Synthesis of ester and amide derivatives of 1-phenyl-3-(thiophen-3-yl)-1H- pyrazole-4-carboxylic acid and study of their anticancer activity

Article abstract of DOI:10.1007/s00044-012-0317-2

A series of novel thiophene containing 1,3-diarylpyrazole derivatives were synthesized and the structures were determined by IR, ¹H-NMR, and HRMS analysis. The anticancer activity of the title compounds against MCF7, MDA-MB-231, HeLa, Raji, and HL60 human cancer cells growth were investigated by MTT assay. Interestingly, Raji and HL60 cells exhibited more sensitivity to synthesized compounds. (4-Benzyl-piperidin-1-yl)-(1-phenyl-3-thiophen-3-yl-1H- pyrazol-4-yl)-methanone (4c) possessed the highest growth inhibitory effect on Raji and HL60 cancer cells (GI₅₀ 25.2 ± 3.2 and 28.3 ± 1.53 μM, respectively). Compound 4f, 4-trifluoromethylphenyl piperazine at the amide part, also showed potent activity on Raji and HL60 cancer cell lines with a GI₅₀ value of 32.0 ± 1.27 and 36.7 ± 2.15 μM, respectively. Physicochemical properties of the synthesized compounds were evaluated in silico, and it was found that all compounds should present good passive oral absorption. All synthesized compounds demonstrated good drug-likeness values. The data suggested that these compounds might be promising for further development.

Full text of DOI:10.1007/s00044-012-0317-2

MEDICINAL
CHEMISTRY
RESEARCH
Med Chem Res (2013) 22:3109–3118
DOI 10.1007/s00044-012-0317-2
ORIGINAL RESEARCH
Synthesis of ester and amide derivatives of 1-phenyl-3-(thiophen-
3-yl)-1H-pyrazole-4-carboxylic acid and study of their anticancer
activity
•
•
Nazan Inceler Akın Yılmaz Sultan Nacak Baytas
Received: 7 June 2012 / Accepted: 25 October 2012 / Published online: 10 November 2012
Ó Springer Science+Business Media New York 2012
Abstract A series of novel thiophene containing 1,3-di-
arylpyrazole derivatives were synthesized and the struc-
tures were determined by IR, 1H-NMR, and HRMS
analysis. The anticancer activity of the title compounds
against MCF7, MDA-MB-231, HeLa, Raji, and HL60
human cancer cells growth were investigated by MTT
assay. Interestingly, Raji and HL60 cells exhibited more
sensitivity to synthesized compounds. (4-Benzyl-piperidin-
1-yl)-(1-phenyl-3-thiophen-3-yl-1H-pyrazol-4-yl)-metha-
none (4c) possessed the highest growth inhibitory effect
on Raji and HL60 cancer cells (GI50 25.2 3.2 and
28.3 1.53 lM, respectively). Compound 4f, 4-trifluoro-
methylphenyl piperazine at the amide part, also showed
potent activity on Raji and HL60 cancer cell lines with a
GI50 value of 32.0 1.27 and 36.7 2.15 lM, respec-
tively. Physicochemical properties of the synthesized
compounds were evaluated in silico, and it was found that
all compounds should present good passive oral absorption.
All synthesized compounds demonstrated good drug-like-
ness values. The data suggested that these compounds
might be promising for further development.
Introduction
Cancer is one of the most serious threats against human
health in the world, and the clinical prognosis remains
relatively poor. Chemotherapy is a major form of cancer
treatment. However, the majority of cancers are either
resistant to chemotherapy or acquire resistance during
treatment. As a result, the design and discovery of non-
traditional, efficient, and safe chemical classes of agents
are the prime targets in contemporary medicinal chemistry
(Cozzi, 2003; Johnston et al., 2005).
Pyrazoles constitute an important heterocyclic family
containing nitrogen in their five-membered ring. Several
pyrazole derivatives have been found to possess significant
biological activities, stimulating the research activity in
medicinal chemistry and chemical biology (Silveira et al.,
1993; Sridhar et al., 2004; Nagarapu et al., 2011; Padmaja
et al., 2009; Gaston et al., 1996). Many pyrazole derivatives
are well acknowledged to possess a wide range of anticancer
bioactivities (Riyadh et al., 2010; Anzaldi et al., 2009; El-
Shafei et al., 2009; Zheng et al., 2010; Xie et al., 2010; Lian
et al., 2009). Literature survey revealed that some pyrazoles
have been implemented as antileukemic (Daidone et al.,
2004; Chou et al., 2007), antitumor (Li et al., 2006; Xia et al.,
2007), and anti-proliferative (Schenone et al., 2004) agents,
beside their capability to exert remarkable anticancer effects
through inhibiting different types of enzymes which play
important roles in cell division (Warshakoon et al., 2006;
Huang et al., 2007). Although the skeleton of pyrazole plays
an important role in its biological effects, the type of
peripheral substituents is also crucial. Wei et al. demon-
strated that ethyl 1-(20-hydroxy-30-aroxypropyl)-3-aryl-1H-
pyrazole-5-carboxylate derivatives suppressed lung cancer
cell growth (Wei et al., 2006). They found that ethyl
1-arylmethyl-3-aryl-1H-pyrazole-5-carboxylate derivatives
Keywords Synthesis ꢀ Anticancer activity ꢀ
1H-Pyrazoles ꢀ Thiophene ꢀ MTT
N. Inceler ꢀ S. N. Baytas (&)
Division of Pharmaceutical Sciences, Department of
Pharmaceutical Chemistry, Faculty of Pharmacy, Gazi
University, Etiler, 06330 Ankara, Turkey
e-mail: sbaytas@gmail.com; baytas@gazi.edu.tr
A. Yılmaz
Department of Medical Biology and Genetics, Faculty of
Medicine, Gazi University, Bes¸evler, 06500 Ankara, Turkey
123

3110
Med Chem Res (2013) 22:3109–3118
promoted human umbilical vein endothelial cell (HUVEC)
apoptosis to a certain extent at the concentrations of
5–20 lM and the effect on the cell viability was dose
dependent (Ding et al., 2007). Pyrazole-fused heterocycles
such as dihydropyrazoloxazin-4-one and pyrazolopyrazi-
none derivatives also showed anticancer activity (Wei et al.,
2007; Xie et al., 2008; Zhang et al., 2008; Pan et al., 2008).
It is well known that the incorporation of heterocyclic
rings into prospective pharmaceutical candidates is a major
tactic to gain activity and safety advantages. Heterocyclic
rings such as thiophene are important pharmacophores in
search of molecules with antitumor activity (Micale et al.,
2002; Insuasty et al., 2008; Leite et al., 2004; Al-Obaid et al.,
2009; Basnet et al., 2010; Barresi et al., 2002). N-substituted
2-pyrazolines bearing thiophene substituent showed impor-
tant activity against different cancer cell lines with remark-
able values in leukemia, and renal and prostate cancer panels.
It is also reported that terthiophene derivatives, bioisosteres
of terpyridine, resulted considerable protein kinase C (PKC)
inhibitory activity and antitumor cytotoxicities against sev-
eral human cancer cell lines (Kim et al., 1998).
