Hypervalent iodine induced oxidative cross coupling Via thiophene cation radical intermediate

Article abstract of DOI:10.3987/COM-12-S(N)39

The hypervalent iodine-induced arene cross coupling Via a singleelectron- transfer (SET) oxidation process could proceed in some extent even in heteroaromatic compounds, that is, several types thiophenes 1, using alkyl benzenes 2 as coupling partners. The structure of the obtainable heteroaromatic biaryl products could be elaborated by utilizing the known metal-catalyzed coupling technology, i.e., Negishi cross coupling, for the synthesis of multiple arylated (bi)thiophenes.

Full text of DOI:10.3987/COM-12-S(N)39

HETEROCYCLES, Vol. 86, No. 1, 2012
767
HETEROCYCLES, Vol. 86, No. 1, 2012, pp. 767 - 776. © 2012 The Japan Institute of Heterocyclic Chemistry
Received, 19th June, 2012, Accepted, 5th July, 2012, Published online, 17th July, 2012
DOI: 10.3987/COM-12-S(N)39
HYPERVALENT IODINE INDUCED OXIDATIVE CROSS COUPLING
VIA THIOPHENE CATION RADICAL INTERMEDIATE
Toshifumi Dohi, Motoki Ito, Sho Sekiguchi, Yohei Ishikado, and Yasuyuki
Kita*
College of Pharmaceutical Sciences, Ritsumeikan University, 1-1-1 Nojihigashi,
Kusatsu, Shiga, 525-8577, JAPAN
*Corresponding author. Tel.: +81-77-561-5829; fax: +81-77-561-5829; e-mail:
kita@ph.ritsumei.ac.jp (Y. Kita)
Abstract – The hypervalent iodine-induced arene cross coupling via a single-
electron-transfer (SET) oxidation process could proceed in some extent even in
heteroaromatic compounds, that is, several types thiophenes 1, using alkyl
benzenes 2 as coupling partners. The structure of the obtainable heteroaromatic
biaryl products could be elaborated by utilizing the known metal-catalyzed
coupling technology, i.e., Negishi cross coupling, for the synthesis of multiple
arylated (bi)thiophenes.
Dedicated to the Honor of Professor Ei-ichi Negishi.
The well-established cross coupling technologies using transition metal catalysts, such as the so-called
Negishi coupling and Suzuki coupling,1 are the most promising strategies to form new aryl carbon-
carbon bonds of required biary structures.2 The 1st generation cross couplings typically deal with
extensive organic halides and organometallic compounds (e.g., metal = [Zn]; Negishi, [B]; Suzuki) as
pre-functionalized and activated aryl substrates (Scheme 1, stepwise route). Recently, rapid evolution of
this area has opened a new opportunity of cross couplings with non-functionalized substrates.3 One of
them, the oxidative coupling between some unactivated aryl molecules, which only causes the loss of two
protons from two coupling substrates, has become possible using transition metal catalysts with suitable
stoichiometric terminal oxidants (Scheme 1, direct route).4 This method can avoid the stepwise route, and
decreases the steps and amount of released metal wastes classically observed in the 1st generation

