Diselenides and benzisoselenazolones as antiproliferative agents and glutathione-S-transferase inhibitors

Article abstract of DOI:10.3390/molecules24162914

A series of variously functionalized selenium-containing compounds were purposely synthesized and evaluated against a panel of cancer cell lines. Most of the compounds showed an interesting cytotoxicity profile with compound 5 showing a potent activity on MCF7 cells. The ethyl amino derivative 5 acts synergistically with cis-platin and inhibits the GST enzyme with a potency that well correlates with the cytotoxicity observed in MCF7 cells. A computational analysis suggests a possible binding mode on the GST enzyme. As the main outcome of the present study, the ethyl amino derivative 5 emerged as a valid lead compound for further, future developments.

Full text of DOI:10.3390/molecules24162914

molecules
Article
Diselenides and Benzisoselenazolones as
Antiproliferative Agents and
Glutathione-S-Transferase Inhibitors
Dorota Krasowska 1,† , Nunzio Iraci 2,† , Claudio Santi 3 , Józef Drabowicz 1,4
,
Marcin Cieslak 5 , Julia Kaz´mierczak-Baran´ska 5, Martina Palomba 3,
Karolina Królewska-Golin´ska 5, Jakub Magiera 5 and Luca Sancineto 1,
*
1
Division of Organic Chemistry, Centre of Molecular and Macromolecular Studies, Polish Academy of
Science, Sienkiewicza, 112, 90-363 Lodz, Poland
Department of Pharmacy, University of Salerno, Via G. Paolo II 132, 84084 Fisciano, Salerno, Italy
Department of Pharmaceutical Sciences, University of Perugia, Via del Liceo 1, 06123 Perugia, Italy
Institute of Chemistry Jan Długosz University in Cze˛stochowa Cze˛stochowa,
42-200 Armii Krajowej 13/15, Poland
2
3
4
5
Division of Bioorganic Chemistry, Centre of Molecular and Macromolecular Studies, Polish Academy of
Science, Sienkiewicza, 112, 90-363 Lodz, Poland
*
†
Correspondence: sancineto.luca@gmail.com or sancinet@cbmm.lodz.pl
These authors contributed equally to this work.
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
ꢀꢁꢂꢃꢄꢅꢆ
Received: 8 July 2019; Accepted: 9 August 2019; Published: 11 August 2019
Abstract: A series of variously functionalized selenium-containing compounds were purposely
synthesized and evaluated against a panel of cancer cell lines. Most of the compounds showed an
interesting cytotoxicity profile with compound
5 showing a potent activity on MCF7 cells. The ethyl
amino derivative acts synergistically with cis-platin and inhibits the GST enzyme with a potency
5
that well correlates with the cytotoxicity observed in MCF7 cells. A computational analysis suggests
a possible binding mode on the GST enzyme. As the main outcome of the present study, the ethyl
amino derivative 5 emerged as a valid lead compound for further, future developments.
Keywords: diselenide; benzisoselenazolone; breast cancer; glutathione S-transferase
1. Introduction
Cancers and neoplastic disorders are global health threats due to a year-on-year increase in the
number of new diagnoses and deaths. The International Agency for Research on Cancer (IARC)
estimates that one-in-five men and one-in-six women worldwide will develop cancer, and that
one-in-eight men and one-in-eleven women with a history of cancer will die from their disease [1].
Just to give a brief overview, according to the World Health Organization (WHO) cancer is the second
leading cause of death globally, with an estimated 9.6 million deaths and more that 18 million of
new cases in 2018. Among women, the most frequent cancer, impacting 2.1 million individuals
yearly, is breast cancer. It also causes the greatest number of cancer-related deaths. Besides, with an
estimated 570,000 new cases in 2018, cervical cancer is the fourth most frequent cancer in women,
representing 6.6% of all female cancers [2,3]. Similarly to solid tumors, blood cancers are pandemic;
indeed, approximately every three minutes, one person in the United States (US) is diagnosed with
leukemia or lymphoma and one death every nine minutes is because of these neoplasms [4].
Globally, cancer treatments have an estimated total economic cost of 1 trillion US dollars [5].
The use of cytotoxic agents, together with radiation therapy, is still the first line of treatment for
most of solid and blood cancers. The so-called cancer chemotherapy consists of the simultaneous
Molecules 2019, 24, 2914; doi:10.3390/molecules24162914
www.mdpi.com/journal/molecules

Molecules 2019, 24, 2914
2 of 19
administration of drugs, endowed with heterogeneous mechanisms of actions, that synergistically
interact in a clear attempt to cope with the clinical problem of cancer multi drug resistance (MDR) and
tumor cell heterogeneity [6]. Unfortunately chemotherapy is linked with serious side effects that affect
the quality of life of patients in earnest. Most of the chemotherapeutic drugs, with very few exceptions,
are highly reactive and unselective compounds that target both normal and cancer cells. While normal
cells are capable of fixing the damage eventually created by chemotherapeutics, cancer cells are not,
thus making them more susceptible to the cytotoxicity [7,8].
Selenium (Se) is an essential nutritional trace element and its deficiency correlates with various
human diseases [
recently been adopted [10
as a poison [12 13]. Starting from the identification of ebselen [14] (Figure 1) as a mimic of the
9]. Its incorporation into organic molecules to develop bioactive compounds has only
,11] since, for more than half of its history, selenium has been considered
,
key antioxidant enzyme glutathione peroxidase [15], medicinal chemistry efforts have led to the
discovery of several selenium-containing compounds worthy of mention, such as ebselen, currently
under clinical investigations for a number of disorders [11,16], or ethaselen, evaluated for the
treatment of thioredoxin reductase overexpressing non-small cell lung cancers [17]. The lesser known
selenazine derivative ALT2017 (not shown), was recently investigated for the treatment of diabetes and
psoriasis [18]. Besides, several interesting examples of preclinical compounds have been reported, such
as the anti-HIV DiSeBAs [19], the sole selenium-containing NCp7 inhibitor reported to date [20,21],
the selenides carbonic anhydrase inhibitors reported by Capperucci and Supuran [22], and the
ebselen-like compounds able to inhibit bacterial urease [23], just to quote some among the most
recent examples.
selones
selenoesters
O
Se
Se
R'
R'
R'
R'
R
Se
R'
O
Yin et al.
Antunes et al.
Sanmartin, Dominguez-Alvarez et al.
benzisoselenazolones
ebselen R= Ph
OAc
O
O
Zhang, Jiang et al.
OAc
O
O
R=
OAc
N R
Se
ethaselen R=
N
Scianowsky et al.
R=
Se
diselenides
selenides
CF3
O
Cl
N
N
NH
SeR'
Se)2
Park et al.
F3C
Se)2
N
O
O
HN
N
Rizvi, Shah et al.
N
selenophenes and
selenodiazoles
R
Se
N3
Huang, Li et al.
Rodrigues et al.
N
Se
R
O
selenocyanates
SeCN
Se
Br
R
N
N
H
N
N
O
Ruan et al.
O
O
Sharma et al.
Arsenian et al.
Figure 1. Selection of Se-containing compounds preclinically profiled as anti-neoplastic agents.

Molecules 2019, 24, 2914
3 of 19
Being selenorganic compounds redox active agents, they are particularly fit for the development
of anticancer chemotherapeutics. Cancer cells are indeed characterized by the so-called Warburg
effect, i.e., an increased aerobic glycolysis that leads to high basal levels of reactive oxygen species [24].
In addition, Se and selenium-containing compounds have proved to be selectively absorbed by cancer
cells [25] and have been shown to alter cancer angiogenesis [26,27]. This body of literature represents a
strong rationale and gives reason to the number of cancer-targeting selenium-containing compounds
reported in literature. Most of them were recently reviewed by some of us [28], by Fernandez [29],
and by Domínguez-Álvarez [30], and a selection of these compounds is presented in Figure 1.
Selenoesters were reported by Sanmartin et al. in a series of papers where their synergistic
activity with marketed drugs was also tested [31
functionality of flavonoids and isocombretastatins into selone getting compounds endowed with
in vivo antineoplastic activities [33 34]. In vivo data are also available for the selenocyanate-containing
,32]; Antunes and Yin converted the keto
,
aspirin analogue developed by Sharma and coworkers [35]. The selenide functional group was exploited
by Rodriguez and Huang for the development of AZT analogues and quinazoline-based compounds,
respectively [36
diselenide functional group was fairly explored [40
,
37]. Zhang et al. [38] and Scianowski et al. [39] took inspiration from ebselen, while the
41]. Arsenian et al. developed some selenopheno
,
quinolinones [42] and, finally, the most recent paper in chronological order reports selenodiazole
analogues bioavailable enough to be tested in vivo in a model of liver tumor [43].
Glutathione S-transferases (GSTs) are a widely distributed family of enzymes with diverse
biological roles, including cell defense against oxidative stress and toxic molecules. These enzymes
exert protection by conjugating glutathione (GSH) to a wide variety of substrates the cells judge
toxic, making them suitable for further modification, and finally excreting them from the cellular
environment [44]. In cancer cells, GSTs are often overexpressed, leading to an increased detoxification
from anticancer drugs [45]. GSTs overexpression, together with efflux pumps, is the main contributor in
cancer MDR [45]. GST overproduction in cancer cells offers an opportunity for the selective activation
of prodrugs leading to high concentrations of the active principle in neoplastic districts [46]. Taken
together, these results make GST a suitable, yet poorly exploited, target for the development of
anticancer compounds or agents that act synergistically with known, marketed drugs.
In this paper we report the design and synthesis of selenium containing compounds, and their
detailed biological evaluation on cancerous and non-cancerous cellular lines. The cytotoxicity of the
best-in-class compounds was evaluated in combination with two marketed drugs and the anti-GST
activity was tested. In conclusion, a computational analysis was carried out to shed light on the
possible compound-GST interaction.
2. Results
A series of selenium-containing compounds was designed, synthesized, and then tested for their
influence on the proliferation of different cancer cell lines. As reported in Figure 2, four groups
of derivatives can be identified. In the benzyl alcohol diselenide (
weak interaction (chalcogen bond), which proved to deeply influence the biological properties
of Se-containing compounds [47 48], was present; in addition, an increased steric hindrance was
introduced in compounds 2 and 3. A different nonbonded interaction was introduced in compounds
where a disubstituted or a monosubstituted amine was placed in ortho position to the selenium.
Carbonyl-containing diselenides were included in this study. Beside compound , which had
already been reported by us with its hormetic activity [49], amides and were purposely synthesized
1), an intramolecular Se–O
,
4–6
7
–
9
7
8
9
in order to check the effect of this decoration on the anticancer activity. Finally, compounds containing
the benzisoselenazolone scaffold were prepared by taking inspiration from ebselen and ethaselen,
the latter being the most studied selenium-containing compound in anticancer research [17,50].

