ) m/z = 397
0 CP 0 3
+
[
M+1]
Synthesis of dendron 4-G1
N,N-diethylethylenediamine (1.35 g, 8.2 mmol) was added at 0°C to a solution of dendron 3-G1
1.500 g, 3.77 mmol) in THF (25 mL), containing K CO (3.75 g, 27.1 mmol). The resulting
(
2
3
mixture was stirred overnight at room temperature, then filtered. The resulting solution was
evaporated to dryness. The residue was dissolved in toluene (25 mL) and evaporated to dryness
(
3 times), then in CH Cl (3 times) to eliminate the slight excess of N,N-diethylethylene diamine.
2 2
Dendron 4-G was obtained as a white powder in 99% yield.
1
3
1
1
1
4
-G : P{ H} NMR (CDCl ): δ = 71.4 (s) ppm. H NMR (CDCl ): δ = 0.18 (s, 6H, CH Si), 0.96
1 3 3 3
3
(
s, 9H, CH C), 1.01 (t, J = 7 Hz, 12H, CH CH N), 2.63 (m, 12H, CH N(CH CH ), 3.04 (m,
3 HH 3 2 2 2 3
3
3
4
2
H, CH NP), 3.16 (d, J = 10 Hz, 3H, CH NP), 4.15 (br s, 2H, NH), 6.79 (d, J = 8.6 Hz,
2 HP 3 HH
2
0
3
3
13
1
H, C ), 7.46 (br s, 1H, CH = N), 7.50 (d, J = 8.6 Hz, 2H, C ) ppm. C{ H} NMR (CDCl ):
HH
0
3
2
δ = -3.6 (s, CH Si), 11.2 (s, CH CH ), 19.4 (s, CCH ), 25.6 (s, CCH ), 30.4 (d, J = 11 Hz,
3
2
3
3
3
CP
3
2
0
CH NP), 38.3 (s, CH NP), 46.4 (s, CH CH ), 53.1 (d, J = 7.5 Hz, CH CH NP), 120.5 (s, C ),
3
2
2
3
CP
2
2
4
3
0
3
1
1
26.5 (s, C ), 128.2 (s, C ), 137.3 (d, J = 12 Hz, CH = N), 158.7 (s, C ) ppm.
0
CP
0
Synthesis of dendron 6-G1.
A solution [0.24 mol/L] of compound 2 in chloroform (10.5 mL, 2.52 mmol) was added at 0°C
to a solution of compound 5 (0.500 g, 2.47 mmol) in chloroform (5 mL). The resulting solution
was stirred overnight at room temperature, then evaporated to dryness. The residue was
9
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
dissolved in a minimum amount of pentane, and cooled to induce the crystallization of 6-G as
1
colorless crystals in 75% yield. A single crystal obtained in this way was suitable for X-ray
diffraction studies.
3
1
1
1
6
-G : P{ H} NMR (CDCl ): δ = 62.7 (s) ppm. H NMR (CDCl ): δ = 0.31 (s, 9H, CH Si), 3.48
1 3 3 3
3
3
2
4
(
d, J = 13.8 Hz, 3H, CH NP), 7.51 (d, J = 8.4 Hz, 2H, C ), 7.63 (d, J = 2.4 Hz, 1H, CH
HP 3 HH 0 HP
3
3
13
1
=
N), 7.67 (d, J = 8.4 Hz, 2H, C ) ppm. C{ H} NMR (CDCl ): δ = 0.0 (CH Si), 31.9 (d,
HH 0 3 3
2
1
2
0
3
J = 13.3 Hz, CH NP), 96.6 (s, Ca), 104.7 (s, Cb), 124.8 (s, C ), 127.2 (s, C ), 132.3 (s, C ),
CP
3
0
0
4
3
1
34.0 (s, C ), 141.0 (d, J = 18.7 Hz, CH = N) ppm.
0 CP
Synthesis of dendron 8-G1.