768
HETEROCYCLES, Vol. 86, No. 1, 2012
couplings. Needless to say, transition metal catalysts, such as palladium, persists for aiding the reaction
progress in the latter oxidative cross coupling method, while a metal catalyst-free system, that only uses
an oxidant, providing a direct route to biaryls, is quite limited and still remains as an important challenge
in modern biaryl synthesis.
direct route
oxidation
Ar1
Ar2
Ar1
Ar2
H
+
+
H
[2H+]
mixed biaryl
stepwise
route
substitution
Ar1
Ar2
metal waste
[ML]
M
L
metal catalyst
M = metal
(Zn, B, etc.)
L = leaving group
(halogen, etc.)
Scheme 1. Arene Cross Coupling: Direct and Stepwise Routes to Biaryls. (Ar1, Ar2 = aryl)
Over the past decades, we have continually tackled the development of a new metal-catalyst-free strategy
utilizing an unique oxidation ability of hypervalent iodine reagents for the direct coupling route to
biaryls.5 Under suitable activation conditions, hypervalent iodine reagents show single-electron- transfer
(SET) oxidation abilities toward various electron-rich aromatic rings.6,7 It was also revealed that oxidative
couplings of electron-rich aromatic hydrocarbons, i.e., alkylbenzenes and phenyl ethers, smoothly
proceed via their reactive aromatic cation radicals generated in situ by the action of PhI(OCOCF3)2
[phenyliodine(III) bis(trifluoroacetate), PIFA] with Lewis acids.8 Recently, we extended the strategy for
the first time to the corresponding intermolecular cross coupling versions.9 The unprecedented formation
of the cross coupling products of naphthalenes and alkylbenzenes would well explain the exclusive
charge-transfer (CT) complexion of the naphthalene rings toward the suitably activated hypervalent
iodine reagent (Scheme 2), from which subsequent generation of the naphthalene cation radicals should
occur by the hypervalent iodine-induced SET oxidations. The nucleophilic alkylbenzenes, e.g.,
mesitylene,10 on the other hand, could attack the cationic intermediates, effectively producing the cross
coupling products. We believe that the naphthalenes and the alkylbenzenes are thus regarded as
indispensable aromatic cation radical sources and nucleophiles, respectively, for the successful cross
couplings. Based on these considerations, the possibility of the SET oxidation strategy for the cross
coupling for heteroaromatic compounds has not yet been fully investigated,11,12 though generation of

HETEROCYCLES, Vol. 86, No. 1, 2012
769
heteroaromatic cation radicals has already been confirmed in the homocoupling studies.13
BF3
BF3
F3COCO
F3COCO
F3COCO
+
I Ph
+
I
PhI(OCOCF3)2
Ph
(PIFA)
F3COCO
v.s.
+
BF3 OEt2
CT-complex
CT-complex
(favored)
selective SET
for naphthalene
- e-
coupling with
mesitylene
+
cation radical
- e-, - 2H+
Scheme 2. Hypervalent Iodine Induced SET Strategy for Oxidative Arene Cross Coupling.
In this paper, we report the examinations and results of our cross coupling based on the SET oxidation
strategy in heteroaromatic compounds, specifically, thiophenes 1. Actually, halothiophene 1a via its
cation radical was first found to be a substrate for coupling with mesitylene 2a (Eq. 1). Using 3 equiv. of
mesitylene 2a referred to the thiophene 1a, the desired cross coupling thiophene biaryl 3aa was formed in
a moderate yield (56%) under the standard condition using PIFA (1 equiv.) and BF3·Et2O (2 equiv.) in
dichloromethane (0.1 M concentration for the substrate 1a).9a However, we were also aware that the use
of an excess amount of mesitylene 2a produced a significant amount of its homocoupling dimer (ca. 20%
formation). Thus, the reaction was re-tested using a lower amount of mesitylene 2a (1.5 equiv.), but the
yield of the coupling product 3aa decreased to 40%. Unfortunately, screening of the concentration,
temperature, and solvent for the reaction resulted in no considerable improvement in the ratio of the cross
coupling product 3aa versus the mesitylene homocoupling dimer. FPIFA (pentafluorophenyliodine(III)
bis(trifluoroacetate), C6F5I(OCOCF3)2) was apparently an effective reagent for inducing the biaryl
coupling reaction,9b and indeed could provide the two products, 3aa (63%) and the mesitylene
homodimer (33%), in a 96% total yield, while the selectivity decreased to 66 : 34 ratio (3aa : homodimer)
similar to the previous study in mesitylene 2a.9a