Molecules 2019, 24, 2914
4 of 19
OH
Se)2
O
O
benzylalcohol-derived
diselenides
Se)2
2
Se)2
3
1
N
N
N
benzylamine-derived
diselenides
H
Se)2
4
Se)2
5
Se)2
6
O
O
COOEt
O
carbonyl-
containing
diselenides
OEt
OH
N
H
Se)2
9
N
H
Se)2
8
O
Se)2
7
O
O
ebselen-like
structures
NH
Se
10
N
OEt
Se
O
11
Figure 2. Collection of compounds selected for this study.
2.1. Synthesis
As reported in Scheme 1, compound
1 was synthesized through a two-step process starting
from benzyl alcohol initially ortho lithiated with n-butyllithium in dry pentane. The lithium salt
was then treated with elemental Se to give the corresponding selenol, that spontaneously converted
into the target diselenide after oxidative work-up [51]. Compound
1
was the starting compound for
the preparation of two amino derivatives, i.e., compound and
4
5, through its conversion into the
chloride 12, then submitted to nucleophilic displacement in the presence of triethylamine as HCl
scavenger. The use of sterically demanding diisopropylamine as nucleophile under the same reaction
condition was found unsuccessful, thus compound
6 was obtained in low yield. As a result, a different
approach was developed in order to improve the yield. It consisted in the preparation of ortho-bromo
N,N-diisopropylbenzylamine followed by the metal-halogen exchange and subsequent addition of
selenium. In this way compound 6 was obtained in 64% yield.
Scheme 1. Synthesis of compound 1 and its further transformations.
Methyl and ethyl ether derivatives,
2 and 3 respectively, were achieved following the reaction
sequence illustrated in Scheme 2. Starting from the commercially available ortho-bromobenzyl alcohol,
an initial alkylation followed by the metal-halogen exchange and subsequent addition of elemental
selenium afforded the ether derivatives in good yields.

Molecules 2019, 24, 2914
5 of 19
Scheme 2. Synthesis of the ethers 2 and 3.
While compound 7 [52,53] and 9 [19] were synthesized according to previously reported procedures,
compounds 10 and 11 were prepared following the synthetic path illustrated in Scheme 3. In particular,
by treating the benzoic acid diselenide with stoichiometric amounts of thionyl chloride the diselenide
bridge was preserved and the acidic chloride was selectively obtained. It was not isolated but
directly reacted with pure methylamine, giving compound in good yield and purity. Conversely,
8,
7
8
the ebselen-like compounds 10 and 11 were obtained by using SOCl2 in ~3 molar excess in the respective
reactions in Scheme 3, after the reaction with ammonia or ethyl glycinate.
O
O
NH2Me
NH2R
SOCl2
NHMe
Cl
O
Se)2
Se)2
O
OH
8
O
Se)2
Cl
SeCl
7
NR
SOCl2
excess
Se
10 R = H
11 R = CH2COOEt
Scheme 3. Synthesis of the ethers 8, 10, and 11.
2.2. Pharmacological Evaluation
2.2.1. Cytotoxicity Screening
Selenium-containing compounds were screened for their cytotoxic properties using MTT assays.
The following cell lines were used: K562 (leukemia), HeLa (cervix carcinoma), MCF7 (breast cancer),
and non-cancerous HUVEC (human umbilical vein endothelial). Cells treated with 1% DMSO served
as a control (100% viability). Initially, the viability of cells was determined after 48 h incubation with
compounds at the concentration of 100
µM, the results are summarized in Figure 3. Unexpectedly,
we noticed that compounds and were not compatible with the MTT assay because after addition of
4
5
tetrazolium salt, they caused a concentration-dependent color development. Therefore, the MTT assay
was modified for these two compounds, i.e., after 48 h incubation with adherent cells (HeLa, MCF7)
and just before the addition of tetrazolium salt, the cell medium was replaced with a fresh one that did
not contain
were done using ATP-based luminescence assay (see materials and methods for details).
Compounds that displayed significant cytotoxicity at 100 M (i.e., reduced cancer cells survival
4 or 5. In the case of suspension K562 cells, the viability and IC50 measurements for 4 and 5
µ
by at least 50%) were further tested at different concentrations. Based on the obtained data, IC50 values
were calculated and are reported in Table 1.

Molecules 2019, 24, 2914
6 of 19
Figure 3. Cell survival [%] after 48 h incubation with test compounds at 100 µM.
Table 1. The IC50 values calculated from the dose-response curves. Cells were incubated with
compounds for 48 h. All the values are given in µM.
Compound
HeLa
K562
MCF7
HUVEC
1
2
3
4
5
8
9
10
11
11.0 ± 6.4
4.2 ± 1.3
62 ± 6.9
88 ± 9.2
20 ± 1.2 2
30 ± 1.5 2
18 ± 3.6
85 ± 8.4
22 ± 7.8
32 ± 5.7
>50
3 ± 1.4
18 ± 1.4
28 ± 1.3
18 ± 2.1 1
15 ± 4.9 1
20 ± 1.0
20 ± 1.8
18 ± 0.9
10 ± 0.9
Nd 3
3 ± 2.9
30 ± 4.0
160 ± 6.9
9 ± 1.0
>100
>100
55 ± 5.8 1
20 ± 1.9 1
>100
30 ± 2.8
21 ± 3.1
31 ± 6.0
20 ± 2.8
20 ± 2.7
15 ± 1.54
0.4 ± 0.14
>100
21 ± 5.6
20 ± 4.0
Nd 3
0.5 ± 0.01
Cis-Pt
Doxorubicin
Nd 3
1.1 ± 0.06
During MTT assay, medium was replaced before addition of tetrazolium salt; 2 Determined by ATP measurement
1
using CellTiter-Glo luminescence cell viability assay; 3 Not determined.
2.2.2. Inhibition of Glutathione S-Transferase (GST) Activity
Glutathione S-transferases (GSTs) comprise a large group of enzymes involved in the removal of
xenobiotic from cells [44
example carcinogens, environmental pollutants, or anticancer drugs), which are subsequently pumped
out of the cell. Based on reports [28 49], we hypothesized that the selenorganic compounds herein
reported might inhibit the activity of GST. Therefore, we measured the activity of purified equine
liver GST in the presence of test compounds at the concentration of 10 M. Figure 4 summarizes the
inhibitory effect of compounds on the activity of GST. Interestingly, some of them exerted a moderate
,46]. GSTs catalyze conjugation of glutathione with electrophilic substrates (for
,
µ
inhibition. This is particularly evident for compounds
activity by 30–40% (Figure 4).
1, 10, and 5, which reduced the enzymatic

Molecules 2019, 24, 2914
7 of 19
120
100
80
60
40
20
0
Figure 4. Anti-GST activity of test compounds at the concentration of 10 µM.
2.3. Molecular Docking Simulations
Given its anti-GST activity, compound
5
was selected for molecular docking simulations meant
to investigate its interaction with the enzyme. The compound was flexibly docked onto the whole
apo GST structure (PDB ID: 5DCG) using Autodock Vina [54]. Compound docked into the H-site,
embraced by residues Y7, F8, P9, V10, G12, R13, V35, W38, I104, Y108, N204, and G205 (Figure 5).
Both amine moieties of compound may engage in H-bond interaction with the protein. One is indeed
5
5
in the proximity of the hydroxyl groups of Y7 and Y108 (N-O distances 3.09Å and 4.19Å, respectively),
while the other one lies at 3.17Å from the backbone oxygen of G205. The docked conformation shows
that the geometry of the diselenide bridge permits the two aromatic rings to engage in
interactions with Y108 and F8. stacking interactions at the H-site are pretty common among H-site
binders, as they are found in several co-crystal structures [55–57].
π–π stacking
π–π
Figure 5. Left, docking-predicted binding site for compound 5 (Magenta surface). GST crystal structure
is depicted in blue (chain A) and green (chain B) cartoons. Glutathione (PDB ID: 5DJM) and cis-platin
(PDB ID: 1AQW) experimental coordinates are represented in orange and yellow, respectively. Right,
docking-predicted bound conformation of compound 5, in magenta sticks. GST crystal structure is
depicted in blue sticks and cartoons. Glutathione experimental bound conformation (PDB ID: 5DJM) is
depicted in orange sticks. Potential π–π interactions are represented by yellow dashed lines.
2.4. Synergistic Studies with Doxorubicin and Cisplatin.
Cisplatin (cis-Pt) and doxorubicin are widely used in the treatment of many cancers. These drugs
are metabolized with the aid of GSTs, resulting in their efficient removal from cells. Indeed, cancer cells