Results
Chemistry
We focused our synthetic efforts on diaryl heterocyclic ring
systems as illustrated in Scheme 1. The starting compound,
the hydrazone derivative 1, was generated by carrying out
condensation reaction in the presence of phenyl hydrazine
and acetic acid in refluxing ethanol. This hydrazone
derivative was then reacted with POCl3 and DMF resulting
in 1,3-diaryl pyrazole 2 with aldehyde group at 4 position.
1-Phenyl-3-thiophen-3-yl-1H-pyrazole-4-carbaldehyde
2
was oxidized to carboxylic acid derivative 3 in the presence
of potassium permanganate in acetone–water mixture. By
treatment of 3 with appropriate amines or phenols in the
presence of triethylamine and ethyl chloroformate, which
was used as the carboxylate activator, the amide and ester
derivatives 4 were prepared in good yield (40–88 %)
(Table 1). The chemical structures of these compounds
were elucidated by their IR, HRMS, and 1H-NMR spectral
data.
In the present study, Compounds A (Zheng et al., 2009)
and B (Insuasty et al., 2011) were considered as the parent
compounds for the design of our target compounds
(Fig. 1). In our effort to discover and develop potential new
anticancer agents, we synthesized a series of novel 1,3-
diarylpyrazole derivatives bearing thiophene functionality
and evaluated their anticancer activities. The title com-
pounds 4a–m were designed by inserting thiophene-3-yl
residue and introduction of the carboxamide side chain at 4
position of pyrazole ring. Herein, we report the synthesis
and antiproliferative activity of compounds against five
different human cancer cell lines. In silico evaluations of
title compounds are also reported.
The IR spectrum of hydrazone 1 has shown the disap-
pearance of the carbonyl peak belonging to acetyl group of
3-acetyl-thiophene and the secondary N–H stretching band
was observed at 3349 cm-1 as singlet. The IR spectra of
compound 2 exhibited a characteristic strong absorption for
aldehyde carbonyl group at 1667 cm-1. In the IR spectra of
compound 3, strong absorption band at 1690 cm-1 and
intense O–H stretching absorption in the region of
3300–2500 cm-1 for carboxylic acid were observed. Final
amide and ester derivatives exhibited a characteristic
strong absorption in the area of 1744–1615 cm-1 attribut-
able to the C=O of amide or ester group.
1
In the H-NMR spectra of compound 2, two singlets
were observed due to the aldehyde group at 10.10 ppm and
pyrazole-H5 at 8.50 ppm, each showing the integration for
one proton. In the 1H-NMR spectra of compounds 3, signal
of the carboxylic acid was not observed, but signal of the
pyrazole-H5 was seen at 8.59 ppm. In the 1H-NMR spectra
of final amide and ester derivatives 4a–m, pyrazole-H5
gave a singlet at about 9.00–8.04 ppm.
O
HO
N
H
N
N
R
N
N
N
S
O
R
A
B
Biological evaluations
Effects of the compounds on the viability of cancer
cells
O
S
N
Synthesized 1-phenyl-3-thiophen-3-yl-1H-pyrazole-4-car-
boxylic acid 3 and its amide and ester derivatives 4a–m
were screened against five human cancer cell lines
(HeLa, MCF7, MDA-MB-231, Raji, and HL60) using
3-(4,5-dimethyldiazol-2-yl)-2,5-diphenyltetrazolium bromide
N
4a-m
N
Fig. 1 Design of the title compounds
123

Med Chem Res (2013) 22:3109–3118
3111
Scheme 1 a Phenyl hydrazine,
acetic acid, ethanol, 2 h reflux.
b Dimethyl formamide, POCl3,
50 °C, 4 h. c Potassium
S
a
N
b
N
S
S
CH3
HN
N
H
O
permanganate, acetone–water
(3:2), 2.5 h reflux.
O
2
1
d Appropriate amine or phenol
derivative, ethyl chloroformate,
triethylamine, dichloromethane,
rt, overnight
S
S
N
d
N
c
N
N
COR
COOH
3
4
Table 1 Characterization data of 1,3-diarylpyrazole derivatives (3, 4a–m)
S
N
N
COR
Compnd.
R
Melting point (°C) % of yield Compnd.
R
Melting point (°C)
% of yield
N
N
N
3
OH
201-203
128-130
87
40
4g
4h
243-245
41
4a
NH
O
O
153-155
49
4b
4c
4i
4j
O
O
N
O
147-149
78-80
70
61
75-77
65-68
54
88
N
O
4d
4k
CH3
N
N
110-112
179-181
143-145
42
40
43
116-118
146-148
129-131
43
56
64
4e
4f
4l
N
N
O
O
4m
F
F
N
N
F
(MTT) assay. The MTT cell proliferation assay has been
widely accepted as a reliable way to measure the cell
proliferation rate, and conversely when metabolic events
lead to apoptosis or necrosis (Holst-Hansen and Bru¨nner,
1998; Reile et al., 1990, Kueng et al., 1989; Senaratne
et al., 2000). After incubation with compounds at the
concentration of 50 lM for 48 h, the cells were treated
with MTT to measure their growth/viability (% of the
untreated control) by a spectrophotometric method as
described previously (Mosmann, 1983; Denizot and Lang,
1986). Figure 2 indicates the cytotoxic effects of the
compounds on the viability of the tested cancer cells that
were incubated for 48 h. For example, exposure of HeLa
cells to compounds 4a, 4c, 4e, and 4f at 50 lM for 48 h
resulted in cell viability decrease from 100 to 82.3, 71.8,
67.9, and 80.7 %, respectively. For MDA-MB-231 cells,
compounds 3, 4a, 4b, 4c, 4e, 4f, and 4g decreased the cell
viability from 100 to 80.9, 85.0, 77.6, 82.8, 81.4, 84.2, and
87.4 %, respectively. Furthermore, only compounds 4c and
4f exhibited poor activity toward the MCF7 cell line (cell
viability reduced from 100 to 90.7 % for 4c and from 100
to 85.9 % for 4f). On the other hand, compound 4c showed
the ever highest growth inhibitory potential against Raji
cell line. Additionally, compound 4c was able to display a
significant activity against HL60 tumor cell lines, reducing
cell viability from 100 to 39.1 %.
123

3112
Med Chem Res (2013) 22:3109–3118
Table 2 The GI50 values of the 4c and 4fa for cell viability in Raji
and HL60 cell lines
Among all compounds, 4c showed the most potent
inhibitory effect on Raji and HL60 cells growth (GI50
25.2 3.2 and 28.3 1.53 lM, respectively), followed
by 4f (GI50 32.0 1.27 and 36.7 2.15 lM, respec-
tively) (Table 2).
Cell line
GI50 (lM)
4c
4f
Raji
HL60
a
25.2 3.2
28.3 1.53
36.7 2.15
32.0 1.27
Lipinski’s rule-of-five and drug-likeness profile
Rest of the compounds have IC50 values of [100 lM. Results are
presented as mean SE; (n = 4. * P \ 0.05 vs control; ** P \ 0.01
vs control; *** P \ 0.001 vs control)
The synthesized compounds (4a–m) were submitted to an
in silico evaluation using a molecular modeling approach.