770
HETEROCYCLES, Vol. 86, No. 1, 2012
I
I
2a
(1)
+
S
hypervalent iodine reagent
conditions
S
1a
3aa
via:
I
homodimer
+
S
In spite of the low reaction yield, other alkylbenzene 2b could partially produce the cross coupling
o
product 3ab by the reaction of the halothiophene 1a under the standard conditions at -40 C (Eq. 2). In
comparison, the homocoupling problem was rather suppressed in the sterically hindered alkylbenzene 2b.
Indeed, the formation of very small amount (<5%) of homodimer was observed. Similarly, the
alkylthiophene 1b was coupled with mesitylene 2a, albeit in a lower product yield than in the case of the
halothiophene 1a (Eq. 3).
R
R
R
I
I
2a (R = Me)
2b (R = iPr)
R
(2)
S
1a
S
PIFA
BF3 OEt2
CH2Cl2, -40 oC
R
R
56% (3aa: R = Me)
30% (3ab: R = iPr)
2a
(3)
S
S
PIFA
1b
BF3 OEt2
CH2Cl2, -40 oC
3ba
(38%)
It is known that multiple arylated thiophenes are interesting synthetic targets being valuable in modern
organic chemistry.14 Inspired by this and expand the range of the obtainable thiophene biaryl products 3,
our coupling strategy should be utilized along with the well-known metal-catalyzed coupling technologies.
Thus, we prepared 3-arylthiophene 1c from the halothiphene 1a by the standard Negishi coupling,15a and

HETEROCYCLES, Vol. 86, No. 1, 2012
771
examined it for the hypervalent iodine-induced oxidative cross coupling in order to obtain a diarylated
thiophene product (Scheme 3). Consequently, the thiophene 1c containing a phenyl group has become a
possible entry to our cross coupling strategy, and the two coupling sequences, i.e., the Negishi coupling
followed by our metal-free coupling, could provide the diarylthiophene 3ca in only two steps from the
halothiophene 1a.
Our Cross Coupling
Negishi Coupling
I
i) Rieke Zn
2a
S
1a
S
ii) cat. Ni(dppe)Cl2
S
PIFA
BF3 OEt2
CH2Cl2, -40 oC
1c
PhI
THF
3ca
(80%)
(30%)
Scheme 3. Multiple Arylated Thiophene 3ca by Collaboration of Our Method with Negishi Coupling.
(dppe = 1,2-bis(diphenylphosphino)ethane)
Notably, bithiophenes have appeared as acceptable substrates, whose successes in oxidative coupling are
very rare and quite specific in our method (Scheme 4). One example is that the metal-free coupling
method was compatible with the alkylated bithiophene 1d15b to give a linear teraryl compound 3da (Eq.
4). The more electron-rich oxygenated bithiophene 1e, prepared by our coupling method,12 could also
couple with pentamethylbenzene 2c to give a linear teraryl compound 3ec (Eq. 5). The oxygenated
thiophene dimers and oligomers obtained in such a sequence have been found to be new applications as
important structural units of several low band gap organic materials.16 Due to the lower oxidation
potential of bithiophenes compared to the corresponding thiophene monomers, the oxidation-sensitive
bithiophene 1e should be the most problematic substrate to control its reaction in other oxidative coupling
methods. Thus, the hypervalent iodine-used case in Eq. 5 is, to our knowledge, the only successful
example to date of the oxygenated bithiophene being supplied as a successful substrate in an oxidative
cross coupling reaction.

772
HETEROCYCLES, Vol. 86, No. 1, 2012
Our Cross Coupling
Negishi Coupling
Zn powder
S
S
2a
(4)
Br
PIFA
BF3 OEt2
CH2Cl2, -40 oC
S
S
S
cat. NiCl2(PPh3)2
Et4NI
3da
(45%)
1d
THF
(31%)
Our Cross Coupling
MeO
OMe
OMe
MeO
MeO
OMe
Our Coupling ref. 12
S
S
2c
(5)
as above
S
S
S
PhI(OH)OTs
TMSBr
(CF3)2CHOH
MeO
MeO
OMe
OMe
1e
3ec
(45%)
(83%)
Scheme 4. Cross Coupling of Bithiophenes 1d and 1e.
In summary, we have evaluated in this paper a series of halo-, alkyl-, aryl-, and bi-thiophenes 1a-e, as
useful heteroaromatic coupling substrates in the cross coupling with mesitylene 2a and its analogues via
the SET oxidation processes using hypervalent iodine reagents. The obtainable aryl-aryl linked systems in
our coupling method should be further expanded when combined with the known Negishi cross coupling
technology for the expeditious access to multiple arylated thiophenes.
EXPERIMENTAL
1
Melting points (mp) are uncorrected. All H- and 13C-NMR spectra of the products were measured in
1
CDCl3. Chemical shifts of H-NMR were recorded in parts per million (ppm, ) relative to tetramethyl
silane ( = 0.00 ppm) as an internal standard. Data are reported as follows: chemical shift in ppm (),
multiplicity (s = singlet, d = doublet, sep = septet, m = multiplet), coupling constant (J) in Hz, and
integration. Chemical shifts of 13C-NMR were reported in ppm with the solvent as reference peak
(CDCl3:  = 77.0 ppm). Infrared spectra (IR) were recorded by using a Hitachi 270-50 spectrometer;
intensities of absorptions are reported in reciprocal centimeters (cm-1). High resolution mass
measurements and elemental analysis were performed by the Elemental Analysis Section of Osaka
University and the Analysis Section of Osaka University of Pharmaceutical Sciences. Flash column
chromatography was performed with Merck Silica Gel 60 (230-400 mesh) eluting with hexane and ethyl
acetate. Thin-layer chromatography (TLC) was performed on Merk Silica Gel F254 plates (0.25 mm). The
spots and bands were detected by UV light of irradiation (254, 365 nm).