Molecules 2019, 24, 2914
8 of 19
very often overexpress GSTs and the therapeutic effect of cis-Pt or doxorubicin may be significantly
limited. This limitation could be overcome by the use of GST inhibitors. We examined whether
inhibition of GST by compound
cells were treated with increasing concentrations of cis-Pt or doxorubicin in the presence of compound
(1 M), 10 (5 M), or (5 M) for 48 h. At these concentrations, the selenorganic compounds had no
effect on the survival of K562, only compound at 5 M slightly reduced K562 survival to 85–90%
(data not shown). As shown in Figure 6, the cytotoxicity of cis-Pt against K562 cells was significantly
enhanced in the presence of , while and 10 did not show any effect. Moreover, as shown in Figure 5,
the effect of seems to be concentration dependent. On the other hand, none of the tested compounds
1, 10, or 5 would increase the toxicity of cis-Pt or doxorubicin. K562
1
µ
µ
5
µ
5
µ
5
1
5
enhanced the cytotoxicity of doxorubicin in K562 cells (data not shown).
Figure 6. Toxicity of cis-Pt in presence of compounds 1, 5, and 10.
3. Discussion
A series of a selenium-containing compounds was prepared through different methodologies
allowing the achievement of the target compounds in moderate to good yields. Looking at the synthetic
strategies, it is possible to highlight that the use of selenium as electrophile is the method of choice
for the preparation of aromatic diselenide bearing electron donating groups in ortho position to the
selenium (see Schemes 1 and 2). On the contrary, when an electron-withdrawing group is present
in the aromatic ring, the selenium containing functional group is better introduced as nucleophile.
Once obtained, some of the diselenides were functionalized through late stage reactions (see compound
4, 5, and 8) while for compounds 2, 3, and 6 selenium installation was the last reaction step, highlighting
that the synthetic tractability of some diselenides is still to be improved through the development of
novel synthetic methodologies.
All the selenium-containing compounds were assayed for their cytotoxic activity towards three
different cancer cell lines and non-cancerous HUVEC cells in a two-step approach. Initially, all of
the compounds were screened at the fixed concentration of 100 µM; then, for those displaying a
significant antiproliferative activity, the IC50 was determined. From a structure activity relationship
(SAR) standpoint, the benzisoselenazolone scaffold confirms its cytotoxic properties, here displayed by
compounds 10 and 11, endowed with a good and wide spectrum activity, which is however not selective,
being the compounds able to inhibit the proliferation of the normal HUVEC cells. The cytotoxicity is
not influenced by the substituent on the amidic nitrogen because both compounds are equivalently
potent in terms of IC50, while, when looking at the GST inhibitory activity the amidic substitution
seems to play a role, as 10 is slightly more potent than 11. Among diselenides, compound
in this experimental setting, its lack of antiproliferative activity as we previously reported [49]. Benzyl
alcohol-derived diselenides (compounds ), gave intriguing SAR information; indeed all of them
displayed an unselective activity but their potency decreases as the steric hindrance on the benzylic
oxygen increases ( OH > OMe > OEt). Compound confirmed its therapeutic potential as it was
previously tested by Ali Shah, although on different cancer cell lines [40]. Worthy to be mentioned,
compound showed a moderate activity on MCF7 cells coupled with the lack of toxicity on normal
7 confirmed,
1–3
1
2
3
1
3

Molecules 2019, 24, 2914
9 of 19
HUVEC cells (Table 1, entry 3). The steric hindrance is also important for the anti-GST activity where
compound is yet the most potent. In this regard the presence of a H-bond donor is plausibly important
for the activity as demonstrated further in the amine series (compounds ). In this series, while the
isopropyl amino derivative was inactive, compounds and displayed low micromolar potency
against the three cancer cell lines tested. As mentioned above, we found some incompatibility between
the MTT assay and compounds and 5, that initially led to an underestimation of their activity and
1
4–6
6
4
5
4
that required a slight modification of the assay protocol. This finding should be taken into account in
future investigation employing the MTT method on amino group-containing diselenides. Among this
series, the sole compound 5 inhibited GST activity to a relevant extent at 10 µM.
Ortho-amidic diselenides 8 and 9 were inactive in HeLa cells while showing an interesting activity
on leukemia and breast cancer cellular models but none of them were able to block GST activity.
When tested in combination with cis-Pt and doxorubicin on K562 cells, the GST inhibitors
1,
5
, and 10 gave contrasting results. None of them were found to exert any synergistic effect with
doxorubicin, which is however potent enough to reasonably conceal the synergistic effect of the
compounds. On the opposite, compound exerted a dose dependent synergism with cis-Pt. Indeed,
when tested at 5 M it significantly increased the drug toxicity. At this concentration the cytotoxicity
of was minimal, and the observed effect cannot be seen as additive. A plausible explanation entails
the inhibition of GST by compound 5, which in turn hampers the removal of cis-Pt from cancer
cells. Worthy to be mentioned, the anti GST activity of the amino derivative correlates well with
5
µ
5
5
the anti-cancer activity observed in MCF7 cells. Synergistic studies between selenium-containing
compounds and known antineoplastic drugs are published in literature [31], but just a few examples
report an improvement of cis-Pt potency [58,59], and compound 5 represents the first diselenide which
carries out this sort of talent. The combination of selenorganic compounds with cis-Pt is surely fruitful;
cis-Pt indeed exerts, beside the therapeutic response, severe side effects such as the ototoxicity, which
seems to be attenuated by selenium sources, as demonstrated for ebselen [60].
The computational analysis, carried out using the crystal structure of GST as a target, clearly
indicates that the compound might be hosted in the H-site of the enzyme active site stabilized by
multiple interactions. Noteworthy, the diselenide bridge docks close to the Y7 phenol group, which
has been proven to be critical for GST catalytic activity [61–63]. In addition, 5 engages in π–π stacking
interaction with Y108, which has been proven to be critical for the enzymatic activity [61] as well as a
target of covalent inhibition [64,65].
4. Materials and Methods
4.1. Cells and Cytotoxicity Assay
The HeLa (human cervix carcinoma) and K562 (leukemia) cells were cultured in RPMI 1640,
while MCF7 (breast carcinoma) was cultured in MEM medium. The media were supplemented with
antibiotics and 10% fetal calf serum. Cells were grown in a 5% CO2–95% air atmosphere. For the
cytotoxicity assay, 7
×
103 cells were seeded on each well on 96-well plate (Nunc, Roskilde, Denmark).
Human umbilical vein endothelial cells (HUVEC) were from Life Technologies and cultured in
Medium 200 with low serum growth supplement (Life Technologies, Waltham, MA, USA) according
to manufacturer’s instructions. 10
24 h later cells were exposed to the test compounds for additional 48 h. Stock solutions of test
compounds were freshly prepared in DMSO. The final concentrations of the compounds tested in the
cell cultures were: 2
×
103 cells were seeded on each well on a 96-well plate (Nunc).
×
10−1 mM, 1
×
10−1 mM, 5
×
10−2 mM, 1
×
10−2 mM, 1
×
10−3 mM, 1
×
10−4 mM.
The concentration of DMSO in the cell culture medium was 1%.
The cytotoxicity of compounds was determined by the MTT [3-(4,5-dimethylthiazol-2-yl)-2,5-
diphenyltetrazolium bromide; Sigma, St. Louis, MO, USA] assay as described [66]. Briefly, after 48 h
of incubation with compounds, the cells were treated with the MTT reagent for 2 h. MTT-formazan
crystals were dissolved in 20% SDS and 50% DMF at pH 4.7 and absorbance was read at 570 and

Molecules 2019, 24, 2914
10 of 19
650 nm on the FLUOstar Omega plate reader. Cells grown in the presence of 1% DMSO were used as a
control (100% viability). Since and interfered with MTT assay, their toxicity in HeLa and MCF7 cells
4
5
was measured as above except that after 48 h incubation and just before the addition of MTT, the cell
medium was replaced with a fresh one without compounds. In the case of K562 cells, the cytotoxicity
of 4 and 5 was measured with CellTiter-Glo luminescent cell viability assay (Promega) according to
manufacturer’s instructions. The luminescence was measured using FLUOstar Omega plate reader
(BMG Labtech, Offenburg, Germany).
The values of IC50 (the concentration of test compounds required to reduce the cell survival to 50%
of the control) were calculated from dose-response curves and used as a measure of cellular sensitivity
to a given treatment.
The effect of
was measured in K562 cells. The concentrations of cis-Pt were 3.12, 6.25, 12.5, 25, 50
doxorubicin were 0.15, 0.312, 0.625, 1.25, 2.5, 5 M. Test compounds (or DMSO as vehicle control) and
1
(at 1
µM), 10 (5
µM), and
5
(at 1.25, 2.5 or 5
µM) on the toxicity of cis-Pt or doxorubicin
µM and those of
µ
cis-Pt or doxorubicin were added to K562 cells simultaneously. Cells viability was measured 48 h later
by CellTiter-Glo luminescent cell viability assay (Promega).
4.2. GST Activity Assay
The inhibitory activity of organoselenium compounds against equine liver GST was tested using
Glutathione S-Transferase Assay Kit from Cayman Chemical (item 703302, Ann Arbore, MI, USA).
All reagents were provided in the assay kit: GST enzyme (lyophilized), assay buffer, glutathione
(GSH) and CNDB (1-chloro-2,4-dinitrobenzene). Lyophilized GST enzyme was reconstituted in water
immediately prior use according to manufacturer’s instructions. The final reaction volume was 100
The samples contained 74 L assay buffer, 10 L GSH, 10 L GST enzyme, 1 L of test compound (final
concentration 10 M) or 1 L DMSO (control) and 5 L CNDB. Blank sample contained 85 L assay
buffer, 10 L GSH and 5 L CNDB. Immediately after addition of CNDB the absorbance at 340 nm was
µL.
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
read (time zero) and subsequently every 2 min for total time of 20 min. The readings were taken by
FluoStar Omega plate reader in a kinetic mode. The activity of GST enzyme in a control sample was
calculated and expressed as 100% and used for calculation of relative inhibition by the test compounds.
4.3. Chemistry
Reactions were conducted in round bottom flask and were stirred with Teflon-coated magnetic
stirring bars. Commercially available organic and inorganic reagents were used without further
purification unless otherwise stated. Tetrahydrofuran, diethyl ether, dioxane were dried over sodium
and distilled under argon. Dichloromethane was dried over calcium hydride and distilled under argon
prior to use. Analytical thin-layer chromatography (TLC) was performed on silica gel 60 F254 precoated
aluminum foil sheets and visualized by UV irradiation or by KMnO4 staining followed by gentle
heating. Silica gel Kieselgel 60 (70–230 mesh) was used for column chromatography. NMR experiments
were conducted at 25 ◦C with a Bruker Avance 200 spectrometer (Billerica, MA, USA) operating at
200.16 MHz for 1H, or with a Bruker Avance III 500 spectrometer operating at 500.13 MHz for 1H,
1
125.76 MHz for 13C and 95.43 MHz 77Se experiments. H, 13C and 77Se chemical shifts (
δ) are reported
in parts per million (ppm), and are cited with respect to TMS (δ = 0.0 ppm), as internal standard (1H)
and the residual solvent peak of CDCl3 (
= 7.26 and 77.00 ppm in 1H and 13C-NMR, respectively) or
Ph2Se2 (77Se
= 463 ppm) as the external standard. Data are reported as: Chemical shift (multiplicity,
δ
δ
coupling constants where applicable, number of hydrogen atoms, and assignment where possible).
Abbreviations are: s (singlet), d (doublet), t (triplet), q (quartet), dd (doublet of doublet), dt (doublet of
triplet), tt (triplet of triplet), m (multiplet), br. s (broad signal). Coupling constant (J) quoted in Hertz
(Hz) to the nearest 0.1 Hz. High-resolution mass spectrometry (HRMS) measurements were performed
using Synapt G2-Si mass spectrometer (Waters, Milford, MA, USA) equipped with an APCI source and
quadrupole-Time-of-Flight mass analyzer. The mass spectrometer was operated in the positive and
negative ion detection modes with discharge current set at 4.0 µA. The heated capillary temperature