In order to predict drug-like properties of the synthesized
compounds, we analyzed these derivatives according to the
rule-of-five developed by Lipinski et al. 2001. Predictions
of ADME properties for the compounds are given in
Table 3. Calculated physicochemical properties (http://www.
molinspiration.com/cgi-bin/properties) showed that most of
the compounds fulfilled the Lipinski ‘‘rule-of-five.’’ The
compound 4f violated the criteria for molecular weight and
logP. Compounds 4c, 4i, 4j, 4k, 4l, and 4m had very large
clogP values, which might be disadvantageous with regard to
pharmacokinetic properties of these molecules in biological
systems. Rest of the compounds exhibited favorable clog P
values. The polar surface areas of the synthesized compounds
were relatively small in comparison with the average value
Discussion
Cancer is the second leading cause of death in developed
countries, accounting for nearly one in five deaths. A key
feature of cancer cells is their uncontrolled proliferation;
thus, inhibition of proliferative pathways is believed to be
an effective strategy to fight cancer and much attention has
recently been paid to the discovery and development of
new, more selective anticancer agents (Lee et al., 2007;
Kemnitzer et al., 2008; Hu et al., 2008). The design and
synthesis of new pyrazole derivatives has been a subject of
consistent interest. Pyrazole derivatives have occupied a
unique position in drug discovery due to their broad range
of biological activities, including anti-inflammatory, anti-
angiogenic, antibacterial, antimicrobial, anticancer, anti-
depressant, antioxidant, anti-influenza, and analgesic
activities (Tewari et al., 2010; Christodoulou et al., 2010;
Lv et al., 2010; Gouda et al., 2010; Chou et al., 2010;
Abdel-Aziz et al., 2009; Bandgar et al., 2009; Shih et al.,
2010; Machado et al., 2009). In the present study, 1,3-
diarylpyrazole derivatives bearing thiophene moiety
showed moderate anticancer activity. It is possible to relate
the structural characteristics of the compounds to their
´
2
˚
for acceptable drug molecules (\90A ).
Currently, there are many approaches to assess a com-
pound’s drug-likeness based on topological descriptors,
fingerprints of molecular drug-likeness structure keys
(Tetko, 2005). In this work, we used the Osiris program
(http://www.organic-chemistry.org/prog/peo) for calculat-
ing the fragment-based drug-likeness of the compounds
(Table 3). The most active compound 4c demonstrated
good drug-likeness value (=3.5).
Fig. 2 Effects of the compounds on cervical carcinoma (HeLa),
breast cancer (MDA-MB-231 and MCF7), Burkitt lymphoma (Raji),
and human promyelocytic leukemia (HL60) cells viability. HeLa,
MDA-MB-231, MCF7, Raji, and HL60 cells were treated with
compounds 3, 4a–m at concentration of 50 lM or left untreated
(control) for 48 h. Cell viability was analyzed by MTT assay and
illustrated in column figures. Results are presented as mean SE;
(n = 4; * P \ 0.05 vs control; ** P \ 0.01 vs control;
*** P \ 0.001 vs control); Compounds 4a and 4e were not tested
against MCF7, Raji, and HL60 cells due to poor solubility
123

Med Chem Res (2013) 22:3109–3118
3113
Table 3 Calculated physicochemical properties of the synthesized compounds
Compound
Predicted oral bioavailability
Drug-likeness
HBAa
HBDb
M.Wc
clogPd
logSe
TPSAf
3
4
4
5
4
5
5
5
6
5
4
4
4
4
4
1
1
0
0
0
0
0
0
0
0
0
0
0
0
296.35
385.49
365.45
453.61
378.50
440.57
508.56
441.56
402.47
400.50
414.53
428.55
448.54
422.50
2.642
3.901
2.594
5.325
2.639
4.336
5.232
3.047
4.42
-3.41
-4.73
-3.11
-5.29
-2.61
-4.46
-5.23
-3.66
-4.89
-5.37
-5.74
-6.08
-6.96
-6.48
55.125
46.924
47.369
38.135
41.373
41.373
41.373
54.265
53.365
44.131
44.131
44.131
44.131
44.131
0.69
0.25
4a
4b
4c
4d
4e
4f
4g
4h
4i
1.58
3.5
6.94
7.06
-3.32
5.29
-1.83
-1.64
-2.65
-4.89
-1.42
-3.73
5.278
5.852
5.779
6.159
5.547
4j
4k
4l
4m
a
Number of hydrogen-bond acceptor
Number of hydrogen-bond donor
Molecular weight
b
c
d
e
f
Calculated lipophilicity
Solubility parameter
´
2
˚
Topological polar surface area (A )
antitumor activity. The data obtained by MTT assay
showed that amide derivatives 4a–g had inhibitory effects
on the growth of tested human cancer cells as shown in
Fig. 2. When chemical structure of the compounds are
taken into consideration, introduction of benzylpiperidin
moiety at the amide portion led to 4c with enhanced
activity against all the cancer cell lines with the best results
against Raji and HL60. The compound 4b with morpholine
was inactive against all tested tumor cell lines except
against MDA-MB-231 which showed poor inhibitor effect
on cell growth. Piperazine amide derivatives 4d, 4e, and 4g
displayed diminished activity. Interestingly, introduction of
p-fluoromethylphenyl piperazine group in amide portion
led to 4f with improved activity against especially Raji and
HL60 cells. Taken together, compound 4c was the most
effective compound in suppressing Raji and HL60 cells
growth (GI50 25.2 3.2 and 28.3 1.53 lM, respec-
tively). Ester derivatives of 1-phenyl-3-(thiophen-3-yl)-1H-
pyrazole-4-carboxylic acid 4h–m did not affect the growth
of HeLa, MCF7, MDA-MB-231, Raji, and HL60 cells.
We then determined the suitability of compounds for
anticancer purposes where a good absorption after oral
administration is obligatory. LogP, the measure of the
compound’s solubility and permeability, is believed to be
very important. Very high lipophilicity and the resulted
large logP values cause poor absorption or permeation and
should be avoided. Physicochemical properties of the
synthesized compounds were evaluated in silico, and found
that all compounds should present good passive oral
absorption. All the synthesized compounds demonstrated
good drug-likeness values.
Conclusion
A series of novel 1,3-diarylpyrazole derivatives has been suc-
cessfully synthesized. Structures of all products were deter-
mined by IR, 1H-NMR, and HRMS. We found that compounds
4c and 4f could suppress Raji and HL60 cancer cell growth.
Compound 4c bearing benzylpiperidine group in the amide
portion showed significant inhibitory effect against Raji and
HL60 cell lines. Owing to the significant results obtained,
chemical studies are being conducted to modify structures to
improve the antitumor activity of such compounds.
Experimental
Chemistry
The chemicals were purchased from the commercial
vendors and were used without purification. Thin-layer
123

3114
Med Chem Res (2013) 22:3109–3118
1-Phenyl-3-(thiophen-3-yl)-1H-pyrazole-4-carboxylic acid
3
chromatography (TLC) was performed on Merck 60F254
plates. Reactions were monitored by TLC on silica gel,
with detection by UV light (254 nm) or charring Drag-
endorff reagent (Stahl, 1969). Melting points were deter-
mined with an SMP-II Digital Melting Point Apparatus and
are uncorrected (Schorpp Geaetetechnik, Germany). IR
spectra were obtained in-house using a Perkin Elmer
Spectrum 400 FTIR/FTNIR spectrometer equipped with a
universal ATR Sampling Accessory. 1H-NMR spectra were
recorded in CDCl3 or DMSO-d6 on a Varian Mercury
400 MHz High Performance Digital FT-NMR spectrome-
ter using tetramethylsilane as the internal standard at the
NMR facility of Faculty of Pharmacy, Ankara University.