HETEROCYCLES, Vol. 86, No. 1, 2012
773
Materials
Hypervalent iodine reagents, PhI(OCOCF3)2 (PIFA) and C6F5I(OCOCF3)2 (FPIFA), are commercially
available. Trimethylthiophene 1b was prepared according to literature.17 All other chemicals and solvents
for the experiments and chromatography were obtained from commercial suppliers, and used as received.
General procedure for the cross coupling reaction of thiophenes 1 using hypervalent iodine reagent
To a stirred solution of iodothiophene 1a (1.04 g, 5 mmol) and alkylbenzene nucleophile 2a (1.80 g, 15
mmol, 3 equiv.) in CH2Cl2 (0.1 M referred to 1a) was successively added BF3·Et2O (1.27 mL, 10 mmol, 2
equiv.) and PIFA (2.15 g, 5 mmol, 1 equiv.) under a nitrogen atmosphere at -40 °C. The reaction mixture
was stirred for 3 h at the same temperature, then quenched with a saturated aqueous NaHCO3 solution.
After extraction using CH2Cl2, the obtained organic layer was dried over anhydrous Na2SO4. After
filtration, removal of the solvent in vacuo followed by column chromatography of the residue gave the
pure cross coupling product, the thiophene biaryl 3aa (0.92 g, 2.8 mmol), in 56% yield.
3-Iodo-2-(2,4,6-trimethylphenyl)thiophene (3aa)
Colorless crystals; mp 120-122 °C; IR (KBr): 3101, 2914, 2729, 1735, 1608, 1473, 1440, 1373, 1334,
1224, 1136, 1031, 968, 910, 852, 790, 734, 715, 640, 553 cm-1; 1H-NMR (300 MHz, CDCl3): 2.04 (s, 6H),
2.33 (s, 3H), 6.95 (s, 2H), 7.14 (d, J = 5.1 Hz, 1H), 7.33 (d, J = 5.1 Hz, 1H) ppm; 13C-NMR (67.8 MHz,
CDCl3): 20.3, 21.2, 81.7, 127.4, 128.2, 130.5, 134.9, 138.2, 138.6, 142.1 ppm; HRMS (FAB): Calcd for
C13H13IS (M)+: 327.9783, Found 327.9794.
3-Iodo-2-[2,4,6-tris(propan-2-yl)phenyl]thiophene (3ab)
Colorless crystals; mp 82-83 °C; IR (KBr): 2959, 1606, 1458, 1382, 1361, 911, 877, 856, 743, 706, 655
cm-1; 1H-NMR (400 MHz, CDCl3): 1.09 (d, J = 6.8 Hz, 6H), 1.21 (d, J = 6.8 Hz, 6H), 1.29 (d, J = 6.8 Hz,
6H), 2.59 (sep, J = 6.8 Hz, 2H), 2.96 (sep, J = 6.8 Hz, 1H), 7.04 (s, 2H), 7.13 (d, J = 5.4 Hz, 1H), 7.31 (d,
J = 5.4 Hz, 1H) ppm; 13C-NMR (100 MHz, CDCl3): 24.1, 25.1, 30.7, 30.9, 34.5, 83.5, 121.2, 127.3, 128.2,
134.9, 142.4, 148.9, 150.0 ppm.
Trimethyl-2-(2,4,6-trimethylphenyl)thiophene (3ba)
1
Colorless crystals; mp 73-75 °C; IR (KBr): 2920, 2856, 1454, 1377, 912, 742, 711 cm-1; H-NMR (300
13
MHz, CDCl3): 1.77 (s, 3H), 2.05 (s, 9H), 2.31 (s, 3H), 2.36 (s, 3H), 6.91 (s, 2H) ppm; C-NMR (67.8
MHz, CDCl3): 12.7, 13.1, 13.3, 20.4, 21.0, 127.9, 130.9, 131.0, 132.6, 133.9, 137.3, 138.6 ppm; Anal.
Calcd for C16H20S: C, 78.63; H, 8.25; S, 13.12. Found C, 78.79; H, 8.28; S, 12.90.