Molecules 2019, 24, 2914
11 of 19
was 350 ◦C. The results of the measurements were processed using the MassLynx 4.1 software (Waters)
incorporated with the instrument. Melting points (m.p.) were determined on Mel-Temp® apparatus
(Electrothermal, Rochford, Essex, UK) and are uncorrected.
4.3.1. Bis[2-(hydroxymethyl)phenyl] Diselenide (1)
The synthesis of di(2-hydroxybenzyl) diselenide was prepared according to the procedure reported
1
in [51]. Yield (64%). H-NMR (CDCl3)
δ: 1.80 (br. s, 1H, OH), 4.72 (s, 2H, CH2OH), 7.20 (dt, J = 1.4 and
7.6 Hz, 1H, ArH), 7.30 (dt, J = 1.4 and 7.3 Hz, 1H, ArH), 7.39 (dd, J = 1.3 and 7.5 Hz, 1H, ArH), 7.68 ppm
(dd, J = 1.2 and 7.7 Hz, 1H, ArH); 13C-NMR (CDCl3)
δ
: 65.40, 128.43, 128.84, 128.95, 130.66, 135.03,
142.10 ppm; 77Se NMR (CDCl3)
δ
: 431.74 ppm. HRMS calculated for C14H14O2Se2Na+ = 396.9222,
found =396.9224.
4.3.2. Bis[2-(chloromethyl)phenyl] Diselenide (12)
Compound 12 was prepared in 83% yield from compound
1 by using of thionyl chloride as
1
described in the literature [67]. H-NMR (CDCl3)
δ: 4,67 (s, 2H, CH2Cl), 7.23, (dt, J = 1.5 and 7.6 Hz,
1H, ArH), 7.29 (dt, J = 1.2 and 7.4 Hz, 1H, ArH), 7.38 (dd, J = 1.2 and 7.6 Hz, 1H, ArH), 7.72 ppm (dd,
J = 1.0 and 7.6 Hz, 1H, ArH); 77Se NMR (CDCl3) δ: 437.97 ppm.
4.3.3. Bis[2-(N,N-dimethylaminomethyl)phenyl] Diselenide (4)
To a solution of bis[2-(chloromethyl)phenyl] diselenide 12 (0.293 g, 0.73 mmol) in THF (4 mL) were
added triethylamine (0.2 mL, 1.45 mmol) and 2M solution of dimethylamine in THF (1.5 mL, 2.92 mmol)
under argon atmosphere. The reaction mixture was stirred at 36 ◦C for 24 h and then concentrated
under reduced pressure. The mixture was diluted with Et2O and the ethereal solution was extracted
with a 1% aqueous solution of hydrochloric acid (2
were alkalized with solid K2CO3, and extracted with dichloromethane (3
×
20 mL). The combined acidic aqueous layers
20 mL). The organic layers
×
were combined, washed with brine, dried over anhydrous magnesium sulfate and evaporated under
reduced pressure. The obtained crude product was purified by silica gel column chromatography
(hexane-ethyl acetate 10:0.5) to afford product
δ = 2.27 (s, 6H, CH3), 3.56 (s, 3H, CH2), 7.09–7,14 (m, 3H, ArH), 7.77–7.82 ppm (m, 1H, ArH); 13C-NMR
4
(0.209 g, 67%) as a yellow oil. 1H-NMR (CDCl3)
(CDCl3) δ
= 44.39, 64.64, 125.83, 128.16, 128.47, 131.42, 134.30, 139.15; 77Se NMR (CDCl3) 428.24 ppm;
HRMS calculated for [C18H25N2Se2+] = 429.0348, found = 429.0348.
4.3.4. N,N0-((Diselanediylbis(2,1-phenylene))bis(methylene))diethanamine (5)
To a solution of bis[2-(chloromethyl)phenyl] diselenide 12 (0.558 g, 1.38 mmol) in THF (15 mL)
trietylamine (0.38 mL, 2.76 mmol) and ethylamine (2 M in THF, 2.8 mL, 5.55 mmol) were added
dropwise under argon atmosphere. The reaction mixture was stirred at 50 ◦C for 2 days. After the
reaction was complete, the mixture was concentrated under reduced pressure. The resulting oil was
diluted with Et2O and the ethereal solution was extracted with a 1 M aqueous solution of hydrochloric
acid (3
with dichloromethane (2
×
20 mL). The combined acidic aqueous layers were alkalized with solid K2CO3, and extracted
20 mL). The organic layers were combined, washed with brine, dried over
×
anhydrous magnesium sulfate and the solvent was evaporated in a vacuum. The product was purified
by silica gel column chromatography (DCM-methanol 25:1 then DCM-methanol 9:1) and isolated as
1
yellow oil (0.371 g, 63% yield). H-NMR (CDCl3)
δ
= 1.12 (t, J = 7.1 Hz, 3H, CH3), 2.68 (q, J = 7.1 Hz,
2H, CH2CH3), 3.30 (s, 1H, NH), 3.92 (s, 2H, CH2N), 7.10–7.23 (m, 3H, ArH), 7.74–7.79 ppm (m, 1H,
ArH). 13C-NMR (CDCl3) = 13.96, 42.82, 52.80, 127.50, 128.77, 129.06, 133.18, 133.50, 138.12; 77Se NMR
(CDCl3) δ = 422.54 ppm; HRMS calculated for [C18H25N2Se2+] 429.0348, found = 429.0358.
δ

Molecules 2019, 24, 2914
12 of 19
4.3.5. 2-Bromo-N,N-diisopropylbenzylamine (13)
A slight modification of the previously reported procedure [68] was applied. A round bottom flask
equipped with stirring bar was charged with potassium iodide (31.3 mg, 0.19 mmol) and the solution
of 2-bromobenzyl bromide (0.471 g, 1.88 mmol) and diisopropylamine (0.65 mL, 7.54 mmol) in 2 mL of
dry dioxane was added. After being stirred at room temperature for 3 days under argon atmosphere,
the flask was fitted with the condenser and the reaction mixture was heated to 50 ◦C with continuous
stirring for 2 days. An aqueous solution of sodium bicarbonate (10 mL) and diethyl ether (10 mL)
were added to the cooled reaction mixture and the solution was extracted. The combined ethereal
phases were washed with brine, dried over anhydrous magnesium sulfate, filtered and concentrated in
vacuo to give product 13 (0.452 g) as a yellow oil in 89% yield. Spectral analysis matched with the data
reported in [69].
4.3.6. N,N0-((Diselanediylbis(2,1-phenylene))bis(methylene)) bis (N-isopropylpropan-2-amine) (6)
◦
To a solution of 13 (1.18 g, 4.37 mmol) in hexane (10 mL) cooled to
−
78 C, t-BuLi (1.7 M in
pentane, 5.1 mL) was added dropwise under argon atmosphere. The reaction mixture was stirred
for 1 h and then was allowed to reach room temperature during the next 1 h. Dry THF (10 mL) was
added to the reaction mixture, and the diluted solution was cooled to
78 ◦C when grey selenium
powder was added. The mixture was allowed to warm to room temperature, quenched with 1 M HCl
solution (20 mL) and extracted with diethyl ether. Ethereal layer was washed with additional 10 mL
of 1 M hydrochloric acid. The combined acidic aqueous layers were alkalized by slow addition of
−
potassium carbonate and the compound was extracted with ethyl acetate (5
organic extracts were dried over magnesium sulfate, filtered and concentrated in vacuo. The crude
product was purified by column chromatography (silica gel, petroleum ether-ethyl acetate 10:1) and
×
20 mL). The resulting
then recrystallized from ethyl acetate/hexane to afford product (
6
) (0.754 g) as yellow crystals in 64%
1
yield, mp = 117–118 ◦C [70]. H-NMR (CDCl3)
δ = 1.09 (d, J = 6.6 Hz, 12H, CH3), 3.10 (sept, J = 6.6
Hz, 2H, CH), 3.86 (s, 2H, CH2), 7.04–7.17 (m, 2H, ArH), 7.26–7.31 (m, 1H, ArH) 7.70–7.74 ppm (m, 1H,
ArH). 13C-NMR (CDCl3)
δ
= 20.71, 48.33, 51.46, 126.00, 127.61, 128.59, 130.37, 132.63, 141.22 ppm; 77Se
NMR (CDCl3) δ = 408.53 ppm; HRMS calculated for [C26H41N2Se2+] = 541.1600, found = 541.1605.
4.3.7. 1-Bromo-2-(methoxymethyl)benzene (14)
To a solution of 2-bromobenzyl alcohol (1.97 g, 10.53 mmol) in 10 mL of THF cooled to 0 ◦C, sodium
hydride (60% suspension in paraffin oil) (0.46 g, 11.58 mmol) was added under argon atmosphere.
The mixture was stirred for 0.5 h at this temperature and 0.5 h at room temperature additionally.
Methyl iodide (1.65 g, 11.58 mmol) was diluted with THF (4 mL) and added dropwise. The reaction
mixture was refluxed for 4 h, then it was allowed to cool to room temperature. Saturated aqueous
solution of ammonium chloride was poured into the reaction mixture, and the product was extracted
with Et2O (3
×
30 mL). The combined organic extracts were dried over magnesium sulfate, filtrated
and concentrated in vacuo. The product purified by distillation (106–108 ◦C/16 mmHg) in 82% yield as
1
a colorless oil (1.74 g). H-NMR (CDCl3)
δ
= 3.47 (s, 3H, CH3), 4.53 (s, 2H, CH2), 7.15 (dt, J = 1.7 and
7.6 Hz, 1H, ArH), 7.32 (dt, J = 7.6 and 1 Hz, 1H, ArH), 7.45–7.57 ppm (m, 2H, ArH). Spectral analysis
matched with the literature data reported in [71].
4.3.8. 1-Bromo-2-(ethoxymethyl)benzene (15)
Sodium hydride (60% in paraffine oil, 0.538 g, 13.5 mmol) was suspended in 4 mL of THF and
the suspension was cooled to 0 ◦C. At this temperature, a solution of 2-bromobenzyl alcohol (2.287 g,
12.2 mmol) in THF was added dropwise under argon. The reaction mixture was stirred at 0 ◦C for 0.5 h,
then warmed to room temperature and stirred for 0.5 h. Ethyl iodide (1.46 mL, 18.3 mmol) was added
dropwise and the mixture was heated under reflux for 6 h. An aqueous solution of ammonium chloride
(20 mL) was poured into the mixture, and the product was extracted with diethyl ether (3 × 20 mL)
.