THF (20 mL) was added to a mixture of dendron 6-G (0.500 g, 1.37 mmol), of 4-
1
hydroxybenzaldehyde 7 (0.350 g, 2.87 mmol), and cesium carbonate (1.00 g, 3.07 mmol). The
resulting mixture was stirred overnight at room temperature. The suspension was filtered over
Celite, then the solution was evaporated to dryness. The resulting powder was washed 3 times
with 25 mL of a mixture diethylether/pentane (1:1), affording dendron 8-G as a white powder in
1
6
5% yield.
3
1
1
1
8
-G : P{ H} NMR (CDCl ): δ = 60.1 (s) ppm. H NMR (CDCl ): δ = 0.25 (s, 9H, CH Si), 3.40
1 3 3 3
3
3
2
3
(
d, J = 10.8 Hz, 3H, CH NP), 7.47 (d, J = 8.4 Hz, 4H, C ), 7.59 (d, J = 8.4 Hz, 2H,
HP 3 HH 1 HH
2
0
4
3
3
0
3
C ), 7.65 (d, J = 1.2 Hz, 1H, CH = N), 7.68 (d, J = 8.4 Hz, 2H, C ), 7.84 (d, J = 8.4
HP
HH
HH
3
13
1
2
Hz, 4H, C ) ppm. C{ H} NMR (CDCl ): δ = 0.0 (CH Si), 33.0 (d, J = 13.3 Hz, CH NP),
1
3
3
CP
3
2
1
2
3
9
6.4 (s, Ca), 104.7 (s, Cb), 122.0 (s, C ), 124.4 (s, C ), 126.8 (s, C ), 131.5 (s, C ), 132.4 (s,
1 0 0 1
10
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
3
0
4
0
4
3
2
C ), 133.7 (s, C ), 134.4 (s, C ), 140.0 (d, J = 13.8 Hz, CH = N), 155.2 (d, J = 7.3 Hz,
1
CP
CP
1
1
+
+
C ), 190.7 (s, CHO) ppm. MS (DCI/NH ) m/z = 535 [M+H] , 552 [M+NH ] .
3
4
Synthesis of dendron 10-G1.
A solution of dendron 8-G (0.250 g, 0.68 mmol) in THF (5 mL) was added to a suspension of
1
compound 9 (0.540 g, 1.44 mmol) and cesium carbonate (0.500g, 1.54 mmol) in THF (30 mL).
The resulting mixture was stirred at room temperature for two days. This mixture was then
filtered over Celite, and the solution was evaporated to dryness. The resulting powder was
purified by column chromatography on silica gel, with a gradient of polarity for the eluent, from
ethylacetate/hexane (1:1) to ethylacetate/1% methanol. Dendron 10-G was isolated as a yellow
1
powder in 40% yield.
3
1
1
1
1
2
3
0-G : P{ H} NMR (CDCl ): δ = 62.4 (s) ppm. H NMR (CDCl ): δ = 0.30 (s, 9H, CH Si),
1 3 3 3
3
3
.58 (t, J = 6.2 Hz, 4H, CH Ar), 2.84 (s, 12H, N(CH ) ), 3.10 (t, J = 6.5 Hz, 4H, CH N),
HH
2
3 2
HH
2
3
3
2
1
.30 (d, J = 10.2 Hz, 3H, CH NP), 5.28 (br s, 2H, NH), 6.84 (d, J = 8.2 Hz, 4H, C ), 6.99
HP
3
HH
3
3
1
3
2
0
(
d, J = 8.2 Hz, 4H, C ), 7.11 (d, J = 7.8 Hz, 2H, H ), 7.48 (m, 6H, C , 2H ), 7.65 (m,
HH
HH
Dns
Dns
3
0
3
13
1
3
H, C , CH = N), 8.22 (m, 4H, 2H ), 8.51 (d, J = 8.4 Hz, 2H, H ) ppm. C{ H} NMR
Dns
HH
Dns
2
(
CDCl ): δ = 0.0 (s, CH Si), 33.1 (d, J = 12.7 Hz, CH NP), 35.1 (s, CH Ar), 44.3 (s, CH N),
3
3
CP
3
2
2
2
4
1
5.4 (s, N(CH ) ), 96.0 (s, Ca), 104.9 (s, Cb), 115.3 (s, C ), 118.8 (s, C ), 121.3 (s, C ),
3 2 Dns Dns 1
1
2
0
3
23.2 (s, C ), 126.8 (s, C ), 128.5 (s, C ), 129.5 (s, C ), 129.7 (s, C ), 129.8 (s, C ), 130.4
0
Dns
Dns
1
Dns
3
4
4
3
(
s, C ), 132.3 (s, C ), 134.8 (s, C ), 134.9 (s, C ), 135.0 (s, C ), 139.1 (d, J = 10 Hz, CH
Dns 0 Dns 0 1 CP
2
1
=
N), 149.2 (d, J = 7.1 Hz, C ), 151.9 (s, C ) ppm.
