4
S. Pal, T. K. Chakraborty / Tetrahedron Letters xxx (2014) xxx–xxx
method, compound 33 was treated with PdCl2 and Et3SiH in the
presence of Et3N in CH2Cl2 to afford the seco acid 2. The reaction
was fairly clean with very negligible degraded products observed
in the TLC.
Compound 2 was subjected to Mitsunobu cyclization with TPP
and DEAD in THF.22 But the expected product could not be isolated.
ESI mass spectra of the crude and worked-up product did not show
any peak at the desired region. Compound 2 was also tried to be
cyclized with 2-chloro-N-methylpyridinium iodide23 in the pres-
ence of DIPEA in ACN under highly diluted conditions, but again
failed to provide the desired result.
Finally, success was achieved when compound 2 was subjected
to the Shiina cyclization method24 using 2-methyl-6-nitrobenzoic
anhydride (MNBA) in the presence of DIPEA and a catalytic amount
of DMAP in CH2Cl2 at high dilution that gave a product which was
isolated and showed an ESI mass peak at m/z 906 [M+Na]+. But the
yield was very low. As a result, it was becoming very difficult to get
the final compound in sufficient quantities for purification, spectral
characterization, and further work. Work is now in progress to
improve the yields of some of the steps, especially the macrocycli-
zation step, and complete the total synthesis of the target
molecule.
In conclusion, we have been able to devise a synthetic protocol
for the synthesis of lagunamide B with a careful choice of an
appropriate ester protecting group. At the end, its selective
removal keeping the other ester intact allowed us to successfully
construct the macrocyclic framework of this depsipeptide using
lactonization strategy rather than lactamization approach.
20. Synthesis of 32: To a stirred solution of 4 (450 mg, 0.74 mmol) in CH2Cl2 (3 mL),
Et3N (0.15 mL, 1.1 mmol), PdCl2 (7 mg, 0.04 mmol), and Et3SiH (0.2 mL,
1.1 mmol) were sequentially added at 0 °C. After stirring for 15 min at 0 °C,
the reaction mixture was quenched with saturated NH4Cl solution and diluted
with EtOAc (60 mL), washed with 1 N HCl (25 mL), water (25 mL), brine
(25 mL), dried with anhydrous Na2SO4, filtered, and concentrated in vacuo to
afford crude acid 27 as a yellow liquid. To a stirred solution of 30 (630 mg,
0.89 mmol) in CH2Cl2 (6 mL) at 0 °C, trifluoroacetic acid (3 mL) was added and
stirring was continued for 2 h at room temperature. The reaction mixture was
then concentrated in vacuo to get the trifluoroacetate salt 31. To a stirred
solution of 27 in dry CH2Cl2 (10 mL) at 0 °C, HOBtÁH2O (169 mg, 1.1 mmol) and
EDCI (213 mg, 1.1 mmol) were sequentially added. After 10 min, 31, dissolved
in dry CH2Cl2 (5 mL), was added to the reaction mixture followed by the
addition of DIPEA (0.4 mL, 2.2 mmol). After stirring for 8 h at room
temperature, the reaction mixture was diluted with EtOAc (125 mL), washed
with 1 N HCl (2 Â 75 mL), saturated NaHCO3 (2 Â 75 mL), water (75 mL), brine
(75 mL), dried (anhydrous Na2SO4), filtered, and concentrated in vacuo.