All chemical shifts were recorded as d (ppm). High-reso-
lution mass spectra data (HRMS) were collected in-house
using a Waters LCT Premier XE Mass Spectrometer (high-
sensitivity orthogonal acceleration time-of-flight instru-
ment) operating in either ESI (?) or ESI (-) methods, also
coupled to an AQUITY Ultra Performance Liquid Chro-
matography system (Waters Corporation, Milford, MA,
USA). Flash chromatography was performed with a
CombiflashÒ Rf automated flash chromatography system
with RediSep columns (Teledyne-Isco, Lincoln, NE, USA)
using dichloromethane-methanol solvent gradients.
To a solution of aldehyde (2 g, 7.86 mmol) in 100 ml
acetone–water mixture (3:2) potassium permanganate
(2.48 g, 15.7 mmol) was added and the corresponding dark
violet reaction mixture was stirred for 2.5 h to achieve full
conversion. The solvents were removed under vacuum and
the dark suspension was quenched upon addition of 20 ml
saturated sodium sulfite solution. The violet solid was fil-
tered off and washed with water. The turbid light brown
mother liquor was treated with HCl adjusting the pH to 1
and CH2Cl2 was added. Organic phase was washed with
water, dried over sodium sulfate, and evaporated under
vacuum. The precipitate obtained was purified by crystal-
lization in acetone–water mixture. IR (FT-IR/ATR):
1
1690 cm-1 (C=O), 2618 cm-1 (C=C). H-NMR (CDCl3)
d: 8.59 (1H, s, pyrazole H-5), 8.32 (1H, m, ArH), 7.79 (3H,
m, ArH), 7.51 (2H, m, ArH), 7.37 (2H, m, ArH). HRMS
C14H11N2O2S [M ? H]? Calc. 271.0541, Found m/z
271.0535.
General procedure for the preparation of amide/ester
derivatives of 1-phenyl-3-(thiophen-3-yl)-1H-pyrazole-4-
carboxylic acid 4
N-Phenyl-N0-(1-thiophen-3-yl-ethylidene)hydrazine 1
To the solution of acid derivatives (1 mmol) triethylamine
(2 mmol) and ethyl chloroformate (1 mmol) were added,
followed by stirring at 0 °C for 30 min. After addition of
the appropriate amine or phenol derivative (1.2 mmol),
mixture was stirred for an additional 1 h at 0 °C. Then, the
reaction mixture was warmed to room temperature and
kept stirring overnight. After the solvent was evaporated
under reduce pressure, acetone was added, filtered, and
evaporated. Residue was dissolved in DCM and the organic
phase was washed with a 1 N HCl and 1 % NaHCO3
solutions and brine, dried over Na2SO4, and evaporated
under vacuum. The residue was purified by automated flash
column chromatography (CombiflashÒ Rf) using DCM-
MeOH (0–10 %) as eluents.
A solution of acetylthiophene (0.052 mol), phenyl hydra-
zine (0.058 mol), and acetic acid (2 ml, 0.035 mol) in
ethanol was stirred for 2 h at reflux, and then evaporated.
The precipitated was filtered off and dried. Yield 80 %; IR
1
(FT-IR/ATR): 3349 cm-1 (N–H), 1933 cm-1 (C=N). H-
NMR (DMSO-d6) d: 9.13 (1H, s, N–NH), 7.64 (1H, m,
ArH), 7.59 (1H, m, ArH), 7.51 (1H, m, ArH), 7.20 (4H, m,
ArH), 6.73 (1H, m, ArH), 2.23 (3H, s, C–CH3).
1-Phenyl-3-(thiophen-3-yl)-1H-pyrazole-4-carbaldehyde 2
In a dry flask, phosphoroxy chloride (POCl3) (16.77 ml,
0.18 mol) was added dropwise to an ice-cold stirred solu-
tion of hydrazone derivative (0.06 mol) in 100 ml DMF.
The reaction mixture was allowed to attain room temper-
ature, and then heated at 50 °C for about 5 h. The resulting
mixture was poured onto crushed ice, neutralized with
dilute NaOH, and left overnight. The precipitate obtained
was purified by crystallization in acetone–water mixture.
Yield 82 %, mp 124 °C (Lit. mp: 120 °C (Arbaciauskiene
et al., 2011); IR (FT-IR/ATR): 1667 cm-1 (C=O). 1H-
NMR (CDCl3) d: 10.10 (1H, s, CHO), 8.50 (1H, s, pyrazole
H-5), 8.19 (1H, m, ArH), 7.80–7.77 (2H, m, ArH), 7.70
(1H, m, ArH), 7.54–7.50 (2H, m, ArH), 7.44–7.38 (2H, m,
ArH). HRMS C14H11N2OS [M ? H]? Calc. 255.0592,
Found m/z 255.0586.
N-Benzyl-1-phenyl-3-(thiophen-3-yl)-1H-pyrazole-4-carbox-
amide 4a IR (FT-IR/ATR): 1639 cm-1 (C=O), 3318
1
cm-1 (N–H). H-NMR (CDCl3) d: 8.45 (1H, s, pyrazole
H-5), 7.73 (2H, m, ArH), 7.68 (1H, m, ArH), 7.48–7.44
(2H, m, ArH), 7.40–7.21 (8H, m, ArH), 6.13 (1H, s, NH),
4.54 (2H, d, J = 5.6 Hz, NH–CH2). HRMS C21H18N3OS
[M ? H]? Calc. 360.1171, Found m/z 360.1162.
Morpholin-4-yl[1-phenyl-3-(thiophen-3-yl)-1H-pyrazol-4-
yl]methanone 4b IR (FT-IR/ATR): 1630 cm-1 (C=O).
1H-NMR (CDCl3) d: 8.09 (1H, s, pyrazole H-5), 7.73 (2H,
m, ArH), 7.65 (1H, m, ArH), 7.48 (1H, m, ArH), 7.47 (2H,
123

Med Chem Res (2013) 22:3109–3118
3115
m, ArH), 7.40 (1H, m, ArH), 7.35 (1H, m, ArH), 3.70 (4H,
m, morpholine H-2,6), 3.29 (4H, m, morpholine H-3,5).
HRMS C18H18N3O2S [M ? H]? Calc. 340.1120, Found
m/z 340.1103.
HRMS C23H22N5OS [M ? H]? Calc. 416.1545, Found
m/z 416.1534.
4-Methoxyphenyl 1-phenyl-3-(thiophen-3-yl)-1H-pyrazole-
4-carboxylate 4h IR (FT-IR/ATR): 1738 cm-1 (C=O).
1H-NMR (CDCl3) d: 8.67 (1H, s, pyrazole H-5), 8.39 (1H,
m, ArH), 7.83 (3H, m, ArH), 7.53 (2H, m, ArH), 7.40–7.32
(2H, m, ArH), 7.13 (2H, m, ArH), 6.95 (2H, m, ArH), 3.82
(3H, s, CH3). HRMS C21H17N2O3S [M ? H]? Calc.
377.0960, Found m/z 377.0956.