CP 1 Dns
11
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Methods of data collection and structure solving and refinement
Intensity data were collected at 180K on an IPDS STOE diffractometer. Structure was solved by
direct methods using SIR92, and refined by full-matrix least-squares procedures using the
programs of CRYSTALS. Atomic scattering factors were taken from the International tables for
X-ray Crystallography. All non-hydrogen atoms were refined anisotropically. Hydrogen atoms
were refined using a riding model. Absorption corrections were introduced using the program
MULTISCAN.
CCDC 1410508 contains the supplementary crystallographic data for this paper. These data can
be obtained free of charge via www.ccdc.cam.ac.uk/retrieving.html (or from the Cambridge
Crystallographic Data Centre, 12, Union Road, Cambridge, B2 1EZ, UK; fax +44 1223 336033;
or deposit@ccdc.cam.ac.uk).
CONCLUSION
We have synthesized two new families of small phosphorus-containing dendrons, having as core
either a phenol protected by a t-butyldimethylsilyl group, or a terminal alkyne protected by a
trimethylsilyl group. The structure of one of the smallest dendron, having a P(S)Cl terminal
2
group, has been determined by X ray crystallography. The P(S)Cl terminal group is particularly
2
suitable for further functionalization, as illustrated by the grafting of amines (potentially
protonable for inducing solubility in water), aldehydes (potentially usable for continuing the
growing of the dendron), and dansyl derivatives (potentially usable as fluorescent marker). This
work demonstrates that the known reaction of the P(S)Cl functions with amines and with
2
12
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
phenols in basic conditions is compatible with the presence of the protecting groups at the core.
Unfortunately, the deprotection of the core was difficult. In the case of the t-
butyldimethylsilyloxy group, the deprotection is quantitative with tetrabutylammonium fluoride,
but the t-butyldimethylsilyl derivatives are very difficult to remove from the reaction mixture. In
the case of the trimethylsilyl group protecting the alkyne, despite 3 different attempts,
degradation of the dendrons was observed together with the deprotection. It is clear that other
protection and deprotection methods have to be found, but the concept of using dendrons for the
specific functionalization of dendrimers remains an interesting target for the precise
functionalization of dendrimers with two or more types of functions.
ACKNOWLEDGMENTS
We thank the CNRS for financial support, and also the COST action CM1302 SIPs.
13
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
REFERENCES
[
1] Caminade, A.-M.; Turrin, C.-O.; Laurent, R.; Ouali, A.; Delavaux-Nicot, B.; Editors
Dendrimers: Towards Catalytic, Material and Biomedical Uses; John Wiley & Sons Ltd.:
Chichester, UK, 2011.
[
2] Caminade, A. M.; Ouali, A.; Laurent, R.; Turrin, C. O.; Majoral, J. P. Chem. Soc. Rev. 2015,
4, 3890-3899.
4
[
[
3] Caminade, A. M.; Hameau, A.; Majoral, J. P. Chem.-Eur. J. 2009, 15, 9270-9285.
4] Quintana, A.; Raczka, E.; Piehler, L.; Lee, I.; Myc, A.; Majoros, I.; Patri, A. K.; Thomas, T.;
Mule, J.; Baker, J. R. Pharm. Res. 2002, 19, 1310-1316.