Molecules 2019, 24, 2914
13 of 19
The combined organic phases were washed with brine, dried over magnesium sulfate and filtered.
The evaporation of the solvent followed by the distillation (120 ◦C/15 mmHg) afforded the product (15
)
1
as colorless liquid in 88% (2.32 g). H-NMR (CDCl3)
δ
= 1.29 (t, J = 7.0 Hz, 3H, CH3), 3.63 (q, J = 7.0 Hz,
2H, CH2CH3), 4.57 (s, 2H, CH2), 7.14 (dt, J = 7.6 Hz, J = 1.6 Hz, 1H, ArH), 7.32 (dt, J = 7.5 Hz, J = 1 Hz,
1H, ArH), 7.51 ppm (dt, J = 8.4 Hz, J = 1 Hz, 2H, ArH).
4.3.9. 1,2-Bis(2-(methoxymethyl)phenyl)diselane (2)
Compound
2
was prepared by following the procedure reported in [72] with few modifications.
78 ◦C
To a solution of 2-bromobenzyl methyl ether 14 (0.57 g, 2.83 mmol) in hexane (10 mL) stirred at
under argon atmosphere, t-BuLi (1.8 mL, 3.11 mmol) was added dropwise. The mixture was stirred at
−
this temperature for 0.5 h and allowed to warm to room temperature. After the addition of THF (10 mL)
and subsequent cooling to
78 ◦C, powder selenium (0.224 g, 2.83 mmol) was added. The reaction
−
mixture was stirred with warming to room temperature. An aqueous solution of ammonium chloride
(20 mL) was poured into the reaction mixture which was allowed to have contact with atmospheric
oxygen. The product was then extracted with ethyl acetate (3
were washed once with brine and dried over magnesium sulfate. The drying agent was filtered off and
×
20 mL), the combined organic layers
the solvent evaporated in vacuo to give the crude product. Its purification by silica gel chromatography
with eluent ether-petroleum ether 1:10 afforded 0.267 g of the compound (
2
) (51% yield) as dark yellow
1
oil. H-NMR (CDCl3)
δ = 3.39 (s, 3H, CH3), 4.54 (s, 2H, CH2), 7.19–7.24 (m, 2H, ArH), 7.3–7.31 (m,
2H, ArH), 7.75–7.76 ppm (m, 2H, ArH). 13C-NMR (CDCl3)
δ = 58.05, 74.77, 127.48, 128.43, 128.91,
131.81, 132.79, 138.26 ppm. 77Se NMR (CDCl3)
δ
= 414.63 ppm. HRMS calculated for [C16H19O2Se2 ]
+
= 402.9715, found = 402.9721.
4.3.10. 1,2-Bis(2-(ethoxymethyl)phenyl)diselane (3)
To a solution of 2-bromobenzyl ethyl ether 15 (1.068 g, 4.97 mmol) in hexane (25 mL) stirred at
78 ◦C under argon atmosphere, 1.7 M pentane solution of t-BuLi (5.8 mL, 9.93 mmol) was added
dropwise. The mixture was stirred at this temperature for 1 h and allowed to warm to room temperature.
−
◦
After the addition of THF (30 mL) and subsequent cooling to
−
78 C, powder selenium (0.392 g,
4.97 mmol) was added. The reaction mixture was allowed to reach room temperature and then
stirred for 18 h. An aqueous solution of ammonium chloride (50 mL) was poured into the reaction
mixture which was allowed to have contact with atmospheric oxygen. The product was extracted with
ethyl acetate (3
×
30 mL), the combined organic layers were washed once with brine and dried over
magnesium sulfate. The drying agent was filtered off and the solvent evaporated in vacuo to give the
crude product. Its purification by silica gel chromatography with eluent ether-petroleum ether 0.5:9.5
1
afforded 0.725 g of the compound (
3
) (68% yield) as an orange oil. H-NMR (CDCl3)
δ
= 1.26 (t, J =7.0
Hz, 3H, CH3), 3.56 (q, J = 7.0 Hz, 2H, CH2CH3), 4.59 (s, 2H, CH2), 7.18–7.23 (m, 2H, ArH), 7.29–7.30
(m, 2H, ArH), 7.75–7.77 ppm (m, 2H, ArH); 13C-NMR (CDCl3)
δ = 15.28, 65.82, 72.85, 127.26, 128.31,
128.79, 131.83, 132.50, 138.41 ppm; 77Se (CDCl3) = 411.53 ppm. HRMS calculated for [C18H23O2Se2+] =
431.0028, found = 431.0028.
4.3.11. 2,20-Diselanediylbis(N-methylbenzamide) (8)
To a suspension of 7 [52] (510 mg, 1.27 mmol) in dry toluene (5 mL), thionyl chloride (0.2 mL,
2.82 mmol) was added. The resulting mixture was refluxed until no gas evolution was observable
and a clear solution was formed. The unreacted thionyl chloride was evaporated in vacuo and the
residue was washed with dry toluene (three times, 3 mL each). The brown oil was solubilized in dry
THF (8 mL) and poured into a 3 neck round bottom flask then pure methylamine was added until a
precipitate was formed. The suspension was allowed to react at room temperature for 12 h. The solid
was filtrated and the filtrate was evaporated in vacuo, giving a yellow solid which was purified by
column chromatography eluting with dichloromethane: methanol 99:1. A white solid was obtained
and then recrystallized with EtOH (365 mg, 67%). Mp > 250 ◦C; 1H-NMR (DMSO-d6)
δ: 2.78 (d, J =