(4-Benzylpiperidin-1-yl)(1-phenyl-3-(thiophen-3-yl)-1H-pyr-
azol-4-yl)-methanone 4c IR (FT-IR/ATR): 1618 cm-1
1
(C=O). H-NMR (CDCl3) d: 8.04 (1H, s, pyrazole H-5),
7.73 (2H, m, ArH), 7.64 (1H, m, ArH), 7.50–7.44 (3H, m,
ArH), 7.36–7.23 (4H, m, ArH), 7.19 (1H, m, ArH), 7.08
(2H, m, ArH), 4.75–2.70 (4H, m, piperidin H-2,6), 2.46
(2H, s, CH2), 1.73–1.20 (4H, m, piperidin H-3,5), 0.71 (1H,
m, piperidin H-4). HRMS C26H26N3OS [M ? H]? Calc.
428.1797, Found m/z 428.1790.
4-Ethylphenyl 1-phenyl-3-(thiophen-3-yl)-1H-pyrazole-4-
1
carboxylate 4i IR (FT-IR/ATR): 1714 cm-1 (C=O). H-
NMR (CDCl3) d: 8.67 (1H, s, pyrazole H-5), 8.39 (1H, m,
ArH), 7.81 (3H, m, ArH), 7.53–7.49 (2H, m, ArH),
7.40–7.36 (1H, t, J = 7.6 Hz, ArH), 7.32 (1H, m, ArH),
7.25 (2H, d, J = 8.8 Hz, ArH), 7.10 (2H, d, J = 8.4 Hz,
ArH), 2.69–2.63 (2H, q, J = 7.6 Hz, CH2–CH3), 1.26 (3H,
t, J = 7.2 Hz, CH2–CH3). HRMS C22H19N2O2S
[M ? H]? Calc. 375.1167, Found m/z 375.1150.
(4-Methylpiperazin-1-yl)[1-phenyl-3-(thiophen-3-yl)-1H-
pyrazol-4-yl]methanone 4d IR (FT-IR/ATR): 1619 cm-1
1
(C=O). H-NMR (CDCl3) d: 8.06 (1H, s, pyrazole H-5),
7.73 (2H, d, J = 7.2 Hz, ArH), 7.64 (1H, m, ArH),
7.50–7.44 (3H, m, ArH), 7.37 (1H, m, ArH), 7.33 (1H, m,
ArH), 3.80 (2H, m, piperazine H-5), 3.29 (2H, m, pipera-
zine H-3), 2.42 (2H, m, piperazine H-2), 2.23 (3H, s, CH3),
2.06 (2H, m, piperazine H-6). HRMS C19H21N4OS
[M ? H]? Calc. 353.1436, Found m/z 353.1432.
3-Isopropylphenyl 1-phenyl-3-(thiophen-3-yl)-1H-pyrazole-
4-carboxylate 4j IR (FT-IR/ATR): 1744 cm-1 (C=O).
1H-NMR (CDCl3) d: 8.67 (1H, s, pyrazole H-5), 8.39 (1H,
m, ArH), 7.82 (3H, m, ArH), 7.51 (2H, m, ArH), 7.40–7.31
(3H, m, ArH), 7.13 (1H, m, ArH), 7.05 (2H, m, ArH), 2.93
(1H, m, CH–(CH3)2), 1.27 (6H, s, CH–(CH3)2). HRMS
C23H21N2O2S [M ? H]? Calc. 389.1324, Found m/z
389.1325.
[1-Phenyl-3-(thiophen-3-yl)-1H-pyrazol-4-yl)(4-phenylpi-
perazin-1-yl)methanone 4e IR (FT-IR/ATR): 1636 cm-1
1
(C=O). H-NMR (CDCl3) d: 8.11 (1H, s, pyrazole H-5),
7.73 (2H, m, ArH), 7.67 (1H, m, ArH), 7.52–7.46 (3H, m,
ArH), 7.37 (2H, m, ArH), 7.25 (2H, m, ArH), 6.90 (3H, m,
ArH), 3.93 (2H, s, piperazine H-5), 3.43 (2H, s, piperazine
H-3), 3.20 (2H, s, piperazine H-2), 2.81 (2H, s, piperazine
H-6). HRMS C24H23N4OS [M ? H]? Calc. 415.1593,
Found m/z 415.1576.
2-Isopropyl-5-methyl-phenyl 1-phenyl-3-(thiophen-3-yl)-
1H-pyrazole-4-carboxylate
4k IR
(FT-IR/ATR):
1729 cm-1 (C=O). H-NMR (CDCl3) d: 8.67 (1H, s, pyr-
azole H-5), 8.40 (1H, m, ArH), 7.82 (3H, m, ArH), 7.54
(2H, m, ArH), 7.41 (1H, m, ArH), 7.32 (1H, m, ArH), 7.23
(1H, m, ArH), 7.08 (1H, m, ArH), 6.94 (1H, s, ArH), 3.07
(1H, m, CH–(CH3)2), 2.34 (3H, s, CH3), 1.21–1.19 (6H, s,
CH–(CH3)2). HRMS C24H23N2O2S [M ? H]? Calc.
403.1480, Found m/z 403.1465.
1
[1-Phenyl-3-(thiophen-3-yl)-1H-pyrazol-4-yl)[4-(4-trifluo-
romethylphenyl)-piperazin-1-yl]-methanone 4f IR (FT-
1
IR/ATR): 1615 cm-1 (C=O). H-NMR (CDCl3) d: 8.12
(1H, s, pyrazole H-5), 7.75 (2H, d, J = 8 Hz, ArH), 7.66
(1H, m, ArH), 7.51–7.46 (5H, m, ArH), 7.38 (2H, m, ArH),
6.86 (2H, d, J = 8.4 Hz, ArH), 3.92 (2H, m, piperazine
H-5), 3.43–3.30 (4H, m, piperazine H-2,3), 2.89 (2H, m,
piperazine H-6). HRMS C25H22F3N4OS [M ? H]? Calc.
483.1466, Found m/z 483.1467.
Biphenyl-4-yl 1-phenyl-3-(thiophen-3-yl)-1H-pyrazole-4-
1
carboxylate 4l IR (FT-IR/ATR): 1698 cm-1 (C=O). H-
NMR (CDCl3) d: 9.00 (1H, s, pyrazole H-5), 8.70 (1H, m,
ArH), 8.13 (3H, m, ArH), 7.94–7.89 (2H, m, ArH),
7.89–7.69 (8H, m, ArH), 7.58–7.49 (2H, m, ArH). HRMS
C26H19N2O2S [M ? H]? Calc. 423.1167, Found m/z
423.1174.
[1-Phenyl-3-(thiophen-3-yl)-1H-pyrazol-4-yl)(4-pyridin-4-
yl-piperazin-1-yl)-methanone
4g IR
(FT-IR/ATR):
1630 cm-1 (C=O). 1H-NMR (CDCl3) d: 8.28 (2H, d,
J = 6.8 Hz, pyridine H-2,6), 8.12 (1H, s, pyrazole H-5),
7.74 (2H, m, ArH), 7.66 (1H, m, ArH), 7.50–7.46 (3H, m,
ArH), 7.38–7.32 (2H, m, ArH), 6.58 (2H, d, J = 6.8 Hz,
pyridine H-3,5), 3.88–2.99 (8H, m, piperazine H-2,3,5,6).