5] Thomas, T. P.; Huang, B. H.; Choi, S. K.; Silpe, J. E.; Kotlyar, A.; Desai, A. M.; Zong, H.;
Gam, J.; Joice, M.; Baker, J. R. Mol. Pharm. 2012, 9, 2669-2676.
[
[
[
6] Hawker, C. J.; Frechet, J. M. J. Macromolecules 1990, 23, 4726-4729.
7] Launay, N.; Caminade, A. M.; Lahana, R.; Majoral, J. P. Angew. Chem.-Int. Edit. Engl. 1994,
3
3, 1589-1592.
[
[
8] Majoral, J. P.; Caminade, A. M.; Maraval, V. Chem. Commun. 2002, 2929-2942.
9] Maraval, V.; Caminade, A.M.; Majoral, J.P.; Blais, J.C. Angew. Chem. Int. Ed. 2003, 42,
1
822-1826.
10] Keller, M.; Colliere, V.; Reiser, O.; Caminade, A. M.; Majoral, J. P.; Ouali, A. Angew.
Chem. Int. Ed. 2013, 52, 3626-3629.
11] Neumann, P.; Dib, H.; Caminade, A. M.; Hey-Hawkins, E. Angew. Chem. Int. Ed. 2015, 54,
11-314.
[
[
3
14
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
[
12] Feng, C. L.; Zhong, X. H.; Steinhart, M.; Caminade, A. M.; Majoral, J. P.; Knoll, W. Small
008, 4, 566-571.
13] Griffe, L.; Poupot, M.; Marchand, P.; Maraval, A.; Turrin, C. O.; Rolland, O.; Metivier, P.;
Bacquet, G.; Fournie, J. J.; Caminade, A. M.; Poupot, R.; Majoral, J. P. Angew. Chem. Int. Ed.
007, 46, 2523-2526.
14] Hayder, M.; Poupot, M.; Baron, M.; Nigon, D.; Turrin, C. O.; Caminade, A. M.; Majoral, J.
P.; Eisenberg, R. A.; Fournie, J. J.; Cantagrel, A.; Poupot, R.; Davignon, J. L. Sci. Transl. Med.
011, 3, 11.
15] Caminade, A. M.; Fruchon, S.; Turrin, C. O.; Poupot, M.; Ouali, A.; Maraval, A.; Garzoni,
M.; Maly, M.; Furer, V.; Kovalenko, V.; Majoral, J. P.; Pavan, G. M.; Poupot, R. Nature Comm.
015, in press DOI: 10.1038/ncomms8722.
16] Caminade, A. M.; Laurent, R.; Delavaux-Nicot, B.; Majoral, J. P. New J. Chem. 2012, 36,
17-226.
17] Fuchs, S.; Pla-Quintana, A.; Mazeres, S.; Caminade, A. M.; Majoral, J. P. Org. Lett. 2008,
0, 4751-4754.
18] Maraval, V.; Laurent, R.; Donnadieu, B.; Mauzac, M.; Caminade, A. M.; Majoral, J. P. J.
Am. Chem. Soc. 2000, 122, 2499-2511.
19] Sommer, L. H. Stereochemistry, Mechanism and Silicon, McGraw-Hill, New York, N. Y.,
965, pp 132, 138.
20] Kaburagi, Y.; Osajima, H.; Shimada, K.; Tokuyama, H.; Fukuyama, T. Tetrahedron Lett.
004, 45, 3817-3821.
21] Slany, M.; Caminade, A. M.; Majoral, J. P. Tetrahedron Lett. 1996, 37, 9053-9056.
2
[
2
[
2
[
2
[
2
[
1
[
[
1
[
2
[
15
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
[
22] Lartigue, M. L.; Slany, M.; Caminade, A. M.; Majoral, J. P. Chem.-Eur. J. 1996, 2, 1417-
426.
23] Franc, G.; Badetti, E.; Colliere, V.; Majoral, J. P.; Sebastian, R. M.; Caminade, A. M.
Nanoscale 2009, 1, 233-237.