Molecules 2019, 24, 2914
14 of 19
4.37 Hz, 3H, NHCH3); 7.28 (t, J = 7.37 Hz, 1H, ArH); 7.34 (t, J = 7.65 Hz, 1H, ArH); 7.63 (d, J = 7.65, 1H,
ArH); 7.73 (d, J = 7.65, 1H, ArH); 8.68 (bq, J = 4.37 Hz, 1H, NHCH3) ppm. 13C-NMR (DMSO-d6)
δ:
26.89; 126.68; 128.26; 130.29; 132.28; 132.42; 133.29; 168.24 ppm. 77Se NMR (DMSO-d6)
HRMS calculated for [C16H17N2O2Se2+] = 428.9620 found = 428.9611.
δ: 441.84 ppm.
4.3.12. Benzo[d][1,2]selenazol-3(2H)-one (10)
To a suspension of 7 [52] (175 mg, 0.44 mmol) in dry toluene (3 mL), thionyl chloride (0.2 mL,
2.82 mmol) was added. The resulting mixture was refluxed until no gas evolution was observable
and a clear solution was formed. The unreacted thionyl chloride was evaporated in vacuo and the
residue was washed with dry toluene (three times, 2 mL each). The brown oil was solubilized in
dry THF (8 mL) and poured into a 3 neck round bottom flask then pure ammonia was added until a
precipitate was formed. The suspension was allowed to react at room temperature for 12 h. The solid
was filtrated and the filtrate was evaporated in vacuo giving a yellow solid which was treated with
Et2O then filtered and recrystallized from EtOH giving the target compound as a white solid (120 mg;
71% yield). Mp = 221–223 ◦C; 1H-NMR (DMSO-d6)
1H, ArH); 7.80 (dd, J = 0.72 and 7.77 Hz, 1H, ArH); 8.03 (d, J = 8.29 Hz, 1H, ArH); 9.18 (bs, 1H, NH)
δ: 7.40 (t, J = 7.79 Hz, 1H, ArH); 7.60 (t, J = 8.29 Hz,
ppm; 13C-NMR (DMSO-d6) : 125.77; 126.39; 127.40; 127.68; 131.70; 141.56; 168.89 ppm. 77Se NMR
δ
(DMSO-d6) δ: 796.71 ppm. HRMS calculated for [C7H6NOSe+] = 199.9615 found = 199.9621
4.3.13. Ethyl 2-(3-oxobenzo[d][1,2]selenazol-2(3H)-yl)acetate (11)
To a suspension of 7 [52] (400 mg, 1 mmol) in dry toluene (6 mL), thionyl chloride (0.47 mL,
6.5 mmol) was added. The resulting mixture was refluxed until no gas evolution was observable and a
clear solution was formed. The unreacted thionyl chloride was evaporated in vacuo and the residue
was washed with dry toluene (three times, 2 mL each). The brown oil was solubilized in dry THF
(8 mL) and poured into a 3 neck round bottom flask then a mixture of glycine ethyl ester hydrochloride
(360 mg, 2.5 mmol) and Et3N (1.4 mL, 10.3 mmol) was added by dropping at 0 ◦C. A suspension rapidly
formed and was allowed to react at room temperature for 12 h. The suspension was filtered and
the filtrate was evaporated in vacuo giving a yellow oil purified by column chromatography eluting
with dichloromethane:methanol 99:1. A white solid was obtained and recrystallized by EtOH, giving
330 mg of target compound (66% yield). Mp = 118–120 ◦C. 1H-NMR (CDCl3)
δ: 1.29 (t, J = 7.00 Hz, 3H,
OCH2CH3); 4.24 (q, J = 7.00 Hz, 2H, OCH2CH3); 4.59 (s, 2H, NCH2); 7.41 (t, H = 7.37 Hz, 1H, ArH); 7.60
(t, H = 7.30 Hz, 1H, ArH); 7.64 (d, J = 8.02 Hz, 1H, ArH); 8.05 (d, J = 7.80 Hz, 1H, ArH) ppm. 13C-NMR
(CDCl3) δ
: 14.17; 45.62; 61.89; 123.97; 126.06; 126.27; 128.98; 132.42; 139.01; 167.84; 168.70 ppm. 77Se
NMR (CDCl3) δ: 935.43 ppm. HRMS = calculated for [C11H12NO3Se+] = 285.9982, found = 285.9993.
4.4. Molecular Modeling
Compound
Schrödinger, LLC, New York, NY, USA, 2018) and its ionization states were predicted using Epik [73
at a pH range of 7 1; the state with the lowest ionization penalty was chosen for the following
docking studies. The docking target structure 5DCG was downloaded from the Protein Data Bank
and prepared, analogously to previously reported studies [74 75], using the Protein Preparation
5 was sketched using the Maestro GUI (Schrödinger Release 2018-4: Maestro,
]
±
,
Wizard [76]. AutoDockTools v1.5.6 [77] was used to prepare ligand and protein input files for the
docking simulations. Molecular docking simulations were performed using AutoDock Vina [54].
The search space was set as a cube (62.5 Å side) centered on the protein and including both chain A
and B. Considering the pretty big search space, exhaustiveness was set to 1000. The best scoring pose
( 7.7 kcal/mol) was considered as the predicted bound conformation. Molecular modeling pictures
−
were generated using open source PyMol (The PyMOL Molecular Graphics System, Version 1.7.0.0-1,
Schrödinger, LLC., New York city, NY, USA)

Molecules 2019, 24, 2914
15 of 19
5. Conclusions
In summary, a series of selenium-containing compounds were purposely synthesized and stepwise
tested for their cytotoxic properties; three out of eleven were eventually selected for an in depth
biological screening meant to determine their anti-GST properties and synergism with marketed
antineoplastic drugs. The enzymatic results were then investigated by computational methodologies
that suggested a possible binding mode of the most interesting compound. The results presented in
this manuscript may enlarge the SAR information of the diselenide and benzisoselenazolone class
of compounds reported in literature. As a result of this study, we have identified compound
5 as a
new lead compound endowed with a fairly potent antiproliferative activity in vitro toward MCF7
cancer cells. It was also able to potentiate the antiproliferative activity of the marketed drug cis-Pt in a
dose dependent fashion. Compound 5 surely emerges as a suitable starting point for a future drug
discovery campaign. In particular, given the availability of the experimental structural information,
a structure-based optimization, meant to fine-tune the compound activity, will be the next step of our
drug discovery program.
Author Contributions: Conceptualization, L.S. and M.C.; methodology, D.K., J.M., J.K.-B., K.K.-G. and M.P.;
software, N.I. and C.S.; validation, N.I., L.S., C.S. and J.D.; investigation, L.S., M.C. and N.I.; resources, L.S. and
C.S.; writing—original draft preparation, L.S., D.K., J.D. and M.C.; writing—review and editing, C.S. and M.P.;
supervision, L.S.; project administration, L.S. and J.D.; funding acquisition, L.S.
Funding: This project has received funding from the European Union’s Horizon 2020 research and innovation
programme under the Marie Skłodowska-Curie grant agreement No 665778 - POLONEZ funding programme,
National Science Centre, Poland - project registration number 2016/21/P/ST5/03512.
Acknowledgments: L.S. acknowledges that this project has received funding from the European Union’s Horizon
2020 research and innovation programme under the Marie Skłodowska-Curie grant agreement No 665778 -
POLONEZ funding programme, National Science Centre, Poland - project registration number 2016/21/P/ST5/03512.
CS acknowledges University of Perugia “Fondo Ricerca di base 2017”. This work was carried out under the
umbrella of the International network Selenium, Sulfur, Redox and Catalysis.
Conflicts of Interest: Authors declare no conflicts of interests.
References
1.
2.
3.
IARC. New Global Cancer Data: GLOBOCAN 2018. Available online: https://www.uicc.org/news/new-
global-cancer-data-globocan-2018 (accessed on 3 June 2019).
World Health Organization (WHO). Cacer today factsheet. Available online: http://gco.iarc.fr/today/data/
factsheets/cancers/39-All-cancers-fact-sheet.pdf (accessed on 6 March 2019).
Bray, F.; Ferlay, J.; Soerjomataram, I.; Siegel, R.L.; Torre, L.A.; Jemal, A. Global cancer statistics 2018:
GLOBOCAN estimates of incidence and mortality worldwide for 36 cancers in 185 countries. CA Cancer
J. Clin. 2018, 68, 394–424. [CrossRef] [PubMed]
4.
Leukemia and Lymphoma society Facts and Statistics of the Leukemia and Lymphoma society. Available
online: https://www.lls.org/http%3A/llsorg.prod.acquia-sites.com/facts-and-statistics/facts-and-statistics-
overview/facts-and-statistics (accessed on 9 March 2019).
5.
6.
7.
8.
9.
McGuire, S. World Cancer Report 2014. Geneva, Switzerland: World Health Organization, International
Agency for Research on Cancer, WHO Press, 2015. Adv. Nutr. 2016, 7, 418–419. [CrossRef] [PubMed]
Mokhtari, R.B.; Homayouni, T.S.; Baluch, N.; Morgatskaya, E.; Kumar, S.; Das, B.; Yeger, H. Combination
therapy in combating cancer. Oncotarget 2017, 8, 38022. [CrossRef] [PubMed]
Schirrmacher, V. From chemotherapy to biological therapy: A review of novel concepts to reduce the side
effects of systemic cancer treatment (Review). Int. J. Oncol. 2019, 54, 407–419. [PubMed]
Stout, N.L.; Sabo Wagner, S. Antineoplastic Therapy Side Effects and Polypharmacy in Older Adults With
Cancer. Top. Geriatr. Rehabil. 2019, 35, 15–30. [CrossRef]
Yang, G.Q.; Ge, K.Y.; Chen, J.S.; Chen, X.S. Selenium-related endemic diseases and the daily selenium
requirement of humans. World Rev. Nutr. Diet. 1988, 55, 98–152.
10. Lenard
ão, E.J.; Santi, C.; Sancineto, L. New Frontiers in Organoselenium Compounds; Springer International
Publishing: Cham, Switzerland, 2018.