Naphthalen-2-yl 1-phenyl-3-(thiophen-3-yl)-1H-pyrazole-
4-carboxylate 4m IR (FT-IR/ATR): 1732 cm-1 (C=O).
1H-NMR (CDCl3) d: 8.96 (1H, s, pyrazole H-5), 8.61 (1H,
d, J = 2.8 Hz, ArH), 8.13–8.03 (6H, m, ArH), 7.89 (1H, d,
123

3116
Med Chem Res (2013) 22:3109–3118
J = 2.4 Hz, ArH), 7.76–7.69 (4H, m, ArH), 7.63–7.55
(3H, m, ArH). HRMS C24H17N2O2S [M ? H]? Calc.
397.1011, Found m/z 397.1008.
Statistical significance of the effects of compounds to
the cell viability was analyzed by one-way ANOVA and
Tukey’s post hoc test using SigmaStat v3.5 software.
P values \0.05 were considered to be statistically signifi-
cant. (* P B 0.05, ** P B 0.01, *** P B 0.001).
Anticancer activity
Lipinski’s rule-of-five and drug-likeness profile
Cell lines and cell culture
In order to explore the bioavailability of synthesized deriv-
atives, theoretical calculations were carried out to predict
some physicochemical properties of the synthesized com-
pounds. The bioavailability of the compounds was assessed
using ADME (absorption, distribution, metabolism, and
elimination) prediction methods. In particular, we calculated
the compliance of compounds to the Lipinski’s rule-of-five
(Lipinski et al., 2001). Lipinski’s ‘‘rule-of-five’’ and the later
addition of other parameters such as polar surface area
(PSA) (Ertl et al., 2000) describes molecular properties
important for a drug pharmacokinetics in the human body.
This approach has been widely used as a filter for substances
that would likely be further developed in drug design pro-
grams. Poor absorption and permeation are more likely to
occur when there are more than five hydrogen-bond donors
(HBD), more than ten hydrogen-bond acceptors (HDA), the
molecular mass (MM) is greater than 500, or the log P value
(clogP) is greater than five. The topological polar surface
The human cancer cell lines, cervical carcinoma (HeLa),
estrogen receptor positive breast carcinoma (MCF7),
estrogen receptor negative breast carcinoma (MDA-MB-
231), Burkitt’s lymphoma (Raji), and human promyelo-
cytic leukemia (HL60), were obtained from ATCC.
Cytotoxicity assay
MDA-MB-231 and MCF7 cells were cultured in DMEM;
whereas, HeLa, HL60, and Raji cells were grown in RPMI-
1640 medium in a humidified atmosphere containing 5 %
CO2 at 37 °C. Both DMEM and RPMI-1640 medium were
supplemented with 10 % fetal bovine serum (FBS),
200 mM L-glutamine, 100 IU/ml penicillin, and 100 lg/ml
streptomycin (all from Hyclone Laboratories, Logan, UT,
USA). Cell viability was determined using MTT (3-[4,5-
˚
area (TPSA) should be smaller than 90 A (Brueggemeier
dimethyl-2-thiazolyl]-2,5-diphenyl-2H-tetrazolium
bro-
mide) assay (Cell Proliferation Kit I, Roche, Germany).
Briefly, cells were seeded in a 96-well plate at 10.000 cells
per well and cultured for overnight in growth medium
containing 1 % FBS. Then cells were treated with 50 lM
of the test compounds for 48 h. As a solvent control, cells
were also treated with dimethyl sulfoxide (DMSO) at a
final concentration of 0.1 %. At the end of the incubation
time, MTT reagent at the final concentration of 0.5 mg/ml
was added to each well and incubated for an additional 4 h.
After formation of blue formazan crystals, medium con-
taining MTT was discarded and DMSO was added to the
wells to dissolve crystals. The absorbance of samples was
measured with Spectra Max M3 micro plate reader
(Molecular Devices, Sunnyvale, CA, USA) at a wavelength
of 570 nm. Average absorbance values from quadruplicate
replicates per test compound and solvent control (DMSO)
were calculated. Mean solvent control values were set to
100 % of viability and then the effects of the test com-
pounds to the cell viability were calculated by comparing
mean values obtained from compound treated culture wells
with those of the solvent controls. As the compounds
exhibited to reduction on cell viability more than 50 % at
50 lM, the GI50 values were also calculated from the
concentration-response curves using the PRISM 5,
GraphPad Software (GraphPad Prism Version 5.04, 2010).
et al., 2005). Molecules violating more than one of these
rules may have problems with bioavailability.
Acknowledgments This investigation was partially supported by
Scientific Research Grant 02/2011-08, awarded by Gazi University
BAP.
References
Abdel-Aziz M, Abuo-Rahma GEA, Hassan AA (2009) Synthesis of
novel pyrazole derivatives and evaluation of their antidepressant
and anticonvulsant activities. Eur J Med Chem 44:3480–3487
Al-Obaid AM, Abdel-Hamide SG, El-Kashef HA, Abdel-Aziz AA-M,
El-Azab AS, Al-Khamees HA, El-Subbagh HI (2009) Substi-
tuted quinazolines, part 3. Synthesis, in vitro antitumor activity
and molecular modeling study of certain 2-thieno-4(3H)-qui-
nazolinone analogs. Eur J Med Chem 44:2379–2391
`
Anzaldi M, Maccio C, Mazzei M, Bertolotto M, Ottonello L, Dallegri
F, Balbi A (2009) Antiproliferative and proapoptotic activities of
a new class of pyrazole derivatives in HL-60 cells. Chem
Biodivers 6:1674–1687
Arbaciauskiene E, Martynaitis V, Krikstolaityte S, Holzer W, Sackus
A (2011) Synthesis of 3-substituted 1-phenyl-1H-pyrazole-4-
carbaldehydes and the corresponding ethanones by Pd-catalyzed
cross-coupling reactions. ARKIVOC 11:1–21
Bandgar BP, Gawande SS, Bodade RG, Gawande NM, Khobragade
CN (2009) Synthesis and biological evaluation of a novel series
of pyrazole chalcones as anti-inflammatory, antioxidant and
antimicrobial agents. Bioorg Med Chem 17:8168–8173
123

Med Chem Res (2013) 22:3109–3118
3117
Barresi V, Condorelli DF, Fortuna CG, Musumarra G, Scire S (2002)
In vitro antitumor activities of 2,6-di-[2-(Heteroaryl)vinyl]pyr-
idines and pyridiniums. Bioorg Med Chem 10:2899–2904
Basnet A, Thapa P, Karki R, Choi H, Choi JH, Yun M, Jeong B-S,
Jahng Y, Na Y, Cho W-J, Kwon Y, Lee C-S, Lee E-S (2010) 2,6-
Dithienyl-4-furyl pyridines: synthesis, topoisomerase I and II
inhibition, cytotoxicity, structure-activity relationship, and dock-
ing study. Bioorg Med Chem Lett 20:42–47
Insuasty B, Orozco F, Quiroga J, Abonia R, Nogueras M, Cobo J
(2008) Microwave induced synthesis of novel 8,9-dihydro-7H-
pyrimido[4,5-b][1,4]diazepines as potential antitumor agents.