24] Loup, C.; Zanta, M. A.; Caminade, A. M.; Majoral, J. P.; Meunier, B. Chem.-Eur. J. 1999,
, 3644-3650.
1
[
[
5
[
[
[
25] Corey, E. J.; Venkateswarlu, A. J. Am. Chem. Soc. 1972, 94, 6190-6191.
26] Sonogashira, K.; Tohda, Y.; Hagihara, N. Tetrahedron Lett. 1975, 4467-4470.
27] Takahashi, S.; Kuroyama, Y.; Sonogashira, K.; Hagihara, N. Synthesis-Stuttgart 1980, 627-
6
30.
[
[
28] Thorand, S.; Krause, N. J. Org. Chem. 1998, 63, 8551-8553.
29] Lartigue, M. L.; Donnadieu, B.; Galliot, C.; Caminade, A. M.; Majoral, J. P.; Fayet, J. P.
Macromolecules 1997, 30, 7335-7337.
30] Lartigue, M. L.; Launay, N.; Donnadieu, B.; Caminade, A. M.; Majoral, J. P. Bull. Soc.
Chim. Fr. 1997, 134, 981-988.
31] Larre, C.; Donnadieu, B.; Caminade, A. M.; Majoral, J. P. Chem.-Eur. J. 1998, 4, 2031-
036.
32] Riegert, D.; Pla-Quintana, A.; Fuchs, S.; Laurent, R.; Turrin, C. O.; Duhayon, C.; Majoral,
J. P.; Chaumonnot, A.; Caminade, A. M. Eur. J. Org. Chem. 2013, 2013, 5414-5422.
33] Koprowski, M.; Sebastian, R. M.; Maraval, V.; Zablocka, M.; Cadierno, V.; Donnadieu, B.;
Igau, A.; Caminade, A. M.; Majoral, J. P. Organometallics 2002, 21, 4680-4687.
[
[
2
[
[
16
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
[
34] Mongin, O.; Pla-Quintana, A.; Terenziani, F.; Drouin, D.; Le Droumaguet, C.; Caminade,
A. M.; Majoral, J. P.; Blanchard-Desce, M. New J. Chem. 2007, 31, 1354-1367.
35] Routaboul, L.; Vincendeau, S.; Turrin, C. O.; Caminade, A. M.; Majoral, J. P.; Daran, J. C.;
Manoury, E. J. Organomet. Chem. 2007, 692, 1064-1073.
36] Rolland, O.; Griffe, L.; Poupot, M.; Maraval, A.; Ouali, A.; Coppel, Y.; Fournie, J. J.;
Bacquet, G.; Turrin, C. O.; Caminade, A. M.; Majoral, J. P.; Poupot, R. Chem.-Eur. J. 2008, 14,
836-4850.
37] Launay, N.; Caminade, A. M.; Lahana, R.; Majoral, J. P. Angew. Chem.-Int. Edit. Engl.
994, 33, 1589-1592.
[
[
4
[
1
[
[
38] Launay, N.; Caminade, A. M.; Majoral, J. P. J. Organomet. Chem. 1997, 529, 51-58.
39] Brauge, L.; Caminade, A. M.; Majoral, J. P.; Slomkowski, S.; Wolszczak, M.
Macromolecules 2001, 34, 5599-5606.
40] Fuchs, S.; Pla-Quintana, A.; Mazeres, S.; Caminade, A. M.; Majoral, J. P. Org. Lett. 2008,
0, 4751-4754.
41] Hameau, A.; Fuchs, S.; Laurent, R.; Majoral, J. P.; Caminade, A. M. Beilstein J. Org. Chem.
011, 7, 1577-1583.
[
1
[
2
[
[
42] Ziessel, R.; Suffert, J.; Youinou, M. T. J. Org. Chem. 1996, 61, 6535-6546.
43] Cavazza, C.; Fabrizi de Biani, F.; Funaioli, T.; Leoni, P.; Marchetti, F.; Marchetti, L.;
Zanello, P. Inorg. Chem. 2009, 48, 1385-1397.