Molecules 2019, 24, 2914
16 of 19
11. Lenardão, E.J.; Santi, C.; Sancineto, L. Bioactive Organoselenium Compounds and Therapeutic Perspectives.
In New Frontiers in Organoselenium Compounds; Springer International Publishing: Cham, Switzerland, 2018;
pp. 99–143.
12. Frost, D.V.; Olson, O.E. The Two Faces of Selenium—Can Selenophobia Be Cured? CRC Crit. Rev. Toxicol.
1972, 1, 467–514. [CrossRef]
13. Nelson, A.A.; Fitzhugh, O.G.; Calvery, H.O. Liver Tumors Following Cirrhosis Caused by Selenium in Rats.
Cancer Res. 1943, 3, 230–236.
14. Parnham, M.J.; Sies, H. The early research and development of ebselen. Biochem. Pharmacol. 2013, 86,
1248–1253. [CrossRef]
15. Müller, A.; Cadenas, E.; Graf, P.; Sies, H. A novel biologically active seleno-organic compound-1. Glutathione
peroxidase-like activity in vitro and antioxidant capacity of PZ 51 (Ebselen). Biochem. Pharmacol. 1984, 33,
3235–3239. [CrossRef]
16. NIH Clinical trials on ebselen. Available online: http://www.webcitation.org/76lXfKjpm (accessed on 10
March 2019).
17. Wang, L.; Yang, Z.; Fu, J.; Yin, H.; Xiong, K.; Tan, Q.; Jin, H.; Li, J.; Wang, T.; Tang, W.; et al. Ethaselen: A potent
mammalian thioredoxin reductase 1 inhibitor and novel organoselenium anticancer agent. Free Radic. Biol.
Med. 2012, 52, 898–908. [CrossRef]
18. NIH Clinical trials on ALT2074. Available online: http://www.webcitation.org/76lYW6zNk (accessed on 10
March 2019).
19. Sancineto, L.; Mariotti, A.; Bagnoli, L.; Marini, F.; Desantis, J.; Iraci, N.; Santi, C.; Pannecouque, C.; Tabarrini, O.
Design and Synthesis of DiselenoBisBenzamides (DISeBAs) as Nucleocapsid Protein 7 (NCp7) Inhibitors
with anti-HIV Activity. J. Med. Chem. 2015, 58, 9601–9614. [CrossRef]
20. Sancineto, L.; Iraci, N.; Tabarrini, O.; Santi, C. NCp7: Targeting a multitasking protein for next-generation
anti-HIV drug development part 1: Covalent inhibitors. Drug Discov. Today 2018, 23, 260–271. [CrossRef]
21. Iraci, N.; Tabarrini, O.; Santi, C.; Sancineto, L. NCp7: Targeting a multitask protein for next-generation
anti-HIV drug development part 2. Noncovalent inhibitors and nucleic acid binders. Drug Discov. Today
2018, 23, 687–695. [CrossRef]
22. Angeli, A.; Tanini, D.; Capperucci, A.; Supuran, C.T. Synthesis of Novel Selenides Bearing Benzenesulfonamide
Moieties as Carbonic Anhydrase I, II, IV, VII, and IX Inhibitors. ACS Med. Chem. Lett. 2017, 8, 1213–1217.
[CrossRef]
23. Macegoniuk, K.; Grela, E.; Palus, J.; Rudzin´ska-Szostak, E.; Grabowiecka, A.; Biernat, M.; Berlicki, Ł.
1,2-Benzisoselenazol-3(2H)-one Derivatives As a New Class of Bacterial Urease Inhibitors. J. Med. Chem.
2016, 59, 8125–8133. [CrossRef]
24. Misra, S.; Boylan, M.; Selvam, A.; Spallholz, J.E.; Björnstedt, M. Redox-active selenium compounds—from
toxicity and cell death to cancer treatment. Nutrients 2015, 7, 3536–3556. [CrossRef]
25. Cavalieri, R.R.; Scott, K.G.; Sairenji, E. Selenite (75Se) as a tumor-localizing agent in man. J. Nucl. Med. 1966
7, 197–208.
,
26. Jiang, C.; Ganther, H.; Lu, J. Monomethyl selenium-specific inhibition of MMP-2 and VEGF expression:
Implications for angiogenic switch regulation. Mol. Carcinog. 2000, 29, 236–250. [CrossRef]
27. Bhattacharya, A.; Seshadri, M.; Oven, S.D.; Tóth, K.; Vaughan, M.M.; Rustum, Y.M. Tumor vascular
maturation and improved drug delivery induced by methylselenocysteine leads to therapeutic synergy with
anticancer drugs. Clin. Cancer Res. 2008, 14, 3926–3932. [CrossRef]
28. Bartolini, D.; Sancineto, L.; Fabro de Bem, A.; Tew, K.D.; Santi, C.; Radi, R.; Toquato, P.; Galli, F.
Selenocompounds in Cancer Therapy: An Overview. In Advances in Cancer Research; Academic Press:
Cambridge, MA, USA, 2017; Volume 136, pp. 259–302.
29. Gandin, V.; Khalkar, P.; Braude, J.; Fernandes, A.P. Organic selenium compounds as potential
chemotherapeutic agents for improved cancer treatment. Free Radic. Biol. Med. 2018, 127, 80–97. [CrossRef]
30.
Á
lvarez-P
A Review of Their Anticancer and Chemopreventive Activity. Molecules 2018, 23, 628. [CrossRef]
31. Spengler, G.; Gajd cs, M.; Marc´, M.; Dom nguez- lvarez, E.; Sanmart n, C. Organoselenium Compounds
érez, M.; Ali, W.; Marc´, M.; Handzlik, J.; Domínguez-Álvarez, E. Selenides and Diselenides:
á
í
Á
í
as Novel Adjuvants of Chemotherapy Drugs—A Promising Approach to Fight Cancer Drug Resistance.
Molecules 2019, 24, 336. [CrossRef]

Molecules 2019, 24, 2914
17 of 19
32. Dom
ínguez-Á
lvarez, E.; Gajd
ács, M.; Spengler, G.; Palop, J.A.; Marc´, M.A.; Kiec´-Kononowicz, K.; Amaral, L.;
Moln
ár, J.; Jacob, C.; Handzlik, J.; et al. Identification of selenocompounds with promising properties to
reverse cancer multidrug resistance. Bioorg. Med. Chem. Lett. 2016, 26, 2821–2824. [CrossRef]
33. Pang, Y.; An, B.; Lou, L.; Zhang, J.; Yan, J.; Huang, L.; Li, X.; Yin, S. Design, Synthesis, and Biological Evaluation
of Novel Selenium-Containing Iso combretastatins and Phenstatins as Antitumor Agents. J. Med. Chem.
2017, 60, 7300–7314. [CrossRef]
34. Martins, I.L.; Charneira, C.; Gandin, V.; Ferreira Da Silva, J.L.; Justino, G.C.; Telo, J.P.; Vieira, A.J.S.C.;
Marzano, C.; Antunes, A.M.M. Selenium-containing chrysin and quercetin derivatives: Attractive scaffolds
for cancer therapy. J. Med. Chem. 2015, 58, 4250–4265. [CrossRef]
35. Plano, D.; Karelia, D.N.; Pandey, M.K.; Spallholz, J.E.; Amin, S.; Sharma, A.K. Design, Synthesis, and
Biological Evaluation of Novel Selenium (Se-NSAID) Molecules as Anticancer Agents. J. Med. Chem. 2016
,
59, 1946–1959. [CrossRef]
36. De Souza, D.; Mariano, D.O.C.; Nedel, F.; Schultze, E.; Campos, V.F.; Seixas, F.; da Silva, R.S.; Munchen, T.S.;
Ilha, V.; Dornelles, L.; et al. New Organochalcogen Multitarget Drug: Synthesis and Antioxidant and
Antitumoral Activities of Chalcogenozidovudine Derivatives. J. Med. Chem. 2015, 58, 3329–3339. [CrossRef]
37. An, B.; Wang, B.; Hu, J.; Xu, S.; Huang, L.; Li, X.; Chan, A.S.C. Synthesis and Biological Evaluation of
Selenium-Containing 4-Anilinoquinazoline Derivatives as Novel Antimitotic Agents. J. Med. Chem. 2018, 61,
2571–2588. [CrossRef]
38. Tang, Y.; Zhang, S.; Chang, Y.; Fan, D.; De Agostini, A.; Zhang, L.; Jiang, T. Aglycone Ebselen and
β-D-Xyloside
Primed Glycosaminoglycans Co-contribute to Ebselen
β-d-Xyloside-Induced Cytotoxicity. J. Med. Chem.
2018, 61, 2937–2948. [CrossRef]
´
39. Pacuła, A.J.; Kaczor, K.B.; Wojtowicz, A.; Antosiewicz, J.; Janecka, A.; Długosz, A.; Janecki, T.; Scianowski, J.
New glutathione peroxidase mimetics—Insights into antioxidant and cytotoxic activity. Bioorg. Med. Chem.
2017, 25, 126–131. [CrossRef]
40. Rizvi, M.A.; Guru, S.; Naqvi, T.; Kumar, M.; Kumbhar, N.; Akhoon, S.; Banday, S.; Singh, S.K.; Bhushan, S.;
Mustafa Peerzada, G.; et al. An investigation of in vitro cytotoxicity and apoptotic potential of aromatic
diselenides. Bioorg. Med. Chem. Lett. 2014, 24, 3440–3446. [CrossRef]
41. Kim, C.; Lee, J.; Park, M.-S. Synthesis of new diorganodiselenides from organic halides: Their antiproliferative
effects against human breast cancer MCF-7 cells. Arch. Pharm. Res. 2015, 38, 659–665. [CrossRef]
42. Domracheva, I.; Kanepe-Lapsa, I.; Jackevica, L.; Vasiljeva, J.; Arsenyan, P. Selenopheno quinolinones and
coumarins promote cancer cell apoptosis by ROS depletion and caspase-7 activation. Life Sci. 2017, 186,
92–101. [CrossRef]
43. Chen, Z.; Li, D.; Xu, N.; Fang, J.; Yu, Y.; Hou, W.; Ruan, H.; Zhu, P.; Ma, R.; Lu, S.; et al. Novel
1,3,4-Selenadiazole-Containing Kidney-Type Glutaminase Inhibitors Showed Improved Cellular Uptake and
Antitumor Activity. J. Med. Chem. 2019, 62, 589–603. [CrossRef]
44. Hayes, J.D.; Flanagan, J.U.; Jowsey, I.R. Glutathione Transferases. Annu. Rev. Pharmacol. Toxicol. 2005, 45,
51–88. [CrossRef]
45. Sau, A.; Pellizzari Tregno, F.; Valentino, F.; Federici, G.; Caccuri, A.M. Glutathione transferases and
development of new principles to overcome drug resistance. Arch. Biochem. Biophys. 2010, 500, 116–122.
[CrossRef]
46. Allocati, N.; Masulli, M.; Di Ilio, C.; Federici, L. Glutathione transferases: Substrates, inihibitors and pro-drugs
in cancer and neurodegenerative diseases. Oncogenesis 2018, 7, 8. [CrossRef]
47. Iwaoka, M.; Komatsu, H.; Katsuda, T.; Tomoda, S. Nature of Nonbonded Se···O Interactions Characterized
by 17 O NMR Spectroscopy and NBO and AIM Analyses. J. Am. Chem. Soc. 2004, 126, 5309–5317. [CrossRef]
48. Mukherjee, A.J.; Zade, S.S.; Singh, H.B.; Sunoj, R.B. Organoselenium chemistry: Role of intramolecular
interactions. Chem. Rev. 2010, 110, 4357–4416. [CrossRef]
49. Bartolini, D.; Commodi, J.; Piroddi, M.; Incipini, L.; Sancineto, L.; Santi, C.; Galli, F. Glutathione S-transferase
pi expression regulates the Nrf2-dependent response to hormetic diselenides. Free Radic. Biol. Med. 2015, 88,
466–480. [CrossRef]
50. Dong, C.; Zhang, L.; Sun, R.; Liu, J.; Yin, H.; Li, X.; Zheng, X.; Zeng, H. Role of thioredoxin reductase 1 in
dysplastic transformation of human breast epithelial cells triggered by chronic oxidative stress. Sci. Rep.
2016, 6, 36860. [CrossRef]