Eur J Med Chem 43:1955–1962
Insuasty B, Chamizo L, Munoz J, Tigreros A, Quiroga J, Abonia R,
Nogueras M, Cobo J (2011) Synthesis of 1-substituted 3-aryl-5-
aryl(hetaryl)-2-pyrazolines and study of their antitumor activity.
Arch Pharm Chem Life Sci 345:275–286
Brueggemeier RW, Hackett JC, Diaz-Cruz ES (2005) Aromatase
inhibitors in the treatment of breast cancer. Endocr Rev 26:
331–345
Johnsto SRD, Ford H, Ross P (2005) In the royal marsden hospital
hand book of cancer chemotherapy. Elsevier, London, New
York, Oxford
Chou L-C, Huang L-J, Yang J-S, Lee F-Y, Teng C-M, Kuo S-C
(2007) Synthesis of furopyrazole analogs of 1-benzyl-3-(5-
hydroxymethyl-2-furyl)indazole (YC-1) as novel anti-leukemia
agents. Bioorg Med Chem 15:1732–1740
Chou LC, Huang LJ, Hsu MH, Fang MC, Yang JS, Zhuang SH, Lin
HY, Lee FY, Teng CM, Kuo SC (2010) Synthesis of 1-benzyl-3-
(5-hydroxymethyl-2-furyl)selenolo[3,2-c]pyrazole derivatives as
new anticancer agents. Eur J Med Chem 45:1395–1402
Christodoulou MS, Liekens S, Kasiotis KM, Haroutounian SA (2010)
Novel pyrazole derivatives: synthesis and evaluation of anti-
angiogenic activity. Bioorg Med Chem 18:4338–4350
Cozzi P (2003) The discovery of a new potential anticancer drug: a
case history. Farmaco 58:213–220
Daidone G, Maggio B, Raffa D, Plescia S, Schillaci D, Raimondi MV
(2004) Synthesis and in vitro antileukemic activity of new
4-triazenopyrazole derivatives. Farmaco 59:413–417
Denizot F, Lang R (1986) Rapid colorimetric assay for cell growth
and survival. Modifications to the tetrazolium dye procedure
giving improved sensitivity and reliability. J Immunol Methods
89:271–277
Kemnitzer W, Jiang S, Wang Y, Kasibhatla S, Crogan-Grundy C,
Bubenik M, Labrecque D, Denis R, Lamothe S, Attardo G,
Gourdeau H, Tseng B, Drewe J, Cai SX (2008) Discovery of
4-aryl-4H-chromenes as a new series of apoptosis inducers using
a cell- and caspase-based HTS assay. Part 5. Modifications of the
2- and 3-positions. Bioorg Med Chem Lett 18:603–607
Kim DSHL, Ashendel CL, Zhou Q, Chang CT, Lee E-S, Chang CJ
(1998) Novel protein kinase c inhibitors: a-terthiophene deriv-
atives. Bioorg Med Chem Lett 8:2695–2698
Kueng W, Silber E, Eppenberger U (1989) Quantification of cells
cultured on 96-well plates. Anal Biochem 182:16–19
Lee ER, Kang YJ, Choi HY, Kang GH, Kim JH, Kim BW, Han YS,
Nah SY, Paik HD, Park YS, Cho SG (2007) Induction of
apoptotic cell death by synthetic naringenin derivatives in human
lung epithelial carcinoma A549 cells. Biol Pharm Bull 30:
2394–2398
Leite ACL, da Silva KP, de Souza IA, de Araujo JM, Brondani DJ
(2004) Synthesis, antitumor and antimicrobial activities of new
peptidyl derivatives containing the 1,3-benzodioxole system. Eur
J Med Chem 39:1059–1065
Ding X-L, Meng N, Xia Y, Wang L-J, Zhang X-F, Zhao B-X, Miao
J-Y (2007) Synthesis of 3-phenyl-1-[(aryl)methyl]-1H-pyrazole-
5-carboxylic acid ethyl ester derivatives and determination of
their activity as promoters of cell apoptosis. Youji Huaxue
27:1542–1546
El-Shafei A, Fadda AA, Khalil AM, Ameen TAE, Badria FA (2009)
Synthesis, antitumor evaluation, molecular modeling and quan-
titative structure-activity relationship (QSAR) of some novel
arylazopyrazolodiazine and triazine analogs. Bioorg Med Chem
17:5096–5105
Ertl P, Rohde B, Selzer P (2000) Fast calculation of molecular polar
surface area as a sum of fragment-based contributions and its
application to the prediction of drug transport properties. J Med
Chem 43:3714–3717
Gaston MA, Dias LRS, Freitas ACC, Miranda ALP, Barreiro EJ
(1996) Synthesis and analgesic properties of new 4-arylhydraz-
one 1-H pyrazole [3,4-b]pyridine derivatives. Pharm Acta Helv
71:213–219
Li J, Zhao YF, Zhao XL, Yuan XY, Gong P (2006) Synthesis and
anti-tumor activities of novel pyrazolo[1,5-a]pyrimidines. Arch
Pharm Chem Life Sci 339:593–597
Lian S, Su H, Zhao B-X, Liu W-Y, Zheng L-W, Miao J-Y (2009)
Synthesis and discovery of pyrazole-5-carbohydrazide N-glyco-
sides as inducer of autophagy in A549 lung cancer cells. Bioorg
Med Chem 17:7085–7092
Lipinski CA, Lombardo F, Dominy BW, Feeney PJ (2001) Exper-
imental and computational approaches to estimate solubility and
permeability in drug discovery and development settings. Adv
Drug Deliv Rev 46:3–26
Lv PC, Sun J, Luo Y, Yang Y, Zhu HL (2010) Design, synthesis, and
structure-activity relationships of pyrazole derivatives as poten-
tial FabH inhibitors. Bioorg Med Chem Lett 20:4657–4660
Machado P, Campos PT, Lima GR, Rosa FA, Flores AFC, Bonacorso
HG, Zanatta N, Martins MAP (2009) Experimental and calcu-
lated structural parameters of 5-trihalomethyl-4,5-dihydro-1H-
pyrazole derivatives, novel analgesic agents. J Mol Struct 917:
176–182
Micale N, Zappala M, Grasso S (2002) Synthesis and antitumor
activity of 1,3-benzodioxole derivatives. Farmaco 57:853–859
Mosmann T (1983) Rapid colorimetric assay for cellular growth and
survival: application to proliferation and cytotoxicity assays.
J Immunol Methods 65:55–63
Nagarapu L, Mateti J, Gaikwad HK, Bantu R, Rani MS, Subhashini
NJP (2011) Synthesis and anti-inflammatory activity of some
novel 3-phenyl-N-[3-(4-phenylpiperazin-1yl)propyl]-1H-pyra-
zole-5-carboxamide derivatives. Bioorg Med Chem Lett 21:
4138–4140
Padmaja A, Payani T, Reddy DG, Padmavathi V (2009) Synthesis,
antimicrobial and antioxidant activities of substituted pyrazoles,
isoxazoles, pyrimidine and thioxopyrimidine derivatives. Eur J
Med Chem 44:4557–4566
Pan XH, Liu X, Zhao BX, Xie YS, Shin DS, Zhang SL, Zhao J,
Miao JY (2008) 5-Alkyl-2-ferrocenyl-6,7-dihydropyrazolo[1,5-
GraphPad Prism Version 5.04 for Windows (2010) GS, San Diego.
www.graphpad.com
Gouda MA, Berghot MA, Shoeib AI, Khalil AM (2010) Synthesis and
antimicrobial activity of new anthraquinone derivatives incor-
porating pyrazole moiety. Eur J Med Chem 45:1843–1848
Holst-Hansen C, Bru¨nner N (1998) MTT-cell proliferation assay. In:
Celis JE (ed) Cell Biology: a Laboratory Handbook, 2nd edn.