44] Abele, E.; Rubina, K.; Abele, R.; Popelis, J.; Mazeika, I.; Lukevics, E. J. Organomet. Chem.
999, 586, 184-189.
[
1
17
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Table 1 Crystallographic data and refinement for dendron 6-G1
Formula
M
C H Cl N PSSi
13 17 2 2
363.32
180
Temperature K
Cryst. Syst.
Space group
a/Å
monoclinic
C 2/c
34.971(7)
6.9711(14)
15.192(3)
96.70(3)
3678.2(13)
8
b/Å
c/Å

/deg
3
V/Å
Z
µ(Mo-Kα)/mm
1
0.611
Reflections measured
Reflections unique
Parameters
14747
3516 (Rint = 0.069)
181
Reflections used in the R1 = 0.0458, wR2 =
calculations [I>1.2σ(I)] 0.0531
18
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Table 2 Selected bond lengths (Å) for dendron 6-G1.
Bond
Bond Length Bond
Å)
Bond Length Bond
(Å)
Bond Length
(Å)
(
C1 -- C2
1.211(6)
C6 -- C7
1.395(5)
C13
Si1
-- 1.843(5)
C1 -- Si1
C2 -- C3
C3 -- C4
C3 -- C8
C4 -- C5
C5 -- C6
1.832(4)
1.439(5)
1.410(6)
1.397(6)
1.379(5)
1.396(5)
C6 -- C9
C7 -- C8
C9 -- N1
1.465(5)
1.382(5)
1.281(5)
P1 -- Cl2 2.0232(15)
P1 -- Cl1 2.0162(15)
P1 -- S1
1.8936(15)
C10 -- N2 1.464(5)
C11 -- Si1 1.854(5)
C12 -- Si1 1.852(5)
P1 -- N2 1.637(3)
N2 -- N1 1.391(4)
19
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Table 3 Selected bond angles (°) for dendron 6-G1.
Bonds
Angle (°) Bonds
Angle (°)
Bonds
Angle (°)
C2 -- C1 -- Si1 177.8(4) C6 -- C7 -- C8
120.1(4)
C11 -- Si1 -- 111.9(3)
C13
C1 -- C2 -- C3 176.8(4) C3 -- C8 -- C7
121.0(4)
C12 -- Si1 -- 110.4(2)
C13
C2 -- C3 -- C4 120.9(4) C6 -- C9 -- N1
C2 -- C3 -- C8 120.2(4) Cl2 -- P1 -- Cl1
C4 -- C3 -- C8 118.9(3) Cl2 -- P1 -- S1
C3 -- C4 -- C5 119.7(4) Cl1 -- P1 -- S1
C4 -- C5 -- C6 121.2(4) Cl2 -- P1 -- N2
C5 -- C6 -- C7 119.1(3) Cl1 -- P1 -- N2
C5 -- C6 -- C9 119.0(3) S1 -- P1 -- N2
119.3(3)
99.82(7)
C1 -- Si1 -- Cl1 108.4(2)
C1 -- Si1 -- Cl2 108.3(2)
114.17(7) C1 -- Si1 -- Cl3 108.2(2)
114.78(7) C10 -- N2 -- P1 124.2(2)
105.62(13) C10 -- N2 -- N1 121.7(3)
103.92(12) P1 -- N2 -- N1
116.63(12) C9 -- N1 -- N2
113.8(2)
118.6(3)
C7 -- C6 -- C9 121.9(3) C11 -- Si1 -- 109.6(2)
C12
20
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Figure 1 A) X-ray diffraction structure of dendron 6-G (H atoms are omitted for clarity). B)
1
Other view of the structure of dendron 6-G1.
21
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Figure 2 Numbering used for the assignment of NMR signals.
22
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Scheme 1 Synthesis of dendrons 3-G and 4-G .
1
1
23
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Scheme 2 Synthesis of dendron 6-G1.
24
ACCEPTED MANUSCRIPT

ACCEPTED MANUSCRIPT
Scheme 3 Synthesis of dendrons 8-G and 10-G .
1
1
25
ACCEPTED MANUSCRIPT