Molecules 2019, 24, 2914
18 of 19
51. Tripathi, S.K.; Patel, U.; Roy, D.; Sunoj, R.B.; Singh, H.B.; Wolmershäuser, G.; Butcher, R.J.
o-Hydroxylmethylphenylchalcogens: Synthesis, intramolecular nonbonded chalcogen· · · OH interactions,
and glutathione peroxidase-like activity. J. Org. Chem. 2005, 70, 9237–9247. [CrossRef]
52. Nascimento, V.; Ferreira, N.L.; Canto, R.F.S.; Schott, K.L.; Waczuk, E.P.; Sancineto, L.; Santi, C.; Rocha, J.B.T.;
Braga, A.L. Synthesis and biological evaluation of new nitrogen-containing diselenides. Eur. J. Med. Chem.
2014, 87, 131–139. [CrossRef]
53. Krasowska, D.; Begini, F.; Santi, C.; Mangiavacchi, F.; Drabowicz, J.; Sancineto, L. Ultrasound-assisted
synthesis of alkali metal diselenides (M2Se2) and their application for the gram-scale preparation of
2,2’-diselenobis(benzoic acid). Arkivoc 2019, 2019. [CrossRef]
54. Trott, O.; Olson, A.J. AutoDock Vina: Improving the speed and accuracy of docking with a new scoring
function, efficient optimization, and multithreading. J. Comput. Chem. 2009, 31, 455–461. [CrossRef]
55. Federici, L.; Lo Sterzo, C.; Pezzola, S.; Di Matteo, A.; Scaloni, F.; Federici, G.; Caccuri, A.M. Structural Basis
for the Binding of the Anticancer Compound 6-(7-Nitro-2,1,3-Benzoxadiazol-4-Ylthio)Hexanol to Human
Glutathione S-Transferases. Cancer Res. 2009, 69, 8025–8034. [CrossRef]
56. Harshbarger, W.; Gondi, S.; Ficarro, S.B.; Hunter, J.; Udayakumar, D.; Gurbani, D.; Singer, W.D.; Liu, Y.; Li, L.;
Marto, J.A.; et al. Structural and Biochemical Analyses Reveal the Mechanism of Glutathione S-Transferase
Pi 1 Inhibition by the Anti-cancer Compound Piperlongumine. J. Biol. Chem. 2017, 292, 112–120. [CrossRef]
57. Parker, L.J.; Ciccone, S.; Italiano, L.C.; Primavera, A.; Oakley, A.J.; Morton, C.J.; Hancock, N.C.; Bello, M.L.;
Parker, M.W. The Anti-cancer Drug Chlorambucil as a Substrate for the Human Polymorphic Enzyme
Glutathione Transferase P1-1: Kinetic Properties and Crystallographic Characterisation of Allelic Variants.
J. Mol. Biol. 2008, 380, 131–144. [CrossRef]
˙
58. Sakallı Çetin, E.; Nazırog˘lu, M.; Çig˘, B.; Övey, I.S.; Aslan Kos¸ar, P. Selenium potentiates the anticancer effect
of cisplatin against oxidative stress and calcium ion signaling-induced intracellular toxicity in MCF-7 breast
cancer cells: Involvement of the TRPV1 channel. J. Recept. Signal Transduct. 2017, 37, 84–93. [CrossRef]
59. Chakraborty, P.; Roy, S.; Bhattacharya, S. Molecular Mechanism Behind the Synergistic Activity of
Diphenylmethyl Selenocyanate and Cisplatin Against Murine Tumor Model. Anticancer. Agents Med. Chem.
2015, 15, 501–510. [CrossRef]
60. Kopke, R.D.; Liu, W.; Gabaizadeh, R.; Jacono, A.; Feghali, J.; Spray, D.; Garcia, P.; Steinman, H.; Malgrange, B.;
Ruben, R.J.; et al. Use of organotypic cultures of Corti’s organ to study the protective effects of antioxidant
molecules on cisplatin-induced damage of auditory hair cells. Am. J. Otol. 1997, 18, 559–571.
61. Lo Bello, M.; Oakley, A.J.; Battistoni, A.; Mazzetti, A.P.; Nuccetelli, M.; Mazzarese, G.; Rossjohn, J.;
Parker, M.W.; Ricci, G. Multifunctional Role of Tyr 108 in the Catalytic Mechanism of Human Glutathione
Transferase P1-1. Crystallographic and Kinetic Studies on the Y108F Mutant Enzyme. Biochemistry 1997, 36,
6207–6217. [CrossRef]
62. Kong, K.-H.; Takasu, K.; Inoue, H.; Takahashi, K. Tyrosine-7 in human class Pi glutathione S-transferase
is important for lowering the pKa of the thiol group of glutathione in the enzyme-glutathione complex.
Biochem. Biophys. Res. Commun. 1992, 184, 194–197. [CrossRef]
63. Cesareo, E.; Parker, L.J.; Pedersen, J.Z.; Nuccetelli, M.; Mazzetti, A.P.; Pastore, A.; Federici, G.; Caccuri, A.M.;
Ricci, G.; Adams, J.J.; et al. Lo Nitrosylation of Human Glutathione Transferase P1-1 with Dinitrosyl
Diglutathionyl Iron Complex in Vitro and in Vivo. J. Biol. Chem. 2005, 280, 42172–42180. [CrossRef]
64. Shishido, Y.; Tomoike, F.; Kuwata, K.; Fujikawa, H.; Sekido, Y.; Murakami-Tonami, Y.; Kameda, T.; Abe, N.;
Kimura, Y.; Shuto, S.; et al. A Covalent Inhibitor for Glutathione S-Transferase Pi (GSTP1-1) in Human Cells.
ChemBioChem 2018, 20, 900–905. [CrossRef]
65. Shishido, Y.; Tomoike, F.; Kimura, Y.; Kuwata, K.; Yano, T.; Fukui, K.; Fujikawa, H.; Sekido, Y.;
Murakami-Tonami, Y.; Kameda, T.; et al. A covalent G-site inhibitor for glutathione S-transferase Pi
(GSTP 1-1). Chem. Commun. 2017, 53, 11138–11141. [CrossRef]
66. Maszewska, M.; Leclaire, J.; Cieslak, M.; Nawrot, B.; Okruszek, A.; Caminade, A.-M.; Majoral, J.-P.
Water-Soluble Polycationic Dendrimers with a Phosphoramidothioate Backbone: Preliminary Studies of
Cytotoxicity and Oligonucleotide/Plasmid Delivery in Human Cell Culture. Oligonucleotides 2003, 13, 193–205.
[CrossRef]
67. Iwaoka, M.; Tomoda, S. Direct Observation of Intramolecular Interaction between a Divalent Selenium and
a Tertiary Amine by Means of Single Crystal X-Ray Analysis and NMR Spectroscopy. Phosphorus. Sulfur.
Silicon Relat. Elem. 1992, 67, 125–130. [CrossRef]

Molecules 2019, 24, 2914
19 of 19
68. Mohanty, A.D.; Bae, C. Mechanistic analysis of ammonium cation stability for alkaline exchange membrane
fuel cells. J. Mater. Chem. A 2014, 2, 17314–17320. [CrossRef]
69. Chirca, I.; Soran, A.; Silvestru, A.; Silvestru, C. Homoleptic organometallic compounds of heavy pnicogens.
Crystal and molecular structure of [2-(iPr2NCH2)C6H4]3M (M = Sb, Bi). Rev. Roum. Chim. 2015, 60, 643–650.
70. Bhabak, K.P.; Mugesh, G. Synthesis and Structure-Activity Correlation Studies of Secondary- and
Tertiary-Amine-Based Glutathione Peroxidase Mimics. Chem. A Eur. J. 2009, 15, 9846–9854. [CrossRef]
71. Tan, N.; Chen, Y.; Zhou, Y.; Au, C.T.; Yin, S.F. Synthesis and structure of organobismuth chlorides and triflates
containing (C,E)-chelating ligands (E=O, S) and their catalytic application in the allylation of aldehydes with
tetraallyltin. ChemPlusChem 2013, 78, 1363–1369. [CrossRef]
72. Poleschner, H.; Seppelt, K. First Detection of a Selenenyl Fluoride ArSe?F by NMR Spectroscopy: The Nature
of Ar2Se2/XeF2 and ArSe?SiMe3/XeF2 Reagents. Chem. A Eur. J. 2004, 10, 6565–6574. [CrossRef]
73. Shelley, J.C.; Cholleti, A.; Frye, L.L.; Greenwood, J.R.; Timlin, M.R.; Uchimaya, M. Epik: A software program
for pK a prediction and protonation state generation for drug-like molecules. J. Comput. Aided. Mol. Des.
2007, 21, 681–691. [CrossRef]
74. Astolfi, A.; Iraci, N.; Sabatini, S.; Barreca, M.; Cecchetti, V. p38α MAPK and Type I Inhibitors: Binding Site
Analysis and Use of Target Ensembles in Virtual Screening. Molecules 2015, 20, 15842–15861. [CrossRef]
75. Sancineto, L.; Iraci, N.; Massari, S.; Attanasio, V.; Corazza, G.; Barreca, M.L.; Sabatini, S.; Manfroni, G.;
Avanzi, N.R.; Cecchetti, V.; et al. Computer-aided design, synthesis and validation of 2-phenylquinazolinone
fragments as CDK9 inhibitors with anti-HIV-1 tat-mediated transcription activity. ChemMedChem 2013, 8,
1941–1953. [CrossRef]
76. Madhavi Sastry, G.; Adzhigirey, M.; Day, T.; Annabhimoju, R.; Sherman, W. Protein and ligand preparation:
Parameters, protocols, and influence on virtual screening enrichments. J. Comput. Aided. Mol. Des. 2013, 27,
221–234. [CrossRef]
77. Sanner, M.F. Python: A Programming Language for Software Integration and Development. J. Mol.
Graph. Model. 1999, 17, 57–61.
Sample Availability: Samples of the compounds 1–11 are available from the authors.
©
2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