Academic Press, San Diego, pp 16–18
http://www.molinspiration.com/cgi-bin/properties
http://www.organic-chemistry.org/prog/peo
Hu WP, Yu HS, Chen YR, Tsai YM, Chen YK, Liao CC, Chang LS,
Wang JJ (2008) Synthesis and biological evaluation of thioben-
zanilides as anticancer agents. Bioorg Med Chem 16:5295–5302
Huang S, Lin R, Yu Y, Lu Y, Connolly PJ, Chiu G, Li S, Emanuel SL,
Middleton SA (2007) Synthesis of 3-(1H-benzimidazol-2-yl)-5-
isoquinolin-4-ylpyrazolo[1,2-b]pyridine, a potent cyclin dependent
kinase 1 (CDK1) inhibitor. Bioorg Med Chem Lett 17:1243–1245
123

3118
Med Chem Res (2013) 22:3109–3118
a]pyrazin-4(5H)-one derivatives inhibit growth of lung cancer
A549 cell by inducing apoptosis. Bioorg Med Chem 16:
9093–9100
M (2006) Design and synthesis of a series of novel pyrazolyl-
pyridines as HIF 1-a prolyl hydroxylase inhibitors. Bioorg Med
Chem Lett 16:5687–5690
Reile H, Birnbock H, Bernhardt G, Spruss T, Schonenberger H (1990)
Computerized determination of growth kinetic curves and
doubling times from cells in microculture. Anal Biochem
187:262–267
Riyadh SM, Farghaly TA, Abdallah MA, Abdallah MM, Abd El-Aziz
MR (2010) New pyrazoles incorporating pyrazolylpyrazole
moiety: synthesis, anti-HCV and antitumor activity. Eur J Med
Chem 45:1042–1050
Schenone S, Bruno O, Ranise A, Bondavalli F, Brullo C, Fossa P,
Mosti L, Menozzi G, Carraro F, Naldini A, Bernini C, Manettic
F, Botta M (2004) New pyrazolo[3,4-d]pyrimidines endowed
with A431 antiproliferative activity and inhibitory properties of
Src phosphorylation. Bioorg Med Chem Lett 14:2511–2517
Senaratne SG, Pirianov G, Mansi JL, Arnett TR, Colston KW (2000)
Bisphosphonates induce apoptosis in human breast cancer cell
lines. Br J Cancer 82:1459–1468
Shih SR, Chu TY, Reddy GR, Tseng SN, Chen HL, Tang WF, Wu
MS, Yeh JY, Chao YS, Hsu JT, Hsieh HP, Horng JT (2010)
Pyrazole compound BPR1P0034 with potent and selective anti-
influenza virus activity. J Biomed Sci 17:13–21
Wei F, Zhao B-X, Huang B, Zhang L, Sun C-H, Dong W-L, Shin
D-S, Miao J-Y (2006) Design, synthesis, and preliminary
biological evaluation of novel ethyl 1-(20-hydroxy-30-aroxypro-
pyl)-3-aryl-1H-pyrazole-5-carboxylate. Bioorg Med Chem Lett
16:6342–6347
Wei F, Zhao BX, Dong WL, Hua Z, Shin DS, Wang DW, Xia Y, Ge
YQ (2007) Microwave-assisted rapid and straightforward syn-
thesis of novel 6-(aroxymethyl)-2-aryl-6,7-dihydropyrazolo[5,1-
c][1,4]oxazin-4-one derivatives. Synth Commun 37:4415–4424
Xia Y, Dong Z-W, Zhao B-X, Ge X, Meng N, Shin D-S, Miao J-Y
(2007) Synthesis and structure-activity relationships of novel
1-arylmethyl-3-aryl-1H-pyrazole-5-carbohydrazide derivatives
as potential agents against A549 lung cancer cells. Bioorg Med
Chem 15:6893–6899
Xie YS, Pan XH, Zhao BX, Liu JT, Shin DS, Zhang JH, Zheng LW,
Zhao J, Miao JY (2008) Synthesis, structure characterization and
preliminary biological evaluation of novel 5-alkyl-2-ferrocenyl-
6,7-dihydropyrazolo[1,5-a]pyrazin-4(5H)-one derivatives. J Or-
ganomet Chem 693:1367–1374
Xie Y-S, Zhao H-L, Su H, Zhao B-X, Liu J-T, Li J-K, Lv H-S, Wang
B-S, Shin D-S, Miao J-Y (2010) Synthesis, single-crystal
characterization and preliminary biological evaluation of novel
ferrocenyl pyrazolo[1,5-a]pyrazin-4(5H)-one derivatives. Eur J
Med Chem 45:210–218
Silveira IAFB, Paulo LG, Miranda ALP, Rocha SO, Freita ACC,
Barreiro EJ (1993) New pyrazolylhydrazone derivatives as
inhibitors of platelet aggregation. J Pharm Pharmacol 45:
646–649
Sridhar R, Perumal PT, Etti S, Shanmugam G, Ponnuswamy MN,
Prabavathy VR, Mathivanan N (2004) Design, synthesis and
antimicrobial activity of 1H-pyrazolecarboxylates. Bioorg Med
Chem Lett 14:6035–6040
Stahl E (1969) Thin-layer chromatography. Springer, New York
Tetko IV (2005) Computing chemistry on the web. Drug Discov
Today 10:1497–1500
Tewari AK, Srivastava P, Singh VP, Singh A, Goel RK, Monhan CG
(2010) Novel anti-inflammatory agents based on pyrazole based
dimeric compounds; design, synthesis, docking and in vivo
activity. Chem Pharm Bull 58:634–638
Warshakoon NC, Wu S, Boyer A, Kawamoto R, Renock S, Xu K,
Pokross M, Evdokimov AG, Zhou S, Winter C, Walter R, Mekel
Zhang JH, Fan CD, Zhao BX, Shin DS, Dong WL, Xie YS, Miao JY
(2008) Synthesis and preliminary biological evaluation of novel
pyrazolo[1,5-a]pyrazin-4(5H)-one derivatives as potential agents
against A549 lung cancer cells. Bioorg Med Chem 16:0165–10171
Zheng LW, Wub LL, Zhao BX, Dong WL, Miao JY (2009) Synthesis
of novel substituted pyrazole-5-carbohydrazide hydrazone deriv-
atives and discovery of a potent apoptosis inducer in A549 lung
cancer cells. Bioorg Med Chem 17:1957–1962
Zheng L-W, Li Y, Geb D, Zhao B-X, Liu Y-R, Lv H-S, Ding J, Miao
J-Y (2010) Synthesis of novel oxime-containing pyrazole
derivatives and discovery of regulators for apoptosis and
autophagy in A549 lung cancer cells. Bioorg Med Chem Lett 20:
4766–4770
123