Purification by silica gel column chromatography (SiO2, 50% EtOAc in
petroleum ether eluant) afforded compound 32 (286 mg, 35%) as pale yellow
liquid. Rf = 0.5 (SiO2, 60% EtOAc in petroleum ether). 1H NMR (300 MHz, CDCl3):
d 7.29–7.15 (m, 10H), 7.06 (d, J = 7.8 Hz, 1H), 6.89 (m, 1H), 6.61 (d, J = 8.6 Hz,
1H), 5.75–5.65 (m, 1H), 5.38–5.31 (m, 2H), 5.17 (d, J = 12.2 Hz, 1H), 5.10 (d,
J = 12.2 Hz, 1H), 5.01–4.97 (m, 1H), 4.87–4.71 (m, 1H), 4.63 (d, J = 7.0 Hz, 1H),
4.52 (d, J = 7.0 Hz, 1H), 3.69 (d, J = 9.2 Hz, 1H), 3.44–3.40 (m, 1H), 3.31 (s, 3H),
3.24–2.70 (m, 5H), 3.03 (s, 3H), 3.00 (s, 3H), 2.88 (s, 3H), 2.39–2.28 (m, 1H),
2.21–2.15 (m, 1H), 2.05–1.96 (m, 4H), 1.88–0.79 (m, 8H), 1.84 (s, 3H), 1.58 (d,
J = 6.2 Hz, 3H), 1.57 (s, 3H), 1.40 (d, J = 7.2 Hz, 3H), 0.98 (d, J = 6.7 Hz, 3H), 0.89–
0.79 (m, 10H), 0.88 (s, 9H), 0.03 (s, 3H), À0.05 (s, 3H). MS (ESI): m/z (%): 1128
(100) [M+Na]+, HRMS (ESI): calcd for C60H95N5O12SiNa 1128.6639 [M+Na]+,
found 1128.6637.
Acknowledgements
The authors wish to thank DST, New Delhi for JC Bose Fellow-
ship (T.K.C.; DST No: SR/S2/JCB-30/2007), CSIR, New Delhi for
research fellowship (S.P.) and the SAIF division of CSIR-CDRI for
analytical support.
Supplementary data
21. Synthesis of 33: To a stirred solution of 32 (286 mg, 0.26 mmol) in dry THF
(3 mL), HFÁpyridine complex (1 mL) at 0 °C was added. The reaction was
monitored using TLC. After stirring for 2 h at 0 °C, the reaction mixture was
quenched with aqueous saturated NaHCO3 solution and diluted with EtOAc
(125 mL), washed with 1 N HCl (50 mL), water (50 mL), brine (50 mL), dried
(anhydrous Na2SO4), filtered and concentrated in vacuo. Purification by silica
gel column chromatography (SiO2, 50% EtOAc in petroleum ether eluant)
afforded compound 33 (157 mg, 61%) as pale yellow liquid. Rf = 0.5 (SiO2, 70%
EtOAc in petroleum ether). 1H NMR (300 MHz, CDCl3): d 7.33–7.20 (m, 10H),
6.88 (m, 2H), 6.67 (d, J = 8.9 Hz, 1H), 5.69–5.67 (m, 1H), 5.57–5.55 (m, 1H),
5.34–5.33 (m, 1H), 5.17 (d, J = 12.0 Hz, 1H), 5.10 (d, J = 12.1 Hz, 1H), 5.01 (m,
2H), 4.81–4.76 (m, 2H), 4.66 (s, 2H), 4.24–4.13 (m, 2H), 3.77–3.66 (m, 2H),
3.41–3.32 (m, 1H), 3.38 (s, 3H), 3.04 (s, 3H), 3.01 (s, 3H), 2.85 (s, 3H), 3.15–2.80
(m, 5H), 2.49 (m, 2H), 2.41–2.33 (m, 2H), 2.05–2.00 (m, 4H), 1.88 (s, 3H), 1.64
(d, J = 3.09 Hz, 3H), 1.56 (s, 3H), 1.41–1.06 (m, 6H), 1.06–0.73 (m, 12H). MS
(ESI): m/z (%): 1014 (100) [M+Na]+, HRMS (ESI): calcd for C54H82N5O12
992.5954 [M+H]+, found 992.5931.
Supplementary data associated with this article can be found, in
References and notes
1. IUPAC, Compendium of Chemical Terminology, 2nd ed. (the ‘Gold Book’), 1997.