774
HETEROCYCLES, Vol. 86, No. 1, 2012
3-Phenyl-2-(2,4,6-trimethylphenyl)thiophene (3ca)
Colorless crystals; mp 52-53 °C; IR (KBr): 2915, 2366, 1601, 1496, 1438, 1375, 1211, 1027, 877, 849,
769, 722, 694, 670, 658, 648 cm-1; 1H-NMR (400 MHz, CDCl3): 2.08 (s, 6H), 2.36 (s, 3H), 6.94 (s, 2H),
7.21-7.25 (m, 5H), 7.37 (d, J = 4.0 Hz, 1H), 7.45 (d, J = 4.0 Hz, 1H) ppm; 13C-NMR (100 MHz, CDCl3):
21.5, 22.1, 125.7, 127.5, 128.3, 129.2, 129.3, 129.4, 131.3, 137.4, 137.7, 138.8, 139.2, 139.3 ppm; HRMS
(EI): Calcd for C19H18S (M)+: 278.1129, Found 278.1124.
3,3’-Dimethyl-5-(2,4,6-trimethylphenyl)-2,2’-bithiophene (3da)
1
Colorless oil; IR (KBr): 2920, 2856, 1446, 1377, 848, 833, 709 cm-1; H-NMR (300 MHz, CDCl3): 2.19
(s, 9H), 2.22 (s, 3H), 2.31 (s, 3H), 6.60 (s, 1H), 6.91 (d, J = 4.8 Hz, 1H), 6.93 (s, 2H), 7.26 (d, J = 4.8 Hz,
13
1H) ppm; C-NMR (67.8 MHz, CDCl3): 14.9, 15.0, 20.7, 20.8, 21.1, 124.6, 127.9, 129.3, 129.9, 130.8,
136.0, 136.1, 137.6, 138.0, 140.8 ppm; Anal. Calcd for C16H20S: C, 73.03; H, 6.45. Found C, 73.20; H,
6.65.
3,3’,4,4’-Tetramethoxy-5-pentamethylphenyl-2,2’-bithiophene (3ec)
Pale-yellow crystals; mp 115-120 °C; IR (KBr): 3111, 2933, 1556, 1520, 1477, 1388, 1308, 1276, 1255,
1204, 1156, 1127, 1088, 1066, 1037, 997, 961, 750, 695 cm-1; 1H-NMR (400 MHz, CDCl3): 2.16 (s, 6H),
2.23 (s, 6H), 2.36 (s, 3H), 3.57 (s, 3H), 3.83 (s, 3H), 3.85 (s, 3H), 3.94 (s, 3H), 6.09 (s, 1H) ppm;
13C-NMR (100 MHz, CDCl3): 16.7, 16.9, 18.5, 57.2, 59.1, 59.9, 60.1, 94.2, 116.3, 117.9, 120.6, 129.3,
132.4, 134.2, 135.5, 142.3, 144.6, 145.0, 150.4 ppm; HRMS (FAB): Calcd for C23H28O4S2 (M)+:
432.1249, Found 432.1434.
ACKNOWLEDGEMENTS
This work was supported by a Grant-in-Aid for Scientific Research (A) and Encouragement of Young
Scientists (A) from JSPS, a Grant-in-Aid for Scientific Research on Innovative Areas “Advanced
Molecular Transformations by Organocatalysts” from MEXT, and Ritsumeikan Global Innovation
Research Organization (R-GIRO) project. T.D. also acknowledges financial support from the Asahi Glass
Foundation and the Industrial Technology Research Grant Program from NEDO of Japan. M.I. thanks
support from the Research Activity Start-up of the JSPS.
REFERENCES
1. (a) E. Negishi, Angew. Chem. Int. Ed. (Nobel Lecture), 2011, 50, 6738; (b) A. Suzuki, Angew. Chem.
Int. Ed. (Nobel Lecture), 2011, 50, 6722; (c) Metal-Catalyzed Cross-Coupling Reactions; F.
Diederich and P. J. Stang, Eds.; Wiley-VCH: New York, 2004.

HETEROCYCLES, Vol. 86, No. 1, 2012
775
2. (a) R. Noyori, Chem. Soc. Rev., 1989, 18, 187; (b) K. Narasaka, Synthesis, 1991, 1; (c) G.
Bringmann, R. Walter, and R. Weirich, Angew. Chem., Int. Ed. Engl., 1990, 29, 977; (d) G. M.
Keserú and M. Nógrádi, In Studies in Natural Products Chemistry; Atta-ur-Rahman, Ed.; Elsevier:
Amsterdam, 1998; Vol. 20, pp 263; (e) I. Cepanec, Synthesis of Biaryls, Elsevier: New York, 2004.
3. (a) G. P. McGlacken and L. M. Bateman, Chem. Soc. Rev., 2009, 38, 2447; (b) J. A. Ashenhurst,
Chem. Soc. Rev., 2010, 39, 540; (c) C. S. Yeung and V. M. Dong, Chem. Rev., 2011, 111, 1215.
4. (a) D. R. Stuart and K. Fagnou, Science, 2007, 316, 1172; (b) D. R. Stuart, E. Villemure, and K.
Fagnou, J. Am. Chem. Soc., 2007, 129, 12072; (c) T. A. Dwight, N. R. Rue, D. Charyk, R. Josselyn,
and B. DeBoef, Org. Lett., 2007, 9, 3137; (d) S. H. Cho, S. J. Hwang, and S. Chang, J. Am. Chem.
Soc., 2008, 130, 9254; (e) P. Xi, F. Yang, S. Qin, D. Zhao, J. Lan, G. Gao, C. Hu, and J. You, J. Am.
Chem. Soc., 2010, 132, 1822; (f) C.-Y. He, S. Fan, and X. Zhang, J. Am. Chem. Soc., 2010, 132,
12850; (g) Z. Wang, K. Li, D. Zhao, J. Lan, and J. You, Angew. Chem. Int. Ed., 2011, 50, 5365.
5. For our recent accounts, see: (a) Y. Kita, T. Dohi, and K. Morimoto, J. Synth. Org. Chem. Jpn., 2011,
69, 1241; (b) Y. Kita, T. Dohi, and K. Morimoto, Kagaku, 2011, 66, 12; (c) Y. Kita and T. Dohi,
Fain Kemikaru, 2011, 40, 49; (d) Y. Kita and T. Dohi, Shokubai, 2012, 54, 145.
6. Original paper: (a) Y. Kita, H. Tohma, K. Hatanaka, T. Takada, S. Fujita, S. Mitoh, H. Sakurai, and
S. Oka, J. Am. Chem. Soc., 1994, 116, 3684; Accounts: (b) Y. Kita, T. Takada, and H. Tohma, Pure
Appl. Chem., 1996, 68, 627; (c) T. Dohi, M. Ito, N. Yamaoka, K. Morimoto, H. Fujioka, and Y. Kita,
Tetrahedron, 2009, 65, 10797.
7. Selected recent reviews of hypervalent iodine reagents: (a) T. Wirth, M. Ochiai, V. V. Zhdankin, G.
F. Koser, H. Tohma, and Y. Kita, in Top. Curr. Chem.: Hypervalent Iodine Chemistry Modern
Developments in Organic Synthesis, T. Wirth (ed.), Springer-Verlag, Berlin (2003); (b) V. V.
Zhdankin and P. J. Stang, Chem. Rev., 2008, 108, 5299; (c) T. Dohi and Y. Kita, Chem. Commun.,
2009, 2073; (d) L. F. Silva, Jr. and B. Olofsson, Nat. Prod. Rep., 2011, 28, 1722; (e) V. V. Zhdankin,
J. Org. Chem., 2011, 76, 1185.
8. (a) Y. Kita, M. Gyoten, M. Ohtsubo, H. Tohma, and T. Takada, Chem. Commun., 1996, 1481; (b) T.
Takada, M. Arisawa, M. Gyoten, R. Hamada, H. Tohma, and Y. Kita, J. Org. Chem., 1998, 63,
7698; (c) H. Tohma, H. Morioka, S. Takizawa, M. Arisawa, and Y. Kita, Tetrahedron, 2001, 57,
345; (d) H. Tohma, M. Iwata, T. Maegawa, and Y. Kita, Chem. Eur. J., 2002, 8, 5377.
9. (a) T. Dohi, M. Ito, K. Morimoto, M. Iwata, and Y. Kita, Angew. Chem. Int. Ed., 2008, 47, 1301; (b)
T. Dohi, M. Ito, I. Itani, N. Yamaoka, K. Morimoto, H. Fujioka, and Y. Kita, Org. Lett., 2011, 13,
6208.
10. Polyalkyl-substituted benzenes were estimated to possess higher nucleophilicities than naphthalene:
(a) H. Mayr and A. R. Ofial, Angew. Chem., Int. Ed. Engl., 1992, 31, 1613; (b) H. Mayr and M. Patz,

776
HETEROCYCLES, Vol. 86, No. 1, 2012
Angew. Chem., Int. Ed. Engl., 1994, 33, 938.
11. Cross coupling of heteroaromatic compounds via diaryliodonium bromides were reported: (a) Y.
Kita, K. Morimoto, M. Ito, C. Ogawa, A. Goto, and T. Dohi, J. Am. Chem. Soc., 2009, 131, 1668;
(b) T. Dohi, M. Ito, N. Yamaoka, K. Morimoto, H. Fujioka, and Y. Kita, Angew. Chem., Int. Ed.,
2010, 49, 3334; (c) K. Morimoto, N. Yamaoka, C. Ogawa, T. Nakae, H. Fujioka, T. Dohi, and Y.
Kita, Org. Lett., 2010, 12, 3804.
12. The methods in ref. 11 are also applicable for the bithiophene synthesis: K. Morimoto, T. Nakae, N.
Yamaoka, T. Dohi, and Y. Kita, Eur. J. Org. Chem., 2011, 6326.
13. (a) H. Tohma, M. Iwata, T. Maegawa, Y. Kiyono, A. Maruyama, and Y. Kita, Org. Biomol. Chem.,
2003, 1, 1647; (b) T. Dohi, K. Morimoto, Y. Kiyono, A. Maruyama, H. Tohma, and Y. Kita, Chem.
Commun., 2005, 2930.
14. For known synthetic methods and utility of multiple arylated thiophenes, see: A. Rahimi, J. C.
Namyslo, M. H. H. Drafz, J. Halm, E. Huebner, M. Nieger, N. Rautzenberg, and A. Schmidt, J. Org.
Chem., 2011, 76, 7316 and references cited therein.
15. Synthesis of 3-phenylthiophene 1c by the Negishi coupling: (a) R. M. S. Maior, K. Hinkelmann, H.
Eckert, and F. Wudl, Macromolecules, 1990, 23, 1268; bithiophene 1d synthesis: (b) M. Takahashi,
K. Masui, H. Sekiguchi, N. Kobayashi, A. Mori, M. Funahashi, and N. Tamaoki, J. Am. Chem. Soc.,
2006, 128, 10930.
16. (a) P. Amaladass, J. A. Clement, and A. K. Mohanakrishnan, Tetrahedron, 2007, 63, 10363 and
references therein; (b) A. Borghese, G. Geldhof, and L. Antoine, Tetrahedron Lett., 2006, 47, 9249.
17. B. F. Crowe and F. F. Nord, J. Org. Chem., 1950, 15, 1177.
